CRAWLER CMP190 User manual

EN
User Guide
CMP190

CRAWLER
Model: CMP190
Version: EN 1.00.422
2
Refrigerator Usage........................................................................................17
Battery/ Sink Usage ......................................................................................17
Stove Use......................................................................................................18
Portable Toilet Use........................................................................................19
Diesel Heater ................................................................................................20
Technical Specifications................................................................................21
Care Instructions...........................................................................................22
Warranty Text................................................................................................24
Warranty Form ..............................................................................................25
Foreword.........................................................................................................3
Basic Warnings ...............................................................................................4
Safety ..............................................................................................................6
Equipment List ................................................................................................9
Exterior Design................................................................................................9
Exterior Kitchen Area......................................................................................9
Interior Design.................................................................................................9
Living and Sleeping Area................................................................................9
Electrical/ Control Installation ...................................................................... 10
Water Pipe System ...................................................................................... 10
Gas Installation ............................................................................................ 10
Schematic Explanation ................................................................................ 11
Use of CMP190............................................................................................ 12
Unlocking ..................................................................................................... 12
Opening the Rear Entry Door....................................................................... 12
Unlocking the Spare Wheel, Installing the Lock.......................................... 13
Opening the Back Cover and Ladder........................................................... 13
Emptying the Interior Space......................................................................... 14
Using the Upper Awning.............................................................................. 14
Opening the Side Bed Area ........................................................................ 15
Opening the Side Canvas ............................................................................ 15
Use of the Kitchen Area............................................................................... 16
Use of Exterior Shower Area ....................................................................... 16
Interior Hardware ......................................................................................... 17

CRAWLER
Model: CMP190
Version: EN 1.00.422
3
Foreword
Use the user guide to access specific information and familiarize yourself with your CMP190’s functions.
In addition to standard equipment, this manual also describes optional equipment or accessories.
This user manual helps you to enjoy your CMP190 as best as possible.
It also contains important information that concerns the safety of you and other users.
Thanks for choosing CRAWLER!
* Certain countries may have legal requirements that affect the level of equipment.
* CRAWLER continues its continuous product development efforts to provide a better
experience. Features, designs and illustrations in the user manual are not binding. CRAWLER
reserves the right to make changes without prior notice.

CRAWLER
Model: CMP190
Version: EN 1.00.422
4
Basic Warnings
Things to check before setting off;
- Make sure the CMP190 has a good connection with the vehicle.
- Make sure the upper awning is closed and locked.
- Make sure doors and cabinets are locked.
- Make sure the outside kitchen area is closed and locked.
- Place breakable items in cabinets.
- Make sure the battery is full.
- Make sure the entrance step is off.
- Electrical inlets and outlets should be checked.
- Do not keep flammable and explosive materials in CMP190.
- Make sure the tubing is removed.
- Make sure the diesel heater is off.
- Make sure the lightning is off.
Things to consider while traveling;
- Do not exceed the specified speed limit for pick-up vehicles.
- When descending long and steep slopes, the brake is loaded more than
normal. Shift to a lower gear and adjust your speed accordingly.
- Do not travel inside CMP190.
- Do not keep flammable and explosive materials in CMP190.
- Make sure breakable items are secured inside CMP190.
- Attention should be paid to the height of CMP190 at the parking garage and
garage entrances.
- CMP190 does notexceed the mirror width ofthe vehicle, but it may be wider
than the body of the vehicle. Care should be taken at narrow turning points.

CRAWLER
Model: CMP190
Version: EN 1.00.422
5
Things to consider while camping;
- Thanks to the automatic gas cut-off safety system, the stove turns itself off
in case of emergency.
- Make sure the curtains are closed to prevent heat loss inside during cold
weather.
- Be careful when opening and closing the top awning while staying inside
the CMP190.
- Make sure the fuel tank is full when using diesel heaters.
Things to consider while parked;
- It is recommended to park the CMP190 on level ground.
- Make sure doors, windows and cabinets are closed and locked.
- Make sure the upper awning is closed.
- In case of long-term parking, keep the main switch off.
- Do not leave flammable or explosive materials inside CMP190.
- Make sure the gas valve is closed.
- It is recommended to ventilate the inside of CMP190 at regular intervals.
- Provide external cleaning of CMP190 at regular intervals.
- When upper awning is closed, the rear door must be open so that the air
inside can escape.
- Make sure there are no mosquito nets or curtains left outside when upper
awning is closed.

CRAWLER
Model: CMP190
Version: EN 1.00.422
6
Safety
Passenger Transportation
Since CMP190 does not have a seat belt, it should not be traveled in CMP190
while driving in order to balance the weight distribution.
Tire Safety
Properly maintained tires improve handling and stopping.
Tools and Equipment
Appliances (stove, refrigerator, etc.) and equipment (hot water heater, oven,
etc.) typically run on LPG. LPG is flammable and is under high pressure.
Misuse may cause fire and/or explosion. Be sure to follow all instructions and
warnings in the manual, as well as in the device and equipment specific user
manuals.
Mold
Mold and mildew spores are present in indoor and outdoor environments. In
order to keep all mold and mildew spores under control, check humidity and
ventilate your caravan regularly. A healthy ventilation should be provided to
control humidity.
Chemical Sensitivity
Immediately after the CMP190 is purchased, and sometimes after a long
period of inactivity, a strong odor and/or chemical sensitivity may be
experienced. As in homes, many different products are used in the
construction of CMP190, such as carpet, linoleum, plywood, insulation,
flooring. In the use of different materials, odor sensitivity is more obvious.
Since CMP190 has a small living space, the air exchange inside is significantly
less than the house. These products can outgas different chemicals, including
formaldehyde, when new or when exposed to high temperatures and/or
humidity. This outgassing, along with minimal air exchange, can cause
irritation of the eyes, nose, and throat, and sometimes headaches, nausea,
and various asthma-like symptoms. The elderly and young children, as well as
anyone with a history of asthma, allergies or lung problems, may be more
sensitive to the effects of gassing.
Ventilation
It is very important to ventilate the CMP190 to reduce exposure to chemicals
from outgassing. Ventilation should be done frequently after purchase and
when temperatures and humidity rise. Note that gas output is accelerated by
heat and humidity. Open windows, vents and doors. Use natural ventilation or
a fan to expel stale air and bring in fresh air. Reducing airflow by sealing the
CMP190 increases the formaldehyde level in the vehicle's interior air.
Do not smoke
It is recommended that you do not smoke inside the CMP190. It will damage
CMP190 and also release formaldehyde and other toxic chemicals.

CRAWLER
Model: CMP190
Version: EN 1.00.422
7
Medical Advice
Questions about the effects of formaldehyde on your health should be
addressed to your doctor or local health department.
Long-Term Use Effects
- In long-term use of CMP190, it is necessary to be prepared for
condensation and humid conditions that may be encountered.
- In cold weather, when the relative humidity of the indoor air is high,
moisture may condense on the inner surfaces of CMP190. This is
exacerbated by the fact that CMP190's insulated walls are much thinner
than house walls.
The relatively small volume and tight, compact nature of the
CMP190 mean that even a few passengers' normal living activities
will lead to rapid moisture saturation.
-Water vapor will condense as moisture inside windows and walls, or as
frost or ice in cold weather, unless it is carried outside by ventilation or
condensed with a dehumidifier.
- Inside the walls or ceiling, warped or stained panels can also condense
out of sight.
- The appearance of these conditions can indicate a serious problem.
When signs of excessive humidity and condensation appear on the
CMP190, it is important to take action to minimize their effects.
Tips for Checking Condensation
Uses where it is important to let excess moisture out:
- Bathroom
- Washing dishes
- Hair drying
- Cooking
Avoid dead air spaces as shown!
- Use of a fan to ensure air circulation.
- Leaving cabinets and cabinet doors partially open.
- To help alleviate condensation in cold weather;
- In cold weather keep the temperature reasonably cool as much as
possible.
- CMP190 needs to breathe, it will smell when airtight.
- Let some warm air out and outside air in.
- Do not allow humid indoor air to be recycled from use and provide
reasonable ventilation.
Factors Contributing to Mold Growth
For mold growth to occur, indoor or outdoor temperatures must be between 4°
and 33°C, and it must also have a source of moisture such as humidity,
stagnant water, moist materials. The fastest growth inside CMP190 is due to
its hot and humid condition.

CRAWLER
Model: CMP190
Version: EN 1.00.422
8
Inhibition of Mold Growth
- Checking relative humidity can prevent mold and mildew growth.
- The use of air conditioners in hot climates will reduce the relative humidity.
- Ventilation is available in the kitchen area.
- To prevent mold growth, using vents when preparing food is an important
factor, even in cold weather.
- Also, opening windows during these activities will help with natural
ventilation.
- In extremely humid conditions, using a dehumidifier may help.
- Regular cleaning of mold, which is caused by frequent use of CMP190
and/or growing, is an important preventive measure.
- Any spills should be wiped up quickly and dried as soon as possible.
- Avoid leaving damp items lying around.
- On safe surfaces use mold or mildew-killing cleaning products.
- Check the sealing wicks regularly and reseal as necessary to prevent water
leaks.
- Proper preventive maintenance of the CMP190 and its accessories, as
described in both this manual and accompanying literature, will provide the
best protection for the CMP190.
Winter Travel
Traveling in sub-freezing temperatures will require certain precautions to
protect the plumbing system and personal belongings from damage by
freezing.
It is necessary to clear the snow accumulations on the pop-up.
Whenever possible the heat should be kept at a constant temperature.
It is easier for the heater to keep the room temperature constant than to let
the CMP190 temperature drop to 10°C and then try to raise it to room
temperature.
When parking in temperatures below freezing, be sure to have a full supply
of LPG or Diesel and plug into a 220V power source whenever possible.
In order to allow hot air to circulate around plumbing lines and fixtures leave
cabinet doors, wardrobes and bedroom doors partially open.

CRAWLER
Model: CMP190
Version: EN 1.00.422
9
Interior Design
- Electrostatic Powder Coating (Cabinet and Interior Walls)
- Ceramic Based Heat Insulation
- Zippered Storage Compartments
- Rear Door Fly Screen
- Aluminum Folding Work Table
- Upper Bed Rail
- PVC Flooring
- Inner Curtain
- LED Indoor Lighting
- USB Charge Inputs
- 12v Cigarette Lighter Input
Living and Sleeping Area
- First Bed Section (195x190 cm)
- Second Bed Section (165x60 cm)
- 3 Person Seating Area
- Sofa and Bed Cushions
- Underarm Wardrobe
Equipment List
Exterior Design
- Electrostatic Powder Painted Aluminium Body
- Openable Entrance Step
- Height Adjustable Fixing Feet (2 Pieces)
- Side Opening Bed Compartment
- Side Opening Bed Compartment Window
- Windowed Pop-up Roof System
- Premium Pop-up Roof Fabric
- Chrome Door Stoppers
- Wide Angle Chrome Hinges
- Tube Rack (2 Pieces)
- Wood Rack (2 Pieces)
- LED Tail Light
- Chrome Locked Storage Cabinets
- Kitchen Cabinet Lights
- Tailgate (Left)
Exterior Kitchen Area
- Sliding Exterior Kitchen
- Double Stove
- Chrome Faucet
- 2 Piece Plastic Sink
- Stove Wind Shade
- Kitchen Wardrobe

CRAWLER
Model: CMP190
Version: EN 1.00.422
10
Electrical/ Control Installation
- 6 Analog Control Panel
- 40 Ah Gel Battery
- Remote Controlled and Dimmer Adjustable LED
Indoor Lighting
- Pako Switch
- Victron Blue Smart Charger (7 Ampere) *
- 220v Charge Input
- Charging Cable and Bag
- Vehicle Electric Charging System (Cyrx)
Water Pipe System
- Water Pump (19 L/Min.)
- Water Level Indicator
- Chrome White Water Tank (90 L)
- Chrome Water Fill Cap
- Water Drain Valve
Gas Pipe System
- Gas Detector
- Gas Hose
Optional Features
- Indel B 65 Refrigerator *
- Berhimi 50 Refrigerator *
- Dometic 65 Refrigerator *
- Engel 57 Refrigerator *
- Spare Wheel Carrier & Premium Exterior Shower Area
- Headlight Protection Grille (Black)
- 270 Degree Premium Awning (Light Grey)
- Fishing rod holder
- Weaponry
- Thetford Portable WC *
- Victron Energy 220 Ah Battery*
- Eberspacher D2 L Airtronic Space Heater (Diesel) *
- Imkar Air Conditioner (Cooling) *
- Neta Portable Satellite *
- Solara Solar Panel 160w & Solara Regulator*
- Water Freeze Protection Unit
- Crawler Smart Panel

CRAWLER
Model: CMP190
Version: EN 1.00.422
11
Schematic Explanation
1. Side Opening Bed Compartment
2. Side Opening Bed Compartment Window
3. Chrome Door and Cabinet Locks
4. Chrome Door Stoppers
5. Storage Cabinets
6. Kitchen Cabinet Lights
7. Spare Wheel
8. Back Entrance Cover
9. Openable Entrance Step
10. Height Adjustable Fixing Feet
11. Openable Roof Pop-up System with Window
12. Chrome Door and Cabinet Locks
13. High Angle Chrome Hinge
14. Tube Connecting Places (2 Pieces)
15. Was LED Tail Light

CRAWLER
Model: CMP190
Version: EN 1.00.422
12
Use of CMP190
Unlocking
Turn the lock with the CMP190's door key. Then lift the cover by turning the
lock lever towards yourself and then up.
Opening the Rear Entry Door
Bring it to the desired height with the help of the wheel wrench used for fixing
the feet with your key.

CRAWLER
Model: CMP190
Version: EN 1.00.422
13
Unlocking the Spare Wheel, Installing the Lock
Open the spare wheel switch located at the rear of the CMP190 by pushing it
forward. When installing the lock, do not forget to install it as shown.
Opening the Back Cover and Ladder
Lift the back cover up. After opening, open the ladder.

CRAWLER
Model: CMP190
Version: EN 1.00.422
14
Emptying the Interior Space
Remove the materials inside the CMP190 to open the side bed.
Using the Upper Awning
To open the awning, first unlock the awning. After unlocking, push the
awning section up.

CRAWLER
Model: CMP190
Version: EN 1.00.422
15
Opening the Side Bed Area
Remove the lock pins before opening the bed.
Opening the Side Canvas
After opening the canvas, open the top two legs. Don't forget to pin.

CRAWLER
Model: CMP190
Version: EN 1.00.422
16
Use of the Kitchen Area
The stove and sink are in the rear left storage area.
Use of Exterior Shower Area
Move the shower curtain to the same position as shown.

CRAWLER
Model: CMP190
Version: EN 1.00.422
17
Interior Equipment
Refrigerator Usage
1. You can open the refrigerator from the outside.
2. The opening direction of the cover may vary according to the product
models.
3. You can adjust the temperature of the refrigerator with the level-adjusted
cooling feature.
(For detailed information, see the user manual of your refrigerator brand)
What if the refrigerator does not work?
Attention is paid to the indicators on the Crawler Smart Panel or Control
Panel.
- Paco switch is opened and closed.
-Battery level is checked.
- If there is a problem with the refrigerator the user manual of your
refrigerator brand is checked.
Battery/ Sink Usage
1. To put it into use, first check the clean water level in the tank.
2. Turn on the booster before using the battery.
3. You can use the battery according to your needs thanks to its rotating
head.
4. When the battery is not in use, it can be kept closed thanks to its
foldable feature.
What if the battery does not work?
- Attention is paid to the water level indicator on the Crawler Smart Panel
or control panel.
- The booster is checked.
- Battery level is checked.
- If there is a problem with the battery, the user manual of your battery
brand is checked.

CRAWLER
Model: CMP190
Version: EN 1.00.422
18
Compatible with LPG & Natural Gas.
Stove Use
CMP190's outer stove use;
1. First unlock the drawer of the CMP190 to open it for use.
2. Remove the gas hose from the under-counter drawer of the
CMP190.
3. Connect CMP190 with the jack on the back.
4. You can store the tube in the right rear tube holder of CMP190.
5. Light the stove with the help of the lighter and adjust the
temperature of the gas coming to the stove with the stove top
buttons.
6. It is recommended to keep the gas off when not in use.
STOVE
Thanks to the automatic gas cut-off safety system, the stove turns
itself off in case of emergency.

CRAWLER
Model: CMP190
Version: EN 1.00.422
19
Portable Toilet Use
Thetford Portable Toilet / Porta Potti 565 P
Dimensions: H 448 / W 383 / D 450 mm
Seating Height: 443 mm
Clean Water Tank Capacity: 15 Liters
Waste Tank Capacity: 21 Liters
Weight Manual Model: 5.3 Kg
1. Open the toilet seat for use.
2. Liquids called "caravan toilet chemicals" are poured onto the tape
to break up waste and prevent odor. Pour the toilet chemical into
the tank at scale before use.
3. Open the drain by pulling back the latch located next to the toilet
during use. Close the drain by pulling in the opposite direction after
use.
4. In order not to have to carry the waste tank cassette, it can be
transported more simply with the wheel system and pull handle.
5. Do not forget to turn off the lock after emptying and cleaning.

CRAWLER
Model: CMP190
Version: EN 1.00.422
20
What to do when smelling gas?
Avoid ignition sources! For example extinguish all open flames, do not use
any electrical switches, mobile phones or radios in the vehicle, do not start
the engine of the vehicle, operate devices, do not smoke in the vehicle.
Open windows and doors.
Evacuate all persons from the vehicle.
Shut off gas cylinders or turn off gas supply from outside. The entire gas
system must be checked and repaired by qualified personnel!
You can only put the gas system back into operation after inspection and
repair!
CMP190 Owner's Obligations
The owner of CMP190 is responsible for using the device in accordance with
the rules.
Hoses should be checked regularly and replaced if worn.
When a new appliance is put into operation for the first time, smoke and odor
may develop for a short time. When the appliance is put into operation after a
particularly long standstill period a slight smoke and odor may occur due to
dust or dirt.
It is recommended to run the appliance for a few minutes at the highest
power level and then to ensure that the room is well ventilated for self-
cleaning.
The air temperature should always be checked before adjusting the hot air
outlets. Hot water can be dangerous if misused and can cause burns. Check
the water temperature before each shower or bath.
The waste gas double pipe should be checked regularly, especially after long
trips, for damage and the soundness of the connections, as well as the
device and chimney connections. In order not to cause any damage due to
splashing water while washing the vehicle, water should not be poured
directly into the chimney.
Diesel Heater
Heating Mode
The air circulated by the fan motor is heated in the boiler and transmitted to
the CMP190. Working integrated with the diesel heater control unit, the heat
sensors inside the CMP190 detect the temperature of the intake air. If the
temperature of the intake air is below the temperature set in the control unit,
the heater continues to operate.
Setting Mode
In the setting mode, the fan motor speed and the fuel delivery capacity of the
dosing pump depend on the heating capacity. In the meantime, the spark plug
is deactivated.
Thermostat Range
In case of approaching the temperature set on the operating switch, the
heating capacity is reduced by the control unit. The speed of the fan motor and
the fuel delivery capacity of the dosing pump are reduced in direct proportion
If the temperature set at a minimum heating capacity is reached, the fuel
pumping process of the dosing pump is terminated and the combustion
process ends with the heater blowing its last.
Note
Throughout the thermostat range, the heater fan motor operates at idle speed,
providing indoor air circulation. In addition, a change to be made on the
operating switch is evaluated by the control unit and then activated.
