I-CAN 2000T User manual

WWW.I-CAN.TV i

WWW.I-CAN.TV ii
All Rights Reserved
The product described in this manual is protected by international copyright laws. Under this copyright law,
you are prohibited from duplicating the software or hardware for any purpose. In addition, no part of this
manual may be reproduced or transmitted, in any form or by any means, electronic or mechanical, including
photocopying, recording, or information storage and retrieval systems, for any purpose other than the
purchaser’s personal use, without the prior written permission of the manufacturer.
Disclaimer
The manufacturer specifically disclaims all warranties, either express or implied, including but not limited to
implied warranties of merchantability and fitness for a particular purpose, with respect to the software, the
accompanying product manual(s) and written materials, and any other accompanying hardware. The
manufacturer reserves the right to revise or make improvements to its product at any time and without
obligation to notify any person of such revisions or improvements. In no event shall the manufacturer be
liable for any consequential or incidental damages, including any loss of business profits or any other
commercial damages, arising out of the use of its product.
Trademarks
The manufacturer does not claim any trademarks that appear in this publication. All names, brands,
products or services are trademarks or registered trademarks of their respective companies.

WWW.I-CAN.TV iii
Safety First
This digital decoder has been manufactured to meet international safety standards. However, safety precautions must
be followed to ensure the safe and reliable operation of the decoder. Please take note of the following guidelines.
To Avoid the Risk of an Electric Shock
This decoder operates with an external power supply in the range
of 100 to 240V AC, 50/60 Hz. Use a standard AC wall outlet; a DC
power source cannot be used. Remember that contact with 110-
240 Volts AC power supply can be lethal.
Ensure that all electrical connections are properly made before
connecting the decoder to the power supply. Always unplug the
decoder before connecting or disconnecting any cables.
Whenever you connect the decoder to the power supply, always
connect the power lead to the power input connector on the back
panel of the decoder before you connect the power brick to the
wall socket outlet.
Whenever you disconnect the decoder from the power supply, always remove the power brick
from the wall socket-outlet before you remove the other end of the lead from the power input
connector on the back panel of the decoder.
Never attempt to repair or reconstruct the decoder yourself. A serious electric shock may occur if
this decoder is repaired, disassembled or reconstructed by an unauthorized person.
Be extremely careful if this unit is in contact with water. Immediately disconnect the power brick if
possible.
DO
 If anything falls into the cabinet, unplug the decoder and have it checked by a qualified technician.
 Allow adequate air circulation to prevent internal heat build-up. Do not place the unit next to a radiator or any heat
source and make sure that the air vents are not covered.
DO NOT
× … expose the decoder to extreme temperature, direct sunlight or high humidity.
× … place any objects on top of the decoder in order to allow air circulation.
× … place the decoder on fabric furnishings, carpets or other flammable materials.
Removing the decoder’s cover
may lead to a severe & potentially
fatal electric shock.

WWW.I-CAN.TV iv
Maintenance
If you wish to clean your decoder, disconnect it first of all from the power supply. To clean the decoder, use a soft, dry
cloth. For very dirty surfaces, dip a soft cloth in a weak soap-and-water solution and wring well. After cleaning, wipe with
a soft, dry cloth. Never use alcohol, paint thinner, or a chemically treated cloth to clean this unit. Such chemicals may
damage the unit’s finishing.

WWW.I-CAN.TV v
Contents
1INTRODUCTION.................................................................................................................................... 1
2YOUR DECODER .................................................................................................................................. 1
Unpacking Your Digital Decoder ............................................................................................................ 1
Front Panel............................................................................................................................................. 2
Back Panel ............................................................................................................................................. 2
Connectivity Diagram ............................................................................................................................. 3
Smart Card ............................................................................................................................................. 3
Remote Control ...................................................................................................................................... 4
3HOW TO SET UP YOUR DECODER .................................................................................................... 5
Welcome Screen .................................................................................................................................... 5
Language................................................................................................................................................ 5
Country ................................................................................................................................................... 5
Channel Search...................................................................................................................................... 6
4USING YOUR DECODER...................................................................................................................... 7
Turning Your Decoder On / Off .............................................................................................................. 7
Basic Rule “Point & Select” .................................................................................................................... 7
Channel Banner ..................................................................................................................................... 7
Channel List.......................................................................................................................................... 10
Options Menu ....................................................................................................................................... 10
Extended Information About Programs ................................................................................................ 11
Locked Channels.................................................................................................................................. 11
Running Interactive Applications.......................................................................................................... 11
5MAIN MENU......................................................................................................................................... 12
Viewer Planner ..................................................................................................................................... 14
Channel Manager................................................................................................................................. 14
List Organization .................................................................................................................................. 17
For Parents........................................................................................................................................... 17
Your Preferences ................................................................................................................................. 18
Installation ............................................................................................................................................ 20

WWW.I-CAN.TV vi
Help ...................................................................................................................................................... 24
6ELECTRONIC PROGRAM GUIDE...................................................................................................... 25
Categories ............................................................................................................................................ 25
Reminders ............................................................................................................................................ 26
Extended Information ........................................................................................................................... 26
7BEFORE REQUESTING SERVICE..................................................................................................... 27
8APPENDIX A TECHNICAL DATA .................................................................................................... 29
9APPENDIX B GLOSSARY OF TERMS ............................................................................................ 30

WWW.I-CAN.TV 1
1 Introduction
About This Manual
This User Manual describes the overall functionality of your decoder (set-top box). You will find here all the information
you need to get started. First, make sure that your decoder is properly installed. Next, pick up your remote control and
follow the instructions in this manual. Once you have learnt how to operate the remote control and familiarized yourself
with the main features of your decoder, you will need this manual only for reference.
About Your Decoder (Set-Top Box)
Using your digital decoder makes viewing easier, with much more information and guidance, and much more control
over what you watch than any previous TV system.
Your decoder will allow you to do the following:
 see what programs are on all accessible channels
 prevent your children from viewing unsuitable programs
 display additional information pertaining to a selected program
 download a selection of games or interactive services
 sort channels lists
 and many others
Please be aware that from time to time your decoder’s software may be automatically updated, and this new
software can change the functionality of your decoder.
Please note that if want to have always the most up-to-date software version and updated channels list on
your decoder, it is advised to switch your decoder to standby mode if you are not using it.
2 Your Decoder
Unpacking Your Digital Decoder
As you unpack your digital decoder, please make sure that the following accessories are included:
 Remote control with separately packed batteries
 External power supply (power brick)
 SCART and RF coaxial cables
 Telephone modem cable
 Getting Started document
If any parts are missing, please contact your vendor.

WWW.I-CAN.TV 2
Front Panel
Smart Card allows you to view
scrambled TV and Radio channels.
Gently push the card into the slot.
Its chip should face downwards and
the symbol of an arrow should face
inwards.
Indicator light:
Green - operating mode
Red - in standby, low power consumption
The indicator light flickers when your
decoder is receiving signals from the
remote control
Back Panel
2
13
4568
7
1– RJ-11 plug for connection of a modem to the phone line 5 – SCART for connection to the TV
2– DC Input from external power supply 6 – Antenna signal input
3– Video output for connection to the VCR 7 – Output to TV for analogue TV programs
4– Analogue audio outputs for a Hi-Fi system or VCR 8 – Optical S/PDIF for AC-3 Digital Audio out

WWW.I-CAN.TV 3
Connectivity Diagram
Smart Card
Your Smart Card
Smart Card allows you to view scrambled TV and Radio channels. Gently
push the card into the slot. Its chip should face downwards and the
symbol of an arrow should face inwards. Without the smart card, you
can view all free-to-air channels. More information about the card can be
found in the Decoder Status submenu.
Looking After Your Smart Card
The card is fragile, so keep in mind the following precautions:
 Do not bend or twist the card
 Do not expose the card to heat or sunlight
 After inserting the card, leave it in the slot permanently
 Clean only with a soft dry tissue
Inserting Smart Card

WWW.I-CAN.TV 4
Remote Control
Button Action
Switches your decoder between standby and the operating modes.
Displays the Applications window. Pressing this button a second time
closes the Application window.
Displays one of the channel lists. Pressing this button a second time
hides both the Channel List and the Channel Banner.
Select the channel you want to tune to then press .
Switches circularly between: viewing mode, Channel Banner and
Channel Banner with Extended Information.
In the Channel Banner, switch between the current program information
and the next program information. In the menu, select menu items or
change parameters with predefined values.
In Channel Banner, scroll channel information up/down. The decoder
remains tuned to the current channel. In the menu, select menu items or
options.
In viewing mode, runs interactive applications (if available).
In the Channel Banner, tunes to the channel the Channel Banner refers
to. In the menu, selects the currently highlighted menu item or confirms
your choices made in the menu screens.
Increases / decreases audio volume.
Displays / leaves the menu system.
In viewing mode or in the Channel Banner, tune to the next/previous
channel. In the Channel List, menu, or in Electronic Program Guide,
scroll the channel list page up/down.
Mutes the sound. Pressing this button once again will restore the
previously set volume level.
Displays the Options menu.
In viewing mode or in the Channel Banner, alternates between the
current and previous program within the same Channel List. In the
menu or in the Electronic Program Guide, returns to the previous
screen.
Removes the Channel Banner, or Extended Information from the screen.
In the menu system or Electronic Program Guide, returns to normal
viewing.
Color buttons are used to navigate through external MHP applications
such as program guide, t-commerce, voting, etc.
The number buttons allow you to type your choice directly, for example
channel numbers or a PIN.
Switches the source signal.
Displays the Viewer Planner, for example if you have programmed
reminders.
Adds the current channel to the selected favorite list.
Displays the Electronic Program Guide for the currently tuned channel.
This button is used to navigate through external MHP applications such
as program guide, t-commerce, voting, etc

WWW.I-CAN.TV 5
3 How to Set up Your Decoder
Welcome Screen
Once your decoder and any other equipment have been connected, plug
both the TV set and the decoder to the mains and turn it on. Now you will
see the Welcome screen on your TV screen. After a few seconds, the
Language screen appears.
Welcome Screen
Language
The Language screen allows you to select the language for any
information displayed on the screen. Press / to highlight
the on-screen language, and then press to make a selection. Once
you select the language, the confirmation screen appears. After you
have confirmed your choice, the change is taken into effect and the
Country selection screen appears.
Language
Country
The Country screen allows you to select the country in which the
decoder is configured. Press / to highlight the country,
and then press to make a selection. Once you select the country,
the confirmation screen appears. After you have confirmed your choice,
the change is taken into effect and the channel search procedure is
initialized.
Country

WWW.I-CAN.TV 6
Channel Search
Once you select and confirm the country and press , the channel
search will start automatically. When this procedure has been
completed, you will be informed about the total number of channels
found. Then press the button to tune to the first TV channel.
If the channel searching procedure has not been concluded
successfully, a respective error message appears. You can then
press the button to go back to the Language screen or enter
the menu system where you will be able to access Installation and
Help submenus. These and other parts of the menu system are
described later in this manual.
Channel Search
Channel Searching Completed

WWW.I-CAN.TV 7
4 Using Your Decoder
Turning Your Decoder On / Off
Switch on the TV set and any other connected equipment. Then switch your decoder on by pressing the button on
the remote control. When you are not using your decoder, put it into standby by pressing this buttons again. The standby
mode of operation is indicated by the red light on the front panel. When the decoder comes out of standby, the last
channel viewed appears.
Basic Rule “Point & Select”
You only need to know one rule to use your decoder. This rule is called
“Point and Select”. Once you master this rule, you can use any part of
your decoder’s functionality. You “point” by pressing the arrow buttons on
the remote control or front panel. Pressing the arrow buttons moves the
“on-screen” highlight to different items on the screen. Once you have
pointed to an item on the screen, select it by pressing the button
on the remote control.
Channel Banner
Channel Banner appears at the bottom of the screen
when you tune your decoder to a new channel or when
you press the button.
It offers you basic information about individual programs
and facilitates surfing through channels and programs.
Channel Banner will disappear automatically after a few
seconds or when you press .
Note that some Channel Banner information will be
available only in case of digital channels.

WWW.I-CAN.TV 8
Channel Banner Icons
Alternative audio languages are available for the current program.
Channel Banner displays info concerning a locked channel.
Extended info about a particular program is available.
Informs you that pressing tunes to the channel that the Channel Banner refers to.
Program is broadcast with the surround sound.
Informs that the recording reminder has been set for a particular event.
Informs that the viewing reminder has been set for a particular event.
This symbol informs that the program is parentally locked.
This symbol informs that external applications are available on a particular channel.
This symbol informs that teletext is broadcast on the currently tuned channel.
This symbol informs that the viewer has a choice of subtitles for the current program.
This symbol informs that a particular channel is scrambled.

WWW.I-CAN.TV 9
Selecting programs in the Channel Banner
Channel Banner allows you to display information concerning the current
program and the next program broadcast on the selected channel.
 If the information displayed in the Channel Banner concerns the
current program, the right arrow symbol appears to the left of
the program name. Pressing the button displays information
about the program that is broadcast next on the same channel.
 If the Channel Banner displays information about the next program,
the right arrow symbol is replaced with the left arrow symbol
. Pressing the button then displays information about the
current program on the same channel.
Current Program Info
Next Program Info
Selecting channels
There are three different ways of changing channels.
 Press / to scroll through the current channels list.
When you press , the Channel Banner displays information
concerning the next higher channel. When you press , the
Channel Banner displays information concerning the next lower
channel. Please note that your decoder remains tuned to the current
channel.
If the Channel Banner displays information about the current
program that is not broadcast on the currently tuned channel, the
symbol appears. Pressing tunes to that program.
 When you press ch , your decoder tunes to the next higher
channel. When you press ch , your decoder tunes to the next
lower channel.
 You can also select channels by entering their numbers directly.
Once you press a number button, the channel number entry box
appears in the upper right corner of the screen.
Channel Banner (Tuning to the Channel)
Channel Number Entry Box

WWW.I-CAN.TV 10
Channel List
Your receiver gives you access to 7 TV channel lists and 7 Radio
channel lists. In order to access the list, press the button on your
remote. After that you will have access to the lists of all your TV and
Radio channels. Use the button to switch between Radio and TV
lists. If there are already defined favorite channels lists, you can access
them by pressing / buttons. Creating your favorite channels lists is
described in the Channel Manager section later in this manual. Once you
are in the desired channels list, select the channel by pressing /
or number keys. Each time you highlight a non-current channel,
the icon appears in the Channel Banner. To tune to this channel,
press .
The Channel List allows you to work in so-called browsing mode. In this
mode, the decoder remains tuned to the same channel, while you
browse through channels and programs.
Channel List
Options Menu
Press the button to gain access to the Options menu. This
menu allows you to change the Audio Language, the Subtitle
Language, the Teletext Language or the Display Format for the
currently broadcast program. Your new settings take effect immediately
and they are remembered until the program ends. When the program
ends, the settings revert to their default values.
Audio Language
If available, you can select among different audio languages being
broadcast. If any AC3 languages are available for the current program
they are marked by the symbol.
Subtitle Language
If available, you can select among different subtitle languages. If you
select OFF, no subtitles will be displayed.
Teletext Language
If available, you can select among different teletext languages.
Display Format
If you have a TV set with a 4:3 picture format, and the transmission is in
the 16:9 format (or the other way round), you can change display
format for the currently broadcast program. You have a choice
between: Letter-box, Pan-Scan, and Full Screen.
Options Menu
No Options Are Available

WWW.I-CAN.TV 11
Extended Information About Programs
The icon displayed in the Channel Banner informs you that
pressing the button displays some additional information about
the currently selected program. When you press , the Extended
Info window appears above the Channel Banner. Press or to
remove the Extended Info window from the screen.
Extended Info
Locked Channels
You can protect access to entire channels using your PIN code. For
more information on how to lock channels see For Parents section of this
manual. All locked channels are marked by the sign in the Channel
Banner. When you try to tune to a locked channel, the PIN entry box
appears. Enter your PIN if you want to unlock the channel, or press
and tune to another channel. When you enter the correct PIN code, all
the locked channels remain unlocked until you switch your decoder into
standby mode and then into the operation mode again.
Locked Channel (PIN Code Box)
Running Interactive Applications
If you can see the icon in the Channel Banner, this means that
there are interactive applications available on this channel. In order to get
access to a list of the applications simply press the button on your
remote. This brings up the Applications window. You can select any
available application using / buttons and confirm your
selection by pressing button.
If you want to leave the running application, you can press the
button or simply change the channel with the ch /buttons.
Note, that if the same application is available on the consecutive
channel, changing to that channel will not end the application.
Interactive Applications Window

WWW.I-CAN.TV 12
5 Main Menu
Your decoder offers the Menu System allowing you to
change the way many of the features of your decoder
operate. To gain access to the Menu System, press the
button. To evoke one of the submenus, highlight the
item using the arrow buttons and then press . To
return to the Main Menu from one of its submenus, press
the button. To exit the Menu System immediately,
press the button or button again.
Main Menu window

WWW.I-CAN.TV 13
Here is a short overview of basic functions performed by individual submenus:
Viewer Planner
Gives you access to the Recording Timers and Viewing Timers.
Channel Manager
Allows you to rename, move and skip channels.
List Organization
Allows you to organize your favorite lists of channels.
For Parents
Allows you to lock/unlock an entire channel, to change the current PIN code, and to define the decoder’s lock
or parental level.
Your Preferences
Allows you to define your preferences concerning on-screen display as well as audio and subtitle languages.
Installation
Allows you to configure your system, to set up your modem, to search for existing channels, to check
decoder’s status, to set up local time, and to restore factory settings of your decoder.
Help
Gives you access to the on-line help information concerning the basic functionality of your decoder.

WWW.I-CAN.TV 14
Viewer Planner
When you select Viewer Planner from the Main Menu, you get access to
already set timers. If there are no timers set, that can be done is this
screen. Pressing will bring up the Setting A Timer screen.
Viewer Planner
Setting A Timer
In the Setting a Timer screen, the current data are displayed such as: the
current channel, current date and time. By pressing / , you
can select the channel, date, start/end time, timer type and frequency.
Using /
buttons you can change the values. For channel, date
and start/end time modification you can also use digit buttons on your
remote. When you set all the values, simply press . If all the values
are acceptable, the acceptance screen will appear. Pressing
returns you the Viewer Planner screen where you the timer you set will
be shown.
Note that if the selected channel is locked, you will be asked for the PIN
before the timer is accepted.
Setting A Timer
Channel Manager
When you select Channel Manager from the Main Menu, you can define
content of individual channel lists as well as modify channels belonging
to individual lists. The Modify option allows you to perform a number of
operations relating to channels belonging to the currently selected
channel list. You can Add, Lock, Move, Skip, Rename or Delete
channels.
Channel Manager
