HydraMaster Titan 875 User manual

Titan 875
Owner’s Manual
HydraMaster
11015 47th Avenue West
Mukilteo, Washington 98275
MAN-33180 Rev. 0 March 23, 2012
(182-077-D)
No part of this manual may be reproduced or used in any form or by any means (i.e. graphic, electronic, photocopying or electronic
retrieval systems) without the express written permission of HydraMaster. Specications and information in this document are
subject to change without prior notice. All rights reserved. © 2012 HydraMaster

i: Titan 875 Owner’s Manual
This document contains QR (Quick Response) tags, or
codes, like that shown in the illustration on this page.
QR tags can be scanned by smartphones or mobile
devices in which QR readers have been downloaded.
WHY USE QR TAGS
QR tags shown throughout this document contain links to
HydraMaster webpages or videos which explain specic
instructions for machine operations, maintenance or
troubleshooting.
One advantage of QR tags is that you do not need a
computer to access webpages or online videos. Also,
no typing is required; just select the QR reader, aim the
smartphone’s viewnder at the QR tag and select how to view the webpage or video.
To learn more about QR tags, access this link:
http://searchengineland.com/what-is-a-qr-code-and-why-do-you-need-one-27588
INSTRUCTIONS
Download a QR tag reader from an app store or install the QR reader from this1. link:
http://www.i-nigma.com/Downloadi-nigmaReader.html
Follow instructions depending on whether you have a smartphone or a standard
2. mobile device.
Scan the QR tag with your smartphone or mobile phone, and view the webpage or
3. watch the video.
Links to other QR readers include:
http://reader.kaywa.co• m/
http://get.neoreader.co
• m
http://www.beetagg.com/supportedphones
• /
http://code.google.com/p/zxing/wiki/GettheReade
• r
http://www.
youtube.com/user/
HydraMasterProducts#g/a

Titan 875 Owner’s Manual: ii

iii: Titan 875 Owner’s Manual
Table of Contents
GENERAL INFORMATION........................................................................... SECTION 1
System Concept......................................................................................1-3
Contact Information.................................................................................1-4
Warnings, Cautions and Notices.............................................................1-5
Responsibilities.......................................................................................1-9
Machine Specications ........................................................................... 1-12
Spare Parts List.......................................................................................1-14
High Altitude Operation...........................................................................1-15
Local Water Precautions.........................................................................1-15
INSTALLATION INFORMATION .................................................................. SECTION 2
Fuel Pump Installation Guidelines...........................................................2-1
Operating the Titan 875 In Hot Weather ................................................. 2-4
Setting Up the Titan 875..........................................................................2-7
CLEANING AND CHEMICALS..................................................................... SECTION 3
Preparing the Carpet for Extraction.........................................................3-2
Rinse and Recover..................................................................................3-3
Overwetting.............................................................................................3-3
Streaking.................................................................................................3-3
Cleaning Tool Tips................................................................................... 3-4
Severe Cleaning Situations.....................................................................3-9
MACHINE MAINTENANCE..........................................................................SECTION 4
Operational Maintenance........................................................................4-2
Overall Machine Maintenance.................................................................4-5
Engine Maintenance ............................................................................... 4-6
High Pressure Pump Maintenance ......................................................... 4-10
Vacuum System Maintenance.................................................................4-19
Descaling Procedure (Required).............................................................4-20
Freeze Guarding.....................................................................................4-21
OPERATING INSTRUCTIONS.....................................................................SECTION 5
Start-Up Procedure.................................................................................5-3
Shut-Down Procedure.............................................................................5-5
Setting the Temperature.......................................................................... 5-7
Machine Safeties.....................................................................................5-8
WATER AND CHEMICAL SYSTEM .............................................................SECTION 6
Water and Chemical Flow Operation ...................................................... 6-1

Titan 875 Owner’s Manual: iv
ELECTRICAL SYSTEM................................................................................SECTION 7
TROUBLESHOOTING ................................................................................. SECTION 8
Heating System.......................................................................................8-2
Chemical System....................................................................................8-3
Engine.....................................................................................................8-4
High Pressure System ............................................................................ 8-7
Vacuum System......................................................................................8-9
MACHINE ASSEMBLIES AND PARTS LISTS .............................................SECTION 9
Machine Assembly Parts List..................................................................9-6
Frame Assembly Parts List .....................................................................9-9
Engine Assembly Parts List.....................................................................9-13
Solenoid Assembly Parts List..................................................................9-14
Idler Pulley Tensioner Assembly Parts List ............................................. 9-15
Blower Assembly Parts List.....................................................................9-18
Air Actuator Assembly Parts List............................................................. 9-19
Pump and Silencer Assembly Parts List ................................................. 9-20
Pump Assembly Parts List ...................................................................... 9-23
Exhaust Assembly Parts List...................................................................9-25
Blower Heat Exchanger Assembly Parts List..........................................9-28
Coolant Heat Exchanger Assembly Parts List.........................................9-30
Lower Instrument Panel Assembly Parts List..........................................9-34
PSI Regulator Valve (0 - 3,200 psi) Assembly Parts List ........................9-35
Orice Manifold Assembly Parts List.......................................................9-36
Hi Pressure Out Manifold Assembly Parts List........................................9-37
3-Way Valve Assembly Parts List............................................................ 9-38
2-Way Valve Assembly Parts List............................................................ 9-39
Water Box 8 Gallon Assembly Parts List.................................................9-41
DiffuserAssembly Parts List ................................................................... 9-42
Upper Dash Assembly Parts List.............................................................9-43
Dash Gauge Panel Assembly Parts List ................................................. 9-45
Grill Assembly Parts List .........................................................................9-46
Electrical Panel Assembly Parts List.......................................................9-48
Catalytic Cover Assembly Parts List ....................................................... 9-50
Top Cover - Machine Assembly Parts List............................................... 9-52
Left Side Cover - Machine Assembly Parts List......................................9-53
Right Side Cover - Machine Assembly Parts List....................................9-54
100 Gallon Universal Recovery Tank Assembly Parts List...................... 9-56
100 Gallon Universal Recovery Cover Tank Assembly Parts List........... 9-58
Vacuum Relief Valve Assembly Parts List...............................................9-59
Machine Hose Routings..........................................................................9-60

v: Titan 875 Owner’s Manual
HOW TO ORDER PARTS............................................................................ SECTION 10
Warranty Parts Orders ............................................................................ 10-1
Parts Orders............................................................................................10-1
Emergencies...........................................................................................10-1
WARRANTY INFORMATION....................................................................... SECTION 11
Blower ....................................................................................................11-2
High Pressure Water Pump ...................................................................11-2
Vacuum Tank ..........................................................................................11-2
Chemical System ...................................................................................11-2
Control Panel .........................................................................................11-2
Vacuum and Solution Hoses ..................................................................11-3
Cleaning Wand ....................................................................................... 11-3
Water Heating System ...........................................................................11-3
Hard Water Deposits ..............................................................................11-3
Warranty Procedure................................................................................11-3
ACCESSORIES AND CHEMICAL SOLUTIONS.......................................... SECTION 12

Titan 875 Owner’s Manual: vi
List of Figures
Figure 1-1. Hard Water Map of Continental United States..........................................1-16
Figure 2-1. Fuel Pump Diagram....................................................................................2-2
Figure 2-2. Location of Roof Vents in Vehicle ...............................................................2-3
Figure 2-3. Recommended Location of Titan 875 in Van ..............................................2-5
Figure 4-1. Remove Valve Cap and Valve Assembly.................................................4-11
Figure 4-2. Inspect Manifold and Old Valves.............................................................4-11
Figure 4-3. Replace Center Inlet Check Valve With Modied Check Valve.............. 4-12
Figure 4-4. Apply Grease and Install Valves.............................................................. 4-12
Figure 4-5. Replace Valve Cap and Torque to 95 ft lbs............................................. 4-12
Figure 4-6. Separate Manifold from Crankcase......................................................... 4-13
Figure 4-7. Seal Assemblies May Come Off with Manifold........................................ 4-13
Figure 4-8. Examine Ceramic Plungers..................................................................... 4-13
Figure 4-9. Remove Stainless Steel Plunger Bolt and Ceramic Plunger ................. 4-14
Figure 4-10. Install O-ring, Apply Sealant and Slide Plunger over Plunger Guide .... 4-14
Figure 4-11. Extract Retainers and Seals.................................................................. 4-15
Figure 4-12. Seal Kit and Insertion Tool for Seal Installation..................................... 4-16
Figure 4-13. Install Seal Assembly Using O-Ring Grease......................................... 4-16
Figure 4-14. Install Retainers into Cavities................................................................ 4-17
Figure 4-15. Press Low Pressure Seal Assembly into Cavity.................................... 4-17
Figure 4-16. Re-install Manifold and Torque Fasteners............................................. 4-18
Figure 4-17. Torque Sequence in “X” Pattern............................................................ 4-18
Figure 4-18. Torque Bolts to 22 ft lbs......................................................................... 4-18
Figure 4-19. Recirculation Fitting............................................................................... 4-20
Figure 5-1. Titan 875 Upper Dash Assembly.................................................................5-1
Figure 5-2. Titan 875 Lower Dash Assembly.................................................................5-2
Figure 5-3. Blower Port Located on Lower Dash Assembly..........................................5-5
Figure 5-4. Set Heat Selector Valve..............................................................................5-7
Figure 5-5. Rotate Thermostat Dial and Select Engine rpm..........................................5-7
Figure 6-1. Flow Diagram - View 1 of 3.........................................................................6-3
Figure 6-2. Flow Diagram - View 2 of 3.........................................................................6-4
Figure 6-3. Flow Diagram - View 3 of 3.........................................................................6-5

vii: Titan 875 Owner’s Manual
Figure 7-1. Electrical Schematic....................................................................................7-2
Figure 7-2. Wiring Diagram - View 1 of 3 ......................................................................7-3
Figure 7-3. Wiring Diagram - View 2 of 3 ......................................................................7-4
Figure 7-4. Wiring Diagram - View 3 of 3 ......................................................................7-5
Figure 7-5. Schematic of Wire Harness -
Fuel Pump Manifold to Machine - View 1 of 2....................................................7-6
Figure 7-6. Schematic of Wire Harness -
Fuel Pump Manifold to Machine - View 2 of 2....................................................7-7
Figure 9-1. Machine Assembly - View 1 of 4.................................................................9-2
Figure 9-2. Machine Assembly -View 2 of 4..................................................................9-3
Figure 9-3. Machine Assembly - View 3 of 4.................................................................9-4
Figure 9-4. Machine Assembly -View 4 of 4 .................................................................9-5
Figure 9-5. Frame Assembly - View 1 of 2 ....................................................................9-7
Figure 9-6. Frame Assembly - View 2 of 2 ....................................................................9-8
Figure 9-7. Engine Assembly - View 1 of 3..................................................................9-10
Figure 9-8. Engine Assembly - View 2 of 3..................................................................9-11
Figure 9-9. Engine Assembly - View 3 of 3..................................................................9-12
Figure 9-10. Solenoid Assembly..................................................................................9-14
Figure 9-11. Idler Pulley Tensioner Assembly..............................................................9-15
Figure 9-12. Blower Assembly - View 1 of 2................................................................9-16
Figure 9-13. Blower Assembly - View 2 of 2................................................................9-17
Figure 9-14. Air Actuator Assembly .............................................................................9-19
Figure 9-15. Pump and Silencer Assembly .................................................................9-20
Figure 9-16. Pump Assembly - View 1 of 2 .................................................................9-21
Figure 9-17. Pump Assembly - View 2 of 2 .................................................................9-22
Figure 9-18. Exhaust Assembly...................................................................................9-24
Figure 9-19. Blower Heat Exchanger Assembly - View 1 of 2.....................................9-26
Figure 9-20. Blower Heat Exchanger Assembly - View 2 of 2.....................................9-27
Figure 9-21. Coolant Heat Exchanger Assembly.........................................................9-29
Figure 9-22. Lower Instrument Panel Assembly - View 1 of 3.....................................9-31
Figure 9-23. Lower Instrument Panel Assembly - View 2 of 3.....................................9-32
Figure 9-24. Lower Instrument Panel Assembly - View 3 of 3.....................................9-33
Figure 9-25. PSI Regulator Valve (0 - 3,200 psi) Assembly .......................................9-35
Figure 9-26. Orice Manifold Assembly.......................................................................9-36
Figure 9-27. Hi Pressure Out Manifold Assembly........................................................9-37
Figure 9-28. 3-Way Valve Assembly............................................................................9-38
Figure 9-29. 2-Way Valve Assembly............................................................................9-39

Titan 875 Owner’s Manual: viii
Figure 9-30. Water Box 8 Gallon Assembly.................................................................9-40
Figure 9-31. DiffuserAssembly ...................................................................................9-42
Figure 9-32. Upper Dash Assembly.............................................................................9-43
Figure 9-33. Dash Gauge Panel Assembly .................................................................9-44
Figure 9-34. Grill Assembly .........................................................................................9-46
Figure 9-35. Electrical Panel Assembly.......................................................................9-47
Figure 9-36. Catalytic Cover Assembly .......................................................................9-49
Figure 9-37. Top Cover - Machine Assembly...............................................................9-51
Figure 9-38. Left Side Cover - Machine Assembly......................................................9-53
Figure 9-39. Right Side Cover - Machine Assembly....................................................9-54
Figure 9-40. 100 Gallon Universal Recovery Tank Assembly......................................9-55
Figure 9-41. 100 Gallon Universal Recovery Tank Cover Assembly...........................9-57
Figure 9-42. Vacuum Relief Valve Assembly...............................................................9-59

1-1: General Information
1- General Information
The Titan 875 truckmount carpet cleaning and restoration machine is powered by the 61
HP GM 4-cylinder, fuel injected engine and the Tuthill Competitor Plus™ 5009 Tri-Lobe
dual oil bath blower.
For superior carpet and upholstery cleaning, the Titan 875 provides temperatures up
to 270° F at 1,200 psi *. It also provides non-heated pressure washing at 3,000 psi for
cleaning hard surfaces.
* Patented Heat Exchanger System - U.S. Patent No. 8,032,976

General Information: 1-2
The Titan 875 also features:
a simple 3-panel maintenance access• keyless ignition• last-step chemical injection which reduces scale buildup•
Standard equipment includes:
100 Gallon MaxAir™ Recovery Tank
• 5 gallon chemical jug• 150 ft long, 2” diameter vacuum hose• 150 ft long, 1/4” diameter solution hose•
Optional pieces of equipment available are:
Dura-Flow™ Automatic Pump Out (APO)
• 2.5” adaptor kit for triple wand capability•
It is the purpose of this manual to help you properly understand, maintain and service
the Titan 875. By following these guidelines carefully, you can expect years of reliable
operation.
Other topics covered in this section of the manual are:
Contact Information
Warnings, Cautions and Notices
Responsibilities
Machine Specications
Spare Parts List
High Altitude Operation
Local Water Precautions

1-3: General Information
SYSTEM CONCEPT
The Titan 875’s system utilizes an internal combustion engine to provide the power
necessary to turn both the vacuum blower and the high pressure water pump.
The heat from the engine and blower exhausts is transferred to the high pressure water
in the nned tube heat exchanger and copper tube and shell of the system. Finally, the
chemical is injected into the pressurized water stream and the heated solution is delivered
to the cleaning tool.
Solution is recovered by the vacuum generated by the vacuum blower and is collected in
the recovery tank for proper disposal.
Engine
Vacuum
Blower
Water
Pump
Finned Tube
Heat Exchanger
Water Box
Silencer

General Information: 1-4
CONTACT INFORMATION
If you have any questions regarding the operation, maintenance or repair of this machine,
please contact your local distributor.
To nd a local distributor, please visit our website at
http://hydramaster.com/HowToBuy/DealerLocator.aspx
If your question cannot be resolved by your distributor or by the information within
the Owner’s Manual, you may contact HydraMaster direct using the following phone
numbers.
HOURS TELEPHONE NUMBERS E-MAIL ADDRESSES
Monday-Friday
7:00 a.m. to 5:00 p.m.
Pacic Standard Time
Technical Support
[phone]
FAX : [phone]
Technical Support
[e-mail]
Customer Service/Parts
[phone]
FAX: [phone]
Customer Service/Parts
[e-mail]
When calling your distributor, be sure to reference the serial number and date of
purchase.
FOR YOUR REFERENCE:
Serial No. ____________________________________________________
Date of Purchase: _____________________________________________
Purchased From (Distributor): ____________________________________

1-5: General Information
WARNINGS, CAUTIONS AND NOTICES
HydraMaster uses this WARNING symbol throughout the manual to warn of
possible injury or death.
This CAUTION symbol is used to warn of possible equipment damage.
This NOTICE symbol indicates that federal or state regulatory laws may apply,
and also emphasizes supplemental information.

General Information: 1-6
Warnings and Cautions specic to the Titan 875 include the following:
During the operation of the truckmount many components are in motion. Never
touch any part of the truckmount that is in motion. Serious injury may result.
During the operation of the truckmount many surfaces will become extremely hot.
Never touch hot surfaces. Serious injury may result.
The operation of this truckmount can produce noise levels exceeding 85 decibels
to a distance of 10 ft. The Occupational Safety and HealthAdministration (OSHA)
recommends the use of hearing protective equipment if a person is exposed
to an average of 85 decibels over an 8-hour period. Check with local and state
agencies concerning hearing conservation rules.
During the operation of the truckmount carbon monoxide and other toxic fumes
are produced. Position the vehicle so that any fumes produced will be directed
away from inhabited areas and any points of building entry (doors, windows, air
conditioning units, fans, etc.). Do not occupy the vehicle while the truckmount is
in operation. Serious injury may result.
Duringthe operation of the truckmount, chemicals knownto the Stateof California
to cause cancer, birth defects and other reproductive harm are produced by the
engine exhaust.
Never operate the truckmount with a portable gas container inside the vehicle.
Doing so will increase the risk of re and explosion. Serious injury or death may
result.

1-7: General Information
Transportingaventedfuelcontainerthatpresentlycontains,orhasevercontained
in the past, a ammable liquid is strictly forbidden by HydraMaster and by federal
and state regulations. Doing so will increase the risk of re and explosion. Serious
injury or death may result.
Never smoke in or around the truckmount. Doing so will increase the risk of re
and explosion. Serious injury or death may result.
During the operation of the truckmount the exhaust system will become extremely
hot. Keep all ammable materials away from the truckmount exhaust system.
Failure to do so will increase the risk of re and explosion. Serious personal injury
and property damage may result.
Never operate the truckmount when the vehicle is tilted more than 10 degrees in
anydirection.Doingsowillresultinimproperlubricationoftheinternalcomponents,
and will increase the risk serious component or engine damage.
Never perform cleaning operations when the truckmount engine is running at the
IDLE throttle position. Failure to do so will increase the risk of serious component
or engine damage.
Never operate the truckmount with the vehicle doors closed. Doing so results in
extremelyhightemperaturesinsidethevehicleandwillleadtoseriouscomponent
or engine damage.
Neveruseconcentratedacidsorsolvents(includingd-limonene)inthetruckmount
water system or chemical system. Use of these products will cause serious
component damage.

General Information: 1-8
Never operate the truckmount with a water hardness reading measuring 3.0
grains per gallon or higher. Using reading than 3.0 grains per gallon will cause
scale to build up inside the truckmount water system. Scale build up causes
serious component damage. Test all water prior to use and use water softening
equipment if necessary.
Never allow water to freeze inside the truckmount. Serious component damage
will occur. Perform all freeze guarding procedures as outlined in Section 4 of this
Owner’s Manual.
Many vehicles have critical components mounted directly below the oor that
can easily be damaged. Before drilling holes in the oor of the vehicle inspect
the underside of the vehicle for critical components. Failure to do so may result
in damage to the vehicle.
Use of the vacuum recovery system when stripping or otherwise removing wax
from oors is specically excluded as an approved use of the truckmount. Failure
to follow this exclusion may lead to component failure and will invalidate your
warranty.
Use of the vacuum recovery system for “dry cleaning”, without corresponding
solution application (i.e. duct cleaning), is specically excluded as an approved
use of the truckmount. Failure to follow this exclusion may lead to component
failure and will invalidate your warranty.
If concentrated acids or solvents are used to pre-treat surfaces before power
washing, do not recover them through the vacuum system. Failure to follow this
exclusion may lead to component failure and will invalidate your warranty.

1-9: General Information
RESPONSIBILITIES
Purchaser’s Responsibilities
Prior to purchasing a van, ensure that the payload is suitable for all of the equipment• that willbeinstalledandtransported.Thisincludesandisnotlimitedto:thetruckmount,
recovery tanks, fresh water tanks, on-board water, hose reels, hoses, cleaning tools,
chemicals and drying equipment. Payload capacity information is available through
the auto dealer, the manufacturer’s web site, and is also located on the door pillar of
the driver’s side door.
Purchase a heavy duty Group 24 (500+ CC Amps) battery for this truckmount. This is
• normally available from the installation dealer.
Prior to dropping your van off at the distributor for the truckmount to be installed, have
•
a spray-on bed liner applied to the oor such as Rhino Lining® or Line-X®.
Plywood and carpet are not recommended.
Prior to operating the truckmount, read this manual in its entirety and familiarize• yourself with the information contained here. Special attention should be paid to all
Warnings and Cautions.
The distributor is responsible for the correct installation of the truckmount. The
• distributor is also responsible to train you in the correct and proper operation and
maintenance of the truckmount.
Any modication of the truckmount may void the warranty.

General Information: 1-10
Distributor’s Responsibility
Acceptance of Shipment
Before accepting the truckmount, check the following:
The truckmount should be free from any damage during shipping. Do not sign the1. delivery receipt until you have closely inspected the truckmount and noted any
damageonthedeliveryreceipt.Hiddendamagemaybepresenteveniftheboxlooks
okay. It is recommended that the box be opened before you sign for the shipment.
Check the packing list and verify that all items are accounted for.
2.
Installation Responsibilities
Ensure proper payload capacity. It is the distributor’s responsibility to verify that the• equipment package does not exceed the vehicle capacity.
Ensure installation of a safe fuel tap system and through-oor ttings as provided by
• HydraMaster.
Ensure proper placement of the truckmount, recovery tank, fresh water tank, and• accessories in the vehicle, and check that they are secured with bolts and back up
plates. The distributor should verify that the owner is in agreement with the layout.
Ensure proper connection of the fuel lines.• Ensure proper connection and installation of the battery. Verify that the battery is in• accordance with HydraMaster’s recommendation.
Check the pump, vacuum blower and engine oil levels prior to starting the
• truckmount.
Start and run the truckmount and check that all systems function properly.
• Test all hoses, wands and other accessories for correct operation.• Ensure timely return of the document package.•
