Hyundai ELANTRA HYBRID User manual

NP150-82021-A
(Rev 01/27/21)
Printing 01/31/21
☐ BLUE LINK
- Assist with creating MyHyundai.com account
- Assist with Blue Link enrollment
- Encourage customer to download the MyHyundai with Blue Link app
• To activate wipers, move the speed
control switch down to one of the three
positions (INT, LO, HI)
• To adjust “INT” speed, move the
speed control switch.
• To spray the washer fluid, pull the
lever towards you
• Push the lever up for a single wiper pass
☐ WINDSHIELD WIPER / WASHER - page 10
☐UNLOCKING VEHICLE - page 01
UNLOCK
TRUNK OPEN
LOCK
ALARM
Roadside Assistance: 1-800-243-7766
Consumer Affairs: 1-800-633-5151
Sirius XM®Radio: 1-800-967-2346
Blue Link: 1-855-2BLUELINK
(1-855-225-8354)
Sales Consultant Date Sales Manager Date
Customer Date
Email
☐ INTRODUCTION AND LOCATION OF THE SERVICE DEPARTMENT
☐ SET FIRST SERVICE APPOINTMENT
☐ REVIEW FACTORY RECOMMENDED MAINTENANCE SCHEDULE
☐ WAS THE CONDITION OF YOUR VEHICLE (AT DELIVERY) TO YOUR
SATISFACTION?
VOICE
RECOGNITION TIPS
Command Example
BLUETOOTH®
Dial <Phone #>
Call <Name>
“Dial
7-1-4-9-6-5-3-0-0-0”
“Call John Smith”
Command
(If equipped)
Example
NAVIGATION
Find Address
<House #, Street,
City, State>
“1-2-3-4-5 1st Street,
Fountain Valley”
Improving how you store your contacts can optimize your
Bluetooth® Voice Recognition performance:
• Use full names instead of short or single-syllable names
(“John or Dad”)
• Avoid using special characters/emojis or abbreviations
(“Dr.”) when saving contacts
Find <POI Name> “Find McDonald’s®”
The
Hyundai
ELANTRA
HYBRID
Quick Reference Guide
MIST
OFF
INT
LO
HI
MIST
OFF
INT
LO
HI PULL
MIST
OFF
INT
LO
HI PULL
MIST
OFF
INT
LO
HI PULL
MIST
OFF
INT
LO
HI PULL
MIST
OFF
INT
LO
HI PULL
MIST
OFF
INT
LO
HI PULL
MAINTENANCE
Looking For more detailed information? This Quick Reference Guide does not replace your vehicle’s
Owner’s Manual. If you require additional information or are unsure of a specific issue,We
recommend that you always refer to the vehicle’s Owner’s Manual or contact your authorized
Hyundai dealer. The information contained in this Quick Reference Guide is correct at the time
of printing; however, specifications and equipment can change without notice. No warranty or
guarantee is being extended in this Quick Reference Guide, and Hyundai reserves the right to
change product specifications and equipment at any time without incurring obligations.
Some vehicles are shown with optional equipment.
Scheduled Maintenance Normal Usage Severe Usage*
Engine Oil and Filter Replace 5,000 or 6 mos. Replace 3,750 or 6 mos.
Fuel Additive Add 8,000 or 12 mos. Inspect Same as Normal
Tire Rotation Perform 8,000 Perform 7,500
Air Cleaner Filter Inspect
Replace
8,000
24,000
Inspect
Replace
Same As Normal
More Frequently
Vacuum Hose Inspect Every 12 mos. Inspect Same As Normal
Climate Control Air Filter
(for Evaporator and Blower Unit) Replace 15,000 Replace More Frequently
Air Conditioning Refrigerant Inspect 8,000 Inspect Same As Normal
Brake Hoses & Lines Inspect 8,000 Inspect Same As Normal
Drive Shafts & Boots Inspect 8,000 Inspect 7,500
Exhaust Pipe & Mufer Inspect 15,000 Inspect Same As Normal
Front Disc Brake/Pads, Calipers & Rotors Inspect 8,000 Inspect More Frequently
Steering Gear Box, Linkage & Boots/
Lower Arm Ball Joint, Upper Arm Ball
Joint
Inspect 8,000 Inspect More Frequently
Suspension Mounting Bolts Inspect 8,000 Inspect Same As Normal
Brake uid Inspect 32,000 Inspect Same As Normal
Crankcase Ventilation Hose Inspect 32,000 Inspect Same As Normal
Fuel Filter Inspect 32,000 Inspect Same As Normal
Fuel Lines, Fuel Hoses and Connections Inspect 32,000 Inspect Same As Normal
Fuel Tank Air Filter Inspect 32,000 Inspect Same As Normal
Rear Disc Brake/Pads, Parking Brake Inspect 32,000 Inspect More Frequently
Vapor Hose, Fuel Tank & Fuel Filler Cap Inspect 32,000 Inspect Same As Normal
Spark Plugs Replace 100,000 Replace More Frequently
Coolant 1st Replace 120,000 or 120 mos.
Add’l Replace 30,000 or 24 mos. Replace Same As Normal
Automatic Transmission Fluid No check, No service required Replace 60,000
*See Owner’s Manual for details.

HYUNDAI VEHICLE OWNER PRIVACY POLICY
Your Hyundai vehicle may be equipped with technologies and services
that use information collected, generated, recorded or stored by the
vehicle. Hyundai has created a Vehicle Owner Privacy Policy to explain
how these technologies and services collect, use, and share this
information.
You may read our Vehicle Owner Privacy Policy on the Hyundaiusa.com
website at https://www.hyundaiusa.com/owner-privacy-policy.aspx
If you would like to receive a hard copy of our Vehicle Owner Privacy
Policy, please contact our Customer Care Center at:
Hyundai Customer Care
P.O. Box 20850
Fountain Valley, CA 92728
800-633-5151
[e-mail]
Hyundai’s Customer Care Center representatives are available Monday
through Friday, between the hours of 6:00 AM and 5:00 PM PST
and Saturday between 6:30 AM and 3:00 PM PST (English).
For Customer Connect Care assistance in Spanish or Korean,
representatives are available Monday through Friday between 6:30 AM
and 3:00 PM PST.

MIST
OFF
INT
LO
HI PULL
MODE
Steering wheel
adjustment
Page 02
Instrument
cluster
Page 11
Head lights
Page 09
Electric
Parking Brake
(EPB)
Page 51
Wiper and
washer
Page 10
Cruise Control/
Smart Cruise
Control
Page 48
Navigation
Page 27
Climate
control
Page 19
USB data/
Smartphone
port
Page 30
WARNING!
To reduce the risk of serious injury to yourself and others,
read and understand the important SAFETY
INFORMATION in your Owner’s Manual.
Use this Quick Reference Guide to learn
about the features that will enhance your
enjoyment of your Hyundai. More
detailed information about these features
are available in your Owner’s Manual.
* Some vehicles may not be equipped
with all the listed features.
FEATURES AND CONTROLS
12 volt battery reset switch 17
Climate control 19
Driver's main controls 02
Fuel filler door 06
Headlights 09
Hybrid Battery SOC (State of charge) gauge 15
Hybrid system modes 16
Instrument cluster 11
Instrument panel illumination 1 4
Interior lights 08
LCD display mode control 13
Remote & Smart key 01
Seat-Front seat adjustment 03
Seat-Headrest adjustment 04
Seat-Seat belt adjustment 04
Seat-Seat warmer 05
Steering wheel adjustment 02
Sunroof 07
Trunk-Smart trunk 06
Trunk-Trunk opening 05
Vehicle power gauge 15
View modes 13
Warnings and indicators 14
Wipers and washer 10
INFOTAINMENT
AM/FM Radio 26
Android Auto™ 33
Android Auto™ wireless 35
Apple CarPlay™ 37
Apple CarPlay™ wireless 41
Audio mode 25
Bluetooth operational tips 24
Bluetooth phone operation 23
Bluetooth phone pairing 23
Homelink wireless control system 31
Navigation 27
Steering wheel audio control 26
USB data/Smartphone port 30
Wireless cellular phone charging system 29
DRIVING
Auto Hold 51
Blind-Spot Collision-Avoidance Assist(BCA)44
Cruise Control (CC)/ Smart Cruise Control (SCC) 48
Digital key pairing 53
Drive mode 46
Electric Parking Brake (EPB) 51
Forward Collision-Avoidance Assist (FCA) 44
Highway Driving Assist (HDA) 49
Lane Following Assist (LFA) 43
Lane Keeping Assist (LKA) 43
Leading vehicle departure alert 49
Near field communication (NFC) 54
Rear Cross-Traffic Collision-Avoidance Assist (RCCA) 50
Rear Occupant Alert (ROA) 45
Reverse Parking Distance Warning(PDW) 52
Safe Exit Warning (SEW) 45
Tire Pressure Monitoring System (TPMS) 47

Quick Reference Guide I 02
01 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
FEATURE AND CONTROLS
Driver’s door Lock / Unlock
· To Unlock : Press the button on the outside of the handle.
※Touch sensor type (If equipped)
Touch the touch sensor on the handle
(only the inside part for at least 1 second.)
· To Lock : Press the button or touch sensor on the outside handle.
NOTE: User selectable option:
Please see section 5 from Owner’s
Manual for more details.
Removing the mechanical key
Slide and hold the release button
A
to remove the mechanical key.
To unfold the mechanical key, press
the release button on the remote.
* CAUTION
· If you locked the door with the touch sensor on the door handle,
the doors cannot be unlocked with the sensor within 3 seconds.
· If you unlocked the door with the touch sensor on the door handle,
the doors cannot be locked with the sensor for up to 2 seconds.
REMOTE & SMART KEY
Lock
Unlock
Engine remote
start button
Trunk Unlock
Panic
A
NOTE: To start the vehicle remotely, press and hold the remote start
button for over 2 seconds within 4 seconds after locking the doors.
STEERING WHEEL ADJUSTMENTS
1. Pull the lever
1
down.
2. Set the angle
2
and distance
3
.
3. Pull the lever
1
up to lock
position.
NOTE: Do not adjust while driving.
1
2
3
Move the lever towards L (left) or R
(right) on the switch.Then adjust the
mirror by using the mirror adjustment
control switch.
DRIVER'S MAIN CONTROLS
Outside Rearview Mirror
Power window lock button
Disables the power window switches
on the rear passenger doors.
Door Lock
Locks/unlocks all doors.
Press past detent to fully open/close
window.
Window Auto down/up (if equipped)

Quick Reference Guide I 04
03 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
FEATURE AND CONTROLS
2
3
FRONT SEAT ADJUSTMENT Manual
Forward and Backward
1
Seat Height
2
(for the Driver’s Seat)
Seatback Angle
3
- Push down on the lever several times to
lower the seat cushion.
- Pull up on the lever several times to raise it.
FRONT SEAT ADJUSTMENTPower, forthe Driver's Seat
Forward and Backward
1
Seat Height
Forward and backward adjustment (if equipped)
Lumbar Support (driver's seat only)
3
Seatback Angle
2
123
1
HEADREST ADJUSTMENT
To Raise Headrest:
Pull headrest up.
To Lower Headrest:
Press lock button while pressing
down on headrest.
To move headrest forward:
Pull headrest forward.
To move headrest backward:
Pull headrest fully forward and
release it.
SEAT BELT ADJUSTMENT (Front seat)
Pull up to raise.
Press button and
push down to
lower.

Quick Reference Guide I 06
05 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
FEATURE AND CONTROLS
Key FOB / Smart Key
Press and hold the trunk
unlock button on the remote
key FOB or Smart Key for
about 1.5 seconds
Trunk Release Lever
From inside the vehicle,
pull the trunk release lever
located inside the vehicle.
TRUNK OPENING
Opening the trunk
The trunk can be opened using the key FOB
or Smart Key, by pressing the trunk release
button under the emblem, or by pulling the
trunk release lever inside the vehicle.
SMARTTRUNK
FUEL FILLER DOOR
Smart Trunk
Trunk will slightly open automatically
when detecting smart key within range
near the trunk for more than 3 seconds.
To open fuel filler door :
The fuel ller door must be opened from inside the vehicle by pulling up
the fuel ller door opener.
1. Turn the engine off.
2. Pull up the fuel ller door opener.
To enable Smart Trunk function:
Vehicle must be in P (Park) to adjust
settings in the User Setting mode.
1. Select "Door/Trunk" in the User
Settings in the instrument cluster.
2. Check "Smart Trunk".
NOTE: Function is active after 15 seconds when all doors are closed and
locked and key is not detected. The vehicle will also provide an audible and
visual alarm while activating. For more details, refer to Owner's Manual.
Seat Warmer
OFF HIGH ( )MED ( ) LOW ( )
Press the button
A
to increase heat
MIST
OFF
INT
LO
HI PULL
MODE
SEAT WARMER
HIGH
MEDIUM
LOW
A

Quick Reference Guide I 08
07 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
FEATURE AND CONTROLS
INTERIOR LIGHTS
SUNROOF
Sunshade
The sunshade will open automatically
with the sunroof when the glass panel
moves. If you want it closed, move the
sunshade manually.
Sliding the sunroof
Pull the sunroof control lever
backward to open the sunroof.
(This operation will also open
the Sunshade, if it is not in the
open position.)
Push the sunroof control lever
forward to close the sunroof.
Tilting the sunroof
To Open:
Push and hold the sunroof
control switch upward to tilt the
sunroof.
To Close: Push and hold the sunroof
control switch forward to close the
sunroof.
Map Lamp Switch (Lens Switch)
1 2
3
44
Interior Light ON position ( )
1
Interior Light OFF position ( )
2
Room Lamp Switch ( )
5
Press the switch to the left
1
to turn
the map lamp
4
and room lamp
5
.
Press the switch to the right to leave
the map lamp
4
and room lamp
5
off.
Door Mode Position ( )
3
When the Switch is Door Mode
Position (Switch is not pushed), The
map lamp
4
and room lamp
5
ON
if any door is opened and will turn off
after all doors are closed.
Press the lens to turn on and off for
each side of map lamp.
Press the switch to turn on and off
the room lamp.
4
Room Lamp (Rear)
5

Quick Reference Guide I 10
09 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
FEATURE AND CONTROLS
WIPERS AND WASHER
Intermittent Wipe Time Adjustment
Move the control switch.
Windshield Washer
Pull the lever gently toward you to
spray washer fluid on the windshield
and to run the wipers 1-3 cycles.
MIST
OFF
INT
LO
HI PULL
MIST
OFF
INT
LO
HI PULL
Fastest wiper speed
Slowest wiper speed
MIST
OFF
INT
LO
HI PULL
MIST
OFF
INT
LO
HI PULL
MIST
OFF
INT
LO
HI PULL
MIST
OFF
INT
LO
HI PULL
MIST
OFF
INT
LO
HI PULL
MIST
OFF
INT
LO
HI PULL
MIST -Single wipe
INT - Intermittent wipe
LO -Low wiper speed
HI -High wiper speed
OFF
PULL
HEADLIGHTS
Parking light
OFF
Auto light
Headlight
Headlight Delay
Headlights may stay on for 15 seconds after exiting and locking
vehicle. Press remote lock button twice to turn headlights off.
Turn signals and lane change
signals
Flashing headlights
PULL
High beam
PUSH
High Beam Assist
PUSH
NOTE:
To turn off high beam,
pull the lever towards
you.
High Beam Assist
1. Select AUTO position on lever.
2. Turn on the high beam by pushing the lever
away from you. High Beam Assist
Indicator will illuminate
3. High Beam Assist will turn on when vehicle
speed is above 25 mph.
4. To turn off High Beam Assist, push the lever
forward.

Quick Reference Guide I 12
11 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
FEATURE AND CONTROLS
Type B (LCD display)
1
Power gauge
2
Speedometer
3
Hybrid Battery SOC (State of Charge)
gauge
4
Fuel Gauge
5
Warning and Indicator Lights
6
LCD Display (including trip computer)
3
4
1
2
5
6
3
4
1
2
5
5
6
Type A
INSTRUMENT CLUSTER

Quick Reference Guide I 14
13 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
FEATURE AND CONTROLS
MODE
OK
MODE
OK
VIEW MODES
LCD DISPLAY MODE CONTROL
Modes Symbol Explanation
Trip Computer This mode displays driving information like
the tripmeter, fuel economy, and so on.
Turn By Turn (TBT)
(if equipped)
This mode displays the state of the
navigation.
Drive Assist
(if equipped)
This mode displays the state of:
- Smart Cruise Control system
Lane Keeping Assist
Lane Following Assist
- Driver Attention Warning
- Tire pressure
User Settings Displays service interval and warning
messages. Changes settings.
Warning Displays service interval and warning
messages.
MODE
OK
MODE
OK
1
23
1
: VIEW MODE button for
changing modes
2
: MOVE switch for changing
items
3
: SELECT/RESET button for
setting or resetting the
selected item
WARNINGS AND INDICATORS
Air bag warning light
Electric Power Steering
(EPS) warning light
Seat belt
warning light
Parking brake & Brake
fluid warning light
Electronic Brake Force Distribution (EBD)
system warning light
Low tire pressure
warning indicator/TPMS
malfuction lamp
Low fuel level
warning light
Low beam indicator
High Beam Assist
Indicator
Light ON indicator
Forward Collision-
Avoidance Assist
warning light
Lane Following Assist
Indicator
Icy Road
Warning Light
Headlamp Warning
Light
Anti-lock Brake System
(ABS) warning light
High beam indicator
Electronic Stability
Control (ESC) indicator
Master warning light
Electric Parking Brake
(EPB) warning light
Engine oil pressure
warning light
Charging system
warning light
Immobilizer indicator
Malfunction Indicator
Lamp (MIL)
Electronic Stability Control
(ESC) OFF indicator
Cruise indicator
Lane Keeping Assist
Indicator
SPORT mode
indicator
AUTO HOLD indicator
Turn signal indicator
Engine coolant
temperature warning light
INSTRUMENT PANEL ILLUMINATION
Press - or + to adjust instrument
cluster illumination brightness.
EV mode indicator

Quick Reference Guide I 16
15 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
FEATURE AND CONTROLS
Ready indicator
When the vehicle is ready to be driven, this indicator
is illuminated.
When the ready indicator goes off or blinks, we recommend
the vehicle be checked by an authorized HYUNDAI dealer.
EV mode indicator
This indicator illuminates when the vehicle is driven by the
electric motor.
Service warning light
If a problem with the hybrid vehicle control system
occurs, the service warning light will illuminate.
We recommend the vehicle be checked by an authorized
HYUNDAI dealer.
Main indicators in cluster for Hybrid Vehicle
The power gauge indicates whether the current
driving condition is fuel efficient or not.
CHARGE
Shows that the energy made by the vehicle is
being converted to electrical energy.
(Regenerated energy)
ECO
Shows that the vehicle is being driven in an Eco-
friendly manner.
POWER
Shows that the vehicle is exceeding the Eco-
friendly range.
VEHICLE POWER GAUGE
This gauge indicates the remaining hybrid
battery power. If the SOC is near the "L (Low)"
level, the vehicle
automatically operates the engine to charge
the battery.
HYBRID BATTERY SOC STATE OF CHARGE GAUGE
Energy Flow Mode
This screen displays the energy flow
from the engine and battery.
Fuel Economy Mode
This screen displays average fuel
economy. The graph shows fuel
economy for the last 30 minutes and
it is updated every 2 minutes and 30
seconds.
Select the Hybrid Icon on the home screen.
HYBRID SYSTEM MODES

Quick Reference Guide I 18
17 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
FEATURE AND CONTROLS
This vehicle does not have a
replaceable 12V flooded lead acid
battery. The 12V battery is
integrated into the lithium high
voltage battery assembly. Is it
automatically protected against
vehicle current draw when a
minimum level of 12.8V 10% SOC
level is reached. The 12V Battery
Reset Switch has to be activated in
order to start the vehicle. This
should negate the need to jump
start the car.
If the door is locked you will need to
use the manual key to enter the
vehicle after removing the lock
access cover.
1. Press the lever located under the
cover with mechanical key.
1
2. While pushing the lever so that
the mechanical key does not fall
out of the cover hole, slowly push
it towards the rear of the vehicle
and remove the cover.
2
3. After removing the cover, only
driver’s door can be locked or
unlocked by using mechanical
key.
4. Turn the key toward the rear of the
vehicle to lock and toward the
front of the vehicle to unlock.
3
12 VOLT BATTERY RESET SWITCH
1. Press the 12V Battery Reset switch to reconnect the 12V battery.
2. Start the vehicle within 15 seconds of pressing the 12V Battery
Reset switch.
3. After starting vehicle ( indicator on), operate the vehicle safely
outdoors stopped and/or drive it for 30 minutes total to charge
the 12V battery fully.
If the reset does not work due to over discharge of the 12V battery,
try to jump-start the vehicle. For more detailed information, please
refer to your Owner’s Manual.
If the vehicle Start/Stop button does not respond (it has no indicator
light) and the dash does not illuminate, the vehicle may be operated
after the 12V Battery Reset Switch is activated per the instructions
below.
1
2
3

Quick Reference Guide I 20
19 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
FEATURE AND CONTROLS
5
Rear Window Defroster Button
6
Air intake control button
7
A/C (Air conditioning) button
1
Fan Speed Control Knob
2
Temperature control knob
3
Mode selection knob
4
Front windshield defroster position
MANUAL CLIMATE CONTROL
+
0
+
0
+
0
3
4
1
56 67
2
3. Set the fan speed to
the medium speed.
2. Select the warmest
temperature.
+
0
+
0
+
0
+
0
+
0
+
0
+
0
+
0
+
0
+
0
+
0
+
0
1. Select the Front
Windshield Defrost
Mode.
Face-Level
Bi-Level
Floor-Level
Floor & Defrost-Level
Defrost-Level
Changes the direction of
the air flow as following:
NOTE:
To reduce the tendency of the glass fogging and also to improve visibility,
keep the interior surface of the windshield clean by wiping it with a clean
cloth and glass cleaner. In addition, select air intake control to the
outside (fresh) air position whenever possible while operating the vehicle.
Outside (fresh) air
position
Recirculated air
position
+
0
+
0
+
0
+
0
+
0
+
0
Press to activate/deactivate the
rear defroster.
A/C MAX mode
Rear Window Defroster
A/C MAX Mode automatically
engages Recirculated air position
and air conditioning. Return to
normal A/C mode after the vehicle
interior has cooled sufficiently.
Mode selection
Defogging / Defrosting Air intake control

Quick Reference Guide I 22
21 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
FEATURE AND CONTROLS
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
AUTOMATIC CLIMATE CONTROL
Air intake control
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
Automatic heating /
Air conditioning
Auto fan speed control
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
Changing the direction of the air flow as follow.
Mode selection
Outside (fresh) air position
(LED OFF)
Recirculated air
position (LED ON)
Defogging / Defrosting
3. Set the fan speed to
the highest speed.
2. Select warmest
temperature.
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
HIGH
MEDIUM
LOW
1. Press the defrost
button.
System off
Pressing the OFF button will
place the system in the OFF
mode.
1. The fan speed is controlled automatically
in 3 available settings.
2. Pressing the AUTO button will activate
the AUTO function and change the
AUTO fan speed setting
3. Settings: HIGH → MEDIUM → LOW
4. If the temperature is set to either ‘HI’ or
‘LO’, the fan speed setting will be ‘HIGH’.
* For detailed precautions and instructions,
see the Owner’s Manual.
• Climate control fan will turn off.
• Outside (fresh) air position will
be selected.
• Vented air will be at last set
temperature.
NOTE:
To reduce tendency of the glass fogging and also to improve
visibility, keep the interior surface of the windshield clean by wiping it
with a clean cloth and glass cleaner. In addition, select air intake
control to the outside (fresh) air position whenever possible while
operating the vehicle.
12
7
4
6
3
2
5 10
8 89
11
1
1
Driver’s temperature control knob
2
Passenger’s temperature control knob
3
AUTO (automatic control) button
4
SYNC button
5
OFF button
6
Front windshield defroster button
7
Air conditioning button
8
Air intake control button
9
Rear window defroster button
10
Fan speed control button
11
Mode selection button
12
Climate control information screen

Quick Reference Guide I 24
23 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
INFOTAINMENT
Making a call using voice recognition:
The menu tree identies available voice recognition Bluetooth®functions.
Calling by Name:
1. P ress button.
2. Say the following command:
• “Call <John Smith>”: Connects the call to John.
• “Call <John Smith> on <on Mobile/at Work/at Home>: Connects the
call to John’s Mobile, Home, or Work phone number.
Dialing by Number:
1. Press button.
2. Say “Dial Number”.
3. Say desired phone number.
For complete list of commands, refer to your Owner’s Manual.
To Answer a Call: • Press button on the steering wheel.
To Reject a Call: • Press button on the steering wheel.
To Adjust Ring Volume: • Use the VOLUME buttons on the steering wheel.
To Transfer a Call to the Phone
(Private call on handset – do not use while driving):
•Press and hold button on the steering wheel until the audio system
transfers a call to the phone.
To Finish a Call: • Press button on the steering wheel.
BLUETOOTH®OPERATIONAL TIPS
In the following situations you or the other party may have difficulty
hearing each other:
1. Keep the Bluetooth®volume to a low level. High level volume may result in
distortion and echo.
2. When driving on a rough road, high speeds and/or with the window open.
3. When the air conditioning vents are facing the microphone and/or when
the air conditioning fan is at the max speed.
Steering wheel bluetooth® control
MODE
MODE
1
TALK Activates voice recognition.
2
CALL Places and transfers calls.
3
END Ends calls or cancels functions.
2 3
1
Pairing tutorials, phone compatibility and
operational tips can be found through the
Smart QR code using the QR reader
application on your Smartphone.
BLUETOOTH PHONE PAIRING
BLUETOOTH PHONE OPERATION
Phone setup (pairing phone)
2. Select the function to connect.
3. Turn on Bluetooth on the Bluetooth device to connect and select the
vehicle system on the list of searched devices.
4. Bluetooth is connected.
1. Turn Bluetooth® on from your mobile phone. : All Menus > Setup >
Device Connections > Bluetooth > Bluetooth Connections > Add New.
MODE
NOTE: Vehicle must be parked to complete pairing process.
Note: Vehicles without Navigation require a compatible Apple or
Android phone connected to the USB port or Wireless connection to use
the Voice recognition button on the steering wheel.
- If connected via Bluetooth you cannot place a call using VR, you can
only accept and end a call.
MAP
NAV

Quick Reference Guide I 26
25 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
INFOTAINMENT
Press POWER button
A
to turn radio on.
•
TUNING/LISTENING TO CHANNELS
1. Press the RADIO button
B
.
2. Press the search backward button SEEK
C
or the search forward
button TRACK to desired channel.
NOTE: A clear view of the southern sky is recommended to ensure SXM®
radio reception.
•
SETTING PRESET MEMORY BUTTONS (FM/AM/SXM
® )
Press and hold any preset button
D
until an audible beep is
heard to store current channel.
•
ADJUSTING THE SOUND CONTROL
1. Press SETUP button .
2. Select Sound button on screen.
3. Touch on-screen arrows to adjust
desired setting.
MAP
NAV
AUDIO MODE
A
BC
E
D
MODE
MODE
MODE
MODE
MODE
MODE
STEERING WHEEL AUDIO CONTROL
MODE
MODE
MODE
MODE
MODE
MODE
2
3
1
1
VOLUME
Raises or lowers speaker volume.
2
SEEK/PRESET
Change station.
3
MODE
Change the audio source.
NOTE:
1. Users can set the volume level of each source (FM, AM, SXM, USB,
BT and etc.) individually by adjusting the “A” knob.
2. When the volume of a source is adjusted to the desired level, it will
be automatically saved at that setting. Thus, when the user
changes source and reverts back, the volume will be set at the last
desired level.
A
B
AM/FM RADIO
2
3
1
RADIO NOISE CONTROL MODE
1. Press the AMenu button
2. Press the BFM Radio Noise Control button
3. Select Radio Noise Control Mode
1
,
2
,
3
as your preference.
※ Default :
2
Minimum Noise Reduction

Quick Reference Guide I 28
27 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
INFOTAINMENT
NAVIGATION
Basic features on the map screen
1
Displays the Home screen.
2
Used to change the map display mode.
3
The scale of the map automatically changes.
4
You can adjust the volume of navigation or GPS warning sound.
5
Displays the point to change the driving direction.
6
Displays the next point to change the driving direction.
7
Displays the lanes in different colors.
8
Displays quick menu items that can be used during guidance.
9
Can pause or cancel the route guidance.
10
Displays the remaining distance to the destination and the estimated
time of arrival. For more details, press the information item.
11
Displays or hides the detailed guidance.
12
Displays the system information on the map. (It can display up to two
items.)
11
22
33
7
7
12
11
11
4
4
8
8
9
9
10
10
5
5
6
6
Destination search screen
1
Returns to the previous step.
2
You can change the Navigation-related settings.
3
Search for a location by entering various types of keyword such as
place name and address.
4
Search for POIs by category to set as a destination.
5
Select any of previous destinations to set as a destination.
6
Register the location or use the address book for setting a
destination.
7
You can easily search for Hyundai Dealerships.
8
You can cancel guidance to the destination.
9
You can see the entire route information to the destination.
10
You can edit the current route so that you can travel via waypoints on
the way to the destination.
11
You can change the route search criteria to resume routing.
NOTE: To stop route guidance, press Pause Route.

WIRELESS CELLULAR PHONE CHARGING SYSTEM if equipped
There is a wireless cellular phone
charging system inside the front
console. The system will operate
when all doors are closed, and the
ignition switch is in the ACC/ON
position. The wireless charging
pad is equipped with a cooling
fan to help prevent overheating
while charging.
The wireless charging must be enabled in the User Settings prior
to using.
Using the Wireless Phone Charging System
1. Place a compatible (Qi enabled) device on the center of the
charging pad.
2. The wireless charging symbol will be shown on the upper right
corner of the audio display when the wireless charging begins.
3. If the charging symbol does not come on after placing your
device on the pad, slightly adjust the location of your device on
the pad until the indicator light comes on.
NOTE:
•Wireless charging systems are less efficient than conventional
charging using a cable. As a result, higher device operating
temperatures may be experienced during use and, thick phone
cases may negatively affect charging speed and temperature.
•Do not place credit cards or other magnetic media on the pad
as they could be damaged by the magnetic field. In addition,
avoid placing any metallic objects on the pad as they may
impede charging performance.
The USB data port can be used to
connect an external audio device
and listen to it through the audio
system in your vehicle.
The USB data port can also be used
to access Android Auto or Apple Car
Play with your compatible phone.
Insert the USB charger into the USB
charging port, and re-charge a
smart phone or a tablet PC.
USB DATA/SMARTPHONE PORT
Quick Reference Guide I 30
29 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
INFOTAINMENT

Quick Reference Guide I 32
31 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
INFOTAINMENT
HOMELINK WIRELESS CONTROL SYSTEM
1. Press and release
1
,
2
or
3
button.
• If the indicator
7
is turned ON in Orange, go to Step 3
(programming mode)
• If the indicator
7
is continuously turned ON or ashes in Green
rapidly several times, go to Step 2 (erasing mode)
2. Press and hold the button you wish to program for approximately
15- 25 seconds until the LED ashes in Orange for several times.
3. Hold the Garage Door Opener Original Transmitter near the
HomeLink Mirror.
4. Press the Original Transmitter button until the indicator
7
is
turned continuously ON or ashes in Green for approximately 10
seconds and it indicates the programing is completed.
NOTE: If the indicator
7
ashes in Green continuously, but if the
garage door opener does not operate, please continue to follow
Rolling Code Programming steps below.
Indicator
4
&
6
:
Flashes in orange → “Closing” & “Opening”
Solid Green → “Closed” & “Opened”
123
4
4
5
7
6
6
Rolling Code Programming
•You may need a ladder to access your garage door opener.
•You may need help from a second person.
•Be prepared some of the steps are time sensitive.
1. Firmly press and release the “Learn”, Smart”, or “ Program” button
of garage door opener on the ceiling while the indicator
7
ashes
in Green. Once the button is pressed, you have approximately 30
seconds to initiate the next step.
2. Return to the vehicle and rmly press the HomeLink button, hold
for two seconds and release the button up to three times. Do not
press the HomeLink button rapidly. At this point programming is
complete and your device should operate.
For more detailed information, please refer to your Owner’s manual
or visit www.homelink.com or call [phone]
Two Way Communication
Some new garage door openers come equipped with a two-way
communication feature. If your garage door opener has this feature,
please also continue to follow the Rolling Code Programming steps
below. For more information and programming tips on two-way
communication please visit www. homelink.com/compatible/two-
waycommunication or call (800)-355-3515.
NOTE: If your garage door opener has Two-Way Communication
functionality, it is possible for HomeLink to stop functioning the garage
door shortly after initial programming, if the Two-Way Communication
Programming wasn’t properly completed. If you experience this,
completing the “Programming a New HomeLink Button” and “Two-
Way Communication Programming” will restore door operation.

Quick Reference Guide I 34
33 I Quick Reference Guide
ELANTRA HYBRIDHYUNDAI
INFOTAINMENT
CAR SETUP
1. Press the SETUP button on the radio.
2. Touch the “Device Connections”
icon on screen.
3. Select Android Auto
4. Select Enable Android Auto
5. Connect your Android phone to the vehicle USB port. Agree to the
notification and disclaimers on your phone then the “Android Auto”
icon will appear confirming the setup.
For more detailed information on how to operate Android Auto, please
refer to your display audio or navigation manual.
For additional Android Auto support, please refer to the Android Auto
Support Website
https://support.google.com/androidauto/
Android Auto, Google Play, Android, and other marks are trademarks
of Google Inc.
PHONE SETUP
Turn on Bluetooth®on your phone and connect the micro USB cable to
your phone and the USB port on the vehicle.
Phone will prompt you to download the Android Auto app and update
other needed apps (e.g. Google Maps™, Google Play Music™, Google
Now™).
NOTE:
Vehicle must be parked.
- Location mode setting should be set to High accuracy.
- Car and phone setup should be completed in one sitting. If phone
setup needs to be resumed, recommend to Force Stop the Android
Auto app on the Phone then reopen the app and accept the
Disclaimer notifications.
REQUIREMENTS:
- USB cable
- OS Android™ 5.0 or higher
- Compatible Android Phone
- Data and wireless plan for applicable features
BEFORE YOU BEGIN:
- Android Auto features may operate differently than on your phone.
- Message and data charges may apply when using Android Auto.
- Android Auto relies on the performance of your phone. If you
experience performance issues:
- Close all apps and then restart them
- Disconnect and then reconnect your phone
- Using the USB cable that was provided with your phone is
recommended.
- When Android Auto is active, your in-vehicle voice recognition
system is disabled and you will be using talk to Google™ to make
your requests.
ANDROID AUTO SUPPORT
https://support.google.com/androidauto/
ANDROID AUTO ™
