IBM ThinkPad T20 User manual

Setup Guide
Setup Guide
P/N: 46L4324
IBM ThinkPad T20
RR
Checklist for unpacking
Thank you for purchasing the IBM ThinkPad T20 computer. Match the items on this list with the items in the box.
If any item is missing or damaged, please contact your place of purchase.
Ø Computer Ø Diskette drive Ø Telephone cable
Ø Miscellaneous parts
Security screw
TrackPointcap
With some models, additional
items may be provided.
Ø CDs:
Ø AC adapter
 Software Selections CD
Recovery CD kit for Windows
Ø Power cord Ø Publications
 Setup Guide
 User's Reference
 Manual package
for Microsoft

Windows
User's Reference
Setup Guide
Ø Battery pack
Note: For how to install the battery pack in the computer, refer to the online information. For access to that information, use the ac
adapter to turn on the computer.
 Copyright IBM Corporation 2000. All rights reserved.
1

Setting up your computer
1 Connecting to a power source.
Connect the ac adapter to the computer's power jack (at
the rear of the computer). Make the connections in the
order shown.
2 Turning on the system.
a) Open the liquid crystal display (LCD).
Press the LCD latches .1/ and open the LCD .2/.
Then position the LCD so that it is convenient for
viewing.
1
2
3
1
1
2
2

b) To turn on the computer, push the power switch .1/.
3 Using the TrackPoint pointing device
The TrackPoint pointing device is a unique system for
moving the cursor on the screen. Using the TrackPoint
stick and buttons, you can perform all mouse operations.
The left and right click buttons function like the left and
right buttons on a mouse.
To move the cursor, use the red-topped stick in the center
of the keyboard. Press gently with your left or right index
finger in the direction you want to move the cursor. To
select and drag an object, press and hold one of the
buttons with either thumb, as required by your software.
Click means to press the left button once. Double-click
means to press the left button twice within 1 second.
For more information about the TrackPoint pointing device,
see the online information. You can launch it by pressing
the ThinkPad Button. Refer to page 5 on the ThinkPad
Button.
1
Stick
Left click button
Cursor
Right click button
Center button
3

4 Using the volume control.
You can adjust the sound level produced by the built-in
speakers by using the following three buttons:
.1/ Volume down
.2/ Volume up
.3/ Mute
If the sound is muted when you turn off the
computer, it remains muted when you turn the
computer on again.
To turn on the sound, press the Volume up or
Volume down button.
When you press one of these buttons, the volume
indicator appears on the screen for a few seconds. For
more details on volume control, see the online information.
You can launch it by pressing the ThinkPad Button. Refer
to page 5 on the ThinkPad Button.
5 Setting up Windows.
The computer is preloaded with Windows 98, Windows
2000, Windows 95, or Windows NT. To set up the
operating system, follow the instructions on the computer
display.
1 2 3
4

6 Using Access ThinkPad
Your computer features the unique ThinkPad Button.
Press the ThinkPad Button anytime to open the online
help and information center—Access ThinkPad.
With Access ThinkPad, you can obtain information from
two sources. On the left, Access ThinkPad offers
information from the ThinkPad Assistant, your online user's
guide. On the right are Internet portal buttons that link you
to helpful Internet Web sites. There is no need to carry
heavy manuals or reference books.
With ThinkPad Assistant, you can either perform a Quick
Search of the ThinkPad Assistant index or search the
entire help system.
If you are logged on to the Internet, click one of the
Internet portal buttons in Access ThinkPad to do any of the
following:
Get help and user support
Update software
Find business solutions
Learn about accessories that can help make you even
more productive
ThinkPad Button
5

Service and Support information
Getting help around the world
International Warranty Service (IWS) is available for customers
who are moving products or traveling to countries where their
product (as identified by the 4-digit machine type) is sold and
serviced by IBM or IBM-authorized representatives. Warranty
service delivery methods of the country providing the service will
be in effect. IBM reserves the right to change or modify its
service delivery methods by country at any time without notice.
Service procedures differ by country, and some service and
parts may not be available in all countries because of the laws of
that particular country. In some countries, fees may apply to
service provided on-site in remote locations.
To register, call one of the following IWS Offices:
The IWS office will issue an International Warranty Service
Certificate, which you can use wherever IBM or IBM resellers
sell and service this product.
Before you call for service, have on hand:
The exact wording of any error messages
Information on the configuration of your hardware and
software
A description of the problem
Information on any options installed on your system,
including serial numbers
Southeast Asia, Australia, New Zealand, and Hong Kong: 61-2-9354-4171
Canada, Latin America, and the U.S.: 1-800-497-7426
or
248-740-1215
Europe, Middle East, and Africa: 44-1475-893638
Japan, Korea, China (except Hong Kong), and Taiwan: 81-462-73-7598
6

Trademarks
The following terms are trademarks of the IBM Corporation in the
United States or other countries or both:
IBM
ThinkPad
TrackPoint
Microsoft, Windows, Windows NT, and the Windows logo are
trademarks of Microsoft corporation in the United Sates and/or
other countries.
Your name:
Company name:
Model number:
Serial number:
Company or reseller service:
IBM service Web site:
IBM service number:
Notes:
7
