Vista QNVR User manual

Installation and User manual
QNVR
Quantum IP Network Video Recorder

2
QNVR Installation Manual V1.1
QNVR installation and user manual

3
QNVR Installation Manual V1.1
QNVR installation and user manual
CE Information
The product must be installed according to the currently valid installation regulat
ions for EMC to guarantee the designed use and to prevent EMC problems.
The device supplied with this manual meets the requirements of the following E
C Directives: EMC: 2004/108/EC, LVD : 2006/95/EC and RoHS: 2011/65/EU
Safety Precautions
1. Apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, such as vases, shall be placed on the apparatus.
2. WARNING –TO PREVENT FIRE OR SHOCK HAZARD DO NOT EXPOSE THE
SET TO RAIN OR MOISTURE.
3. "IMPORTANT SAFETY INSTRUCTIONS"
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with a dry cloth.
7) Do not block any of the ventilation openings. Install in accordance with the
manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding type plug.
A polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. When the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
WARNING
This is a Class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.

4
QNVR Installation Manual V1.1
QNVR installation and user manual
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use the attachments/accessories specified by the manufacturer.
12) Use only with a cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart
is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods
of time.
14) Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
15) the apparatus shall not be exposed to dripping or splashing and that no
objects filled with liquids, such as vases, shall be placed on the apparatus.
16) Shall be connected to a MAINS socket outlet with a protective earthing
connection.
17) the disconnect device shall remain readily operable.
18) The socket-outlet shall be installed near the equipment and shall be easily
accessible.
4. Explanation of Safety Related Symbols
WARNING
Hazardous moving parts
Keep away from moving fan blades

5
QNVR Installation Manual V1.1
QNVR installation and user manual
Contents
OVERVIEW........................................................................................................................... 7
1. CONTENTS OF PACKING.................................................................................................... 7
2. FEATURES ....................................................................................................................... 8
INSTALLATION .................................................................................................................... 9
1. FRONT PANEL CONTROLS................................................................................................. 9
2. REAR PANEL CONNECTORS .............................................................................................10
3. REMOTE CONTROL..........................................................................................................13
4. CONNECTION GUIDE........................................................................................................14
5. TURNING ON THE NVR ....................................................................................................16
OPERATION........................................................................................................................17
1. NAVIGATION....................................................................................................................17
1-1. Mouse Control........................................................................................................................................ 17
1-2. Menu Navigation .................................................................................................................................... 17
2. SCREEN DISPLAYS ..........................................................................................................18
2-1. OSD Description..................................................................................................................................... 18
2-2. Select Channel....................................................................................................................................... 18
2-3. Digital Zoom........................................................................................................................................... 19
3. PLAYBACK ......................................................................................................................20
3-1. OSD Description..................................................................................................................................... 20
3-2. Playback Control.................................................................................................................................... 21
3-3. Playback Search .................................................................................................................................... 22
4. PTZ CONTROL VIA RS485...............................................................................................23
4-1. PTZ Control by mouse............................................................................................................................ 23
4-2. PTZ Control by remote keyboard ........................................................................................................... 25
4-3. PTZ Control by remote controller ........................................................................................................... 25
4-4. PTZ Control by Client software............................................................................................................... 25
SETUP MENU......................................................................................................................26
1. DISPLAY .........................................................................................................................26
1-1. OSD Setting ........................................................................................................................................... 26
1-2. Live Setting............................................................................................................................................. 28
1-3. Camera Covert....................................................................................................................................... 28
1-4. Camera Name........................................................................................................................................ 29
2. IPCAMERA SET UP,FOR LIVE VIEWING AND RECORDING.....................................................30
2.1 Camera Discovery and Connection......................................................................................................... 31
2.2 Constant record setup ............................................................................................................................. 32
2.3 Event Boost record setup ........................................................................................................................ 32
2.4 Stream Switching record setup................................................................................................................ 33
2-5. IP CAMERA menu overview................................................................................................................... 34
2-6. Normal (Time Lapse).............................................................................................................................. 35
2-7. Alarm...................................................................................................................................................... 36
2-8. Motion..................................................................................................................................................... 37
2-9. Schedule ................................................................................................................................................ 39
3. SYSTEM..........................................................................................................................41
3-1. Basic....................................................................................................................................................... 41
3-2. Disk ........................................................................................................................................................ 43
3-3. Account................................................................................................................................................... 44
3-4. Program Update..................................................................................................................................... 45
3-5. PTZ Setup.............................................................................................................................................. 46
3-6. More....................................................................................................................................................... 46
4. NETWORK.......................................................................................................................47
4-1. Basic....................................................................................................................................................... 47

6
QNVR Installation Manual V1.1
QNVR installation and user manual
4-2. NTP........................................................................................................................................................ 48
5. EVENT............................................................................................................................48
5-1. E-Mail Registration................................................................................................................................. 49
5-2. E-mail Out .............................................................................................................................................. 50
5-3. Beep Out................................................................................................................................................ 50
5-4. Alarm Out ............................................................................................................................................... 51
SEARCH MENU...................................................................................................................51
1. SEARCHING RECORDED DATA..........................................................................................52
1-1. Date/Time Search................................................................................................................................... 52
1-2. Event Search.......................................................................................................................................... 52
1-3. Calendar Search .................................................................................................................................... 53
1-4. Bookmark Search................................................................................................................................... 54
2.ARCHIVING EVIDENCE TO DVD/CD OR USB .....................................................................54
3. LOG ..............................................................................................................................56
CLIENT VIEWER SOFTWARE ............................................................................................58
1. CONNECTION..................................................................................................................58
2. LOGGING ON...................................................................................................................59
3. EXPLANATION OF SCREEN BUTTONS ................................................................................60
4. LIVE MONITORING ...........................................................................................................61
5. REMOTE SEARCH............................................................................................................65
5-1. Search.................................................................................................................................................... 65
5-2. Archive.................................................................................................................................................... 67
5-3. Remote Log............................................................................................................................................ 69
5-4. Information ............................................................................................................................................. 69
6. REMOTE SETUP (MENU SETTINGS -SAME AS DVR) ...........................................................71
6-1. Display.................................................................................................................................................... 71
7-2. IP Camera .............................................................................................................................................. 73
7-3. System ................................................................................................................................................... 75
7-4. Event...................................................................................................................................................... 77
8. LOCAL SEARCH (VIEWING DOWNLOADED FOOTAGE)...........................................................79
8-1. Search.................................................................................................................................................... 79
8-2. Log ......................................................................................................................................................... 81
8-3. Info ......................................................................................................................................................... 81
9. LOCAL SETUP .................................................................................................................82
9-1. Global..................................................................................................................................................... 82
9-2. Opacity................................................................................................................................................... 82
9-3. Audio Buffer............................................................................................................................................ 83
9-4. Camera Name........................................................................................................................................ 83
9-5. Deinterlace............................................................................................................................................. 83
10. TELEMETRY CONTROL (PAN/TILT/ZOOM/FOCUS) .............................................................84
10-1. Pan / Tilt / Zoom / Focus ...................................................................................................................... 84
10-2. Preset / Learn....................................................................................................................................... 85
11. SCREEN POSITION SAVE/LOAD.......................................................................................86
11-1. Screen Position Save ........................................................................................................................... 86
11-2. Screen Position Load............................................................................................................................ 86
12. FIRMWARE UPGRADE ....................................................................................................87
APPENDIX 1........................................................................................................................88
DYNAMIC IP(SUPPORTING DDNS SERVER) .........................................................................88
APPENDIX 2........................................................................................................................90
SETUP FOR DVR PORT &WEB SERVER PORT USING IPSHARING ROUTER...............................90
APPENDIX 3........................................................................................................................91
SPECIFICATION ...................................................................................................................91

7
QNVR Installation Manual V1.1
QNVR installation and user manual
Overview
1. Contents of Packing
Mouse
Power Cable
User Manual
Remote Controller
Battery
(AAA x2)
Installation
CD

8
QNVR Installation Manual V1.1
QNVR installation and user manual
2. Features
● Convenience
- User-friendly GUI (Graphical User Interface)
- Easy-to-use menu structure
- Easy-to-use recorded data search (Time, Date, Motion, and Alarm)
- Easy-to control via Front Panel, IR remote control and USB 2.0 mouse.
● Stability
- Auto restart after power interruption
- DB structure offers data stabilisation and better storage utilisation
● Expandability
- Remote NVR’s can be controlled using the supplied software client viewer.
● Technology
- Embedded LINUX OS
- Multi-Decoding (H.264/MPEG4/JPEG)
- High-resolution & high-quality H.264 algorithm
- Uses watermarking & scrambling technologies,
● Functionality
- Variable recording function (normal, alarm, motion, schedule)
- RS485 Telemetry
- Full channel real-time monitoring
- Live monitoring, recording, playback, backup, remote access simultaneously
- Multi channel playback
- Variable events notification to e-mail, buzzer or PC Client system

9
QNVR Installation Manual V1.1
QNVR installation and user manual
①②③④ ⑤⑥⑦⑧⑨
⑩⑪⑫ ⑬⑭⑮
Installation
1. Front Panel Controls
①Volume Up & Down ( / )
To increase or decrease the volume.
②Audio Selection
Switches through audio channels
③Multi-screen Display
Use the Multi-screen display button to select the display mode (single/4/9/16way).
④PTZ Channel Selection
Used to select the PTZ channel on multi-screen.
⑤Menu
Displays the menu on the screen
⑥Indicator
- POWER: System Power On/Off (When power is on, the green light will be illuminated)
- REC: Recording status (When recording is on, the red light will flash)
- NET: Network status (When network is connected, the light will lash)
- HDD: HDD status (When the system is reading or writing to the HDD, the light will flash)
⑦Search
Entering search mode
⑧Stop / Eject (■)

10
QNVR Installation Manual V1.1
QNVR installation and user manual
To stop playback and go back to live mode. To eject DVD-RW
Pause ( ▌▌)
To freeze picture on playback mode and live mode.
Forward Play (▶)
Playback of the recorded data. When in play mode press again to enter fast forward mode.
When video is paused this allows frame forward.
Reverse Play / Rewind ()
Reverse play of recorded data. When in play mode press again to enter fast rewind mode.
When video is paused this allows frame forward
Rec (●)
It starts & stops manual recording, password protected.
⑨Power
System Power On/Off (Password protected)
⑩Pan / Tilt
To enable the pan & tilt of PTZ cameras, a “T” will appear in the task bar at the bottom of
the screen
⑪Arrow Buttons
Moves the cursor while in menu mode
Pan and tilt in telemetry mode
Play forward / backwards in play mode
⑫Select
Menu selection
⑬Zoom
To control the zoom in & out of PTZ camera
⑭Numeric & Character
Input for numbers & letters within the setup menus and searches
⑮USB Port
USB connector for mouse control & downloading to USB memory.
2. Rear Panel Connectors
⑭

11
QNVR Installation Manual V1.1
QNVR installation and user manual
①Network Port for NAS
Connecting to the network storage across a LAN
②HDMI Output
HDMI output port (1080p)
③VGA Output
VGA video output for main monitor (1024x768 to 1920x1080)
④Audio Output
Audio output
⑤Network Port for PC Client
Connecting to the PC through Internet or LAN
⑥Network Port for IP camera
Connecting to IP cameras on a LAN
⑦USB Port
USB 2.0 port for mouse, USB storage
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
⑪
⑫
⑬

12
QNVR Installation Manual V1.1
QNVR installation and user manual
⑧RS232 Port
Serial Communication (for service)
⑨E-SATA Port
Port for e-SATA HDD
⑩PTZ Camera Controller
Serial Communication for Pan / Tilt Camera
⑪Keyboard Controller
Serial Communication for P/T/Z Control Keyboard
⑫Alarm Output
Alarm(relay) output port
⑬Sensor Input
16 Sensor input ports
⑭AC Power Input
AC 100-240V 50/60Hz

13
QNVR Installation Manual V1.1
QNVR installation and user manual
3. Remote Control
①POWER : Power on/off
②P/T/Z : Entering PTZ Setup menu directly
③REC : Start & Stop Recording
④Numbers and letters (1 to 9)
⑤INFO : Direct access system infomation
ID : Entering remocon ID set mode
MUTE : Audio Mute
AUDIO : Switches through Audio channels
⑥MENU: Entering system menu
SEARCH: Entering search
ARROW : Left, Right, Up and Down
SEL : Select/Enter
⑦VOL +/- : Up, down volume
⑧CH +/- : Up, down channel
⑨(◀)◀: Reverse play
▶(▶) :Play (or fast forward)
I I : Pause
■: Stop playback
⑩OSD : On Screen Display ON/OFF
SEQ : Sequence operation
LOG : Direct access Log list
⑪CAM : Changing PTZ icon
P/T : Pan &Tilt
Z/F : Zoom/ & Focus
DIS : Channel Division
⑩
①
②
③
④
⑤
⑥
⑧
⑨
⑦
⑪

14
QNVR Installation Manual V1.1
QNVR installation and user manual
4. Connection Guide
Connecting the monitor
There are two available monitor outputs on NVR.
●HDMI output : Connect to the HDMI port of the HD monitor(HDTV).
●VGA output : Connect to the VGAport of the VGAmonitor.
Connecting to a network
Use the Ethernet port to connect to remote PC, IP cameras and NAS via Ethernet network.
●Port for PC Client: Connect to the PC. (Default: 192.168.1.111)
● Port for IP Camera: Connect to IP camera network. (Default: 192.168.30.222)
● Port for NAS: Connect to the network storage. This can be share either of the above
sub-nets or be on a third independent sub-net (default 192.168.30.223).
Important: The PC port and IP camera port must not be on the same subnet.
Connecting audio
To listen to live or recorded audio, connect to an amplified speaker system.

15
QNVR Installation Manual V1.1
QNVR installation and user manual
●Audio output : Connect to the audio in of the audio AMP.
Connecting to a sensor input
There are 16 individual alarm inputs marked as Sensor In (1-16).
●Sensor inputs : Connect to (+) terminal of a sensor.
●Common GND : Connect to (–) terminals of sensors.
Connecting to a alarm output
The NVR can activate external devices such as buzzers or lights using the relay.
There are 4 relay outputs marked asAlarm out.
●A1/A2/A3/A4 : Connect to (+) terminal of buzzer or light.
●B1/B2/B3/B4 : Connect to (–) terminals of buzzer or light.
Connecting to a PTZ camera
This RS485 connector can be used to control Pan / Tilt / Zoom camera.
●Telemetry (+) : Connect to RS485 Rx(+) of PTZ camera.
● Telemetry (-) : Connect to RS485 Rx(-) of PTZ camera.
Connecting to a remote keyboard (VKBD4)
This RS485 connector is for a control keyboard.
Alarm
Outputs
Common
GND
Sensor
Inputs
Common
GND
(-)
(+)

16
QNVR Installation Manual V1.1
QNVR installation and user manual
●Keyboard (+) : Connect to RS485 Tx(+) of the keyboard.
● Keyboard (-) : Connect to RS485 Tx(-) of the keyboard.
Connecting to a mouse
●USB 2.0 : Connect to the mouse.
Connecting to a external HDD
To expand the HDD capacity, connect the external storage.
●e-SATA : Connect to the e-Sata HDD storage.
5. Turning on the NVR
1. Connect the power cable.
2. Connect camera cables.
3. Connect a network cable and a monitor cable.
4. Press the POWER button on the front panel and wait until the main screen is displayed on
the connected monitor; this process may take a couple of minutes.
(+)
(-)

17
QNVR Installation Manual V1.1
QNVR installation and user manual
Operation
1. Navigation
You can navigate the on screen menus using the front panel buttons, IR remote control or
mouse.
1-1. Mouse Control
Right clicking the mouse brings up the following popup menu.
①Setup Menu
②Search Menu
③PAN/Tilt Menu
④Focus/Zoom Menu
⑤Power Button
⑥Sequence Button
⑦Playback Button
⑧Eject Button
⑨Volume Up/Down Button
⑩Multi-screen Display Button
⑪Channel Up/Down Button
1-2. Menu Navigation
To enter the Setup menu, the user has to have the required access rights and be logged on.
Press the Menu button or right click with mouse on screen and select the menu icon.
The following screen will be displayed asking for password.
①Select the user ID.
②Enter the password.
The default password is 00000000(8 zeros).
③Press OK, the setup menu will be displayed
on screen.
All menus are navigated around using the Left/
Right/ Up/ Down and the Select button or mouse.
To step back out of the menus, press MENU button
or click the right button of the mouse.
①
②
③
⑦
⑨
⑪
⑤
⑧
⑩
①
③
⑥
⑨
⑪
②
④

18
QNVR Installation Manual V1.1
QNVR installation and user manual
2. Screen Displays
2-1. OSD Description
The Status Bar on screen shows HDD capacity, network connection, current time, etc.
①HDD capacity: Used capacity / Duration
②Multi-screen Display icons : Single/ 4/ 9/ 16way
③e-SATA connection
④USB memory connection
⑤Mouse connection
⑥Network connection
⑦Current Date/Time
2-2. Select Channel
Use the Multiscreen display button ( ) on the popup menu to select the display mode.
Single Channel 4 Channel 9 Channel
Live 1ch Live 4ch Live 9ch
16 Channel
Live 16ch
Also you can use the DIS button on the remote controller to change the display mode.
①
⑤
⑦
②
③
⑥
④

19
QNVR Installation Manual V1.1
QNVR installation and user manual
Display switches in the following order when the DIS button is pressed.
Single Channel 4 Channel 9 Channel 16 Channel Single Channel
2-3. Digital Zoom
When the system is in full-screen mode, drag your mouse in the screen to select a section
and then left click mouse to realize digital zoom.
You can right click mouse to exit.

20
QNVR Installation Manual V1.1
QNVR installation and user manual
3. Playback
Click the right button on the mouse, the popup menu will be displayed on screen.
To begin playback, press the Play button on the popup menu:
3-1. OSD Description
The Control Bar on screen shows Playback control buttons, Progress bar, Display mode
buttons, Playback time, etc.
①Previous/ Next time buttons ⑨Reverse Slow Play button
②Time Bar ⑩Slow Play button
③Playback Speed Display ⑪Replay button
④Display mode buttons(1/4/9/16ch) ⑫Add Bookmark button
⑤Stop button ⑬Search Bookmark button
⑥Pause button ⑭Quick Archive button
⑦Reverse Play button ⑮ Playback Date & Time
⑧ Play button
④
⑫
⑬
③
⑮
⑭
①
①
②
⑩
⑧
⑥
⑤
⑦
⑨
⑪
