iBall Baton iB-W3GX150N User manual

3G+ Wireless-N Router
Model No. iB-W3GX150N
User Manual
Ver.: 1.0.0
1

FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
pro-vide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not in-stalled and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
•Consult the dealer or an experienced radio/ TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including
interference that may cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
2

CE Mark Warning
This is a class B product. In a domestic environment, this product may cause
radio interference, in which case the user may be required to take adequate
measures.
3

Contents
CHAPTER 1. INTRODUCTION .................................................................................. 1
A. HARDWARE INSTALLATION ................................................................................6
B. INSTALLATION STEPS.......................................................................................... 7
CHAPTER 2. CONFIGURING THE ROUTER............................................................ 8
CHAPTER 3. NETWORK SETTING......................................................................... 20
3.2 FORWARDING ................................................................................................... 35
3.3 SECURITY SETTINGS....................................................................................... 38
3.4 ADVANCED SETTINGS ..................................................................................... 44
3.5 SYSTEM TOOLS ................................................................................................ 52
CHAPTER 4.TROUBLESHOOTING....................................................................... 55
APPENDIX A. SPEC SUMMARY TABLE................................................................ 59
APPENDIX B. GLOSSARY.................................................................................. 5960
APPENDIX C. CONTACT INFORMATION .......................................................... 5961
4

Chapter 1 Introduction
iBall Baton 3G+ Wireless-N Router complies with IEEE 802.11 b/g/n wireless standards.
Enhanced 150Mbps wireless transmission speed.
Combo Router
Supports Dual WAN Connection - USB slot for 3G modem and 1 WAN port to connect internet
3G USB modem with 2G/3G+ Network support - EV-DO, HSUPA, HSDPA, WCDMA
SupportsAuto-Failover/ Failback andAuto Load-sharing
Easy Setup Wizard - Utility helps users to configure the router easily.
Package contents
The following contents should be found in the product packaging:
Items Description Contents Quantity
1 3G+ Wireless-N Router with
Antenna (iB-W3GX150N)
1
2 Power adapter
1
3 CD Easy Setup, UM
1
4 QIG Print copy 1
5 Patch Cord RJ45 UTP Patch Cord 1
)Note:
Make sure that the package contains the above items. If any of the listed items are damaged or
missing, please contact with your nearest dealer.
5

A. Hardware Installation
¾Front View
Antenna
Reset Button LAN Port
WLAN LED
WAN LED
USB / Status LED WPS Button
PowerJACK
WANPORT
LANPORT
USBPORT
6

B. Installation Steps
Note: DO NOT connect the router to power before performing the installation steps
below.
a. Locate an optimum location for the router. The best place is usually near the center
of the area in which your PC(s) will wirelessly connect.
b. Adjust the direction of the antenna. Normally, upright is a good direction.
Step 1.
Connect the DSL/Cable Modem/Ethernet to the WAN port or 3G USB Modem on the
router as shown below is the following image.
3G USB Modem Ethernet (WAN)
Step 2.
Insert RJ45 UTP Patch cord one end into the Router LAN Port and another end to the PC LAN
port.
Step 3.
Connect the power adapter one end to the router and other end into an electrical outlet.
Step 4.
Power on your PC and Cable/DSL modem.
Step 5.
7

When all of the devices boot up completely, make sure that the router's LEDs light
ON as per your connection required.
Chapter 2. Configuring the Router
There are two methods for you to set up the 3G+ Wireless-N Router quickly and easily.
Method - I Easy Setup Wizard
Method - II Web Based configuring through browser
Method - I Easy Setup Wizard
Configuring the Router via Easy Setup Wizard (Resource CD)
a. Insert the Resource CD into your CD-ROM device.
b. The Easy Setup Wizard will automatically pop up on the computer’s screen.
Click START button and follow the steps as per easy setup configuration to complete the router
configuration
8

Chapter 2.1
Easy Setup Wizard - (Utility Software)
Step 1：
Run the Easy Setup Wizard
from the provided CD then
follow the steps to configure
the device.
Step 2：
Select Language then click
“Next” to continue.
Step 3：
Then click the “Quick
Wizard” to continue.
9

Step 4：
Click “Next” to continue.
Step 5：
Select Wireless Enable, and
then click “Next” to continue.
Step 6：
Enter SSID, Channel and
Security options, and then
click “Next” to continue.
Default Parameters:
SSID: iBall-Baton
Password: 12345678
10

Step 7：
Click” Let me select WAN
service by myself” to select
WAN service manually.
Step 8：
Select Ethernet WAN
Service by clicking Ethernet
WAN icon to configure
Ethernet WAN Connection.
Step 9 : Select Ethernet
WAN Connection Type by
clicking on proper icon to
continue
11

Step 10 : Select Ethernet /
Wireless WAN Connection
type by clicking on proper
icon to continue
Step 11 : Wireless WAN
Connection Type will display
3G or iBurst menu - Click the
proper menu as per your
ISP settings to continue
Step 12-1：
¾Auto-Detection
In “Auto-Detection” mode
WAN Service will try to
detect and configure the
required 3G service settings
automatically.
Click “Next” to continue.
12

Step 12-2：
¾Manual
In “Manual” WAN Service
you will need to insert the
required 3G service settings
as provided by your ISP.
Click “Next” to continue
Step 13:
Click “Next” to save your
setting.
Step 14:
The 3G+ Wireless-N Router
is rebooted to make your
entire configuration take
effect.
13

Step 15：
Click“Next”toWAN
Networking service.
Step 16：
Click “Next” to test the
Internet connection or you
Can ignore test.
Step 17：
Setup is completed.
14

Method – II Configuring the Router by Web Console
With a Web-based utility, it is easy to configure and manage the iB-W3GX150N
3G+ Wireless-N Router.
The Web-based utility can be used on any Windows, Macintosh or UNIX OS with a Web
browser, such as Microsoft Internet Explorer, Mozilla Firefox or Apple Safari.
Login to the Router
To login to the router, you should set up the TCP/IP Protocol in "Obtain an IP address
automatically" mode on your PC(s).
a. To access the configuration utility, open a web-browser and type in the default address
http://192.168.1.1 in the address field of the browser.
I. After a moment, a login window will appear. Enter admin for the User Name
and Password, both in lower case letters. Then click OK or press Enter.
2.2.1 Configure with the Quick Setup
Default Router Settings
IPAddress: 192.168.1.1
User Name: admin
Password: admin
15

Select “Quick Setup” for
basic settings with simple
way.
Press “Next” to start the
Setup Wizard.
16

Step 1:
Change System
Password.
Set up your system
password.
(Default：admin)
Step 2:
Select Time Zone.
Step 3:
Select WAN Type.
Choose Auto-Detecting or
Manually to set WAN
Type.
17

Step 4:
Select Wan Type.
If you want to use 3G
service as the main
internet access, please
set the WAN interface as
“3G Wireless” and the
WAN type as “3G”.
Step 5:
3G Mode.
Select Auto-Detection
then click “Next” to
continue.
Step 6:
Set up your Wireless
Network.
Set up your SSID.
Step 7:
Setup your Encryption
Key here, then click”Next”
to continue.
18

Step 8:
Apply your Setting.
Then click Apply Setting.
Step 9:
Click Finish to complete it.
19

Chapter 3 Network Setting
The below menu will help you to configure advanced settings in Router menu.
3.1.1. Network Setup
Ethernet LAN Setup
Ethernet WAN Setup
1. LAN IP Address: The local IP address of this device. The computers on your network
must use the LAN IP address of this device as their Default Gateway. You can change it
if necessary.
2. Subnet Mask: Input your Subnet mask. (All devices in the network must have the same
subnet mask.) The default subnet mask is 255.255.255.0.
3. WAN Interface: Select Ethernet WAN or Wireless WAN to continue.
4. WAN Type: WAN connection type of your ISP. You can click WAN Type button to
choose a correct one from the following options:
20
