IBA ibaBM-SLM User manual

ibaBM-SLM
Monitor for Siemens Simolink Bus
Manual
Issue 2.0

Manufacturer
iba AG
Koenigswarterstr. 44
90762 Fuerth
Germany
Contacts
Main office [phone]
Fax [phone]
Support [phone]
Engineering [phone]
E-Mail: [email protected]
Web: www.iba-ag.com
This manual must not be circulated or copied, or its contents utilized and disseminated,
without our express written permission. Any breach or infringement of this provision will
result in liability for damages.
©iba AG 2011, All Rights Reserved
The content of this publication has been checked for compliance with the described
hardware and software. Nevertheless, deviations cannot be excluded completely,
therefore full compliance is not guaranteed. However, the information in this publication
is updated regularly. Required corrections are contained in the following regulations or
can be downloaded on the Internet.
The current version is available for download on our web site http://www.iba-ag.com.
Protection note
Windows® is a label and registered trademark of the Microsoft Corporation. Other pro-
duct and company names mentioned in this manual can be labels or registered trade-
marks of the corresponding owners.
Certification
The device is certified according to the European standards and directives. This device
corresponds to the general safety and health requirements. Further international cu-
stomary standards and directives have been observed.
Issue Date Revision Chapter Author Version
HW / FW
2 Issue 2.0

ibaBM-SLM Manual
Issue 2.0 3
Table of contents
1About this manual.............................................................................................5
1.1 Target group...................................................................................................... 5
1.2 Notations........................................................................................................... 5
1.3 Used symbols ................................................................................................... 6
2Scope of delivery ..............................................................................................7
3System requirements iba system ....................................................................7
3.1 Hardware .......................................................................................................... 7
3.2 Software ............................................................................................................ 7
4Supported Siemens Drive and Automation Systems.....................................7
5Further Manuals ................................................................................................7
6Product description ..........................................................................................8
6.1 Application ........................................................................................................ 8
6.2 Advantages ....................................................................................................... 8
6.3 ibaBM-SLM ....................................................................................................... 9
6.3.1 Properties.......................................................................................................... 9
6.3.2 Data types ......................................................................................................... 9
6.3.3 Overview device configuration ........................................................................ 10
7Device Design ................................................................................................. 11
7.1 Base Circuit Board .......................................................................................... 11
7.2 SIMOLINK Board (SLB Module) ..................................................................... 11
7.3 Device view, Connections and Displays.......................................................... 12
7.3.1 Device views ................................................................................................... 12
7.4 Status Display ................................................................................................. 13
7.5 24 V DC Power Supply (X14).......................................................................... 13
7.6 Fiber Optic connections (X32, X33) for ibaNet................................................ 13
7.7 Notebook connections (X30, X31) .................................................................. 13
7.8 Status LEDs SIMOLINK bus ........................................................................... 13
7.9 Power Supply Connectors for SIMOLINK Bus (X15) ...................................... 14
7.10 Fiber-Optic Interface to the SIMOLINK Bus (X34, X35).................................. 14
7.11 Interface for loading of the ibaPDA parameters sets....................................... 14
8ibaBM-SLM functionality on the Simolink Bus.............................................15
8.1 Bus Topology................................................................................................... 15
8.2 Simolink Bus Characteristics:.......................................................................... 15
8.3 Topology example ibaBM-SLM with ibaPDA-V6 ............................................. 16

Manual ibaBM-SLM
4 Issue 2.0
9Mounting and dismounting............................................................................ 17
9.1 Mounting and connecting................................................................................ 17
9.2 Dismounting .................................................................................................... 17
10 Initial operation............................................................................................... 18
10.1 Basic Steps ..................................................................................................... 18
10.2 Configuration in ibaPDA.................................................................................. 18
10.2.1 Hardware Configuration .................................................................................. 18
10.2.2 Reference to simulated parameters (simulation mode) .................................. 23
11 Working with SIMOLINK signals in ibaPDA.................................................. 24
11.1 Analog signal grid ........................................................................................... 24
12 Technical Data and Environmental Conditions ............................................ 25
12.1 Dimension sheet ............................................................................................. 26
13 Support and contact....................................................................................... 27

ibaBM-SLM Manual
Issue 2.0 5
1 About this manual
This manual describes the construction, use and operation of the device
ibaBM-SLM.
1.1 Target group
This manual addresses in particular the qualified professionals who are familiar with
handling electrical and electronic modules as well as communication and measurement
technology. A person is regarded as professional if he/she is capable of assessing
safety and recognizing possible consequences and risks on the basis of his/her special
training, knowledge and experience and knowledge of the standard regulations.
1.2 Notations
The following designations are used in this manual:
Action Notations
Menu command Menu „Logic diagram“
Call of menu command „Step 1 – Step 2 – Step 3 – Step x”
Example:
Select menu „Logic diagram – Add – New logic
diagram”
Keys <Key name>
Example: <Alt>; <F1>
Press keys simultaneously <Key name> + <Key name>
Example:
<Alt> + <Ctrl>
Buttons <Button name>
Example:
<OK>; <Cancel>
File names, Paths „File name“, „Path”
Example:
„Test.doc“

Manual ibaBM-SLM
6 Issue 2.0
1.3 Used symbols
If safety instructions or other notes are used in this manual, they mean:
The non-observance of this safety information may result in an imminent risk of death o
r
severe injury:
By an electric shock!
Due to the improper handling of software products which are coupled to input and
output procedures with control function!
The non-observance of this safety information may result in a potential risk of death or
severe injury!
The non-observance of this safety information may result in a potential risk of injury or
material damage!
Note
A note specifies special requirements or actions to be observed.
Important note
Note if some special features must be observed, for example exceptions from the rule.
Tip
Tip or example as a helpful note or insider tip to make the work a little bit easier.
Other documentation
Reference to additional documentation or further reading.

ibaBM-SLM Manual
2 Scope of delivery
After unpacking check the completeness and intactness of the delivery.
The scope of delivery includes:
Device with 2-pole Phoenix screw terminal
Documentation for the device (iba)
SLB SIMOLINK Board Documentation (Siemens) as well as extended information
to this document
SIMOLINK fiber-optic cable with 2 SC connectors and an auxiliary power connector
for buffering the SIMOLINK SLB module power
Additional equipment, that is not included in the scope of delivery,
see www.iba-ag.com.
3 System requirements iba system
3.1 Hardware
IBM-compatible PC with an ibaFOB-D card
ibaNet FO cable
or
Notebook computer with ibaPCMCIA-F card
spiral cable
3.2 Software
ibaPDA-V6 for capturing and recording
ibaAnalyzer for analyzing
4 Supported Siemens Drive and Automation Systems
SIMOVERT Masterdrive MC
SIMOREG 6RA70 (DC Drive)
S7-400 FM: FM458 SIMOLINK Master (SIMADYN D)
SIMADYN D
M7 Motion Control System
5 Further Manuals
ibaPDA-V6 manual
ibaAnalyzer manual
System and communication configuration D7-SYS - SIMADYN D
Operating instructions SLB SIMOLINK Board
D7-SYS „Hardware“ manual
„STEP 7“ Hardware configuration manual
Issue 2.0 7

Manual ibaBM-SLM
6 Product description
6.1 Application
The ibaBM-SLM device can be used to capture data from one or more frequency con-
verters of the SIMOVERT masterdrive series. The SIMOLINK Board (SLB) is integrated
in the SIMOVERT Masterdrive in order to guarantee the communication via the
SIMOLINK bus. The same board is inserted n the ibaBM-SLM device and hence en-
ables the connection of the device to a SIMOLINK system.
The SIMOLINK board is a participant within the SIMOLINK ring. In a closed ring all par-
ticipants work with the same system cycle.
The SIMOLINK board reads all telegrams on the SIMOLINK and saves the selected te-
legrams in a reception memory.
ibaBM-SLM was developed to capture and analyze the data of the SIMOVERT Master-
drives with an iba system. The central parts of the device are the iba technology and
the integrated SIMOLINK board (SLB).
For further information refer to Operating instructions SLB SIMOLINK Board
The goals of the ibaBM-SLM diagnostic unit are
Fast identification of errors from frequency converters (drives)
Quantification of drive regulator tuning and estimation of motor condition from volt-
age/current signals
Motor control optimization
Applications for the ibaBM-SLM are foreseen for the following purposes.
Permanent interface to an ibaPDA data acquisition system in a SIMOLINK topology
Intermediate use for troubleshooting and commissioning purposes
Short-term interface via a portable PC or notebook PC (if necessary, also as an ad-
dition to a fixed installation).
6.2 Advantages
The ibaPDA software is optimized for large-scale process monitoring. Up to 2048 ana-
log and binary signals can be visualized and recorded synchronously. Specifically for
the ibaBM-SLM Simolink Monitor, the ibaPDA software has been extended to support
sample resolutions in steps of 100 sec. This provides for bus update cycle matching
integer multiples of the Simolink bus cycle rate (min. 1.6 milliseconds per cycle). Set-
tings from 1.6 ms in steps of 100 µs are also possible (e.g. bus cycle time of 1.8 ms)
Apart from the ibaBM-SLM, additional I/O interfaces and software components exist for
multiple PLC systems (SIMATIC S5, SIMATIC S7, MMC216, SIMADYN D). ibaPDA
supports these interfaces in parallel. It should be noted, that the number of values must
not exceed the licensed number of signals.
8 Issue 2.0

ibaBM-SLM Manual
6.3 ibaBM-SLM
6.3.1 Properties
Rugged metal housing for DIN rail mounting
1 SIMOLINK bus connection, can be buffered against voltage failure (SIEMENS
SLM module)
SIMOLINK module address of the diagnostic unit is adjustable within ibaPDA
Two uni-directional fiber-optic links (3.3 Mbps) with ST fiber optic connections to
ibaPDA computer
2 wired connections (RS422 on RJ11 socket) for Notebook PC
Transfer of up to 128 analog (INT or DINT) + 128 binary signals. Each fiber-optic or
RS422 connection can transmit 64 Float and 64 binary signals.
Data transfer on fiber-optic links synchronous to SIMOLINK bus cycle
Parallel data transfer on fiber optic link and RS422, whereas only one RS422 inter-
face of an ibaCom-PCMCIA-F card can be used on the notebook side.
Unregulated 24 V DC power supply
Unregulated 24 V DC SIMOLINK buffer supply
Configuration is stored permanently in the device
6.3.2 Data types
The data to be measured from the SIMOLINK bus is defined by using a setup dialog
within ibaPDA. The following data types may be measured.
16 bit integer (INTLOW and INTHIGH: -LOW indicates lower word, -HIGH indicates
upper word of 32-bit data word)
32 bit integer (DINT)
bit; via ibaPDA packed binary input through bit selection from 16-bit status words
Each data type corresponds to a measuring value. Up to 128 analog (INT16; DINT)
and 128 packed binary signals per ibaBM-SLM device can be transmitted to ibaPDA.
Note
Regardless of selected data types, all data are transmitted as 32-bit IEEE floating point
values.
Due to the conversion from 24 bit measuring resolution to 32 bit format, inaccuracy
may occur when using DINT data format.
Issue 2.0 9

Manual ibaBM-SLM
6.3.3 Overview device configuration
The data to be measured are selected in the I/O Manager of ibaPDA-V6. The defini-
tion of the measuring data to be recorded in measuring files is done in the “Configu-
ration - Data storage” menu in ibaPDA-V6. You can define profiles which are avail-
able for several data stores and the number and the names of the data stores.
The configuration defined in ibaPDA is transmitted from the ibaPDA computer to
ibaBM-SLM via the serial interface.
10 Issue 2.0
