Hyperion FR632 User manual

FR632
5.8GHz 32CH Diversity Receiver
I . Specication:
1 Receiving frequency: ISM 5.6GHz-5.95GHz 32 CH
2Operating Voltage : +6.0V~+28.0V
3 Supply current : <130mA/12V DC
4 Video Output Level: 1V±0.2Vp-p/75Ω
5 Audio Output Level: 0.5 ~ 2.0Vp-p/10KΩ
6 TV System: PAL/NTSC/SECAM (AUTO)
7 Wireless Receiver Sensitivity: <-92dBm(15dBuV)
8 Antenna Connector: SMA Connector
9 Weight: 92g
10 Dimensions (L x W x H): 78x68x15mm
11 Operating Temperature: -10℃~ +85 ℃
Operating Frequency Table
CH 1 CH 2 CH 3 CH 4 CH 5 CH 6 CH 7 CH 8
A5865MHz 5845MHz 5825MHz 5805MHz 5785MHz 5765MHz 5745MHz 5725MHz
b5733MHz 5752MHz 5771MHz 5790MHz 5809MHz 5828MHz 5847MHz 5866MHz
C5705MHz 5685MHz 5665MHz 5645MHz 5885MHz 5905MHz 5925MHz 5945MHz
d5740MHz 5760MHz 5780MHz 5800MHz 5820MHz 5840MHz 5860MHz 5880MHz
II. Features:
32 Channel
Automatic Switching Built-in Dual Receiver Automatically for best reception
Dual buffered AV outputs
Unique channel search function
Large input voltage range,Very low current consumption
Not affect by 2.4GHz R/C Radios
LCD display, high brightness, very intuitive work status
III. Operation and Figures
Display
Display content description：
A: RFA; B: RF B (Show A or B)
A8: Group and Chaneel
5725 MHz : Frequency
CH
Group

Functions Operating
Key operation
Scan/Group(1)
Press button 2S, the system will enter the
search state, when search for a certain intensity
signal, a stop at the channel;
Short press button to select a different
frequency groups, namely A, b, c, d.
Power/Channel(2)
Press button 2S, power on or off;
Short press button to select a different channel,
1--- 8.
Interface
RF A AV OUT(3)
RF A receives the output of an AV signal ;
RF B AV OUT(4)
RF B receives the output of an AV signal;
DIVERSITY AV OUT(5)
DIVERSITY the received AV signal output ;
DC IN(6)
DC IN, +6V~+28V power supply.
ANT B(7)
RFB Antenna;
ANT A(8)
RFA Antenna;
1
5 3 4 6
2
87
