i-Stor iS16U3 User manual

SATA II RAID Subsystem
User Manual
Revision 1.0

SATA II RAID Subsystem
2 User Manual
Table of Contents
Preface ................................................................................................................................ 5
Before You Begin ............................................................................................................. 6
Safety Guidelines............................................................................................................................................................... 6
Controller Configurations .............................................................................................................................................. 6
Packaging, Shipment and Delivery ............................................................................................................................ 6
Unpacking the Shipping Carton ............................................................................................................................ 7
Chapter 1 Product Introduction ................................................................................. 8
1.1 Technical Specifications ..................................................................................................................................... 10
1.2 RAID Concepts ...................................................................................................................................................... 11
1.3 SCSI Concepts........................................................................................................................................................ 16
1.3.1 Multiple SCSI Format Support ................................................................................................................ 16
1.3.2 Host SCSI ID Selection .............................................................................................................................. 16
1.3.3 Terminators .................................................................................................................................................... 17
1.4 Array Definition ..................................................................................................................................................... 18
1.4.1 Raid Set ........................................................................................................................................................... 18
1.4.2 Volume Set .................................................................................................................................................... 18
1.5 High Availability .................................................................................................................................................... 19
1.5.1 Creating Hot Spares ............................................................................................................................. 19
1.5.2 Hot-Swap Disk Drive Support .......................................................................................................... 19
1.5.3 Hot-Swap Disk Rebuild ........................................................................................................................ 19
Chapter 2 Identifying Parts of the RAID Subsystem .......................................... 20
2.1 Main Components ............................................................................................................................................... 20
2.1.1 Front View ...................................................................................................................................................... 20
2.1.2 Rear View ........................................................................................................................................................ 23
Chapter 3 Getting Started with the Subsystem ................................................... 25
3.1 Disk Drive Installation......................................................................................................................................... 25
3.2 Connecting to Host ............................................................................................................................................. 26
3.3 Powering On .......................................................................................................................................................... 26
3.4 SCSI Termination .................................................................................................................................................. 27
3.5 Connecting an Interrupted Power Supply (UPS) ..................................................................................... 28
3.6 Connecting to a PC or Terminal .................................................................................................................... 29
Chapter 4 RAID Configuration Utility Options .................................................... 30
4.1 Configuration through Terminal .................................................................................................................... 30

SATA II RAID Subsystem
User Manual 3
4.2 Configuration through the LCD Panel......................................................................................................... 36
4.2.1 Menu Diagram ............................................................................................................................................. 37
4.3 Configuration through web browser-based proRAID Manager ....................................................... 43
Chapter 5 RAID Management .................................................................................. 45
5.1 Quick Function ...................................................................................................................................................... 45
5.1.1 Quick Create .................................................................................................................................................. 45
5.2 RAID Set Functions .............................................................................................................................................. 47
5.2.1 Create RAID Set ........................................................................................................................................... 47
5.2.2 Delete RAID Set ........................................................................................................................................... 48
5.2.3 Expand RAID Set .......................................................................................................................................... 49
5.2.4 Offline RAID Set ........................................................................................................................................... 51
5.2.5 Rename RAID Set ........................................................................................................................................ 52
5.2.6 Activate Incomplete RAID Set ................................................................................................................ 53
5.2.7 Create Hot Spare ......................................................................................................................................... 55
5.2.8 Delete Hot Spare ......................................................................................................................................... 56
5.2.9 Rescue Raid Set ........................................................................................................................................... 56
5.3 Volume Set Function .......................................................................................................................................... 57
5.3.1 Create Volume Set ...................................................................................................................................... 57
5.3.2 Delete Volume Set ...................................................................................................................................... 60
5.3.3 Modify Volume Set ..................................................................................................................................... 61
5.3.3.1 Volume Set Expansion ...................................................................................................................... 62
5.3.3.2 Volume Set Migration ...................................................................................................................... 63
5.3.4 Check Volume Set ....................................................................................................................................... 64
5.3.5 Schedule Volume Check ........................................................................................................................... 66
5.3.6 Stop Volume Check .................................................................................................................................... 67
5.4 Physical Drive ......................................................................................................................................................... 68
5.4.1 Create Pass-Through Disk ....................................................................................................................... 68
5.4.2 Modify a Pass-Through Disk .................................................................................................................. 69
5.4.3 Delete Pass-Through Disk ....................................................................................................................... 70
5.4.4 Identify Enclosure ........................................................................................................................................ 71
5.4.5 Identify Selected Drive .............................................................................................................................. 72
5.5 System Controls .................................................................................................................................................... 73
5.5.1 System Configuration ................................................................................................................................ 73
5.5.2 HDD Power Management ........................................................................................................................ 75
5.5.3 U320 SCSI Target Config ......................................................................................................................... 77
5.5.4 EtherNet Configuration ............................................................................................................................. 78
5.5.5 Alert By Mail Configuration .................................................................................................................... 79
5.5.6 SNMP Configuration .................................................................................................................................. 80
5.5.7 NTP Configuration ...................................................................................................................................... 81

SATA II RAID Subsystem
4 User Manual
5.5.8 View Events / Mute Beeper .................................................................................................................... 82
5.5.9 Generate Test Event ................................................................................................................................... 83
5.5.10 Clear Event Buffer ..................................................................................................................................... 84
5.5.11 Modify Password ....................................................................................................................................... 85
5.5.12 Upgrade Firmware .................................................................................................................................... 85
5.5.13 Shutdown Controller ............................................................................................................................... 86
5.5.14 Restart Controller ...................................................................................................................................... 87
5.6 Information Menu ................................................................................................................................................ 88
5.6.1 RAID Set Hierarchy ..................................................................................................................................... 88
5.6.2 System Information .................................................................................................................................... 90
5.6.3 Hardware Monitor ....................................................................................................................................... 91
Chapter 6 Maintenance ............................................................................................. 92
6.1 Upgrading the RAID Controller’s Cache Memory .................................................................................. 92
6.1.1 Replacing the Memory Module ............................................................................................................ 92
6.2 Upgrading the RAID Controller’s Firmware .............................................................................................. 93

SATA II RAID Subsystem
User Manual 5
Preface
About this manual
This manual provides information regarding the hardware features, installation and
configuration of the RAID subsystem. This document also describes how to use the
storage management software. Information contained in the manual has been
reviewed for accuracy, but not for product warranty because of the various
environment/OS/settings. Information and specifications will be changed without
further notice.
This manual uses section numbering for every topic being discussed for easy and
convenient way of finding information in accordance with the user’s needs. The
following icons are being used for some details and information to be considered in
going through with this manual:
Copyright
No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photocopying,
recording or otherwise, without the prior written consent.
Trademarks
All products and trade names used in this document are trademarks or registered
trademarks of their respective owners.
Changes
The material in this document is for information only and is subject to change without
notice.
IMPORTANT!
These are the important information that the user must
remember.
WARNING!
These are the warnings that the user must follow to avoid
unnecessary errors and bodily injury during hardware and
software operation of the subsystem.
CAUTION:
These are the cautions that user must be aware of to
prevent damage to the subsystem and/or its components.
NOTES:
These are notes that contain useful information and tips
that the user must give attention to in going through with
the subsystem operation.

SATA II RAID Subsystem
6 User Manual
Before You Begin
Before going through with this manual, you should read and focus on the following
safety guidelines. Notes about the subsystem’s controller configuration and the
product packaging and delivery are also included here.
Safety Guidelines
To provide reasonable protection against any harm on the part of the user and to
obtain maximum performance, user is advised to be aware of the following safety
guidelines particularly in handling hardware components:
Upon receiving of the product:
Place the product in its proper location.
Do not try to lift it by yourself alone. Two or more persons are needed to remove
or lift the product to its packaging. To avoid unnecessary dropping out, make
sure that somebody is around for immediate assistance.
It should be handled with care to avoid dropping that may cause damage to the
product. Always use the correct lifting procedures.
Upon installing of the product:
Ambient temperature is very important for the installation site. It must not
exceed 30◦C. Due to seasonal climate changes; regulate the installation site
temperature making it not to exceed the allowed ambient temperature.
Before plugging-in any power cords, cables and connectors, make sure that the
power switches are turned off. Disconnect first any power connection if the power
supply module is being removed from the enclosure.
Outlets must be accessible to the equipment.
All external connections should be made using shielded cables and as much as
possible should not be performed by bare hand. Using anti-static hand gloves is
recommended.
In installing each component, secure all the mounting screws and locks. Make
sure that all screws are fully tightened. Follow correctly all the listed procedures
in this manual for reliable performance.
Controller Configurations
This RAID subsystem supports both single controller configurations. The single
controller can be configured depending on the user’s requirements.
This manual will discuss single controller configuration.
Packaging, Shipment and Delivery
Before removing the subsystem from the shipping carton, you should visually
inspect the physical condition of the shipping carton.
Unpack and verify that the contents of the shipping carton are complete and in
good condition.
Exterior damage to the shipping carton may indicate that the contents of the
carton are damaged.
If any damage is found, do not remove the components; contact the dealer where
you purchased the subsystem for further instructions.

SATA II RAID Subsystem
User Manual 7
Unpacking the Shipping Carton
The shipping package contains the following:
NOTE: If any damage is found, contact the dealer or vendor for
assistance.
RAID Subsystem Unit
Three (3) power cords
Two (2) external SCSI cables
One (1) RJ45 Ethernet cable
One (1) external null modem cable
One (1) external UPS cable
Two (2) Active LVD/SE terminators
User Manual

SATA II RAID Subsystem
8 User Manual
Chapter 1 Product Introduction
The RAID Subsystem
Highest Density Available
3U chassis with 16 bays carriers.
Extraordinary fault tolerance
Advanced Guarding technology (RAID ADG) provides the highest level of data
protection.
Extraordinary performance
Serial ATA: The Next Generation Internal Storage Interconnect.
Better connectivity, higher data transfer rates.

SATA II RAID Subsystem
User Manual 9
Features
Supports RAID levels 0, 1, 10, 3, 5, 6, and JBOD
Supports hot spare and automatic hot rebuild.
Allows online capacity expansion within the enclosure.
Local audible event notification alarm.
Supports password protection and UPS connection.
Built-in serial port interface for remote event notification.
Dual host channels support clustering technology.
Tagged commend queuing for 256 commands, allows for overlapping data
streams.
Transparent data protection for all popular operating systems.
RAID ADG provides the highest level of data protection.
Supports multiple array enclosure per host connection.
Online RAID level migration.
RAID Management
Smart-function LCD panel.
Environmental monitoring unit.
Real-time drive activity and status indicators.
Browser-based GUI management utility.

SATA II RAID Subsystem
10 User Manual
1.1 Technical Specifications
Form-factor 3U 19-inch rackmount chassis
RAID processor Intel 64 bit RISC
RAID level 0, 1, 10, 3, 5, 6, and JBOD
Cache memory 512MB~4GB
No. of Channels (host+drive) 2 + 16
Host interface Ultra 320 LVD
Drive bus interface SATA II
Data Rate Transfer Up to 320MB/Sec
Backplane board SATA II
Hot-swap drive trays Sixteen (16) 1-inch trays
Hot-swappable power supplies Three (3) 300W power supplies with PFC
Cooling fans 2 (blower)
Battery backup Option
Fibre hub No
R-Link support Yes
SNMP Protocol Support Yes
Background RAID Initialization Yes
S.M.A.R.T. Yes
Array roaming Yes
Power Requirements AC 90V ~ 254V Full Range
12A/6A at 110V/220V, 47Hz ~ 63Hz
Relative Humidity 10% ~ 85% Non-condensing
Operating Temperature 10°C ~ 50°C (50°F ~ 122°F)
Physical Dimension 133(H) x 482 (W) x 609(D) mm
Weight (Without Disk) 20.5kgs / 45.1Lbs
