ПОРТАТИВНЫЙ DVD-ПРОИГРЫВАТЕЛЬ С 7” LED-ДИСПЛЕЕМ И ТВ-ТЮНЕРОМPORTABLE DVD PLAYER WITH 7” LED DISPLAY AND TV TUNERРуководство по эксплуатации Instruction manualH-LCDVD725T

2Table of contentsDear customer!Thank you for purchasing our product. For safety, it is strongly recommended to read this manual carefully before connecting, operating and/or adjusting the product and keep the manual for reference in the future.88999910101011111111121213131313141414141516Table of contents Before you start Utilization of the product Important safeguardsConnectionOperationControl elementsMain controllersRight panelLeft panelRemote controllerChanging the batteryJoystickButton functionsON/OFF switchOPEN buttonNumber buttonsCursor buttonsENTERVOL+/VOL-MUTEMODECH-/ and CH+/ (PLAY/PAUSE) (STOP)SETUP and DISPLAYTFT ON/OFFGOTOZOOMREPEATA-BCOPY/SUBTITLETITLEPROGRAMDVD/SD/USBRETURN23334555566667777777777777778888888888AUDIOPBC/MENUSystem setupGeneral setupAudio setupDolby digital setupVideo setupTV/FM setupPreference setupOther functionsMP3/JPEG/MPEG4 backgroundInserting discPlayback operationsUSB/SD/MMC operationRippingCopying dataDeleting data from USB/SD/MMCRotary screenGamesGeneral informationHandling compact discsCleaning discsAccessoriesTroubleshootingSpecification

3Before you startIf you want to dispose this product, do not mix it with general household waste. There is a separate collection system for used electronic products in accordance with legislation that requires proper treatment, recovery and recycling.Please contact your local authorities for the correct method of disposal. By doing so, you will ensure that your disposed product undergoes the necessary treatment, recovery and recycling and thus prevent potential negative effects on the environment and human health.Utilization of the productImportant safeguards Alerts the user to the presence of dangerous voltage within the product’s enclosure. Alerts the user to the presence of important operating instructions. To reduce the risk of electric shock or fire, do not open the cover. Refer servicing to qualified service personnel. This mark indicates this unit belongs to class 1 laser product.• To prevent the risk of fire or electric shock, don’t allow water to come into contact with the device and don’t use the device in high humidity conditions.• The device is equipped with high voltage components and a laser system, hence you shall not open the device and repair it by yourself. The laser beam is dangerous to eyes when the housing is removed. Don’t look at it.• When the device is moved from cold premises to the warm room or vice versa, condensate may form on the laser head and the device may not operate properly. In this case please turn the device on for 1-2 hours without disc before playback to heat it to a proper operation temperature.• Don’t try to manually open or close the disc tray to load discs.• Disconnect the receiver only when there is no disc therein.• If you are not going to use the device for a long time disconnect it from the wall outlet.• Before turning the device on, please make sure that you have connected it properly, adjust the volume of speakers and amplifiers of your radio system to the minimum. Adjust the volume as necessary only after normal playback has started to avoid damage of your audio system.• Use supply sources of rated voltage, otherwise the unit may not function or may be damaged.• Place the unit on a horizontal surface. Keep the unit ventilated. Don’t block the heat hole. Overheat may cause malfunction.• Do not place any objects on the player’s cover, this may make it function improperly (incorrect playback).• Please place the device in a dry and well-aired area. Do not place it near heating units or expose it to direct sunlight, mechanical vibration, humidity or excessive dust.• If using power plug and appliance coupler as a cutting-connecting device, it should be operated easily.• Never use liquid detergents, abrasives or organic compounds (alcohol, gasoline, etc) to clean the unit body.W a rning
RISK OF ELECTRIC SHOCK
DO NOT OPEN

4Before you start• All repairs and technical service should be made by qualified specialist from service centers.All images provided herein are schematic drawings and they may differ from the real objects.Connection Before you start connection of external devices, ensure that power of the unit is switched off.Audio/video outputAudio-video output is intended for connecting an external display to this unit. For connection use the included audio-video cable.Audio/video inputThe audio-video input is intended for connecting external signal sources to this unit by using the included AV cable.Headphone jackConnect your headphones to this unit by using the headphone output. When headphone is connected, the built-in speakers are mute.Power connection• For power supply from the electric mains outlet 220 V, connect the included power adaptor to the DC adaptor jack of this unit. Do not use other DC adaptors.• For power supply from the vehicle power circuit, connect the car adaptor to the DC adaptor jack of this unit. Do not use other car adaptors.• Power supply can be performed from the built-in Li-Ion battery of this unit. The battery power is enough for about 2 hours of operation. The battery charge is performed automatically when the unit is connected to external power supply. During charging, the green light of the power indicator is blinking.TV antenna jackConnect the included TV antenna to the TV antenna jack for reception of TV signal.Joystick socketsConnect the included joysticks to the GAME1/GAME joystick sockets of this unit to play the games contained in the included disc. Do not use other joysticks to ensure good performance and safety.

5OperationControl elementsMain controllers1234567891011121314151617Right panel18192021222324Left panel25261. Disc compartment cover2. OPEN button3. PLAY/PAUSE button4. DVD/USB/SD button5. button6. OK button7. MENU button8. VOL- button9. TFT OFF/ON button10. STOP button11. MODE button12. button13. button14. button15. SETUP button16. VOL+ button17. AUDIO button18. USB port19. SD/MMC memory card slot20. Headphone jack21. AV output22. AV input23. ON/OFF switch24. DC adaptor jack 12 V25. GAME1/GAME2 joystick sockets26. TV antenna jackNot indicated: power indicator (on the front side)

6Operation Remote controller12345678910111213141516171819202122231. DVD/SD/USB button2. TFT ON/OFF button3. Number buttons4. RETURN button5. COPY/SUBTITLE button6. SETUP button7. Cursor buttons/ENTER button8. button9. / buttons10. MODE button11. PROGRAM button12. DISPLAY button13. MUTE button14. TITLE button15. REPEAT button16. A-B button17. PBC MENU button18. VOL+/VOL- buttons19. AUDIO button20. button21. CH-/ and CH+/ buttons22. ZOOM button23. GOTO buttonChanging the battery1. Remove the battery compartment cover on the back of the RC.2. Insert 2 x AAA (1.5 V) batteries into the battery compartment making sure that the correct polarity is observed.3. Install the cover back.• The RC should be pointed at remote sensor within 8 meters and within 30 degrees at the left or the right side.• Take the battery out of the RC if it is not used for a long time.• Do not mix new and used batteries or different types of batteries. Weak batteries can leak and severely damage the RC.• Do not expose the RC to shock, liquids, and do not place it in an area with high humidity.Joystick12345671. Cursor2. MODE button3. START button4. A button5. C button6. B button7. D button

7OperationButton functionsON/OFF switchAfter the unit is connected to power source or if you want to use the built-in accumulator energy, set the ON/OFF switch to ON positionto switch on the unit. When the unit is on, the red light of the power indicator will light. To turn off the power set the ON/OFF switch to OFF position.OPEN buttonPress OPEN button on the unit to open the disc compartment cover.Number buttonsPress number buttons to input digits and numbers (e.g. track/chapter number, playback time, channel numbers etc.).Cursor buttonsPress cursor buttons to navigate in various menus.ENTERPress ENTER button (or OK button on the panel) for confirmation of chosen options.VOL+/VOL-Press VOL+ button to adjust volume up. Press VOL- button to adjust volume down.MUTEPress MUTE button; the sound output will be muted. Press this button again or adjust volume to resume the sound.MODEPress this button repeatedly to switch between TV, FM, DVD and AV input modes. Media mode selection is available only if the corresponding storage is inserted into the unit.CH-/ and CH+/• When playing DVD disc, press CH-/ button to go to the previous chapter.• When playing SVCD, VCD, CD disc, press CH-/ button to go to the previous track.• In TV and FM modes press CH-/ button to go to the previous channel/station.• When playing DVD disc, press CH+/ button to go to the next chapter.• When playing SVCD, VCD, CD disc, press CH+/ button to go to the next track.• In TV and FM modes press CH+/ button to go to the next channel/station. Functions of CH-/ and CH+/ buttons on the RC correspond to functions of and buttons on the panel correspondingly. (PLAY/PAUSE)When the playback is paused or stopped, or a file/track is selected in a menu, press button on the RC or PLAY/PAUSE button on the panel to start playback. During playback press this button to pause playback. (STOP)When playing DVD/SVCD/VCD/CD disc, press this button once, the unit will memorize the previous ending point; when afterwards you play the same disc, playback will start from the memorized point. Press button twice, playback will stop without memorizing the stop point.SETUPPress SETUP button to enter or exit the system setup menu. and • When playing video or music, press button repeatedly for quick rewind search. Press button repeatedly for quick forward search. Search speed will increase with each pressing: 2x => 4x => 8x => 16x => 32x => normal.• In TV and FM modes press these buttons repeatedly to adjust the frequency step by step. Functions of and buttons on the RC correspond to functions of and buttons on the panel correspondingly.DISPLAYPress this button to display various info on

8Operationthe current playback: title/chapter number or time elapsed/remaining, etc.TFT ON/OFFPress this button to switch off the display; there will be dark screen instead of the image of the current mode. Press the button again to switch on the display.GOTOPress this button to display menu in which you can input track/chapter/title number or disc playback time by pressing number buttons. After you input the data, playback will start from the input point.ZOOMWhen playing DVD/VCD disc, press ZOOM button to zoom in the picture as follows: 2x => 3x => 4x => 1/2 => 1/3 => 1/4 => normal. In zoom in mode, press cursor buttons to move the picture for viewing.REPEATPress REPEAT button to repeat a title, chapter, track or the whole disc (available repeat modes depend of the disc and file type).A-BPress A-B button to set the initial point of a video fragment. Press A-B button again to set the final point; the selected fragment will be played repeatedly. Press this button again to cancel framgent playback.COPY/SUBTITLE• When playing a disc with multi-language subtitle, press this button continually, the subtitle languages are changed in a circle, and you can select the needed one.• When a USB/SD/MMC is connected, press this button to access Copying menu (if data disc is being used) or Ripping menu (if CD disc is being used).TITLEWhen playing a DVD disc, press this button to return to the main title menu of the disc.PROGRAM• If the disc contains 2 or more tracks, chapters or titles, set up the playing order to your preference. Press PROGRAM button to enter program menu.• Press number buttons to input the number of the track, title or chapter. If programmed tracks are over ten, select item and press ENTER button to go on programming. Maximum 20 programmable items are possible. Use cursor buttons to move the cursor to START item. Press ENTER button to start program playback. Press PROGRAM button to cancel programming. For MP3 disc, this function is not available.DVD/SD/USBPress this button to select disc, memory card or USB playback, when these storages are connected to the unit.RETURNPress this button to return to disc menu while playback. Press again to resume playback.AUDIO• When playing DVD with more than one audio stream, press this button to select the needed language.• When playing CD/VCD/MPEG, press this button to select audio channel (left mono/right mono/mix-mono/stereo).PBC/MENU• When playing a VCD disc, press this button to turn on or off Playback Control (PBC) function.• When playing a DVD/USB/SD, press this button to go to the root menu.

9OperationSystem setup1. Press SETUP button to enter the setup menu. In Setup menu, press SETUP button again to quit the setup page.2. Use / buttons to choose a setup page.3. Press button to enter the setup page selected.4. Use / buttons to select the option you want to adjust.5. Press button to enter the adjustment list. Use / buttons to select the adjustment and press ENTER button to confirm and button to return to options list.6. To return to setup page list press button when in the option list. The items in gray can’t be set up. The setup is memorized and kept after power is off.General setup pageGeneral setup pageTV displayAngle markOSD langCaptionsScreen saverLast memory• TV DISPLAYNormal/PS: the wide-screen image shows on the full screen, but some part is cut off.Normal/LB: the wide-screen image shows and black bars appear on the top and bottom of screen.Wide: Use this item for wide-screen image.• ANGLE MARKIt will show the angle mark when playing DVD disc with multi-angle view if selecting On.• OSD LANGUAGESelect on-screen display language: English, Russian.• CAPTIONSThis function doesn’t work when the disc without caption. The default setup is On.• SCREEN SAVERIf the Screen saver is set On and the unit is switched on without a disc playing for several minutes, a moving picture appears on the screen, and the unit will go to standby mode after several minutes. You can press any button to wake it up.• LAST MEMORYWhen this function is on, the unit can memorize the time elapsed from the last time you played the disc. Then at the next playing, it will resume playing from the memorized time. Audio setup pageAudio setup pageDownmix• DOWNMIXLT/RT: The audio out is Left and Right channels format even if the original sound is 5.1CH format.Stereo: The audio out format is stereo even if the original sound is 5.1CH format. Dolby digital setupDolby Digital SetupDual monoDynamic• DUAL MONOStereo: stereo output signal,

10OperationL-Mono: left output signal,R-Mono: right output signal,Mix-Mono: left/right output average signal.• DYNAMICIf watching large dynamic scope movie program at night, to select this mode you can reduce the volume to a very low level, at the same time, to keep the fine details sounds. In this case, this doesn’t disturb the family and keep the quality sounds.Video setupVideo Setup PagePanel quality• PANEL QUALITYYou can set the level of Sharpness, Brightness, Contrast, Hue and Saturation according to your preference.TV/FM setup (available only in TV and FM modes)TV PageAuto searchManual searchTV system• AUTO SEARCHSelect START and press ENTER button to start automatical search and saving of all available strong-signal TV or FM (depending on the current mode) stations in the memory. Press button to stop search.• MANUAL SEARCHSelect START and press ENTER button to start automatical search and saving for the nearest available TV or FM (depending on the current mode) station. After finding the first station the search will stop. Press ENTER button again to continue. Press button to stop search..• TV SYSTEM (not available in FM mode)Select the color and sound system: NTSC M, PAL D/K, PAL B/G, PAL I, SECAM-BG, SECAM-DK.Preference setup (available only after full stop of playback)Preference PageTV typeAudioSubtitleDisc menuParentalPasswordDefault• TV TYPEThis unit is suitable for all kinds of TV systems. You can select one of the PAL, NTSC or Auto.AUTO: the TV system is auto switched according to the disc system.NTSC: this system is used in USA, Taiwan, Japan etc.PAL: this system is used in China, Europe, Hong Kong etc.• AUDIO, SUBTITLE, DISC MENU language These are the initial settings by your preference. If a setting is supported by disc content, it will work. Otherwise the disc default value works. And these settings can be changed respectively by pressing AUDIO and COPY/SUBTITLE buttons when playing.• PARENTALThe control level is for parental to control playing content and protect your children from violence and erotic. The disc, the level of which

11Operationfollowing interface will be displayed:1231. Playback info window - shows current playback time, track number, volume level, playback status (stop/play/pause) etc.2. Address window - shows directory address at which the currently played file is found.3. Directory window - shows the currently selected directory.Use / buttons to select the directory you want and press ENTER button to enter it. Select a file and press ENTER button to start its playback. For more playback operations please refer to “Button functions“ chapter. JPEG playback notes:• While a file playback, press button, 8 thumbnails will be shown on the screen.• Press cursor buttons to select the desired picture.• Press number buttons to input directly the number of the desired picture.• Use cursor buttons to select SLIDE SHOW item, then press ENTER button to start slide show.• Use cursor buttons to select MENU item, then press ENTER button to enter button function menu.The button function menu is as follows:ButtonFunctionPROGRAMSelect slideshow transition effectEntering thumbnail modeis higher than the setting level can not be played.• PASSWORDChange the password. The initial factory password is 0000. You can set your own password. If you forget your own password, you can use 0000 as general password.• DEFAULTReset to the initial factory setups (except Parental and Password items).Other functionsMP3/JPEG/MPEG4 backgroundMP3 - generally adopted standard of audio compression, compressing audio data to 1/12 of their size. One CD disc mat store more than 600 minutes of music (170 songs). And the quality of MP3 disc approximates to an audio CD disc quality.JPEG (Joint Photographic Expert Group) - image compression algorithm, used all over the world and providing high level of compression of the source data. Any graphics editor may edit images of this format and their size in 15-20 times less then the original images.MPEG4 - standard for transmitting audio and video data via channels with low capacity. This format is very popular since it made possible to place full-length movies with good enough resolution in one CD. Manufacturer guarantees regular playback of licensed discs only. Some AVI files cannot be played due to their parameters and recording conditions. Video files more than 2 Gb having AVI extension can be played partially.Inserting discPress OPEN button on the unit to open the disc compartment cover. Put a disc onto the spindle and press on the center until it is fixed. Close the compartment cover.Playback operationsWhen a disc, a USB or a memory card containing files of these formats is inserted,

12OperationNext picturePrevious pictureTo play pictureInvert imageMirror imageSelect CONTINUE item and press ENTER button to go to the second menu page:Rotate 90 degrees anticlockwiseRotate 90 degrees clockwiseZOOMChange zoom modeZoom outZoom in///Move the zoomed imageSelect EXIT MENU item and press ENTER button to exit. Depending on file volume and encoding, some delay is possible when changing modes or passing to the next menu item.USB/SD/MMC operationsInsert a USB drive in the USB port, then select the Disc mode and press DVD/SD/USB button to select USB playback.Insert an SD or MMC card into the Memory card slot, then select the Disc mode and press DVD/SD/USB button to select card playback.Operations with USB/SD/MMC file playback are the same as file disc operations. SD/MMC up to 16 Gb and USB up to 500 Gb are supported by this unit. FAT/FAT32 file systems are supported. Please use USB devices and memory cards of famous brands; some models of USB devices or memory cards cannot be supported by this unit due to incompatibility.According to the USB 1.1/2.0 Standard, usage of a USB device with power current consumption exceeding 500 mA is not recommended without supplementary power supply. Failure to use supplementary power for connected USB drives with power consumption exceeding this value as well as defective USB drives may cause mechanical or thermal changes of elements of this unit as well as failure of internal elements of the USB port. Such damages are not warrantee cases.Warning: usage of external USB drives containing BIN files in the root directory may cause malfunction of the unit or damage to the software.RippingThis unit has Ripping function making it handy and quick to copy audio files (e.g. music) from CDs. RIPPING is converting from CDDA format to the compressed MP3 format onto a USB drive or memory card. In the course of copying, ID3 tags are generated automatically in Russian and English, depending on the source. If the disc does not contain such information in CD-text format, ID3 tags will be written as “Unknown artist” and “Unknown album”.RIPPING function has a simple and intuitive menu. To display the Ripping menu, press COPY/SUBTITLE button on the RC while CD playback. A USB-drive or a memory card should be connected to the unit.Create ID3 Yes
For navigation in the menu use cursor buttons and press ENTER button to confirm your option. In “Options” column you may set speed and bit rate for ripping, confirm or cancel ID3-tag creation, select USB or memory card

13Operationas destination storage. In “Track” column you may select tracks for ripping (press ENTER button to select a highlighted track). Besides, you can select all tracks (“Select all”) or cancel your choice (“Select none”). To start converting process, select “Start” and press ENTER button.SummaryAfter the CD ripping procedure begins, the system will proceed to the next menu page.In Ripping window, there are a track progress bar and a total progress bar showing how much the ripping procedure for the current track has been done and how much the total task has been finished respectively.During ripping, the option Cancel is highlighted, so whenever you want to cancel ripping, just press ENTER button.The ripped tracks from CD or HDCD discs will be stored in a folder created automatically by the system in the destination storage.Copying data• Play data disc or USB/SD/MMC containing MP3/JPG/DivX files.• Press COPY/SUBTITLE button on RC, the COPY menu will appear with option of ALL SELECT/ALL UNSEL/COPY/DELETE/EXIT.• Move the cursor to the target file or folder, press ENTER button to tick it, or select ALL SELECT item to select all the data.• Move the cursor to COPY item, then press ENTER button to display the destination (USB or Memory card).• Select the desired target device (USB or Memory card), press ENTER button to display the option BACK/NEXT.• Choose NEXT item to start copying data the selected device.Deleting data from USB/SD/MMC• Play USB device or memory card containing the desired data.• Press COPY/SUBTITLE button to get the menu of ALL SELECT/ALL UNSEL/COPY/DELETE/EXIT.• Move the cursor to the target file or folder, press ENTER button to tick it, then move to DELETE item and press ENTER button to delete the data from the device.Rotary screenThis unit is equipped with a rotary screen. When the screen is open, rotate is with both hands clockwise (1800) and counterclockwise (900). When the screen is rotated, you can fold the unit body for a more comfortable use.Games• Insert the supplied game disc into the disc compartment, select Disc mode. The display will show page 1 of the game bank.• Connect the supplied joysticks to the joystick slots of this unit. Press LEFT/RIGHT cursor buttons on the joystick to select bank pages. Press UP/DOWN cursor buttons on the joystick or press number buttons on the RC to select a game in the current page. Press START button on the joystick to start the game.• Functions and operation of joystick buttons may vary for each individual game.• Press button on the RC to quit the current game.

14General informationHandling compact discs• Do not insert anything other than a CD into the disc tray.• Do not use cracked, chipped, warped, or otherwise damaged discs as they may cause damage to the player.• Handle the disc only by the edges (as shown in the picture). To keep discs clean do not touch its surface.• Store discs in their cases when not in use.• Do not expose discs to direct sunlight, high humidity, high temperature or dust.• Prolonged exposure to extreme temperature can wrap a disc.• Do not attach labels, write on or apply chemicals to the surface of the discs.• Do not touch the recorded surface of the discs.• Use 12-cm CDs. Use only conventional, fully circular discs. Do not use irregularly shaped discs.Cleaning discsFingerprints should be carefully wiped from the surface of disc with a soft cloth. Unlike conventional records, compact discs have no grooves to collect dust and macroscopic dirt, so gently wiping them with a soft cloth should remove must panicles. Wipe in a straight motion from the center to the edge.Never use thinner benzine, record cleaner or anti static spray on a compact disc. Such chemicals can damage its plastic surface.AccessoriesDVD player 1 pcRemote controller 1 pсAudio-video cable 1 pcBattery AAA/1.5V 2 pcsHeadphones 1 pcCar adaptor 1 pcTV antenna 1 pcAC/DC adaptor 1 pcBattery pack (built-in) 1 pcProtective bag 1 pcJoystick 2 pcsGame disc 1 pcConsumer information 1 pcWarranty card 1 pcInstruction manual 1 pc

15General informationTroubleshootingBelow is a table describing simple measures that can help you eliminate most problems likely to emerge when this unit is in use. If below measures do not help, turn to a service center or to the nearest dealer.SymptomCauseSolutionNo soundPoor audio cable connectionMake proper connectionDisc dirty or damagedClean the discMUTE function is onDisable MUTE functionNo imagePoor video cable connectionMake proper connectionIncorrect setting of your TV setCorrect the settings of your TV setDisc cannot be readDisc not insertedInsert the discDisc inserted incorrectlyInstall the disc with the label side facing upCondensate on the unit laser headSwitch the unit on without disc for an hourRemote control does not operateRemote control is incorrectly directed at the unitUse the remote controller according to the manualDistance and angle to the unit are too largeDecrease the distance and angleRun out batteriesReplace both batteriesSome functions do not workDisc is recorded incorrectlyWait 5-10 seconds and the unit will automatically return to normal styleIncorrect key sequenceRepeat the operation one more timeStatic voltage on the unit housingSwitch the unit off for 1-2 minutes and then switch it on againUnstable imageIncorrect TV settingsCorrect the TV settings

16General informationSpecificationsAppearanceUnit dimensions 208 mm x 160 mm x 45 mmNet/Gross weight 0.78 kg/1.66 kgDisplay 7” TFT LEDDisplay format 16:9CompatibilitySupports DVD/DVD±R/DVD±RW/CD/CD-R/CD-RW/USB/SD/MMCFormats of playback DVD-video/DVD-audio/SVCD/VCD/HDCD/CDDA/MP3/ Kodak Picture CD/JPEG/MPEG4 (DivX/XviD)AudioBuilt-in Dolby Digital decoder +VideoColor system NTSC/PALTV-tunerTV system PAL/SECAMSound system DK/BG/IConnectorsAudio-video out +Earphone jack +Audio-video in +FunctionsChildren lock +Rotary screen 2700Russian and English OSD +Audio CD ripping in MP3 format toUSB flash drive/SD card +Copy function from data discs toUSB flash drive/SD card +Games +PowerAC/DC adaptor +Car adaptor +Battery Li-ion +Nominal voltage 12 V, 1.5 ANominal power consumption 18 WSpecifications are subject to change without notice. Dimensions are approximate.

17СодержаниеУважаемый покупатель!Благодарим Вас за покупку нашего изделия. Чтобы понять, как правильно и безо-пасно пользоваться приобретенным устройством, рекомендуется тщательно изучить настоящее руководство перед подключением и эксплуатацией изделия. Сохраняйте руководство для использования в будущем.2424242424252525262627272727282929303030313131313233Содержание Перед началом эксплуатации Утилизация изделия Меры предосторожностиПодключениеУправление устройствомЭлементы управленияОсновные органы управленияПравая панельЛевая панельПульт дистанционного управленияУстановка батареекДжойстикФункции кнопокПереключатель ON/OFFКнопка OPENКнопки с цифрамиКнопки курсораENTERVOL+/VOL-MUTEMODECH-/ и CH+/ (PLAY/PAUSE) (STOP)SETUP и DISPLAYTFT ON/OFFGOTOZOOMREPEATA-BCOPY/SUBTITLETITLEPROGRAMDVD/SD/USB17181818192020202021212121222222222222222222222222232323232323232323232324RETURNAUDIOPBC/MENUНастройка системыСтраница общих настроекСтраница аудио установокНастройки Dolby DigitalСтраница установки видеоНастройки ТВ/FMНастройка предпочтенийПрочие операцииВоспроизведение файлов MP3/JPEG/MPEG4Загрузка дискаВоспроизведениеОперации с USB/SD/MMCФункция RippingКопирование данныхУдаление файлов с USB/SD/MMCПоворотный экранИгрыОбщая информацияОбращение с компакт-дискамиЧистка дисковКомплект поставкиРуководство по устранению неисправностейТехнические характеристики

18Перед началом эксплуатацииЕсли вы желаете утилизировать данное изделие, не выбрасывайте его вместе с обычным бытовым мусором. Существует отдельная система сбора использованных электронных изделий в соответствии с законодательством, которая предполагает соответствующее обращение, возврат и переработку.Обращайтесь в органы местного управления за инструкциями по правильной утилизации продукта. Тем самым Вы обеспечите утилизацию Вашего изделия с соблюдением обязательных процедур по обработке, утилизации и вторичной переработке и, таким образом, предотвратите потенциальное негативное воздействие на окружающую среду и здоровье людей.Утилизация изделияМеры предосторожности Предупреждение о наличии высокого напряжения внутри устройства. Напоминание о проведении всех действий в соответствии с инструкциями. Во избежание риска поражения электрическим током или пожара не открывайте корпус изделия. Обращайтесь к квалифицированному пер-соналу. Изделие принадлежит к лазерной продукции 1 класса.• Для предотвращения риска возгорания или удара током избегайте попадания в устройство воды и эксплуатации устройства в условиях высокой влажности.• Устройство содержит компоненты под высоким напряжением и лазерную систему, поэтому не пытайтесь самостоятельно от-крывать и ремонтировать устройство. Лазер-ный луч опасен при снятой крышке корпуса.• При перемещении устройства из холод-ного места в теплое и наоборот на лазер-ной головке может образоваться конденсат и устройство не будет работать должным образом. В этом случае перед началом вос-произведения включите устройство на 1-2 часа без диска для прогрева до комнатной температуры.• Не пытайтесь открывать или закрывать лоток для загрузки дисков вручную.• Отключайте питание устройства только при отсутствии диска.• Выключайте устройство из розетки, если Вы не собираетесь использовать его в течение долгого времени.• Перед включением устройства убе-дитесь, что оно подключено правильно, установите на минимум уровень громкости усилителя и динамиков Вашей аудиосисте-мы. Регулируйте уровень громкости только после начала воспроизведения, чтобы из-бежать повреждения аудиосистемы.• Подключайте устройство только к сети с параметрами, соответствующими напря-жению питания аппарата.• Устанавливайте устройство горизон-тально; обеспечивайте хорошую вентиля-цию, не закрывайте отверстия, предназна-ченные для отвода тепла.• Не ставьте посторонние предметы на корпус устройства; это может стать причи-W a rning
RISK OF ELECTRIC SHOCK
DO NOT OPEN

19Перед началом эксплуатацииной некорректной работы устройства.• Устройство должно находиться в сухом и проветриваемом месте. Исключайте на-хождение устройства вблизи нагреватель-ных приборов, не подвергайте воздействию солнечного света, механической вибрации, влажности и пыли.• Не используйте для чистки корпуса устройства жидкие чистящие средства, абразивные материалы или органические соединения (алкоголь, бензин и др.).• Для ремонта и технического обслужи-вания устройства обращайтесь в сервисные центры.Все иллюстрации, приведенные в на-стоящем руководстве, являются схе-матическими изображениями, которые могут отличаться от реальных объектов.Подключение Перед началом подключения устрой-ства к другому оборудованию убедитесь, что электропитание отключено.АудиовидеовыходАудио/видеовыход предназначен для подсоединения дополнительного внешне-го монитора к данному устройству. Для подсоединения используйте входящий в комплект аудиовидеокабельАудиовидеовходАудиовидеовход предназначен для под-ключения данного устройства к внешнему источнику сигнала; подсоединение выпол-няется с помощью входящего в комплект аудиовидеокабеля.Разъем для наушниковПодсоедините наушники к разъему для наушников данного устройства. При подклю-ченных наушниках звук через встроенный динамик устройства не воспроизводится.Питание устройства• Дли питания от электросети 220 В под-соедините входящий в комплект сетевой адаптер к разъему для адаптера данного устройства. Не используйте адаптеры, не входящие в комплект поставки.• Для питания от бортовой сети авто-мобиля подсоедините автомобильный адаптер, входящий в комплект поставки, к разъему для адаптера данного устройства.• Возможно питание от встроенной батареи. Заряда батареи хватает при-близительно на 2 часа работы устройства. Зарядка батареи происходит автоматиче-ски при подключении устройства к внешней сети питания. При первом использовании батарея будет заряжена не полностью, это не является дефетом. Время зарядки бата-реи зависит от степени ее разряжености. Во время зарядки батареи мигает зеленая лампа индикатора питания.Разъем для ТВ-антенныПодсоедините входящую в комплект ТВ-антенну к разъему для ТВ-антенны данного устройства для получения ТВ-сигнала.Разъемы для джойстиковПодсоедините входящие в комплект джойстики к разъемам GAME1/GAME данного устройства; с помощью джойсти-ков вы можете играть в игры, доступные на входящем в комплект диске с играми. Не используйте джойстики, не входящие в комплект поставки.
