Hygge Aarhus User manual

www.hyggebikes.comwww.hyggebikes.com
AARHUS MANUAL
READ BEFORE YOU RIDE

CONGRATULATIONS
Kind Regards,
Copenhagen, Denmark.
On the Purchase of your new Hygge E-Bike.
You are now ocially the part of owner of Hygge, We welcome
you to the ever-expanding global Hygge family.
We ask that you read through this Manual thoroughly and
apply our instructions before you ride your eBike, our safety
warnings are especially important.
Please scan the QR code below to access your Hygge Assistant
directly. It aims to provide you with a comprehensive Hygge
eBike experience that is easily accessible via both mobile and
computer devices.
We also recommend registering online with us at -
https://hyggebikes.com/my-account/

REGISTRATION
Register of your Hygge Bike
Owner’s name
Frame number
Model and color
Date of purchase
Please keep this manuel safe and ll in the details below. The serial number
is located at the back of the E-Bike near the gears. This number is unique to
your E-Bike and will help for warranty issues and also if the ebike is lost
or stolen. For Aarhus it starts with GS followed by 5 numbers.
In addition, if you would like to insure your ebike you’ll need to provide your
insurance company with a frame number and invoice/receipt of sale.

TABLE OF CONTENTS
Quick set up guide
Specication
Bicycle and components
LCD Display
Brakes
Motor
Battery Pack
Gears
Tyre Pressure
Protective Clothing
Unpowered riding
Battery Care
Folding your eBike
EU/UK regulations for eBikes
Warranty & General Tips
01
02
03
05
06
07
07
09
09
11
11
15
17
19
20

QUICK SET UP GUIDE
Unpacking and Open-box Inspection
• Open the package.
• Remove the bicycle from the box. – Use two people to avoid any damages.
• Remove the protection packaging from the bike.
• Unfold the bike from the frame rst then lock it in using the locking pin.
• Now unfold the handles bars, again lock these in.
• The battery comes factory charged but should be charged 2-3 hours before
using the rst time.
• Charging the battery can be done when the battery is on or o the ebike.
NOTE: DO NOT HAVE THE EBIKE OR BATTERY ON WHILST CHARGING,
THIS WILL DETOIRATE THE BATTERY QUICKILY.
• Remove the battery charger from its packaging.
• Insert the charger plug into plug socket the light on the convertor will be green.
• Now insert the cable into the battery and the light will show Red.
Keep charging the battery until the light is green. Green light states
the battery is fully charged. NOTE: DO NOT LEAVE BATTERY CHARGING
OVERNIGHT OR LONGER THAT 4 HOURS.
• There are two keys – keep the spare safe!
• To remove the battery from the slot please insert key then push in
and turn to unlock.
• To avoid suocating, keep children from playing with packaging.
Dispose of packaging materials in accordance with local legislation
and guidelines.
01 02
This manuel is made to get the most out of your ebike. Your box should
also come with a quick set-up guide which is made to get you riding as
soon and as safe as possible. If you have any further questions please contact
us at – [e-mail]
1Frame material: Alloy Frame
Wheels: 27.5”Spoke
Suspension: Front Alloy Crown
Tyres: CST 20”FAT tyres
Saddle: Comfortable City
Cables: Waterproof
Weight: 25 kg
Max Rider Weight: 130 kg
Front/Rear Brakes: Shimano Disc Brakes
2Display: Smart LCD Display
3Motor: 250w
4Max Speed: 25km
5Range: up to 70 to 80 Km
6Charging time: 2-6hrs (250w)
7Gears: Shimano Altus RD-M370, 9SP
8
9
10
11
12
13
14
15
16
Crank Set: 40T, 170 mm
SPECIFICATION:

GET TO KNOW
YOUR HYGGE
Bicycle and Componentvz
14
1
4
6
3
15
11
8
12
5
2
7
10
13
9
8
10
0403
1Front Disk Brake 11
12
13
Motor
14
Shimano Derailleur Gears
15
Saddle
Back rack
CST Tyres
Suspension
Brakes
2Rear Disk Brake
3Horn
4Front light
5Back Light (Red)
6
7
LCD
8
9
Folding pedal
1o
Removable Battery

BRAKESLCD DISPLAY
The content displayed by the meter includes:
• battery display
• riding mode display
• riding speed display
• riding single mileage display
• total riding mileage display
• electronic control system fault code display
05 06
Description
of speed
Sports Mode
ECO
Gear
Description of
Range
Total
Mileage
Speed
Single Mileage
Mileage Data
Battery
capacity
Walking
assistance
• Always check that both your front and rear brakes are properly adjusted
before riding your bike.
• Squeeze your brake together and slip the cable into the trough. You may
need to adjust the cable length by loosening the nut and sliding the cable
through to the proper position.
• Retighten nut to hold the proper position
• Adjust the brake pads on either side by using an Allen wrench so that they
make contact on the metal wheel rim and not the tire.
• Be sure they are straight, and the distance is 1- 1.5mm between rim and the
two brake pads. The pads will be close when adjusted properly.
• There are some small adjusting screws on the sides of the brake pad levers that
can be used to adjust the distance of each side.
• If the distance of the two brake pads to the rim is dierent then adjust the
spring screw on the two brake arm of the xed mount till the distance of the
two sides is the same, making sure that it can brake eciently.
• If the brake pad is damaged severely, please replace it in time thus ensure
the eciency of the brake

The ebike is operated by a mid motor based on 250W motor. This means the motor
operates directly on the back wheel and assists in the rider's pedalling. Using
the LCD control system, the user may change the motor's power and pick from
several riding levels 1-5. The motor provides a maximum speed of 25 kilometres
per hour in accordance with EU/UK regulations.
Power assist recommendations
Downhill – levels 1-2
Uphill – levels 4-5
Flat – Levels 3
BATTERY PACK
The bike is powered by a battery that can be removed from behind the seat post.
Simply insert the key into the key slot to remove the battery from its place on
the ebike. The battery may now be readily removed from its container after pushing
in the key and turning to 'Unlock'.
Ensure the key is in the unlock position before reinstalling the battery in the ebike.
Slide the battery down while ensuring that the rear of the battery is aligned with
the back of the rack. Turn the key to the on or o position depending on whether
or not you intend to ride the bicycle. These two options will lock the
battery to the rack.
MOTOR
07 08

GEARS
The gears or derailleur should only be shifted as you pedal to keep the derailleur
in adjustment. The derailleur / shifting and pedaling are completely independent
of the motor. You should use the SHIMANO gear shifter at the handlebar to set the
gears appropriately according to road conditions and pedal as usual, you will nd
that you need to exert a lot less eort and the e-bike travels faster and at a
steadier speed.
TYRE PRESSURE
The user may locate the acceptable ination pressure range on the side of the
tyre, for the Vester range it is 25-30 PSI. To examine and adjust tyre pressure,
it is advised to use a foot pump with a pressure gauge or pressure metre.
NOTE: ITS ESSENTIAL THAT THE TYRES ARE INFLATED TO RECCOMENDED
PRESSURE BEFORE USE. PLEASE INFLATE TYRES TO 25-30 PSI
09 10

PROTECTIVE
CLOTHING
• Please use a helmet that meets the most recent certication requirement
while riding. When riding, the head can sustain the most serious injuries,
which may be avoided by wearing a helmet.
• Please wear secure footwear with nonslip soles (such as special-shaped
rubber soles).
• Please wear gloves at all times.
• Please wear tights to prevent getting grabbed by the bicycle or other
roadside items.
• Please use glasses that are (transparent) dirtproof, dustproof, and insect proof.
• Please ensure that you are wearing sunglasses on sunny days.
UNPOWERED RIDING
You may also utilise a bicycle without a power. When the power-assisted
mechanism is deactivated, the bicycle becomes unpowered. For example:
when the batteries are depleted.
11
12
12

1413

BATTERY CARE
15 16
IIt takes 3 to 4 hours (from 1% to 100%) to completely recharge the battery
Please follow the methods below to store battery for longer than two months:
Take the battery out.
Ensure the battery housing and any visible components are undamaged.
Charge the battery before long-term storage.
Place the battery in a secure and dry location. Keep the battery between
5° and 20°C. Prevent battery temperature from uctuating excessively.
Please refrain from storing battery in direct sunlight or at high temperatures.
Please charge the batteries every two months at minimum.

Transportation regulations vary from country to country (or state to state,
as the case may be), so please familiarise yourself with the specic regulations
applicable to the territory in which you intend to ride your Hygge ebike.
The specic regulations may include (but are not limited to): the requirement
to wear a specic approved helmet, a valid driver's licence, speed limits,
an age restriction, a riding regulation (such as the use/non-use of cycle paths),
limitations on bicycle weight and dimensions, and mandatory insurance,
among others. In certain instances, the legal classication of your Hygge
may limit its use to private property.
WARRANTY
• One year on the motor.
• One year on the battery.
• Three years on the frame.
• One year limited warranty on the electrical components and other parts.
• Hygge Bikes are categorised as having: I a maximum nominal power
output of 250 W
• only assist the rider when pedalling
• no throttle function – for the walking assist function of no more than 6 km/h
• only provide assistance up to a maximum top speed of 25 km/h / 15.5 mph
GENERAL TIPS
• It is recommended to take your Hygge for a full tune-up and maintenance check
by a bike mechanic on a regular basis, at least once a year.
• While our Hygge bikes are rain and splash-proof, their electrcial components
should not be submerged in water.
• When washing your Hygge, use soap and water only, When rising with water,
use nothing stronger than a normal low pressure garden hose. Be sure to
avoid spraying directly into the motor as well as any pivot and connection
points or areas where bearings are housed. This includes headset, bottom
bracket and hubs. Never use a hugh pressure water hose under an circumtances
• To prevent corrosion, dry the HYGGE and its components after every wet ride.
• Under extreme weather conditions please store the battery in room
temperature environment.
EU/UK REGULATION
19 20
For Warranty Information please visit:
https://hyggebikes.com/warranty/
Returns and Refunds information please visit:
https://hyggebikes.com/refund_returns/
