Ice-Tech CD 50 User manual

Granular Ice Technical Service Manual
1
COD: IQ02_404MTIN.DOC
TECHNICAL SERVICE MANUAL
GRANULAR ICE MACHINES
MODELS:
ICETECH CD 50
ICETECH CD 90
ICETECH GR140
ICETECH GR 220
ICETECH GR 400
ICETECH GR 560
ICETECH GR 560 SPLIT
CAREFULLY READ THE INSTRUCTIONS CONTAINED IN THIS MANUAL SINCE THEY PROVIDE IMPORTANT
INFORMATION RELATIVE TO SAFETY DURING INSTALLATION, USE AND MAINTENANCE.

Granular Ice Technical Service Manual
2
COD: IQ02_404MTIN.DOC
TABLE OF CONTENTS
1. INTRODUCTION.....................................................................................................................................................................................3
1.1. Warnings.........................................................................................................................................................................................3
1.2. Description......................................................................................................................................................................................4
1.3. Operating principle........................................................................................................................................................................4
1.4. Electric diagrams...........................................................................................................................................................................5
2. SPECIFICATIONS................................................................................................................................................................................12
2.1. Installation diagrams for inlet/outlet tubes and dimensions...................................................................................................12
2.2. Consumption data, weights, crated dimensions and volumes..............................................................................................12
NOTE: Expansion controlled by a thermostatic valve...........................................................................................................................15
2.3. Production tables for Ice Flakers...............................................................................................................................................16
2.4. About Crushed-Ice production...................................................................................................................................................17
3. DELIVERY & UNPACKING.................................................................................................................................................................18
4. INSTALLATION.....................................................................................................................................................................................19
4.1. Recommended placement of unit..............................................................................................................................................19
4.2. Water and Drainage....................................................................................................................................................................20
4.3. Connecting unit to water source (water-cooler units).............................................................................................................20
4.4. Connecting unit to drain (water-cooled models)......................................................................................................................20
4.5. Electrical connection...................................................................................................................................................................21
4.6. Assembling the dispersión one..................................................................................................................................................21
5. OPERATION..........................................................................................................................................................................................22
5.1. Preliminary checks......................................................................................................................................................................22
5.2. Starting up....................................................................................................................................................................................22
5.3. Inspection and adjustment of water level in the tray...............................................................................................................23
5.4. Cross checking ............................................................................................................................................................................23
6. ADJUSTMENTS....................................................................................................................................................................................23
7. INSPECTION AND REPLACEMENT PROCEDURES....................................................................................................................27
7.1. Lower bearing ..............................................................................................................................................................................27
7.2. Speed Reducer (Gearbox).........................................................................................................................................................28
7.3. Upper flange.................................................................................................................................................................................28
7.4. Upper bearing (depending on the model)................................................................................................................................29
8. MAINTENANCE AND CLEANING INSTRUCTIONS.......................................................................................................................30
9. MAINTENANCE AND CLEANING PROCEDURES.........................................................................................................................31
9.1. Special advise concerning R-404 Refrigerant.........................................................................................................................34
10. TROUBLESHOOTING.....................................................................................................................................................................35

Granular Ice Technical Service Manual
3
COD: IQ02_404MTIN.DOC
1. INTRODUCTION
1.1. Warnings
This appliance should be installed by approved Technical Service Personnel.
This plug should be accessible at all times.
To reduce the risk of electrical shock, ALWAYS disconnect the machine BEFORE cleaning or
maintaining the equipment. Do not attempt to install, service, or modify this machine. Improper
use by other than specially trained technicians is extremely dangerous and may result in a fire
or electric shock.
This machine should not be placed outdoors or exposed to rain.
Connect to drinking water mains.
This appliance is not intended for use by young children or infirm persons without supervision.
Young children should be supervised to ensure that they do not play with the appliance.
IMPORTANT!
• DO NOT ATTEMPT TO SERVICE THIS MACHINE AS IT IS DANGEROUS AND COULD
CAUSE SEVERE DAMAGE TO THE UNIT.
•SERVICE SHOULD ONLY BE CARRIED OUT BY TRAINED, QUALIFIED PERSONNEL.
•WE STRONGLY RECOMMEND USING ONLY ORIGINAL REPLACEMENT PARTS
AVAILABLE FROM AN AUTHORIZED DISTRIBUTOR.
•WASTE AND OTHER MATERIAL SHOULD BE DISPOSED OF ACCORDING TO LOCAL
REGULATIONS AND PROCEDURES FOR WASTE DISPOSAL.
•CLEANING AND MAINTENANCE ARE NOT COVERED BY THE WARRANTY.

Granular Ice Technical Service Manual
4
COD: IQ02_404MTIN.DOC
1.2. Description
Main Features of the Machine
▪18/8 stainless steel housing
▪Powerful speed reducer (24Kg./m. @ 7 rpm.)
▪Copper evaporator on precision bored tubing
▪Durable stainless steel auger with resilient coating
▪Ice drops out of the bottom of unit
▪Speed reducer in top part of the unit
▪Ecological refrigerant R404a
1.3. Operating principle
Water enters water trough via a float valve which provides a constant head of water. Through a
hole in the bottom of the trough, water flows into the bottom of the evaporator and floods it to
the same height as in the water trough. Water freezes upon contact with evaporator wall, and is
scraped off as ice by the vertical, rotating auger. Ice is carried upward until it passes through
discharge flap and falls into bin. When bin is full, automatic shut-off sensor (micro-switch on
discharge flap) switches off machine.
IMPORTANT!
If unit is placed on top of a cold room, and/or ice has to fall a long distance from unit, a
MECHANICAL ICE LEVEL SENSOR should be installed. (except 50 and 90)
To prevent ice from compressing in cold storage, we recommend transferring ice through a
plastic tube (80-100 mm diameter) attached to its lower end the DISPERSION CONE which is
PROVIDED WITH THE MACHINE in all models. (except 50 and 90).

Granular Ice Technical Service Manual
5
COD: IQ02_404MTIN.DOC
1.4. Electric diagrams
ICETECH CD 90

Granular Ice Technical Service Manual
6
COD: IQ02_404MTIN.DOC
ICETECH GR 560 TRIFASIC

Granular Ice Technical Service Manual
7
COD: IQ02_404MTIN.DOC
ICETECH GR 560 SPLIT

Granular Ice Technical Service Manual
8
COD: IQ02_404MTIN.DOC
ICETECH CD 50

Granular Ice Technical Service Manual
9
COD: IQ02_404MTIN.DOC
ICETECH GR 400, 560

Granular Ice Technical Service Manual
10
COD: IQ02_404MTIN.DOC
ICETECH DIAMOND 50, 90
MODELO
Dimensiones
máquina
Peso neto
Dimensiones
embalado
Peso bruto
Ancho x fondo
x alto
(KG)
Ancho x fondo
x alto
(KG)
ICETECH
50
405x515x750
36
480x575x900
41
ICETECH
90
465x595x795
58
535x685x850
63
MODELO
Producción
Consumo
agua
fabricación
Consumo
agua cond.
Watios
Amp.
Volt/Hz
Kg/24h (1)
L/h (1)
L/h (1)
-2
-2
ICETECH
50 A
40
1.6
460
2.2
220/50
ICETECH
50 W
42
1.6
8
460
2.2
220/50
ICETECH
90 A
85
3.54
533
2.93
220/50
ICETECH
90 W
85
3.54
20
533
2.93
220/50

Granular Ice Technical Service Manual
11
COD: IQ02_404MTIN.DOC
MODEL
ICE BIN
STORAGE
CAPACITY
(KG)
COOLING
WATER
CONSUMPTION
(L/Hour)
WATER
CONSUMPTION
(L/Hour)
NET
WEIGHT
(KG)
DIMENSIONS
(CRATED)
X*Y*Z
GROSS
WEIGHT
(KG)
VOLUME
(M3)
GR 140 A
60
5.5
70
615x650x146
5
85
0.58
GR 140 W
60
40
5.5
68
615x650x146
5
83
0.58
MODEL
REFRIGERANT
CHARGE
HIGH PRESURE
LOW
PRESURE
TOTAL
AMPS
FUSE
RATING
COMPRESSO
R POWER
TOTAL
POWER
MINIMUM
MAXIMUM
AVERAGE
(2)
(1)
(2)
(gr)
Kg/cm
2
Psi
Kg/cm
2
Psi
Kg/cm
2
Psi
(A)
(A)
(W)
(W)
GR 140 A
500
16
228
17
242
2.5
35
4.2
16
360
650
GR 140 W
360
16
228
17
242
2.5
35
4.2
16
360
650
(1) Data obtained at room temperature 20°C, water introduced at 15°C; water quality = 500ppm
(2) Maximum consumption obtained at room temperature = 43°C, according to UNE climate classification, Class T
(TROPICALISED).
NOTE: Expansion controlled by capillary.

Granular Ice Technical Service Manual
12
COD: IQ02_404MTIN.DOC
2. SPECIFICATIONS
2.1. Installation diagrams for inlet/outlet tubes and dimensions
2.2. Consumption data, weights, crated dimensions and volumes
PANEL ICETECH CD 50
Green led: Shows that the machine is activated. The machine might be stopped by the stock
thermostat.
Black button: Starts the machine.
Red button: Stops the machine.

Granular Ice Technical Service Manual
13
COD: IQ02_404MTIN.DOC
PANEL ICETECH CD 90
Green button: Starts the machine. It is indicated with the led on.
Red led: Shows that the machine is stopped by the security element.
Orange led: Shows that the bin is full.

Granular Ice Technical Service Manual
14
COD: IQ02_404MTIN.DOC
TECHNICAL DATA
(1) Data obtained at room temperature (20°C), water introduced at 15°C; water quality = 500ppm
MODEL
CONSUMPTION
CONSUMPTION
NET
PACKING
GROSS
VOLUME
WATER COND.
WATER COND.
WEIGHT
DIMENSIONS
WEIGHT
L/Hour (1)
L/Hour (1)
(KG)
X*Y*Z
(KG)
(M3)
GR 220 A
8.5
52
600x630x650
60
0.23
GR 220 W
60
8.5
50
600x630x650
58
0.23
GR 400 A
16
85
750X650X750
94
0.33
GR 400 W
114
16
85
750X650X750
89
0.33
GR 560 A
25
95
750x650x900
115
0.39
GR 560 W
177
25
93
750x650x900
113
0.39
MODEL
CARG
A
HIGH PRESSURE
LOW
INTENS.TOTA
L
FUSE
POWER
POWER
REFRI
.
PRESSURE
SECURITY
COMPRES
SOR
TOTAL
ABSORBED
404ª
MÍNIMUM
MÁXIMUM
MEDIUM
-2
-1
-2
(GR)
Kg/cm2
Psi
Kg/cm2
Psi
Kg/cm2
Psi
(A)
(A)
(W)
(W)
GR220A
430
16
228
17
242
2.5
33.4
4.6
16
550
950
GR220W
400
16
228
17
242
2.5
33.4
4.6
16
440
800
GR400A
630
16
228
17
242
2.5
33.4
6
16
900
1250
GR400W
440
16
228
17
242
2.5
33.4
6
16
900
1250
GR560A
1050
16
228
17
242
2.5
33.4
10
20
1500
2000
GR560W
1050
16
228
17
242
2.5
33.4
10
20
1500
2000
Ice discharge slot.
Water trough overflow
MODEL
X
Y
Z
A
B
C
D
GR220
A/W
515
550
575
70
92
207
85
GR 560
A/W
675
550
800
70
92
227
89

Granular Ice Technical Service Manual
15
COD: IQ02_404MTIN.DOC
(2) Maximum consumption obtained at room temperature = 43°, according to UNE climate classification Class T (TROPICALISED).
NOTE: Expansion controlled by capillary, except for model GR 560 which is controlled by a thermostatic valve.
Models: GR 560 380V+III+N
NOTE: Expansion controlled by a thermostatic valve.
MODELO
CARG
A
HIGH PRESSURE
LOW
INTENS.TOTA
L
FUSE
POWER
POWER
REFRI.
PRESSURE
SECURITY
COMPRES
SOR
TOTAL
ABSORBED
404ª
MÍNIMUM
MÁXIMUM
MEDIUM
-2
-1
-2
(GR)
Kg/cm2
Psi
Kg/cm2
Psi
Kg/cm2
Psi
(A)
(A)
(W)
(W)
GR560A
1500
16
228
17
242
2.3
33.4
5
16
2200
2700
GR560W
1500
16
228
17
242
2.3
33.4
5
16
2200
2700
CD 90
Kg / 24h
AMBIENT °C
10
15
20
25
30
35
40
WATER °C
5
91
90
87
84
79
73
67
10
89
87
85
81
77
71
64
15
85
83
81
77
73
67
60
20
80
79
76
73
68
62
55
25
74
73
70
67
62
56
49
30
67
65
63
59
55
49
42
35
58
57
55
51
46
41
34

Granular Ice Technical Service Manual
16
COD: IQ02_404MTIN.DOC
2.3. Production tables for Ice Flakers
GR140A GR220A
45
104
102
96
92
86
82
78
40
119
114
111
102
98
95
94
35
134
124
118
115
110
106
102
30
136
134
123
120
111
109
106
25
139
135
126
121
119
115
110
20
141
138
131
123
121
119
114
15
142
141
132
126
124
122
118
10
144
142
134
128
126
124
120
5
10
15
20
25
30
35
GR 400A GR 560A
45
192
184
168
156
144
138
118
40
198
192
184
169
155
143
136
35
204
196
190
176
168
154
142
30
207
204
194
188
174
168
154
25
210
206
202
191
187
174
167
20
213
209
205
201
190
186
173
15
221
211
208
205
200
190
185
10
224
220
211
208
204
198
188
5
10
15
20
25
30
35
45
330
325
310
300
280
251
232
40
352
342
334
324
306
275
255
35
370
360
354
338
313
287
275
30
385
378
372
360
332
310
300
25
400
395
378
360
343
325
308
20
410
405
387
365
354
335
315
15
418
409
400
375
365
346
326
10
430
420
412
395
380
360
340
5
10
15
20
25
30
35
45
470
450
420
400
370
360
345
40
500
480
454
430
405
390
375
35
520
510
490
455
435
425
405
30
600
566
538
510
480
465
455
25
611
568
549
522
500
486
471
20
622
570
560
535
515
498
482
15
626
589
567
540
520
502
488
10
630
608
575
545
525
506
495
5
10
15
20
25
30
35
A
M
B
I
E
N
T
T
E
M
P
E
R
A
T
U
R
E

Granular Ice Technical Service Manual
17
COD: IQ02_404MTIN.DOC
WATER TEMPERATURE ºC
Water quality = 500 ppm (240 Microhms/cm)
2.4. About Crushed-Ice production
IMPORTANT: Production figures have been obtained under the following conditions:
Water Quality: 550 ppm. total solids
Water Temperature: 15°C
Ambient Temperature: 20°C
Ice production and quality is heavily dependent on the following:
a) Ambient temperature
b) Water temperature
c) Water quality
d) Level of water in evaporator
The following graph illustrates variations in production according to these factors. As shown,
production decreases as water temperature increases.
IT IS IMPORTANT THAT WATER INTAKE TUBE IS NOT CLOSE TO ANY HEAT
SOURCE. THIS WILL AFFECT ICE PRODUCTION AND QUALITY.
• Ambient temperature should be taken 4cm away from the centre of the front grille
• Water temperature should be taken inside the water trough. Check that water line and filter
do not receive hot air from condenser + fan. If so, then re-direct water inlet line + filter to
avoid hot air current.
• Ice quality can be improved by lowering the position of the water trough. The trough is
attached to a panel with two screws. This panel has several slots, so that the trough can be
moved up or down as required.
• The trough may be lowered up to 80mm (GR 560). This will result in decrease of
production (see dotted line in graph below), but harder, drier ice.
• Water content in ice (obtained by straining ice) may be as much as 10%
• Ice production also decreases with improved water quality. (See graph for approximate
production variations).
Kg/Day

Granular Ice Technical Service Manual
18
COD: IQ02_404MTIN.DOC
10
15
20
25
30
35
40
45
Production Variations According to Water Quality
When Water Temperature is Maintained at 15°C.
Room temperature
* 1500 ppm
* 1000 ppm
* 500 ppm
* Level -60 mm
(500 ppm)
* 30 ppm
3. DELIVERY & UNPACKING
Upon receipt, thoroughly inspect the packing container. If there appears to be damage to the
container contact the shipper immediately. Unpack unit in the presence of delivery personnel
noting any damage on the waybill.
ITV packing bears the “Green Point” on all models according to the European Directives on
management of Packaging and Waste Disposal.
Be sure to include model name and serial number on all claims. Serial number is located in the
following three places:
(1) Packing
There is a label stuck onto the cardboard packing bearing this serial number (1).
(2) Machine body
On the back of the machine (1).
(3) Rating plate and serial number
Located at the back of the machine.
Water cooled machines: check that the drainage hose at the back of the
machine is in good condition.
Verify that the installation kit is inside the bin, and has the following
pieces: scoop, 3/4’ water hose, two small filters and user manual.
In all models there is a large particle filter (5 micres) with accessories,
and an ice dispersion cone.

Granular Ice Technical Service Manual
19
COD: IQ02_404MTIN.DOC
WARNING: DO NOT LEAVE PACKING MATERIALS (PLASTIC BAGS, CARDBOARD
BOXES, ETC.) WITHIN REACH OF CHILDREN.
4. INSTALLATION
4.1. Recommended placement of unit
IMPORTANT!
ICETECH machines are intended to operate at room temperature between 5°C and 43°C and
with water temperature ranging between 5°C and 35°C. You may encounter evaporator/gearbox
malfunctions should the machine run at temperatures below the recommended minimum. When
running above maximum recommended temperatures you can expect shorter compressor life
and decreased production.
Air-cooled units receive air input via front of machine and expel air through rear grille.
IMPORTANT!
If front and/or rear ventilation is inadequate, obstructed, or in close proximity to other heat
producing machinery, use of a water-cooled unit is strongly recommended.
The above mentioned also applies should unit be installed in an area where dust, smoke, or
other airborne pollutants may be present. Units—especially air-cooled ones—should not be
installed in kitchens. To facilitate access to condenser and/or water pressure valve, allow
sufficient space at front of the machine. Ensure that flooring is firm and even.

Granular Ice Technical Service Manual
20
COD: IQ02_404MTIN.DOC
4.2. Water and Drainage
Water quality influences ice hardness, flavour, and quality as well as condenser life.
Keep in mind the following points:
a) WATER IMPURITIES: Major impurities are eliminated by the two small wire mesh filters
provided and installed on either end of the water inlet hose. Filters should be cleaned/replaced
regularly depending on purity of water. For minor impurities we recommend installing a 5-micron
filter such as the one provided with the unit: Part # ITV 207499. This filter will need to be
replaced only when machine stops due to insufficient water flow (filter is obstructed with
impurities).
b) WATER WITH MORE THAN 500 PPM: Ice will be less hard and tend to adhere. Lime
deposits may impede proper function. In water-cooled models, condenser obstruction is likely.
Installation of a high quality water softener is recommended.
c) CHLORINATED WATER: In most cases the filter which is included in the machine should be
sufficient. However, if mains water smells or tastes of bleach, this indicates an excess of
chlorine, which may eventually corrode the stainless steel auger. A carbon filter will remove
chlorine in water (average filter life: 6 months), not included with machine. (Part # ITV 207509).
(NOTE: You may encounter water with ALL aforementioned properties.)
d) PURIFIED WATER: A 10% reduction in overall production may occur.
4.3. Connecting unit to water source (water-cooler units)
• Use 1.3 m. flexible tube (with the two filters attached) provided. NOTE: We advise using a
single faucet fixture.
• Water pressure should be between 0.7 and 6 Kgs/cm2. (10/85 Psi.)
• If water pressure exceeds these values, installation of appropriate corrective units will be
necessary.
• It is important that water tubing does not come close to or in contact with any heat sources
or heat generated by unit as this could decrease production.
4.4. Connecting unit to drain (water-cooled models)
• Drain must be located at least 150mm below machine level. Drain tube must have an inner
diameter of 30mm and a minimum gradient of 3 cm per metre.(3%)
