INTRODUCTION
IB704 User’s Manual 1
Introduction
Product Description
The IB704 PC/104 Plus module features the AMD Geode CS5536
companion device that is optimized to work with the AMD Geode LX
[email protected] processor. With a compact 90mm x 96mm footprint
standard, the IB704 is suited for space-constraint applications in factory
automation, military, security, transportation and POS. The board does
not require a fan and features extended temperature operation that
enables it to perform in harsh environment..
The IB704 delivers the highest power/performance ratio available in the
industry and comes with advanced graphics, connectivity and expansion
features. On board is one SO-DIMM socket supporting up to 1GB of DDR
SDRAM. The integrated VGA controller supports for CRT and LVDS LCD
displays. Connectivity interfaces include the PC/104+ connector and a
10/100 BaseT Ethernet, four USB 2.0 and two serial ports.
FEATURES
Embedded AMD Geode LX700 (433MHz) / LX800 (500MHz)
DDR SO-DIMM x 1, Max. 1GB
Realtek RTL8100C 10/100 BaseT Ethernet
Integrated LX800/LX700 2D VGA controller, supports CRT and
LVDS interfaces
4 x USB 2.0, 2 x COM, Watchdog timer
PC/104+ connector (PCI+ISA)
Extended Temperature (-20C ~ 80C)
Remarks: In installing the PC/104 Plus CPU board into a chassis, it is
recommended that the CPU board be placed on the topmost level of the
PC/104 board layers. The chassis environment should be designed in
such a way that there is good airflow to ventilate the system.

INTRODUCTION
2 IB704 User’s Manual
Checklist
Your IB704 package should include the items listed below. Damaged or
missing items should be reported to your supplier.
The IB704 CPU Module
This User’s Manual
One Driver CD
Optional cable kit (IDE7, IDE6, PK3-2, PS2G, VGA8, RJ45A2,
USB2-2, PK1-12, FF2)

INTRODUCTION
IB704 User’s Manual 3
Specifications
Form Factor
PC/104+
CPU Type
AMD Geode LX processor
CPU Operating
Frequency
LX800 @500MHz (IB704F)
LX700 @433MHz (IB704)
Green / APM
APM1.2
BIOS
Award BIOS (4MB FWH)
Chipset
AMD CS5536 I/O companion multi-function south
bridge
Memory
One DDR SODIMM socket, Max. Up to 1GB
Graphics
LX800/LX700 built-in high performance 2D
graphic controller, supports LVDS LCD & CRT
display
LAN Controller
Realtek RTL8100C-LF 10/100Mbps
IDE
CS5536 built-in one channel UDMA100 IDE
USB
CS5536 built-in USB2.0 controller, support 4
ports
LPC I/O
Winbond W83627HG: KB/Mouse controller,
Parallel, IrDA, Floppy, COM1, COM2 (RS232) &
Hardware monitor (3 thermal inputs, 4 voltage
monitor inputs)
RTC/CMOS
Geode CS5536 built-in w/ on board Lithium
battery
PCI Arbiter
ITE IT8209R PCI arbiter/clock buffer chip, extend
PCI devices (master) from 1 to 3
PCI to ISA Bridge
ITE IT8888G
Watchdog Timer
Yes (256 segments, 0, 1, 2…255. sec/min)
On Board header
PC/104+ (PCI + ISA) connector set x1
2x8 pin-header x1 for VGA
2x13 pin-header x1 for parallel port
2x5 pin-header x2 for COM1, 2
2x4 pin-header x2 for USB
2x22 box-header x1 for IDE
2x5 pin-header x1 for LAN
DF13-20 connector x1 for LVDS
6-pin pin-header x1 for PS/2 KB&MS
5-pin pin-header x1 for IrDA
4-pin FDD power connector x1 for system power
input.
Operating
Temperature
-20C ~ 70C (68F ~158F)
Board Size
96mm x 90mm

INTRODUCTION
4 IB704 User’s Manual
Board Dimensions

INSTALLATIONS
IB704 User’s Manual 5
Installations
This section provides information on how to use the jumpers and
connectors on the IB704 in order to set up a workable system. The topics
covered are:
Installing the Memory (SODIMM) .............................................. 6
Jumpers and Connector on IB704 ................................................ 7

INSTALLATIONS
6 IB704 User’s Manual
Installing the Memory (SODIMM)
The IB704 has a 144-pin SODIMM socket. The SODIMM socket
supports a maximum total memory of 1GB.
Installing and Removing DIMMs
To install the SODIMM, locate the memory slot on the CPU module and
perform the following steps:
1. Hold the SODIMM so that the two keys of the DIMM align with those
on the memory slot.
2. Gently push the SODIMM in an upright position until the clips of the
slot close to hold the DIMM in place when the SODIMM touches the
bottom of the slot.
3. To remove the SODIMM, press the clips with both hands.
Top View of SODIMM Socket
