Icom IC-PW1 User manual

SERVICE MANUAL
ADDENDUM
CONTENTS
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BOARD LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Jun. 2010

Jun. 2010
1
SECTION 5
.
PARTS LIST
[FRONT UNIT]
REF ORDER DESCRIPTION
NO. NO.
DS1 5080000380 LAM HRS-4160A-H9 L150
DS2 5080000380 LAM HRS-4160A-H9 L150
ME1 5510000470 MET ME-39 (KL-293S-09) EX1900
ME2 5510000460 MET ME-38 (KL-293S-8B) EX1900
EP1 6910011040 TUB A-4210-G20
EP2 6910011040 TUB A-4210-G20
S.=Surface mount
[SW UNIT]
REF ORDER DESCRIPTION
NO. NO.
IC1 1130007700 S.IC BU4094BCF-E2
IC2 1130007700 S.IC BU4094BCF-E2
IC3 1130007700 S.IC BU4094BCF-E2
IC4 1130007700 S.IC BU4094BCF-E2
IC5 1110003690 S.IC M62354GP 75EC
IC6 1180001072 S.IC TA7805F(TE16L1,NQ)
IC7 1130004670 S.IC BU4021BF-E2
IC8 1130007261 S.IC TC7W74FU(TE12L,F)
IC9 1130005821 S.IC TC4S584F(TE85R,F)
IC11 1130007301 S.IC TC4W66FU(TE12L,F)
Q1 1590002310 S.TRA DTC114EE TL
Q2 1590002310 S.TRA DTC114EE TL
Q3 1590002310 S.TRA DTC114EE TL
Q4 1590002310 S.TRA DTC114EE TL
Q5 1590002310 S.TRA DTC114EE TL
Q6 1590002310 S.TRA DTC114EE TL
Q7 1590002310 S.TRA DTC114EE TL
Q8 1590002310 S.TRA DTC114EE TL
Q9 1590002310 S.TRA DTC114EE TL
Q10 1590002310 S.TRA DTC114EE TL
Q11 1590002310 S.TRA DTC114EE TL
Q12 1590002310 S.TRA DTC114EE TL
Q13 1590002310 S.TRA DTC114EE TL
Q14 1590002310 S.TRA DTC114EE TL
Q15 1590002310 S.TRA DTC114EE TL
Q16 1590002310 S.TRA DTC114EE TL
Q17 1590002310 S.TRA DTC114EE TL
Q18 1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q19 1590002310 S.TRA DTC114EE TL
Q20 1590002310 S.TRA DTC114EE TL
Q21 1590002310 S.TRA DTC114EE TL
Q22 1590002310 S.TRA DTC114EE TL
Q23 1590002310 S.TRA DTC114EE TL
Q24 1590002310 S.TRA DTC114EE TL
Q25 1590002310 S.TRA DTC114EE TL
Q26 1590002310 S.TRA DTC114EE TL
Q27 1590002310 S.TRA DTC114EE TL
Q31 1590001940 S.TRA DTC144EE TL
Q32 1520000460 S.TRA 2SB1132 T100 R
D1 1750000271 S.DIO 1SS301(TE85L,F)
D2 1750000271 S.DIO 1SS301(TE85L,F)
D3 1750000291 S.DIO 1SS300(TE85R,F)
D4 1750000291 S.DIO 1SS300(TE85R,F)
D5 1730002321 S.ZEN MAZ8051GML
D6 1750000271 S.DIO 1SS301(TE85L,F)
D7 1750000291 S.DIO 1SS300(TE85R,F)
D10 1750000231 S.DIO 1SS315(TPH3,F)
D11 1750000231 S.DIO 1SS315(TPH3,F)
D13 1750000291 S.DIO 1SS300(TE85R,F)
D16 1750000271 S.DIO 1SS301(TE85L,F)
L1 6200003261 S.COI NLV32T-101J
L2 6200003261 S.COI NLV32T-101J
L3 6200003261 S.COI NLV32T-101J
L4 6200003261 S.COI NLV32T-101J
L5 6200003950 S.COI HF50ACC 322513-T
L6 6200003950 S.COI HF50ACC 322513-T
L7 6200003261 S.COI NLV32T-101J
L8 6200003261 S.COI NLV32T-101J
L9 6200003950 S.COI HF50ACC 322513-T
R1 7030003340 S.RES ERJ3GEYJ 151 V (150)
R2 7030003340 S.RES ERJ3GEYJ 151 V (150)
R3 7030003340 S.RES ERJ3GEYJ 151 V (150)
R4 7030009220 S.RES ERJ12YJ561U
R5 7030003340 S.RES ERJ3GEYJ 151 V (150)
R6 7030003340 S.RES ERJ3GEYJ 151 V (150)
R7 7030003340 S.RES ERJ3GEYJ 151 V (150)
R8 7030009220 S.RES ERJ12YJ561U
R9 7030003340 S.RES ERJ3GEYJ 151 V (150)
R10 7030003340 S.RES ERJ3GEYJ 151 V (150)
R11 7030003340 S.RES ERJ3GEYJ 151 V (150)
R12 7030003340 S.RES ERJ3GEYJ 151 V (150)
R13 7030003340 S.RES ERJ3GEYJ 151 V (150)
R14 7030003340 S.RES ERJ3GEYJ 151 V (150)
R15 7030003340 S.RES ERJ3GEYJ 151 V (150)
R16 7030003340 S.RES ERJ3GEYJ 151 V (150)
R17 7030003340 S.RES ERJ3GEYJ 151 V (150)
R18 7030003340 S.RES ERJ3GEYJ 151 V (150)
R19 7030003340 S.RES ERJ3GEYJ 151 V (150)
R20 7030003340 S.RES ERJ3GEYJ 151 V (150)
R21 7030003340 S.RES ERJ3GEYJ 151 V (150)
R22 7030003340 S.RES ERJ3GEYJ 151 V (150)
R23 7030003340 S.RES ERJ3GEYJ 151 V (150)
R24 7030003340 S.RES ERJ3GEYJ 151 V (150)
R25 7030009220 S.RES ERJ12YJ561U
R26 7030003340 S.RES ERJ3GEYJ 151 V (150)
R27 7030003340 S.RES ERJ3GEYJ 151 V (150)
R29 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R30 7030008190 S.RES ERJ12YJ330U (33)
R31 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R32 7030003640 S.RES ERJ3GEYJ 473 V (47K)

Jun. 2010
2
[SW UNIT]
REF ORDER DESCRIPTION
NO. NO.
R33 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R34 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R35 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R36 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R37 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R38 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R39 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R40 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R41 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R42 7030006060 S.RES ERJ12YJ100U (10)
R43 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R44 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R45 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R46 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R47 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R48 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R51 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R52 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R53 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R54 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R55 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R56 7310005540 S.TRI TMC3ADC14X (10K)
R57 7310005540 S.TRI TMC3ADC14X (10K)
R58 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R59 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R60 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R61 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R62 7030009170 S.RES ERJ1WYJ1R5U (1.5)
R63 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R65 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R66 7030003550 S.RES ERJ3GEYJ 822 V (8.2K)
R67 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
W1 7030003860 S.RES ERJ3GE JPW V
W3 7030003860 S.RES ERJ3GE JPW V
W4 7030003860 S.RES ERJ3GE JPW V
W5 7030003860 S.RES ERJ3GE JPW V
W6 7030003860 S.RES ERJ3GE JPW V
C1 4030011600 S.CER C1608 JB 1E 104K-T
C2 4030011600 S.CER C1608 JB 1E 104K-T
C3 4030011600 S.CER C1608 JB 1E 104K-T
C4 4030011600 S.CER C1608 JB 1E 104K-T
C5 4030011600 S.CER C1608 JB 1E 104K-T
C6 4510008530 S.ELE EEE1HA2R2SR
C7 4030011600 S.CER C1608 JB 1E 104K-T
C8 4510008820 S.ELE EEE1CA330WR
C9 4030011600 S.CER C1608 JB 1E 104K-T
C10 4030011600 S.CER C1608 JB 1E 104K-T
C11 4510008540 S.ELE EEE1CA100SR
C16 4030006880 S.CER C1608 JB 1H 472K-T
C17 4030006880 S.CER C1608 JB 1H 472K-T
C18 4030011600 S.CER C1608 JB 1E 104K-T
C19 4510008490 S.ELE EEE1CS100SR
C20 4030011600 S.CER C1608 JB 1E 104K-T
C21 4030011600 S.CER C1608 JB 1E 104K-T
C24 4030011600 S.CER C1608 JB 1E 104K-T
C25 4030006860 S.CER C1608 JB 1H 102K-T
C26 4030006860 S.CER C1608 JB 1H 102K-T
C27 4030006860 S.CER C1608 JB 1H 102K-T
C28 4030006860 S.CER C1608 JB 1H 102K-T
C29 4030008920 S.CER C1608 JB 1H 473K-T
C30 4030008920 S.CER C1608 JB 1H 473K-T
C31 4030006860 S.CER C1608 JB 1H 102K-T
C32 4030006860 S.CER C1608 JB 1H 102K-T
C33 4510008540 S.ELE EEE1CA100SR
C34 4030006860 S.CER C1608 JB 1H 102K-T
C35 4030006880 S.CER C1608 JB 1H 472K-T
C36 4030008920 S.CER C1608 JB 1H 473K-T
C38 4030011600 S.CER C1608 JB 1E 104K-T
J1 6510003461 CON B10B-EH-S(LF)(SN)
J2 6910005801 CON IMSA-9210B-1-03ZA043-PT1
P1 6910007600 CON IMSA-9215H-T
DS1 5040002080 S.LED CL-200YG-C-TU
DS2 5040002080 S.LED CL-200YG-C-TU
DS3 5040002080 S.LED CL-200YG-C-TU
DS4 5040002080 S.LED CL-200YG-C-TU
DS5 5040002080 S.LED CL-200YG-C-TU
DS6 5040002080 S.LED CL-200YG-C-TU
DS7 5040002080 S.LED CL-200YG-C-TU
DS8 5040001870 S.LED SEC 2462C
DS9 5040002010 S.LED CL-170PG-CD-T
DS10 5040002010 S.LED CL-170PG-CD-T
DS11 5040002010 S.LED CL-170PG-CD-T
DS12 5040002010 S.LED CL-170PG-CD-T
DS13 5040002010 S.LED CL-170PG-CD-T
DS14 5040002010 S.LED CL-170PG-CD-T
DS15 5040002010 S.LED CL-170PG-CD-T
DS16 5040002010 S.LED CL-170PG-CD-T
DS17 5040002010 S.LED CL-170PG-CD-T
DS18 5040002080 S.LED CL-200YG-C-TU
DS19 5040002080 S.LED CL-200YG-C-TU
DS20 5040002010 S.LED CL-170PG-CD-T
DS21 5040002010 S.LED CL-170PG-CD-T
DS22 5040002080 S.LED CL-200YG-C-TU
DS23 5040002080 S.LED CL-200YG-C-TU
S.=Surface mount
[SW UNIT]
REF ORDER DESCRIPTION
NO. NO.
DS24 5040002080 S.LED CL-200YG-C-TU
DS26 5040002080 S.LED CL-200YG-C-TU
DS27 5040002080 S.LED CL-200YG-C-TU
S1 2260001890 S.SWI SKQDPA
S2 2260001890 S.SWI SKQDPA
S3 2260001890 S.SWI SKQDPA
S4 2260001890 S.SWI SKQDPA
S5 2260001890 S.SWI SKQDPA
S6 2260001890 S.SWI SKQDPA
S7 2260001890 S.SWI SKQDPA
S8 2260001890 S.SWI SKQDPA
S9 2260001890 S.SWI SKQDPA

Jun. 2010
3
[PA UNIT]
REF ORDER DESCRIPTION
NO. NO.
Q1 1560001212 FET MRF150.(SRFJ150MP)-1 <M/A>
Q2 1560001212 FET MRF150.(SRFJ150MP)-1 <M/A>
Q3 1560001212 FET MRF150.(SRFJ150MP)-1 <M/A>
Q4 1560001212 FET MRF150.(SRFJ150MP)-1 <M/A>
MF1 2710000620 FAN PUDC12Z4-992
MF2 2710000620 FAN PUDC12Z4-992
MF3 2710000620 FAN PUDC12Z4-992
W1 8900014730 CAB OPC-683A (P1,N10,L110) <TJM>
W2 8900017720 CAB OPC-711A (P1,N10,L250) <TJM>
W3 8900014730 CAB OPC-683A (P1,N10,L110) <TJM>
W4 8900017720 CAB OPC-711A (P1,N10,L250) <TJM>
S.=Surface mount
[PA–1 UNIT]
REF ORDER DESCRIPTION
NO. NO.
D1 1750000271 S.DIO 1SS301(TE85L,F)
D2 1750000271 S.DIO 1SS301(TE85L,F)
D3 1750000271 S.DIO 1SS301(TE85L,F)
D4 1750000271 S.DIO 1SS301(TE85L,F)
L1 6110001730 COI LA-262
L2 6140003040 COI LR-322B
L3 6140002590 COI LR-296 (TR18X8X8 D12A)
L4 6140000720 COI LR-95
L5 6180000900 COI LAL 03NA 101K
L6 6180000900 COI LAL 03NA 101K
L7 6140002030 COI LR-230 (SK-10M-15Y 120)
L9 6200003261 S.COI NLV32T-101J
L11 6200003950 S.COI HF50ACC 322513-T
R2 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R4 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R5 7070000890 RES ERG3SJ 150 (15)
R6 7070000890 RES ERG3SJ 150 (15)
R7 7030006140 S.RES ERJ1WYJ560U (56)
R8 7030006140 S.RES ERJ1WYJ560U (56)
R9 7310005210 TRI VM5CK-PVB 20K
R10 7310005210 TRI VM5CK-PVB 20K
R11 7070001010 RES ERG3SJ 120 (12)
R12 7070001010 RES ERG3SJ 120 (12)
R15 7070000960 RES ERG3SJ 561 (560)
R16 7080001300 RES ERG3SJ 270 (27)
R17 7070000940 RES ERG3SJ 331 (330)
R18 7070000890 RES ERG3SJ 150 (15)
R19 7070000890 RES ERG3SJ 150 (15)
R20 7070000930 RES ERG3SJ 330 (33)
R21 7070001000 RES ERG3SJ 821 (820)
R23 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R24 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R25 7070001010 RES ERG3SJ 120 (12)
W6 7030003860 S.RES ERJ3GE JPW V
C1 4010005740 CER HM60SJ SL 560J 500V
C3 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C4 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C11 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C13 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C16 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C17 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C18 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C19 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C23 4510006830 ELE 63 ME 470CZ
C24 4510006830 ELE 63 ME 470CZ
C25 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C26 4030003410 S.CER GRM319B11H473KA01D (GRM42-6)
C27 4030018770 S.CER C3216 CH 2J 102J-T
C29 4030011600 S.CER C1608 JB 1E 104K-T
C35 4030011600 S.CER C1608 JB 1E 104K-T
C37 4030011600 S.CER C1608 JB 1E 104K-T
C40 4030011600 S.CER C1608 JB 1E 104K-T
C41 4030011600 S.CER C1608 JB 1E 104K-T
C42 4030006900 S.CER C1608 JB 1H 103K-T
C43 4030006860 S.CER C1608 JB 1H 102K-T
C44 4030011600 S.CER C1608 JB 1E 104K-T
C45 4030006900 S.CER C1608 JB 1H 103K-T
C46 4030006860 S.CER C1608 JB 1H 102K-T
C51 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C52 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C55 4030011600 S.CER C1608 JB 1E 104K-T
C56 4030006880 S.CER C1608 JB 1H 472K-T
C57 4030006880 S.CER C1608 JB 1H 472K-T
C58 4030011740 S.CER GRM32N2C2H201JV01L(GRM42-2 CH)
J2 6510017920 CON 1811P342
J3 6510019971 S.CON 52808-1071
J4 6510019971 S.CON 52808-1071
J5 6510003391 CON B03B-EH-S(LF)(SN)
W2 9008503023 JUM 74/98/060/X98/X98
EP1 6910011330 TER OT-009 M3
EP2 6910011330 TER OT-009 M3
EP3 6910000640 BEA FSRH090160RN000B (FSOH090RN)

Jun. 2010
4
[PA-2 UNIT]
REF ORDER DESCRIPTION
NO. NO.
D1 1750000271 S.DIO 1SS301(TE85L,F)
D2 1750000271 S.DIO 1SS301(TE85L,F)
D3 1750000271 S.DIO 1SS301(TE85L,F)
D4 1750000271 S.DIO 1SS301(TE85L,F)
L1 6110001730 COI LA-262
L2 6140003040 COI LR-322B
L3 6140002590 COI LR-296 (TR18X8X8 D12A)
L4 6140000720 COI LR-95
L5 6180000900 COI LAL 03NA 101K
L6 6180000900 COI LAL 03NA 101K
L7 6140002030 COI LR-230 (SK-10M-15Y 120)
L9 6200003261 S.COI NLV32T-101J
L11 6200003950 S.COI HF50ACC 322513-T
R2 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R4 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R5 7070000890 RES ERG3SJ 150 (15)
R6 7070000890 RES ERG3SJ 150 (15)
R7 7030006140 S.RES ERJ1WYJ560U (56)
R8 7030006140 S.RES ERJ1WYJ560U (56)
R9 7310005210 TRI VM5CK-PVB 20K
R10 7310005210 TRI VM5CK-PVB 20K
R11 7070001010 RES ERG3SJ 120 (12)
R12 7070001010 RES ERG3SJ 120 (12)
R15 7070000960 RES ERG3SJ 561 (560)
R16 7080001300 RES ERG3SJ 270 (27)
R17 7070000940 RES ERG3SJ 331 (330)
R18 7070000890 RES ERG3SJ 150 (15)
R19 7070000890 RES ERG3SJ 150 (15)
R20 7070000930 RES ERG3SJ 330 (33)
R21 7070001000 RES ERG3SJ 821 (820)
R23 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R24 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R25 7070001010 RES ERG3SJ 120 (12)
W6 7030003860 S.RES ERJ3GE JPW V
C1 4010005740 CER HM60SJ SL 560J 500V
C3 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C4 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C11 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C13 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C16 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C17 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C18 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C19 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C23 4510006830 ELE 63 ME 470CZ
C24 4510006830 ELE 63 ME 470CZ
C25 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C26 4030003410 S.CER GRM319B11H473KA01D (GRM42-6)
C27 4030018770 S.CER C3216 CH 2J 102J-T
C29 4030011600 S.CER C1608 JB 1E 104K-T
C35 4030011600 S.CER C1608 JB 1E 104K-T
C37 4030011600 S.CER C1608 JB 1E 104K-T
C40 4030011600 S.CER C1608 JB 1E 104K-T
C41 4030011600 S.CER C1608 JB 1E 104K-T
C42 4030006900 S.CER C1608 JB 1H 103K-T
C43 4030006860 S.CER C1608 JB 1H 102K-T
C44 4030011600 S.CER C1608 JB 1E 104K-T
C45 4030006900 S.CER C1608 JB 1H 103K-T
C46 4030006860 S.CER C1608 JB 1H 102K-T
C51 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C52 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C55 4030011600 S.CER C1608 JB 1E 104K-T
C56 4030006880 S.CER C1608 JB 1H 472K-T
C57 4030006880 S.CER C1608 JB 1H 472K-T
C58 4030011740 S.CER GRM32N2C2H201JV01L(GRM42-2 CH)
J2 6510017920 CON 1811P342
J3 6510019971 S.CON 52808-1071
J4 6510019971 S.CON 52808-1071
J5 6510003391 CON B03B-EH-S(LF)(SN)
W2 9008503023 JUM 74/98/060/X98/X98
EP1 6910011330 TER OT-009 M3
EP2 6910011330 TER OT-009 M3
EP3 6910000640 BEA FSRH090160RN000B (FSOH090RN)
S.=Surface mount
[PA-3 UNIT]
REF ORDER DESCRIPTION
NO. NO.
D1 1750000271 S.DIO 1SS301(TE85L,F)
D2 1750000271 S.DIO 1SS301(TE85L,F)
D3 1750000271 S.DIO 1SS301(TE85L,F)
D4 1750000271 S.DIO 1SS301(TE85L,F)
L1 6110001730 COI LA-262
L2 6140003040 COI LR-322B
L3 6140002590 COI LR-296 (TR18X8X8 D12A)
L4 6140000720 COI LR-95
L5 6180000900 COI LAL 03NA 101K
L6 6180000900 COI LAL 03NA 101K
L7 6140002030 COI LR-230 (SK-10M-15Y 120)
L9 6200003261 S.COI NLV32T-101J
L11 6200003950 S.COI HF50ACC 322513-T
R2 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R4 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R5 7070000890 RES ERG3SJ 150 (15)
R6 7070000890 RES ERG3SJ 150 (15)
R7 7030006140 S.RES ERJ1WYJ560U (56)
R8 7030006140 S.RES ERJ1WYJ560U (56)
R9 7310005210 TRI VM5CK-PVB 20K
R10 7310005210 TRI VM5CK-PVB 20K
R11 7070001010 RES ERG3SJ 120 (12)
R12 7070001010 RES ERG3SJ 120 (12)
R15 7070000960 RES ERG3SJ 561 (560)
R16 7080001300 RES ERG3SJ 270 (27)
R17 7070000940 RES ERG3SJ 331 (330)
R18 7070000890 RES ERG3SJ 150 (15)
R19 7070000890 RES ERG3SJ 150 (15)
R20 7070000930 RES ERG3SJ 330 (33)
R21 7070001000 RES ERG3SJ 821 (820)
R23 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R24 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R25 7070001010 RES ERG3SJ 120 (12)
W6 7030003860 S.RES ERJ3GE JPW V
C1 4010005740 CER HM60SJ SL 560J 500V
C3 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C4 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C11 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C13 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C16 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C17 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C18 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C19 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C23 4510006830 ELE 63 ME 470CZ
C24 4510006830 ELE 63 ME 470CZ
C25 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C26 4030003410 S.CER GRM319B11H473KA01D (GRM42-6)
C27 4030018770 S.CER C3216 CH 2J 102J-T
C29 4030011600 S.CER C1608 JB 1E 104K-T
C35 4030011600 S.CER C1608 JB 1E 104K-T
C37 4030011600 S.CER C1608 JB 1E 104K-T
C40 4030011600 S.CER C1608 JB 1E 104K-T
C41 4030011600 S.CER C1608 JB 1E 104K-T
C42 4030006900 S.CER C1608 JB 1H 103K-T
C43 4030006860 S.CER C1608 JB 1H 102K-T
C44 4030011600 S.CER C1608 JB 1E 104K-T
C45 4030006900 S.CER C1608 JB 1H 103K-T
C46 4030006860 S.CER C1608 JB 1H 102K-T
C51 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C52 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C55 4030011600 S.CER C1608 JB 1E 104K-T
C56 4030006880 S.CER C1608 JB 1H 472K-T
C57 4030006880 S.CER C1608 JB 1H 472K-T
C58 4030011740 S.CER GRM32N2C2H201JV01L(GRM42-2 CH)
J2 6510017920 CON 1811P342
J3 6510019971 S.CON 52808-1071
J4 6510019971 S.CON 52808-1071
J5 6510003391 CON B03B-EH-S(LF)(SN)
W2 9008503023 JUM 74/98/060/X98/X98
EP1 6910011330 TER OT-009 M3
EP2 6910011330 TER OT-009 M3
EP3 6910000640 BEA FSRH090160RN000B (FSOH090RN)

Jun. 2010
5
[PA-4 UNIT]
REF ORDER DESCRIPTION
NO. NO.
D1 1750000271 S.DIO 1SS301(TE85L,F)
D2 1750000271 S.DIO 1SS301(TE85L,F)
D3 1750000271 S.DIO 1SS301(TE85L,F)
D4 1750000271 S.DIO 1SS301(TE85L,F)
L1 6110001730 COI LA-262
L2 6140003040 COI LR-322B
L3 6140002590 COI LR-296 (TR18X8X8 D12A)
L4 6140000720 COI LR-95
L5 6180000900 COI LAL 03NA 101K
L6 6180000900 COI LAL 03NA 101K
L7 6140002030 COI LR-230 (SK-10M-15Y 120)
L9 6200003261 S.COI NLV32T-101J
L11 6200003950 S.COI HF50ACC 322513-T
R2 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R4 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R5 7070000890 RES ERG3SJ 150 (15)
R6 7070000890 RES ERG3SJ 150 (15)
R7 7030006140 S.RES ERJ1WYJ560U (56)
R8 7030006140 S.RES ERJ1WYJ560U (56)
R9 7310005210 TRI VM5CK-PVB 20K
R10 7310005210 TRI VM5CK-PVB 20K
R11 7070001010 RES ERG3SJ 120 (12)
R12 7070001010 RES ERG3SJ 120 (12)
R15 7070000960 RES ERG3SJ 561 (560)
R16 7080001300 RES ERG3SJ 270 (27)
R17 7070000940 RES ERG3SJ 331 (330)
R18 7070000890 RES ERG3SJ 150 (15)
R19 7070000890 RES ERG3SJ 150 (15)
R20 7070000930 RES ERG3SJ 330 (33)
R21 7070001000 RES ERG3SJ 821 (820)
R23 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R24 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R25 7070001010 RES ERG3SJ 120 (12)
W6 7030003860 S.RES ERJ3GE JPW V
C1 4010005740 CER HM60SJ SL 560J 500V
C3 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C4 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C11 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C13 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C16 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C17 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C18 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C19 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C23 4510006830 ELE 63 ME 470CZ
C24 4510006830 ELE 63 ME 470CZ
C25 4030006480 S.CER GRM319B11H104KA01D (GRM42-6)
C26 4030003410 S.CER GRM319B11H473KA01D (GRM42-6)
C27 4030018770 S.CER C3216 CH 2J 102J-T
C29 4030011600 S.CER C1608 JB 1E 104K-T
C35 4030011600 S.CER C1608 JB 1E 104K-T
C37 4030011600 S.CER C1608 JB 1E 104K-T
C40 4030011600 S.CER C1608 JB 1E 104K-T
C41 4030011600 S.CER C1608 JB 1E 104K-T
C42 4030006900 S.CER C1608 JB 1H 103K-T
C43 4030006860 S.CER C1608 JB 1H 102K-T
C44 4030011600 S.CER C1608 JB 1E 104K-T
C45 4030006900 S.CER C1608 JB 1H 103K-T
C46 4030006860 S.CER C1608 JB 1H 102K-T
C51 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C52 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C55 4030011600 S.CER C1608 JB 1E 104K-T
C56 4030006880 S.CER C1608 JB 1H 472K-T
C57 4030006880 S.CER C1608 JB 1H 472K-T
C58 4030011740 S.CER GRM32N2C2H201JV01L(GRM42-2 CH)
J2 6510017920 CON 1811P342
J3 6510019971 S.CON 52808-1071
J4 6510019971 S.CON 52808-1071
J5 6510003391 CON B03B-EH-S(LF)(SN)
W2 9008503023 JUM 74/98/060/X98/X98
EP1 6910011330 TER OT-009 M3
EP2 6910011330 TER OT-009 M3
EP3 6910000640 BEA FSRH090160RN000B (FSOH090RN)
S.=Surface mount
[SPLITR UNIT]
REF ORDER DESCRIPTION
NO. NO.
IC1 1180001252 S.IC TA7808F(TE16L1,NQ)
D1 1750000271 S.DIO 1SS301(TE85L,F)
D2 1750000271 S.DIO 1SS301(TE85L,F)
D3 1790000491 S.DIO HSM88ASTR-E
D4 1710000951 DIO RG3D-E3/51
D5 1710000951 DIO RG3D-E3/51
L1 6200003261 S.COI NLV32T-101J
L2 6140000970 COI LR-119
L3 6140000970 COI LR-119
L4 6140001001 COI LR-123A
L5 6180000900 COI LAL 03NA 101K
L6 6140001001 COI LR-123A
L7 6200003261 S.COI NLV32T-101J
L8 6200003261 S.COI NLV32T-101J
L9 6200003261 S.COI NLV32T-101J
L10 6200003261 S.COI NLV32T-101J
L11 6200003261 S.COI NLV32T-101J
R1 7070000591 RES ERG1SJ 333 (33K)
R2 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R3 7100000900 RES H-RWF7J 50
R4 7100000900 RES H-RWF7J 50
R5 7100000900 RES H-RWF7J 50
R6 7100000900 RES H-RWF7J 50
R7 7080001330 RES ERG3SJ 472 (4.7K)
R8 7030007550 S.RES ERJ8ENF 4700V (470)
R9 7030006180 S.RES ERJ1WYJ101U (100)
R10 7030006180 S.RES ERJ1WYJ101U (100)
R11 7030006070 S.RES ERJ12YJ101U (100)
R12 7030006070 S.RES ERJ12YJ101U (100)
R13 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R14 7030003590 S.RES ERJ3GEYJ 183 V (18K)
R15 7030003690 S.RES ERJ3GEYJ 124 V (120K)
R16 7510000140 THE ERT-D2FHL 802S
R17 7030003460 S.RES ERJ3GEYJ 152 V (1.5K)
R18 7030006210 S.RES ERJ12YJ4R7U (4.7)
R21 7030011310 S.RES ERJ1TY 271U (270)
C1 4030006880 S.CER C1608 JB 1H 472K-T
C2 4030011790 S.CER GRM55RF52A684ZD01L(GRM44-1)
C3 4030006880 S.CER C1608 JB 1H 472K-T
C4 4510009170 S.ELE EEE1HAR47NR
C5 4030006880 S.CER C1608 JB 1H 472K-T
C7 4030006960 S.CER C1608 CH 1H 050C-T
C8 4010006900 CER HE80SJ YB 472K 50V
C9 4510006880 ELE 100 ME 33 CZ
C10 4010006900 CER HE80SJ YB 472K 50V
C11 4010005740 CER HM60SJ SL 560J 500V
C14 4010005740 CER HM60SJ SL 560J 500V
C17 4010005740 CER HM60SJ SL 560J 500V
C18 4010005610 CER HM60SJ SL 100D 500V
C19 4010005690 CER HM60SJ SL 300J 500V
C20 4030011600 S.CER C1608 JB 1E 104K-T
C21 4030011600 S.CER C1608 JB 1E 104K-T
C22 4510008490 S.ELE EEE1CS100SR
C23 4030011600 S.CER C1608 JB 1E 104K-T
C24 4030011600 S.CER C1608 JB 1E 104K-T
C25 4510008490 S.ELE EEE1CS100SR
C26 4010005370 CER HM11SJ SL 331J 500V
RL1 6330001330 REL AG 201344
RL2 6330001530 REL NR-HD(5V) AE5349
J1 6510007020 CON TMP-J01X-V6
J2 6510007020 CON TMP-J01X-V6
J4 6510007020 CON TMP-J01X-V6
J5 6510007020 CON TMP-J01X-V6
J6 6510007020 CON TMP-J01X-V6
J7 6510007020 CON TMP-J01X-V6
J8 6510007020 CON TMP-J01X-V6
J11 6510019971 S.CON 52808-1071

Jun. 2010
6
[COMBINR UNIT]
REF ORDER DESCRIPTION
NO. NO.
D1 1710000041 DIO 1S953-AZ
D2 1710000041 DIO 1S953-AZ
D3 1710000041 DIO 1S953-AZ
L1 6140000970 COI LR-119
L2 6140000970 COI LR-119
L3 6140001950 COI LR-211
L5 6140004530 COI LR-512
R1 7070000830 RES ERG3SJ 101 (100)
R2 7070000830 RES ERG3SJ 101 (100)
R3 7010007450 RES PSD1/4 100
R4 7010003952 RES PSD1/4 10
R5 7010003952 RES PSD1/4 10
R6 7100000900 RES H-RWF7J 50
R7 7010007350 RES PSD1/4 4.7
R8 7010003971 RES PSD1/4 15
R9 7010003952 RES PSD1/4 10
R10 7010003952 RES PSD1/4 10
R11 7010007450 RES PSD1/4 100
C1 4020000990 CYL UP050 B 473K-NA-CZ
C2 4020000990 CYL UP050 B 473K-NA-CZ
C3 4010004790 CER DEC1X3J680JC4B (DE1210SL680J)
C4 4010004790 CER DEC1X3J680JC4B (DE1210SL680J)
C5 4010005110 CER DEC1X3J220JC4B (DE0910SL220J)
C6 4010005110 CER DEC1X3J220JC4B (DE0910SL220J)
C7 4030005050 S.CER C2012 CH 1H 331J-T
C8 4030005050 S.CER C2012 CH 1H 331J-T
J1 6510017920 CON 1811P342
J2 6510017920 CON 1811P342
J3 6510017920 CON 1811P342
J4 6510017920 CON 1811P342
EP1 6910011330 TER OT-009 M3
EP2 6910011330 TER OT-009 M3
S.=Surface mount
[TUNER UNIT]
REF ORDER DESCRIPTION
NO. NO.
C1 4620000170 VAR KA-150-18 150P
C2 4620000170 VAR KA-150-18 150P
MF1 2710000800 MOT MP24ZA
MF2 2710000800 MOT MP24ZA
MF3 2710000630 FAN FBA08T12HC
W1 8900015420 CAB OPC-1630
W2 8900015420 CAB OPC-1630
W5 9054500260 WIR 76/98/050/X98/X98
W6 9054500260 WIR 76/98/050/X98/X98
W7 9054500260 WIR 76/98/050/X98/X98

Jun. 2010
7
[DET UNIT]
REF ORDER DESCRIPTION
NO. NO.
IC1 1110006830 IC MC10H116PG
IC2 1110006820 IC MC10H125PG
IC3 1120002252 S.IC TC74ACT32F(F)
IC4 1120002242 S.IC TC74AC112F(F)
IC5 1180002900 REG NJM79L05L2A-#ZZZD
Q1 1560000871 S.FET 2SK515-T1B-A (X33)
D3 1790000620 S.DIO MA77(TX)
D4 1790000620 S.DIO MA77(TX)
D5 1790000620 S.DIO MA77(TX)
D6 1790000620 S.DIO MA77(TX)
D7 1750000271 S.DIO 1SS301(TE85L,F)
D8 1750000271 S.DIO 1SS301(TE85L,F)
D11 1710000981 DIO MBD701G
D12 1710000981 DIO MBD701G
D13 1790001531 DIO 1SS286-E
D14 1790001531 DIO 1SS286-E
L1 6180000960 COI LAL 03NA 102K
L3 6140002660 COI LR-299
L4 6180000960 COI LAL 03NA 102K
L5 6140002660 COI LR-299
L8 6180000990 COI LAL 04NA 101K
L9 6200003261 S.COI NLV32T-101J
L10 6200003261 S.COI NLV32T-101J
L11 6140002220 COI LR-270 (TR6X3X2 3A9)
L12 6180000990 COI LAL 04NA 101K
R1 7030003400 S.RES ERJ3GEYJ 471 V (470)
R2 7030000080 S.RES MCR10EZHJ 3.3 (3R3)
R3 7030003400 S.RES ERJ3GEYJ 471 V (470)
R4 7030008320 S.RES ERJ1WYJ6R8U (6.8)
R5 7030003400 S.RES ERJ3GEYJ 471 V (470)
R6 7030000080 S.RES MCR10EZHJ 3.3 (3R3)
R7 7030003400 S.RES ERJ3GEYJ 471 V (470)
R8 7030003280 S.RES ERJ3GEYJ 470 V (47)
R9 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R11 7030003280 S.RES ERJ3GEYJ 470 V (47)
R12 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R13 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R14 7030009330 S.RES ERJ1WYJ300U
R15 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R16 7030003800 S.RES ERJ3GEYJ 105 V (1M)
R17 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R18 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R19 7030003450 S.RES ERJ3GEYJ 122 V (1.2K)
R20 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R21 7030009330 S.RES ERJ1WYJ300U
C1 4010005570 CER HM60SJ SL 060D 500V
C2 4010005370 CER HM11SJ SL 331J 500V
C3 4010005370 CER HM11SJ SL 331J 500V
C4 4030006880 S.CER C1608 JB 1H 472K-T
C5 4030006880 S.CER C1608 JB 1H 472K-T
C6 4510008490 S.ELE EEE1CS100SR
C7 4030011600 S.CER C1608 JB 1E 104K-T
C8 4030006880 S.CER C1608 JB 1H 472K-T
C9 4010005740 CER HM60SJ SL 560J 500V
C10 4030011600 S.CER C1608 JB 1E 104K-T
C11 4030011600 S.CER C1608 JB 1E 104K-T
C12 4030006880 S.CER C1608 JB 1H 472K-T
C13 4030006880 S.CER C1608 JB 1H 472K-T
C14 4030006880 S.CER C1608 JB 1H 472K-T
C15 4010005540 CER HM60SJ SL 030C 500V
C16 4010005880 CER HM95SJ SL 271J 500V
C17 4010005850 CER HM95SJ SL 181J 500V
C18 4030006860 S.CER C1608 JB 1H 102K-T
C19 4010005780 CER HM60SJ SL 101J 500V
C20 4030006880 S.CER C1608 JB 1H 472K-T
C21 4030006860 S.CER C1608 JB 1H 102K-T
C22 4030006880 S.CER C1608 JB 1H 472K-T
C23 4030006860 S.CER C1608 JB 1H 102K-T
C24 4030006880 S.CER C1608 JB 1H 472K-T
C25 4030006880 S.CER C1608 JB 1H 472K-T
C26 4030006880 S.CER C1608 JB 1H 472K-T
C27 4030006880 S.CER C1608 JB 1H 472K-T
C29 4510008490 S.ELE EEE1CS100SR
C30 4030011600 S.CER C1608 JB 1E 104K-T
C33 4010005120 CER DEC1X3J270JC4B (DE0910SL270J)
C34 4030006880 S.CER C1608 JB 1H 472K-T
C35 4010005850 CER HM95SJ SL 181J 500V
C36 4030006900 S.CER C1608 JB 1H 103K-T
C37 4030011600 S.CER C1608 JB 1E 104K-T
C38 4030011600 S.CER C1608 JB 1E 104K-T
C39 4030006900 S.CER C1608 JB 1H 103K-T
C40 4030011600 S.CER C1608 JB 1E 104K-T
C41 4030011600 S.CER C1608 JB 1E 104K-T
C42 4010004760 CER DEC1X3J330JC4B (DE0910SL330J)
C43 4010008730 CER DEA1X3F180JCDB
C44 4510008490 S.ELE EEE1CS100SR
C45 4030006880 S.CER C1608 JB 1H 472K-T
W1 9040401001 JUM 74/98/050/X98/X98
W2 9040401001 JUM 74/98/050/X98/X98
EP5 6910011330 TER OT-009 M3
S.=Surface mount
[DET UNIT]
REF ORDER DESCRIPTION
NO. NO.
EP6 6910011330 TER OT-009 M3
EP7 6910011330 TER OT-009 M3
EP8 6910011330 TER OT-009 M3

Jun. 2010
8
[MAIN UNIT]
REF ORDER DESCRIPTION
NO. NO.
IC1 1110001340 S.IC NJM3403AM-TE1-#ZZZB
IC2 1110000960 S.IC NJM4558M-TE1-#FMZB
IC3 1110000960 S.IC NJM4558M-TE1-#FMZB
IC4 1110000960 S.IC NJM4558M-TE1-#FMZB
IC5 1180001072 S.IC TA7805F(TE16L1,NQ)
IC7 1130011081 S.IC R1EX24016ASA00A
IC8 1180001260 S.IC BA9700AF-T1
IC9 1110000960 S.IC NJM4558M-TE1-#FMZB
IC10 1130003921 S.IC TC4S69F(TE85R,F)
IC11 1130003921 S.IC TC4S69F(TE85R,F)
IC12 1140004120 S.IC M38022M2-138FP ()
IC13 1110005711 S.IC S-80842CLUA-B63-T2G
IC14 1160000131 S.IC TD62783AFG(5,S,EL)
IC15 1110004510 S.IC TD62597AFN(EL) [USA]
1110004511 S.IC TD62597AFNG(5,EL) [EUR]
1110004511 S.IC TD62597AFNG(5,EL) [EUR-1]
1110004511 S.IC TD62597AFNG(5,EL) [CHN]
IC16 1130011200 S.IC BU4069UBF-E2
IC17 1130015370 S.IC S-24CS01AFJ-TB-G
IC18 1160000131 S.IC TD62783AFG(5,S,EL)
IC19 1160000131 S.IC TD62783AFG(5,S,EL)
IC20 1130008411 S.IC TC74AC393F(EL,F)
IC21 1110000960 S.IC NJM4558M-TE1-#FMZB
IC25 1110005711 S.IC S-80842CLUA-B63-T2G
IC26 1140007691 S.IC TMP90PM38FG(Z)(EX-1900)
IC27 1130007031 S.IC TC7W08FU(TE12L,F)
IC28 1140003831 S.IC TC4W66F(TE12L,F)
IC30 1130007431 S.IC TC7S14FU(TE85R,F)
IC31 1110000960 S.IC NJM4558M-TE1-#FMZB
IC33 1130005821 S.IC TC4S584F(TE85R,F)
IC35 1180001072 S.IC TA7805F(TE16L1,NQ)
Q1 1510000781 S.TRA 2SA1586-Y(TE85R,F)
Q2 1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q3 1520000531 S.TRA 2SB1119S-TD-E
Q4 1590002310 S.TRA DTC114EE TL
Q5 1520000531 S.TRA 2SB1119S-TD-E
Q6 1590002310 S.TRA DTC114EE TL
Q7 1520000531 S.TRA 2SB1119S-TD-E
Q8 1590002310 S.TRA DTC114EE TL
Q9 1520000531 S.TRA 2SB1119S-TD-E
Q10 1520000531 S.TRA 2SB1119S-TD-E
Q11 1520000531 S.TRA 2SB1119S-TD-E
Q12 1520000531 S.TRA 2SB1119S-TD-E
Q13 1520000531 S.TRA 2SB1119S-TD-E
Q14 1520000531 S.TRA 2SB1119S-TD-E
Q15 1520000531 S.TRA 2SB1119S-TD-E
Q16 1590002310 S.TRA DTC114EE TL
Q17 1590002310 S.TRA DTC114EE TL
Q18 1590002310 S.TRA DTC114EE TL
Q19 1590002310 S.TRA DTC114EE TL
Q20 1590002310 S.TRA DTC114EE TL
Q21 1590002310 S.TRA DTC114EE TL
Q22 1590002310 S.TRA DTC114EE TL
Q23 1510000781 S.TRA 2SA1586-Y(TE85R,F)
Q24 1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q25 1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q26 1510000671 S.TRA 2SA1588-GR(TE85R, F)
Q27 1520000531 S.TRA 2SB1119S-TD-E
Q28 1590002310 S.TRA DTC114EE TL
Q29 1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q30 1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q32 1590002310 S.TRA DTC114EE TL
Q33 1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q34 1530002371 S.TRA 2SC2714-O(TE85R,F)
Q35 1560000271 S.FET 2SK302-Y(TE85R,F)
Q36 1590002310 S.TRA DTC114EE TL
Q100 1590002310 S.TRA DTC114EE TL
Q101 1520000581 S.TRA 2SB1124S-TD-E
Q102 1590002310 S.TRA DTC114EE TL
Q103 1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q104 1590002310 S.TRA DTC114EE TL
Q105 1590002310 S.TRA DTC114EE TL
Q106 1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q107 1590002310 S.TRA DTC114EE TL
Q108 1590002310 S.TRA DTC114EE TL
Q109 1590002310 S.TRA DTC114EE TL
Q111 1590002310 S.TRA DTC114EE TL
Q112 1590002310 S.TRA DTC114EE TL
Q113 1590002310 S.TRA DTC114EE TL
Q114 1510000781 S.TRA 2SA1586-Y(TE85R,F)
D1 1750000341 S.DIO 1SS357(TPHR3,F)
D2 1790000620 S.DIO MA77(TX)
D3 1790000620 S.DIO MA77(TX)
D4 1730000681 S.ZEN RD4.7M-T2B-A B2
D6 1730000681 S.ZEN RD4.7M-T2B-A B2
D7 1750000341 S.DIO 1SS357(TPHR3,F)
D8 1750000341 S.DIO 1SS357(TPHR3,F)
D11 1750000271 S.DIO 1SS301(TE85L,F)
D12 1750000271 S.DIO 1SS301(TE85L,F)
D13 1750000291 S.DIO 1SS300(TE85R,F)
D14 1750000291 S.DIO 1SS300(TE85R,F)
D15 1790001131 S.DIO D2FS4-5063
D16 1790000620 S.DIO MA77(TX)
D17 1790000620 S.DIO MA77(TX)
D18 1790000620 S.DIO MA77(TX) [USA] only
D20 1790000620 S.DIO MA77(TX)
D21 1790000620 S.DIO MA77(TX)
D23 1730000411 S.ZEN RD5.1M-T2B-A B2
D24 1730000411 S.ZEN RD5.1M-T2B-A B2
D26 1750000271 S.DIO 1SS301(TE85L,F)
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION
NO. NO.
D27 1790000620 S.DIO MA77(TX)
D50 1790000620 S.DIO MA77(TX)
D51 1790000620 S.DIO MA77(TX)
D52 1750000271 S.DIO 1SS301(TE85L,F)
D54 1790000620 S.DIO MA77(TX)
D55 1790000620 S.DIO MA77(TX)
D56 1750000341 S.DIO 1SS357(TPHR3,F)
D59 1750000341 S.DIO 1SS357(TPHR3,F)
D60 1750000341 S.DIO 1SS357(TPHR3,F)
D61 1750000271 S.DIO 1SS301(TE85L,F)
D62 1750000291 S.DIO 1SS300(TE85R,F)
D63 1750000271 S.DIO 1SS301(TE85L,F)
D66 1790001131 S.DIO D2FS4-5063
D67 1750000341 S.DIO 1SS357(TPHR3,F)
D68 1750000341 S.DIO 1SS357(TPHR3,F)
D69 1790000620 S.DIO MA77(TX)
D70 1750000341 S.DIO 1SS357(TPHR3,F)
D71 1790000620 S.DIO MA77(TX)
D72 1750000271 S.DIO 1SS301(TE85L,F)
D73 1750000271 S.DIO 1SS301(TE85L,F)
D75 1750000271 S.DIO 1SS301(TE85L,F)
D76 1750000341 S.DIO 1SS357(TPHR3,F)
D77 1790001131 S.DIO D2FS4-5063
D78 1790001131 S.DIO D2FS4-5063
D84 1790001131 S.DIO D2FS4-5063
D85 1750000271 S.DIO 1SS301(TE85L,F)
D86 1790001131 S.DIO D2FS4-5063
D87 1790001131 S.DIO D2FS4-5063
D88 1790001131 S.DIO D2FS4-5063
X1 6050009890 S.XTA CR-569 SMD-49 6.144 MHz <KDS>
X2 6050009870 S.XTA CR-567 SMD-49 9.8304 MHz <KDS>
L1 6200003261 S.COI NLV32T-101J
L2 6200003261 S.COI NLV32T-101J
L3 6200003261 S.COI NLV32T-101J
L4 6200003261 S.COI NLV32T-101J
L5 6200003261 S.COI NLV32T-101J
L6 6200003261 S.COI NLV32T-101J
L7 6200003261 S.COI NLV32T-101J
L8 6200003261 S.COI NLV32T-101J
L9 6200001831 S.COI NLV32T-100J
L10 6200001831 S.COI NLV32T-100J
L11 6200003261 S.COI NLV32T-101J
L12 6200003261 S.COI NLV32T-101J
L13 6200003950 S.COI HF50ACC 322513-T
L14 6200003950 S.COI HF50ACC 322513-T
L15 6200003261 S.COI NLV32T-101J
L16 6200003261 S.COI NLV32T-101J
L17 6200001831 S.COI NLV32T-100J
L19 6200003261 S.COI NLV32T-101J
L22 6200003261 S.COI NLV32T-101J
L24 6200003261 S.COI NLV32T-101J
L25 6200003261 S.COI NLV32T-101J
L27 6200001831 S.COI NLV32T-100J
L28 6140002220 COI LR-270 (TR6X3X2 3A9)
L29 6190000221 COI S0971136-101K-LF
L30 6200003261 S.COI NLV32T-101J
L31 6200003261 S.COI NLV32T-101J
L32 6200003261 S.COI NLV32T-101J
L35 6140002220 COI LR-270 (TR6X3X2 3A9)
L36 6200003261 S.COI NLV32T-101J
L37 6180000990 COI LAL 04NA 101K
L38 6200003950 S.COI HF50ACC 322513-T
L39 6200003950 S.COI HF50ACC 322513-T
L40 6200003950 S.COI HF50ACC 322513-T
L41 6200003950 S.COI HF50ACC 322513-T
L42 6200003950 S.COI HF50ACC 322513-T
L43 6200003950 S.COI HF50ACC 322513-T
L44 6200003950 S.COI HF50ACC 322513-T
L45 6200003950 S.COI HF50ACC 322513-T
L46 6200003950 S.COI HF50ACC 322513-T
L47 6200003950 S.COI HF50ACC 322513-T
L48 6200003950 S.COI HF50ACC 322513-T
L49 6200003261 S.COI NLV32T-101J
L50 6200003950 S.COI HF50ACC 322513-T
L51 6200003261 S.COI NLV32T-101J
L52 6200003261 S.COI NLV32T-101J
L54 6200003950 S.COI HF50ACC 322513-T
L55 6200003950 S.COI HF50ACC 322513-T
L56 6200003950 S.COI HF50ACC 322513-T
L57 6200003950 S.COI HF50ACC 322513-T
L58 6200003950 S.COI HF50ACC 322513-T
L59 6200003950 S.COI HF50ACC 322513-T
L60 6200003950 S.COI HF50ACC 322513-T
L61 6200003950 S.COI HF50ACC 322513-T
L62 6200003950 S.COI HF50ACC 322513-T
L63 6200003950 S.COI HF50ACC 322513-T
L64 6200003950 S.COI HF50ACC 322513-T
L65 6200003950 S.COI HF50ACC 322513-T
L66 6200003950 S.COI HF50ACC 322513-T
L67 6200003950 S.COI HF50ACC 322513-T
L68 6200003950 S.COI HF50ACC 322513-T
L69 6200003950 S.COI HF50ACC 322513-T
L70 6200003950 S.COI HF50ACC 322513-T
L71 6200003950 S.COI HF50ACC 322513-T
L72 6200003950 S.COI HF50ACC 322513-T
L73 6200003950 S.COI HF50ACC 322513-T
L74 6200003950 S.COI HF50ACC 322513-T
L75 6200003261 S.COI NLV32T-101J
L76 6200003261 S.COI NLV32T-101J
L77 6200001831 S.COI NLV32T-100J

Jun. 2010
9
[MAIN UNIT]
REF ORDER DESCRIPTION
NO. NO.
L78 6200001831 S.COI NLV32T-100J
L79 6200001831 S.COI NLV32T-100J
L80 6910003570 COI 2943-666663
L81 6200003261 S.COI NLV32T-101J
L82 6200003261 S.COI NLV32T-101J
L100 6200003261 S.COI NLV32T-101J
L101 6200003261 S.COI NLV32T-101J
L104 6200003950 S.COI HF50ACC 322513-T
L105 6200003950 S.COI HF50ACC 322513-T
L106 6200003950 S.COI HF50ACC 322513-T
L107 6910003570 COI 2943-666663
L108 6910003570 COI 2943-666663
L109 6200003261 S.COI NLV32T-101J
L110 6200003261 S.COI NLV32T-101J
L111 6200003950 S.COI HF50ACC 322513-T
L113 6200003261 S.COI NLV32T-101J
L114 6180000900 COI LAL 03NA 101K
L115 6180000880 COI LAL 03NA 100K
L116 6180000880 COI LAL 03NA 100K
L117 6200003261 S.COI NLV32T-101J
L118 6200003261 S.COI NLV32T-101J
L119 6200003261 S.COI NLV32T-101J
L120 6200003261 S.COI NLV32T-101J
L121 6200003950 S.COI HF50ACC 322513-T
L122 6200003950 S.COI HF50ACC 322513-T
L123 6200003261 S.COI NLV32T-101J
L124 6200003261 S.COI NLV32T-101J
L125 6200003950 S.COI HF50ACC 322513-T
R1 7030003840 S.RES ERJ3GEYJ 225 V (2.2M)
R2 7030003740 S.RES ERJ3GEYJ 334 V (330K)
R3 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R4 7310005570 S.TRI TMC3ADC15X (100K)
R5 7310005180 S.TRI RH03ADC16X (1M)
R6 7310005570 S.TRI TMC3ADC15X (100K)
R7 7030003570 S.RES ERJ3GEYJ 123 V (12K)
R9 7030003840 S.RES ERJ3GEYJ 225 V (2.2M)
R10 7030003750 S.RES ERJ3GEYJ 394 V (390K)
R11 7030003810 S.RES ERJ3GEYJ 125 V (1.2M)
R12 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R13 7030003810 S.RES ERJ3GEYJ 125 V (1.2M)
R14 7030003690 S.RES ERJ3GEYJ 124 V (120K)
R15 7310005540 S.TRI TMC3ADC14X (10K)
R22 7310005570 S.TRI TMC3ADC15X (100K)
R23 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R24 7030003750 S.RES ERJ3GEYJ 394 V (390K)
R25 7030003750 S.RES ERJ3GEYJ 394 V (390K)
R26 7310005590 S.TRI TMC3ADCJ5X (220K)
R27 7030003650 S.RES ERJ3GEYJ 563 V (56K)
R28 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R29 7030003750 S.RES ERJ3GEYJ 394 V (390K)
R30 7030003750 S.RES ERJ3GEYJ 394 V (390K)
R31 7310005510 S.TRI TMC3ADCS5X (470K)
R32 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R33 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R34 7030003730 S.RES ERJ3GEYJ 274 V (270K)
R35 7030003660 S.RES ERJ3GEYJ 683 V (68K)
R37 7030003670 S.RES ERJ3GEYJ 823 V (82K)
R38 7030003450 S.RES ERJ3GEYJ 122 V (1.2K)
R39 7030003450 S.RES ERJ3GEYJ 122 V (1.2K)
R44 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R45 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R46 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R47 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R48 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R49 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R50 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R51 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R52 7030006060 S.RES ERJ12YJ100U (10)
R53 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R54 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R55 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R56 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R57 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R58 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R59 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R60 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R61 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R62 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R63 7030003670 S.RES ERJ3GEYJ 823 V (82K)
R64 7030003540 S.RES ERJ3GEYJ 682 V (6.8K)
R65 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R66 7030003540 S.RES ERJ3GEYJ 682 V (6.8K)
R67 7030003570 S.RES ERJ3GEYJ 123 V (12K)
R68 7030003630 S.RES ERJ3GEYJ 393 V (39K)
R69 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R70 7030003380 S.RES ERJ3GEYJ 331 V (330)
R71 7030006220 S.RES ERJ12YJ470U (47)
R73 7030008170 S.RES ERJ12YJ1R0U (1)
R75 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R76 7030003510 S.RES ERJ3GEYJ 392 V (3.9K)
R77 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R78 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R79 7030003810 S.RES ERJ3GEYJ 125 V (1.2M)
R80 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R82 7030003520 S.RES ERJ3GEYJ 472 V (4.7K)
R83 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R84 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R85 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R86 7030003800 S.RES ERJ3GEYJ 105 V (1M)
R87 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R88 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R89 7030003640 S.RES ERJ3GEYJ 473 V (47K)
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION
NO. NO.
R90 7030003380 S.RES ERJ3GEYJ 331 V (330)
R91 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R92 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R93 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R94 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R95 7030003760 S.RES ERJ3GEYJ 474 V (470K)
R96 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R97 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R98 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R99 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R100 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R101 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R102 7030003370 S.RES ERJ3GEYJ 271 V (270)
R103 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R104 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R105 7030003650 S.RES ERJ3GEYJ 563 V (56K)
R106 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R107 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R108 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R109 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R110 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R111 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R112 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R113 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R114 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R115 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R116 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R117 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R118 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R119 7030003540 S.RES ERJ3GEYJ 682 V (6.8K)
R120 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R121 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R122 7030003590 S.RES ERJ3GEYJ 183 V (18K)
R123 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R124 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R125 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R126 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R127 7030003840 S.RES ERJ3GEYJ 225 V (2.2M)
R128 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R130 7030003700 S.RES ERJ3GEYJ 154 V (150K)
R132 7030003620 S.RES ERJ3GEYJ 333 V (33K)
R133 7030003610 S.RES ERJ3GEYJ 273 V (27K)
R135 7030003620 S.RES ERJ3GEYJ 333 V (33K)
R136 7030003540 S.RES ERJ3GEYJ 682 V (6.8K)
R137 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R139 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R140 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R141 7030000420 S.RES MCR10EZHJ 2.2K (222)
R142 7030000420 S.RES MCR10EZHJ 2.2K (222)
R143 7030000420 S.RES MCR10EZHJ 2.2K (222)
R144 7030000420 S.RES MCR10EZHJ 2.2K (222)
R145 7030000420 S.RES MCR10EZHJ 2.2K (222)
R146 7030000420 S.RES MCR10EZHJ 2.2K (222)
R147 7030000420 S.RES MCR10EZHJ 2.2K (222)
R148 7030000420 S.RES MCR10EZHJ 2.2K (222)
R149 7030000420 S.RES MCR10EZHJ 2.2K (222)
R150 7030000420 S.RES MCR10EZHJ 2.2K (222)
R151 7030000420 S.RES MCR10EZHJ 2.2K (222)
R152 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R153 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R155 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R157 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R158 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R159 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R160 7030003760 S.RES ERJ3GEYJ 474 V (470K)
R161 7030003380 S.RES ERJ3GEYJ 331 V (330)
R162 7030003630 S.RES ERJ3GEYJ 393 V (39K)
R163 7030003420 S.RES ERJ3GEYJ 681 V (680)
R164 7030003260 S.RES ERJ3GEYJ 330 V (33)
R165 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R166 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R167 7030003400 S.RES ERJ3GEYJ 471 V (470)
R170 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R171 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R172 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R173 7030000420 S.RES MCR10EZHJ 2.2K (222)
R174 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R175 7030000420 S.RES MCR10EZHJ 2.2K (222)
R176 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R177 7030000420 S.RES MCR10EZHJ 2.2K (222)
R178 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R179 7030000420 S.RES MCR10EZHJ 2.2K (222)
R180 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R181 7030000420 S.RES MCR10EZHJ 2.2K (222)
R182 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R183 7030000420 S.RES MCR10EZHJ 2.2K (222)
R184 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R185 7030000420 S.RES MCR10EZHJ 2.2K (222)
R186 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R187 7030000420 S.RES MCR10EZHJ 2.2K (222)
R188 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R189 7030000420 S.RES MCR10EZHJ 2.2K (222)
R190 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R191 7030000420 S.RES MCR10EZHJ 2.2K (222)
R192 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R193 7030000420 S.RES MCR10EZHJ 2.2K (222)
R194 7030003580 S.RES ERJ3GEYJ 153 V (15K)
R196 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R197 7310005550 S.TRI TMC3ADCJ4X (22K)
R198 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R199 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R200 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R201 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R202 7030003720 S.RES ERJ3GEYJ 224 V (220K)

Jun. 2010
10
[MAIN UNIT]
REF ORDER DESCRIPTION
NO. NO.
R203 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R204 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R205 7030003620 S.RES ERJ3GEYJ 333 V (33K)
R206 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R207 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R208 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R209 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R210 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R211 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R212 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R213 7030003480 S.RES ERJ3GEYJ 222 V (2.2K)
R222 7030003400 S.RES ERJ3GEYJ 471 V (470)
R223 7030003400 S.RES ERJ3GEYJ 471 V (470)
R224 7030003760 S.RES ERJ3GEYJ 474 V (470K)
R225 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R226 7030003760 S.RES ERJ3GEYJ 474 V (470K)
R227 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R228 7030003560 S.RES ERJ3GEYJ 103 V (10K)
R229 7030003710 S.RES ERJ3GEYJ 184 V (180K)
R230 7030003440 S.RES ERJ3GEYJ 102 V (1K)
R231 7030003760 S.RES ERJ3GEYJ 474 V (470K)
R232 7010000992 RES PSN1/4 47
R233 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R234 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R235 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R237 7030003610 S.RES ERJ3GEYJ 273 V (27K)
R238 7030003800 S.RES ERJ3GEYJ 105 V (1M)
R240 7310005180 S.TRI RH03ADC16X (1M)
R241 7030003610 S.RES ERJ3GEYJ 273 V (27K)
R242 7030000420 S.RES MCR10EZHJ 2.2K (222)
R243 7030000420 S.RES MCR10EZHJ 2.2K (222)
R244 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R245 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R246 7030003600 S.RES ERJ3GEYJ 223 V (22K)
R247 7030008190 S.RES ERJ12YJ330U (33)
R249 7030003680 S.RES ERJ3GEYJ 104 V (100K)
R250 7030003660 S.RES ERJ3GEYJ 683 V (68K)
W3 7030003860 S.RES ERJ3GE JPW V
W10 7030003860 S.RES ERJ3GE JPW V
C1 4030006880 S.CER C1608 JB 1H 472K-T
C2 4030006880 S.CER C1608 JB 1H 472K-T
C3 4030011600 S.CER C1608 JB 1E 104K-T
C5 4030011600 S.CER C1608 JB 1E 104K-T
C6 4030011600 S.CER C1608 JB 1E 104K-T
C8 4030011600 S.CER C1608 JB 1E 104K-T
C13 4030011600 S.CER C1608 JB 1E 104K-T
C17 4030006880 S.CER C1608 JB 1H 472K-T
C18 4030006880 S.CER C1608 JB 1H 472K-T
C19 4030011600 S.CER C1608 JB 1E 104K-T
C20 4030011600 S.CER C1608 JB 1E 104K-T
C21 4030011600 S.CER C1608 JB 1E 104K-T
C22 4030011600 S.CER C1608 JB 1E 104K-T
C23 4030011600 S.CER C1608 JB 1E 104K-T
C25 4030011600 S.CER C1608 JB 1E 104K-T
C26 4030011600 S.CER C1608 JB 1E 104K-T
C28 4030011600 S.CER C1608 JB 1E 104K-T
C29 4030011600 S.CER C1608 JB 1E 104K-T
C31 4030011600 S.CER C1608 JB 1E 104K-T
C33 4030006880 S.CER C1608 JB 1H 472K-T
C34 4030011600 S.CER C1608 JB 1E 104K-T
C35 4030011600 S.CER C1608 JB 1E 104K-T
C36 4030011600 S.CER C1608 JB 1E 104K-T
C37 4510008520 S.ELE EEE1CA470SP
C38 4030011600 S.CER C1608 JB 1E 104K-T
C39 4030011600 S.CER C1608 JB 1E 104K-T
C40 4510008520 S.ELE EEE1CA470SP
C41 4030006880 S.CER C1608 JB 1H 472K-T
C43 4030009580 S.CER C1608 JB 1H 681K-T
C44 4030011600 S.CER C1608 JB 1E 104K-T
C45 4030006860 S.CER C1608 JB 1H 102K-T
C46 4510008830 S.ELE EEE1CA221P
C47 4030010210 S.CER C3216 JB 1C 105M-T
C48 4510008510 S.ELE EEE1CA471P
C49 4510008510 S.ELE EEE1CA471P
C50 4030010210 S.CER C3216 JB 1C 105M-T
C51 4030010210 S.CER C3216 JB 1C 105M-T
C52 4510008520 S.ELE EEE1CA470SP
C53 4510008520 S.ELE EEE1CA470SP
C54 4030011600 S.CER C1608 JB 1E 104K-T
C55 4030011600 S.CER C1608 JB 1E 104K-T
C56 4510008490 S.ELE EEE1CS100SR
C57 4030011600 S.CER C1608 JB 1E 104K-T
C59 4030011600 S.CER C1608 JB 1E 104K-T
C60 4030011600 S.CER C1608 JB 1E 104K-T
C61 4030011600 S.CER C1608 JB 1E 104K-T
C64 4030011600 S.CER C1608 JB 1E 104K-T
C65 4030011600 S.CER C1608 JB 1E 104K-T
C66 4510008490 S.ELE EEE1CS100SR
C67 4030006880 S.CER C1608 JB 1H 472K-T
C68 4030011600 S.CER C1608 JB 1E 104K-T
C69 4030007030 S.CER C1608 CH 1H 150J-T
C70 4030007030 S.CER C1608 CH 1H 150J-T
C71 4030011600 S.CER C1608 JB 1E 104K-T
C72 4030011600 S.CER C1608 JB 1E 104K-T
C73 4030011600 S.CER C1608 JB 1E 104K-T
C74 4030011600 S.CER C1608 JB 1E 104K-T
C75 4030011600 S.CER C1608 JB 1E 104K-T
C76 4030011600 S.CER C1608 JB 1E 104K-T
C77 4030011600 S.CER C1608 JB 1E 104K-T
C78 4030011600 S.CER C1608 JB 1E 104K-T
S.=Surface mount
[MAIN UNIT]
REF ORDER DESCRIPTION
NO. NO.
C79 4030011600 S.CER C1608 JB 1E 104K-T
C80 4030011600 S.CER C1608 JB 1E 104K-T
C81 4030011600 S.CER C1608 JB 1E 104K-T
C82 4030011600 S.CER C1608 JB 1E 104K-T
C83 4030011600 S.CER C1608 JB 1E 104K-T
C84 4030011600 S.CER C1608 JB 1E 104K-T
C85 4030011600 S.CER C1608 JB 1E 104K-T
C86 4030011600 S.CER C1608 JB 1E 104K-T
C87 4030011600 S.CER C1608 JB 1E 104K-T
C88 4030009660 S.CER C1608 JF 1C 224Z-T
C89 4030011600 S.CER C1608 JB 1E 104K-T
C90 4030011600 S.CER C1608 JB 1E 104K-T
C92 4030011600 S.CER C1608 JB 1E 104K-T
C93 4030011600 S.CER C1608 JB 1E 104K-T
C94 4030006880 S.CER C1608 JB 1H 472K-T
C95 4030011600 S.CER C1608 JB 1E 104K-T
C96 4030011600 S.CER C1608 JB 1E 104K-T
C97 4030011600 S.CER C1608 JB 1E 104K-T
C98 4030011600 S.CER C1608 JB 1E 104K-T
C99 4030011600 S.CER C1608 JB 1E 104K-T
C100 4030011600 S.CER C1608 JB 1E 104K-T
C101 4030011600 S.CER C1608 JB 1E 104K-T
C102 4030011600 S.CER C1608 JB 1E 104K-T
C103 4030011600 S.CER C1608 JB 1E 104K-T
C104 4030011600 S.CER C1608 JB 1E 104K-T
C105 4030011600 S.CER C1608 JB 1E 104K-T
C106 4030011600 S.CER C1608 JB 1E 104K-T
C107 4030011600 S.CER C1608 JB 1E 104K-T
C108 4030011600 S.CER C1608 JB 1E 104K-T
C109 4030011600 S.CER C1608 JB 1E 104K-T
C110 4030011600 S.CER C1608 JB 1E 104K-T
C111 4030011600 S.CER C1608 JB 1E 104K-T
C112 4030011600 S.CER C1608 JB 1E 104K-T
C113 4030011600 S.CER C1608 JB 1E 104K-T
C114 4030011340 S.CER C1608 CH 1H 471J-T
C115 4030011600 S.CER C1608 JB 1E 104K-T
C121 4030008920 S.CER C1608 JB 1H 473K-T
C122 4030011340 S.CER C1608 CH 1H 471J-T [USA]
4030011340 S.CER C1608 CH 1H 471J-T [EUR]
4030011340 S.CER C1608 CH 1H 471J-T [EUR-1]
4030010110 S.CER C1608 SL 1H 471J-T [CHN]
C123 4030008920 S.CER C1608 JB 1H 473K-T
C124 4030006880 S.CER C1608 JB 1H 472K-T
C125 4030006860 S.CER C1608 JB 1H 102K-T
C126 4030011600 S.CER C1608 JB 1E 104K-T
C201 4030007020 S.CER C1608 CH 1H 120J-T
C202 4030007020 S.CER C1608 CH 1H 120J-T
C203 4030011600 S.CER C1608 JB 1E 104K-T
C204 4030011600 S.CER C1608 JB 1E 104K-T
C205 4030011600 S.CER C1608 JB 1E 104K-T
C206 4030011600 S.CER C1608 JB 1E 104K-T
C207 4030011600 S.CER C1608 JB 1E 104K-T
C208 4030011600 S.CER C1608 JB 1E 104K-T
C209 4030011600 S.CER C1608 JB 1E 104K-T
C210 4030006880 S.CER C1608 JB 1H 472K-T
C211 4030011600 S.CER C1608 JB 1E 104K-T
C212 4030011600 S.CER C1608 JB 1E 104K-T
C213 4510008490 S.ELE EEE1CS100SR
C214 4030011600 S.CER C1608 JB 1E 104K-T
C215 4030011600 S.CER C1608 JB 1E 104K-T
C216 4030011600 S.CER C1608 JB 1E 104K-T
C219 4030011600 S.CER C1608 JB 1E 104K-T
C220 4030011600 S.CER C1608 JB 1E 104K-T
C221 4030011600 S.CER C1608 JB 1E 104K-T
C222 4030006860 S.CER C1608 JB 1H 102K-T
C223 4030006860 S.CER C1608 JB 1H 102K-T
C224 4030006860 S.CER C1608 JB 1H 102K-T
C225 4030006860 S.CER C1608 JB 1H 102K-T
C226 4030008920 S.CER C1608 JB 1H 473K-T
C227 4030008920 S.CER C1608 JB 1H 473K-T
C228 4030006860 S.CER C1608 JB 1H 102K-T
C229 4030006860 S.CER C1608 JB 1H 102K-T
C230 4030011600 S.CER C1608 JB 1E 104K-T
C231 4030011600 S.CER C1608 JB 1E 104K-T
C232 4030011600 S.CER C1608 JB 1E 104K-T
C233 4510008490 S.ELE EEE1CS100SR
C234 4030011600 S.CER C1608 JB 1E 104K-T
C235 4030006860 S.CER C1608 JB 1H 102K-T
C236 4510003860 ELE 50 ME 3R3 SWB
C239 4030006860 S.CER C1608 JB 1H 102K-T
C240 4030011600 S.CER C1608 JB 1E 104K-T
C241 4030011600 S.CER C1608 JB 1E 104K-T
C242 4030006860 S.CER C1608 JB 1H 102K-T
C245 4510008540 S.ELE EEE1CA100SR
C246 4030011600 S.CER C1608 JB 1E 104K-T
C247 4030011600 S.CER C1608 JB 1E 104K-T
C248 4510008820 S.ELE EEE1CA330WR
C249 4510003790 ELE 16 ME 10 SWB
C260 4030006880 S.CER C1608 JB 1H 472K-T
C261 4030017810 S.CER C1608 CH 1H 102J-T
C262 4030017810 S.CER C1608 CH 1H 102J-T
C263 4030017810 S.CER C1608 CH 1H 102J-T
C271 4030008650 S.CER C1608 JB 1H 332K-T
RL2 6330001320 REL AHY103
RL3 6330001320 REL AHY103
CP1 6910009670 S.CHE HK3-S-T
J2 6510022091 S.CON 52610-1271(1290)
J3 6510003461 CON B10B-EH-S(LF)(SN)

Jun. 2010
11
[MAIN UNIT]
REF ORDER DESCRIPTION
NO. NO.
J4 6510003481 CON B12B-EH-S(LF)(SN)
J6 6510003411 CON B05B-EH-S(LF)(SN)
J8 6510003491 CON B13B-EH-S(LF)(SN)
J9 6510003411 CON B05B-EH-S(LF)(SN)
J10 6510003451 CON B09B-EH-S(LF)(SN)
J14 6510017650 CON 52045-1045
J17 6510003391 CON B03B-EH-S(LF)(SN)
J18 6510003411 CON B05B-EH-S(LF)(SN)
J19 6510003421 CON B06B-EH-S(LF)(SN)
J20 6510003431 CON B07B-EH-S(LF)(SN)
J21 6510003441 CON B08B-EH-S(LF)(SN)
J22 6510003391 CON B03B-EH-S(LF)(SN)
J23 6910005801 CON IMSA-9210B-1-03ZA043-PT1
P1 6910007600 CON IMSA-9215H-T
S3 2260002220 SWI S-1010A
S4 2260002220 SWI S-1010A
S5 2220000530 S.SWI SW-161 (SSSS822-A-0)
S.=Surface mount
[JACK1 UNIT]
REF ORDER DESCRIPTION
NO. NO.
L1 6200003261 S.COI NLV32T-101J
L2 6200003261 S.COI NLV32T-101J
L3 6200003261 S.COI NLV32T-101J
L4 6200003261 S.COI NLV32T-101J
L5 6200003950 S.COI HF50ACC 322513-T
L6 6200003950 S.COI HF50ACC 322513-T
R1 7310003820 TRI EVN-D2AA03 B14
R2 7310003820 TRI EVN-D2AA03 B14
C1 4030006880 S.CER C1608 JB 1H 472K-T
C2 4030006880 S.CER C1608 JB 1H 472K-T
C3 4030006880 S.CER C1608 JB 1H 472K-T
C4 4030006880 S.CER C1608 JB 1H 472K-T
C5 4030006880 S.CER C1608 JB 1H 472K-T
C6 4030006880 S.CER C1608 JB 1H 472K-T
J1 6510024541 CON TCS5073-2741577
J3 6450001130 CON JPJ2042-01-110
J4 6450000140 CON HSJ0807-01-010
J5 6510024541 CON TCS5073-2741577
J7 6450001130 CON JPJ2042-01-110
J8 6450000140 CON HSJ0807-01-010
J9 6510022091 S.CON 52610-1271(1290)
J10 6510003461 CON B10B-EH-S(LF)(SN)
J11 6510003461 CON B10B-EH-S(LF)(SN)
J12 6510018961 S.CON B2B-PH-SM4-TB(LF)(SN)
S1 2220000570 SWI HSW1196-01-020

Jun. 2010
12
[ANT-SW UNIT]
REF ORDER DESCRIPTION
NO. NO.
D1 1710000051 DIO 1SS53-AZ
D2 1710000051 DIO 1SS53-AZ
D3 1710000051 DIO 1SS53-AZ
D4 1710000051 DIO 1SS53-AZ
L1 6180000900 COI LAL 03NA 101K
L2 6180000900 COI LAL 03NA 101K
L3 6180000900 COI LAL 03NA 101K
L4 6180000900 COI LAL 03NA 101K
R1 7540000190 ABS SRYG-2000L
C1 4010006900 CER HE80SJ YB 472K 50V
C2 4010006900 CER HE80SJ YB 472K 50V
C3 4010006900 CER HE80SJ YB 472K 50V
C4 4010006900 CER HE80SJ YB 472K 50V
C6 4010006900 CER HE80SJ YB 472K 50V
C7 4010006900 CER HE80SJ YB 472K 50V
C8 4010006900 CER HE80SJ YB 472K 50V
C9 4010006900 CER HE80SJ YB 472K 50V
C11 4010008640 CER DEA1X3A100JC1B
C12 4010008640 CER DEA1X3A100JC1B
C13 4010008640 CER DEA1X3A100JC1B
RL1 6330001460 REL FTR-F1CA012V
RL2 6330001460 REL FTR-F1CA012V
RL3 6330001460 REL FTR-F1CA012V
RL4 6330001460 REL FTR-F1CA012V
EP1 6910011340 TER OT-010 M3
EP2 6910011340 TER OT-010 M3
S.=Surface mount
[FILTER UNIT]
REF ORDER DESCRIPTION
NO. NO.
D2 1790001491 DIO D1NL20U-5070
D4 1790001491 DIO D1NL20U-5070
D6 1790001491 DIO D1NL20U-5070
D8 1790001491 DIO D1NL20U-5070
D10 1790001491 DIO D1NL20U-5070
D12 1790001491 DIO D1NL20U-5070
D14 1790001491 DIO D1NL20U-5070
D15 1710000981 DIO MBD701G
D16 1710000981 DIO MBD701G
D17 1790001491 DIO D1NL20U-5070
D18 1790001491 DIO D1NL20U-5070
L1 6110003450 COI LA-539
L2 6110002280 COI LA-405
L3 6110003430 COI LA-540
L4 6110002250 COI LA-402
L6 6110003420 COI LA-541
L7 6140001901 COI LR-200A
L8 6140001911 COI LR-201A
L9 6140001891 COI LR-198A
L10 6140001941 COI LR-199A
L11 6140003331 COI LR-369A
L12 6140003341 COI LR-370A
L13 6140004540 COI LR-513
L14 6140004550 COI LR-514
L15 6180001220 COI LAL 04NA 100K
L16 6180001220 COI LAL 04NA 100K
L17 6180001220 COI LAL 04NA 100K
L18 6180000990 COI LAL 04NA 101K
L19 6180000990 COI LAL 04NA 101K
L20 6180000990 COI LAL 04NA 101K
L21 6180000990 COI LAL 04NA 101K
L22 6140001001 COI LR-123A
L23 6180000990 COI LAL 04NA 101K
L27 6110003440 COI LA-538
L28 6110003460 COI LA-537
L29 6110003460 COI LA-537
L30 6180001220 COI LAL 04NA 100K
L31 6110002260 COI LA-403
L32 6180000990 COI LAL 04NA 101K
L33 6910000670 COI BL01RN1A1D2B (BL01RN1-A62)
R2 7010006980 RES PSD1/4 10 K
R3 7010006980 RES PSD1/4 10 K
R4 7010006980 RES PSD1/4 10 K
R5 7010006980 RES PSD1/4 10 K
R7 7030007360 S.RES ERJ1WYJ470U (47)
R8 7030007360 S.RES ERJ1WYJ470U (47)
R9 7030007360 S.RES ERJ1WYJ470U (47)
R10 7030007360 S.RES ERJ1WYJ470U (47)
R11 7010006980 RES PSD1/4 10 K
R12 7010006980 RES PSD1/4 10 K
R13 7030007360 S.RES ERJ1WYJ470U (47)
R14 7030007360 S.RES ERJ1WYJ470U (47)
R15 7540000050 ABS DSA-701MA
C1 4010004770 CER DEC1X3J390JC4B (DE0910SL390J)
C4 4010005130 CER DEC1X3J470JC4B (DE0910SL470J)
C5 4010005130 CER DEC1X3J470JC4B (DE0910SL470J)
C6 4010004770 CER DEC1X3J390JC4B (DE0910SL390J)
C7 4010004760 CER DEC1X3J330JC4B (DE0910SL330J)
C8 4010004770 CER DEC1X3J390JC4B (DE0910SL390J)
C9 4010004790 CER DEC1X3J680JC4B (DE1210SL680J)
C10 4010004790 CER DEC1X3J680JC4B (DE1210SL680J)
C11 4010004780 CER DEC1X3J560JC4B (DE1010SL560J)
C12 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C13 4010004780 CER DEC1X3J560JC4B (DE1010SL560J)
C14 4010004780 CER DEC1X3J560JC4B (DE1010SL560J)
C15 4010004770 CER DEC1X3J390JC4B (DE0910SL390J)
C16 4010005110 CER DEC1X3J220JC4B (DE0910SL220J)
C18 4010004800 CER DEC1X3J820JC4B (DE1210SL820J)
C19 4010005130 CER DEC1X3J470JC4B (DE0910SL470J)
C20 4010005130 CER DEC1X3J470JC4B (DE0910SL470J)
C23 4010004800 CER DEC1X3J820JC4B (DE1210SL820J)
C24 4010004800 CER DEC1X3J820JC4B (DE1210SL820J)
C25 4010004820 CER DEC1X3J121JC4B (DE1410SL121J)
C26 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C27 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C28 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C29 4010004820 CER DEC1X3J121JC4B (DE1410SL121J)
C30 4010004820 CER DEC1X3J121JC4B (DE1410SL121J)
C31 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C32 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C33 4010005130 CER DEC1X3J470JC4B (DE0910SL470J)
C34 4010004820 CER DEC1X3J121JC4B (DE1410SL121J)
C35 4010008700 CER DEA1X3F181JA3B
C36 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C37 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C38 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C39 4010008700 CER DEA1X3F181JA3B
C40 4010008700 CER DEA1X3F181JA3B
C41 4010008750 CER DEA1X3F331JA3B
C42 4010004790 CER DEC1X3J680JC4B (DE1210SL680J)
C43 4010008760 CER DEA1X3F271JA3B
C44 4010008620 CER DEA1X3F221JA3B
C45 4010008760 CER DEA1X3F271JA3B
C46 4010008760 CER DEA1X3F271JA3B
C47 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C48 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C49 4320000210 DIP DM19C 561J5
C50 4320000200 DIP DM19C 471J5

Jun. 2010
13
[FILTER UNIT]
REF ORDER DESCRIPTION
NO. NO.
C51 4010008620 CER DEA1X3F221JA3B
C52 4010008620 CER DEA1X3F221JA3B
C53 4010008620 CER DEA1X3F221JA3B
C54 4010008620 CER DEA1X3F221JA3B
C55 4320000210 DIP DM19C 561J5
C56 4320000200 DIP DM19C 471J5
C58 4020000970 CYL UP050B 472K Z
C60 4020000970 CYL UP050B 472K Z
C62 4020000970 CYL UP050B 472K Z
C64 4020000970 CYL UP050B 472K Z
C66 4020000970 CYL UP050B 472K Z
C68 4020000970 CYL UP050B 472K Z
C70 4020000970 CYL UP050B 472K Z
C71 4030004740 S.CER C2012 JB 1H 472K-T
C72 4030004740 S.CER C2012 JB 1H 472K-T
C73 4610001220 TRI CVE101-42(56) (100P)
C74 4030005040 S.CER C2012 CH 1H 271J-T
C75 4020000970 CYL UP050B 472K Z
C76 4010005080 CER DEA1X3F470JC3B (DE0707SL470J)
C77 4010008660 CER DEA1X3F330JC3B
C78 4010005120 CER DEC1X3J270JC4B (DE0910SL270J)
C79 4010004760 CER DEC1X3J330JC4B (DE0910SL330J)
C80 4010008640 CER DEA1X3A100JC1B
C81 4010008640 CER DEA1X3A100JC1B
C83 4010008650 CER DEA1X3F120JCDB
C86 4010008650 CER DEA1X3F120JCDB
C87 4010008650 CER DEA1X3F120JCDB
C88 4010005110 CER DEC1X3J220JC4B (DE0910SL220J)
C89 4010008650 CER DEA1X3F120JCDB
C90 4010008650 CER DEA1X3F120JCDB
C91 4010008650 CER DEA1X3F120JCDB
C95 4010008670 CER DEC1X3J150JC4B
C96 4010008650 CER DEA1X3F120JCDB
C98 4010008740 CER DEA1X3F220JCDB
C100 4010006880 CER HE50SJ YB 102K 50V
C101 4020000970 CYL UP050B 472K Z
C102 4020000970 CYL UP050B 472K Z
C103 4020000970 CYL UP050B 472K Z
C104 4020000970 CYL UP050B 472K Z
C107 4030004740 S.CER C2012 JB 1H 472K-T
C108 4030004740 S.CER C2012 JB 1H 472K-T
C110 4010004820 CER DEC1X3J121JC4B (DE1410SL121J)
C112 4010004800 CER DEC1X3J820JC4B (DE1210SL820J)
C115 4010006900 CER HE80SJ YB 472K 50V
C116 4010004770 CER DEC1X3J390JC4B (DE0910SL390J)
C117 4010008750 CER DEA1X3F331JA3B
C118 4010005120 CER DEC1X3J270JC4B (DE0910SL270J)
C119 4010005120 CER DEC1X3J270JC4B (DE0910SL270J)
C120 4010008650 CER DEA1X3F120JCDB
C123 4010008650 CER DEA1X3F120JCDB
C124 4010004800 CER DEC1X3J820JC4B (DE1210SL820J)
C125 4010004800 CER DEC1X3J820JC4B (DE1210SL820J)
C126 4010004790 CER DEC1X3J680JC4B (DE1210SL680J)
C128 4010008650 CER DEA1X3F120JCDB
C129 4010008650 CER DEA1X3F120JCDB
C130 4010008650 CER DEA1X3F120JCDB
C131 4010008700 CER DEA1X3F181JA3B
C133 4030008960 S.CER C2012 JB 1C 104K-T
C134 4030008960 S.CER C2012 JB 1C 104K-T
C135 4030006850 S.CER C1608 JB 1H 471K-T
C136 4030006850 S.CER C1608 JB 1H 471K-T
C138 4010008620 CER DEA1X3F221JA3B
C139 4010008620 CER DEA1X3F221JA3B
C140 4010008620 CER DEA1X3F221JA3B
C141 4010008620 CER DEA1X3F221JA3B
C144 4010006900 CER HE80SJ YB 472K 50V
RL1 6330000201 REL VS-12TBU-E-UC
RL2 6330000201 REL VS-12TBU-E-UC
RL3 6330000201 REL VS-12TBU-E-UC
RL4 6330000201 REL VS-12TBU-E-UC
RL5 6330000201 REL VS-12TBU-E-UC
RL6 6330000201 REL VS-12TBU-E-UC
RL7 6330000201 REL VS-12TBU-E-UC
RL8 6330000201 REL VS-12TBU-E-UC
RL9 6330000201 REL VS-12TBU-E-UC
RL10 6330000201 REL VS-12TBU-E-UC
RL11 6330000201 REL VS-12TBU-E-UC
RL12 6330000201 REL VS-12TBU-E-UC
RL13 6330000201 REL VS-12TBU-E-UC
RL14 6330000201 REL VS-12TBU-E-UC
RL15 6330001500 REL AW3033
RL16 6330001210 REL VB-12TBU-UC
RL17 6330001210 REL VB-12TBU-UC
W12 9040401001 JUM 74/98/050/X98/X98
W48 9010001090 WIR 74/98/010/X98/X98
EP1 6910011330 TER OT-009 M3
EP2 6910011330 TER OT-009 M3
EP3 6910011330 TER OT-009 M3
EP4 6910011330 TER OT-009 M3
S.=Surface mount
[CONNECT UNIT]
REF ORDER DESCRIPTION
NO. NO.
C1 4030010210 S.CER C3216 JB 1C 105M-T
C2 4030010210 S.CER C3216 JB 1C 105M-T
C3 4030010210 S.CER C3216 JB 1C 105M-T
C4 4030010210 S.CER C3216 JB 1C 105M-T
C5 4030010210 S.CER C3216 JB 1C 105M-T
C6 4030010210 S.CER C3216 JB 1C 105M-T
C7 4030010210 S.CER C3216 JB 1C 105M-T
C8 4030010210 S.CER C3216 JB 1C 105M-T
J1 6510017650 CON 52045-1045
J2 6510003411 CON B05B-EH-S(LF)(SN)
J3 6510003411 CON B05B-EH-S(LF)(SN)

Jun. 2010
14
[L-NET UNIT]
REF ORDER DESCRIPTION
NO. NO.
D1 1710000051 DIO 1SS53-AZ
D2 1710000051 DIO 1SS53-AZ
L1 6180000990 COI LAL 04NA 101K
L2 6180000990 COI LAL 04NA 101K
L3 6110003360 COI LA-530
L4 6110003500 COI LA-543
L5 6110003490 COI LA-542
C1 4020000970 CYL UP050B 472K Z
C2 4020000970 CYL UP050B 472K Z
C3 4010008840 CER DSTB90SJYR104K
C4 4010008840 CER DSTB90SJYR104K
RL1 6330000571 REL AR322173FC01
RL2 6330000571 REL AR322173FC01
EP1 6910011340 TER OT-010 M3
S.=Surface mount
[H-NET UNIT]
REF ORDER DESCRIPTION
NO. NO.
D1 1710000051 DIO 1SS53-AZ
D2 1710000051 DIO 1SS53-AZ
D3 1710000051 DIO 1SS53-AZ
D4 1710000051 DIO 1SS53-AZ
D5 1710000051 DIO 1SS53-AZ
D6 1710000051 DIO 1SS53-AZ
D7 1710000051 DIO 1SS53-AZ
D8 1710000051 DIO 1SS53-AZ
D9 1710000051 DIO 1SS53-AZ
D10 1710000051 DIO 1SS53-AZ
L1 6180000990 COI LAL 04NA 101K
L2 6180000990 COI LAL 04NA 101K
L3 6180000990 COI LAL 04NA 101K
L4 6180000990 COI LAL 04NA 101K
L5 6180000990 COI LAL 04NA 101K
L6 6180000990 COI LAL 04NA 101K
L7 6180000990 COI LAL 04NA 101K
L8 6180000990 COI LAL 04NA 101K
L9 6180000990 COI LAL 04NA 101K
L10 6180000990 COI LAL 04NA 101K
L11 6110003410 COI LA-535
L12 6110003400 COI LA-534
L13 6110003510 COI LA-544
L14 6110003380 COI LA-532
L15 6110003370 COI LA-531
C1 4010008840 CER DSTB90SJYR104K
C2 4010008840 CER DSTB90SJYR104K
C3 4010008840 CER DSTB90SJYR104K
C4 4010008840 CER DSTB90SJYR104K
C5 4010008840 CER DSTB90SJYR104K
C6 4010008840 CER DSTB90SJYR104K
C7 4010008840 CER DSTB90SJYR104K
C8 4010008840 CER DSTB90SJYR104K
C9 4010008840 CER DSTB90SJYR104K
C10 4010008840 CER DSTB90SJYR104K
C11 4020000970 CYL UP050B 472K Z
C12 4020000970 CYL UP050B 472K Z
C13 4020000970 CYL UP050B 472K Z
C14 4020000970 CYL UP050B 472K Z
C15 4020000970 CYL UP050B 472K Z
C16 4020000970 CYL UP050B 472K Z
C17 4020000970 CYL UP050B 472K Z
C18 4020000970 CYL UP050B 472K Z
C19 4020000970 CYL UP050B 472K Z
C20 4020000970 CYL UP050B 472K Z
RL1 6330000571 REL AR322173FC01
RL2 6330000571 REL AR322173FC01
RL3 6330000571 REL AR322173FC01
RL4 6330000571 REL AR322173FC01
RL5 6330000571 REL AR322173FC01
RL6 6330000571 REL AR322173FC01
RL7 6330000571 REL AR322173FC01
RL8 6330000571 REL AR322173FC01
RL9 6330000571 REL AR322173FC01
RL10 6330000571 REL AR322173FC01
EP2 6910011340 TER OT-010 M3

Jun. 2010
15
[C-NET UNIT]
REF ORDER DESCRIPTION
NO. NO.
D1 1710000051 DIO 1SS53-AZ
D2 1710000051 DIO 1SS53-AZ
D14 1710000051 DIO 1SS53-AZ
D15 1710000051 DIO 1SS53-AZ
D16 1710000051 DIO 1SS53-AZ
D17 1710000051 DIO 1SS53-AZ
D18 1710000051 DIO 1SS53-AZ
D19 1710000051 DIO 1SS53-AZ
D20 1710000051 DIO 1SS53-AZ
D21 1710000051 DIO 1SS53-AZ
L1 6180000990 COI LAL 04NA 101K
L2 6180000990 COI LAL 04NA 101K
L14 6180000990 COI LAL 04NA 101K
L15 6180000990 COI LAL 04NA 101K
L16 6180000990 COI LAL 04NA 101K
L17 6180000990 COI LAL 04NA 101K
L18 6180000990 COI LAL 04NA 101K
L19 6180000990 COI LAL 04NA 101K
L20 6180000990 COI LAL 04NA 101K
L21 6180000990 COI LAL 04NA 101K
C1 4020000970 CYL UP050B 472K Z
C2 4020000970 CYL UP050B 472K Z
C34 4020000970 CYL UP050B 472K Z
C39 4020000970 CYL UP050B 472K Z
C40 4010004790 CER DEC1X3J680JC4B (DE1210SL680J)
C41 4010004790 CER DEC1X3J680JC4B (DE1210SL680J)
C42 4010004790 CER DEC1X3J680JC4B (DE1210SL680J)
C43 4010004790 CER DEC1X3J680JC4B (DE1210SL680J)
C44 4020000970 CYL UP050B 472K Z
C45 4010008620 CER DEA1X3F221JA3B
C46 4010008620 CER DEA1X3F221JA3B
C47 4010008620 CER DEA1X3F221JA3B
C48 4010008620 CER DEA1X3F221JA3B
C49 4020000970 CYL UP050B 472K Z
C50 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C51 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C52 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C53 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C54 4020000970 CYL UP050B 472K Z
C55 4010008670 CER DEC1X3J150JC4B
C56 4010008670 CER DEC1X3J150JC4B
C57 4010008670 CER DEC1X3J150JC4B
C58 4010008670 CER DEC1X3J150JC4B
C59 4020000970 CYL UP050B 472K Z
C60 4010004800 CER DEC1X3J820JC4B (DE1210SL820J)
C61 4010004800 CER DEC1X3J820JC4B (DE1210SL820J)
C62 4010004800 CER DEC1X3J820JC4B (DE1210SL820J)
C63 4010004800 CER DEC1X3J820JC4B (DE1210SL820J)
C64 4020000970 CYL UP050B 472K Z
C65 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C66 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C67 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C68 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C69 4020000970 CYL UP050B 472K Z
C70 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C71 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C72 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C73 4010004830 CER DEC1X3J151JC4B (DE1510SL151J)
C74 4010008670 CER DEC1X3J150JC4B
C75 4010008670 CER DEC1X3J150JC4B
C76 4010008670 CER DEC1X3J150JC4B
C77 4010008670 CER DEC1X3J150JC4B
C82 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C84 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C86 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C87 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C88 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C89 4010004810 CER DEC1X3J101JC4B (DE1310SL101J)
C90 4010008670 CER DEC1X3J150JC4B
C91 4010008670 CER DEC1X3J150JC4B
C92 4010008670 CER DEC1X3J150JC4B
C93 4010008670 CER DEC1X3J150JC4B
C94 4010008670 CER DEC1X3J150JC4B
C95 4010008670 CER DEC1X3J150JC4B
C96 4010008670 CER DEC1X3J150JC4B
C97 4010008670 CER DEC1X3J150JC4B
RL1 6330001440 REL VS-12TBU-VD3
RL2 6330001440 REL VS-12TBU-VD3
RL3 6330000571 REL AR322173FC01
RL4 6330001490 REL VB-12MBU-UC
RL5 6330001490 REL VB-12MBU-UC
RL6 6330001490 REL VB-12MBU-UC
RL7 6330000571 REL AR322173FC01
RL8 6330001490 REL VB-12MBU-UC
RL9 6330001490 REL VB-12MBU-UC
RL10 6330001490 REL VB-12MBU-UC
S.=Surface mount

Jun. 2010
16
• MAIN UNIT
(TOP VIEW)
• PA-1/PA-2/PA-3/PA-4 UNIT
(TOP VIEW)
• FILTER UNIT
(TOP VIEW)
J4
J5
J5 1
3
M
GND
J1
J3
PA1 BOARD J4
PA1
BOARD J2
PA2
BOARD J2
PA3
BOARD J2
PA4
BOARD J2
EP1
EP2
TO PA-2
BOARD
J2
TO PX-1981
(OPTION)
TO COMBINR UNIT
TO PX-1981
(OPTION)
EP2
J1J2J4J3
EP1
(each PA bords)
(each PA bords) (each PA bords) (each PA bords)
10 2
91
TO PA4 BOARD J3
GND
PAF
PAF
GND
T8V
NC
GND
GND
GND
GND
T8V
GND
NC
J3
J4 J4 J4 J4
10
2
9
1
TO SPLITR UNIT J11
GND
PAF
PAF
GND
T8V
HV
GND
T8V
GND
NC
PA4 BOARD J4
PA3 BOARD J4 PA2 BOARD J4
10
2
9
1
TO PA3 BOARD J3
GND
PAF
PAF
GND
T8V
NC
T8V
GND
NC
10 2
91
TO PA2 BOARD J3
GND
PAF
PAF
GND
T8V
NC
T8V
GND
NC
10 2
91
NONE
GND
PAF
PAF
GND
T8V
NC
T8V
GND
NC
GND
HV
–
PAF
MF2
TO PA-3
BOARD
TO PX-1981
(OPTION)
EP2
EP2
GND
TO PX-1981
(OPTION)
TO PA-4
BOARD
EP1
EP1
HV
EP7
J8
J17
EP6
11
1
3
1
CP44
CP43
CP42
CP41
CP45
CP46
CP47
10
13 1
15
5
1
4
13
J9
P1
TO
FILTER
UNIT J1
TO
FILTER
UNIT
10M
14M
7M
35M
19M
50M
24M
18M
GND
10M
14M
7M
35M
19M
50M
24M
18M
GND
T13
FOR
REF
GND
T13
FOR
REF
GND
J1
1
110
101
3
1
3
P1
J2
TO
COMBINR
UNIT J8
TO JACK1
UNIT J9
BAL
13_1
13_2
SEND1
SEND2
ALC1
ALC2
CI5
FANV
GND
GND
13_1
13_2
SEND1
SEND2
ALC1
ALC2
CI5
FANV
GND
GND
GND
GND
BAL
GND
GND
J8
1
1
P1
J9
EP4
J3
11
5
9
9
J10 J6
TO SPLITR UNIT TO TUNER UNIT
(DET BOARD)
TO SPLITR UNIT
GND
F
5V
TEMP
IN
DRIV
T13
PAF
GND
1163
GND
F
5V
TEMP
IN
DRIV
T13
PAF
GND
11
112
11
99
J3
P3
5
6
1
1
1
2
3
4
5
6
7
2
2
3579
9
46 810
10
1
P1
J1
8
8
J21
50M 28M 21M 14M 10M
GND
50M 28M 21M 14M 10M
GND
NC NC
16
1
P1
–13R
5V
PV
RV
GND
–13R
5V
PV
RV
GND
15
5
J1
TO ANT-SW UNIT
J1
P1
S4
S3
S2
S1
GND
15
S4
S3
S2
S1
GND
J19 J22
TO TUNER UNIT
(C-NET BOARD)
1
P1
CO1B CO2B CO3B
VHCO
TU1
GND
CO1B CO2B CO3B
VHCO
TU1
GND
16
6
J1
J4
TO PX1981 (OPTIONAL UNIT)
P1
REGT
MAXI
REGHC
REGF
VD
ID
112
SEL
H12 H12
GND
–13V
GND
TO TUNER UNIT
(L-NET BOARD)
TO TUNER UNIT
(H-NET BOARD)
CLK
DATA
DATK
STR
H12
S12
DATA2
STR2
GND
1
7
J20
J18
TU2
VHCI
CI3B
CI2B
CI1B
GND
GND
1
9P4
CLK
DATA
DATK
STR
H12
S12
DATA2
STR2
GND
TO SW
BOARD
J1
1
P1
7M
35M
GND
7M
35M
GND
13
3
J1
TO TUNER UNIT
CPU WRITE
TO TUNER UNIT
(C-NET BOARD J2)
GND
13.8
IKEY
ISTA
TTRC
J14
RY
RW
PZ
PX
12V
RZ
RX
12V
PY
PW
1
2
9
10
TO TUNER UNIT
(CONNECT BOARD J1)
RY
RW
PZ
PX
12V
RZ
RX
12V
PY
PW
5
1
EP7 EP6
113
P1
J1
TO MAIN UNIT J8
TO COMBINR UNIT
TO
SPLITER
UNIT J8
FIN
50M
24M
18M
10M
10M
14M
14M
7M
7M
35M
35M
19M
19M
GND
50M
24M
18M
GND
GND
TRU
J2
T13
EP1 EP2
FOR
REF
GND
T13
FOR
REF
GND
EP3
EP4
SECTION 9
.
BOARD LAYOUTS

Jun. 2010
14
• PA-1/PA-2/PA-3/PA-4 UNIT
(BOTTOM VIEW)
• MAIN UNIT
(BOTTOM VIEW)
• FILTER UNIT
(BOTTOM VIEW)
TO TUNER UNIT
(DET BOARD)
TIN
GND EP8
EP7

SERVICE MANUAL
ADDENDUM
CONTENTS
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
BOARD LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 18
Apr. 2010

Apr. 2010
1
SECTION 5
.
PARTS LIST
[FRONT UNIT]
REF ORDER DESCRIPTION
NO. NO.
DS1 5080000380 LAM HRS-4160A-H9 L150
DS2 5080000380 LAM HRS-4160A-H9 L150
ME1 5510000470 MET ME-39 (KL-293S-09) EX1900
ME2 5510000460 MET ME-38 (KL-293S-8B) EX1900
EP1 6910011040 TUB A-4210-G20
EP2 6910011040 TUB A-4210-G20
S.=Surface mount
[SW UNIT]
REF ORDER DESCRIPTION
NO. NO.
IC1 1130007700 S.IC BU4094BCF-E2
IC2 1130007700 S.IC BU4094BCF-E2
IC3 1130007700 S.IC BU4094BCF-E2
IC4 1130007700 S.IC BU4094BCF-E2
IC5 1110003690 S.IC M62354GP 75EC
IC6 1180001072 S.IC TA7805F(TE16L1,NQ)
IC7 1130004670 S.IC BU4021BF-E2
IC8 1130007261 S.IC TC7W74FU(TE12L,F)
IC9 1130005821 S.IC TC4S584F(TE85R,F)
IC11 1130007301 S.IC TC4W66FU(TE12L,F)
Q1 1590002310 S.TRA DTC114EE TL
Q2 1590002310 S.TRA DTC114EE TL
Q3 1590002310 S.TRA DTC114EE TL
Q4 1590002310 S.TRA DTC114EE TL
Q5 1590002310 S.TRA DTC114EE TL
Q6 1590002310 S.TRA DTC114EE TL
Q7 1590002310 S.TRA DTC114EE TL
Q8 1590002310 S.TRA DTC114EE TL
Q9 1590002310 S.TRA DTC114EE TL
Q10 1590002310 S.TRA DTC114EE TL
Q11 1590002310 S.TRA DTC114EE TL
Q12 1590002310 S.TRA DTC114EE TL
Q13 1590002310 S.TRA DTC114EE TL
Q14 1590002310 S.TRA DTC114EE TL
Q15 1590002310 S.TRA DTC114EE TL
Q16 1590002310 S.TRA DTC114EE TL
Q17 1590002310 S.TRA DTC114EE TL
Q18 1530002691 S.TRA 2SC4116-GR(TE85R,F)
Q19 1590002310 S.TRA DTC114EE TL
Q20 1590002310 S.TRA DTC114EE TL
Q21 1590002310 S.TRA DTC114EE TL
Q22 1590002310 S.TRA DTC114EE TL
Q23 1590002310 S.TRA DTC114EE TL
Q24 1590002310 S.TRA DTC114EE TL
Q25 1590002310 S.TRA DTC114EE TL
Q26 1590002310 S.TRA DTC114EE TL
Q27 1590002310 S.TRA DTC114EE TL
Q31 1590001940 S.TRA DTC144EE TL
Q32 1520000460 S.TRA 2SB1132 T100 R
D1 1750000271 S.DIO 1SS301(TE85L,F)
D2 1750000271 S.DIO 1SS301(TE85L,F)
D3 1750000291 S.DIO 1SS300(TE85R,F)
D4 1750000291 S.DIO 1SS300(TE85R,F)
D5 1730002321 S.ZEN MAZ8051GML
D6 1750000271 S.DIO 1SS301(TE85L,F)
D7 1750000291 S.DIO 1SS300(TE85R,F)
D10 1750000231 S.DIO 1SS315(TPH3,F)
D11 1750000231 S.DIO 1SS315(TPH3,F)
D13 1750000291 S.DIO 1SS300(TE85R,F)
D16 1750000271 S.DIO 1SS301(TE85L,F)
L1 6200003261 S.COI NLV32T-101J
L2 6200003261 S.COI NLV32T-101J
L3 6200003261 S.COI NLV32T-101J
L4 6200003261 S.COI NLV32T-101J
L5 6200003950 S.COI HF50ACC 322513-T
L6 6200003950 S.COI HF50ACC 322513-T
L7 6200003261 S.COI NLV32T-101J
L8 6200003261 S.COI NLV32T-101J
L9 6200003950 S.COI HF50ACC 322513-T
R1 7030003340 S.RES ERJ3GEYJ 151 V (150)
R2 7030003340 S.RES ERJ3GEYJ 151 V (150)
R3 7030003340 S.RES ERJ3GEYJ 151 V (150)
R4 7030009220 S.RES ERJ12YJ561U
R5 7030003340 S.RES ERJ3GEYJ 151 V (150)
R6 7030003340 S.RES ERJ3GEYJ 151 V (150)
R7 7030003340 S.RES ERJ3GEYJ 151 V (150)
R8 7030009220 S.RES ERJ12YJ561U
R9 7030003340 S.RES ERJ3GEYJ 151 V (150)
R10 7030003340 S.RES ERJ3GEYJ 151 V (150)
R11 7030003340 S.RES ERJ3GEYJ 151 V (150)
R12 7030003340 S.RES ERJ3GEYJ 151 V (150)
R13 7030003340 S.RES ERJ3GEYJ 151 V (150)
R14 7030003340 S.RES ERJ3GEYJ 151 V (150)
R15 7030003340 S.RES ERJ3GEYJ 151 V (150)
R16 7030003340 S.RES ERJ3GEYJ 151 V (150)
R17 7030003340 S.RES ERJ3GEYJ 151 V (150)
R18 7030003340 S.RES ERJ3GEYJ 151 V (150)
R19 7030003340 S.RES ERJ3GEYJ 151 V (150)
R20 7030003340 S.RES ERJ3GEYJ 151 V (150)
R21 7030003340 S.RES ERJ3GEYJ 151 V (150)
R22 7030003340 S.RES ERJ3GEYJ 151 V (150)
R23 7030003340 S.RES ERJ3GEYJ 151 V (150)
R24 7030003340 S.RES ERJ3GEYJ 151 V (150)
R25 7030009220 S.RES ERJ12YJ561U
R26 7030003340 S.RES ERJ3GEYJ 151 V (150)
R27 7030003340 S.RES ERJ3GEYJ 151 V (150)
R29 7030003720 S.RES ERJ3GEYJ 224 V (220K)
R30 7030008190 S.RES ERJ12YJ330U (33)
R31 7030003640 S.RES ERJ3GEYJ 473 V (47K)
R32 7030003640 S.RES ERJ3GEYJ 473 V (47K)
