INSTALLATION
Unpacking
Remove packaging materials
IMPORTANT: Do not remove any permanent instruction labels or the data label on your ICER-ETTETM.
Remove tape and glue from your ICER-ETTETM before using.
• To remove any remaining tape or glue, rub the area briskly with your thumb. Tape or glue
residue can also be easily removed by rubbing a small amount of liquid dish soap over the
adhesive with your fingers. Wipe with warm water and dry.
• Do not use sharp instruments, rubbing alcohol, flammable fluids, or abrasive cleaners to
remove tape or glue. These products can damage the surface of your ICER-ETTETM.
Cleaning before use
Excessive Weight Hazard
Use two or more people to move and install ICER-ETTETM.
Failure to do so can result in back or other injury.
After you remove all of the packaging materials, clean the inside of your ICER-ETTETM before using it.
Location requirements:
Required Cabinet Opening : 14 1/4”(362mm) W x 24 5/8”(626mm) H for B Model
• If unit is to be built-in, 3/4”(2cm) or more must be allowed
behind the unit for water line and plug clearance for proper
operation. Built-in units are designed for zero clearance at
the top and each side of the unit. Fan-forced condenser
cooling is used. This requires air circulation through lower
section of unit(see FIG 4).
CAUTION:
FIG 4
WARNING: This device does not meet Federal requirement
for ignition protection. DON'T install, in spaces containing
gasoline engines, fuel tanks or fuel line fittings. Failure to
comply could result in accidental injury or death.
1. Air path for exhaust and fresh air intake must
be unrestricted! Recirculation between fresh air intake
and exhaust air must be prevented.
2. Any restriction of airflow or ventilation will disrupt
normal operation of the unit, resulting in damage to
components and voids warranty.
L588 1222 jlc
15 1/8”(384mm) W x 24 5/8”(626mm) H for F Model
PN:1866566205
•Choose a well ventilated area. This unit MUST be installed in a location protected from the elements, such rain, water
spray or drips.
•The unit should not be located next to ovens, grills or other high heat sources.
•When installing the unit it should be noted that some servicing requires access to the rear of the unit and that the unit
must be readily removable should servicing be necessary.
•Units are designed to operate between 50℉ (10℃) and 100℉(38℃). High ambient temperatures (100℉/38℃ or
higher) may reduce Ice production rate. For best performance, keep the unit out of direct sunlight and away from heat
generating equipment.
•Unit must sit on a secure level surface. Mounting flange must NOT be used to support the unit’s weight. It is important
for the ICER-ETTETM to be leveled in order to work properly. If needed, you can adjust the height of the ICER-ETTETM
by revolving the rubber feet.
•When mounting unit within cabinetry, make sure that the door has the desired range of motion. All doors are hinged on
the right(facing the unit) but may be reversed in the field.
