iCandy apple User manual
iCandy apple instruction manual
MPORTANT
Keep for future reference
Read these instructions carefully before use and keep them for future reference.
Your child’s safety may be affected if you do not follow these instructions.
WARN NG! t may be dangerous to leave your child unattended.
Safety tested and certified to BSEN1888:2003 for the UK and Europe,
ASTM F833-08 for the USA and SOR-85-379 for Canada.
Tested to ensure compliance with the Furniture and Furnishings (Fire) (safety) Regulations.
The iCandy apple is a quality product designed and distributed by:
iCandy World Limited
Montgomery Way
Biggleswade
Bedfordshire
SG18 8UB
England
F: +44 (0) 1767 604410
Email: [email protected]
www.icandyworld.com
© iCandy World Limited.
iCandy apple
iCandy apple
a
b
c
f
g
d
e
123
456
7
10 11
8 9
12
iCandy apple
iCandy apple instructions
Correct use and maintenance of your
pushchair is essential. Please take the time
to fully and carefully read this instruction
manual. f you require any further advice or
assistance when using your pushchair,
please contact the place of purchase.
# #-8,8,))<')48-323*
8,) 398)6 4%'/%+-2+ '%6832 83
46):)28 -2.96= *631 ',3/-2+ 6)13:)
%2( -11)(-%8)0= (-7'%6( %00 38,)6
4638)'8-:)4%'/%+-2+328,-7463(9'8
Follow these simple instructions to
assemble your iCandy apple.
acanopy (hood)
bbumper bar
cseat unit
dchassis
erear wheels
fcar seat adaptors (sold separately)
graincover
The iCandy apple is tested to comply with
BSEN 1888:2003 and is tested to ensure
compliance with the Furniture and
Furnishings (Fire) (Safety) Regulations.
Useful tip
New products are sometimes stiff to
engage and operate. We recommend ALL
adaptors (sold separately) and connector
parts be lightly lubricated with a silicone
based furniture polish. This is best
achieved by spraying polish onto a soft
cloth and applying to relevant parts.
1. Folded/hold together latch
To release the folding strap depress both
indicated clips simultaneously. ",-7 0%8',
1978&))2+%+)(&)*36)7836%+)
2. To open
To open the iCandy apple stand behind the
pushchair and, with both hands on the
pushbar, pull-up until the iCandy Apple
clicks into place.
3. Fitting the brake bar/rear axle
assembly
Turn the iCandy apple upside down.
Position the brake bar / rear axle assembly
with the brake levers uppermost. Once the
rear axle assembly is secure to the main
chassis pull firmly on each side of the
combined brake bar / rear axle assembly to
check that the assembly on both sides is
securely locked into place.
4. To fit the rear wheels
Lift locking locating catch. Place the wheel
into the axle. Release locking locating
catch and wheel should lock into position.
Pull on wheel to ensure that it is securely
fitted. This process is repeated for the other
side.
5. Attaching the canopy (hood)
Fit the canopy by locating onto the seat
frame ensuring it latches into the bracket
securely.
6. Removing the canopy (hood)
Remove canopy by depressing both side
clips as shown and pull to remove.
13 14 15
16 17 18
19
22 23
20 21
24 & 25
12
3
2
1
3
iCandy apple
# ,)'/ 8,%8 8,) '%6
7)%8-7'366)'80=)2+%+)(&)*36)97)
18. Attaching the adaptors (sold
separately)
Locate and fit the car seat adaptors as
shown, ensuring the grey buttons latch
flush. The adaptors should lean rearwards
for correct orientation.
19. nstalling the Maxi-Cosi nfant
Carrier
Place the car seat onto the adaptors with
the head end at the front until you hear a
“click”. Check to make sure that everything
is attached securely.
20. Removing the Maxi-Cosi nfant
Carrier
Press the control buttons on both sides
while at the same time lifting the car seat
from the adaptors.
21. Removing the Car Seat
Adaptors (sold separately)
Depress the grey buttons and withdraw.
22. Securing your child using the
5-point safety harness
Feed the buckle tongues 1 & 2 into the
buckle housing 3 and click together.
Adjust your five-point harness at the points
indicated in the direction of the double
arrows as required.
To unfasten the harness squeeze in the
buckle tongues 1 & 2 and pull out of the
buckle housing 3.
D-Rings are provided for attaching an extra
harness complying to BS 6684.
# "3 %:3-( 7)6-397
-2.96=%0;%=797)8,)43-287%*)8=
,%62)77
23, 24 & 25. Fitting the PVC
Raincover
Fit raincover as shown ensuring velcro tabs
are secure where necessary.
# ):)6 0)%:)
6%-2'3:)67,33(7%2(%463273236
3:)68,)497,',%-6-2(3367-2%,38
%81374,)6) 36 2)%6 % ,)%8 7396')
=396',-0(1%=3:)6,)%8
7. Bumper bar
Attach the bumper bar onto the brackets, it
will click into place. Press in grey buttons
simultaneously and pull up bumper bar to
release.
8. Bumper bar blanks
Bumper bar/carry handle blanks can be
fitted if preferred.
9. Attaching the seat unit to the
chassis
nsert the seat adaptor assembly into the
main connector on the frame. You can
position the seat unit to have your child
facing you or facing forward.
# ",-7 7)%8 -7 238
79-8%&0)*36',-0(6)292()61328,7
# ,)'/8,%88,)46%1
&3(= '%66='38 36 7)%8 92-8
%88%',1)28 ():-')7 %6) '366)'80=
)2+%+)(&)*36)97)
10. Reclining the seat unit
To recline the seat unit press the grey
buttons on both sides and move into
required reclined or upright position.
Release buttons when in desired position.
11. Adjusting the footrest
Press both buttons on the sides of the leg
rest, adjust to desired position and release
to lock.
12 & 13. Front wheel
The front wheels can be selected either in a
fixed position or in a swivel position.
14. Handle height adjustment
There are seven handle height positions. To
adjust, press the grey centre button and
pull up simultaneously to desired level.
Release button and engage at the desired
height.
15. Using the brakes
To apply brake, press down gently on the
middle of the brake bar. Rocking the
pushchair assists engagement. To release
brake, place foot under brake bar and pull
upwards.
# 0;%=7 %440= 8,)
&6%/)7 ;,)2 8,) 497,',%-6 -7
78%8-32%6=
16 & 17. Folding the chassis
Remove the seat unit before folding. Press
the grey handle height adjuster button 1
whilst depressing the secondary lock
button 2. When the handle is at its lowest
point, push downwards to disengage and
fold the stroller 3. Apply the hold together
latch as per picture 1.
Using with a Maxi-Cosi nfant
Carrier Car Seat
Maxi-Cosi nfant Carriers are suitable for
children from birth to 15 months and
weighing up to 13kgs. (As indicated on the
Maxi-Cosi nfant Carrier).
iCandy apple
26 27 28
29 30 31
32 33 34
iCandy apple carrycot
26. Remove the mattress
27. Remove the inner liner
28. Stay Bars
Slide the support stay bars at front and rear
until under location lugs. Refit the liner and
mattress.
29. Operation of the canopy (hood)
Pull up the handle as illustrated until the
two grey latching buttons (arrowed) engage
with a positive "click". Check that the
handle is secure before placing your baby
into the carrycot.
30. To lower the canopy (hood)
Depress both grey latching buttons as
shown before attempting to rotate the hood
handle.
31, 32 & 33. Attaching the carrycot
to the chassis
Lower the carrycot as shown ensuring both
side grey side buttons latch into place.
Ensure securely positioned by pulling up on
the handle.
Pull down the stabilizer bar and lock onto
the basket bar as shown.
# ,)'/8,%88,)46%1
&3(= 36 7)%8 92-8 %88%',1)28
():-')7 %6) '366)'80= )2+%+)(
&)*36)97)
34. Removal of carrycot
Release and store the stabilizer bar.
Depress each grey side button as shown,
whilst lifting up gently and simultaneously
holding handle. Pull up and clear of chassis
once both sides are released.
35. Carrycot Raincovers
Fit raincover over the hood/canopy area
before fitting over the foot end of carrycot.
Ensure elasticated seams of raincover are
positioned under the base of the carrycot.
%66='38'0)%2-2+-2*361%8-32
The exterior of the carrycot, hood and
apron of the iCandy apple carrycot may be
cleaned with a damp cloth.
The lining and cover must be washed by
hand using a soft detergent at a maximum
temperature of 30 degrees (see instructions
on washing label). Do not place in washing
machine or tumble-dryer!
iCandy apple
# ",) -%2(= %440)
'%66='38 -7 320= 79-8%&0) *36 % ',-0(
;,3'%22387-89492%-()(63003:)6
%2( '%2238 497, -87)0* 94 32 -87
,%2(7%2(/2))7%<-191;)-+,83*
8,)',-0(/+%4463<1328,7
# 3 238 0)8 38,)6
',-0(6)2 40%= 92%88)2()( 2)%6 8,)
'%66='38
# 3 238 97) -* %2=
4%68-7&63/)28362361-77-2+
# ):)6 97) %
1%886)77 8,-'/)6 8,%2 11 ",-7
;-00 6)(9') 8,) )**)'8-:) ,)-+,8
-27-() 3* 8,) '%66='38 83 0)77 8,%2
11 #,)2 % 1%886)77 -7
496',%7)( 7)4%6%8)0= -8 7,390(
'32*36183!4%68
14368%28
1. Use only on a firm, horizontal, level and
dry surface.
2. The handles and the bottom of the
carrycots should be inspected regularly for
signs of damage and wear.
3. Be aware of the risk of open fire and
other source of strong heat, such as
electric bar fires, gas fires etc, in the vicinity
of the carry cot.
4. The iCandy apple carrycot is not a safe
means of transport by car and should
NEVER be used as such. Use an approved
car safety seat for transport by car.
General nstructions
•Use the iCandy apple for only one child
at a time.
•The iCandy apple is suitable for children
from birth to approx 4 years (up to 20kg),
and when seated, the midpoint of the
childs head is at or below the top of the
stroller seat. The maximum weight
allowance for use with a Maxi-Cosi
nfant Carrier is 13kg. The maximum
weight allowance for the iCandy apple
carrycot is 9kg.
•t is recommended that you do not use
the iCandy apple seat unit until
your child is able to sit up unassisted,
usually at around 6 months.
•Make sure the iCandy apple is fully
unfolded and locked before placing your
child in it.
•Keep your child away from all moving
parts when folding, unfolding or
adjusting the pushchair.
•Always apply brakes when parking, even
when standing still for a few moments.
•nspect and clean your pushchair
frequently. Never use abrasive cleaners
or lubricants.
•Never lift the iCandy apple or use
escalators or stairs when there is a child
in it.
•Use original accessories and
manufacturer-approved parts only.
Failure to do so may affect your
warranty.
•Do not make any changes to this
product. f you have any problems or
complaints, contact your retailer or
importer.
•To avoid the risk of suffocation, keep all
plastic packaging materials out of the
reach of children.
•Safety tested and certified to BSEN1888
for the UK and Europe, ASTM F833-08
for the USA and SOR-85-379 for
Canada.
iCandy apple
• GENERAL SAFETY - Open fires and
heating appliances, particularly portable
types, must be guarded by a nursery type
fireguard. To avoid burns, keep your child
away from hot liquids, cookers, radiators,
portable convectors, flexes, fireplaces etc.
Use a stair gate at all times.
• NOTE n the interest of customer care
and product development, we review the
quality of our products on a daily basis.
We reserve the right to modify or amend
the specification of our products and their
parts without prior notice.
Product Care and maintenance
",) -%2(= %440) 497,',%-6 6)59-6)7
6)+90%61%-28)2%2')&==39
•Regularly inspect the locking devices,
brakes, harness assembly, catches, seat
adjusters, joints and fixings to ensure
they are secure and in full working order.
•The brakes and wheels are subject to
wear and should be replaced as and
when necessary.
•Should any parts of your iCandy apple
pushchair become stiff or difficult to
operate, ensure that dirt is not the
cause. Then try a light application of a
sprayable lubricant e.g. silicon spray,
ensuring that the lubricant penetrates
between the components, but take care
as excessive application may encourage
the accumulation of dirt. Regular light
lubrication of moving parts will extend
the life of your pushchair and make
opening and folding easier.
•Do not leave the iCandy apple pushchair
in sunlight for prolonged periods as the
colour of some fabrics may fade.
•Store the pushchair in a dry, well
ventilated and safe place.
•Your pushchair should be serviced and
reconditioned before using it for a
second baby, or within 18 months,
whichever is the sooner. This can be
arranged by contacting your iCandy
dealer.
Safety WarningS
% # 8 1%=&)(%2+)639783
0)%:) =396 ',-0( 92%88)2()( 0;%=7
/))4 =396 ',-0( -2 :-); ;,-0)
497,',%-6-7-297)
& # 0)%7))2796)8,%8=396
',-0( ;)%67 % '366)'80= *-88)( %2(
%(.978)( ,%62)77 %8 %00 8-1)7 36
)<86% 7%*)8= 6-2+ 03347 %6)
463:-()( *36 8,) %88%',1)28 3* %
7)4%6%8) 7%*)8= ,%62)77 -* ()7-6)(
%4463:)(83!
' # ))4 ',-0(6)2 '0)%6 3*
13:-2+ 4%687 &)*36) 1%/-2+
%(.9781)287 "3 %:3-( )286%41)28
/))4 =396 3;2 %2( =396 ',-0(6)27
*-2+)67 '0)%6 3* %2= *30(-2+ 4%687
:)603%(-2+ -2'366)'8 *30(-2+ %2(
8,)97)3*232%4463:)(%'')7736-)7
1%= (%1%+) &6)%/ 36 38,)6;-7)
6)2()68,)497,',%-6927%*)*3697)
( # 3238 %003; =396 ',-0(
83 '0-1& 92%77-78)( -283 8,)
497,',%-6
) # ",-77)%8-723879-8%&0)
*36',-0(6)292()61328,7
* # 323897)6)40%')1)28
4%68736%'')7736-)7)+',-0(7)%87
&%+ ,33/7 6%-2 '3:)67 )8' 38,)6
8,%28,37)%4463:)(&=-%2(=
+ # 3 238 3:)603%( 8,)
497,',%-6 ;-8, %((-8-32%0 ',-0(6)2
,)%:= 4%'/%+)7 +33(7 36
%'')7736-)7 %+7 %2( 38,)6 -8)17
1978 238 &) ,92+ *631 8,) ,%2(0)
&%67%78,)= 1%= (%1%+) 8,)*6%1)
3638,)6;-7)'%97)8,)497,',%-683
&)'31)92&%0%2')(%2(8-43:)6
, # 30(3283=396497,',%-6
;,)2 '037) 83 %2= 13:-2+ 63%(
:),-'0)3686%-2:)2;-8,8,)&6%/)7
328,)(6%9+,8*6318,):),-'0)1%=
'%97) 8,) 497,',%-6 83 13:) ",)
497,',%-67,390(320=&)97)(92()6
%(908794)6:-7-32
- # 323897)8,)497,',%-6
-2 % 1%22)6 *36 ;,-', -8 -7 238
()7-+2)(
.# *8,)497,',%-6-783
&)97)(&=731)32)92*%1-0-%6;-8,
-8 )+ &= +6%2(4%6)287 %0;%=7
7,3;8,)1,3;-8;36/7
/ # 0;%=7 97) 8,) '638',
786%4 -2 '31&-2%8-32 ;-8, 8,) ;%-78
&)08
0 # ):)6 97) 8,) '%66='38
32%78%2(
1# ",-7 463(9'8 -7 238
79-8%&0)*366922-2+367/%8-2+
2 # ",) 1%<-191 03%( *36
8,)7,344-2+&%7/)8-7/+
3 # 0;%=7 /))4 8,-7
27869'8-32 %29%0 ;-8, 8,) -%2(=
%440)497,',%-6%2(*36*9896)97)
!
iCandy apple
0)%7) 6)+-78)6 =396 463(9'8
496',%7) 8,639+, 396 320-2)
;%66%28= 6)+-786%8-32 &= :-7-8-2+
;;;-'%2(=9/'31
0)%7) &) %(:-7)( =39 2))( 83
6)+-78)6=396 7)6-%0 291&)6 -2 36()6
83 %'8-:%8) =396 8;3 =)%6
1%29*%'896-2+ ;%66%28= $396 7)6-%0
291&)6 '%2 &) *392( 32 8,)
7,344-2+&%7/)8&%63*=396786300)6
%2( 32 8,) 78%&-0-7-2+ &%6 3* 8,)
'%66= '38 8>7 % ;,-8) 0%&)0 %2(
'0)%60= ,%7 8,) ;36( 7)6-%0 291&)6
;-8,(-+-87%*8)6;%6(7"3%'')778,)
7)6-%0 291&)6 32 =396 786300)6
40)%7)6)13:)8,)7,344-2+&%7/)8
*%&6-'836):)%08,)291&)6
iCandy apple accessories
Accessories available for the iCandy apple:
•Maxi-Cosi Car Seat Adaptors.
•Superfleece Luxury Footmuff - available
in a selection of colours.
•Core Seat Snuggle - available in a
selection of colours. (Not shown).
•Sun Parasol - available in a selection of
colours.
•Lifestyle Changing Bag available.
•Cup Holder available. (Not shown).
•Parasol/cupholder clamp. (Not shown).
•Flavour pack - available in a selection of
colours.
•Jogger wheel. (Not shown).
•Travel Bag available. (Not shown).
Product Care and maintenance
•The plastic and metal parts of the
pushchair may be sponged clean with
warm water and a mild detergent.
•The seat unit may be cleaned by
sponging lightly with warm water and a
mild detergent.
•Never clean with abrasive, ammonia or
bleach-based and spirit-type cleaners.
•Allow all parts to dry thoroughly before
storing.
•After exposure to wet or damp
conditions, leave the pushchair fully
opened in a warm, well-ventilated
environment. Dry it off with a soft, lint
free and absorbent cloth. Residual
moisture, left unattended, will
encourage mildew or rust to form,
damaging the pushchair.
Warranty
Our products are warranted against
defects in materials and workmanship for a
period of two years from date of purchase.
The warranty period for an iCandy apple
carrycot is six months from date of
purchase. f the product has a
manufacturing fault we will repair it for free.
f it is not practical to repair it we will, at our
discretion replace the part in question. f
the product fails due to wear and tear,
accident, neglect or negligence, or is
outside the warranty we will happily repair
it for a reasonable charge.
",) ;%66%28= '3:)67 8,) 36-+-2%0
496',%7)6 &9=-2+ 8,) 463(9'8 *631
%2 %98,36-7)( ()%0)6 633* 3*
496',%7)-76)59-6)(
The warranty covers workmanship or
materials that are deemed faulty, providing
the pushchair has at all times been used in
normal conditions, in accordance with
instructions, and been properly maintained.
The warranty does not cover second hand
product, modified product, poorly
maintained product, normal wear, fading
and fabric cuts, improper use (by way of
example): abnormal use; not following
instructions; child left unattended; safety
harness not used; excessive load;
transport damage i.e. airline or freight
damage.
Customer costs within warranty include
inward freight charges to return the product
to manufacturer’s representative for
warranty and or service.
Manufacturer’s representative reserves the
right to charge a service fee and/or charge
for parts replaced/repaired. A return freight
charge may apply.
Exclusions. Any consequential loss or
damage to any person or property directly
or indirectly as a result of using product.
Please discuss any warranty or service
queries with your store of purchase. $39
;-00 &) 6)59-6)( 83 7,3; 4633* 3*
496',%7) They will inform you of the next
step. Products that are returned directly to
manufacturer by customer will NOT be
eligible for warranty.
Table of contents
