Hybrid+ PA12B User manual

USER MANUAL
REV A 01-2017
PA12B
www.vivaafrika.co.za
BATTERY POWERED
PORTABLE SYSTEM
MAINTENANCE AND WARRANTY
While we have chosen the best components to make this product as rugged and reliable
as possible, some parts in audio products (potentiometers, faders, switches) are subject
to wear which is a matter of operation cycles, and not of time.
In many cases, malfunction of electro-mechanical parts occurs due to dust
contamination, which may require cleaning of such parts. As the inside of such
parts is not accessible, a common practice is to use cleaning fluids in the shape
of sprays. Please be reminded that many of such fluids contain chemicals which
may wash away the dust but at the same time corrode or damage contact
surface and may cause cosmetic damage to other parts. We hence explicitly
exclude any claims for exchange of damaged part due to mechanical
or chemical impact.
1 YEAR GUARANTEE
PLACEMENT TIPS
Avoid placing loudspeakers in the corners of a room. This increases the low-frequency
output and can cause the sound to be unclear and indistinct.
Avoid placing loudspeakers against a wall. This, too, increases the low frequency
output, though not as much as corner placement. However, if you do need to reinforce
the low frequencies, this is a good way to do it.
Avoid placing the active speakers directly on a hollow stage floor. A hollow stage can
resonate at certain frequencies, causing peaks and dips in the frequency response of
the room. It’s better to place the speakers on a sturdy table or tripod stands.
Position the speakers so the high-frequency drivers are two to four feet above ear level
to the audience to maintain high frequency quality.

PAGE 2PAGE 1
USER MANUAL - PA12B BATTERY POWERED PORTABLE SYSTEM
WELCOME
Congratulations on your purchase of a Hybrid battery powered loudspeaker PA12B,
engineered and designed by Hybrid. The PA12B includes a high-output compression driver,
and 12” woofer.
IMPORTANT SAFETY INSTRUCTIONS
All operating instructions should be read before using this equipment.
To reduce the risk of electrical shock, do not open this unit. There are no replaceable
parts inside. Please refer servicing to a qualified service technician.
This unit should only be cleaned with a damp cloth. Avoid solvents or other
cleaning detergents.
When moving this equipment, it should be placed in its original carton and packaging.
This will reduce the risk of damage during transit.
Do not expose this unit to rain or moisture.
Do not use any spray cleaner or lubricant on any controls or switches.
Make sure all of your equipment is completely off and lower all volume,
level and gain controls before connecting a sound source.
Only line level signals should be sent to your speaker.
Disregarding any of the above will void your warranty!!!!
USER INTERFACE ELEMENTS
Rear Side
1: MP3 Player with USB / SD / Bluetooth
2: Mic In
3: Line Output
4: 3.5mm AUX In
5: RCA Input
6: Mic 1 Level
7: Bass Control
8: Mid Control
9: Treble Control
10: AUX Level
11: MP3 Level: Control the Volume of MP3,
including USB / SD / FM / Bluetooth
12: Master Volume
13: Wireless Level
14: LED Battery Status
15: External Battery
16: Antenna of VHF Wireless Microphone
17: Power Cord Connector - IEC Main Power Cable
250V/3A
18: Power Switch
2
3
16
17
14
13
1
10
11
18
15
12
6
7
8
9
5
FEATURES
2-way amplified active battery speaker.
USB / MP3 / Bluetooth.
Mic / Line input and line out, pass-through connector.
VHF wireless microphone.
Charging battery.
Stand/Pole-mountable.
MP3 PLAYER CONTROLS
MENU MP3 Player
Repeat
Mode Stop / Switch USB / SD / Bluetooth
EQ Equalizer
Folder -Last Folder
Folder +Next Folder
Track Last Music Song
Track Next Music Song
Stop / Player
Bluetooth
