Icom PW1 Quick guide

PW1 Linear Amplifier
Setup / Configuration
Icom America Inc.
TSR

TSR
Setting up the Icom PW1
Using the PW1 with 1 or 2 Icom exciters
Physical connections (1 radio)
Physical connections (2 radios)
“Synchronization”
Setting the ALC levels

TSR
Physical Connections (1 Icom radio)
There are only 3 cables required between the PW1 and an Icom radio.
(All 3 cables are included)

TSR
Physical Connections (1 Icom radio)
1 “accessory” cable. (7 pin “DIN” cable)

TSR
Physical Connections (1 Icom radio)
1 “remote” cable. (3.5mm “phono” cable)

TSR
Physical Connections (1 Icom radio)
1 coaxial cable. (50 ohm coax, RG8, etc)

TSR
Physical Connections (1 Icom radio)
The IC-718, 706 series or IC-7000 will also require the optional OPC
599 adapter.

TSR
Physical Connections (1 Icom radio)
Connect the DIN cable to the radio’s “ACC 2” port (7 pin)
** Note that the ports on the PW1 and radio are not labeled the same**

TSR
Physical Connections (1 Icom radio)
Connect the remote cable to the radio’s “remote” port

TSR
Physical Connections (1 Icom radio)
Connect the coax cable to the radio’s “ANT 1” port

TSR
Physical Connections (1 Icom radio)
Make sure the exciter (radio) switch is in the “1” position

TSR
Physical Connections (1 Icom radio)
Connect the 7 pin DIN cable to “ACC 1” of the PW1

TSR
Physical Connections (1 Icom radio)
Connect the remote cable to “remote 1” of the PW1

TSR
Physical Connections (1 Icom radio)
Connect the coax cable to “Input 1” of the PW1

TSR
Physical Connections (1 Icom radio)
Connect your antenna to “ANT 1” of the PW1

TSR
Physical Connections (1 Icom radio)
Connect your dummy load to “ANT 4” of the PW1 (if applicable)

TSR
Physical Connections (2 Icom radios)
Make sure the exciter (radio) switch is in the “1 & 2” position

TSR
Physical Connections (2 Icom radios)
Connect the second radio the same way, using the “2” ports of the PW1

TSR
Synchronization
The PW1 will automatically change bands, as needed, when the radio
frequency is changed.
Synchronization may not be possible with a non-Icom radio.
The synchronization commands are CI-V commands sent from the
radio via the remote cable.
Use of a CT-17 is not recommended with the PW1.

TSR
Synchronization
First, make sure your radio is off, then perform a reset of the PW1 by
pressing and holding the [UP] and [DOWN] buttons while turning the
PW1 on.
