iBall iB-DHM4414P User manual

DVR User Manual
4-CH Full D1 Hybrid Mini DVR
iB-DHM4414P
8-CH Full D1 Hybrid Mini DVR
iB-DHM8841P
Ver.: 1.0.0

Introduction
Thank you for purchasing iBall Guard DVR.
This manual applies for 2 different DVR models, Kindly check the
product name/model no. of the DVR as you have purchased to refer
the actual product specification.
It will help to refer for installations & configuring your DVR.
Before installing this products please refer the manual carefully and
retain it for future reference.
Safety Warnings
Do not place heavy objects on DVR
Do not let any solid or liquid fall into DVR
Do not install DVR in damp environment
Do not dissemble or repair DVR by yourself.
Please install DVR in ventilated place

Package Contents
The following contents should be found in your package:
1- DVR
1- Power Adapter
1 - User Guide
1- Resource CD, which includes this Software utility
Note:
Make sure that the package contains the above items. If any of the
listed items are damaged or missing, please contact the partner from
whom you have purchased.

4-CH Full D1 Hybrid Mini DVR
Model No.:IB-DHM4414P
Product Features:
H.264 Video Compression Technology with Dual Streaming
4-CH Full D1 Resolution Real-time Recording
1 x 4TB SATA HDD support
4 Audio Input & 1 Audio output
DVR Compatibility:-
DVR :- Analog + AHDL Camera
HVR :- Analog + AHDL + IP Camera
NVR :- IP Camera
Multiplex Operation: Live, Record, Playback, Backup& Remote Access
iBall Cloud Technology - Easy management over Internet
PTZ,Email, Video Blind, Motion Detection, Video Loss & Zoom
Backup & Storage: USB Flash, Portable HDD & Network Backup
Central Management Software
Mobile Surveillance: Android/Symbian/iPhone/Blackberry/Windows

8-CH Full D1 Hybrid Mini DVR
Model No.:iB-DHM8841P
Product Features:
H.264 Video Compression Technology with Dual Streaming
8-CH Full D1 Resolution Real-time Recording
1 x 4TB SATA HDD support
4 Audio Inputs & 1 Output
DVR Compatibility:-
DVR :- Analog + AHDL Camera
HVR :- Analog + AHDL + IP Camera
NVR :- IP Camera
1-HDMI Port for HD display output
Multiplex Operation: Live, Record, Playback, Backup, Remote Access
iBall Cloud Technology - Easy management over Internet
PTZ, Email, Video Blind, Motion Detection, Video Loss & Zoom
Backup & Storage: USB Flash, Portable HDD & Network Backup
Central Management Software
Mobile Surveillance: Android/Symbian/iPhone/Blackberry/Windows

Hardware Installation Steps:
Hard Disk Installation:
For the first use，please install the hard disk in the DVR before switch
on the power.
Note: DVR can run and monitor normally without hard disk, while it
can’t record and playback.
USB Connection:
You can connect USB mouse, Flash disk, Portable HDD or DVR-RW
on the USB port as available on Front or Back side of DVR.
Power ON:
Plug the power supply and turn on the power supply switch.
Power LED shining indicates DVR is turning ON & booting the OS.
After finishing the startup you will hear a beep, and indicates as
default setting of DVR is ready to connect for further operation.
Note: Incase of abnormal power off, Switch ON the power as DVR
will automatically recover the state before power off.
Power OFF:
To turn off the DVR press the Soft switch as available in menu i.e.:
Entering [Main menu] and Click [Logout] in the [turn off the system]

Port Details
Name
Description
Video input
Standard BNC port, Connected with the Camera.
Video output
Connected with the video input of the monitor.
VGA
Video signal output port, connected to VGA port
of a computer monitor.
BNC
BNC video signal output connected to TV
HDMI
Video signal output port, connected to HDMI port of a
TV, Computer monitor.
Audio output
Connected to earphone or cable speaker.
Audio input port
Connected audio input device.
"RS485"(AB)
External alarm
port
Connected to PTZ or decoder, and can Control PTZ
via the panel, mouse, remote control and network
Connected with alarm input and output.
USB
Connected to USB Pendrive or mouse and used for system
software upgrade or video file backup.
NET
RJ-45 network port, connected to network cable
and used for remote browse or control.
Power
Power input is DC 12V/2A or 4A (8/16 channel DVR)

Login
When the DVR boots up, below is the screen as appearing confirming
the OS is loading for startup
Kindly wait till the Login Menu screen appears
User must login as entering the Default User Name & Password.
There are 2 login user settings
> User Name: admin | Password: 900009
> Guest: no password
“admin” login is super user as “guest” login is only for preview.

Picture-1 Login
Password protection
If the password is continuous wrong 3 times, the beep will appear.
If the password is continuous wrong 5 times, the account will be
locked.
Password unlock: Just reboot the DVR or wait for max. 30 mins, the
account will be unlocked automatically).
Note: For security reason, kindly modify your password after first
login.
Preview
Login normally and choose the multi-menu preview status. The
system date, time and channel name are shown in each viewing
window. The surveillance video and the alarm status are shown in
each window.
1
Recording status
3
Video loss
2
Motion detect
4
Camera lock

Desktop Shortcut Menu
In preview menu you can right click to get desktop shortcut menu
Main Menu
As you click the Main menu icon from shortcut menu below
image will appear
Recording Setting

Set the recording parameters in the surveillance channel.
You can enter [Main Menu]> [Record]> [Record Config] to set.
The system’s default set is 24 hours continuous recording.
Note: There is at least 1 read-write hard disk if the DVR records
normally.
Picture - 2 Record Config
【Channel】Choose the corresponding channel number to set the
channel. Choose the “all” option to set the entire channels.
【Redundancy】Choose the recording file and backup in two hard
disks. The one is read-write disk, another is redundant disk.
【Length】Set the time length of each video file. 60minutes is
default length.
【Prerecord】Record 1-30 seconds before the action. (File length is
decided by the code stream)
【Record Mode】Set videostate:configuration,manualandstop.
Schedule: Record according to the set video type (regular, detect and
alarm) and time section.
Manual: Click the “all” button and make the corresponding channel
recording no matter it is in any state.
Stop: Click the “stop” button and make the according channel stop
recording no matter it is in any state.
【Period】Set the time section of common recording, The recording

will start only in the set range.
【Recording Type】Set recording type: regular, detection or alarm.
Regular: Perform the regular recording in the set time section. The
video file type is “R”.
Detect：Trigger the “motion detect”, “camera mask” or “video loss”
signal. When above alarm is set as opening recording, the “detection
recording” state is on. The video file type is “M”.
Alarm output：Trigger the external alarm signal in the set time
section, when above alarm is set as opening recording, the “detection
recording” state is on. The video file type is “A”.
Alarminput:
When the equipment obtains the external alarm signal, the alarm
function is turned on.

Snapshot Storage: (Selected models support the feature)
Setup snapshot parameters for different channels. At first time its set
for 24hours snapshot continuously, pls go to Main
Menu->Record->Snapshot Storage for appropriate settings.
Note: If normal snapshot storage, pls setup Snap at Main
Menu->Advanced->HDD Manage->Snapshot.
Picture- 3 Snapshot Storage
Video Playback
There are 2 methods for you to play the video files in the hard disk.
1. in the desktop shortcut menu.
2. Main Menu>Record>Playback.
Note: The hard disk that saves the video files must be set as read-write or
read-only state .

Picture - 4 Video Playback
1. Playback control
2. Operating Tips
3. Record type
4. Time progress bar options

5. Switching time or file mode
6. File Search 7.Channel option 8.Date option 9.Storage Device
option 10.File information 11.File Option 12.Time
【File information】Start time, end time and size.
【File option】Choose the file to playback/backup.
【Playback control】Refer to the following sheet for more
information.
Table2 Playback control key
Note: Frame by frame playback is only performed in the "pause"
playback state.

Network Setup
Picture-5 Network Setup
Doing network setup through Main Menu > System > Network
【IP address】Set the IP address. Default: 192.168.1.200
【Subnet Mask】Set the subnet mask code: Default: 255.255.255.0
【Gateway】Set the default gateway. Default: 192.168.1.1
【TCP Port】Default media port : 9999
【HTTP Port】Default port : 80

Motion Detection
Picture-6 Motion Detection
Motion detection setup: Set DVR equipment making it alarm, linkage
record and make the PTZ turn to preset position when there is a
moving object in designated areas during Monday to Friday.
Step1. Choose【Main Menu】>【Alarm】>【Motion Detect】， then
enter the setup interface
Step2. Choose one channel and adjust sensitivity level, then set the
time period of alarm surveillance. Set the monitor area (click the
“set” button, choose the areas you want, and the “default” means
choose all areas, then right click to choose "up window".
Step3. When at alarm state, the DVR can take linkage measures.
Alarm output, recording, tour, PTZ activation, snapshot, show
message, sending email and buzzer
Step4. Set other channels alarm parameter following step 2 & 3
Note: video block, video loss and alarm input’s setup method are
similar with motion detection.

PTZ Control
Follow the below steps for easy PTZ operations
Step1. Set basic parameter such as channel and protocol.
【Main Menu】>【System】>【PTZ Config】
Step2. At the state of menu preview, enter the PTZ operation menu.
Step3.One is "right click" mouse; choose the “PTZ control” and
doing the PTZ general operation. The other method is "right click"
mouse; choose “High Speed PTZ”. Control the left button and move
it to control the PTZ direction directly. Use the mouse wheel to zoom
in/out the controlled camera.

Remote Monitoring
After connecting the network, 2 kinds of methods can be used for
remote monitoring which are client software and common browser.
Client software
Client software (CMS) is professional software used in
multi-equipments monitoring, which is safe, convenient and stable.
CMS software is used in a computer, and manipulates several DVR at
the same time.
Step1. Please open the CD utility as provided in package & copy
CMS installed software in it.
Step2.After installing this software at the local PC, then open the
operation system as in picture 6, Enter the add device interface
through【System】>【Device Manager】>【Add area/device】, and
enter DVR information which is needed manipulating following the
prompts, in that way, you can manipulate any specified equipment..
Step3. You can add several DVR more to do monitor operation if you
repeat this operation.
Picture-7 CMS Interface

Web Based Login:
Suggested to use Internet Explore for Login the DVR menu
Step1.
Install the browser plugin General_IE_V2.0.0.35_20111222.exe in
case login page not able to access.
Step2.
Open web browser, then enter IP address on the browser address bar
http://192.168.1.200 to login
Note: when first login, below login image will appear
Picture-8 Web Login Interface
Step3. Login. Enter user’s name and password, the default Administrator User
ID is admin, and the password is 900009. The user should change the
administrator’s password timely after logging in. (If you choose "LAN ”, it’s
Mainstreams,if"WAN”, it’s Substreams.)
You will see as follows interface after logging in.
