I-Tech IT6500 Series User manual

Highpowered and Programmable
Switching Power supply
Series IT6500 User’s Manual
Model: IT6512/IT6513/IT6512A/IT6513A/IT6502D
Version No.: 2.1

Notices
© Itech Electronic, Co., Ltd. 2018
No part of this manual may be reproduced
in any form or by any means (including
electronic storage and retrieval or
translation into a foreign language) without
prior permission and written consent from
Itech Electronic, Co., Ltd. as governed by
international copyright laws.
Manual Part Number
IT6500-402006
Revision
Second Edition: July 09, 2018
Itech Electronic, Co., Ltd.
Trademarks
Pentium is U.S. registered trademarks of
Intel Corporation.
Microsoft, Visual Studio, Windows and MS
Windows are registered trademarks of
Microsoft Corporation in the United States
and/or other countries and regions.
Warranty
The materials contained in this
document are provided “as is”, and is
subject to change, without prior notice,
in future editions. Further, to the
maximum extent permitted by
applicable laws, ITECH disclaims all
warrants, either express or implied,
with regard to this manual and any
information contained herein,
including but not limited to the implied
warranties of merchantability and
fitness for a particular purpose.
ITECH shall not be held liable for
errors or for incidental or indirect
damages in connection with the
furnishing, use or application of this
document or of any information
contained herein. Should ITECH and
the user enter into a separate written
agreement with warranty terms
covering the materials in this document
that conflict with these terms, the
warranty terms in the separate
agreement shall prevail.
Technology Licenses
The hardware and/or software described
herein are furnished under a license and
may be used or copied only in accordance
with the terms of such license.
Restricted Rights Legend
Restricted permissions of the U.S.
government. Permissions for software and
technical data which are authorized to the
U.S. Government only include those for
custom provision to end users. ITECH
follows FAR 12.211 (technical data),
12.212 (computer software). DFARS
252.227-7015 (technical data--commercial
products) for national defense and DFARS
227.7202-3 (permissions for commercial
computer software or computer software
documents) while providing the customized
business licenses of software and technical
data.
Safety Notices
A CAUTION sign denotes a
hazard. It calls attention to an
operating procedure or practice
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION sign until the indicated
conditions are fully understood and
met.
A WARNING sign denotes a
hazard. It calls attention to an
operating procedure or practice
that, if not correctly performed or
adhered to, could result in personal
injury or death. Do not proceed
beyond a WARNING sign until the
indicated conditions are fully
understood and met.
NOTE
A NOTE sign denotes important
hint. It calls attention to tips or
supplementary information that is
essential for users to refer to.

IT6500 User’s Manual
i
Quality Certification and Assurance
We certify that IT6500 series power supply meets all the published specifications at
time of shipment from the factory.
Warranty ITECH warrants that the product will be free from defects in material and
workmanship under normal use for a period of one (1) year from the date of delivery
(except those described in the Limitation of Warranty below).
For warranty service or repair, the product must be returned to a service center
designated by ITECH.
The product returned to ITECH for warranty service must be shipped PREPAID.
And ITECH will pay for return of the product to customer.
If the product is returned to ITECH for warranty service from overseas, all the
freights, duties and other taxes shall be on the account of customer.
Limitation of Warranty
This Warranty will be rendered invalid if the product is:
Damaged resulting from customer-wired circuits or customer-supplied parts or
accessories;
Modified or repaired by customer without authorization;
Damaged resulting from customer-wired circuits or use in an environment not
designated by us;
The product model or serial number is altered, deleted, removed or made illegible
by customer;
Damaged as a result of accidents, including but not limited to lightning, moisture,
fire, improper use or negligence.
Safety Symbols
Direct current
ON (power)
Alternating current
OFF (power)
Both direct and alternating
current
Power-on state
Chassis (earth ground) symbol.
Power-off state
Earth (ground) terminal
Reference terminal
Caution
Positive terminal
Warning (refer to this manual for
specific Warning
or Caution
information)
Negative terminal
Achassis terminal
-
-

IT6500 User Manual
Copyright ©ITECH Electronic Co., Ltd.
Safety Precautions
The following safety precautions must be observed during all phases of operation of
this instrument. Failure to comply with these precautions or specific warnings
elsewhere in this manual will constitute a default under safety standards of design,
manufacture and intended use of the instrument. ITECH assumes no liability for the
customer’s failure to comply with these precautions.
Do not use the instrument if it is damaged. Before operation, check the casing
to see whether it cracks. Do not operate the instrument in the presence of
inflammable gasses, vapors or dusts.
The power supply is provided with a three-core power line during delivery
and should be connected to a three-core junction box. Before operation, be
sure that the power supply is well grounded. Make sure to use the power cord
supplied by ITECH.
Check all marks on the instrument before connecting the instrument to
power supply.
Use electric wires of appropriate load. All loading wires should be capable of
bearing maximum short-circuit of electronic load without overheating. If
there are multiple loads, each pair of the load power cord must be carry out
the full rated short-circuit output current of the power securely.
Ensure the voltage fluctuation of mains supply is less than 10% of the
working voltage range in order to reduce risks of fire and electric shock.
Do not install alternative parts on the instrument or perform any
unauthorized modification.
Do not use the instrument if the detachable cover is removed or loosen.
To prevent the possibility of accidental injuries, be sure to use the power
adapter supplied by the manufacturer only.
Never use the instrument with a life-support system or any other equipment
subject to safety requirements.
Failure to use the instrument as directed by the manufacturer may render its
protective features void.
Always clean the casing with a dry cloth. Do not clean the internals.
Make sure the vent hole is always unblocked.
Environmental Conditions
The instrument is designed for indoor use and an area with low condensation. The
table below shows the general environmental requirements for the instrument.
Environmental Conditions
Requirements
Operating temperature
0°C to 40°C
Operating humidity
20%-80% (non-condensation)
Storage temperature
-20°C to 70 °C
Altitude
Operating up to 2,000 meters
Installation category
II
Pollution degree
Pollution degree 2
Note
To make accurate measurements, allow the instrument to warm up for 30 min.

IT6500 User Manual
Copyright ©ITECH Electronic Co., Ltd.
Regulatory Markings
The CE mark indicates that the product
complies with all the relevant European legal
directives. The specific year (if any) affixed
refers to the year when the design was
approved.
The instrument complies with the WEEE
Directive (2002/96/EC) marking requirement.
This affix product label indicates that you
must not discard the electrical/electronic
product in domestic household waste.
This symbol indicates the time period during
which no hazardous or toxic substances are
expected to leak or deteriorate during normal
use. The expected useful life of the product is
10 years. The product can be used safely
during the 10-year Environment Friendly Use
Period (EFUP). Upon expiration of the EFUP,
the product must be immediately recycled.
Waste Electrical and Electronic Equiment (WEEE) Directive
2002/96/EC Waste Electrical and Electronic Equipment (WEEE)
Directive
This product complies with the WEEE Directive (2002/96/EC)
marking requirement. This affix product label indicates that you must
not discard the electrical/electronic product in domestic household
waste.
Product Category
With reference to the equipment classifications described in the
Annex 1 of the WEEE Directive, this instrument is classified as a
“Monitoring and Control Instrument”.
To return this unwanted instrument, contact your nearest ITECH
office.

IT6500 User’s Manual
iv
Compliance Information
Complies with the essential requirements of the following applicable European
Directives, and carries the CE marking accordingly:
Electromagnetic Compatibility (EMC) Directive 2014/30/EU
Low-Voltage Directive (Safety) 2014/35/EU
Conforms with the following product standards:
EMC Standard
IEC 61326-1:2012/ EN 61326-1:2013 ¹²³
Reference Standards
CISPR 11:2009+A1:2010/ EN 55011:2009+A1:2010 (Group 1, Class A)
IEC 61000-4-2:2008/ EN 61000-4-2:2009
IEC 61000-4-3:2006+A1:2007+A2:2010/ EN 61000-4-3:2006+A1:2008+A2:2010
IEC 61000-4-4:2004+A1:2010/ EN 61000-4-4:2004+A1:2010
IEC 61000-4-5:2005/ EN 61000-4-5:2006
IEC 61000-4-6:2008/ EN 61000-4-6:2009
IEC 61000-4-11:2004/ EN 61000-4-11:2004
1. The product is intended for use in non-residential/non-domestic environments. Use of the
product in residential/domestic environments may cause electromagnetic interference.
2. Connection of the instrument to a test object may produce radiations beyond the specified
limit.
3. Use high-performance shielded interface cable to ensure conformity with the EMC standards
listed above.
Safety Standard
IEC 61010-1:2010/ EN 61010-1:2010

IT6500 User Manual
Copyright ©ITECH Electronic Co., Ltd.
Content
Quality Certification and Assurance.................................................................................................................... 1
Warranty.............................................................................................................................................................. 1
Limitation of Warranty........................................................................................................................................ 1
Safety Symbols.................................................................................................................................................... 1
Safety Precautions............................................................................................................................................... 2
Environmental Conditions................................................................................................................................... 2
Regulatory Markings........................................................................................................................................... 3
Waste Electrical and Electronic Equiment (WEEE) Directive............................................................................ 3
Compliance Information................................................................................................................................... 4
Chapter1 Inspection and Installation..................................................................................1
1.1 Verifying the Shipment.................................................................................................................................. 1
1.2 Instrument Size Introduction......................................................................................................................... 1
1.3 Connecting the Power Cord .......................................................................................................................... 3
Chapter2 Quick Start.........................................................................................................5
2.1 Brief Introduction.......................................................................................................................................... 5
2.2 Front Panel Introduction................................................................................................................................ 5
2.3 keyboard introduction.................................................................................................................................... 6
2.4 VFD Indicator Lamps Description................................................................................................................ 7
2.5 Rear Panel Introduction................................................................................................................................. 8
2.6 Power-on selftest........................................................................................................................................... 8
2.7 Output Checkout ......................................................................................................................................... 10
Chapter3 Function and Features.......................................................................................11
3.1 Local/Remote.............................................................................................................................................. 11
3.2 Setting voltage............................................................................................................................................. 11
3.3 Setting current............................................................................................................................................. 12
3.4 On/off button............................................................................................................................................... 12
3.5 Setting value/Actual value........................................................................................................................... 12
3.6 Voltage and current adjustment ................................................................................................................... 12
3.7 Save operation............................................................................................................................................. 13
3.8 Trigger operation......................................................................................................................................... 13
3.9 Menu Operation........................................................................................................................................... 13
3.10 Protection Function ................................................................................................................................... 26
3.11 Rising time and Fall time setup................................................................................................................. 27
3.12 Key Lock Function.................................................................................................................................... 27
3.13 Connection and Setup................................................................................................................................ 27
3.14 Rear terminal functions............................................................................................................................. 29
3.15AnalogueInterface .................................................................................................................................... 30
Chapter4 Remote Control.................................................................................................36
4.1 RS232 Interface........................................................................................................................................... 36
4.2 USB Interface.............................................................................................................................................. 37
4.3 GPIB Interface............................................................................................................................................. 38
4.4 RS485 Interface........................................................................................................................................... 38
Chapter5 Specification .....................................................................................................39
4.1 Main technical parameters........................................................................................................................... 39
4.2 Supplemental characteristics....................................................................................................................... 41

Inspection and Installation
Copyright ©ITECH Electronic Co., Ltd. 1
Chapter1Inspection and Installation
1.1 Verifying the Shipment
Unpack the box and check the contents before operating the instrument. If wrong items
have been delivered, if items are missing, or if there is a defect with the appearance of the
items, contact the dealer from which you purchased the instrument immediately. The
package contents include:
Checklist of Package Contents
Item
Qty.
Model
Remarks
IT6500 power
supply x1 IT6500 series
The IT6500 series include:
IT6512/IT6513/IT6512A/IT6513A/I
T6502D
Power cord x1 IT-E171/IT-E172/
IT-E173/IT-E174
User may select an appropriate
power cord that matches the
specifications of power socket used
in the area. See the Section
Connecting the Power Cord for
details.
USB cable x1 - -
CD x1 -
It contains IT6500 power supply
User’s Manual, Programming Guide
and other user documentations.
Ex-factory Test
Report
x1 -
It is the test report of the instrument
before delivery.
NOTE
Upon verification of the shipment, keep the package and relevant contents thereof in a safe place.
When returning the instrument for warranty service or repair, the specified packing requirements shall
be met. Refer to IT6500 User’s Manual for detailed requirements on returns.
1.2 Instrument Size Introduction
The instrument should be installed at well-ventilated and rational-sized space. Please
select appropriate space for installation based on the power supply size.
IT6500 series power supply different models are not the same size, the detail size of the
power supply are shown as below.

Inspection and Installation
Copyright ©ITECH Electronic Co., Ltd. 2
Detailed Dimension Drawing

Inspection and Installation
Copyright ©ITECH Electronic Co., Ltd. 3
1.3 Connecting the Power Cord
Before connecting the power cord, please ensure the power switch of the instrument is
turned OFF. Only use the power cord supplied as a standard accessory. A summary of
connection procedures is given below.
AC power input level
Support two kinds of AC input voltage:110VAC and 220VAC.There is no need to
switch the input mode.
AC input grade:
Option Opt.01: 220VAC ± 10%, 47 to 63 Hz
Option Opt.02: 110 VAC ± 10%, 47 to 63 Hz
Categories of power cords
IT6500 series power supply provides the standard power cords as below.
Please select appropriate power cords appropriate to local voltage based on the
specifications of power cords below. If purchased model fails to meet local voltage
requirements, please contact distributor or factory for change.

Inspection and Installation
Copyright ©ITECH Electronic Co., Ltd. 4
China
IT-E171
America,
Canada,Japan
IT-E172
Europe
IT-E173
Britain
IT-E174
The power cords supplied with this product is certified for safety. In case the supplied
lines assembly needs to be replaced, or an extension lines must be added, be sure that
it can meet the required power ratings of this product. Any misuse voids the
warranty of this product.
E
N L
E
L N
E
N L
E
L N

Quick Start
Copyright ©ITECH Electronic Co., Ltd. 5
Chapter2Quick Start
This chapter introduces power-on check steps of IT6500D series to ensure normal start-up
and usage under initialization status. This part also introduces the front panel, the rear
panel, key functions and VFD display function of the power supply, make sure that you
can quickly know the appearance, instruction and the key function before you operate the
power supply, Help you make better use of this series of power supply.
2.1 Brief Introduction
IT6500 series is a flexiable range single output high power supply.With wide power
ranges from 800W to 6KW,currents from 30A to 240A.Standard RS232,USB,
GPIB,RS485 and LAN interfaces included on the rear board provide flexibility for remote
operation of the power supply.Its compact 1U(1200W) to 4U(6KW) size form factor
makes it ideal for use in a standard 19-inch rack.IT6500 series is specially designed for
automobile electronic industry.It provides built-in DIN40839 and ISO16750-2 waveforms
to test the anti-jamming performance of products,such as DVD and sound equipment.
Convenient bench-top features:
Auto-Range function
High Resolution Display (1mV/1mA)
Small size of 1U and 2U
RS232/USB/GPIB/RS485 standard interfaces
Analog Control Interface
Master/Slave Mode for Series/Parallel connectivity
Adjustable voltage slope (rise and fall time)
Sequence programming (List mode)
Built-in DIN40839 and ISO16750-2 waveform(IT6512/IT6513 characteristic)
OVP and OPP protection
Low ripple and low noise
Intelligent fans control
Model
Voltage
Current
Power
IT6502D
80V
60A
800W
IT6512
80V
60A
1200W
IT6513
150V
30A
1200W
IT6512A
80V
60A
1200W
IT6513A
150V
30A
1200W
2.2 Front Panel Introduction
IT6500 series power supply different models are not the same front board. the detail front
board and key function schematic graph of the power supply are shown as below.

Quick Start
Copyright ©ITECH Electronic Co., Ltd. 6
2.3 keyboard introduction
IT6500 series power supply different models are same the key function in front board,
schematic graph as follow.
Detailed description of keys:
keys
Name and functions
0-9
Numeric button
Composite key
Menu
OVP setting button,the button used to set the ovp value/menu
function button which used to set the related parameters of
power supply
Slope
Voltage setting button,used to set the ouput voltage value/set the
rising time and fall time of voltage
Pmax
Current setting button,used to set the output current value/set the
maximum power value
Save
Callback button,used to recall a saved setting parameter/save
button,used to save a setting parameter
Local
Meter button,used to switch the display between actual value
and setting value /switch to the loacl mode
Trigger
Confirm button,to confirm the setting numbers or
functions/trigger button,used to provide a trigger single for list
operation
V-setV-set
I-setI-set
Recall
MeterMeter
EnterEnter
①
Power Switch
②VFD Screen
③
pulsating knob to control voltage,coarse
button,fine botton
④
pulsating knob to control current,coarse
button,fine botton
⑤directioin key and key
⑥function keys and composite key
⑦numeric key and key

Quick Start
Copyright ©ITECH Electronic Co., Ltd. 7
keys
Name and functions
Lock
Ouput on/off button,used to control the output status of power
supply/kelock function button,used to lock the front board
buttons
Left and right direction button,used to adjust the location of the
cursor
Up and down direction button,used to select the items of the
menu or increase(decrease) the output voltage and current value
Confirm button
Quit buttion
Dot
2.4 VFD Indicator Lamps Description
As follows:
Flag
Function Description
chart
function description
OFF
Power supply in off mode
Timer
none
CV
Power supply in CV mode
Sense
none
CC
Power supply in CC mode
Ext
none
*
Open the keylock function
Adrs
Displayed for 3s when
remote operation is
connected successfully.
Meter
“Meter” buttion in on mode
Rmt
Remote control mode
Shift
using composite function
Error
Error occur
Rear
Start external analog quantity function
Prot
Protections for OV or
OT
SRQ
Serial request query
Trig
waiting for triggering
signal
On/Off

Quick Start
Copyright ©ITECH Electronic Co., Ltd. 8
2.5 Rear Panel Introduction
IT6500 series power supply different models are not the same rear board. the detail rear
board schematic graph of the power supply are shown as below.
①
remote sense and ouput terminals
②Output terminal
③RS485 communication interface
④Fuses
⑤Analog control interface
⑥Cooling fans
⑦
GPIB communication interface
⑧USB communication interface
⑨RS232 communication interface
⑩AC power input socket
2.6 Power-on selftest
A successful selftest indicates that the purchased power product meets delivery standards
and is available for normal usage.
Before operation, please confirm that you have fully understood the safety instructions.
To avoid burning out, be sure to confirm that power voltage matches with supply
voltage.
Be sure to connect the main power socket to the power outlet of protective grounding.
Do not use terminal board without protective grounding. Before operation, be sure
that the power supply is well grounded.
To avoid burning out, pay attention to marks of positive and negative polarities before
wiring.
Selftest steps Normal selftest procedures:
1. Correctly connect the power cord. Press Power key to start up.
2. After selftest, VFD display the output voltage and current status as below:
Error Information References
The following error information may occur when an error occurs during Power On
self-test:
OFF
0.000V 0.000A
0.0W

Quick Start
Copyright ©ITECH Electronic Co., Ltd. 9
If the EEPROM was damaged, the VFD will display “EEPROM FAILURE”.
If the lastest operation data in EEPROM is lost, then VFD will display “Config Data
Lost”.
If the calibration data in EEPROM is lost, then VFD will display “Calibration Data
Lost”.
If the factory calibration data in EEPROM is lost, and then the VFD will display
“FactoryCal.Data Lost”.
If the system setting data in EEPROM is lost,the VFD will display
“MainframeInitializeLost”.
Exception handling
If the power supply can not start normally, please check and take measures by reference to
steps below.
1. Check whether the power cord is correctly connected and confirm whether the power
supply is powered.
Correct wiring of power cord = > 2
Incorrect wiring of power cord = > Re-connect the power cord and check whether the
exception is removed.
2. Check whether the power in On. Power key is under “ ” On status.
Yes = > 3
No = > Please check the Power key to start power and check whether the exception is
removed.
3. Check whether the fuse of power supply is burned out.
If yes, change fuse. Detailed steps:
1. Use a screwdriver to push and turn the fuse box on the rear board of the power
supply, refer to the below picture. After the fuse box is opened, you can see the
fuse in it. Please replace with a fuse of the same specification.
2. If the fuse is fused, please change fuse of same specification based on machine
model. See the table blow for matching information of fuse and machine model.
Fuse specification list
Model
Fuse Sepcification
(110/220VAC)
IT6512
15A 250V
IT6513
15A 250V
IT6512A
15A 250V
IT6513A
15A 250V
IT6502D
15A 250V
3. When install, use a screwdriver to push and turn the fuse box. Refer to the picture
below.

Quick Start
Copyright ©ITECH Electronic Co., Ltd. 10
2.7 Output Checkout
The following procedures check to ensure that the power supply develops its rated outputs
and properly responds to operation from the front board.
Voltage Output Checkout
The following steps verify basic voltage functions without load.
1. Turn on the power supply
2. Set the ouput current (≥0.1A)
3. Open the ouput
Press on/off button,the CV indicator lamp will be lit.
4. Open the Meter button
5. Set the ouput voltage
Set different voltage and check whether the VFD display voltage is approximate to the
setting voltage.
6. Ensure the output voltage can be adjusted from 0V to full rated value
Output current checkout
The following steps check basic current functions with a short across the power supply’s
output
1. Turn on the power supply.
2. Disable the output
Press key to ensure that the output is disabled.
3. Connect a short across (+) and (-) output terminals with an insulated test lead.
Use a wire size sufficient to handle the maximum current.
4. Enable the output and open the Meter function button
To ensure the CC indicator lamp is lit
5. Adjust the current
Set different current values and check whether the voltage display is approximate to
0V,the display current value is approximate to the setting value
6. Ensure that the current can be adjusted from zero to the full rated value.
7. Turn off the power supply and remove the short wire from the output terminals.
The wires with closure discharge over 10 A should be used.
On/Off

Function and Features
Copyright ©ITECH Electronic Co., Ltd. 11
Chapter3Function and Features
This chapter describes in detail the use of the front-panel keys and shows how they are
used to accomplish power supply operation.
This chapter is divided into the following sections:
Local mode/Remote mode
Setting voltage
Setting current
On/off
Actual value display/setting value dislay
Adjustment of current/voltage/power
Save operation
Trigger operation
Menu operation
Protection function
Setting rising time and fall time of voltage
Keylock function
Functions of rear terminals
Anolog interfaces
3.1 Local/Remote
You can switch from remote mode to local mode by press + buttons.
When you turn on the unit,it will default in local mode and all buttons are available.That’s
to say,in remote mode,the front board buttons can not be used.The two operating mode can
be switched through PC.When the operating mode is changed,all the output parameters
will not be effected.
3.2 Setting voltage
The constant voltage range is from 0V to the maximum voltage value. It is very easy for
you to set the constant voltage output. You have 3 solutions to set the constant voltage
value.And when you press ,this button will be lit.
directly input through number keys
Input the value you want to set and then please press or button to
confirm.
using knob to set value
Press button
Press button(coarse adjustment,change the value in integer bit) or
button(fine adjustment,change the value in decimal bit),and then rotate the
knob to set the value
using left and right direction key to set value
V-setV-set
V-setV-set

Function and Features
Copyright ©ITECH Electronic Co., Ltd. 12
Press button
Press button(coarse adjustment,change the value in integer bit) or
button(fine adjustment,change the value in decimal bit),and then through left
and right keys to adjust the cursor location,press ▲and ▼ to set the voltage value
3.3 Setting current
The constant current range is from 0A to the maximum current value. It is very easy for
you to set the constant current output. You have 3 solutions to set the constant current
value.And when you press ,this button will be lit.
directly input through number keys
Input the value you want to set and then please press or button to
confirm.
using knob to set value
Press button
Press button (coarse adjustment,change the value in integer bit) or
button(fine adjustment,change the value in decimal bit),and then rotate the
knob to set the value
using left and right direction key to set value
Press button
Press button (coarse adjustment,change the value in integer bit) or
button(fine adjustment,change the value in decimal bit),and then through left
and right keys to adjust the cursor location,press ▲and ▼ to set the current value
3.4 On/off button
button is used to control the output state of power supply. If button
is lit,this represents output is open.And in on mode,the indicator lamp(CC/CV) will be lit.
Note:please ensure that the DC source and product under test have been connected well
before you press button.
NOTE
Make sure you have connected power supply and the test unit well, then press button. If
there is no voltage output, you should first check the voltage and current set.
3.5 Setting value/Actual value
button is used to switch the display between actual value and setting
value.When button is lit,this represents that VFD board display is actual
value.Reversely,if button is dark,VFD board display is corresponding to setting
value.
3.6 Voltage and current adjustment
Power supply’s output voltage and Electronic load’s resistance determine the output
V-setV-set
I-setI-set
I-setI-set
I-setI-set
On/Off
On/Off
On/Off
On/Off
MeterMeter
MeterMeter
MeterMeter

Function and Features
Copyright ©ITECH Electronic Co., Ltd. 13
current.Only when the actual current value is lower than the setting current value,can the
power supply works in CV mode.And the CV indicator lamp will be lit.
If the actual current value is limited by the setting current value or rated current,then
IT6512 will change to CC mode.And the CC indicator lamp will be lit.
3.7 Save operation
IT6512 can enable you to save some often used parameters in nonvolatile memory up to
100sets.So that you can recall the parameters quickly.The following ways can help you
achieve the save and recall operations:by pressing composite button +
(Save) button or through command *SAV,*RCL.Save operation should work in with
GROUP.Each GROUP can save 10sets,IT6512 includes 10 GROUP from 0-9.
Save parameters include setting voltage and setting current
Save method:
Using composite button ++number keys 1…9,and then pressing
button to save the preset value into specified memory region.
Using button +number keys 1-9,and then pressing button to recall the
saved parameters from specified memory region.
3.8 Trigger operation
Please select the trigger mode in the menu setup before you start a trigger operation.
Before you want to run a list sequence file,please provide a trigger signal by press
composited button +(trigger).During the list file running,the button
(trigger) will be alight.
3.9 Menu Operation
Press + (Menu) to enter the menu function.View the meun in VFD,and use
right and left direction key or knob to scroll through the complete menu list as following.If
press button,you could get the selected menu function.Press back to the
previous menu selection page.
Menu of IT6512 and IT6513
SYSTEM
SYSTEM MENU
System menu
Initialize
Initialize the system
Power On
POWER-ON
PARAMENT
Set power on parameters
Rst(Def)
Restore to factory defaults
Sav0
Remain last shutdown parameters
Trigger
TRIGGER SOURCE
Set the trigger mode
Manual(Def)
Manual trigger
Bus
Bus trigger
Memory MEMORY
Work with recall button to recall 100sets saved
parameters
Recall
Recall
Enter
Recall
Enter
Enter
Enter
Enter
