Hyundai R160LC-9 User manual

OPERATION MANUAL
HYUNDAI
Excavator
R160LC-9

http://marengine.com/r160lc-9-excavator

CONTENTS
CONTENTS
Foreword ----------------------------------------------------------- 0-1
Before servicing this machine --------------------------- 0-2
EC regulation approved ------------------------------------ 0-3
Table to enter S/No and distribution --------------------- 0-4
Safety labels ------------------------------------------------------ 0-5
Machine data plate -------------------------------------------- 0-17
Guide (direction, S/No, symbol) ------------------------ 0-18
SAFETY HINTS
SAFETY HINTS
1. Before operating the machine -------------------- 1-1
2. During operating the machine
-------------------- 1-6
3. During maintenance
----------------------------------- 1-13
4. Parking
-------------------------------------------------------- 1-16
SPECIFICATIONS
SPECIFICATIONS
1. Major components ------------------------------------- 2-1
2. Specifications
-------------------------------------------- 2-2
3. Working range
------------------------------------------- 2-5
4. Weight
------------------------------------------------------- 2-7
5. Lifting capacities
---------------------------------------- 2-8
6. Bucket selection guide
------------------------------- 2-12
7. Undercarriage
------------------------------------------- 2-13
8. Specification for major components
----------- 2-15
9. Recommended oils
------------------------------------ 2-18
CONTROL DEVICES
CONTROL DEVICES
1. Cab devices ----------------------------------------------- 3-1
2. Cluster
------------------------------------------------------- 3-2
3. Switches
---------------------------------------------------- 3-23
4. Levers and pedals
------------------------------------- 3-27
5. Air conditioner and heater
------------------------- 3-30
6. Others
-------------------------------------------------------- 3-37
OPERATION
OPERATION
1. Suggestion for new machine ---------------------- 4-1
2. Check before starting the engine
--------------- 4-2
3. Starting and stop the engine
---------------------- 4-3
4. Mode selection system
------------------------------ 4-6
5. Operation of the working device
----------------- 4-11
6. Traveling of the machine ---------------------------- 4-12
7. Efficient working method
--------------------------- 4-15
8. Operation in the special work sites
------------- 4-19
9. Normal operation of excavator
------------------- 4-21
10. Attachment lowering
---------------------------------- 4-22
11. Storage
----------------------------------------------------- 4-23
12. RCV lever operating pattern
----------------------- 4-25
13. Switching hydraulic attachment circuit
-------- 4-27
TRANSPORTATION
TRANSPORTATION
1. Preparation for transportation -------------------- 5-1
2. Dimension and weight
------------------------------- 5-2
3. Loading the machine
--------------------------------- 5-5
4. Fixing the machine
------------------------------------ 5-7
5. Loading and unloading by crane
---------------- 5-8
MAINTENANCE
MAINTENANCE
1. Instruction ------------------------------------------------- 6-1
2. Tightening torque
--------------------------------------- 6-6
3. Fuel, coolant and lubricants
----------------------- 6-9
4. Maintenance check list
------------------------------ 6-11
5. Maintenance chart
------------------------------------ 6-16
6. Service instruction
------------------------------------- 6-18
7. Electrical system
--------------------------------------- 6-39
8. Air conditioner and heater
-------------------------- 6-42
TROUBLESHOOTING GUIDE
TROUBLESHOOTING GUIDE
1. Engine ------------------------------------------------------ 7-1
2. Electrical system
--------------------------------------- 7-2
3. Others
------------------------------------------------------- 7-3
HYDRAULIC BREAKER AND QUICK CLAMP
HYDRAULIC BREAKER AND QUICK CLAMP
1. Selecting hydraulic breaker ------------------------ 8-1
2. Circuit configuration
----------------------------------- 8-2
3. Maintenance
--------------------------------------------- 8-3
4. Precaution while operating the breaker
------ 8-4
5. Quick clamp
---------------------------------------------- 8-6
INDEX
INDEX ------------------------------------------------------------ 9-1

0-1
This manual contains a number of instructions and safety recommendations regarding driving, han-
dling, lubrication, maintenance, inspection and adjustment of the excavator.
The manual is to promote safety maintenance and enhance machine performance.
Keep this manual handy and have all personnel read it periodically.
If you sell the machine, be sure to give this manual to the new owners.
This machine complies with EC directive "2006/42/EC".
1.
Read
Read and
understand
understand this manual before operating the machine.
This operator's manual may contain attachments and optional equipment that are not available in
your area. Please consult your local Hyundai distributor for those items you require.
Improper operation and maintenance of this machine can be hazardous and could result in serious
injury or death.
Some actions involved in operation and maintenance of the machine can cause a serious accident,
if they are not done in a manner described in this manual.
The procedures and precautions given in this manual apply only to intended uses of the machine.
If you use your machine for any unintended uses that are not specifically prohibited, you must be
sure that it is safe for you and others. In no event should you or others engage in prohibited uses
of actions as described in this manual.
2.
Inspect
Inspect the jobsite and
follow
follow the safety recommendations in the
safety hints
safety hints section before oper-
ating the machine.
3. Use
genuine Hyundai spare parts
genuine Hyundai spare parts for the replacement of parts.
We expressly point out that Hyundai will not accept any responsibility for defects resulting from non-
genuine parts or non workmanlike repair.
In such cases Hyundai cannot assume liability for any damage.
Continuing improvements in the design of this machine can lead to changes in detail which may not
be reflected in this manual. Consult Hyundai or your Hyundai distributor for the latest available infor-
mation for your machine or for questions regarding information in this manual.
FOREWORD
FOREWORD

0-2
It is the responsibility of the owner and all service and maintenance personnel to avoid accidents and
serious injury by keeping this machine properly maintained.
It also is the responsibility of the owner and all service and maintenance personnel to avoid accidents
and serious injury while servicing the machine.
No one should service or attempt to repair this machine without proper training and supervision.
All service and maintenance personnel should be thoroughly familiar with the procedures and precau-
tions contained in this manual.
All personnel also must be aware of any federal, state, provincial or local laws or regulations covering
the use and service of construction equipment.
The procedures in this manual do not supersede any requirements imposed by federal, state, provin-
cial or local laws.
Hyundai can not anticipate every possible circumstance or environment in which this machine may be
used and serviced.
All personnel must remain alert to potential hazards.
Work within your level of training and skill.
Ask your supervisor if you are uncertain about a particular task. Do not try to do too much too fast.
Use your common sense.
BEFORE SERVICING THIS MACHINE
BEFORE SERVICING THIS MACHINE

0-3
· Noise level (EN474-1 : 2006 and 2000/14/EC) are as followings.
LWA : 100
dB (EU only)
LPA : 71
dB
· The value of vibrations transmitted by the operator's seat are lower than standard value of (EN474-1
: 2006 and 2002/44/EC)
EC REGULATION APPROVED
EC REGULATION APPROVED

0-4
TABLE TO ENTER SERIAL NO. AND DISTRIBUTOR
TABLE TO ENTER SERIAL NO. AND DISTRIBUTOR
Machine Serial No.
Engine Serial No.
Manufacturing year
Manufacturer
Address
Distributor for U.S.A
Address
Distributor for Europe
Address
Dealer
Address
Hyundai Heavy Industries co., Ltd.
1, Jeonha-Dong, Dong-Ku,
Ulsan 682-792, Korea
Hyundai Heavy Industries U.S.A, Inc
955 Estes Avenue EIK Grove village
IL, 60001
U.S.A
Hyundai Heavy Industries Europe N.V.
Vossendal 11
2240 Geel
Belgium

0-5
SAFETY LABELS
SAFETY LABELS
Bucket
1
2
3
4
7
6
PUMP SCREEN
LH CONSOLE BOX BATTERY COVER
CAB INSIDE-RH CAB INSIDE-LH
26
22
20
41
34
24
21
22
538
35
SCREEN PLATE
19 45
46
8
9
10
10
11 33
1212
13
14
15
16
17
48
1828
32
23
29
37
27
43
39
16
30
42 42
39 316
36
40
47
1. LOCATION
1. LOCATION
Always keep these labels clean. If they are lost or damage, attach them again or replace them with
a new label.
16090SL01
1 Air cleaner filter
2 Turbocharger cover
3 Radiator cap
4 Fueling
5 Battery accident
6 High pressure hose
7 Hydraulic oil level
8 Hydraulic oil lub
9 Keep clear-rear
10 Lifting eye
11 Name plate
12 Slinging ideogram
13 Keep clear-side
14 Stay fix
15 Shearing-engine hood
16
No step-engine hood and CWT
17 Transporting
18 Low emission engine
19 Control ideogram
20
Ref operator manual-cab RH pillar
21 Hammer
22 Safety front window
23 Alternate exit
24 Air conditioner filter
26 Safety lever
27 Model name
28 Logo (ROBEX)
29 Trade mark (boom)
30 Trade mark (CWT)
31 Reduction gear grease
32 Clamp-locking
33 Noise level (LWA)
34 Service instruction
35 Lifting chart
36 Tie
37 Keep clear-Boom/arm
38 ECM connector
39 Falling
40 FOPS FOG plate
41 Turbocharger
42 Reflecting
43 Accumulator
44 Machine control pattern
45 Control ideogram-dozer
46 RCV lever pattern
47 Swing bearing
48 Battery position

0-6
2. DESCRIPTION
2. DESCRIPTION
AIR CLEANER FILTER
AIR CLEANER FILTER (item 1)
This warning label is positioned on the air
cleaner cover.
Periodic and proper inspection, cleaning
Periodic and proper inspection, cleaning
and change of elements prolong engine
and change of elements prolong engine
life time and maintain the good perfor-
life time and maintain the good perfor-
mance of engine.
mance of engine.
There are several specific warning labels on this machine please become familiarized with all warn-
ing labels.
Replace any safety label that is damaged, or missing.
1)
1)
ö
21070FW01
TURBOCHARGER COVER
TURBOCHARGER COVER (item 2)
This warning label is positioned on the tur-
bocharger cover.
Do not touch turbocharger or it may
Do not touch turbocharger or it may
cause severe burn.
cause severe burn.
2)
2)
21070FW02
14070FW03
21070FW04
RADIATOR CAP
RADIATOR CAP (item 3)
This warning label is positioned on the radi-
ator.
Never open the filler cap while engine
Never open the filler cap while engine
running or at high coolant temperature.
running or at high coolant temperature.
3)
3)
FUELING
FUELING (item 4)
This warning label is positioned on the fuel
filler neck.
Stop the engine when refueling. All
Stop the engine when refueling. All
lights or flames shall be kept at a safe
lights or flames shall be kept at a safe
distance while refueling.
distance while refueling.
4)
4)

0-7
BATTERY ACCIDENT
BATTERY ACCIDENT (item 5)
This warning label is positioned on the bat-
tery cover.
Electrolyte containing sulfuric acid cause
Electrolyte containing sulfuric acid cause
severe burns. Avoid being in contact with
severe burns. Avoid being in contact with
skin, eyes or clothes. In the event of
skin, eyes or clothes. In the event of
accident flush with sufficient water, call a
accident flush with sufficient water, call a
physician immediately.
physician immediately.
Maintain the electrolyte at the recom-
Maintain the electrolyte at the recom-
mended level.
mended level.
With electrolyte at proper level, less
With electrolyte at proper level, less
space may cause the gases to be accu-
space may cause the gases to be accu-
mulated in the battery.
mulated in the battery.
Extinguish all smoking materials and
Extinguish all smoking materials and
open flames before checking the battery.
open flames before checking the battery.
Do not use matches, lighters or torches
Do not use matches, lighters or torches
as a light source near the battery for the
as a light source near the battery for the
probable presence of explosive gas.
probable presence of explosive gas.
Do not allow unauthorized personnel to
Do not allow unauthorized personnel to
change the battery or to use booster
change the battery or to use booster
cables.
cables.
For safety from electric shock, do not bat-
For safety from electric shock, do not bat-
tery terminal with a wet hand.
tery terminal with a wet hand.
5)
5)
ö
36070FW05
14070FW29
HIGH PRESSURE HOSE
HIGH PRESSURE HOSE (item 6)
These warning labels are positioned in the
front of upper frame and on the screen
plate.
Escaping fluid under pressure can pene-
Escaping fluid under pressure can pene-
trate the skin causing serious injury.
trate the skin causing serious injury.
Study the service manual before service
Study the service manual before service
job.
job.
6)
6)
ö

0-8
LIFTING EYE
LIFTING EYE (item 10)
This warning label is positioned on the
counterweight.
Do not lift the machine by using lifting
Do not lift the machine by using lifting
eyes on the counterweight or the lifting
eyes on the counterweight or the lifting
eyes may be subject to overload causing
eyes may be subject to overload causing
its breaking and possible personal injury.
its breaking and possible personal injury.
See page 5-8 for proper lifting method of
See page 5-8 for proper lifting method of
the machine.
the machine.
10)
10)
ö
21070FW10
14070FW08
HYDRAULIC OIL LUBRICATION
HYDRAULIC OIL LUBRICATION (item 8)
This warning label is positioned on the top
of the hydraulic tank.
Do not mix with different brand oils.
Do not mix with different brand oils.
Never open the filler cap while high tem-
Never open the filler cap while high tem-
perature.
perature.
Loosen the cap slowly and release inter-
Loosen the cap slowly and release inter-
nal pressure completely.
nal pressure completely.
8)
8)
ö
REAR KEEP CLEAR
REAR KEEP CLEAR (item 9)
This warning label is positioned on the rear
of counterweight.
To prevent serious personal injury or
To prevent serious personal injury or
death keep clear or machine swing radi-
death keep clear or machine swing radi-
us.
us.
Do not deface of remove this label from
Do not deface of remove this label from
the machine.
the machine.
9)
9)
21090FW09
21070FW07
HYDRAULIC OIL LEVEL
HYDRAULIC OIL LEVEL (item 7)
This warning label is positioned on the
screen plate.
Place the bucket on the ground whenever
Place the bucket on the ground whenever
servicing the hydraulic system.
servicing the hydraulic system.
Check oil level on the level gauge.
Check oil level on the level gauge.
Refill the recommended hydraulic oil up
Refill the recommended hydraulic oil up
to specified level if necessary.
to specified level if necessary.
7)
7)
ö
ö

0-9
SHEARING-ENGINE HOOD
SHEARING-ENGINE HOOD (item 15)
This warning label is positioned on the
engine hood.
Don't open the engine hood during the
Don't open the engine hood during the
engine's running.
engine's running.
Don't touch exhaust pipe or it may cause
Don't touch exhaust pipe or it may cause
severe burn.
severe burn.
21070FW15
21070FW13
SIDE KEEP CLEAR
SIDE KEEP CLEAR (item 13)
This warning label is positioned on the LH
side cover.
To prevent serious personal injury or
To prevent serious personal injury or
death keep clear of machine swing radi-
death keep clear of machine swing radi-
us.
us.
Do not deface or remove this label from
Do not deface or remove this label from
the machine.
the machine.
STAY FIX
STAY FIX (item 14)
This warning label is positioned on the both
side cover.
Be sure to support the stay when the
Be sure to support the stay when the
door needs to be opened.
door needs to be opened.
Be careful that the opened door may be
Be careful that the opened door may be
closed by the external or natural force
closed by the external or natural force
like strong wind.
like strong wind.
13)
13)
11)
11)
12)
12)
21070FW14

0-10
REF OPERATOR MANUAL
REF OPERATOR MANUAL (item 20)
This warning label is positioned on the right
side window of the cab.
Study the operator's manual before start-
Study the operator's manual before start-
ing and operating machine.
ing and operating machine.
21070FW22
TRANSPORTING
TRANSPORTING (item 17)
This warning label is positioned right side
of upper frame.
Study the operator's manual before
Study the operator's manual before
transporting the machine, if provided and
transporting the machine, if provided and
tie down arm and track to the carrier with
tie down arm and track to the carrier with
lashing wire.
lashing wire.
See page 5-7 for details.
See page 5-7 for details.
14070FW17
CONTROL IDEOGRAM
CONTROL IDEOGRAM (item 19)
This warning label is positioned in right
window of the cab.
Check the machine control pattern for
Check the machine control pattern for
conformance to pattern on this label. If
conformance to pattern on this label. If
not, change label to match pattern
not, change label to match pattern
before operating machine.
before operating machine.
Failure to do so could result in injury or
Failure to do so could result in injury or
death.
death.
See page 4-11 for details.
See page 4-11 for details.
36070FW19
NO STEP-ENGINE HOOD/CWT
NO STEP-ENGINE HOOD/CWT (item 16)
These warning labels are positioned on the
engine hood and counterweight.
Don't step on the engine hood and coun-
Don't step on the engine hood and coun-
terweight.
terweight.
21070FW16
17)
17)
14)
14)
15)
15)
16)
16)

0-11
MAX HEIGHT
MAX HEIGHT (item 20)
This warning label is positioned on the right
side window of the cab.
Serious injury or death can result from
Serious injury or death can result from
contact with electric lines.
contact with electric lines.
An electric shock being received by
An electric shock being received by
merely coming into the vicinity of an
merely coming into the vicinity of an
electric lines, the minimum distance
electric lines, the minimum distance
should be kept considering the supply
should be kept considering the supply
voltage as page 1-7.
voltage as page 1-7.
21070FW23
INTERFERENCE
INTERFERENCE (item 20)
This warning label is positioned on the
right side window of the cab.
Be careful to operate machine equipped
Be careful to operate machine equipped
with quick clamp or extensions.
with quick clamp or extensions.
Bucket may hit cab or boom, boom cylin-
Bucket may hit cab or boom, boom cylin-
ders when it reached vicinity of them.
ders when it reached vicinity of them.
18)
18)
19)
19)
21090FW62
ALTERNATE EXIT
ALTERNATE EXIT (item 23)
This warning label is positioned on the
inside of rear window.
The rear window serves us an alternate
The rear window serves us an alternate
exit.
exit.
To remove rear window, pull the ring and
To remove rear window, pull the ring and
push out the glass.
push out the glass.
21070FW25
SAFETY FRONT WINDOW
SAFETY FRONT WINDOW (item 22)
This warning label is positioned on the both
side window of the cab.
Be careful that the front window may be
Be careful that the front window may be
promptly closed.
promptly closed.
21
21)
ö
ö
20)
20)
21070FW24

0-12
AIR CONDITIONER FILTER
AIR CONDITIONER FILTER (item 24)
This warning label is positioned on the air
conditioner cover.
Periodic and proper inspection, cleaning
Periodic and proper inspection, cleaning
and change of filter prolong air condition-
and change of filter prolong air condition-
er life time and maintain good perfor-
er life time and maintain good perfor-
mance.
mance.
21070FW26
SAFETY LEVER
SAFETY LEVER (item 26)
This warning label is positioned on the
cover of the safety lever.
Before you get off the machine be sure
Before you get off the machine be sure
to place the safety lever LOCKED posi-
to place the safety lever LOCKED posi-
tion.
tion.
30007A1FW07A
22)
22)
ö
23)
23)
REDUCTION GEAR GREASE
REDUCTION GEAR GREASE (item 31)
This warning label is positioned in the front
of upper frame.
Grease is under high pressure.
Grease is under high pressure.
Grease coming out of the grease plug
Grease coming out of the grease plug
under pressure can penetrate the body
under pressure can penetrate the body
causing injury or death.
causing injury or death.
21070FW35
CLAMP-LOCKING
CLAMP-LOCKING (item 32)
This warning label is positioned on the right
side window of cab.
Serious injury or death can result from
Serious injury or death can result from
dropping bucket.
dropping bucket.
Operating the machine with quick clamp
Operating the machine with quick clamp
switch unlocked or without safety pin of
switch unlocked or without safety pin of
moving hook can cause the bucket to
moving hook can cause the bucket to
drop off.
drop off.
14070FW60
24)
24)
25)
25)

0-13
TIE
TIE (item 36)
This warning label is positioned on the
lower frame.
Make sure no personal are standing
Make sure no personal are standing
close to the tow rope.
close to the tow rope.
See page 4-14 for detail.
See page 4-14 for detail.
4507A0FW02
KEEP CLEAR-BOOM/ARM
KEEP CLEAR-BOOM/ARM (item 37)
This warning label is positioned on both
side of the arm.
Serious injury or death can result from
Serious injury or death can result from
falling of the attachment.
falling of the attachment.
To prevent serious injury or death, keep
To prevent serious injury or death, keep
clear the underneath of attachment.
clear the underneath of attachment.
26)
26)
27)
27)
14070FW31
ECM CONNECTOR
ECM CONNECTOR (item 38)
This warning label is positioned on the bat-
tery cover.
Before carrying out any electric welding
Before carrying out any electric welding
on this machine, follow the below proce-
on this machine, follow the below proce-
dure.
dure.
Pull the connector out of all electric con-
trol units.
Connector the ground lead of the weld-
ing equipment as close to the welding
point as possible.
See page 6-41 for detail.
See page 6-41 for detail.
7807AFW20
ÂBefore carrying out any electric welding on this
machine
- Pull the connectors out of all electronic control
units.
- Connect the ground lead of the welding equipment
as close to the welding point as possible.
ÂRead the instructions in operator's manual for
details.
W A R N I N G
28)
28)
-
-
ö

0-14
TURBOCHARGER
TURBOCHARGER (item 41)
This warning label is positioned on the right
window of the cab.
In order to prevent turbocharger failure,
In order to prevent turbocharger failure,
please allow more than 5 minutes' cool
please allow more than 5 minutes' cool
down period (no load low idle operation)
down period (no load low idle operation)
before shutting the engine off.
before shutting the engine off.
7807AFW20
C A U T I O N
In order to prevent turbocharger failure,
please allow more than 5 minutes' cool
down period(no load low idle operation)
before shutting the engine off.
REFLECTING
REFLECTING (item 42)
This warning label is positioned on the rear
of counterweight.
To prevent serious personal injury or
To prevent serious personal injury or
death keep clear of machine swing radi-
death keep clear of machine swing radi-
us.
us.
Do not deface or remove this label from
Do not deface or remove this label from
the machine.
the machine.
30)
30)
31)
31)
21090FW70
FALLING
FALLING (item 39)
These warning labels are positioned on the
top of the hydraulic tank and counterweight.
Falling is one of the major cause of per-
Falling is one of the major cause of per-
sonal injury.
sonal injury.
Be careful of slippery conditions on the
Be careful of slippery conditions on the
platforms, steps and handrails when
platforms, steps and handrails when
standing on the machine.
standing on the machine.
14070FW30
29)
29)

0-15
ACCUMULATOR
ACCUMULATOR (item 43)
This warning label is positioned on the
accumulator of the solenoid valve.
The accumulator is filled with high-pres-
The accumulator is filled with high-pres-
sure nitrogen gas, and it is extremely
sure nitrogen gas, and it is extremely
dangerous if it is handled in the wrong
dangerous if it is handled in the wrong
way. Always observe the following pre-
way. Always observe the following pre-
cautions.
cautions.
Never make any hole in the accumulator
Never make any hole in the accumulator
expose it to flame or fire.
expose it to flame or fire.
Do not weld anything to the accumulator.
Do not weld anything to the accumulator.
When carrying out disassembly or main-
When carrying out disassembly or main-
tenance of the accumulator, or when dis-
tenance of the accumulator, or when dis-
posing of the accumulator, it is neces-
posing of the accumulator, it is neces-
sary to release the gas from the accu-
sary to release the gas from the accu-
mulator. A special air bleed valve is nec-
mulator. A special air bleed valve is nec-
essary for this operation, so please con-
essary for this operation, so please con-
tact your Hyundai distributor.
tact your Hyundai distributor.
32)
32)
ö
ö
1107A0FW46
MACHINE
MACHINE
CONTROL
CONTROL
PATTERN
PATTERN (item 44)
This warning label is positioned inside of
screen plate.
Check the machine control pattern for
Check the machine control pattern for
conformance to pattern on this label. If
conformance to pattern on this label. If
not, change label to match pattern
not, change label to match pattern
before operating machine.
before operating machine.
Failure to do so could result in injury or
Failure to do so could result in injury or
death.
death.
See page 4-26 for details.
See page 4-26 for details.
14W90FW99
33)
33)
ö

0-16
Swing bearing
Swing bearing (item 47)
This warning label is positioned in the front
of swing ring gear.
See page 6-32 for details.
See page 6-32 for details.
35)
35)
ö
38090FW02
Battery position
Battery position (item 48)
This warning label is positioned right side of
tool box.
36)
36)
38090FW03
RCV lever pattern
RCV lever pattern (item 46)
This warning label is positioned on the
screen plate.
See page 4-25 for details.
See page 4-25 for details.
34)
34)
ö
14W90FW47

0-17
MACHINE DATA PLATE
MACHINE DATA PLATE
EQUIPMENT
MODEL ENGINE POWER(PS/KW/rpm)
SERIAL-NUMBER
OPERATING WEIGHT
DO NOT DEFACE OR REMOVE THIS PLATE
1, JEONHA-DONG, DONG-GU, ULSAN 682-792, KOREA
1
2
3
4
5
EQUIPMENT
MODEL ENGINE POWER(PS/KW/rpm)
SERIAL-NUMBER
OPERATING WEIGHT
MFG. YEAR
DO NOT DEFACE OR REMOVE THIS PLATE
1, JEONHA-DONG, DONG-GU, ULSAN 682-792, KOREA
FOR EU ONLY
1
2
3
4
5
6
21090FW10
The machine serial number assigned to this particular machine and should be used when request-
ing information or ordering service parts for this machine from your authorized HYUNDAI dealer.
The machine serial number is also stamped on the frame.
※
1 Equipment
2 Model name
3 Serial number
4 Operating weight
5 Engine power
6 Manufacturing year
