I-O DATA AVeL Link AVLP2/DVDLA User manual

Network Media Player with Built-in DVD Player
AVeL Link Player
AVLP2/DVDLA
User's Manual
B-MANU200080-02
Read the attached “Setup Guide” before using this product. Keep this
manual and “Setup Guide” in a secure place for future reference.

Table of contents
Introduction
Functions of the AVeL Link Player..................................................................... 2
Important Safety Information ............................................................................. 3
Precautions for Use............................................................................................. 9
Checking the Items in the Package................................................................... 11
Checking the Operating Environment .............................................................. 12
Name of Each Part............................................................................................ 13
・Remote Controller ............................................................................ 13
・AVeL Link Player.............................................................................. 19
Preparation [1] Checking the Operating Environment......................................................... 22
[2] Preparing the Remote Controller ................................................................ 23
[3] Connecting the AVeL Link Player ............................................................... 24
[4] Installing AVeL Link Server ........................................................................ 26
[5] Checking the IP Address of the Computer .................................................. 29
・Windows XP ..................................................................................... 30
・Windows 2000 .................................................................................. 32
・Windows Me/98 SE .......................................................................... 34
・Mac OS X ......................................................................................... 35
[6] Setting the AVeL Link Player for the First Time............................................. 36
・Setting the IP Address of the AVeL Link Player ............................... 36
Playing
Video/Audio
Playing a File in the Computer...................................................................... 40
Playing a DVD-Video, Video CD or Music CD ............................................ 43
Playing from a USB Equipment or DVD/CD Medium................................... 44
Troubleshooting
Troubleshooting................................................................................................ 48
Others Reference on AVeL Link Server........................................................................ 54
・Windows ........................................................................................... 54
・Mac OS X ......................................................................................... 60
Reference on AVeL Link Player Screens .......................................................... 61
Connecting Other Equipment ........................................................................... 66
・Connecting an AV Amplifier............................................................. 66
Updating the Firmware..................................................................................... 67
Content of the CD-ROM .................................................................................. 68
Uninstalling AVeL Link Server......................................................................... 68
Specifications.................................................................................................... 69
Setup:
Step by step
instruction

１
Introduction
Functions of the AVeL Link Player p.2
Important Safety Information p.3
Precautions for Use p.9
Checking the Items in the Package p.11
Checking the Operating Environment p.12
Name of Each Part p.13

２
Functions of the AVeL Link Player
The AVeL Link Player can be connected to a TV to play DVD-Videos as well as movies and other audio/video files
stored in a network computer.
Play videos, music and images stored in a computer!
You can play movies stored in a network computer.
Play DVDs and CDs!
You can play videos, music and images stored in various media
including video CDs, music CDs and recordable DVDs.
Play data from a USB equipment!
You can play videos, music and images stored in a USB
equipment such as USB-compatible hard disk or memory
card reader.

３
Important Safety Information
The following describes cautionary items that must be observed to prevent injury to the user or property damage, and to ensure the safe,
correct use of this product. Be sure to observe the items described below when using your AVeL Link Player. Note that some
instructions cover products in general, in addition to the AVeL Link Player manufactured by I-O DATA DEVICE.
■Warnings and Cautions
Warning Inappropriate handling without observing the instruction given may result in death or serious injury of the user.
Caution Inappropriate handling without observing the instruction given may result in minor injury of the user or property damage.
■Meaning of Symbols
This symbol indicates a caution (or warning).
The specific item requiring caution/warning is described inside or near the symbol.
Example) indicates "Fire Hazard."
This symbol indicates a prohibited action.
The specific action being prohibited is described inside or near the symbol.
Example) indicates "Do Not Disassemble."
This symbol indicates a required action.
The specific action being required is described inside or near the symbol.
Example) indicates "Disconnect Power Plug."
Warning
Disconnect
Power Plug
If you have detected abnormal heat,
smoke, noise or smell, immediately
stop using the product.
In the event of an abnormality, turn off the power
and disconnect the power
p
lug from the power
socket. Continuing to use the product may result
in electric shock or fire.
Do Not
Disassemble
Do not repair, modify or disassemble the
product.
Doing so may result in fire, electric shock, burns or
malfunction.
Should you require repair, contact our repair service section.
We reserve the right to charge the user, even during the
warranty period, for repair of any damage resulting from an
unauthorized disassembly or modification.
Prohibited
Do not block the air vent.
The air vent is provided to prevent the temperature
inside the product from rising. Do not block the
air vent by placing an article on or against the air
vent. Doing so may cause the internal
temperature to rise, resulting in fire or breakdown.
Prohibited
Do not place an object inside the equipment.
Do not place a metal piece or other flammable object inside
the equipment.
Doing so may result in fire or electric shock.
Electric
Shock
Hazard
Do not remove the case cover.
Many of the internal parts are charged with high
voltage. Touching these parts will put life in
danger.
Strictly
Observe
Firmly insert the power plug.
Confirm that the power plug is free from attachment of dust,
and then insert the plug firmly all the way to the end.
An incompletely connected power plug may result in fire due
to poor contact.
Prohibited
Do not step on the product.
The product may tip over or break, resulting in
injury or breakdown.
* In particular, pay attention to small children
playing with the product.
Do Not
Wet
Do not wet the product.
Exercise special caution when using the product on the beach
or near water, or in any other outdoor location or near a
window on a rainy day.

Important Safety Information
４
Warning
Strictly
Observe
Disconnect the power plug to turn off
the power.
Pressing the POWER button alone will not
completely cut off the power supply. If the product
will not be used for a long period of time,
disconnect the power plug from the power socket.
Failure to do so may result in damage or breakdown
of the product in the event of lightening, etc.
Prohibited
Exercise caution when handling the cables.
Use the supplied cables and handle them with care by
observing the instructions given below. Inappropriate
handling may damage the cables, resulting in fire or electric
shock.
●Do not place an object on the cables.
●Do not bend the cables. ●Do not modify the cables.
●Do not pull the cables. ●Do not compress the cables.
●Do not use the cables near a heating equipment.
Prohibited
Do not drop or apply impact on the product.
Do not drop the product, hit it against an object, or otherwise
apply impact on the product. Once the product receives
impact, fire or electric shock may result from subsequent
use.
Strictly
Observe
Connecting/disconnecting the power
plug.
●When connecting/disconnecting the power cable,
always do so by holding the plug. Pulling the
cable may cause the cable to partially break,
resulting in fire.
●When connecting/disconnecting the power plug
to/from the power socket, make sure your hands
are dry. Handling the power plug with wet hands
may result in electric shock.
●Do not place any article around the power socket,
because it will obstruct quick disconnection of
the power plug when necessary.
Prohibited
Do not place any object on the product.
Doing so may cause the product to damage, or result in fire
or electric shock. In particular, a flower vase, planting pot
or other container filled with liquid can cause fire or electric
shock if it tips over and spills the liquid.
If a foreign matter has entered the product, immediately turn
off the power switch and disconnect the power plug from the
power socket.
Prohibited
Do not use this product in the places listed below.
Failure to do so may result in breakdown.
●Humid place ●Dusty place
●Place subject to vibration or shock ●Place where the air vent will be blocked
●Place subject to steep temperature gradient ●On an unstable foundation
●Place exposed to the direct sun ●Near a heating equipment
●Place subject to high temperature, such as inside a closed car ●Poorly ventilated place or narrow space
Strictly
Observe
Moving to a cooler place
If the product is moved from a cold place to a
warm place, bedewing may occur on the exterior
surface of or inside the product. Continuing to
use the product with dews attached on the surface
or internal parts may cause fire or electric shock.
After moving the product, let it assimilate several
hours in the new environment without turning on
the power.
Prohibited
Do not damage the power cable.
●Do not place a heavy object on the cable.
●Do not pull the cable. ●Do not kink the cable.
●Do not modify the cable. ●Do not heat the cable.
●Do not forcibly bend the cable.
●Do not lay another cable together.
Prohibited
Do not charge the batteries.
Doing so may cause battery fluid to leak, resulting
in injury or burns.
Prohibited
Do not use the product after dropping or
otherwise damaging it.
Doing so may result in fire or electric shock.
Prohibited
Do not touch leaked battery fluid with bare hands.
If battery fluid gets into the eye or contacts the skin or clothes, blindness, injury or skin inflammation may occur.
What to do when battery fluid got into the eye
⇒Do not rub the eye. Immediately rinse the eye under clear running water, such as tap water, to wash away the battery
fluid completely, and then immediately seek medical attention.
What to do when battery fluid contacted the skin or clothes
⇒Immediately rinse the affected area under clear running water, such as tap water, to wash away the battery fluid
completely. If there is a symptom of skin inflammation or injury, seek medical attention.

Important Safety Information
５
Warning
Prohibited
Observe the instructions given below regarding the batteries.
Failure to do so may cause battery fluid to leak, resulting in injury or burns.
●Do not put the batteries in fire or heat, disassemble, modify or wet the batteries.
●Do not connect the positive and negative sides in reverse.
●Do not short the positive and negative sides with a metal piece or use solder on the batteries.
●Do not drive a nail into the batteries or disassemble/modify the batteries.
●Do not carry the batteries together with a necklace, hair pin or other metal object.
●Do not leave the batteries in a car or other place subject to high temperatures of 60°C or above.
●Do not put the batteries in a microwave oven or conventional oven.
●Do not use the batteries under conditions outside the ratings.
●Do not mix new and old batteries or dry batteries of different types together.
Strictly
Observe
Keep the batteries away from small children.
If swallowed, a battery may cause suffocation or damage the stomach or other internal organs.
If a child accidentally swallowed a battery, immediately seek medial attention.
Strictly
Observe
Observe the instructions given below regarding the power cable.
●Be sure to use the supplied or specified power cable.
●Do not modify, forcibly bend, kink or pull the power cable.
●When disconnecting the power cable from the AC outlet, be sure to hold the cable by the plug.
Pulling the cable may cause wire breakage or shot circuit, resulting in fire or electric shock.
●Do not connect or disconnect the plug of the power cable to/from the AC outlet using wet hands.
Doing so may result in electric shock.
●Do not touch the product with wet hands while the power cable is connected to the AC outlet.
Doing so may result in electric shock.
●If the product will not be used for a long period, disconnect the power cable from the power source. Leaving the power
cable connected to the power socket for a prolonged period will consume electricity and may result in heating.

Important Safety Information
６
Caution
Disconnect
Power
Plug
Touching the metal and other surfaces of the product.
If abnormality is found in a metal or plastic part of the product after relocation, etc., turn off the power and disconnect the
power plug from the power socket. Continuing to use the product may result in electric shock or fire. Also, do not place any
article around the power socket, because it will obstruct quick disconnection of the power plug when necessary.
Strictly
Observe
About the cables
●Wire the cables carefully so that they will not be accidentally pulled with a leg, etc. If the cables are pulled with an excessive
force, an injury may result or the connected equipment may sustain damage.
●Do not place a heavy object on the cables or wire them near a heating equipment. Doing so may tear the cable cover,
resulting in poor contact or other problem.
Strictly
Observe
Install the product in the specified
orientation.
Do not install the product sideways or upside
down.
Prohibited
Do not place the product on an unstable
foundation.
Placing it on a wobbly base or tilted surface may cause the
product to drop or tip over, resulting in breakdown or injury.
Strictly
Observe
When the batteries have been
consumed or the product will not be
used for a long period, take out the
batteries.
Leaving the batteries in the product may cause
battery fluid to leak due to overdischarge, resulting
in injury or burns. Should battery fluid leak,
thoroughly clean the areas around the battery case
using a dry cloth, etc., and then install new
batteries.
Prohibited
Do not move the product with the cables
connected.
Doing so may damage the power cable, resulting in fire or
electric shock.
Move the product after confirming that the power cable,
antenna wire and other connection cables have been
disconnected.
Prohibited
Do not turn off the power while the product is sending/receiving data.
Doing so may cause breakdown or loss of data.
Strictly
Observe
Observe the instructions given below regarding the handling of medium.
●When holding a medium directly, do not touch the shiny surface.
Secure the medium between fingers hooked at the outer rim or by
hooking one finger at the center hole and another at the outer rim.
●Do not attach a paper or sticker on a medium to ensure the medium will be played properly and also to prevent vibration or
spinning noise from increasing.
●Never use a cracked or warped medium. Do not put together broken
pieces of a medium using tape or adhesive. A medium spins at
high speed in the product, so playing a damaged medium can
create danger.
●Insert a medium into the drive after making absolutely sure that nothing is attached on the medium (DVD-R or CD-R
medium divider, etc.). Inserting a medium together with a divider, etc., may cause breakdown.

Important Safety Information
７
Do not see the internal laser beam directly.
Doing so may result in visual impairment. Never look into the internal mechanism.
DANGER : VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID DIRECT EXPOSURE TO BEAM.
CAUTION : DVD NETWORK PLAYER IS A CLASS 1 LASER PRODUCT. HOWEVER, THIS PLAYER USES
VISIBLE LASER BEAM WHICH COULD CAUSE HAZARDOUS RADIATION EXPOSURE IF
DIRECTED. BE SURE TO OPERATE THE PLAYER CORRECTLY AS INSTRUCTED.
CAUTION : When this player is plugged to the wall outlet, do not place your eyes close to the opening of the disk tray
and other opening to look into the inside of this player.
CAUTION : Use of controls or adjustments or performance of procedures other than those specified herein may result
in hazardous radiation exposure.
CAUTION : Do not open covers and do not repair yourself. Refer servicing to qualified personal.
WARNING : To reduce the risk of fire or electric shock, do not expose this player to rain or moisture.
WARNING : To reduce this risk of fire ro electric shock, and annoying interference, use the recommended accessories
only.
The following caution label appears on your unit.
Location : Back of the unit

Important Safety Information
８
FCC Notices
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
・This device may not cause harmful interference.
・This device must accept any interference received, including interference that may cause undesired operation.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void the user's Authority to operate the
equipment.
NOTE>>>
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generated uses and can radiate radio frequency energy and, if not installed and used in accordance with the manufacturer's
instruction manual, may cause interference with radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, you are encouraged to try to correct the interference by one or more of the following measures:
・Reorient or relocate the receiving antenna.
・Increase the separation between the equipment and the receiver.
・Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
・Consult the dealer or an experienced radio/television technician for help.
FCC CAUTION
Properly shielded the grounded cables and connectors must be used for connection to host computer and / or peripherals in order to meet
FCC emission limits.
For Canadian model / Pour le modèle Canadien
This Class B digital apparatus complies with Canadian ICES-003.
Cet apareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

９
Precautions for Use
Supported Formats
●Supported Video Formats (* The figures are peak values. As for the bit rate, both the CBR and VBR systems are supported.)
Format Wired LAN DVD CD USB 2.0 USB 1.1
MPEG-1,MPEG-2 12Mbps 10Mbps 4Mbps 10Mbps 3Mbps
DivX,XviD 1.5Mbps 1.5Mbps 1.5Mbps 1.5Mbps 1.5Mbps
WMV9 8Mbps 8Mbps 4Mbps 8Mbps 3Mbps
* AVI files can be played only when they are interleaved.
If a non-interleaved file is played, either video or audio will not be played properly. Make sure the file you want to play is interleaved.
For interleaving of a file during the file creation process, refer to the Help screens or manual of the encoding application you are using.
* DivX files encoded with GMC, Quarter Pixel or Adaptive Multiple Consecutive setting cannot be played.
* Copyright-protected WMV9 files cannot be played.
●Supported Audio Formats (* The figures are peak values. As for the bit rate, both the CBR and VBR systems are supported.)
Format Bit rate Sampling rate
MP3 64k～192kbps 32k/44.1k/48kHz
WMA (excluding WMA9Pro) 64k～192kbps 44.1k/48kHz
PCM(WAVE) In conformance with the sampling rate shown to the right. 32k/44.1k/48kHz
Ogg Vorbis 64k～192kbps －
AAC 64k～192kbps 32k/44.1k/48kHz
* Copyright-protected WMA files cannot be played.
●Supported Image Formats
Format Resolution Display method
2048×1532 NetworkJPEG
1600×1200 DVD/CD, USB
BMP 2048×1532 Network
GIF 2048×1532 Network
PNG 2048×1532 Network
* Network refers to wired LAN connection.
●Limitations on Video File Size
Format Maximum file size
AVI(DivX, XviD) 2GB
MPEG Varies in accordance with the format specification of the disk in which the file is saved.
(Example: 4 GB if the disk format is FAT32, or 2 TB if the disk format is NTFS)
WMV9 Varies in accordance with the format specification of the disk in which the file is saved.
(Example: 4 GB if the disk format is FAT32, or 2 TB if the disk format is NTFS)

Precautions for Use
１０
How to Care
●To remove soiling on the cabinet or operation panel, wipe the soiled area gently using a soft cloth.
●To remove stubborn stains, wipe with a cloth that has been moistened with water-diluted neutral detergent and wrung tightly, and
then remove excess liquid using a dry cloth. Do not use benzine, thinner or other solvent. Doing so may cause the surface material
to deteriorate or coating to peel.
●When using a chemically treated cleaning cloth, follow the instructions for use provided by the manufacturer.
Updating the Firmware
I-O DATA DEVICE, INC. releases update versions of the firmware as they become available.
We recommend that you use the latest firmware version, because it often provides functional improvements and enhancements.
* Refer to "Updating the Firmware" (p.67) in this manual.
In order to update the firmware, the network to which your AVeL Link Player is connected must be able to connect to the Internet.

１１
Checking the Items in the Package
Select the check boxes to confirm that all items are included in the package.
Should you find any missing item, please contact our Support Center.
AVeL Link Player (1)
Remote Controller (1) Remote Controller Batteries
(2, AAA)
Straight LAN Cable (1)
AV C a b l e ( 1 )
Component Conversion Cable (1)
Power Cable (1) CD-ROM Containing Support
Software (1)
Setup Guide (1)
User's Manual (this document)
Warranty Card (1)
Wired MAC access
S/N（Serial number）
Mac:
S/N:

１２
Checking the Operating Environment
The types of computers that can be connected to the AVeL Link Player and supported operating environments are specified below.
Check the model and operating environment of your computer once again.
Types of computers that can communicate with the AVeL Link Player
Supported models Supported operating systems
●DOS/V machine
●Windows XP
●Windows 2000
●Windows Me
●Windows 98 Second Edition
●Macintosh series ●Mac OS X 10.3
Other required equipment
LAN Wired
LAN
●LAN adapter
* The LAN software must have been installed and set up.
CD-ROM drive Required for installing the support software provided in the CD-ROM.
Video, audio and image formats supported by the AVeL Link Player
Video: MPEG-1, MPEG-2, DivX®(3.11/4.x/5.0.x/5.1.x/5.2), XviD, WMV9
Audio: MP3, WMA(excluding WMA 9 Pro), PCM(WAVE), Ogg Vorbis, AAC
Image: JPEG, BMP, GIF, PNG
Disks supported by the AVeL Link Player
DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-ROM, CD-R, CD-RW, CD-ROM
* PacketLight is not supported.
Devices connected to the USB port
USB mass storage devices formatted with FAT (16) or FAT32
(To find out if your USB equipment is a USB mass storage device, check with the manufacturer of the
equipment.)
* For the latest information regarding the recommended USB products for use with the AVeL Link Player, please log on to our
web site (http://www.iodata.com/usa/).

１３
Name of Each Part
Remote Controller
●DVD Mode (Playback of DVD-Videos, Video CDs and Music CDs)
(1) Power button (POWER)
⇒Turn on/off the power
(19) Open/close button (EJECT)
⇒Open/close the tray
(2) Alphanumeric input buttons
⇒Enter numbers
(20) PBC button (SELECT)
⇒Perform playback control
(in Video-CD playback mode)
(3) Clear button (CLEAR)
⇒Not used
(21) Play/pause button (PLAY/PAUSE)
⇒Switch between playback and pause
(4) Output switching button (TV MODE)
⇒Switch the output mode
(22) Mute button (MUTE)
⇒Mute the sound
(5) Setup button (SETUP)
⇒Display the setup screen
(23) Stop button (STOP)
⇒Stop playback
(6) Server button (SERVER)
⇒Display the server screen after the
DVDends
(24) Confirm button (ENTER)
⇒Confirm the selection/entry
(7) ↑/↓/←/→button
⇒Move the cursor
(25) Menu button (MENU)
⇒Display the main menu
(8) Return button (BACK)
⇒Not used
(26) Forward button (FWD)
⇒Forward the medium (4 speeds)
(9) Reverse button (REV)
⇒Reverse the medium (4 speeds)
(27) Next button (NEXT)
⇒Move to the next chapter
(10) Previous button (PREV)
⇒Move to the previous chapter
(28) Volume button (VOLUME) (+)
⇒Increase the volume
(11) Slow/step button
(SLOW)
⇒Reverse/forward the medium at
slow speed (maximum 1/8)
(29) Audio button (AUDIO)
⇒Switch the audio mode
(12) Home button (HOME)
⇒Return to the home after the DVD
ends
(30) Volume button (VOLUME) (-)
⇒Decrease the volume
(13) Zoom button (ZOOM)
⇒Enlarge the screen
(31) Search button (SEARCH)
⇒Perform search
(14) Subtitle button (SUBTITLE)
⇒Switch the subtitle
(32) Reload button (RELOAD)
⇒Not used
(15) URL/CODE button (URL/CODE)
⇒Not used
(33) Information button (INFO)
⇒Display information
(16) Repeat button (REPEAT)
⇒Switch the repeat mode
(34) Point-to-point button (A-B)
⇒Specify/cancel the repeat playback
range
(17) Angle button (ANGLE)
⇒Switch the angle
(18) Title button (TITLE)
⇒Display the title menu

Name of Each Part
１４
●File Mode (Playback of Files in a Computer or Medium)
(1) Power button (POWER)
⇒Turn on/off the power
(2) Alphanumeric input buttons
⇒Enter alphabets and numbers
(3) Clear button (CLEAR)
⇒Delete one character
(4) Output switching button (TV MODE)
⇒Switch the output mode
(5) Setup button (SETUP)
⇒Display the setup screen
(6) Server button (SERVER)
⇒Display the server selection screen
(7) ↑(↓) button
⇒Move the cursor
Play the next (previous) file
←(→) button
⇒Move the cursor
Move backward (forward)
(8) Return button (BACK)
⇒Return to the previous screen
(9) Reverse button (REV)
⇒Reverse the file (4 speeds)
(10) Previous button (PREV)
⇒Move to the previous file
(11) Slow/step button
(SLOW)
⇒Not used
(12) Home button (HOME)
⇒Return to the home
(13) Zoom button (ZOOM)
⇒Switch the zoom mode on the screen
Fit To Screen: Keep the aspect ratio
Full Screen: Maximize the image
Actual: Do not enlarge the image
(14) Subtitle button (SUBTITLE)
⇒Switch the subtitle
(This button may not function
depending on the data)
(15) URL/CODE button (URL/CODE)
⇒Display the URL entry screen
(16) Repeat button (REPEAT)
⇒Switch the repeat mode
(video,music)
(17) Angle button (ANGLE)
⇒Not used
(18) Title button (TITLE)
⇒Not used
(19) Open/close button (EJECT)
⇒Open/close the tray
(20) PBC button (SELECT)
⇒Switch the text input mode
(21) Play/pause button (PLAY/PAUSE)
⇒Switch between playback, pause and
continuous playback
(22) Mute button (MUTE)
⇒Mute the sound
(23) Stop button (STOP)
⇒Stop playback
(24) Confirm button (ENTER)
⇒Confirm the selection/entry
(switch between playback and
pause during playback)
(25) Menu button (MENU)
⇒Not used
(26) Forward button (FWD)
⇒Forward the file (4 speeds)
(27) Next button (NEXT)
⇒Play the next file
(28) Volume button (VOLUME) (+)
⇒Increase the volume
(29) Audio button (AUDIO)
⇒Switch the audio mode
(video,music)
(30) Volume button (VOLUME) (-)
⇒Decrease the volume
(31) Search button (SEARCH)
⇒Not used
(32) Reload button (RELOAD)
⇒Refresh the files in a folder
(33) Information button (INFO)
⇒Not used
(34) Point-to-point button (A-B)
⇒Not used

Name of Each Part
１５
●Detail Explanation of the Remote Controller
NO. Button Explanation
(1) POWER
Turn on/off the power to the AVeL Link Player. When this button is off, it means the AVeL Link Player
is in the standby mode. Turn off the POWER button on the AVeL Link Player if the Link Player will
not be used for a long period.
(2) Alphanumeric
input buttons
These buttons are used to enter text during setup. The mode will switch sequentially to CAPS LOCK
ON, NUM LOCK ON and CAPS LOCK OFF each time the SELECT button is pressed.
●CAPS LOCK ON mode (Entry of uppercase alphabets)
You can enter different characters by pressing each button quickly for an appropriate number of times,
just like you do with your mobile phone.
Button Press once Twice 3 times 4 times 5 times 6 times 7 times
1*1 . : / @ ( )
2 A B C 2
Return to "Press Once."
3 D E F 3
Return to "Press Once."
4 G H I 4
Return to "Press Once."
5 J K L 5
Return to "Press Once."
6 M N O 6
Return to "Press Once."
7 P Q R S 7
Return to "Press Once."
8 T U V 8
Return to "Press Once."
9 W X Y Z 9
Return to "Press Once."
0 0SPACE
Return to "Press Once."
* The character will change to ",", "!", "?"..... when the button is pressed eight times or more.
●NUM LOCK ON mode (Entry of numbers)
The numbers displayed on the remote controller are entered.
●CAPS LOCK OFF mode (Entry of lowercase alphabets)
You can enter different characters by pressing each button quickly for an appropriate number of times,
just like you do with your cellular phone.
Button Press once Twice 3 times 4 times 5 times 6 times 7 times
1*1 . : / @ ( )
2 a b c 2
Return to "Press Once."
3 d e f 3
Return to "Press Once."
4 g h i 4
Return to "Press Once."
5 j k l 5
Return to "Press Once."
6 m n o 6
Return to "Press Once."
7 p q r s 7
Return to "Press Once."
8 t u v 8
Return to "Press Once."
9 w x y z 9
Return to "Press Once."
0 0SPACE
Return to "Press Once."
* The character will change to ",", "!", "?"..... when the button is pressed eight times or more.
(3) CLEAR Delete the character immediately before the cursor.
(4) TV MODE
Pressing this button will switch the output mode to Composite/S-Video or Japanese D4* temporarily.
The output mode selected by switching this button will not become effective the next time the power
is turned on. The video output setting you have made on the setup screen will be given priority.
* Supported D modes (480i, 480P, 720P, 1080i)

Name of Each Part
１６
NO. Button Explanation
(5) SETUP Start the setup screen.
Refer to p.62 for the setup screen.
(6) SERVER Display the server selection screen.
↑（↓）
Normally these buttons are used to move the cursor. The cursor is displayed in blue border or crosshatch.
In the file mode, pressing each button during continuous list playback will play the next (or previous)
file.
(7)
←（→）
Normally these buttons are used to move the cursor. The cursor is displayed in red border or crosshatch.
In the file mode, you can specify the playback position directly during data playback by using these
buttons.
(8) BACK Return to the last screen in the file mode.
(9) REV
●In the DVD mode, the reverse playback speed will change sequentially to x8, x16, x32 and x48
each time this button is pressed. The screen shows "REVERSE."
●In the file mode, the reverse playback speed will change sequentially to x1, x2, x3 and x4 each time
this button is pressed. The screen shows "FR."
●The speed is fixed to x8 when a music CD is played.
(10) PREV
Return to the previous chapter in the file currently played. In the DVD mode, pressing this button
will play the previous chapter (track). During continuous list playback in the file mode, pressing
this button will play the immediately preceding file in the list.
(11) SLOW
●In the DVD mode, the slow reverse speed will change sequentially to x1/2, x1/4 and x1/8 each time
this button is pressed. The screen shows "SLOW."
●This button is not used in the file mode.
* Pressing this button during pause will switch to the step mode.
* This function may not be supported depending on the format of the movie file being played.
(12) HOME In the file mode, pressing this button will display the home screen.
(13) ZOOM
●Pressing this button while a DVD is played will enlarge the center of the screen.
●In the file mode, this button will switch the display mode on the screen. One of the following three
modes can be specified:
- Fit To Screen
Image is displayed according to the monitor size. Since the aspect ratio is kept, image will
not be distorted. However, black streaks may be shown depending on the monitor.
- Full Screen
Image is displayed according to the monitor size. Since the aspect ratio is not kept, some
distortion may occur depending on the file, although image can be displayed over the entire
screen.
- Actual Size
Image is displayed in the actual size set in the file. If the image size of the file is larger than
the screen, the image will be adjusted to fit the screen.
(14) SUBTITLE If multiple subtitle options are provided for the AVI file or DVD to be played, this button can be used
to switch the selected subtitle option.
(15) URL/CODE In the file mode, pressing this button will display the URL entry screen.
(16) REPEAT
●In the DVD mode, pressing this button once will display "CHAPTER" on the screen and cause the
applicable chapter to be played repeatedly. Pressing the button again will display "TITLE" on the
screen and cause the applicable title to be played repeatedly.
Pressing the button yet again will display "CLEAR" on the screen and cancel the repeat mode.
●In the file mode, this button can be used to select whether to repeat the file currently played
(REPEAT ONE) or entire file list currently played (REPEAT ALL).

Name of Each Part
１７
NO. Button Explanation
(17) ANGLE If multiple angle options are provided for the DVD to be played, this button can be used to switch the
selected angle option.
(18) TITLE Display the title menu of the DVD.
(19) EJECT Open/close the tray.
(20) SELECT
●Switch the input mode when entering text.
Three input modes are available, as described below.
The mode will switch sequentially every time this button is pressed.
- CAPS LOCK ON mode (Entry of uppercase alphabets)
The symbols and alphabets (uppercase) displayed on the remote controller are entered.
You can enter different characters by pressing each button quickly for an appropriate number of
times, just like you do with your cellular phone.
- NUM LOCK ON mode (Entry of numbers)
The numbers displayed on the remote controller are entered.
- CAPS LOCK OFF mode (Entry of lowercase alphabets)
The symbols and alphabets (lowercase) displayed on the remote controller are entered.
You can enter different characters by pressing each button quickly for an appropriate number of
times, just like you do with your mobile phone.
●When a video CD is being played, pressing this button will enable/disable PBC (PlayBack Control).
The PBC setting will return to the default once the AVeL Link Player is powered off.
(21) PLAY/PAUSE
●In the DVD mode, pressing this button will cancel pause and start playback. The original
playback speed will be restored if the disk is currently in reverse, forward or slow playback mode.
●In the file mode, pressing this button on the playback data selection screen will play all files
currently displayed (continuous playback).
(22) MUTE In both the DVD mode and file mode, pressing this button will mute the sound. Press this button if
you want to mute the sound temporarily. Pressing the button again will restore the sound.
(23) STOP Stop the playback.
(24) ENTER Press this button to confirm the selected/entered item at the cursor position.
(25) MENU In the DVD mode, pressing this button will display the main menu.
(26) FWD
●In the DVD mode, the playback speed will change sequentially to x8, x16, x32 and x48 each time
this button is pressed. The screen shows "FORWARD."
●In the file mode, the playback speed will change sequentially to x1, x2, x3 and x4 each time this
button is pressed. The screen shows "FF."
(27) NEXT
Play the next chapter in the file currently played.
●In the DVD mode, pressing this button will play the next chapter (track).
●During continuous list playback in the file mode, pressing this button will play the file immediately
after in the list.
(28) VOLUME (+)
Increase the volume of the data being played. Normally, the volume should be set to the default
level of 4.
* When the digital audio data is being played, this function supports only for Linear PCM.
(29) AUDIO
If multiple audio options are available for the AVI file or DVD to be played, this button can be used to
switch the selected audio option. In the file mode or while video or music is played, pressing this
button will switch the audio option.
(30) VOLUME (-)
Decrease the volume of the data being played. Normally, the volume should be set to the default
level of 4.
* When the digital audio data is being played, this function supports only for Linear PCM.

Name of Each Part
１８
NO. Button Explanation
(31) SEARCH
You can specify the time or title/chapter and play
the DVD from the specified position.
(Both the title and chapter must be specified.)
(32) RELOAD Refresh the files in a folder.
(33) INFO
Display the information of the DVD, music CD or other medium being played, or information of the
repeat mode or other setting currently effective.
This button is disabled in the file mode.
(34) A-B
In the DVD mode, this button is used to repeat the specified range.
Pressing the button once will show "A POINT SET" on the screen.
Pressing it again will show "B POINT SET."
Thereafter, the segment between A and B will be played repeatedly.
When the button is pressed once again, the screen will show "AB REPEAT CLEARED" and the
repeat mode will be cancelled.
DVD search
Time 00:00:00
Title/chapter 000/000
