MDC XT17-HRT User manual

Copyright © Market Direct Group Pty Ltd 2021 All Rights Reserved
Phone: [phone]
OWNER’S MANUAL
EDITION: 2021 - Version 1
XT17-HRT
OFFROAD CARAVAN
www.marketdirect.com.au

Contentswww.marketdirect.com.au Ph: 1300 494 494
Contents
My XT17HRT Island Hybrid Caravan ...........................1
Section 1. Introduction.......................................................2
WELCOME TO MDC ..........................................................2
Terminology & Abbreviations..........................................2
Specications .........................................................................4
MDC Contact Details and Stores...................................5
Safety Information ...............................................................6
Modications to The Product..........................................6
Jacking Your Caravan..........................................................7
Electrical Safety ....................................................................8
Vehicle Electrical Requirements.....................................9
Brake Controller ...................................................................9
Correct Vehicle Wiring for MDC Caravans................9
Trailer Lights........................................................................ 10
Charging Camper/Caravan While Driving............... 10
Vehicle with or without smart alternator................. 10
Gas & Appliance Safety ................................................... 11
Gas Certication................................................................ 11
General Safety .................................................................... 11
Gas Cylinder Safety .......................................................... 11
Gas Appliance Safety ....................................................... 12
Removing the Flue Cover ............................................... 12
Ventilation and Flues........................................................ 13
Isolating Appliances.......................................................... 13
Weights and Payload Capacities ................................. 14
How to Load Your Caravan............................................ 14
Load Distribution Guide.................................................. 14
Ball Weight........................................................................... 15
Effects of Weight Distribution ..................................... 15
Tyre Pressures .................................................................... 15
Pre-Trip Inspection............................................................ 16
Tyre ......................................................................................... 16
Wheel Nuts.......................................................................... 16
Hitch and Chains................................................................ 16
Fire Extinguisher................................................................ 16
Brakes & Breakaway System......................................... 16
Lights ...................................................................................... 16
Setting Up the Caravan................................................... 17
Finding a Suitable Spot .................................................... 17
Weather ................................................................................ 17
Using Wheel Chocks and Ramps................................. 17
Operating the Jockey Wheel ........................................ 17
Stabiliser Legs ..................................................................... 17
Awning ................................................................................... 18
Kitchen................................................................................... 19
Control Panel ...................................................................... 20
Mains Power........................................................................ 20
RCD Safety Switch ............................................................ 20
Towing with Trucks ........................................................... 20
Towing the Caravan.......................................................... 21
Connecting the Hitch....................................................... 21
Coupling ................................................................................ 23
Uncoupling ........................................................................... 25
Connecting the Breakaway ........................................... 26
Connecting the Safety Chains ...................................... 27
Connecting the Electrics................................................. 27
Charging the Caravan ...................................................... 28
Preparing for Bad Weather ........................................... 28
Packing Down Your Caravan......................................... 28
Storage & Care.................................................................... 29
Care and Maintenance of the Caravan......................30
Protection of Finishes...................................................... 30
Paint........................................................................................30
Acrylic Windows................................................................ 30
Internal Finishes.................................................................30
Ensuite Finishes.................................................................. 30
Mirrors................................................................................... 30
Galvanised Finishes ..........................................................30
High Tensile Bolt and Fittings .......................................30
Stainless Steel .....................................................................30
Fabrics.................................................................................... 30
Shade and screen care..................................................... 31
Corrosion Protection ....................................................... 31
Roof Maintenance ............................................................. 31
Sealants ................................................................................. 31
Solar Panels.......................................................................... 31
Caravan Body Maintenance .......................................... 31
Locks and Latches ............................................................. 31
Rubber Seals........................................................................ 31
Sealants ................................................................................. 31
Winegard Sensar III Antenna (optional Extra)........ 32
Torque Settings ..................................................................34
Wheel Nuts.......................................................................... 34
Hitch .......................................................................................34
Trailing Arm Pivot Bolts...................................................34
Hand Brake .......................................................................... 35
Cable Adjustment.............................................................. 35
Adjuster Automotive Type............................................. 36
Correct Use of Your Electric Brakes........................... 37

Contentswww.marketdirect.com.au Ph: 1300 494 494
Important Safety Notice................................................. 37
Brake Adjustment.............................................................. 37
Brake Cleaning and Inspection..................................... 37
Brake Lubrication .............................................................. 37
Magnets................................................................................. 38
Shoes and Linings ..............................................................38
Corrosion Prevention.......................................................38
Wheels and Tyres .............................................................. 39
Suspension ........................................................................... 39
Shock Absorbers & Bushes............................................ 39
Electrical Systems..............................................................40
Charging from your Vehicle........................................... 40
Battery Care ........................................................................40
12 Volt Wiring Diagram Main Circuit ........................ 41
Truma Rapid Hot WaterSystem ............................. 42
Operating Instructions.................................................... 42
General Safety .................................................................... 42
Filling the Truma UltraRapid with Water.................. 43
Pressure and Temperature Relief Valve (P&T safety
valve).......................................................................................44
Draining the Water Heater............................................44
Switching On Gas Operation......................................... 45
Removing The Cowl Cover............................................. 45
Select Water Heater Mode............................................ 45
Switching Off Gas Operation........................................ 45
Red Indicator Lamp “Fault” ............................................ 46
Maintenance........................................................................46
Decalcication....................................................................46
Fuses....................................................................................... 46
Circuit Breaker ................................................................... 46
Water Heater Trouble Shooting................................... 47
Gas Operation..................................................................... 47
Water Supply....................................................................... 47
Water Pumps.......................................................................48
Selecting Fresh Water Tank...........................................48
Connecting the Gas .......................................................... 49
Protecting from Mould.................................................... 49
Toilet Care and Maintenance........................................ 50
Chemicals.............................................................................. 50
Useful Accessories .............................................................51
Wheel Chocks......................................................................51
Covers .....................................................................................51
Stone Protection ................................................................ 52
Trouble Shooting................................................................ 53
Electrical ............................................................................... 53
Resetting Breakers............................................................ 56
High Load Breakers........................................................... 56
Medium Load Breakers ................................................... 56
Breaker Locations.............................................................. 57
Under Bed Beside Batteries.......................................... 57
Side Of Cupboard Opposite Door............................... 57
Trouble Shooting................................................................ 58
Water...................................................................................... 58
Gas........................................................................................... 58
Brakes .................................................................................... 59
Handy Tips ...........................................................................60
Driving Off Road................................................................ 60
Trip Planning........................................................................ 61
Warranty Statement ........................................................ 62
Travel Record ...................................................................... 66
Mechanical Maintenance ............................................... 68
Hitch ....................................................................................... 68
Ball Bearing Slides ............................................................. 68
Wheels and Tyres .............................................................. 68
Brakes .................................................................................... 68
Bearings and Seals............................................................. 68
Suspension ........................................................................... 69
Spare Part Numbers......................................................... 69
Hub Assembly..................................................................... 70
Trailing Arm Bushes.......................................................... 71
Service Record.................................................................... 72
Supplier Contact Details................................................. 94
Guide to Video Tutorials ................................................. 96
Handover Video ................................................................. 96
Setup Tutorial...................................................................... 96
Pack Down Video Tutorial.............................................. 96
External Ensuite Setup Tutorial.................................... 96

www.marketdirect.com.au Ph: 1300 494 494
Copyright © Market Direct Group Pty Ltd 2021 All Rights Reserved
All les and information contained in this Owner’s Manual are copyright by Market Direct Group Pty Ltd, and
may not be duplicated, copied, modied, or adapted, in any way without our written permission. Our Owner’s
Manual may contain our service marks or trademarks as well as those of our afliates or other companies, in the
form of words, graphics, and logos.
Your use of our Owner’s Manual does not constitute any right or license for you to use our service marks or
trademarks, without the prior written permission of Market Direct Group Pty Ltd.
Our Content, as found within our Owner’s Manual, is protected under Australian and foreign copyrights. The
copying, redistribution, use or publication by you of any such Content, is strictly prohibited. Your use of our
Owner’s Manual does not grant you any ownership rights to our Content.
DISCLAIMER: This manual is provided in good faith and Market Direct Group Pty Ltd.
may amend or update this owner manual from time to time.
Use of Product
The intent and purpose of this manual is to assist owners in the correct use and operation of the product and outline the
servicing schedule to be followed, ensuring the correct maintenance of the product.
Servicing
Servicing information contained in this owner manual is provided for those who have appropriate technical skills and
relevant to the subject matter the publication deals with in regard to maintenance and repairs. The servicing content of this
manual assumes a satisfactory technical knowledge and mechanical skills and experience. It is not suitable for people who
are not trained or qualied in the subject matter it deals with. If you do not have the appropriate skills and experience, or if
you do not have access to appropriate tools and equipment, you may injure yourself or others around you and/or you may
cause damage to the Caravan you are working on, including making it unsafe. Users of this owner manual must:
• Read all content thoroughly. It is especially important to have a good understanding of all the contents shown in the
INTRODUCTION and SAFETY Sections of this publication.
• Use only the correct tools and equipment for all repairs and servicing.
• If part replacement is necessary, replace the part with the same part number or equivalent part.
DO NOT replace it with a part of inferior quality.
• Observe all ‘Cautions’ and ‘Notices’ to reduce the risk of personal injury during service or repair, or improper service or
repair that may damage the Caravan or render it unsafe.
• Understand that the ‘Cautions’ and ‘Notices’ in this publication are not exhaustive because it is impossible to warn of
all possible hazardous consequences that might result from failure to follow the instructions in this publication.
You must carry out your own risk assessments as you work.
Market Direct Group Pty Ltd. does not accept any and all liability which may arise because a user of this
publication fails to follow directions in the publication or safe work methods associated with use and
maintenance of the product.
Those without the required skills, knowledge, tools, and experience to work on and maintain this product should seek the
services of a suitably qualied person or business. This publication is based on the latest product information at the time of
release. However, specications and procedures are subject to change without notice.

www.marketdirect.com.au Ph: 1300 494 494 1
My XT17HRT Island Hybrid Caravan
DISCLAIMER: By receiving this handbook, you confirm there you have read and agree to all
the terms and conditions and understood the use and maintenance care of MDC®
NAME:
MODEL:
VIN:
BUILD DATE:
TARE:
ATM:
TYRE SIZE:
DEALER:
ADDRESS 1:
ADDRESS 2:

www.marketdirect.com.au Ph: 1300 494 494 2
Coupling Mass
Weighbridge Reading = Tare Mass
Section 1. Introduction
WELCOME TO MDC
Off road caravanning is a rewarding way to travel and see our great country. Owning an MDC Caravan will
afford you the opportunity to travel to remote places and stay in comfort. It is the intention of MDC for you to
have the best possible owner experience and enjoy the great outdoors.
Terminology & Abbreviations
Coupling Mass
Weighbridge Reading must not exceed ATM Rating
Load
Load
Weighbridge Reading must not exceed GTM Rating
ATM (Aggregate Trailer Mass) Rating: The total permissible mass of the Trailer. This includes the coupling
mass and whatever you add as payload (e.g. water, gas, luggage)
up to the specified rating. The ATM Rating
must not be exceeded.
GTM (Gross Trailer Mass) Rating: The total permissible mass that can be supported by the wheels/ tyres of
the Trailer. This includes whatever you add as payload (e.g. water, gas, equipment and luggage), but does not
include the mass supported by the tow vehicle.
The GTM Rating must not be exceeded.
Tare Weight: The total weight of the trailer (load on tyres plus coupling load) with all options and fittings as
supplied by the manufacturer, with empty water tanks, excluding fluids not essential for operation on public
roads, and without luggage or personal effects.
Caravans for illustration purposes only.

www.marketdirect.com.au Ph: 1300 494 494 3
Terminology & Abbreviations
Ball Weight: The downward load exerted on the tow point of the vehicle by the trailer.
GCM: (Gross Combination Mass): This is the total allowable combined mass of tow vehicle and trailer as
determined by the tow vehicle manufacturer.
Camber: Camber angle is the measure in degrees of the difference between the wheel’s vertical alignment
perpendicular to the surface. If a wheel is perfectly perpendicular to the surface, its camber would be 0 degrees.
Camber is described as negative when the top of the tyre begins to tilt inward towards the chassis rail.
Toe In/out: Negative toe, or toe out, is the front of the wheel pointing away from the centerline of the vehicle.
Positive toe, or toe in, is the front of the wheel pointing towards the centerline of the vehicle.
Toe can be measured in linear units, at the front or rear of the tyre, or as an angular deflection. In the case of
MDC products, the “toe in” is measured in millimeters at the front of the tyre from the chassis rail.
Tow vehicle and Trailer Compatibility
Your tow vehicle manufacturer has applied a maximum towing capacity to the vehicle which is the Aggregate Trailer
Mass (ATM) and a maximum Gross Combination Mass (GCM). These specifications MUST NOT be exceeded. It is
your responsibility to know, understand and follow these specifications. Vehicle manufacturers may also specify or
recommend “Weight Distribution Bars” when towing under certain conditions. You MUST ensure this is compatible
with the vehicle and trailer combination.
DANGER – Exceeding manufacturer weight and combination limits can result
in loss of control leading to death or serious injury. Your tow vehicle and hitch
must be rated for the Gross Vehicle Weight of the trailer.
DANGER

www.marketdirect.com.au Ph: 1300 494 494 4
Specifications
SIZE (CLOSED WITH AC) 2365mmW x 7150mmL x 3040mmH
SIZE (OPENED WITH AC) 5770mmW x 7655mmL x 3040mmH
STYLE 17’ hybrid offroad caravan
TOWBALL WEIGHT Approx. 258kg
TARE WEIGHT Approx. 2890kg
ATM 3500kg
BERTH 2 Adults & 1 Child
CHASSIS 150mm x 50mm x 3mm
DRAWBAR 150mm x 50mm x 4mm
BODY CONSTRUCTION Aluminium composite panel fully welded frame + chassis
FINISH Gal chassis + aluminium composite panel
STONE GUARD Included with stone tamer mudaps
SUSPENSION Independent trailing arm with 4x shock absorbers and coil springs
WHEELS & TYRES 265/75 R16 Goodride radial mud terrain
COUPLING DO35
BRAKES 4WD 12” electric with hand brake & brake away system
GAS CYLINDERS 2 x 9kg gas cylinder holders
JERRY CAN HOLDER 2 x 20L jerry can holders
KITCHEN CONSTRUCT
(INTERNAL)
Vitrifrigo upright fridge/freezer and Thetford S/S 3 burner stove with oven
and grill
KITCHEN CONSTRUCT
(EXTERNAL)
Slide out stainless steel kitchen with Thetford S/S MK3 Argent 4 burner hob
deluxe cooker
AIR CONDITIONER Dometic FJ3200 air conditioner
APPLIANCES Camec 240V microwave, Camec 12V range hood, NCE 2.5kg washing
machine
WATER TANK 2 x 80L fresh water & 80L grey water
WATER DELIVERY 12V electric pump
HOT WATER SYSTEM 14L Truma (gas)
ENSUITE Internal shower and toilet (Thetford) as well as an external ensuite shower
AWNING 4 metres electric
BATTERY 3 x 100amp hour deep cycle batteries
INVERTER Projecta 12V 1000W modied Sine inverter
BOOSTER CHARGER Projecta IDC 25-9-32V 25A 3 stage
INVERTER Projecta 1000W modied Sine 240V inverter
OUTLETS Multiple 12V, 240V x 2
JOCKEY WHEEL 10” swing up and lockable
STABILISER LEGS 4 x heavy duty lockable and adjustable drop down
LIGHT CONNECTION PLUG 12pin at as standard. 7 pin round or 7 pin at connection available
MATTRESS 200mm custom Queen innerspring
SOUND Kenwood head unit with internal & external speakers
SOLAR 2 x 150W solar included
