HYPERLITE WILL Series User manual

Use hyperlite Led linear high bay light
enjoy brighter life now
T h a n k s f o r y o u r p u r c h a s e !
If you need more information about our lights,
please contact us by email or phone call
Email: [e-mail]
Toll-free number: [phone]
www.hi-hyperlite.com
Instruction manual
LED LIGHTING
LEARN MORE
www.hi-hyperlite.com

LED LINEAR HIGH BAY LIGHT
WILL Series
FEATURES & SPECIFICATIONS
Web: www.hi-hyperlite.com Email: [e-mail] Tel: + 1 [phone]
Performance Data
PHB06-110[DM]-50L0
PHB06-160[DM]-50L0
PHB12-220[DM]-50L0
PHB12-320[DM]-50L0
General
Lumens
14300LM
20800lm
28600lm
41600lm
Efficacy
130 lm/w
CCT
5000K
CRI
>80
L70@25°C
>60,000 hours
Electrical
Power
110W
160W
220W
320W
Power factor
0.9
Input Voltage
AC120-277V
Compable accessories
Emergency LED driver with battery & Motion sensor
(Please contact the seller to purchase this product.)
Opons
Operang temperature
-40°C to 50°C
Lisngs
Listed by UL to meet UL 1598 standards for wet locaon and CE, RoHS approved.
DLC lisng. Please check the DLC Qualified Products list to confirm (www.designlights.org/QPL)
IP Rang
IP 40
Warranty
5 years
P1

STRUCTURE & ILLUMINATION
Model
Power
Lumens
Luminaire
Efficacy
Input
Voltage
Qty/Ctn
Net Weight
Cross Weight
CTN Size
PHB06-110[DM]-50L0
110W
14300LM
130lm/w
120-277VAC
1
8.2 ± 1 lb
10 ± 1 lb
25.6"*15.6"*4.3"
PHB06-160[DM]-50L0
160W
20800LM
9.3 ± 1 lb
11 ± 1 lb
PHB12-220[DM]-50L0
220W
28600LM
9.3 ± 1 lb
11 ± 1 lb
15 ± 1 lb
17.4 ± 1 lb
49.2"*15.6"*4.3"
16.3 ± 1 lb
18.7 ± 1 lb
PHB12-320[DM]-50L0
320W
41600LM
PACKAGING INFORMATION
Web: www.hi-hyperlite.com Email: [e-mail] Tel: + 1 [phone] Web: www.hi-hyperlite.com Email: [e-mail] Tel: + 1 [phone]
[23.6"]
[13.6"]
[47.2"]
[13.6"]
[2.2"][2.2"]
SENSOR
Remote controller
LIGHT
°
P3P2
Power supply
120-277VAC
Maximum load
@ -40°F~+158°F
(-40°C~+70°C)
Resistive/Halogen - 800W/1200W@120/277V
Fluorescent Ballast/CFL -
660W/1200W@120/277V
Electronic Ballast(LED) - 5A/5A@120/277V
Dim control output
0-10V, max.25mA sinking current
Detection radius/angle
30ft @40ft Height/360°
Mounting height
Max 24ft. @Lw1 Max 40ft. @LS2
Remote range
50ft. (15m) indoor, no backlight
Humidity
Max. 95%RH
Temperature
-40°F~+158°F(-40°C~+70°C)

Web: www.hi-hyperlite.com Email: [e-mail] Tel: + 1 [phone] Web: www.hi-hyperlite.com Email: [e-mail] Tel: + 1 [phone]
Industrial LED Linear High Bay Lights
(WILL Series)
Features
• UL&CUL No E490237 Suitable for damp location
• IP40 Rated Ingress Protection
BEFORE YOU INSTALL
Read these instructions completely and carefully.
ATTENTION
WARNING/ADVERTISEMENT
RISK OF ELECTRIC SHOCK
• Turn power off before inspection, installation or removal.
• Properly ground electrical enclosure.
• Follow all NEC and local codes.
• Use only UL or IEC approved wire for input/output connections.
Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own expense.
Save These Instructions
Use only in the manner intended by the manufacturer.
If you have any questions, contact the manufacturer.
Electrical Requirements
The LED driver must be supplied with 100-277
VAC, 50/60 Hz per product label and connected
to an individual properly grounded branch circuit,
protected by a 15 or 20 ampere circuit breaker.
Grounding Instructions
The grounding and bonding of the overall system
shall be done in accordance with National Electric
Code (NEC) Article 600 and local codes.
Prepare Electrical Wiring
1.Please connect the input wire in correct way,
white wire is N, black wire is L, green wire is
ground connection. Pls also make sure the
wire connection is fixed perfectly before using.
Announcements:
1.This equipment is only a professional installation. Non-professional personnel shall not remove or install the
equipment.
2.Please read the instruction manual before installation and keep it for future reference.
3.To avoid damage, falling, electric shock or fire, please do not modify the lamp or replace accessories without
confirming with the supplier
4.Maintenance/installation and replacement the lamps, please confirm to cut off the power supply, and the lamps
have set up a cooling. Please make sure the lamps have been properly installed before processing power.
5.Ensure the accurate and reliable connection.
6.Ensure that the product around the vent, the lamp cannot violate any fire prevention regulations when using.
P5P4
EMERGENCY LED DRIVER
- The LED Emergency Equipment for led product with external
driver allows the same LED fixture to be used for both normal
and emergency operation.
- In the event of a power failure, the LED Emergency Equipment
switches to the emergency mode and operates the existing
fixture for over 90 minutes.
- The unit contains a battery, charger and converter circuit in a
single can and is available in different mounting configurations
for individual fixture requirements.
EMERGENCY
LEDRIVER
UL Listed
For field or factory installation
Universal Input Voltage
100 277VAC 50 60Hz
AC Input Current
90mA max.
AC Input Power Rating
6.0W max.
Output Current and Voltage
420-800mA 25V 48V
Output Power
20W max.
Illumination Time
90 Minutes
Full Warranty
5 Years
Test Switch Charging Indicator Light
Low Voltage,illuminated Test Switch
Battery
High-Temperature, Ni-MH battery
Battery Charging Current
250mA
Recharge Time
24Hours
Temperature Rating
0°C to 50°C (32°F to 122°F)
LED Luminaire

Building Area & Task
Average
Maintained
Footcandles
(Horizontal) (FC)
Range of
Maintained
Footcandles
(Horizontal) (FC)
Average
Maintained
Footcandles
(Vercal) (FC)
Range of
Maintained
Footcandles
(Vercal) (FC)
Comments
INDUSTRIAL/MANUFACTURING
Assembly
Simple (Large Item)
30
15
15-60
Difficult (fine)
100
10-30
10
50-200
Component Manufacturing
Large
30
10-30
30
15-60
Medium
70-80
25-100
50
25-100
EXTERIOR
Parking (Covered)
5
1FC min, 10:1 Max to
Min Uniformity
Parking (Open) (Medium Acvity)
Lighng Zone 3 (Urban)
1.5
75-3
0.8
0.4-1.6
Lighng Zone 2 (suburban)
1
0.5-2
0.6
0.3-1.2
Gas Staon Canopy
12.5
10-15
Safety (Building Exterior)
1
0.5-2
If security is an issue-
raise average level to 3
RETAIL
General Retail (Ambient)
50
Department Store
40
20 - 80
15
7.5-30
Perimeter
75
35-150
Accent Lighng (Displays)
3-10 mes greater than
ambient light levels
AUTOMOTIVE
Showroom
70-80
25-100
10
7.5-30
Service Area
50
25-10
30
15-30
Sales Lot (Exterior)
Lighng Zone 3 (Urban)
20
10-40
20
10-40
Lighng Zone 2 (Suburban)
15
7.5-30
15
7.5-30
GROCERY
Circulaon
20
10-40
7.5
3.5-15
General Retail
70-80
25-100
20
10-40
Perimeter
50
25-100
BANKING
ATM
20
10-40
15
Vercal at face of ATM
NOTES:
• This guide is based on information gathered from the IES ‘The Lighting Handbook’ 10th Edition.
It is highly recommended that all lighting professionals refer to the full IES guide when specifying
lighting projects.
• At least half of users are in the 25 - 65 age range
• Horizontal—horizontal plane that average maintained foot-candles are measured
• Vertical—vertical plane the average maintained foot-candles are measured
• It is the responsibility of the to determine and provide appropriate lighting levels for
each space
Web: www.hi-hyperlite.com Email: [e-mail] Tel: + 1 [phone] Web: www.hi-hyperlite.com Email: [e-mail] Tel: + 1 [phone]
P7P6
Building Area & Task
Average
Maintained
Footcandles
(Horizontal) (FC)
Range of
Maintained
Footcandles
(Horizontal) (FC)
Average
Maintained
Footcandles
(Vercal) (FC)
Range of
Maintained
Footcandles
(Vercal) (FC)
Comments
WAREHOUSING & STORAGE
Bulky Items—Large Labels
10
5
Small Items—Small Labels
30
15
Cold Storage
30-40
10-30
10
5-15
Open Warehouse
30-40
10-30
Warehouse w/Aisles
30-40
10-30
10
5-15
COMMERCIAL OFFICE
Open Office
40
30-50
@30” Above Finished
Floor (AFF)
Private Office
40
30-50
@30” AFF
Conference Room
30
Mae surface
reflectance
for the table 40%
recommended
Restroom
18
75-30
Lunch & Break Room
15
5-20
EDUCATIONAL (SCHOOLS)
Classroom
40
30-50
@30” AFF
Gymnasium
Class I (Pro or Div. 1 College)
125
30
Class II (Div. 2 or 3 College)
80
20
Class III (High School)
50
150
Class IV (Elementary)
30
100
Auditorium
75
3-10
5
2.5-10
Corridor
25
10-40
Footcandles are the most common unit of measure used by lighting professionals to calculate light levels in
businesses and outdoor spaces. A footcandle is defined as the illuminance on a one square foot surface from a
uniform source of light. The Illuminating Engineering Society (IES) recommends the following footcandle levels to
ensure adequate illumination and safety for occupants. Below is a guideline for common areas to assist in achieving
appropriate light levels with the greatest energy-efficiency.
FOOTCANDLE LIGHT GUIDE
This guide is a collaborative efort of Energy Trust of Oregon and the Lighting Design Lab, Seattle, Washington.▲

www.hi-hyperlite.com
...
Web: www.hi-hyperlite.com Email: [e-mail] Tel: + 1 [phone] Web: www.hi-hyperlite.com Email: [e-mail] Tel: + 1 [phone]
P9P8
CERTIFICATE OF COMPLIANCE
Certificate Number: E490237
Report Reference: E490237
Issue Date: 2018-FEBRUARY-01
Only those products bearing the UL Certification Mark should be considered as being covered by UL's ▲
Certification and Follow-Up Service.
Look for the UL Certification Mark on the product▲
Additional Information:
www.ul.com/databaseSee the UL Online Certifications Directory at for additional information
NAMING RULES
UL CERTIFICATION
Base
XX
AAA
BB
CC
D
E
Model
Size
Power
Features
CCT
Voltage
Serial number
PHB
06=600mm
12=1200mm
110=110W
160=160W
220=220W
320=320W
NN
No funcon
SN
Sensing funcon
DM
Dimming funcon
EP
Emergency funcon
SD
Sensing+Dimming funcon
DE
Emergency+Dimming funcon
50=5000K
L=120-277Vac
0=130 lm/w
PHB06-110[DM]-50L0 Example: PHBXX-AAA[BB]-CCDE(PHB06-160[DM]-50L0)
