Hyundai GENESIS User manual

Scheduled Maintenance Normal Usage Severe Usage*
Engine Oil & Filter Replace 7,500 or
12 mos.
Replace 3,000 or 3 mos.
Vacuum Hose Inspect 7,500 Inspect Same As Normal
Air Cleaner Filter Inspect
Replace
7,500
30,000
Inspect
Replace
More Frequently
More Frequently
Power Steering Fluid Inspect 7,500 Inspect Same As Normal
Climate Control Air Filter Replace 10,000 or
12 mos.
Replace More Frequently
Fuel Tank Air Filter Inspect
Replace
15,000
30,000
Inspect
Replace
Same As Normal
Same As Normal
Electronic Throttle Control Inspect 15,000 Inspect Same As Normal
Brake Hoses & Lines Inspect 15,000 Inspect Same As Normal
Front Disc Brake Pads, Calipers & Rotors Inspect 15,000 Inspect More Frequently
Exhaust Pipe & Muffl er Inspect 15,000 Inspect Same As Normal
Suspension Mounting Bolts Inspect 15,000 Inspect Same As Normal
Steering Gear Box, Linkage & Boots/
Lower Arm Ball Joint, Upper Arm Ball Joint
Inspect 15,000 Inspect More Frequently
Power Steering Pump, Belt & Hoses Inspect 15,000 Inspect Same As Normal
Drive Shaft & Boots Inspect 15,000 Inspect 7,500 or 6 mos.
Air Conditioning Refrigerant Inspect 15,000 Inspect Same As Normal
Fuel Lines, Fuel Hoses & Connections Inspect 30,000 Inspect Same As Normal
Crankcase Ventilation Hose Inspect 30,000 Inspect Same As Normal
Vapor Hose & Fuel Filler Cap Inspect 30,000 Inspect Same As Normal
Drive Belt Inspect 30,000 Inspect Same As Normal
Brake Fluid Inspect 30,000 Inspect Same As Normal
Rear Disc Brake Pads, Parking Brake Inspect 30,000 Inspect More Frequently
Fuel Filter Replace 37,500 Replace Same As Normal
Automatic Transaxle Fluid Inspect 37,500 Inspect Same As Normal
Coolant 1st Replace
Add. Replace
60,000 or
60 mos.
30,000 or
24 mos.
Replace
Replace
Same As Normal
Same As Normal
Valve Clearance (3.8L Only) Inspect 60,000 Inspect Same As Normal
Spark Plugs (Iridium Coated) Replace 100,000 or
10 yrs.
Replace More Frequently
*See Owner’s Manual for details.
Maintenance
Looking For More Detailed Information? This Quick Reference Guide does not replace your vehicle’s Owner’s
Manual. If you require additional information or are unsure of a specific issue, you should always refer to the
vehicle’s Owner’s Manual or contact your authorized Hyundai dealer.
The information contained in this Quick Reference Guide was correct at the time of printing; however, specifications
and equipment can change without notice. No warranty or guarantee is being extended in this Quick Reference
Guide, and Hyundai reserves the right to change product specifications and equipment at any time without incurring
obligations. Some vehicles are shown with optional equipment. Specifications apply to U.S. vehicles only. Please
contact your Hyundai dealer for current vehicle specifications.
Roadside Assistance: 1-800-243-7766
Consumer Affairs: 1-800-633-5151
XM®Radio: 1-800-967-2346
www.hyundai.com
NP150-G2010
Rev 9/18/09
Printing XX/XX/09
HYUNDAI_GENESIS
QUICK REFERENCE GUIDE

AUTO
OFF
A/C OFF
H M R
MODE
TEMP
DUAL
PASSENGER
PASSENGER
A
TEMP
FRONT
PASS
AIR BAG
REAR
POWER
VOL
FM/AM CD/AUX DISPLAY
INFO
SETUPTUNE
SCAN
XM
1
RPT
2 3 4 5 6
RDM
SEEK
TRACK
CAT
FOLDER
PUSH
ENGINE
START
STOP
VOL
VOL
MODE
CANCEL
SET
RES
ON
OFF
DISP
RESET
TRIP
MUTE
SCAN
F
C
260
240
220
200
180
160
140
120
20
40
60
80
100 km/h
Trunk
Release
Page 19
Refueling
Page 9
Power
Windows
and Auto
Up/Down
Function
Page 7
Outside
Rearview
Mirrors
Page 6
Driver
Position
Memory
System*
Page 7
Rear
Sunshade*
Page 18
Parking
Assistance
System*
Page 18
Cruise
Control/
Smart
Cruise
Control
Page 16
Parking
Brake/
Electronic
Parking
Brake*
Page 4
Steering
Wheel Power
Adjustment**
Page 7
Clock
Page 14
Windshield
Wiper/Washer
Page 9
Occupant
Classification
System
Page 14
Audio
Systems
Pages 10-13
Engine
Start/Stop
(with Smart
Key)
Page 5
Climate
Control
Page 14
Trunk
Lock
Button***
Page 19
Trip Computer
Page 17
Audio Systems....................10-13
Basic Safety Precautions....... 6
Bluetooth Connectivity ......... 15
Climate Control ...................... 14
Clock .................................... 14
Cruise Control/
Smart Cruise Control............ 16
6-Disc CD Changer* ............. 13
Door Entry
(with Smart Key) .................... 4
Driver Position Memory
System* ................................. 7
Engine Start/Stop
(with Smart Key) .................... 5
Front Headrest Adjustment.... 5
Front Seat Adjustment ............. 5
Front Seat Shoulder Belt
Adjustment ............................ 6
Headlights and Fog Lights..... 8
Homelink®Wireless Control
System.................................. 18
iPod®Use ............................. 13
Occupant Classification
System.................................. 14
Outside Rearview Mirrors ...... 6
Parking Assistance
System* ................................ 18
Parking Brake/Electronic
Parking Brake*....................... 4
Power Windows and Auto
Up/Down Function................. 7
Rear Sunshade*.................... 18
Refueling................................ 9
Remote Keyless Entry/
Smart Key.............................. 4
Steering Wheel Power
Adjustment**.......................... 7
Sunroof*................................ 16
Tire Pressure Monitoring
System (TPMS) ..................... 17
Trip Computer....................... 17
Trunk Release ....................... 19
Windshield Wiper/Washer...... 9
Table of Contents
*if equipped **behind steering wheel ***inside glove box
Tire
Pressure
Monitoring
System
(TPMS)
Page 17
2HYUNDAI_GENESIS Quick Reference Guide 3

Remote Keyless Entry/Smart Key
Door Entry (with Smart Key)
Engine Start/Stop (with Smart Key)
With the ignition OFF push the Engine
Start/Stop:
nOnce for ACC (Accessory) mode.
nTwice for ON mode.
nThree times for OFF.
To start the engine in any mode
(including OFF), push the Engine Start/
Stop button while pressing the brake
pedal.
To shut the engine OFF, place
transmission in PARK and push the
Engine Start/Stop button again.
Front Seat Adjustment
Front Headrest Adjustment
To raise headrest height, pull up on
headrest.
To lower headrest, press lock knob
while pushing down on headrest.
To adjust headrest forward or
backward, slide headrest forward or
push back.
Driver Control Features
Removable Mechanical Key
PRESS TO UNLOCK
ONCE – Unlock driver door
TWICE – Unlock all doors
PRESS TO LOCK
ONCE – Lock all doors after
exiting vehicle Door Handle Button (Smart Key)
To set the parking brake, push the foot
pedal down.
To release the parking brake, push the
foot pedal down one click and then
slowly lift foot.
ELECTRONIC PARKING BRAKE
(if equipped)
nTo apply parking brake press A.
nTo release parking brake, turn ignition
ON and pull Awhile applying pressure
on the brake pedal.
nFor more information on Electronic
Parking Brake and Auto Hold, please
refer to your Owner’s Manual.
Parking Brake/Electronic Parking Brake (if equipped)
Slide to forward/backward
position, lift up/press down to
raise/lower seat.
Tilt to adjust seat back.
Press to adjust lumbar.
A
B
C
A
B
C
ENGINE
START
STOP
LOCK
Press
Once – Lock
Twice – Confirmation chirp
UNLOCK
Press
Once – Unlock driver door
Twice – Unlock all doors
TRUNK UNLOCK
Press and hold
PANIC
Press and hold .
Press any button to turn off panic.
PUSH
ON OFF
VOL
VOL
MODE
C
MUTE
SCAN
A
EMERGENCY SITUATIONS
Shut off engine while driving
nPress Engine Start/Stop button for
more than 3 seconds or 3 times
consecutively.
Restart engine while driving
nPress Engine Start/Stop button with
gear shift in N (Neutral).
4HYUNDAI_GENESIS Quick Reference Guide 5

Driver Control Features (continued)
Front Seat Shoulder Belt Adjustment
Press Ato adjust seat belt height.
NOTE: Moving height adjuster quickly
may cause seat belt retractor to
engage.
Basic Safety Precautions
Whenever operating the vehicle, make sure that you and your occupants are
properly wearing your seat belts. Small children should always ride in the rear seat
in the appropriate child restraint system (see the Owner’s Manual for child safety details).
Never place children under 13 years old in the front seats to avoid injury that may
result from air bag deployment.
Always refer to the Owner’s Manual for complete safety precaution information.
NOTE: If the driver’s seat belt is not fastened when the ignition key is turned to the
ON or START position, the seat belt reminder light will blink and the warning
chime will sound for approximately six seconds to remind the driver to
fasten the driver’s seat belt.
Outside Rearview Mirrors
Steering Wheel Power Adjustment (if equipped)
Toggle switch to adjust steering wheel.
NOTE: Do not adjust steering wheel
while driving.
Driver Position Memory System (if equipped)
Store and recall the driver’s seat, outside
rearview mirror and steering
wheel positions.
1. Place vehicle in Park with the
ignition ON.
2. Adjust the driver’s seat, outside
rearview mirror(s) and steering wheel
to a comfortable position.
3. Press SET button until a beep is
heard and then press button 1 or 2
within 5 seconds. The system will
beep twice when memory has been
successfully stored.
RECALLING SEAT POSITIONS
With vehicle in Park, press the desired
memory button (1 or 2).
Power Windows and Auto Up/Down Function
AUTO UP/DOWN
To fully open/close window(s)
automatically:
nPress fully down to open window(s).
nPull fully up to close window(s).
WINDOW LOCK OUT SWITCH
ADisables all passenger window
controls.
VOL
VOL
MODE
C
MUTE
SCAN
SET
1
2
A
VOL
MODE
MUTE
SCAN
A
MIRROR ADJUSTMENT
TO ADJUST LEFT OR RIGHT MIRROR
1. Move selector Aleft for driver’s side
or right for passenger’s side mirror.
2. Press perimeter switch Bto adjust
mirror angle .
3. Move selector Ato center to
deactivate the perimeter switch.
REVERSE PARKING
ASSIST FUNCTION (if equipped)
When selector Ais in LEFT or RIGHT
position, the outside rearview mirrors
will rotate down in Reverse gear.
A
B
6HYUNDAI_GENESIS Quick Reference Guide 7

MUTE
SCAN
Increase
INT speed
Headlights and Fog Lights
To operate headlights rotate switch A.
OFF – Headlights off
ON
OFF
– Parking lights
ON
OFF
– Headlights
AUTO – Auto lights
Ignition must be ON for headlights to
operate.
HIGH BEAM ACTIVATION
Push lever forward.
FLASH FEATURE
Pull lever back and release.
FOG LIGHT SWITCH
Rotate switch Bto operate fog lights.
Fog lights function on low beam only.
Refueling
Push button on driver’s side door to
open fuel door.
After adding fuel, always reinstall fuel
cap fully and turn it until it clicks. Failure
to do this may result in Check Engine
light illumination.
Windshield Wiper/Washer
Driver Control Features (continued)
ON
OFF
ON
OFF
Reinstall:
Click!
MIST – Single wipe
INTERMITTENT/AUTO
Switch Acontrols:
nAuto (if equipped)
Rain-sensing wiper sensitivity
nINT (if equipped)
Intermittent wipe frequency
LO – Low speed wipe
HI – High speed wipe
WIPE/WASH OPERATION
Pull lever toward you to activate wipe
and wash operation.
Decrease
INT speed
ADAPTIVE FRONT LIGHT SYSTEM
(AFLS) A(if equipped)
AFLS uses the steering angle and
vehicle speed to rotate the headlights
to enhance your field of vision while
driving.
To turn AFLS OFF, push the AFLS OFF
button. Indicator light in the instrument
cluster will illuminate.
INSTRUMENT PANEL
ILLUMINATION B
Rotate dial Bto adjust the instrument
panel illumination intensity.
A
B
AB
A
8HYUNDAI_GENESIS Quick Reference Guide 9

Audio System (varies by model)
Press POWER button Ato turn radio on.
TUNING/LISTENING TO CHANNELS
1. Press FM/AM Bor XM®C.
2. Rotate Audio Control knob Eto
desired channel.
NOTE: A clear view of the southern sky
is recommended to ensure XM®
radio reception.
SETTING PRESET MEMORY
BUTTONS (FM/AM OR XM®)
Press and hold preset button (1-6)
Duntil audible beep is heard to store
current channel.
ADJUSTING THE EQUALIZER
(SOUND QUALITY CONTROL)
1. Press TUNE knob Eto enter SETUP
menu. Rotate knob to highlight
option, then press to select.
nTone – Set sound quality
(Bass/Fade/Treble).
nPosition – Set sound position
(Front/Rear or Right/Left).
nEQ – Set prestored equalizer.
nSurround – On/Off (if equipped).
nXM® – Set XM® display info by CH
Number/Name or Artist/Song Title.
nExit.
2. Rotate TUNE knob Eto adjust
sound quality.
Please refer to your Owner’s Manual for more detailed information on how to use your
audio system.
Complimentary XM®Subscription is for 90 days following the vehicle date of sale. Please contact XM®Radio at
1-800-XM-RADIO (1-800-967-2346) to renew your XM®subscription.
AE
B
C
D
Audio System (continued)
Press POWER button Ato turn radio on.
TUNING/LISTENING TO CHANNELS:
1. Press FM/AM Bor XM®C.
2. Rotate Audio Control knob Dto
desired channel.
NOTE: A clear view of the southern sky
is recommended to ensure XM®
radio reception.
ADJUSTING THE EQUALIZER
(SOUND QUALITY CONTROL)
1. Press Sound Fto enter SETUP
menu. Rotate knob Dto highlight
option, then press to select.
nTone – Set sound quality
(Bass/Fade/Treble).
nPosition – Set sound position
(Front/Rear or Right/Left).
SETTING PRESET MEMORY
BUTTONS (FM/AM OR XM®)
Press and hold preset button (1-6)
until audible beep is heard to store
current channel.
Touch Screen Audio (if equipped)
Standard Audio System (if equipped)
1 2 3 4 5 6
A
B
C
D
F
Please refer to your Touch Screen Audio User’s Manual for more detailed information on
how to use your Touch Screen Audio system.
10 HYUNDAI_GENESIS Quick Reference Guide 11

Audio System (continued) Audio System (continued)
TUNING/LISTENING
TO CHANNELS
1. Press FM/AM A or XM®B.
2. Select Cto set desired
channel.
NOTE: A clear view of the
southern sky is
recommended to ensure
XM®radio reception.
SETTING PRESET MEMORY
BUTTONS (FM/AM OR XM®)
1. Select preset Dand toggle
the DIS control knob Fto
the right to select
station E.
2. Press down DIS control
knob Fto store station.
ADJUSTING THE EQUALIZER
(SOUND QUALITY CONTROL)
Select Settings Gand press
DIS control knob Fto select
the following:
nTone – Set sound quality
(Bass/Fade/Treble).
nPosition – Set sound position
(Front/Rear or Right/Left).
nEQ – Set prestored equalizer.
nSurround – On/Off
(if equipped).
6-Disc CD Changer (if equipped)
Push LOAD button to load CDs to available 6-Disc deck (from 1-6). Place CD
printed side up and push in. After the first CD is loaded, press the LOAD button
again to insert the next CD.
iPod®Use
An auxiliary and USB jack is located in
the center console compartment. Use
the jack to connect an external audio
device and listen to it through the audio
system in your vehicle.
NOTE: To operate your iPod®through
the vehicle’s audio system,
a Hyundai adapter cable is
required. This cable can only
be purchased at your local
Hyundai dealer.
MENU
Hyundai
adapter cable
Driver Information System (DIS) – Audio (if equipped)
A
B F
G
D
C E
Please refer to your Driver Information System User’s Manual for more detailed
information on how to use your Driver Information System.
12 HYUNDAI_GENESIS Quick Reference Guide 13

Climate Control Additional Features
AAUTO TEMPERATURE – To activate
automatic heating and cooling.
BTEMPERATURE CONTROL – To
increase/decrease in-cabin
temperature.
CFAN SPEED CONTROL – To increase/
decrease blower fan speed.
DMODE – To control the directional
flow of air.
E
DUAL – To operate driver and
passenger side temperatures
individually.
FAIR QUALITY CONTROL SYSTEM
(AQS) –To activate the air quality
control system. AQS automatically
senses outdoor air pollutants and
minimizes them from entering
the vehicle.
NOTE: While using AQS, unpleasant or
foul odors may still be noticeable
within the vehicle.
HFRONT DEFROST/DEFOG –
1. Set temperature control Bto warmest
setting.
2. Set fan speed Cto highest setting.
3. Press front windshield defrost control H.
4. Adjust temperature for comfort after
window has defogged.
IREAR WINDOW/SIDE MIRROR
DEFROST – To activate/deactivate.
JAIR CONDITIONING – To activate/
deactivate air conditioning.
KRECIRCULATION – To activate/
deactivate. In this mode, air is
drawn from within the passenger cabin.
LOFF – To turn Climate Control
System off.
G A H
B E
C D
I J L K F E
Occupant Classification System
PASSENGER AIR BAG OFF INDICATOR G
The indicator will illuminate when you turn the ignition ON. The light will
not illuminate when the front passenger’s air bag is enabled. The occupant
classification system will disable the right front passenger’s air bag under certain
conditions (light on). Refer to your Owner’s Manual for a complete description of
this system.
NOTE: Driver’s air bag and side impact air bag are not part of the occupant
classification system. Never place children under 13 years old in front seats
to avoid injury that may result from air bag deployment. Always refer to the
Owner’s Manual for complete safety precaution information.
Hours Minutes Reset
Clock
Push and hold Reset to toggle
between 12 or 24 hours.
STANDARD AUDIO SYSTEM
1. Press TUNE Ebutton.
2. Turn TUNE knob Eto Bluetooth. Press knob to select.
3. Turn TUNE knob Eto Pair. Press knob to select.
4. Follow voice command instructions to complete pairing the phone.
5. When prompted, enter the Passkey (Default Passkey 0000).
DRIVER INFORMATION SYSTEM (DIS)
1. Press INFO/PHONE button H.
2. Select Connect Phone by turning knob F.
3. Select your phone under Pair Phone by
turning knob F.
4. In your mobile phone Bluetooth setup
menu, select Add New Device.
The default name of the Bluetooth
Device is GENESIS.
5. When prompted, enter the Passkey
(Default Passkey 1234).
6. The name of the connected device will
be displayed on the phone.
TOUCH SCREEN SYSTEM
1. Press PHONE button
2. Press the SETTINGS button on phone screen
3. Press the PAIRINGS button
4. Press the ADD TO button
5. In your mobile phone Bluetooth
setup menu, select Add New
Device. The default name of the
Bluetooth Device is GENESIS.
6. When prompted, enter the Passkey (Default Passkey 1234).
7. The name of the connected device will be displayed on the phone.
Bluetooth Connectivity
E
F
H
14 HYUNDAI_GENESIS Quick Reference Guide 15

Additional Features (continued)
Overhead Console
TO SET A CRUISING SPEED – STANDARD
1. Press Aand the CRUISE indicator will
illuminate in the instrument cluster.
Accelerate to desired cruising speed
(above 25 mph).
2. Press Band remove your foot from
the accelerator pedal.
TO ACCELERATE OR DECELERATE
Press Cto increase set cruising speed.
Press Bto decrease set cruising speed.
TO CANCEL CRUISING SPEED
Press CANCEL D, or press brake pedal,
or press ON/OFF A.
SMART CRUISE CONTROL
(if equipped)
1. Turn Smart Cruise Control Eon.
2. Press Bto set speed.
TO SET VEHICLE TO VEHICLE
DISTANCE
3. Press E. Three distances are available:
nDistance 3– 180 feet
nDistance 2– 130 feet
nDistance 1– 85 feet
Distances are approximate.
WHEN THERE IS A VEHICLE AHEAD
IN THE LANE
4. The vehicle will accelerate or
decelerate to maintain the selected
distance.
Please refer to your Owner’s Manual for
additional operational instructions and
other cautionary advisories on Smart
Cruise Control.
Sunroof (if equipped)
Cruise Control/Smart Cruise Control
WITH IGNITION SWITCH ON
TO OPEN – Press switch rearward. Press
switch rearward past the detent to open
completely.
TO CLOSE – Press switch forward. Press
switch forward past the detent to close
completely.
TO TILT – Push or pull switch up or down.
F
C
F
C
INFLATE TIRE(S)
LOW TIRE PRESSURE
LOCATION
SYSTEM MALFUNCTION
SEE DEALER
LOW TIRE PRESSURE INDICATOR
Inflate tire(s) to proper pressure.
NOTE: Tire pressure may vary in
colder temperatures causing
the low tire pressure light
to illuminate.
LOW TIRE PRESSURE LOCATION
TPMS SYSTEM MALFUNCTION
See authorized Hyundai dealer.
NOTE: The TPMS is not a substitute
for proper tire maintenance.
Refer to your Owner’s Manual
for further information.
Trip Computer – without Smart Cruise Control
To change Trip information, press
TRIP button.
ODO

TRIP A

TRIP B
To reset Trip A/B display, press and hold
TRIP button.
To change display information, on
vehicles equipped with Smart Cruise
Control, press the DISP button.
Distance to Empty

Average Speed

Elapsed Time

Average Fuel Consumption

Instant Fuel Consumption
To reset display, press and hold
DISP button.
Tire Pressure Monitoring System (TPMS)
F
C
A
B
C
D
F
C
TRIP
E
Instrument panel indicators
vehicle to vehicle distance
3 2 1
16 HYUNDAI_GENESIS Quick Reference Guide 17

VOL
VOL
MODE
C
MUTE
SCAN
Additional Features (continued)
Rear Sunshade (if equipped)
To raise or lower the rear sunshade
press the button.
NOTE: The rear sunshade will
automatically lower when the
vehicle is shifted into reverse. The
sunshade raises automatically
when the vehicle is shifted back
into Drive and the vehicle speed
is more than 12 mph.
Parking Assistance System (if equipped)
The Parking Assistance System chimes
if any object is sensed within the distance
of approximately 39 inches in front and
behind the vehicle.
To turn ON/OFF, push the park assist
button.
NOTE: The Parking Assistance System is
supplemental and is not intended
to nor does it replace the need
for extreme care and attention of
the driver. Refer to your Owner’s
Manual for further information.
Trunk Release
INTERIOR TRUNK RELEASE
Pull trunk lid release to open trunk from inside
of vehicle.
VOL
MODE
MUTE
SCAN
EXTERIOR TRUNK RELEASE
WITH REAR VIEW CAMERA
Push trunk lid release to open trunk.
WITHOUT REAR VIEW CAMERA
Push trunk lid release to open trunk.
TRUNK LOCK BUTTON
The trunk lock button is used to prevent
unauthorized access to the trunk.
LOCK
To activate the trunk lock system:
1. Open the glove box.
2. Press trunk lock button OFF. In the OFF
position, the trunk can only be opened with
the mechanical key.
3. Remove mechanical key from the Smart Key.
4. Close and lock the glove box with the
mechanical key.
NOTE: Without the mechanical key, the Smart
Key can only start the engine and operate
door locks.
TO UNLOCK AND OPEN THE TRUNK
WITH THE KEY
Insert the mechanical key into the key slot
located as shown on the trunk lid and turn
clockwise.
Homelink®Wireless Control System
The HomeLink®Wireless Control System
can conveniently replace up to three
hand-held radio-frequency transmitters,
such as garage doors, estate gates and
home lighting. Controls for HomeLink®are
located in the lower portion of the inside
rearview mirror.
Refer to your Owner’s Manual for
detailed instructions. Additional
HomeLink®information can be found at:
www.homelink.com or by calling
1-800-355-3515.
18 HYUNDAI_GENESIS Quick Reference Guide 19

Audio System Basics Bluetooth Connectivity
Press POWER button Ato turn radio on.
TUNING/LISTENING TO CHANNELS
1. Press FM/AM Bor XM®C.
2. Rotate Audio Control knob Eto
desired channel.
Press POWER button Fto turn
radio on.
TUNING/LISTENING TO
CHANNELS
1. Press FM/AM Aor XM®B.
2. Select Cto set desired
channel
NOTE: A clear view of the
southern sky is
recommended to ensure
XM®radio reception.
SETTING PRESET MEMORY
BUTTONS (FM/AM OR XM®)
1. Select preset Dand toggle
the DIS control knob Eto
the right to select store
channels.
2. Press down DIS control
knob Eto store channels.
Driver Information System (DIS) – Audio (if equipped)
Standard Audio System (if equipped)
E
C
D
Press POWER button Ato turn radio on.
TUNING/LISTENING TO CHANNELS
1. Press FM/AM Bor XM®C.
2. Rotate Audio Control knob Dto
desired channel.
NOTE: A clear view of the southern sky
is recommended to ensure
XM®radio reception.
Touch-Screen Audio System (if equipped)
AD
B
C
A
D
B
C
ESETTING PRESET MEMORY
BUTTONS (FM/AM OR XM®)
Press and hold preset button (1-6) D
until audible beep is heard to store
current channel.
A
BE
NOTE: A clear view of the southern sky
is recommended to ensure
XM®radio reception.
F
STANDARD AUDIO SYSTEM
1. Press TUNE Ebutton.
2. Turn TUNE knob Eto Bluetooth. Press knob to select.
3. Turn TUNE knob Eto Pair. Press knob to select.
4. Follow voice command instructions to complete pairing the phone.
5. When prompted, enter the Passkey (Default Passkey 0000).
DRIVER INFORMATION SYSTEM (DIS)
1. Press INFO/PHONE button H.
2. Select Connect Phone by turning knob F.
3. Select your phone under Pair Phone by
turning knob F.
4. In your mobile phone Bluetooth setup
menu, select Add New Device.
The default name of the Bluetooth
Device is GENESIS.
5. When prompted, enter the Passkey
(Default Passkey 1234).
6. The name of the connected device will
be displayed on the phone.
E
TOUCH SCREEN SYSTEM
1. Press PHONE button
2. Press the SETTINGS button on phone screen
3. Press the PAIRINGS button
4. Press the ADD TO button
5. In your mobile phone Bluetooth
setup menu, select Add New
Device. The default name of the
Bluetooth Device is GENESIS.
6. When prompted, enter the
Passkey (Default Passkey 1234).
7. The name of the connected
device will be displayed on the
phone.
F
H

Sales Consultant Date Sales Manager Date
Customer Date
INFLATE TIRE(S) LOW TIRE PRESSURE
LOCATION
Genesis Customer Delivery Checklist (continued)
During Delivery
 TIRE PRESSURE MONITORING SYSTEM (TPMS) – PAGE 17
NOTE: Tire pressure may vary in colder temperatures causing the low tire pressure
indicator to illuminate. Inflate tires according to the Tire Pressure Label
located on the driver’s side door pillar.
 HELP CUSTOMER PAIR PHONE WITH BLUETOOTH (IF APPLICABLE)
 DEMONSTRATE AUDIO SYSTEM OPERATION INCLUDING PRESETS
(OPTIONAL – iPOD®CABLE AVAILABLE)
 CONSIDER OWNER’S PREVIOUS VEHICLE TO EXPLAIN WIPER/
HEADLIGHT FUNCTIONS
 DEMONSTRATE HOW TO SET CLOCK
 EXPLAIN AND REVIEW FIRST SERVICE PROCEDURE AND
AMERICA’S BEST WARRANTY – PROVIDE SERVICE
REPRESENTATIVE BUSINESS CARD
 ASK IF CUSTOMER HAS ANY QUESTIONS
nMove the switch up or down to one of the five
positions.
nWIPE / WASH To use the washer, pull the lever
toward you.
nINTERMITTENT/AUTO
Switch Acontrols:
n
Auto (if equipped) Rain-sensing wiper
sensitivity
n
INT (if equipped) Intermittent wipe frequency
A

WINDSHIELD WIPER/WASHER – PAGE 9
Genesis Customer Delivery Checklist
Hyundai Owner Dealership Name
Sales Consultant Date
VIN Previous Vehicle
Before Delivery
Walk the customer through each of the following
key delivery features
 CLIMATE CONTROL – PAGE 14
nTo speed up front windshield defogging, increase temperature and fan speed,
then select defrost button.
 SMART KEY – PAGES 4 & 5
1. Once vehicle is started, vehicle will continue
to run even if key is removed from vehicle.
2. Once ignition is turned off, vehicle will not
restart until smart key is in proximity to
Engine Start/Stop button.
3. Place vehicle in PARK before shutting
off ignition.
4. Push Smart Key in and pull out to
release from Smart Key holder.
ENGINE
START
STOP

CONFIRM “GOOD BATTERY” AND STAPLE TEST TICKET HERE
nMIDTRONICS TEST CCA 780A (V8) OR 740A (V6) AT BATTERY IN
TRUNK (NOT UNDER THE HOOD)

VERIFY ALL TIRE PRESSURES ARE 33 PSI

VERIFY ALL REMOTE FUNCTIONS:
LOCK/UNLOCK/TRUNK RELEASE (IF APPLICABLE)

VERIFY VEHICLE IS CLEAN, IN GOOD CONDITION, FREE OF CHIPS
AND SCRATCHES

ENSURE FLOORMATS ARE SNAPPED INTO PLACE (IF APPLICABLE)
LF LR RF RR
SYSTEM MALFUNCTION
SEE DEALER
