ICC ICRESDC9PE User manual
PremiumProducts I ProvenPerformance I CompetitivePrices
Call us: 888-ASK-4-ICC I E-mail us: csr@icc.com I Go on-line: www.icc.com
© Copyright 2008, ICC. ICC and ICC logo are registered trade name and trademark. All rights reserved. 0808 ISO 9001:2000 Registered
© Copyright 2009, ICC. ICC and ICC logo are registered trade name and trademark. All rights reserved.
Package Content/Contenido
1. Enclosure 1ea.
Caja (14.25" x 9.00" x 3.625")
2. Cover 1ea.
Cubierto (15.00" x 9.40" x 1.00")
3. Installation Instructions 1ea.
Manual de instalacion
4. #10 x 1" Wood Screws 4 pieces
Tornillo de Madera
5. #6-32 x 1" Machine Screw 2 pieces
Tornillos
ICC’s new 9” Plastic Net.Media Center is designed to be
installed in a residence; such as small homes, multi-unit
dwellings and retrofitting existing homes and serve as the
central distribution point for voice, data, audio and video
connectivity. Its compact size makes it perfect for smaller
types of structured cabling installations allowing it to fit
in tight and confined areas. The base is designed to fit
between 16” wall studs and offers a variety of mounting
options. It can be installed inside the wall for a professional
clean appearance, or wall mounted if the walls have
already been installed and painted. ICC’s 9” Plastic
Net.Media Center can be configured with any ICC
Net.Media Center connectivity module.
Holds up to 4 mounting modules.
INSTALLATION INSTRUCTIONS
9” PLASTIC NET.MEDIA CENTER
1
5
4
3
2
Features / Caracteristicas
A. Light-weight ABS plastic construction
Construcion de plastico ligero ABS
B. Holds up to 4 mounting modules
Soporta hasta cuatro modulos
C. 110 power knockout for an AC power outlet (optional)
Accepta cajas electricas de 110V
D. 3 top, 3 bottom, 4 rear, and 2 side cable entry knockouts
Entradas y salidas para cable
E. 4 surface screw mounts
Cuatro agujeros para montar en superficie
F. Extendable mounting tabs
Lenguetas extensibles para montar entre postes
G. Padlock option for additional security (padlock not included)
Opcion para candado de seguridad
H. Dry wall markings
Marcas de guia para pared
A
B
G
C
B
D
D
F
A
Left Right
Bottom
Top
H
E
ICRESDC9PE
Step 1: With the supplied mounting screws, install the enclosure between wall studs or surface mount.
Instalacion de caja entre poste o superficies.
INSTALLATION INSTRUCTIONS
Surface Mount
Stud Mount
Adjust the enclosure according to the thickness of the drywall/sheetrock.
Use the drywall marking on the side of the enclosure for guidance.
Ajuste la caja dependiendo el grosor del drywall/sheetrock. Utilice las
marcas en los lados de la caja como guia para montar la caja entre
postes y asegurar que el frente de la caja quede al nivel del
drywall/sheetrock
Step 3: Install Net.Media Connectivity Modules
Instalacion de modulos
Mount modules vertically or horizontally
Monte modulos vertical o horizontal
1. Secure the top portion of the cover by
sliding the covers hooking mechanism
onto the enclosure.
Ensamble la porcion de arriva del cubierto con la caja
2. Then secure the bottom portion of the cover with the catch
latch located at the bottom center of the enclosure. Install
#6-32 screws to secure the door with the enclosure.
Optional: Use a padlock to restrict access.
Después asegure la porcion de abajo con el cierre de la
caja. Instale los tornillos #6-32.
Opcional: Use un candado para prevenir acceso.
21
Related Products
Premier CAT 5e Data Module
ICRESDPA1C
• Exceeds TIA CAT 5e performance standards
• 8-Port, supports up to 8 computers
Premier Telephone Module
ICRESVPA1C
• 8-Port bridged telephone with RJ-31X
• 4 incoming lines with 8 extensions per line
Premier CAT 6 Data Module
ICRESDPB1C
• Exceeds TIA CAT 6 performance standards
• 8-Port, supports up to 8 computers
Premier Video Splitter Module
ICRESAV82C
• 1 input x 8 outputs, supports up to 8 locations
• 2 GHz, 5-2300 MHz bandwidth
Compact CAT 5e Data Module
ICRESDPA3C
• Exceeds TIA CAT 5e performance standards
• 8-Port, supports up to 8 computers
Compact Telephone Expansion Module
ICRESVPB3C
• 8-Port bridged telephone
• For an additional 8 extensions per line
Compact CAT 6 Data Module
ICRESDPB3C
• Exceeds TIA CAT 6 performance standards
• 8-Port, supports up to 8 computers
Premier Video Splitter Module
ICRESAV42C
• 1 input x 4 outputs, supports up to 4 locations
• 2 GHz, 5-2300 MHz bandwidth
MSR-0463
Step 2: Install the Cover
Instalacion de cubierto
Telephone Module with RJ31X Jack
ICC’s Telephone Module with RJ31X Jack is an 8-port bridged telephone solution. The module offers a 110 IDC input and an expan-
sion jack for additional connectivity. It supports up to 8 telephone outlets for phone, fax, modem devices, and has access up to 4
incoming phone lines.
8-Port Telephone Module with RJ31X Jack
INSTALLATION INSTRUCTIONS
Residential Cabling Solutions
ASSEMBLY INSTRUCTIONS
16800 Edwards Road, Cerritos CA 90703 • 562-356-3111 • Fax 562-356-3100
© Copyright 2007, ICC. ICC and ICC logo are registered trade name and trademark. All rights reserved. MSR-0432-2 rev A
8-Port Telephone Module with RJ31X Jack, 1 piece
A
Fasteners, 4 pieces
B
ICRESVPA3C
INCLUDES:
A
Step 1.
1. Place module horizontally and align fasteners
with the peg board. Make sure the fasteners are
NOT in locked positions.
Step 3.
3. Once the module bracket is in the desired loca-
tion, push the fasteners to their lock position.
Step 2.
2. Push the module so that the fasteners goes into
the peg board of the enclosure.
A
B
Step 4.
4. Connect the incoming phone line to the 110 IDC labeled “From Source.” Use a 110 punch down tool to terminate each wire between contact
blades. Identify each outlet cable and connect to 110 block labeled “To Location.” Punch down twisted pairs depending on which lines are desired
to be activated at each location.
NOTE: Line#1 = Blue, Line#2 = Orange, Line#3 = Green, Line#4 = Brown
Example: Each 110-block represents one location. If you want to activate Line#1 at Location#1, simply punch down the twisted pair (White
Blue/Blue) to the first 110-block. If you want to use a 2-line phone (Line#1 & Line#2) at Location#1, simply punch down twisted pairs (White
Blue/Blue & White Orange/Orange) to the first 110-block to support 2-line phone.
WIRE INSTALLATION: For 110 IDC connector, follow the wire color-code and only use the 110 punch-down tool to terminate the wire between the
contact blades.
RJ-45 Jacks: Phone and data lines are wired according to the TIA T-568-A standard.
ASSEMBLY INSTRUCTIONS
Video Splitter Modules
2 GHz Video Splitters can support up to eight locations, offering a choice of 4, 6, or
8-ports, and are designed for installation in ICC’s Net.Media Centers. The Video
Splitters receive and distribute CATV, antenna, satellite, or modulated video
signals up to eight analog or digital television sets.
Deluxe Series Video Splitter Modules
INSTALLATION INSTRUCTIONS
Residential Cabling Solutions
ASSEMBLY INSTRUCTIONS
16800 Edwards Road, Cerritos CA 90703 • 562-356-3111 • Fax 562-356-3100
© Copyright 2006, ICC. ICC and ICC logo are registered trade name and trademark. All rights reserved. MSR-0411-2 REV C
2 GHz Video Splitter, 1 piece
A
Fasteners, 4 pieces
B
ICRESAV42L
ICRESAV62L
ICRESAV82L
INCLUDES:
A
Step 1.
1. Place module horizontally and align fasteners
with the peg board. Make sure the fasteners are
NOT in locked positions.
Step 3.
3. Once module bracket is in the desired location,
push the fasteners to their lock position.
Step 2.
2. Push the module so that the fasteners goes into
the peg board of the enclosure.
Fasteners (4x)
Splitter
Enclosure
Module Bracket
B
Step 4.
4. Prepare an incoming coaxial cable and outgoing coaxial cable by using ICC’s coax cable stripper tool (ICACSCSCTV), All-in-One Universal
Compression tool (ICACSCT01U), and F-type compression connectors (ICRDSAV01F for RG-6, and ICRDSAV04F for RG-6 Quad-Shield). Connect
the incoming cable to the “IN” port of the splitter and the outgoing coaxial cables to the “OUT” ports. The “OUT” ports route the video signal to each
location.
ASSEMBLY INSTRUCTIONS
