1. Package Contents
HY10000-WK09 integrated writer is a tool for connecting PC to program the chips. As
shown in Figure 1-1, HYCON HY10P/HY11P/HY12P/HY13P/HY15P/HY17P/HY17M series
products can be programmed through the integrated writer, the related hardware is
equipped as shown below:
No.
Model No.
Description
Quantity
HY10000-WK09
1. HY10000-WK09
Integrated Writer
1
2. Cable line
USB Type A to Type B Cable
1
3. Programming line
6pin/2.5(2.5mm pitch)
1
4. Power Supply
Output: DC 5V
1
Figure 1-1
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page5
2. Safety Precautions
Do not place heavy objects on the display panel, in order to avoid damage caused by
stress.
Place the application display boards at steady place, so as to avoid falling damage.
Do not use this product with the input voltage which is not meeting the electrical
specifications, in order to avoid working abnormally or damage.
Avoid application display boards being touched by liquid, dirt and avoid being exposed
to moisture during operation. This application should be kept in a dry environment, so
as not to affect the function and performance.
Remove the power supply when not using it.
When following status occurred, please remove the power supply immediately, and
contact our engineer.
Power Supply line is worn or damaged.
Power source (battery) connected but no any light on while operating.
Component off.
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page6
3. Software Installation Requirements
3.1. Software Installation Requirements
Minimum system configuration required to run the burner application IDE & HexLoader:
(1) PC/NB hardware requirement:
IBM PC compatible X86 system CPU
512MB memory (1GB recommended)
1GB Hard disk
(2) Supported Products:
HY10P/11P/12P/13P/15P/16F/17P/HY17M series products
(3) Supported Hardware Model No.:
HY10000-WK09 writer kit
(4) Supported software version:
Support 8bit OTP IDE’s software version
HYCON 8bit Writer V1.0.4(including) above
HY16F Writer V3.9.2(including) above
(5) Supported Operating system:
Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
(6) Apply the following interface modes:
USB Port with "HID-compliant device"
The HY10000-WK09’s USB Port driver uses the Windows standard
"HID-compliant device" (Figure 3-1), there is no need to install another USB driver.
Figure 3-1
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page7
3.2. Hardware online automatic update
HY10000-WK09 integrated writer supports HY10P/11P/12P/13P/15P/16F/17P/HY17M
series products. Each time the internal firmware is converted, it is only applicable to one
series of products. Before switching between different firmware, you can check the current
firmware supported writer through the "information 1" message.
The integrated writer needs to cooperate with the download software, which can
automatically convert the internal firmware of the burner to support the burning of different
series of products. The usage methods are as follows:
3.2.1 Automatically convert firmware with HYCON 8bit Writer
Connect the integrated writer to the computer via a USB cable,
open software , the interface will be shown in Figure 3-2,
click "Chip Type" and click "Load"load the corresponding HEX file, then click the
"Download to Burner" button, the software will detect the firmware version of the
burner, if it does not support the current chip, it will be automatically upgraded, as
shown in Figure 3-3.
Figure 3-2
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page8
Figure 3-3
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page9
3.2.2 Automatically convert firmware with HY16F Writer
Connect the integrated writer to the computer via a USB cable, open the software
, as shown in Figure 3-4, select "Connect Burner Only" in the Connect
drop-down box, and select the chip model in the pop-up selection dialog box. At this time,
the software will detect the burner Firmware version, if the current chip is not supported, an
upgrade dialog box will pop up, select "Yes (Y)" to automatically upgrade, as shown in
Figure 3-5.
Figure 3-4
Figure 3-5
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page10
3.3. Hardware online manual update
The integrated writer also supports online manual firmware conversion to support the
burning of different series of products. Currently, only the manual conversion of HY16F
firmware is supported. The usage methods are as follows:
Connect the integrated programmer to the computer via a USB cable. Then open the
software , click the "Function" button in the upper right corner of the software,
and select "Update Firmware" in the drop-down box. And selecting the chip model, clicking
"Update" will automatically Upgrade, as shown in Figure 3-6.
Figure 3-6
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page11
4. Writer Architecture
4.1. Architecture Description
The integrated writer can perform programming and other functions through the PC
connection (as shown in Figure 4-1). For details, please refer to the Development
Tools-Hardware Manual (http://www.hycontek.com/).
TypeA to TypeB USB Cable
Writer Software
Programming
Pin
WK09 Writer Kit
HYCON IC
Figure 4-1
4.2. Appearance introduction
The integrated writer is a tool for programming chips, It’s can be programmed
HY10P/11P/12P/13P/15P/16F/17P/HY17M series products through the integrated writer,
as shown in Figure 4-2.
TFT LCD
S3 S2 S1 L2L3L4
J5
J7
J3
J11
Figure 4-2
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page12
4.3. Operating instructions
The following table shows the description of each device:
Item
Descriptions
J5
USB
USB Connector:
It is also a 5V power supply port that can be connected with the PC, and
through the USB port, the Hex & Bin code to be programmed can be
downloaded through USB port for HY10P/11P/12P/13P/15P/16F/17P/HY17M
series products.
J7
Program
Programming Control Port:
The port is connected to the chip’s programming pins, and support 8-bit and
32-bit (HY16F series) MCU product.
The programming pins are shown in Figure 4-3a.
8-bit OTP MCU dedicated programming pin:
VPP, PSCK, PSDI, PSDO, VDD, VSS
8-bit MTP MCU dedicated programming pin
VDD, ECK, EDIO, PCAL, NC, VSS
HY16F dedicated programming pin
RST, ECK, EDIO, NC, VDD, VSS
VSS
VPP
PSCK
VDD
PSDO
PSDI
Program
OTP
MCU
VSS
VDD
ECK
NC
PCAL
EDIO
MTP
MCU
VSS
RST
ECK
VDD
NC
EDIO
FLASH
MCU
1
2
3
4
5
6
J7
Figure 4-3a
J3
TPS calibration extension port: It’s a temperature Sensor module interface.
J3 is dedicated to 8-bit MCU, and its main function is to calibrate the built-in
temperature sensor TPS. Users can connect an external temperature sensor
module board to J3 for TPS calibration. The functions of each pin are described
as follows:
Pin
Name
Descriptions
1
SCL
I2C communication clock pin
2
SDA
I2C communication data pin
3
VDD
3V3 power supply
4
VSS
ground pin
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page13
J11
Handler
Handler extension programming control port:
Users can connect to the semi-automatic programming machine or connect
external buttons and indicators (refer to Figure 4-3b) to achieve extended
programming control according to the defined functions of each pin. The
functions of each pin are described as follows:
Program
Blank
Error
OK
Busy
VDD
L2
L3
L4
VSS
S1
NC
S2
Handler
1
2
3
4
5
6
7
8
J11
Figure 4-3b
The timing diagram of automatic programming control signal, the programming
is successful as shown in Figure 4-3c
3.3V
0V
3.3V
0V
3.3V
0V
3.3V
0V
Program
(S1)
OK
(L2)
Error
(L3)
Busy
(L4)
T1
Figure 4-3c
Pin
Name
Descriptions
1
NC
NC
2
VSS
Ground pin
3
VDD
Integrated Writer 3V/150mA power output pin
4
Busy
Burning busy status pin : Normal High, active Low
5
Program
Chip blank control status pin (built-in pull-up resistor):
active Low
6
Blank
Chip blank status pin (built-in pull-up resistor):active
Low
7
OK
Burning success status pin : Normal High, active Low
8
Error
Burning error status pin : Normal High, active Low
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page14
The timing diagram of the automatic programming control signal, the
programming fails as shown in Figure 4-3d
3.3V
0V
3.3V
0V
3.3V
0V
3.3V
0V
Program
(S1)
OK
(L2)
Error
(L3)
Busy
(L4)
T1
Figure 4-3d
T1: Program "external trigger" low pulse, 10ms < T1
The usage instructions are as follows:
1) Input a low pulse in the Program Pin to start programming, as shown in T1 in
the above figure (this action is equivalent to After pressing the Program (S1)
programming button).
2) The OK(L2) Pin can be continuously inquired. If the pulse changes from high
pulse to low pulse, as shown in Figure 4-3c above, it means the programming
is successful.
3) The Error(L3) Pin can be continuously inquired. If the pulse changes from
high pulse to low pulse, as shown in Figure 4-3d above, it means that the
programming fails.
L2
Action success indicator (OK LED):
Programming success message indicator.
L3
Action failure indicator (Error LED):
This message indicator will be on in case of programming failure, blank
checking failure and HAO frequency calibration failure.
L4
Busy message indicator (Busy LED):
When the Writer is programming, this message indicator will be on.
S1
Program:
Chip programming button.
S2
Blank Check:
Chip blank checking button(HY16F product has no this function).
S3
Information:
Information inquiry button of the Writer.
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page15
4.4. Description of Writer Characteristics
No
Item
Description
1
Model of Writer
HY10000-WK09
2
Supporting chip Model
HY10P/11P/12P/13P/15P/16F/17P/HY17M Series
3
Power on self-check
mechanism
High
4
Programing times counting
support
5
Hardware calibration
function of chip frequency
support
6
Software calculation function
of chip frequency difference
HAO and LPO (8-bit OTP MCU only)
7
“Auto button”function
Blank, Program, Verify
8
LED light display
(L2 / L3 / L4)
Green LED(L2), Red LED(L3), Yellow LED(L4)
9
Programming software
support version
HYCON 8bit Writer V1.0.4 (inclusive) or above
HY16F Writer V3.9.2 (inclusive) or above
It can be used with HY10000-WK09 burner to download
the compiled HEX code
into the programmer, and then the programmer can
perform online or offline programming to IC.
Notice:
1. Supported chip model: HY10000-WK09 can program HY10P/11P/12P/13P/15P
/16F/17P/HY17M Series chips.
2. Program self-checking mechanism at startup: HY10000-WK09 is a high-level self
checking mechanism at startup to ensure the correctness of data, when power on, it
will check whether the code to be programmed is correct or not and Checksum is
correct or not, therefore, the LCM screen will display "Verifying…. " string, If the check
is passed, the "HYCON IDE" string will appear to ensure the correctness of the data,
which means that the Writer can be started; if the check fails,
the "Verify error 6" string will appear, which means that the code to be
programmed is not correct, and the code to be programmed must be
downloaded again.
3. Allowed chip programming times: HY10000-WK09 supported.
4. Auto button function: HY10000-WK09 automatic programming sequence is Blank →
Program →Verify.
5. LED lights: Green(L2)/Red(L3)/Yellow(L4) light of HY10000-WK09 respectively
represents OK / Error / Busy. when the L4(Busy) message indicator is on during the
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page16
programming process, the L4(Busy) message indicator is off after the programming is
completed. When light L2 (OK) is on, it means that the programming is successful, and
when light L3 (Error) is on, it means that the programming has failed or the HAO
frequency calibration has failed.
4.5. Cautions
1. If the HY10000-WK09 Writer displays
Error 6
Verify Fail!
at the first time of startup, it is caused
by the code to be programmed has not been downloaded to the flash of the Writer, not
because the Writer is damaged, so the user does not need to pay attention to this error
message.
2. When HY10000-WK09 Writer use the "limit programming times" function, assuming
that the programming times are used up, pressing the "Program" button will display
Error 8
Program Count=0
and cannot program, pressing the "Information" button will display
"Information 2": program counter enable left 00000000".
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page17
4.6. Program burning instructions
When the user enters the full production stage from the development stage. The
integrated writer can be used programming without connecting to the PC.
TFT LCD
S3 S2 S1 L2L3L4
J5
J7
J3
J11
(Please refer to chapter 4.3 for the description of each device)
The following table describes the functions of the LED indicators and buttons:
NAME
Function
L2
Power-on indicator light (Green).
Burning success message indicator light.
L3
Blank Check Fail indicator light (Red).
Burning failure message indicator light.
HAO frequency calibration failure indicator light.
L4
Busy indicator light (Yellow).
S1
Program Verify; Chip programming button.
S2
Blank Check; Chip blank check button.
S2
Information; Chip information check button.
For offline operation, you need to download the programming code (HEX or BIN file) to
the Flash Memory of the writer first. Please refer to the instruction manual of the
programming software of each product.
When offline programming, press the button S2 (Blank) to check whether the chip is
empty. After checking, at the moment, the L2 (OK) should be light up.
Button S1 (Program) is the chip programming button, and the steps are
ProgramVerify. Then the L4 (Busy) indicator light is light up. If want to checked
"Programming Protection" in "Assembly Options" before Downloading to Flash
Memory, the programming protection will be executed after Verify; if it is not check
mark, it will be stop after Verify. After programming is completed, L4 (Busy) will be light
off, and L2 (OK) will be light up.
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page18
After the programming is completed, you can press the button S2 (Blank) to check
whether the chip is empty again. At the moment, the L3 (Error) should be light up,
indicating that the programming is completed (because the programming code has
been programmed into the IC, so Blank Check Fail).
It is recommended to press S2 (Blank) to check for an empty chip before programming,
and then press S1 (Program) to perform programming to ensure correct programming.
If there is any error or failure in the execution, the L3 (Error) will be light up; if it is
successful, the L2 (OK) will be light up.
.

HY10000-WK09
Integrated Writer User’s Manual
© 2022 HYCON Technology Corp
www.hycontek.com
APD-HYIDE020-V01_EN
page19
5. Revisions
The following describes the major changes made to the document, excluding the font and
punctuation changes.
Version
Page
Date
Revision Summary
V01
All
2022/10/5
First edition
.
