- 3 -
14 Place the optical drive in the rack.
Fasten the four side screws.
15 Slide the optical drive into the chassis. 16 Open the drive door. Check the
alignment of the eject button with the eject
mechanism.
17 Press the eject button to check. If
poorly aligned, adjust the control rod to
suit.
18 Plug the optical drive and power cable
into the optical drive. Refasten screws. 19 Place the HDD in the rack and secure
with screws from the side. Repeat as
appropriate.
20 Place the rack back in the chassis.
Refasten screws. 21 Connect the IDE/Serial ATA cable and
power connector to the HDD. 22 Install expansion card. Unscrew the
back panel expansion slot bracket.
23 Lift and remove the PEG/PCI back
panel bracket and put the bracket aside. 24 Install expansion card and secure
bracket. 25 If applicable connect the 4 pin power
connector to the PCI Express Graphics card.
26 Close the cover. 27 Refasten the screws. 28 iameco Eco XPc in Ash, Beech, Sapele,
or aluminum housing.
Copyright © 2007
iameco accepts no liability for any loss or damage howsoever arising as a result of use or reliance on this guide.
