HXW Avatar DD102 User manual

M
O
D
E
S
E
T

Important Notice
1. The product is powered by lithium polymer battery. Please charge the
product for the first time use.
2. Please practice in the blue area, and do not hit the black part
to prevent the damage of the electronic part.
3. If the product is not used for a long time, the battery inside the product
will discharge slowly. Please charge it every 3 months in order to prevent
battery damage caused by over-discharge.
4. The working temperature of this product is 0-40℃. Please do not use it
in high temperature, sub-zero,and over humid environment to prevent
partial damage of the circuit.
5. This product contains lithium battery, please properly place and handle
when using and discarding.

1
Product Description
USB CHARGING PORT
Please connect the correct charger for DD102.
EARPHONE JACK
Plug the earphone into this jack.
ON-OFF BUTTON/PLAY BUTTON
Long press to turn on/off, short press to open/close the metronome.
MODE
Press this button to choose different modes, metronome mode, TAP tempo mode and counting
mode.
SET BUTTON
The Rhythm, Tempo, Sound, Beat of metronome,volume and limited time of counting can be
adjusted by this button.
PARAMETER ADJUSTMENT BUTTON
Adjust parameters after press SET button, and press these two buttons to adjust tempo directly.
M
O
D
E
S
E
T
BEAT/CHARGING
INDICATOR
HIT REMINDING
MODE
ON-OFF BUTTON/
PLAY BUTTON
SET BUTTON
PARAMETER
ADJUSTMENT BUTTONS
LCD SCREEN
PRACTICE PAD
SPEAKER
EARPHONE JACK
USB CHARGING PORT

2
Operation Instruction
Power On/Off
Long press ON-OFF button to power on or power off. DD102 will turn off
automatically if there is no action in 5 minutes.
Mode
1. Switch Modes
Power on the product, the display will show metronome mode. Short press MODE
button to switch to TAP tempo mode and then switch to counting mode.
2. Operation in each mode
2.1 Metronome Mode
Press ON-OFF button to open/close metronome.
2.1.1 Setting Tempo/Rhythm/Output Volume
Press Parameter Adjustment buttons to adjust Tempo. Short press SET button till
the number of Tempo/Rhythm/Output Volume flashes, then press Parameter
Adjustment buttons to adjust. Press ON-OFF button to confirm.
2.1.2 Setting Sound/Beat/Volume of Metronome(V1)/Volume of Click(V2)
Long press SET button till the number of SOUND flashes, and then short press SET
button, till the number of Beat/V2/V1 flashes. Press Parameter Adjustment buttons
to adjust. Press ON-OFF button to confirm.
2.2 TAP Tempo Mode
Under TAP mode, hit the practice area in a row, the corresponding tempo value of
last 2 times will be displayed. When switch back to metronome mode, the
metronome will work at this Tempo value.
2.3 Counting Mode
Under Counting mode, the count of beat (maximum 999) can be calculated during
the limited time set by the user.
Short press SET button to choose h→m→s, and then press Parameter Adjustment
buttons to adjust. Press ON-OFF button to confirm.
Metronome Mode TAP Tempo Mode Counting Mode

Product Features
Charging Instruction
The pad is with medical silica gel, hardness 45 °. This silica gel has good flexibility
and abrasion resistance, and is a kind of odorless environmental protection material.
The bottom plate adopts high-density plate, with internal bonding strength, ensuring
that the bottom plate is not easy to deformation and damp.Bottom plate and silicone
pad are bonded with fish bone glue, which is environmentally friendly and has strong
adhesion force.
DD102 can be recharged through Micro USD interface. When the icon on the
screen flashes, please recharge it soon.
Note: To ensure the battery life and safety, please use the attached USB cable to
recharge the unit.
Please pay attention the charging voltage is +5V (voltage error range ±5%).
The output current of the power supply should be greater than 500mA.
Specifications
Metronome
The Beat can be tuned from 1 to 8, Tempo can be adjusted from 20 to 240
bpm. 7 kinds of rhythm style. 8 metronome sounds.
Training Mode
Metronome Mode, TAP Tempo Mode, Counting Mode
Dimensions
Diameter: 275mm
Thickness: 27mm
Weight
1.12KG
3
