SERVICE MANUAL

ADDENDUM

CONTENTS

REPLACEMENT PAGES . . . . . . . . . . . . . . . . . . . . . . 6-1, 6-5, 6-6 and 7-1 to 7-9

PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

BOARD LAYOUTS . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

VOLTAGE DIAGRAM . . . . . . . . . . . . . . . . . . . . . . . . . 18

April 2013

Model Version Symbol

Frequency

range

(MHz)

Channel spacing

(kHz) Key

IC-F3021T

USA-02

[#01]

136–174

15.0

10 key

USA-03

[#21] 6.25/15.0/30.0

IC-F3022T

EUR-02

[#02] 12.5/20.0/25.0

CHN-01

[#07] 12.5/25.0 4 key

EUR-03

[#22] 6.25/12.5/20.0/25.0

10 key

IC-F3023T

GEN-02

[#03] 12.5/25.0

GEN-03

[#23] 6.25/12.5/25.0

IC-F3023T-T THA-01 [#05]

12.5/25.0

IC-F3026T

[#04]

IC-F3026T

RUS-01

[#09]

IC-F3033T

EXP-01

[#93]

EXP-02

[#96]

IC-F3033T-T

THA-01

[#95]

IC-F3036T

RUS-01

[#99]

IC-F3021S

USA-02

[#41] 15.0

USA-03

[#61] 6.25/15.0/30.0

IC-F3022S

NOR-02

[#45]

12.5/25.0

4 key

NOR-01

[#46]

CHN-01

[#47]

ESP-01

[#48]

EUR-02

[#42] 12.5/20.0/25.0

NOR-03

[#50] 12.5/25.0

EUR-03

[#62] 6.25/12.5/20.0/25.0

IC-F3023S

GEN-02

[#43] 12.5/25.0

AUS-01

[#53]

GEN-03

[#63] 6.25/12.5/25.0

KOR-01

[#73]

12.5/25.0

IC-F3026S

EXP-01

[#44]

RUS-01

[#49]

IC-F3031S

USA-02

[#81] 15.0

IC-F3032S

EUR-02

[#82] 12.5/20.0/25.0

NOR-02

[#85]

12.5/25.0

NOR-01

[#86]

ESP-01

[#88]

NOR-03

[#90]

IC-F3033S

EXP-01

[#83]

IC-F3036S

RUS-01

[#89]

[VERSION LIST]

SECTION 6 ADJUSTMENT PROCEDURES

6-1 PREPARATION

When adjusting IC-F3020 series, CS-F3020 CLONING SOFTWARE, CS-F3020 ADJ ADJUSTMENT SOFTWARE (Rev. 1.0 or later),

OPC-478/U JIG CABLE (modiﬁed OPC-478/U CLONING CABLE; see the page 6-2) and the following test equipments are required.

EQUIPMENT GRADE AND RANGE EQUIPMENT GRADE AND RANGE

DC power supply Output voltage

Current capacity

: 7.2 V DC

: More than 1.5 A External speaker Input impedance

Capacity

: 8 Ω

: 1 W or more

FM deviation meter Frequency range

Measuring range

: DC–300 MHz

: 0 to ±10 kHz Attenuator Power attenuation

Capacity

: 20 or 30 dB

: 7.5 W

Frequency counter

Frequency range

Frequency accuracy

Sensitivity

: 0.1–300 MHz

: ±1 ppm or better

: 100 mV or better

Standard signal

generator (SSG)

Frequency range

Output level

: 0.1–300 MHz

: 0.1 µV to 32 mV

(–127 to –17 dBm)

RF power meter

Measuring range

Frequency range

Impedance

SWR

: 0.1–7.5 W

: 100–300 MHz

: 50 Ω

: Better than 1.2 : 1

Oscilloscope Frequency rang

Measuring range

: DC–20 MHz

: 0.01–20 V

6 - 1

MSYSTEM REQUIREMENTS (for the ADJUSTMENT SOFTWARE)

• Microsoft®Windows®98/98SE/Me/2000/XP • RS-232C serial port (D-sub 9 pin) or USB port

M STARTING SOFTWARE ADJUSTMENT

1) Connect the transceiver and PC with OPC-478/U JIG

CABLE.

2) Turn the transceiver power ON.

3) Boot up Windows, and click the program group ‘CS-F3020

ADJ’ in the ‘Programs’ folder of the [Start] menu, then CS-

F3020 ADJ’s window appears.

4) Click ‘Connect’ on the CS-F3020 ADJ’s window, then the

window shows transceiver’s condition and adjustment items

as below.

5) Set or modify adjustment data as speciﬁed.

M BEFORE STARTING SOFTWARE ADJUSTMENT

Clone the adjustment frequencies and settings into the

transceiver, and set the conﬁguration using the CS-F3020

CLONING SOFTWARE before starting the software adjustment.

Otherwise, the software adjustment can not be started.

CAUTION!: BACK UP the originally programmed memory

data in the transceiver before programming the

adjustment frequencies. When program the ad-

justment frequencies into the transceiver, the

transceiver’s memory data will be overwritten

and lose original memory data at the same time.

Microsoft and Windows are registered trademarks of

Microsoft Corporation in the U.S.A. and other countries.

M ADJUSTMENT SOFTWARE INSTALLATION

1) Quit all applications when Windows is running.

2) Insert the CD into the appropriate CD drive.

3) Double-click the “Setup.exe” contained in the ‘CS-F3020

ADJ’ folder in the CD drive.

4) The “Welcome to the InstallShield Wizard for CS-F3020

ADJ” will appear. Click [Next>].

5) The “Choose Destination Location” will appear. Then click

[Next>] to install the software to the destination folder. (e.g.

C:\Program Files\Icom\CS-F3020 ADJ)

After the installation is completed, the “InstallShield Wiz-

ard Complete” will appear. Then click [Finish].

7) Eject the CD.

8) Program group ‘CS-F3020 ADJ’ appears in the ‘Programs’

folder of the start menu, and ‘CS-F3020 ADJ’ icon ap-

pears on the desk top screen.

• ADJUSTMENT FREQUENCY LIST

CH FREQUENCY ADJUSTMENT ITEM

1 174.000 MHz TX power

Mode

: Low1

: Narrow

2 136.000 MHz TX power

Mode

: Low1

: Wide

3 155.000 MHz TX power

Mode

: High

: Wide

4 155.000 MHz TX power

Mode

: Low2

: Wide

5 155.000 MHz TX power

Mode

: Low1

: Narrow

6 155.000 MHz

TX power

Mode

DTCS

: Low1

: Narrow

: 007

7* 155.000 MHz TX power

Mode

: Low1

: Middle

8 155.000 MHz

TX power

Mode

CTCSS

: Low1

: Wide

: 151.4 Hz

9 155.000 MHz TX power

Mode

: Low1

: Wide

10 155.000 MHz

TX power

Mode

CTCSS

: Low1

: Wide

: 151.4 Hz

*; [EUR] only

April 2013 (Replacement page)

6 - 5

6-3 TRANSMIT ADJUSTMENT

Select an adjustment item using [↑] / [↓] keys, then set to the speciﬁed value using [←] / [→] keys on the connected PC’s keyboard.

ADJUSTMENT ADJUSTMENT CONDITION MEASUREMENT VALUE

UNIT OPERATION

OUTPUT

POWER

[Power (Hi)]

1 • Channel

• Transmitting

: CH 3 Top

panel

Connect an RF power meter to

the antenna connector.

5.0 W

[Power (L2)] 2 • Channel

• Transmitting

: CH 4 2.0 W

[Power (L1)] 3 • Channel

• Transmitting

: CH 5 1.0 W

MODULATION

BALANCE

[BAL]

1 • Channel : CH 6 Top

panel

Connect the FM deviation me-

ter to the antenna connector

through an attenuator.

Set to square wave form

• No audio applied to the JIG cable.

• Set an FM deviation meter same as;

HPF

LPF

De-emphasis

Detector

: OFF

: 20 kHz

: OFF

: (P–P)/2

• Transmitting

DEVIATION

(NARROW)

[MOD N]

1• Channel : CH 5 Top

panel

Connect the FM deviation me-

ter to the antenna connector

through an attenuator.

±2.05 to ±2.15 kHz

• Connect an audio generator to the JIG

cable and set as;

Frequency : 1.0 kHz

Level : 150 mV rms

• Set the FM deviation meter to same condi-

tion as “MODULATION BALANCE.”

• Transmitting

(WIDE)**

[MOD ratio]

2• Channel

• Transmitting

: CH 9 ±4.05 to ±4.15 kHz

(MIDDLE)*

[MOD ratio]

3• Channel

• Transmitting

: CH 7 ±3.15 to ±3.25 kHz

CTCSS/DTCS

DEVIATION

[CTCS/DTCS]

(WIDE)**

1• Channel : CH 8 Top

panel

Connect an FM deviation meter to

the antenna connector through

an attenuator.

±0.68 to ±0.72 kHz

• No audio applied to the JIG cable.

• Set the FM deviation meter to same condi-

tion as “MODULATION BALANCE.”

• Transmitting

(Narrow) 2 • Channel : CH 10 ±0.33 to ±0.37 kHz

• Transmitting

*; [EUR] only. **; For all models expect [USA].

April 2013 (Replacement page)

6 - 6

6-4 RECEIVE ADJUSTMENT

Select an adjustment item using [↑] / [↓] keys, then set to the speciﬁed value using [←] / [→] keys on the connected PC’s keyboard.

ADJUSTMENT ADJUSTMENT CONDITION MEASUREMENT VALUE

UNIT LOCATION

RECEIVE

SENSITIVITY

[BPF (T1)]

[BPF (T2)]

NOTE: “RECEIVE SENSITIVITY” must be adjusted before “S-METER.” Otherwise, “S-METER” will not be

adjusted properly.

1• Channel : CH 2 [MIC/SP]

jack

Connect the SINAD meter

with an 8 Ωload to the JIG

cable.

Minimum distortion

level

• Connect the SSG to the antenna connec-

tor and set as;

Frequency

Level

Modulation

Deviation

• Receiving

: 136.000 MHz

: +20 dBµ†(–87 dBm)

: 1 kHz

: ±3.5 kHz

CONVENIENT:

The “RECEIVE SENSITIVITY” can be adjusted automatically.

1: Put the cursor on “BPF ALL” and push [ENTER] key.

2: The connected PC tunes BPF’s to peak levels automaticaly.

S-METER

[RSSI]

1• Channel : CH 2 Push the [ENTER] key on the connected PC’s keyboard to set

“S3” level.

• Connect the SSG to the antenna connec-

tor and set as;

Frequency

Level

Modulation

Deviation

• Receiving

: 136.000 MHz

: +23 dBµ† (–84 dBm)

: 1 kHz

: ±3.5 kHz

2• Set the SSG as;

Level

• Receiving

: –7 dBµ† (–114 dBm)

Push the [ENTER] key on the connected PC’s keyboard to set

“S1” level.

SQUELCH

[SQL]

1 • Channel : CH 9 External

speaker

Connect an 8 Ω speaker to

the JIG cable.

Set the [SQL] to the

value that the audio

signals just appears.

• Close the squelch by adjusting the value of

[SQL] item on the CS-F3020 ADJ’s screen.

• Connect the SSG to the antenna connec-

tor and set as;

Frequency

Level

Modulation

Deviation

• Receiving

: 155.000 MHz

: –15 dBµ† (–122 dBm)

: 1 kHz

: ±3.5 kHz

†; The output level of the standard signal generator (SSG) is indicated as the SSG’s open circuit.

April 2013 (Replacement page)

(Replacement page)

7 - 1

SECTION 7

MECHANICAL PARTS

*: Refer to “BOARD LAYOUTS” for the location.

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

April 2013

[CHASSIS PARTS]

REF ORDER DESCRIPTION QTY.

NO. NO.

MP2 8210022971 2927 T-FRONT PANEL ASSEMBLY-1 [#01] 1

8210022971 2927 T-FRONT PANEL ASSEMBLY-1 [#02] 1

8210022971 2927 T-FRONT PANEL ASSEMBLY-1 [#03] 1

8210022971 2927 T-FRONT PANEL ASSEMBLY-1 [#04] 1

8210022971 2927 T-FRONT PANEL ASSEMBLY-1 [#05] 1

8210022971 2927 T-FRONT PANEL ASSEMBLY-1 [#07] 1

8210022971 2927 T-FRONT PANEL ASSEMBLY-1 [#09] 1

8210022971 2927 T-FRONT PANEL ASSEMBLY-1 [#21] 1

8210022971 2927 T-FRONT PANEL ASSEMBLY-1 [#22] 1

8210022971 2927 T-FRONT PANEL ASSEMBLY-1 [#23] 1

8210022981 2927 S-FRONT PANEL ASSEMBLY-1 [#41] 1

8210022981 2927 S-FRONT PANEL ASSEMBLY-1 [#42] 1

8210022981 2927 S-FRONT PANEL ASSEMBLY-1 [#43] 1

8210022981 2927 S-FRONT PANEL ASSEMBLY-1 [#44] 1

8210026340 2927 S-FRONT PANEL [#45] 1

8210024060 2927 S-FRONT PANEL (A) [#46] 1

8210022981 2927 S-FRONT PANEL ASSEMBLY-1 [#47] 1

8210024060 2927 S-FRONT PANEL (A) [#48] 1

8210022981 2927 S-FRONT PANEL ASSEMBLY-1 [#49] 1

8210027470 2927 S-FRONTPANEL (D)-1 [#50] 1

8210022981 2927 S-FRONT PANEL ASSEMBLY-1 [#53] 1

8210022981 2927 S-FRONT PANEL ASSEMBLY-1 [#61] 1

8210022981 2927 S-FRONT PANEL ASSEMBLY-1 [#62] 1

8210022981 2927 S-FRONT PANEL ASSEMBLY-1 [#63] 1

8210027340 2926 S-FRONT PANEL ASSEMBLY [#81] 1

8210027340 2926 S-FRONT PANEL ASSEMBLY [#82] 1

8210027340 2926 S-FRONT PANEL ASSEMBLY [#83] 1

8210028180 2926 S-FRONTPANEL [#85] 1

8210027770 2926 S-FRONT PANEL (A) ASSEMBLY [#86] 1

8210027770 2926 S-FRONT PANEL (A) ASSEMBLY [#88] 1

8210027340 2926 S-FRONT PANEL ASSEMBLY [#89] 1

8210028180 2926 S-FRONTPANEL [#90] 1

8210028450 2926 T-FRONT PANEL ASSEMBLY [#93] 1

8210028450 2926 T-FRONT PANEL ASSEMBLY [#95] 1

8210028450 2926 T-FRONT PANEL ASSEMBLY [#96] 1

8210028450 2926 T-FRONT PANEL ASSEMBLY [#99] 1

J1 6910021491 ANT CONNECTOR 106-1 <SSC> 1

J2 6910015860 IMSA-6277S-02A-G 1

SP1 2510001061 K036NA500-67 <OSC> [#01] 1

2510001061 K036NA500-67 <OSC> [#02] 1

2510001061 K036NA500-67 <OSC> [#03] 1

2510001061 K036NA500-67 <OSC> [#04] 1

2510001061 K036NA500-67 <OSC> [#05] 1

2510001061 K036NA500-67 <OSC> [#07] 1

2510001061 K036NA500-67 <OSC> [#09] 1

2510001061 K036NA500-67 <OSC> [#21] 1

2510001061 K036NA500-67 <OSC> [#22] 1

2510001061 K036NA500-67 <OSC> [#23] 1

2510001061 K036NA500-67 <OSC> [#41] 1

2510001061 K036NA500-67 <OSC> [#42] 1

2510001061 K036NA500-67 <OSC> [#43] 1

2510001061 K036NA500-67 <OSC> [#44] 1

2510001061 K036NA500-67 <OSC> [#45] 1

2510001061 K036NA500-67 <OSC> [#46] 1

2510001061 K036NA500-67 <OSC> [#47] 1

2510001061 K036NA500-67 <OSC> [#48] 1

2510001061 K036NA500-67 <OSC> [#49] 1

2510001061 K036NA500-67 <OSC> [#50] 1

2510001061 K036NA500-67 <OSC> [#53] 1

2510001061 K036NA500-67 <OSC> [#61] 1

2510001061 K036NA500-67 <OSC> [#62] 1

2510001061 K036NA500-67 <OSC> [#63] 1

2510001610 K036NA513-10 <OSC> [#81] 1

2510001610 K036NA513-10 <OSC> [#82] 1

2510001610 K036NA513-10 <OSC> [#83] 1

2510001610 K036NA513-10 <OSC> [#85] 1

2510001610 K036NA513-10 <OSC> [#86] 1

2510001610 K036NA513-10 <OSC> [#88] 1

2510001610 K036NA513-10 <OSC> [#89] 1

2510001610 K036NA513-10 <OSC> [#90] 1

2510001610 K036NA513-10 <OSC> [#93] 1

2510001610 K036NA513-10 <OSC> [#95] 1

2510001610 K036NA513-10 <OSC> [#96] 1

2510001610 K036NA513-10 <OSC> [#99] 1

W1 8900009640 OPC-963 1

Model Version Symbol

IC-F3021T

USA-02

[#01]

USA-03

[#21]

IC-F3022T

EUR-02

[#02]

CHN-01

[#07]

EUR-03

[#22]

IC-F3023T

GEN-02

[#03]

GEN-03

[#23]

IC-F3023T-T THA-01 [#05]

IC-F3026T

[#04]

IC-F3026T

RUS-01

[#09]

IC-F3033T

EXP-01

[#93]

EXP-02

[#96]

IC-F3033T-T

THA-01

[#95]

IC-F3036T

RUS-01

[#99]

IC-F3021S

USA-02

[#41]

USA-03

[#61]

IC-F3022S

NOR-02

[#45]

NOR-01

[#46]

CHN-01

[#47]

ESP-01

[#48]

EUR-02

[#42]

NOR-03

[#50]

EUR-03

[#62]

IC-F3023S

GEN-02

[#43]

AUS-01

[#53]

GEN-03

[#63]

KOR-01

[#73]

IC-F3026S

EXP-01

[#44]

RUS-01

[#49]

IC-F3031S

USA-02

[#81]

IC-F3032S

EUR-02

[#82]

NOR-02

[#85]

NOR-01

[#86]

ESP-01

[#88]

NOR-03

[#90]

IC-F3033S

EXP-01

[#83]

IC-F3036S

RUS-01

[#89]

[VERSION LIST]

(Replacement page)

April 2013

7 - 2

*: Refer to “BOARD LAYOUTS” for the location.

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

[CHASSIS PARTS] [CHASSIS PARTS]

REF ORDER DESCRIPTION QTY.

NO. NO.

REF ORDER DESCRIPTION QTY.

NO. NO.

MP1 8010020412 2927 CHASSIS-2 T [#01] 1

8010020412 2927 CHASSIS-2 T [#02] 1

8010020412 2927 CHASSIS-2 T [#03] 1

8010020412 2927 CHASSIS-2 T [#04] 1

8010020412 2927 CHASSIS-2 T [#05] 1

8010020412 2927 CHASSIS-2 T [#07] 1

8010020412 2927 CHASSIS-2 T [#09] 1

8010020412 2927 CHASSIS-2 T [#21] 1

8010020412 2927 CHASSIS-2 T [#22] 1

8010020412 2927 CHASSIS-2 T [#23] 1

8010020412 2927 CHASSIS-2 T [#41] 1

8010020412 2927 CHASSIS-2 T [#42] 1

8010020412 2927 CHASSIS-2 T [#43] 1

8010020412 2927 CHASSIS-2 T [#44] 1

8010020412 2927 CHASSIS-2 T [#45] 1

8010020412 2927 CHASSIS-2 T [#46] 1

8010020412 2927 CHASSIS-2 T [#47] 1

8010020412 2927 CHASSIS-2 T [#48] 1

8010020412 2927 CHASSIS-2 T [#49] 1

8010020412 2927 CHASSIS-2 T [#50] 1

8010020412 2927 CHASSIS-2 T [#53] 1

8010020412 2927 CHASSIS-2 T [#61] 1

8010020412 2927 CHASSIS-2 T [#62] 1

8010020412 2927 CHASSIS-2 T [#63] 1

8010022270 2926 CHASSIS [#81] 1

8010022270 2926 CHASSIS [#82] 1

8010022270 2926 CHASSIS [#83] 1

8010022270 2926 CHASSIS [#85] 1

8010022270 2926 CHASSIS [#86] 1

8010022270 2926 CHASSIS [#88] 1

8010022270 2926 CHASSIS [#89] 1

8010022270 2926 CHASSIS [#90] 1

8010022270 2926 CHASSIS [#93] 1

8010022270 2926 CHASSIS [#95] 1

8010022270 2926 CHASSIS [#96] 1

8010022270 2926 CHASSIS [#99] 1

MP8 8210020551 2721 REAR PANEL-1 1

MP9 8310066450 2927 WINDOW PLATE [#01] 1

8310066450 2927 WINDOW PLATE [#02] 1

8310066450 2927 WINDOW PLATE [#03] 1

8310066450 2927 WINDOW PLATE [#04] 1

8310066450 2927 WINDOW PLATE [#05] 1

8310066450 2927 WINDOW PLATE [#07] 1

8310066450 2927 WINDOW PLATE [#09] 1

8310066450 2927 WINDOW PLATE [#21] 1

8310066450 2927 WINDOW PLATE [#22] 1

8310066450 2927 WINDOW PLATE [#23] 1

8310066450 2927 WINDOW PLATE [#41] 1

8310066450 2927 WINDOW PLATE [#42] 1

8310066450 2927 WINDOW PLATE [#43] 1

8310066450 2927 WINDOW PLATE [#44] 1

8310066450 2927 WINDOW PLATE [#45] 1

8310066450 2927 WINDOW PLATE [#46] 1

8310066450 2927 WINDOW PLATE [#47] 1

8310066450 2927 WINDOW PLATE [#48] 1

8310066450 2927 WINDOW PLATE [#49] 1

8310066450 2927 WINDOW PLATE [#50] 1

8310066450 2927 WINDOW PLATE [#53] 1

8310066450 2927 WINDOW PLATE [#61] 1

8310066450 2927 WINDOW PLATE [#62] 1

8310066450 2927 WINDOW PLATE [#63] 1

8310079210 2926 WINDOW PLATE [#81] 1

8310079210 2926 WINDOW PLATE [#82] 1

8310079210 2926 WINDOW PLATE [#83] 1

8310079210 2926 WINDOW PLATE [#85] 1

8310079210 2926 WINDOW PLATE [#86] 1

8310079210 2926 WINDOW PLATE [#88] 1

8310079210 2926 WINDOW PLATE [#89] 1

8310079210 2926 WINDOW PLATE [#90] 1

8310079210 2926 WINDOW PLATE [#93] 1

8310079210 2926 WINDOW PLATE [#95] 1

8310079210 2926 WINDOW PLATE [#96] 1

8310079210 2926 WINDOW PLATE [#99] 1

MP10 8930069510 2927 WINDOW SHEET [#01] 1

8930069510 2927 WINDOW SHEET [#02] 1

8930069510 2927 WINDOW SHEET [#03] 1

8930069510 2927 WINDOW SHEET [#04] 1

8930069510 2927 WINDOW SHEET [#05] 1

8930069510 2927 WINDOW SHEET [#07] 1

8930069510 2927 WINDOW SHEET [#09] 1

8930069510 2927 WINDOW SHEET [#21] 1

8930069510 2927 WINDOW SHEET [#22] 1

8930069510 2927 WINDOW SHEET [#23] 1

8930069510 2927 WINDOW SHEET [#41] 1

8930069510 2927 WINDOW SHEET [#42] 1

8930069510 2927 WINDOW SHEET [#43] 1

8930069510 2927 WINDOW SHEET [#44] 1

8930069510 2927 WINDOW SHEET [#45] 1

8930069510 2927 WINDOW SHEET [#46] 1

8930069510 2927 WINDOW SHEET [#47] 1

8930069510 2927 WINDOW SHEET [#48] 1

8930069510 2927 WINDOW SHEET [#49] 1

8930069510 2927 WINDOW SHEET [#50] 1

8930069510 2927 WINDOW SHEET [#53] 1

8930069510 2927 WINDOW SHEET [#61] 1

8930069510 2927 WINDOW SHEET [#62] 1

8930069510 2927 WINDOW SHEET [#63] 1

8930084340 2926 WINDOW SHEET [#81] 1

8930084340 2926 WINDOW SHEET [#82] 1

8930084340 2926 WINDOW SHEET [#83] 1

8930084340 2926 WINDOW SHEET [#85] 1

8930084340 2926 WINDOW SHEET [#86] 1

8930084340 2926 WINDOW SHEET [#88] 1

8930084340 2926 WINDOW SHEET [#89] 1

8930084340 2926 WINDOW SHEET [#90] 1

8930084340 2926 WINDOW SHEET [#93] 1

8930084340 2926 WINDOW SHEET [#95] 1

8930084340 2926 WINDOW SHEET [#96] 1

8930084340 2926 WINDOW SHEET [#99] 1

MP12 8930069490 2927 KEYBOARD <SEP> [#01] 1

8930069490 2927 KEYBOARD <SEP> [#02] 1

8930069490 2927 KEYBOARD <SEP> [#03] 1

8930069490 2927 KEYBOARD <SEP> [#04] 1

8930069490 2927 KEYBOARD <SEP> [#05] 1

8930069490 2927 KEYBOARD <SEP> [#07] 1

8930069490 2927 KEYBOARD <SEP> [#09] 1

8930069490 2927 KEYBOARD <SEP> [#21] 1

8930069490 2927 KEYBOARD <SEP> [#22] 1

8930069490 2927 KEYBOARD <SEP> [#23] 1

8930069700 2927 4-KEY <SEP> [#41] 1

8930069700 2927 4-KEY <SEP> [#42] 1

8930069700 2927 4-KEY <SEP> [#43] 1

8930069700 2927 4-KEY <SEP> [#44] 1

8930072910 2927 4-KEY <SEP> [#45] 1

8930072910 2927 4-KEY <SEP> [#46] 1

8930069700 2927 4-KEY <SEP> [#47] 1

8930072910 2927 4-KEY <SEP> [#48] 1

8930069700 2927 4-KEY <SEP> [#49] 1

8930072910 2927 4-KEY <SEP> [#50] 1

8930069700 2927 4-KEY <SEP> [#53] 1

8930069700 2927 4-KEY <SEP> [#61] 1

8930069700 2927 4-KEY <SEP> [#62] 1

8930069700 2927 4-KEY <SEP> [#63] 1

8930084020 2926 4-KEY <SEP> [#81] 1

8930084020 2926 4-KEY <SEP> [#82] 1

8930084020 2926 4-KEY <SEP> [#83] 1

8930084960 2926 4-KEY (A) <SEP> [#85] 1

8930084960 2926 4-KEY (A) <SEP> [#86] 1

8930084960 2926 4-KEY (A) <SEP> [#88] 1

8930084020 2926 4-KEY <SEP> [#89] 1

8930084960 2926 4-KEY (A) <SEP> [#90] 1

8930086740 2926 KEYBOARD <SEP> [#93] 1

8930086740 2926 KEYBOARD <SEP> [#95] 1

8930086740 2926 KEYBOARD <SEP> [#96] 1

8930086740 2926 KEYBOARD <SEP> [#99] 1

(Replacement page)

April 2013

7 - 3

[CHASSIS PARTS]

REF ORDER DESCRIPTION QTY.

NO. NO.

MP13 8930069500 2927 MAIN SEAL (TOP) [#01] 1

8930069500 2927 MAIN SEAL (TOP) [#02] 1

8930069500 2927 MAIN SEAL (TOP) [#03] 1

8930069500 2927 MAIN SEAL (TOP) [#04] 1

8930069500 2927 MAIN SEAL (TOP) [#05] 1

8930069500 2927 MAIN SEAL (TOP) [#07] 1

8930069500 2927 MAIN SEAL (TOP) [#09] 1

8930069500 2927 MAIN SEAL (TOP) [#21] 1

8930069500 2927 MAIN SEAL (TOP) [#22] 1

8930069500 2927 MAIN SEAL (TOP) [#23] 1

8930069500 2927 MAIN SEAL (TOP) [#41] 1

8930069500 2927 MAIN SEAL (TOP) [#42] 1

8930069500 2927 MAIN SEAL (TOP) [#43] 1

8930069500 2927 MAIN SEAL (TOP) [#44] 1

8930069500 2927 MAIN SEAL (TOP) [#45] 1

8930069500 2927 MAIN SEAL (TOP) [#46] 1

8930069500 2927 MAIN SEAL (TOP) [#47] 1

8930069500 2927 MAIN SEAL (TOP) [#48] 1

8930069500 2927 MAIN SEAL (TOP) [#49] 1

8930069500 2927 MAIN SEAL (TOP) [#50] 1

8930069500 2927 MAIN SEAL (TOP) [#53] 1

8930069500 2927 MAIN SEAL (TOP) [#61] 1

8930069500 2927 MAIN SEAL (TOP) [#62] 1

8930069500 2927 MAIN SEAL (TOP) [#63] 1

8930084060 2926 MAIN SEAL TOP [#81] 1

8930084060 2926 MAIN SEAL TOP [#82] 1

8930084060 2926 MAIN SEAL TOP [#83] 1

8930084060 2926 MAIN SEAL TOP [#85] 1

8930084060 2926 MAIN SEAL TOP [#86] 1

8930084060 2926 MAIN SEAL TOP [#88] 1

8930084060 2926 MAIN SEAL TOP [#89] 1

8930084060 2926 MAIN SEAL TOP [#90] 1

8930084060 2926 MAIN SEAL TOP [#93] 1

8930084060 2926 MAIN SEAL TOP [#95] 1

8930084060 2926 MAIN SEAL TOP [#96] 1

8930084060 2926 MAIN SEAL TOP [#99] 1

MP14 8930063061 2721 T-RUBBER-1 (TOT) 1

MP16 8930069460 2927 SIDE PLATE Y852 [#01] 1

8930069460 2927 SIDE PLATE Y852 [#02] 1

8930069460 2927 SIDE PLATE Y852 [#03] 1

8930069460 2927 SIDE PLATE Y852 [#04] 1

8930069460 2927 SIDE PLATE Y852 [#05] 1

8930069460 2927 SIDE PLATE Y852 [#07] 1

8930069460 2927 SIDE PLATE Y852 [#09] 1

8930069460 2927 SIDE PLATE Y852 [#21] 1

8930069460 2927 SIDE PLATE Y852 [#22] 1

8930069460 2927 SIDE PLATE Y852 [#23] 1

8930069460 2927 SIDE PLATE Y852 [#41] 1

8930069460 2927 SIDE PLATE Y852 [#42] 1

8930069460 2927 SIDE PLATE Y852 [#43] 1

8930069460 2927 SIDE PLATE Y852 [#44] 1

8930069460 2927 SIDE PLATE Y852 [#45] 1

8930069460 2927 SIDE PLATE Y852 [#46] 1

8930069460 2927 SIDE PLATE Y852 [#47] 1

8930069460 2927 SIDE PLATE Y852 [#48] 1

8930069460 2927 SIDE PLATE Y852 [#49] 1

8930069460 2927 SIDE PLATE Y852 [#50] 1

8930069460 2927 SIDE PLATE Y852 [#53] 1

8930069460 2927 SIDE PLATE Y852 [#61] 1

8930069460 2927 SIDE PLATE Y852 [#62] 1

8930069460 2927 SIDE PLATE Y852 [#63] 1

8930084090 2926 SIDE PLATE Y1253 [#81] 1

8930084090 2926 SIDE PLATE Y1253 [#82] 1

8930084090 2926 SIDE PLATE Y1253 [#83] 1

8930084090 2926 SIDE PLATE Y1253 [#85] 1

8930084090 2926 SIDE PLATE Y1253 [#86] 1

8930084090 2926 SIDE PLATE Y1253 [#88] 1

8930084090 2926 SIDE PLATE Y1253 [#89] 1

8930084090 2926 SIDE PLATE Y1253 [#90] 1

8930084090 2926 SIDE PLATE Y1253 [#93] 1

8930084090 2926 SIDE PLATE Y1253 [#95] 1

8930084090 2926 SIDE PLATE Y1253 [#96] 1

8930084090 2926 SIDE PLATE Y1253 [#99] 1

[CHASSIS PARTS]

REF ORDER DESCRIPTION QTY.

NO. NO.

MP17 8930069470 2927 TOP PLATE Y853 [#01] 1

8930069470 2927 TOP PLATE Y853 [#02] 1

8930069470 2927 TOP PLATE Y853 [#03] 1

8930069470 2927 TOP PLATE Y853 [#04] 1

8930069470 2927 TOP PLATE Y853 [#05] 1

8930069470 2927 TOP PLATE Y853 [#07] 1

8930069470 2927 TOP PLATE Y853 [#09] 1

8930069470 2927 TOP PLATE Y853 [#21] 1

8930069470 2927 TOP PLATE Y853 [#22] 1

8930069470 2927 TOP PLATE Y853 [#23] 1

8930069470 2927 TOP PLATE Y853 [#41] 1

8930069470 2927 TOP PLATE Y853 [#42] 1

8930069470 2927 TOP PLATE Y853 [#43] 1

8930069470 2927 TOP PLATE Y853 [#44] 1

8930069470 2927 TOP PLATE Y853 [#45] 1

8930069470 2927 TOP PLATE Y853 [#46] 1

8930069470 2927 TOP PLATE Y853 [#47] 1

8930069470 2927 TOP PLATE Y853 [#48] 1

8930069470 2927 TOP PLATE Y853 [#49] 1

8930069470 2927 TOP PLATE Y853 [#50] 1

8930069470 2927 TOP PLATE Y853 [#53] 1

8930069470 2927 TOP PLATE Y853 [#61] 1

8930069470 2927 TOP PLATE Y853 [#62] 1

8930069470 2927 TOP PLATE Y853 [#63] 1

8930084100 2926 TOP PLATE Y1254 [#81] 1

8930084100 2926 TOP PLATE Y1254 [#82] 1

8930084100 2926 TOP PLATE Y1254 [#83] 1

8930084100 2926 TOP PLATE Y1254 [#85] 1

8930084100 2926 TOP PLATE Y1254 [#86] 1

8930084100 2926 TOP PLATE Y1254 [#88] 1

8930084100 2926 TOP PLATE Y1254 [#89] 1

8930084100 2926 TOP PLATE Y1254 [#90] 1

8930084100 2926 TOP PLATE Y1254 [#93] 1

8930084100 2926 TOP PLATE Y1254 [#95] 1

8930084100 2926 TOP PLATE Y1254 [#96] 1

8930084100 2926 TOP PLATE Y1254 [#99] 1

MP20 8930061880 2721 MIC SPONGE [#01] 1

8930061880 2721 MIC SPONGE [#02] 1

8930061880 2721 MIC SPONGE [#03] 1

8930061880 2721 MIC SPONGE [#04] 1

8930061880 2721 MIC SPONGE [#05] 1

8930061880 2721 MIC SPONGE [#07] 1

8930061880 2721 MIC SPONGE [#09] 1

8930061880 2721 MIC SPONGE [#21] 1

8930061880 2721 MIC SPONGE [#22] 1

8930061880 2721 MIC SPONGE [#23] 1

8930061880 2721 MIC SPONGE [#41] 1

8930061880 2721 MIC SPONGE [#42] 1

8930061880 2721 MIC SPONGE [#43] 1

8930061880 2721 MIC SPONGE [#44] 1

8930061880 2721 MIC SPONGE [#45] 1

8930061880 2721 MIC SPONGE [#46] 1

8930061880 2721 MIC SPONGE [#47] 1

8930061880 2721 MIC SPONGE [#48] 1

8930061880 2721 MIC SPONGE [#49] 1

8930061880 2721 MIC SPONGE [#50] 1

8930061880 2721 MIC SPONGE [#53] 1

8930061880 2721 MIC SPONGE [#61] 1

8930061880 2721 MIC SPONGE [#62] 1

8930061880 2721 MIC SPONGE [#63] 1

8930084260 2926 MIC SEAL TOP [#81] 1

8930084260 2926 MIC SEAL TOP [#82] 1

8930084260 2926 MIC SEAL TOP [#83] 1

8930084260 2926 MIC SEAL TOP [#85] 1

8930084260 2926 MIC SEAL TOP [#86] 1

8930084260 2926 MIC SEAL TOP [#88] 1

8930084260 2926 MIC SEAL TOP [#89] 1

8930084260 2926 MIC SEAL TOP [#90] 1

8930084260 2926 MIC SEAL TOP [#93] 1

8930084260 2926 MIC SEAL TOP [#95] 1

8930084260 2926 MIC SEAL TOP [#96] 1

8930084260 2926 MIC SEAL TOP [#99] 1

*: Refer to “BOARD LAYOUTS” for the location.

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

(Replacement page)

April 2013

7 - 4

[CHASSIS PARTS]

REF ORDER DESCRIPTION QTY.

NO. NO.

MP24 8610012970 KNOB N350 [#01] 1

8610012970 KNOB N350 [#02] 1

8610012970 KNOB N350 [#03] 1

8610012970 KNOB N350 [#04] 1

8610012970 KNOB N350 [#05] 1

8610012970 KNOB N350 [#07] 1

8610012970 KNOB N350 [#09] 1

8610012970 KNOB N350 [#21] 1

8610012970 KNOB N350 [#22] 1

8610012970 KNOB N350 [#23] 1

8610012970 KNOB N350 [#41] 1

8610012970 KNOB N350 [#42] 1

8610012970 KNOB N350 [#43] 1

8610012970 KNOB N350 [#44] 1

8610012970 KNOB N350 [#45] 1

8610012970 KNOB N350 [#46] 1

8610012970 KNOB N350 [#47] 1

8610012970 KNOB N350 [#48] 1

8610012970 KNOB N350 [#49] 1

8610012970 KNOB N350 [#50] 1

8610012970 KNOB N350 [#53] 1

8610012970 KNOB N350 [#61] 1

8610012970 KNOB N350 [#62] 1

8610012970 KNOB N350 [#63] 1

8610014460 KNOB N-350 (A) [#81] 1

8610014460 KNOB N-350 (A) [#82] 1

8610014460 KNOB N-350 (A) [#83] 1

8610014460 KNOB N-350 (A) [#85] 1

8610014460 KNOB N-350 (A) [#86] 1

8610014460 KNOB N-350 (A) [#88] 1

8610014460 KNOB N-350 (A) [#89] 1

8610014460 KNOB N-350 (A) [#90] 1

8610014460 KNOB N-350 (A) [#93] 1

8610014460 KNOB N-350 (A) [#95] 1

8610014460 KNOB N-350 (A) [#96] 1

8610014460 KNOB N-350 (A) [#99] 1

MP25 8830002901 2927 ANT NUT-1 <GA> [#01] 1

8830002901 2927 ANT NUT-1 <GA> [#02] 1

8830002901 2927 ANT NUT-1 <GA> [#03] 1

8830002901 2927 ANT NUT-1 <GA> [#04] 1

8830002901 2927 ANT NUT-1 <GA> [#05] 1

8830002901 2927 ANT NUT-1 <GA> [#07] 1

8830002901 2927 ANT NUT-1 <GA> [#09] 1

8830002901 2927 ANT NUT-1 <GA> [#21] 1

8830002901 2927 ANT NUT-1 <GA> [#22] 1

8830002901 2927 ANT NUT-1 <GA> [#23] 1

8830002901 2927 ANT NUT-1 <GA> [#41] 1

8830002901 2927 ANT NUT-1 <GA> [#42] 1

8830002901 2927 ANT NUT-1 <GA> [#43] 1

8830002901 2927 ANT NUT-1 <GA> [#44] 1

8830002901 2927 ANT NUT-1 <GA> [#45] 1

8830002901 2927 ANT NUT-1 <GA> [#46] 1

8830002901 2927 ANT NUT-1 <GA> [#47] 1

8830002901 2927 ANT NUT-1 <GA> [#48] 1

8830002901 2927 ANT NUT-1 <GA> [#49] 1

8830002901 2927 ANT NUT-1 <GA> [#50] 1

8830002901 2927 ANT NUT-1 <GA> [#53] 1

8830002901 2927 ANT NUT-1 <GA> [#61] 1

8830002901 2927 ANT NUT-1 <GA> [#62] 1

8830002901 2927 ANT NUT-1 <GA> [#63] 1

8830003440 3285 ANT NUT [#81] 1

8830003440 3285 ANT NUT [#82] 1

8830003440 3285 ANT NUT [#83] 1

8830003440 3285 ANT NUT [#85] 1

8830003440 3285 ANT NUT [#86] 1

8830003440 3285 ANT NUT [#88] 1

8830003440 3285 ANT NUT [#89] 1

8830003440 3285 ANT NUT [#90] 1

8830003440 3285 ANT NUT [#93] 1

8830003440 3285 ANT NUT [#95] 1

8830003440 3285 ANT NUT [#96] 1

8830003440 3285 ANT NUT [#99] 1

[CHASSIS PARTS]

REF ORDER DESCRIPTION QTY.

NO. NO.

MP21 8930059362 2600 RELEASE BUTTON-2 (PC) [#01] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#02] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#03] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#04] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#05] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#07] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#09] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#21] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#22] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#23] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#41] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#42] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#43] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#44] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#45] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#46] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#47] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#48] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#49] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#50] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#53] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#61] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#62] 1

8930059362 2600 RELEASE BUTTON-2 (PC) [#63] 1

8930084230 2926 RELEASE BUTTON [#81] 1

8930084230 2926 RELEASE BUTTON [#82] 1

8930084230 2926 RELEASE BUTTON [#83] 1

8930084230 2926 RELEASE BUTTON [#85] 1

8930084230 2926 RELEASE BUTTON [#86] 1

8930084230 2926 RELEASE BUTTON [#88] 1

8930084230 2926 RELEASE BUTTON [#89] 1

8930084230 2926 RELEASE BUTTON [#90] 1

8930084230 2926 RELEASE BUTTON [#93] 1

8930084230 2926 RELEASE BUTTON [#95] 1

8930084230 2926 RELEASE BUTTON [#96] 1

8930084230 2926 RELEASE BUTTON [#99] 1

MP22 8930070363 2775 RELEASE PLATE (A)-3 [#01] 1

8930070363 2775 RELEASE PLATE (A)-3 [#02] 1

8930070363 2775 RELEASE PLATE (A)-3 [#03] 1

8930070363 2775 RELEASE PLATE (A)-3 [#04] 1

8930070363 2775 RELEASE PLATE (A)-3 [#05] 1

8930070363 2775 RELEASE PLATE (A)-3 [#07] 1

8930070363 2775 RELEASE PLATE (A)-3 [#09] 1

8930070363 2775 RELEASE PLATE (A)-3 [#21] 1

8930070363 2775 RELEASE PLATE (A)-3 [#22] 1

8930070363 2775 RELEASE PLATE (A)-3 [#23] 1

8930070363 2775 RELEASE PLATE (A)-3 [#41] 1

8930070363 2775 RELEASE PLATE (A)-3 [#42] 1

8930070363 2775 RELEASE PLATE (A)-3 [#43] 1

8930070363 2775 RELEASE PLATE (A)-3 [#44] 1

8930070363 2775 RELEASE PLATE (A)-3 [#45] 1

8930070363 2775 RELEASE PLATE (A)-3 [#46] 1

8930070363 2775 RELEASE PLATE (A)-3 [#47] 1

8930070363 2775 RELEASE PLATE (A)-3 [#48] 1

8930070363 2775 RELEASE PLATE (A)-3 [#49] 1

8930070363 2775 RELEASE PLATE (A)-3 [#50] 1

8930070363 2775 RELEASE PLATE (A)-3 [#53] 1

8930070363 2775 RELEASE PLATE (A)-3 [#61] 1

8930070363 2775 RELEASE PLATE (A)-3 [#62] 1

8930070363 2775 RELEASE PLATE (A)-3 [#63] 1

8930084250 2926 RELEASE PLATE Y1255 [#81] 1

8930084250 2926 RELEASE PLATE Y1255 [#82] 1

8930084250 2926 RELEASE PLATE Y1255 [#83] 1

8930084250 2926 RELEASE PLATE Y1255 [#85] 1

8930084250 2926 RELEASE PLATE Y1255 [#86] 1

8930084250 2926 RELEASE PLATE Y1255 [#88] 1

8930084250 2926 RELEASE PLATE Y1255 [#89] 1

8930084250 2926 RELEASE PLATE Y1255 [#90] 1

8930084250 2926 RELEASE PLATE Y1255 [#93] 1

8930084250 2926 RELEASE PLATE Y1255 [#95] 1

8930084250 2926 RELEASE PLATE Y1255 [#96] 1

8930084250 2926 RELEASE PLATE Y1255 [#99] 1

*: Refer to “BOARD LAYOUTS” for the location.

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

(Replacement page)

April 2013

7 - 5

[CHASSIS PARTS] [CHASSIS PARTS]

REF ORDER DESCRIPTION QTY.

NO. NO.

REF ORDER DESCRIPTION QTY.

NO. NO.

MP26 8810009561 PHBT M2 X 6 NI-ZK3 [#01] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#02] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#03] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#04] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#05] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#07] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#09] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#21] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#22] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#23] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#41] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#42] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#43] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#44] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#45] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#46] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#47] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#48] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#49] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#50] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#53] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#61] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#62] 2

8810009561 PHBT M2 X 6 NI-ZK3 [#63] 2

8810010750 PHBT M2 X 6 SUS SSBC [#81] 2

8810010750 PHBT M2 X 6 SUS SSBC [#82] 2

8810010750 PHBT M2 X 6 SUS SSBC [#83] 2

8810010750 PHBT M2 X 6 SUS SSBC [#85] 2

8810010750 PHBT M2 X 6 SUS SSBC [#86] 2

8810010750 PHBT M2 X 6 SUS SSBC [#88] 2

8810010750 PHBT M2 X 6 SUS SSBC [#89] 2

8810010750 PHBT M2 X 6 SUS SSBC [#90] 2

8810010750 PHBT M2 X 6 SUS SSBC [#93] 2

8810010750 PHBT M2 X 6 SUS SSBC [#95] 2

8810010750 PHBT M2 X 6 SUS SSBC [#96] 2

8810010750 PHBT M2 X 6 SUS SSBC [#99] 2

MP27 8810009221 PHB0 M2 X 8 NI-ZK3 BT [#01] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#02] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#03] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#04] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#05] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#07] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#09] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#21] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#22] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#23] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#41] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#42] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#43] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#44] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#45] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#46] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#47] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#48] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#49] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#50] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#53] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#61] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#62] 2

8810009221 PHB0 M2 X 8 NI-ZK3 BT [#63] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#81] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#82] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#83] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#85] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#86] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#88] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#89] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#90] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#93] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#95] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#96] 2

8810010850 PHBT B0 M2X8 SUS SSBC [#99] 2

MP28 8810008641 BT M2 X 4 NI-ZC3 11

MP29 8810008971 BT M2 X3.5 NI-ZC3 [#81] 1

8810008971 BT M2 X3.5 NI-ZC3 [#82] 1

8810008971 BT M2 X3.5 NI-ZC3 [#83] 1

8810008971 BT M2 X3.5 NI-ZC3 [#85] 1

8810008971 BT M2 X3.5 NI-ZC3 [#86] 1

8810008971 BT M2 X3.5 NI-ZC3 [#88] 1

8810008971 BT M2 X3.5 NI-ZC3 [#89] 1

8810008971 BT M2 X3.5 NI-ZC3 [#90] 1

8810008971 BT M2 X3.5 NI-ZC3 [#93] 1

8810008971 BT M2 X3.5 NI-ZC3 [#95] 1

8810008971 BT M2 X3.5 NI-ZC3 [#96] 1

8810008971 BT M2 X3.5 NI-ZC3 [#99] 1

MP30 8810010450 PH M2 X3 SUS SSBC [#81] 4

8810010450 PH M2 X3 SUS SSBC [#82] 4

8810010450 PH M2 X3 SUS SSBC [#83] 4

8810010450 PH M2 X3 SUS SSBC [#85] 4

8810010450 PH M2 X3 SUS SSBC [#86] 4

8810010450 PH M2 X3 SUS SSBC [#88] 4

8810010450 PH M2 X3 SUS SSBC [#89] 4

8810010450 PH M2 X3 SUS SSBC [#90] 4

8810010450 PH M2 X3 SUS SSBC [#93] 4

8810010450 PH M2 X3 SUS SSBC [#95] 4

8810010450 PH M2 X3 SUS SSBC [#96] 4

8810010450 PH M2 X3 SUS SSBC [#99] 4

MP31 8810010430 TRUSS M3 X 5 SUS SSBC 1

MP32 8310066810 2927 OPT PLATE [#01] 1

8310066810 2927 OPT PLATE [#02] 1

8310066810 2927 OPT PLATE [#03] 1

8310066810 2927 OPT PLATE [#04] 1

8310066810 2927 OPT PLATE [#05] 1

8310066810 2927 OPT PLATE [#07] 1

8310066810 2927 OPT PLATE [#09] 1

8310066810 2927 OPT PLATE [#21] 1

8310066810 2927 OPT PLATE [#22] 1

8310066810 2927 OPT PLATE [#23] 1

8310066810 2927 OPT PLATE [#41] 1

8310066810 2927 OPT PLATE [#42] 1

8310066810 2927 OPT PLATE [#43] 1

8310066810 2927 OPT PLATE [#44] 1

8310066810 2927 OPT PLATE [#45] 1

8310066810 2927 OPT PLATE [#46] 1

8310066810 2927 OPT PLATE [#47] 1

8310066810 2927 OPT PLATE [#48] 1

8310066810 2927 OPT PLATE [#49] 1

8310066810 2927 OPT PLATE [#50] 1

8310066810 2927 OPT PLATE [#53] 1

8310066810 2927 OPT PLATE [#61] 1

8310066810 2927 OPT PLATE [#62] 1

8310066810 2927 OPT PLATE [#63] 1

MP33 8930046020 1123 SHEET (A)-1 [#01] 1

8930046020 1123 SHEET (A)-1 [#02] 1

8930046020 1123 SHEET (A)-1 [#03] 1

8930046020 1123 SHEET (A)-1 [#04] 1

8930046020 1123 SHEET (A)-1 [#05] 1

8930046020 1123 SHEET (A)-1 [#07] 1

8930046020 1123 SHEET (A)-1 [#09] 1

8930046020 1123 SHEET (A)-1 [#21] 1

8930046020 1123 SHEET (A)-1 [#22] 1

8930046020 1123 SHEET (A)-1 [#23] 1

8930046020 1123 SHEET (A)-1 [#41] 1

8930046020 1123 SHEET (A)-1 [#42] 1

8930046020 1123 SHEET (A)-1 [#43] 1

8930046020 1123 SHEET (A)-1 [#44] 1

8930046020 1123 SHEET (A)-1 [#45] 1

8930046020 1123 SHEET (A)-1 [#46] 1

8930046020 1123 SHEET (A)-1 [#47] 1

8930046020 1123 SHEET (A)-1 [#48] 1

8930046020 1123 SHEET (A)-1 [#49] 1

8930046020 1123 SHEET (A)-1 [#50] 1

8930046020 1123 SHEET (A)-1 [#53] 1

8930046020 1123 SHEET (A)-1 [#61] 1

8930046020 1123 SHEET (A)-1 [#62] 1

8930046020 1123 SHEET (A)-1 [#63] 1

8930085000 2926 VENT SHEET [#81] 1

8930085000 2926 VENT SHEET [#82] 1

8930085000 2926 VENT SHEET [#83] 1

8930085000 2926 VENT SHEET [#85] 1

8930085000 2926 VENT SHEET [#86] 1

8930085000 2926 VENT SHEET [#88] 1

8930085000 2926 VENT SHEET [#89] 1

8930085000 2926 VENT SHEET [#90] 1

8930085000 2926 VENT SHEET [#93] 1

8930085000 2926 VENT SHEET [#95] 1

8930085000 2926 VENT SHEET [#96] 1

8930085000 2926 VENT SHEET [#99] 1

MP34 8930056540 PUSH SPRING (AH) 2

MP35 8830001701 VR NUT (Q)-1 1

MP36 8930048871 2056 A-SPONGE-1 1

MP37 8930070010 2893 VOL RUBBER (TOT) 1

MP38 8930085000 2926 VENT SHEET [#81] 1

8930085000 2926 VENT SHEET [#82] 1

8930085000 2926 VENT SHEET [#83] 1

8930085000 2926 VENT SHEET [#85] 1

8930085000 2926 VENT SHEET [#86] 1

8930085000 2926 VENT SHEET [#88] 1

8930085000 2926 VENT SHEET [#89] 1

8930085000 2926 VENT SHEET [#90] 1

8930085000 2926 VENT SHEET [#93] 1

8930085000 2926 VENT SHEET [#95] 1

8930085000 2926 VENT SHEET [#96] 1

8930085000 2926 VENT SHEET [#99] 1

MP39 8930055920 INSULATION SHEETGQ [#81] 1

8930055920 INSULATION SHEETGQ [#82] 1

8930055920 INSULATION SHEETGQ [#83] 1

8930055920 INSULATION SHEETGQ [#85] 1

8930055920 INSULATION SHEETGQ [#86] 1

8930055920 INSULATION SHEETGQ [#88] 1

8930055920 INSULATION SHEETGQ [#89] 1

8930055920 INSULATION SHEETGQ [#90] 1

8930055920 INSULATION SHEETGQ [#93] 1

8930055920 INSULATION SHEETGQ [#95] 1

8930055920 INSULATION SHEETGQ [#96] 1

8930055920 INSULATION SHEETGQ [#99] 1

*: Refer to “BOARD LAYOUTS” for the location.

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

(Replacement page)

April 2013

7 - 6

[CHASSIS PARTS] [MAIN UNIT]

REF ORDER DESCRIPTION QTY.

NO. NO.

REF ORDER DESCRIPTION QTY.

NO. NO.

MP42 8930084040 2926 SIDE SEAL TOP [#81] 1

8930084040 2926 SIDE SEAL TOP [#82] 1

8930084040 2926 SIDE SEAL TOP [#83] 1

8930084040 2926 SIDE SEAL TOP [#85] 1

8930084040 2926 SIDE SEAL TOP [#86] 1

8930084040 2926 SIDE SEAL TOP [#88] 1

8930084040 2926 SIDE SEAL TOP [#89] 1

8930084040 2926 SIDE SEAL TOP [#90] 1

8930084040 2926 SIDE SEAL TOP [#93] 1

8930084040 2926 SIDE SEAL TOP [#95] 1

8930084040 2926 SIDE SEAL TOP [#96] 1

8930084040 2926 SIDE SEAL TOP [#99] 1

MP43 8930084240 2926 TOP KEY TOP [#81] 1

8930084240 2926 TOP KEY TOP [#82] 1

8930084240 2926 TOP KEY TOP [#83] 1

8930084240 2926 TOP KEY TOP [#85] 1

8930084240 2926 TOP KEY TOP [#86] 1

8930084240 2926 TOP KEY TOP [#88] 1

8930084240 2926 TOP KEY TOP [#89] 1

8930084240 2926 TOP KEY TOP [#90] 1

8930084240 2926 TOP KEY TOP [#93] 1

8930084240 2926 TOP KEY TOP [#95] 1

8930084240 2926 TOP KEY TOP [#96] 1

8930084240 2926 TOP KEY TOP [#99] 1

MP44 8930085330 O-RING (CQ) (TOP) [#81] 1

8930085330 O-RING (CQ) (TOP) [#82] 1

8930085330 O-RING (CQ) (TOP) [#83] 1

8930085330 O-RING (CQ) (TOP) [#85] 1

8930085330 O-RING (CQ) (TOP) [#86] 1

8930085330 O-RING (CQ) (TOP) [#88] 1

8930085330 O-RING (CQ) (TOP) [#89] 1

8930085330 O-RING (CQ) (TOP) [#90] 1

8930085330 O-RING (CQ) (TOP) [#93] 1

8930085330 O-RING (CQ) (TOP) [#95] 1

8930085330 O-RING (CQ) (TOP) [#96] 1

8930085330 O-RING (CQ) (TOP) [#99] 1

MP45 8930084070 2926 OPT RUBBER [#81] 1

8930084070 2926 OPT RUBBER [#82] 1

8930084070 2926 OPT RUBBER [#83] 1

8930084070 2926 OPT RUBBER [#85] 1

8930084070 2926 OPT RUBBER [#86] 1

8930084070 2926 OPT RUBBER [#88] 1

8930084070 2926 OPT RUBBER [#89] 1

8930084070 2926 OPT RUBBER [#90] 1

8930084070 2926 OPT RUBBER [#93] 1

8930084070 2926 OPT RUBBER [#95] 1

8930084070 2926 OPT RUBBER [#96] 1

8930084070 2926 OPT RUBBER [#99] 1

MP46 8810007391 PH M2 X 6 SUS SSBC [#81] 2

8810007391 PH M2 X 6 SUS SSBC [#82] 2

8810007391 PH M2 X 6 SUS SSBC [#83] 2

8810007391 PH M2 X 6 SUS SSBC [#85] 2

8810007391 PH M2 X 6 SUS SSBC [#86] 2

8810007391 PH M2 X 6 SUS SSBC [#88] 2

8810007391 PH M2 X 6 SUS SSBC [#89] 2

8810007391 PH M2 X 6 SUS SSBC [#90] 2

8810007391 PH M2 X 6 SUS SSBC [#93] 2

8810007391 PH M2 X 6 SUS SSBC [#95] 2

8810007391 PH M2 X 6 SUS SSBC [#96] 2

8810007391 PH M2 X 6 SUS SSBC [#99] 2

MP47 8210027310 2926 JACK PANEL [#81] 1

8210027310 2926 JACK PANEL [#82] 1

8210027310 2926 JACK PANEL [#83] 1

8210027720 2926 JACK PANEL [#85] 1

8210027710 2926 JACK PANEL (A) [#86] 1

8210027710 2926 JACK PANEL (A) [#88] 1

8210027310 2926 JACK PANEL [#89] 1

8210027310 2926 JACK PANEL [#93] 1

8210027310 2926 JACK PANEL [#95] 1

8210027310 2926 JACK PANEL [#96] 1

8210027310 2926 JACK PANEL [#99] 1

J2 6450002250 HSJ1456-010320 1

J3 6450000131 HSJ1102-018540 1

J4* 6510021901 BM02B-ASRS-TF (LF) (SN) 1

J5* 6510026770 AXK540147YG 1

DS3 5030003050 S11188 <SUC> 1

MC1 7700002760 EM6027P-46C33-G-01 <HOR> [#01] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#02] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#03] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#04] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#05] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#07] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#09] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#21] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#22] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#23] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#41] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#42] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#43] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#44] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#45] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#46] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#47] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#48] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#49] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#50] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#53] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#61] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#62] 1

7700002760 EM6027P-46C33-G-01 <HOR> [#63] 1

7700002970 EM6027P-30BC33-G <HOR> [#81] 1

7700002970 EM6027P-30BC33-G <HOR> [#82] 1

7700002970 EM6027P-30BC33-G <HOR> [#83] 1

7700002970 EM6027P-30BC33-G <HOR> [#85] 1

7700002970 EM6027P-30BC33-G <HOR> [#86] 1

7700002970 EM6027P-30BC33-G <HOR> [#88] 1

7700002970 EM6027P-30BC33-G <HOR> [#89] 1

7700002970 EM6027P-30BC33-G <HOR> [#90] 1

7700002970 EM6027P-30BC33-G <HOR> [#93] 1

7700002970 EM6027P-30BC33-G <HOR> [#95] 1

7700002970 EM6027P-30BC33-G <HOR> [#96] 1

7700002970 EM6027P-30BC33-G <HOR> [#99] 1

S1* 2230001060 EVQ-PUL 02K 1

S2 2260001900 SW-149 (SKHLLD) 1

S3* 2260002800 SW-167 (SKQTLAE010) 1

S4* 2260002800 SW-167 (SKQTLAE010) 1

S5* 2260002800 SW-167 (SKQTLAE010) 1

EP7 8930063020 SRCN-2721-SP-N-W (SHJ) 2

MP1* 8510016130 2721 VCO CASE Y709 1

MP2 8510016120 2721 VCO COVER Y710 1

MP3 8930069481 2927 LCD HOLDER-1 Y854A 1

MP4 8210020571 2721 REFLECTOR-1 1

MP5 8930070080 WHITE SHEET (V) 1

MP6 8510017720 2927 MAIN SHIELD Y867 1

MP7 8930066240 SPONGE (IM) [#81] 1

8930066240 SPONGE (IM) [#82] 1

8930066240 SPONGE (IM) [#83] 1

8930066240 SPONGE (IM) [#85] 1

8930066240 SPONGE (IM) [#86] 1

8930066240 SPONGE (IM) [#88] 1

8930066240 SPONGE (IM) [#89] 1

8930066240 SPONGE (IM) [#90] 1

8930066240 SPONGE (IM) [#93] 1

8930066240 SPONGE (IM) [#95] 1

8930066240 SPONGE (IM) [#96] 1

8930066240 SPONGE (IM) [#99] 1

*: Refer to “BOARD LAYOUTS” for the location.

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

7 - 7

(Replacement page)

April 2013

[ACCESSORIES]

REF ORDER DESCRIPTION QTY.

NO. NO.

EP1 (Optional) FA-SC55V-2 [#01] 1

(Optional) FA-SC55V-2 [#02] 1

(Optional) FA-SC55V-2 [#03] 1

(Optional) FA-SC55V-2 [#04] 1

(Optional) FA-SC55V-2 [#05] 1

(Optional) FA-SC55V-2 [#07] 1

(Optional) FA-SC55V-2 [#09] 1

(Optional) FA-SC55V-2 [#21] 1

(Optional) FA-SC55V-2 [#22] 1

(Optional) FA-SC55V-2 [#23] 1

(Optional) FA-SC55V-2 [#41] 1

(Optional) FA-SC55V-2 [#42] 1

(Optional) FA-SC55V-2 [#43] 1

(Optional) FA-SC55V-2 [#44] 1

(Optional) FA-SC25V-2 [#45] 1

(Optional) FA-SC25V-2 [#46] 1

(Optional) FA-SC55V-2 [#47] 1

(Optional) FA-SC55V-2 [#48] 1

(Optional) FA-SC55V-2 [#49] 1

(Optional) FA-SC25V-2 [#50] 1

(Optional) FA-SC55V-2 [#53] 1

(Optional) FA-SC55V-2 [#61] 1

(Optional) FA-SC55V-2 [#62] 1

(Optional) FA-SC55V-2 [#63] 1

(Optional) FA-SC55V-2 [#81] 1

(Optional) FA-SC55V-2 [#82] 1

(Optional) FA-SC55V-2 [#83] 1

(Optional) FA-SC25V-2 [#85] 1

(Optional) FA-SC25V-2 [#86] 1

(Optional) FA-SC55V-2 [#88] 1

(Optional) FA-SC55V-2 [#89] 1

(Optional) FA-SC25V-2 [#90] 1

(Optional) FA-SC55V-2 [#93] 1

(Optional) FA-SC55V-2 [#95] 1

(Optional) FA-SC55V-2 [#96] 1

(Optional) FA-SC55V-2 [#99] 1

EP2 (Optional) BP-232H [#01] 1

(Optional) BP-232H [#02] 1

(Optional) BP-232H [#03] 1

(Optional) BP-232H [#04] 1

(Optional) BP-232H [#05] 1

(Optional) BP-232H [#07] 1

(Optional) BP-232H [#09] 1

(Optional) BP-232H [#21] 1

(Optional) BP-232H [#22] 1

(Optional) BP-232H [#23] 1

(Optional) BP-232H [#41] 1

(Optional) BP-232H [#42] 1

(Optional) BP-232H [#43] 1

(Optional) BP-232H [#44] 1

(Optional) BP-232H [#45] 1

(Optional) BP-232H [#46] 1

(Optional) BP-232H [#47] 1

(Optional) BP-232H [#48] 1

(Optional) BP-232H [#49] 1

(Optional) BP-232H [#50] 1

(Optional) BP-232H [#53] 1

(Optional) BP-232H [#61] 1

(Optional) BP-232H [#62] 1

(Optional) BP-232H [#63] 1

(Optional) BP-232WP [#81] 1

(Optional) BP-232WP [#82] 1

(Optional) BP-232WP [#83] 1

(Optional) BP-232WP [#85] 1

(Optional) BP-232WP [#86] 1

(Optional) BP-232WP [#88] 1

(Optional) BP-232WP [#89] 1

(Optional) BP-232WP [#90] 1

(Optional) BP-232WP [#93] 1

(Optional) BP-232WP [#95] 1

(Optional) BP-232WP [#96] 1

(Optional) BP-232WP [#99] 1

EP3 (Optional) BC-160 Only [#96] 1

EP4 (Optional) BC-145SE 1

MP1 (Optional) MB-94 1

[PA UNIT]

[ANT UNIT]

[CONNECT UNIT]

REF ORDER DESCRIPTION QTY.

NO. NO.

REF ORDER DESCRIPTION QTY.

NO. NO.

REF ORDER DESCRIPTION QTY.

NO. NO.

J701 6910017680 IMSA-9230B-1-04Z140-PT1 1

J702 6910017680 IMSA-9230B-1-04Z140-PT1 1

F701* 5210000901 0467003.NR (0434003) 1

MP701* 8410002531 2681 PA HEATSINK-1 1

MP801* 8510017640 2927 ANT PLATE Y851 1

J901* 6910015881 9230B-1-02Z141-PT1 1

*: Refer to “BOARD LAYOUTS” for the location.

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

7 - 8

(Replacement page)

April 2013

[ACCESSORIES]

REF ORDER DESCRIPTION QTY.

NO. NO.

MP2 8310066810 2927 OPT PLATE [#01] 1

8310066810 2927 OPT PLATE [#02] 1

8310066810 2927 OPT PLATE [#03] 1

8310066810 2927 OPT PLATE [#04] 1

8310066810 2927 OPT PLATE [#05] 1

8310066810 2927 OPT PLATE [#07] 1

8310066810 2927 OPT PLATE [#09] 1

8310066810 2927 OPT PLATE [#21] 1

8310066810 2927 OPT PLATE [#22] 1

8310066810 2927 OPT PLATE [#23] 1

8310066810 2927 OPT PLATE [#41] 1

8310066810 2927 OPT PLATE [#42] 1

8310066810 2927 OPT PLATE [#43] 1

8310066810 2927 OPT PLATE [#44] 1

8310066810 2927 OPT PLATE [#45] 1

8310066810 2927 OPT PLATE [#46] 1

8310066810 2927 OPT PLATE [#47] 1

8310066810 2927 OPT PLATE [#48] 1

8310066810 2927 OPT PLATE [#49] 1

8310066810 2927 OPT PLATE [#50] 1

8310066810 2927 OPT PLATE [#53] 1

8310066810 2927 OPT PLATE [#61] 1

8310066810 2927 OPT PLATE [#62] 1

8310066810 2927 OPT PLATE [#63] 1

MP3 8210022780 2927 JACK PANEL [#01] 1

8210022780 2927 JACK PANEL [#02] 1

8210022780 2927 JACK PANEL [#03] 1

8210022780 2927 JACK PANEL [#04] 1

8210022780 2927 JACK PANEL [#05] 1

8210022780 2927 JACK PANEL [#07] 1

8210022780 2927 JACK PANEL [#09] 1

8210022780 2927 JACK PANEL [#21] 1

8210022780 2927 JACK PANEL [#22] 1

8210022780 2927 JACK PANEL [#23] 1

8210022780 2927 JACK PANEL [#41] 1

8210022780 2927 JACK PANEL [#42] 1

8210022780 2927 JACK PANEL [#43] 1

8210022780 2927 JACK PANEL [#44] 1

8210026330 2927 JACK PANEL [#45] 1

8210024010 2927 JACK PANEL [#46] 1

8210022780 2927 JACK PANEL [#47] 1

8210024010 2927 JACK PANEL [#48] 1

8210022780 2927 JACK PANEL [#49] 1

8210022780 2927 JACK PANEL [#53] 1

8210022780 2927 JACK PANEL [#61] 1

8210022780 2927 JACK PANEL [#62] 1

8210022780 2927 JACK PANEL [#63] 1

MP4 8810004861 PH M2 X 6 ZK3 [#01] 2

8810004861 PH M2 X 6 ZK3 [#02] 2

8810004861 PH M2 X 6 ZK3 [#03] 2

8810004861 PH M2 X 6 ZK3 [#04] 2

8810004861 PH M2 X 6 ZK3 [#05] 2

8810004861 PH M2 X 6 ZK3 [#07] 2

8810004861 PH M2 X 6 ZK3 [#09] 2

8810004861 PH M2 X 6 ZK3 [#21] 2

8810004861 PH M2 X 6 ZK3 [#22] 2

8810004861 PH M2 X 6 ZK3 [#23] 2

8810004861 PH M2 X 6 ZK3 [#41] 2

8810004861 PH M2 X 6 ZK3 [#42] 2

8810004861 PH M2 X 6 ZK3 [#43] 2

8810004861 PH M2 X 6 ZK3 [#44] 2

8810004861 PH M2 X 6 ZK3 [#45] 2

8810004861 PH M2 X 6 ZK3 [#46] 2

8810004861 PH M2 X 6 ZK3 [#47] 2

8810004861 PH M2 X 6 ZK3 [#48] 2

8810004861 PH M2 X 6 ZK3 [#49] 2

8810004861 PH M2 X 6 ZK3 [#50] 2

8810004861 PH M2 X 6 ZK3 [#53] 2

8810004861 PH M2 X 6 ZK3 [#61] 2

8810004861 PH M2 X 6 ZK3 [#62] 2

8810004861 PH M2 X 6 ZK3 [#63] 2

EP1 EP2 MP1

MP2

MP3

MP4

*: Refer to “BOARD LAYOUTS” for the location.

Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless

April 2013

7 - 9

MP2* (C)

MP33 (C)

MP20 (C)

SP1 (C)

MP12* (C)

MAIN Unit

MP28 (C)

MP6 (M) MP1 (M)

MP5 (M)

MP4 (M)

EP7 (M)

DS3 (M)

MP3 (M)

MP28 (C)

R315 (M)

MP2 (M)

MP28 (C)

J701 (P)

J901 (CN)

PA Unit

CONNECT Unit

MP28 (C)

ANT Unit MP1 (C)

MP801 (A)

MP17 (C)

MP35 (C)

J1 (C)

MP8 (C)

MP31 (C)

MP13 (C)

MP14 (C)

MP26 (C)

MP27 (C)

MP9 (C)

MP10 (C)

J2 (C)

J2 (M)

J3 (M)

MC1 (M)

S2 (M)

W1 (C)

MP32 (C)

UNIT abbreviations (C): CHASSIS PARTS, (M): MAIN UNIT, (P): PA UNIT, (CN): CONNECT UNIT, (A): ANT UNIT

MP37 (C)

MP21 (C)

MP22 (C)

MP34 (C)

MP36 (C)

MP16 (C)

MP24 (C)

MP25 (C)

J702 (P)

MP9 (M)

120 (4 23/32)

3.7 (9/64)

15.4 (39/64)

53 (2 3/32)

17.8 (45/64)

32.5 (1 9/32)

38.9 (1 17/32)

1.7 (1/16)

5.2 (13/64)

1.7 (1/16)

2.4 (3/32)

167 (6 37/64)

Unit: mm (inch) * MP2 (C), MP12 (C): The shape is depending on the version.

April 2013

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on parts orders and repairs.

SECTION 6

PARTS LIST

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

IC2 1140005991 S.IC MB15A02PFV1-G-BND-ERE1 T 81.2/34.5

IC3 1130011770 S.IC CD4066BPWR B 40.4/22.0

IC5 1110005320 S.IC NJM13403V-TE1-#ZZZB B 40.4/12.8

IC6 1110005340 S.IC NJM12902V-TE1-#ZZZB B 55.4/28.7

IC7 1110005340 S.IC NJM12902V-TE1-#ZZZB B 40.4/40.8

IC8 1110006260 S.IC BD5242G-TR B 21.3/42.0

IC9 1110007720 S.IC AA32416A <SLVJ> T 81.6/17.0

IC10 1130015560 S.IC S-24C64CI-T8T1U3 B 4.4/37.1

IC12 1190001350 S.IC M62364FP 600D B 40.4/30.6

IC15 1110007850 S.IC TA7368PL-R10-R <SLVJ> T 98.9/18.3

IC17 1110005350 S.IC NJM2870F05-TE1-#FZZB B 95.2/17.0

IC20 1130016390 S.IC PT6586-LQ <PTC> T 57.3/20.3

IC22 1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#01] B 16.4/24.5

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#02]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#03]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#04]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#05]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#07]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#09]

1140011511 S.IC HD64F2238BTF13V(EMPTY)[#21]

1140011511 S.IC HD64F2238BTF13V(EMPTY)[#22]

1140011511 S.IC HD64F2238BTF13V(EMPTY)[#23]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#41]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#42]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#43]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#44]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#45]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#46]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#47]

1140011511 S.IC HD64F2238BTF13V(EMPTY)[#48]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#49]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#50]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#53]

1140011511 S.IC HD64F2238BTF13V(EMPTY)[#61]

1140011511 S.IC HD64F2238BTF13V(EMPTY)[#62]

1140011511 S.IC HD64F2238BTF13V(EMPTY)[#63]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#81]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#82]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#83]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#85]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#86]

1140011511 S.IC HD64F2238BTF13V(EMPTY)[#88]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#89]

1140011511 S.IC HD64F2238BTF13V(EMPTY)[#90]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#93]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#95]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#96]

1140016360 S.IC HD6432238BB54TFV

(FX-3334A-3) [#99]

IC23 1190001340 S.IC M62334FP 600C T 99.9/42.5

IC24 1110005310 S.IC AN6123MS [#21] B 30.0/12.4

1110005310 S.IC AN6123MS [#22]

1110005310 S.IC AN6123MS [#23]

1110005310 S.IC AN6123MS [#61]

1110005310 S.IC AN6123MS [#62]

1110005310 S.IC AN6123MS [#63]

IC25 1130009981 S.IC TC7W53FK(TE85LF) [#21] B 28.4/4.8

1130009981 S.IC TC7W53FK(TE85LF) [#22]

1130009981 S.IC TC7W53FK(TE85LF) [#23]

1130009981 S.IC TC7W53FK(TE85LF) [#61]

1130009981 S.IC TC7W53FK(TE85LF) [#62]

1130009981 S.IC TC7W53FK(TE85LF) [#63]

Q5 1580000731 S.FET 3SK293(TE85LF) B 92.4/38.2

Q6 1580000800 S.FET 3SK324UG-TL-E B 88.6/23.4

Q7 1530003311 S.TRA 2SC5107-O(TE85RF) T 88.2/12.5

Model Version Symbol

IC-F3021T

USA-02

[#01]

USA-03

[#21]

IC-F3022T

EUR-02

[#02]

CHN-01

[#07]

EUR-03

[#22]

IC-F3023T

GEN-02

[#03]

GEN-03

[#23]

IC-F3023T-T THA-01 [#05]

IC-F3026T

[#04]

IC-F3026T

RUS-01

[#09]

IC-F3033T

EXP-01

[#93]

EXP-02

[#96]

IC-F3033T-T

THA-01

[#95]

IC-F3036T

RUS-01

[#99]

IC-F3021S

USA-02

[#41]

USA-03

[#61]

IC-F3022S

NOR-02

[#45]

NOR-01

[#46]

CHN-01

[#47]

ESP-01

[#48]

EUR-02

[#42]

NOR-03

[#50]

EUR-03

[#62]

IC-F3023S

GEN-02

[#43]

AUS-01

[#53]

GEN-03

[#63]

KOR-01

[#73]

IC-F3026S

EXP-01

[#44]

RUS-01

[#49]

IC-F3031S

USA-02

[#81]

IC-F3032S

EUR-02

[#82]

NOR-02

[#85]

NOR-01

[#86]

ESP-01

[#88]

NOR-03

[#90]

IC-F3033S

EXP-01

[#83]

IC-F3036S

RUS-01

[#89]

[VERSION LIST]

April 2013

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on parts orders and repairs.

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

Q8 1530002601 S.TRA 2SC4215-O(TE85RF) [#21] T 76.0/11.5

1530002601 S.TRA 2SC4215-O(TE85RF) [#22]

1530002601 S.TRA 2SC4215-O(TE85RF) [#23]

1530002601 S.TRA 2SC4215-O(TE85RF) [#61]

1530002601 S.TRA 2SC4215-O(TE85RF) [#62]

1530002601 S.TRA 2SC4215-O(TE85RF) [#63]

Q9 1590001330 S.TRA DTA114EUA T106 [#21] B 60.2/20.4

Eqv. 1590004010 S.TRA KRA302-RTK/P [#21]

Eqv. 1590004740 S.TRA LMUN5111T1G <SLVJ> [#21]

Q9 1590001330 S.TRA DTA114EUA T106 [#22] B 60.2/20.4

Eqv. 1590004010 S.TRA KRA302-RTK/P [#22]

Eqv. 1590004740 S.TRA LMUN5111T1G <SLVJ> [#22]

Q9 1590001330 S.TRA DTA114EUA T106 [#23] B 60.2/20.4

Eqv. 1590004010 S.TRA KRA302-RTK/P [#23]

Eqv. 1590004740 S.TRA LMUN5111T1G <SLVJ> [#23]

Q9 1590001330 S.TRA DTA114EUA T106 [#61] B 60.2/20.4

Eqv. 1590004010 S.TRA KRA302-RTK/P [#61]

Eqv. 1590004740 S.TRA LMUN5111T1G <SLVJ> [#61]

Q9 1590001330 S.TRA DTA114EUA T106 [#62] B 60.2/20.4

Eqv. 1590004010 S.TRA KRA302-RTK/P [#62]

Eqv. 1590004740 S.TRA LMUN5111T1G <SLVJ> [#62]

Q9 1590001330 S.TRA DTA114EUA T106 [#63] B 60.2/20.4

Eqv. 1590004010 S.TRA KRA302-RTK/P [#63]

Eqv. 1590004740 S.TRA LMUN5111T1G <SLVJ> [#63]

Q14 1530004110 S.TRA MT3S37T(TE85LF) B 79.9/31.3

Q15 1530003260 S.TRA 2SC5006-T1 B 76.3/30.0

Q16 1530003260 S.TRA 2SC5006-T1 B 75.5/25.7

Q17 1530003260 S.TRA 2SC5006-T1 B 74.1/32.1

Q18 1590004500 S.TRA DMC561040R T 74.3/28.3

Q19 1590004350 S.TRA DRC9144E0L T 71.8/28.5

Q20 1530002851 S.TRA 2SC4116-BL(TE85RF) B 98.6/25.2

Q21 1560000541 S.FET 2SK880-Y(T5RICOMF) T 76.8/25.4

Q22 1530003260 S.TRA 2SC5006-T1 T 80.7/24.1

Q23 1510001110 S.TRA 2SA1577T106R B 51.0/6.3

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#01]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#02]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#03]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#04]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#05]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#07]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#09]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#21]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#22]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#23]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#41]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#42]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#43]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#44]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#45]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#46]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#47]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#48]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#49]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#50]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#61]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#62]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#63]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#81]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#82]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#83]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#85]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#86]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#88]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#89]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#90]

Q24 1510001110 S.TRA 2SA1577T106R B 50.4/19.3

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#01]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#02]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#03]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#04]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#05]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#07]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#09]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#21]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#22]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#23]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#41]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#42]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#43]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#44]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#45]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#46]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#47]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#48]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#49]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#50]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#61]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#62]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#63]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#81]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#82]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#83]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#85]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#86]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#88]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#89]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#90]

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

Q25 1510001110 S.TRA 2SA1577T106R B 85.7/12.3

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#01]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#02]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#03]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#04]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#05]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#07]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#09]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#21]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#22]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#23]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#41]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#42]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#43]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#44]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#45]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#46]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#47]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#48]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#49]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#50]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#61]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#62]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#63]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#81]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#82]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#83]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#85]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#86]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#88]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#89]

Eqv. 1510001190 S.TRA 2SA1608-T1-A Y14 [#90]

Q26 1520000460 S.TRA 2SB1132 T100 R B 101.6/17.9

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#01]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#02]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#03]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#04]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#05]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#07]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#09]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#21]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#22]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#23]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#41]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#42]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#43]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#44]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#45]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#46]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#47]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#48]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#49]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#50]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#61]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#62]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#63]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#81]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#82]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#83]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#85]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#86]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#88]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#89]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#90]

Q27 1590004590 S.TRA DMC506010R B 101.7/22.7

Q28 1590004350 S.TRA DRC9144E0L B 99.4/20.6

Q29 1530003260 S.TRA 2SC5006-T1 B 78.3/23.9

April 2013

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on parts orders and repairs.

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

Q31 1560001360 S.FET 2SK3019 TL B 41.9/6.8

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#01]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#01]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#02]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#02]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#03]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#03]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#04]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#04]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#05]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#05]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#07]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#07]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#09]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#09]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#21]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#21]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#22]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#22]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#23]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#23]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#41]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#41]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#42]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#42]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#43]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#43]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#44]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#44]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#45]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#45]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#46]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#46]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#47]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#47]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#48]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#48]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#49]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#49]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#50]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#50]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#61]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#61]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#62]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#62]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#63]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#63]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#81]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#81]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#82]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#82]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#83]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#83]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#85]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#85]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#86]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#86]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#88]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#88]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#89]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#89]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#90]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#90]

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

Q32 1560001360 S.FET 2SK3019 TL B 37.7/6.8

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#01]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#01]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#02]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#02]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#03]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#03]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#04]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#04]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#05]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#05]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#07]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#07]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#09]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#09]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#21]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#21]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#22]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#22]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#23]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#23]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#41]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#41]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#42]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#42]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#43]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#43]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#44]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#44]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#45]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#45]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#46]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#46]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#47]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#47]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#48]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#48]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#49]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#49]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#50]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#50]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#61]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#61]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#62]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#62]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#63]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#63]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#81]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#81]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#82]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#82]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#83]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#83]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#85]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#85]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#86]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#86]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#88]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#88]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#89]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#89]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#90]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#90]

Q33 1590004350 S.TRA DRC9144E0L [#21] B 35.1/6.8

1590004350 S.TRA DRC9144E0L [#22]

1590004350 S.TRA DRC9144E0L [#23]

1590004350 S.TRA DRC9144E0L [#61]

1590004350 S.TRA DRC9144E0L [#62]

1590004350 S.TRA DRC9144E0L [#63]

April 2013

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on parts orders and repairs.

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

Q34 1560001360 S.FET 2SK3019 TL B 46.6/12.8

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#01]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#01]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#02]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#02]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#03]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#03]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#04]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#04]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#05]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#05]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#07]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#07]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#09]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#09]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#21]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#21]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#22]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#22]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#23]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#23]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#41]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#41]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#42]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#42]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#43]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#43]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#44]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#44]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#45]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#45]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#46]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#46]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#47]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#47]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#48]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#48]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#49]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#49]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#50]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#50]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#61]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#61]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#62]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#62]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#63]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#63]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#81]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#81]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#82]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#82]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#83]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#83]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#85]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#85]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#86]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#86]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#88]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#88]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#89]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#89]

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#90]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#90]

Q35 1590004350 S.TRA DRC9144E0L [#21] B 46.6/15.2

1590004350 S.TRA DRC9144E0L [#22]

1590004350 S.TRA DRC9144E0L [#23]

1590004350 S.TRA DRC9144E0L [#61]

1590004350 S.TRA DRC9144E0L [#62]

1590004350 S.TRA DRC9144E0L [#63]

Q36 1560001360 S.FET 2SK3019 TL [#21] B 37.7/4.6

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#21]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#21]

Q36 1560001360 S.FET 2SK3019 TL [#22] B 37.7/4.6

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#22]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#22]

Q36 1560001360 S.FET 2SK3019 TL [#23] B 37.7/4.6

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#23]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#23]

Q36 1560001360 S.FET 2SK3019 TL [#61] B 37.7/4.6

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#61]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#61]

Q36 1560001360 S.FET 2SK3019 TL [#62] B 37.7/4.6

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#62]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#62]

Q36 1560001360 S.FET 2SK3019 TL [#63] B 37.7/4.6

Eqv. 1560001840 S.FET 2SK3107-T1-AT [#63]

Eqv. 1560001860 S.FET 2SK1824-T1-A [#63]

Q37 1590004350 S.TRA DRC9144E0L [#21] B 40.0/4.6

1590004350 S.TRA DRC9144E0L [#22]

1590004350 S.TRA DRC9144E0L [#23]

1590004350 S.TRA DRC9144E0L [#61]

1590004350 S.TRA DRC9144E0L [#62]

1590004350 S.TRA DRC9144E0L [#63]

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

Q38 1590004350 S.TRA DRC9144E0L [#01] B 25.1/35.1

1590004350 S.TRA DRC9144E0L [#02]

1590004350 S.TRA DRC9144E0L [#03]

1590004350 S.TRA DRC9144E0L [#04]

1590004350 S.TRA DRC9144E0L [#05]

1590004350 S.TRA DRC9144E0L [#07]

1590004350 S.TRA DRC9144E0L [#09]

1590004350 S.TRA DRC9144E0L [#21]

1590004350 S.TRA DRC9144E0L [#22]

1590004350 S.TRA DRC9144E0L [#23]

1590004350 S.TRA DRC9144E0L [#41]

1590004350 S.TRA DRC9144E0L [#42]

1590004350 S.TRA DRC9144E0L [#43]

1590004350 S.TRA DRC9144E0L [#44]

1590004350 S.TRA DRC9144E0L [#45]

1590004350 S.TRA DRC9144E0L [#46]

1590004350 S.TRA DRC9144E0L [#47]

1590004350 S.TRA DRC9144E0L [#49]

1590004350 S.TRA DRC9144E0L [#50]

1590004350 S.TRA DRC9144E0L [#53]

1590004350 S.TRA DRC9144E0L [#61]

1590004350 S.TRA DRC9144E0L [#62]

1590004350 S.TRA DRC9144E0L [#63]

1590004350 S.TRA DRC9144E0L [#81]

1590004350 S.TRA DRC9144E0L [#82]

1590004350 S.TRA DRC9144E0L [#83]

1590004350 S.TRA DRC9144E0L [#85]

1590004350 S.TRA DRC9144E0L [#86]

1590004350 S.TRA DRC9144E0L [#89]

1590004350 S.TRA DRC9144E0L [#90]

1590004350 S.TRA DRC9144E0L [#93]

1590004350 S.TRA DRC9144E0L [#95]

1590004350 S.TRA DRC9144E0L [#96]

1590004350 S.TRA DRC9144E0L [#99]

Q39 1590004390 S.TRA DMG504010R B 55.2/10.4

Q40 1590004350 S.TRA DRC9144E0L B 40.6/37.0

Q41 1590004590 S.TRA DMC506010R T 96.4/24.6

Q42 1520000460 S.TRA 2SB1132 T100 R T 100.4/24.4

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#01]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#02]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#03]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#04]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#05]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#07]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#09]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#21]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#22]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#23]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#41]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#42]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#43]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#44]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#45]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#46]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#47]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#48]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#49]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#50]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#61]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#62]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#63]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#81]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#82]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#83]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#85]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#86]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#88]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#89]

Eqv. 1520000910 S.TRA 2SB1132L-R-AB3-R <SLVJ> [#90]

Q43 1590004200 S.TRA DRA9114E0L T 78.4/7.2

Q44 1590004340 S.TRA DRC9144T0L B 28.3/20.0

Q45 1590004190 S.TRA DRA9144E0L T 53.8/4.8

Q46 1590004350 S.TRA DRC9144E0L T 98.8/32.9

Q47 1590004350 S.TRA DRC9144E0L B 86.4/14.6

Q49 1590004350 S.TRA DRC9144E0L B 52.8/19.1

D2 1750001070 S.DIO DAN235ETL [#21] T 69.3/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#21]

D2 1750001070 S.DIO DAN235ETL [#22] T 69.3/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#22]

D2 1750001070 S.DIO DAN235ETL [#23] T 69.3/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#23]

D2 1750001070 S.DIO DAN235ETL [#61] T 69.3/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#61]

D2 1750001070 S.DIO DAN235ETL [#62] T 69.3/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#62]

D2 1750001070 S.DIO DAN235ETL [#63] T 69.3/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#63]

D3 1750001070 S.DIO DAN235ETL [#21] T 71.9/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#21]

D3 1750001070 S.DIO DAN235ETL [#22] T 71.9/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#22]

D3 1750001070 S.DIO DAN235ETL [#23] T 71.9/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#23]

D3 1750001070 S.DIO DAN235ETL [#61] T 71.9/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#61]

D3 1750001070 S.DIO DAN235ETL [#62] T 71.9/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#62]

D3 1750001070 S.DIO DAN235ETL [#63] T 71.9/16.8

Eqv. 1750002470 S.DIO KDS112E-RTK/P [#63]

D4 1750002020 S.DIO DA2S10100L T 84.0/28.9

D6 1750002210 S.DIO DA2S00100L B 27.7/29.2

D8 1750002020 S.DIO DA2S10100L B 98.6/23.3

D9 1750000771 S.VAR HVC376BTRF-E B 69.6/30.9

April 2013

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on parts orders and repairs.

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

D10 1750000771 S.VAR HVC376BTRF-E B 69.6/26.2

D11 1750000721 S.VAR HVC375BTRF-E B 74.9/34.0

D12 1720000471 S.VAR 1SV239(TPH3F) B 76.2/22.8

D13 1750000721 S.VAR HVC375BTRF-E B 72.0/28.4

D16 1750000581 S.DIO 1SV307(TPH3F) B 88.6/14.3

D17 1750002210 S.DIO DA2S00100L B 87.8/17.5

D19 1750000721 S.VAR HVC375BTRF-E B 97.6/37.3

D20 1750002170 S.DIO DB2S31400L B 99.0/32.8

D21 1750000520 S.DIO DAN222TL [#01] B 31.9/21.3

1750000520 S.DIO DAN222TL [#02]

1750000520 S.DIO DAN222TL [#03]

1750000520 S.DIO DAN222TL [#04]

1750000520 S.DIO DAN222TL [#05]

1750000520 S.DIO DAN222TL [#07]

1750000520 S.DIO DAN222TL [#09]

1750000520 S.DIO DAN222TL [#21]

1750000520 S.DIO DAN222TL [#22]

1750000520 S.DIO DAN222TL [#23]

1750000520 S.DIO DAN222TL [#41]

1750000520 S.DIO DAN222TL [#42]

1750000520 S.DIO DAN222TL [#43]

1750000520 S.DIO DAN222TL [#44]

1750000520 S.DIO DAN222TL [#45]

1750000520 S.DIO DAN222TL [#46]

1750000520 S.DIO DAN222TL [#47]

1750000520 S.DIO DAN222TL [#48]

1750000520 S.DIO DAN222TL [#49]

1750000520 S.DIO DAN222TL [#50]

1750001850 S.DIO LDAN222T1G <SLVJ> [#53]

1750000520 S.DIO DAN222TL [#61]

1750000520 S.DIO DAN222TL [#62]

1750000520 S.DIO DAN222TL [#63]

1750000520 S.DIO DAN222TL [#81]

1750000520 S.DIO DAN222TL [#82]

1750000520 S.DIO DAN222TL [#83]

1750000520 S.DIO DAN222TL [#85]

1750000520 S.DIO DAN222TL [#86]

1750000520 S.DIO DAN222TL [#88]

1750000520 S.DIO DAN222TL [#89]

1750001850 S.DIO LDAN222T1G <SLVJ> [#90]

1750001850 S.DIO LDAN222T1G <SLVJ> [#93]

1750001850 S.DIO LDAN222T1G <SLVJ> [#95]

1750001850 S.DIO LDAN222T1G <SLVJ> [#96]

1750001850 S.DIO LDAN222T1G <SLVJ> [#99]

D23 1750002020 S.DIO DA2S10100L B 31.9/23.0

D24 1750000721 S.VAR HVC375BTRF-E B 100.4/38.2

D28 1790001670 S.DIO RB706F-40T106 [#01] B 28.0/17.7

1790001670 S.DIO RB706F-40T106 [#02]

1790001670 S.DIO RB706F-40T106 [#03]

1790001670 S.DIO RB706F-40T106 [#04]

1790001670 S.DIO RB706F-40T106 [#05]

1790001670 S.DIO RB706F-40T106 [#07]

1790001670 S.DIO RB706F-40T106 [#09]

1790001670 S.DIO RB706F-40T106 [#21]

1790001670 S.DIO RB706F-40T106 [#22]

1790001670 S.DIO RB706F-40T106 [#23]

1790001670 S.DIO RB706F-40T106 [#41]

1790001670 S.DIO RB706F-40T106 [#42]

1790001670 S.DIO RB706F-40T106 [#43]

1790001670 S.DIO RB706F-40T106 [#44]

1790001670 S.DIO RB706F-40T106 [#45]

1790001670 S.DIO RB706F-40T106 [#46]

1790001670 S.DIO RB706F-40T106 [#47]

1790001670 S.DIO RB706F-40T106 [#48]

1790001670 S.DIO RB706F-40T106 [#49]

1790001670 S.DIO RB706F-40T106 [#50]

1750001820 S.DIO LRB706F-40T1G <SLVJ> [#53]

1790001670 S.DIO RB706F-40T106 [#61]

1790001670 S.DIO RB706F-40T106 [#62]

1790001670 S.DIO RB706F-40T106 [#63]

1790001670 S.DIO RB706F-40T106 [#81]

1790001670 S.DIO RB706F-40T106 [#82]

1790001670 S.DIO RB706F-40T106 [#83]

1790001670 S.DIO RB706F-40T106 [#85]

1790001670 S.DIO RB706F-40T106 [#86]

1790001670 S.DIO RB706F-40T106 [#88]

1790001670 S.DIO RB706F-40T106 [#89]

1750001820 S.DIO LRB706F-40T1G <SLVJ> [#90]

1750001820 S.DIO LRB706F-40T1G <SLVJ> [#93]

1750001820 S.DIO LRB706F-40T1G <SLVJ> [#95]

1750001820 S.DIO LRB706F-40T1G <SLVJ> [#96]

1750001820 S.DIO LRB706F-40T1G <SLVJ> [#99]

D31 1750002210 S.DIO DA2S00100L B 77.5/34.5

D32 1750002210 S.DIO DA2S00100L T 86.1/37.0

D33 1750000771 S.VAR HVC376BTRF-E B 68.3/30.9

D34 1750000771 S.VAR HVC376BTRF-E B 68.3/26.2

FI1 2030000150 S.MON DSF753SB 46.350 MHz (FL-335) T 89.9/19.9

FI2 2020002410 CER LTM450FW <JJE>

FI3 2020002220 S.CER SFPKA450KH1A-R1 [#21] B 61.3/13.7

2020002220 S.CER SFPKA450KH1A-R1 [#22]

2020002220 S.CER SFPKA450KH1A-R1 [#23]

2020002220 S.CER SFPKA450KH1A-R1 [#61]

2020002220 S.CER SFPKA450KH1A-R1 [#62]

2020002220 S.CER SFPKA450KH1A-R1 [#63]

X1 6070000300 S.DIS JTBM450CX24 <JJE> B 80.0/16.9

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

X2 6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#01] B 61.6/38.9

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#02]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#03]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#04]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#05]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#07]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#09]

6050012380 S.XTA CR-826 DSA535SD 15.3 MHz

[#21]

6050012380 S.XTA CR-826 DSA535SD 15.3 MHz

[#22]

6050012380 S.XTA CR-826 DSA535SD 15.3 MHz

[#23]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#41]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#42]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#43]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#44]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#45]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#46]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#47]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#48]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#49]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#50]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#53]

6050012380 S.XTA CR-826 DSA535SD 15.3 MHz

[#61]

6050012380 S.XTA CR-826 DSA535SD 15.3 MHz

[#62]

6050012380 S.XTA CR-826 DSA535SD 15.3 MHz

[#63]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#81]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#82]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#83]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#85]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#86]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#88]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#89]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#90]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#93]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#95]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#96]

6050011940 S.XTA CR-783 TTS14VSB-A6 15.3 MHz

[#99]

X6 6050011830 S.XTA CR-774 SMD-49TB 12.288 MHz

<KDS> B 31.2/31.0

L7 6200009930 S.COI C2012C-68NG-A B 101.5/34.6

L8 6200009930 S.COI C2012C-68NG-A B 95.8/38.6

L9 6200010090 S.COI ELJND R82JF B 90.0/38.6

L12 6200008090 S.COI LQW2BHN68NJ03L B 86.3/22.3

L13 6200007850 S.COI ELJNC R82K-F T 88.7/26.1

L21 6200011031 S.COI ELJRF R10JFB B 80.2/23.0

L22 6200011031 S.COI ELJRF R10JFB B 77.8/28.2

L24 6200003640 S.COI MLF1608E 100K-T B 70.9/26.2

L25 6200007770 S.COI LQW2BHNR10J03L B 71.2/22.9

L27 6200003550 S.COI MLF1608A 4R7K-T T 69.8/27.2

L28 6200003550 S.COI MLF1608A 4R7K-T T 69.8/29.8

L32 6200007911 S.COI ELJRF 18NJFB T 88.2/35.8

L33 6200004480 S.COI MLF1608D R82K-T T 80.6/22.4

L34 6200007901 S.COI ELJRF 22NJFB T 87.0/33.3

L35 6200003540 S.COI MLF1608D R22K-T T 84.6/25.4

L36 6200007901 S.COI ELJRF 22NJFB T 86.1/33.3

L37 6200007720 S.COI LQW2BHN33NJ03L B 68.6/33.8

L38 6200010180 S.COI LQW2BHN82NG03L B 71.2/34.2

L39 6200008090 S.COI LQW2BHN68NJ03L B 68.6/23.3

L40 6200003640 S.COI MLF1608E 100K-T B 70.9/30.9

L41 6200007911 S.COI ELJRF 18NJFB B 80.5/29.5

L42 6200003550 S.COI MLF1608A 4R7K-T T 72.2/34.5

L43 6200003550 S.COI MLF1608A 4R7K-T T 72.4/25.0

L47 6200011670 S.COI LQW18AN82NG00D B 90.1/36.4

L48 6200011650 S.COI LQW18AN68NG00D B 89.5/29.7

L49 6200009101 S.COI ELJRE R18GFA B 86.0/28.9

L50 6200003960 S.COI MLF1608A 1R0K-T T 91.0/14.6

April 2013

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on parts orders and repairs.

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

R6 7030005070 S.RES ERJ2GEJ 683 X (68K) T 99.5/34.8

R12 7030005530 S.RES ERJ2GEJ 100 X (10) B 92.6/35.2

R13 7030005090 S.RES ERJ2GEJ 104 X (100K) B 99.0/39.2

R15 7030005310 S.RES ERJ2GEJ 124 X (120K) B 94.2/36.4

R16 7030008280 S.RES ERJ2GEJ 271 X (270) B 93.3/40.4

R17 7030004970 S.RES ERJ2GEJ 470 X (47) B 88.5/40.4

R18 7030007280 S.RES ERJ2GEJ 331 X (330) B 88.5/38.8

R19 7030005090 S.RES ERJ2GEJ 104 X (100K) B 94.2/38.2

R24 7030005120 S.RES ERJ2GEJ 102 X (1K) B 85.3/16.7

R25 7030005070 S.RES ERJ2GEJ 683 X (68K) B 88.1/26.4

R26 7030005310 S.RES ERJ2GEJ 124 X (120K) B 88.5/25.4

R27 7030005100 S.RES ERJ2GEJ 154 X (150K) B 86.3/24.4

R28 7030005070 S.RES ERJ2GEJ 683 X (68K) B 84.5/24.4

R29 7030005590 S.RES ERJ2GEJ 680 X (68) B 90.9/21.4

R31 7030004980 S.RES ERJ2GEJ 101 X (100) B 86.3/25.4

R32 7030010040 S.RES ERJ2GEJ-JPW T 90.5/25.3

R33 7030010040 S.RES ERJ2GEJ-JPW T 89.2/14.6

R34 7030008300 S.RES ERJ2GEJ 184 X (180K) T 87.2/14.6

R35 7030007290 S.RES ERJ2GEJ 222 X (2.2K) T 85.2/14.6

R36 7030008410 S.RES ERJ2GEJ 392 X (3.9K) B 81.4/12.6

R38 7030005090 S.RES ERJ2GEJ 104 X (100K) T 81.7/12.2

R39 7030004970 S.RES ERJ2GEJ 470 X (47) B 81.4/11.6

R40 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 82.2/21.3

R42 7030005120 S.RES ERJ2GEJ 102 X (1K) T 76.3/19.8

R43 7030005000 S.RES ERJ2GEJ 471 X (470) T 78.0/14.6

R44 7030005310 S.RES ERJ2GEJ 124 X (120K) T 78.0/20.7

R45 7030005720 S.RES ERJ2GEJ 563 X (56K) T 76.3/20.7

R46 7030009140 S.RES ERJ2GEJ 272 X (2.7K) T 76.3/21.6

R48 7030005010 S.RES ERJ2GEJ 681 X (680) T 86.2/12.9

R50 7030005050 S.RES ERJ2GEJ 103 X (10K) B 85.3/18.4

R51 7030007290 S.RES ERJ2GEJ 222 X (2.2K) [#21] T 70.6/14.2

7030007290 S.RES ERJ2GEJ 222 X (2.2K) [#22]

7030007290 S.RES ERJ2GEJ 222 X (2.2K) [#23]

7030007290 S.RES ERJ2GEJ 222 X (2.2K) [#61]

7030007290 S.RES ERJ2GEJ 222 X (2.2K) [#62]

7030007290 S.RES ERJ2GEJ 222 X (2.2K) [#63]

R52 7030005050 S.RES ERJ2GEJ 103 X (10K) [#21] T 67.7/16.9

7030005050 S.RES ERJ2GEJ 103 X (10K) [#22]

7030005050 S.RES ERJ2GEJ 103 X (10K) [#23]

7030005050 S.RES ERJ2GEJ 103 X (10K) [#61]

7030005050 S.RES ERJ2GEJ 103 X (10K) [#62]

7030005050 S.RES ERJ2GEJ 103 X (10K) [#63]

R53 7030008290 S.RES ERJ2GEJ 183 X (18K) [#21] B 65.8/16.4

7030008290 S.RES ERJ2GEJ 183 X (18K) [#22]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#23]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#61]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#62]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#63]

R54 7030008290 S.RES ERJ2GEJ 183 X (18K) [#21] B 65.8/18.2

7030008290 S.RES ERJ2GEJ 183 X (18K) [#22]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#23]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#61]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#62]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#63]

R55 7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#21] T 78.0/17.8

7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#22]

7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#23]

7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#61]

7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#62]

7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#63]

R56 7030010040 S.RES ERJ2GEJ-JPW [#01] T 72.3/15.2

7030010040 S.RES ERJ2GEJ-JPW [#02]

7030010040 S.RES ERJ2GEJ-JPW [#03]

7030010040 S.RES ERJ2GEJ-JPW [#04]

7030010040 S.RES ERJ2GEJ-JPW [#05]

7030010040 S.RES ERJ2GEJ-JPW [#07]

7030010040 S.RES ERJ2GEJ-JPW [#09]

7030010040 S.RES ERJ2GEJ-JPW [#41]

7030010040 S.RES ERJ2GEJ-JPW [#42]

7030010040 S.RES ERJ2GEJ-JPW [#43]

7030010040 S.RES ERJ2GEJ-JPW [#44]

7030010040 S.RES ERJ2GEJ-JPW [#45]

7030010040 S.RES ERJ2GEJ-JPW [#46]

7030010040 S.RES ERJ2GEJ-JPW [#47]

7030010040 S.RES ERJ2GEJ-JPW [#48]

7030010040 S.RES ERJ2GEJ-JPW [#49]

7030010040 S.RES ERJ2GEJ-JPW [#50]

7030010040 S.RES ERJ2GEJ-JPW [#53]

7030010040 S.RES ERJ2GEJ-JPW [#81]

7030010040 S.RES ERJ2GEJ-JPW [#82]

7030010040 S.RES ERJ2GEJ-JPW [#83]

7030010040 S.RES ERJ2GEJ-JPW [#85]

7030010040 S.RES ERJ2GEJ-JPW [#86]

7030010040 S.RES ERJ2GEJ-JPW [#88]

7030010040 S.RES ERJ2GEJ-JPW [#89]

7030010040 S.RES ERJ2GEJ-JPW [#90]

7030010040 S.RES ERJ2GEJ-JPW [#93]

7030010040 S.RES ERJ2GEJ-JPW [#95]

7030010040 S.RES ERJ2GEJ-JPW [#96]

7030010040 S.RES ERJ2GEJ-JPW [#99]

R60 7030009140 S.RES ERJ2GEJ 272 X (2.7K) B 83.4/13.2

R61 7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#21] T 78.0/12.6

7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#22]

7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#23]

7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#61]

7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#62]

7030005040 S.RES ERJ2GEJ 472 X (4.7K) [#63]

R62 7030005050 S.RES ERJ2GEJ 103 X (10K) [#21] T 74.0/12.6

7030005050 S.RES ERJ2GEJ 103 X (10K) [#22]

7030005050 S.RES ERJ2GEJ 103 X (10K) [#23]

7030005050 S.RES ERJ2GEJ 103 X (10K) [#61]

7030005050 S.RES ERJ2GEJ 103 X (10K) [#62]

7030005050 S.RES ERJ2GEJ 103 X (10K) [#63]

R67 7030004980 S.RES ERJ2GEJ 101 X (100) B 88.7/10.9

R68 7030005050 S.RES ERJ2GEJ 103 X (10K) B 90.5/10.9

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

R69 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 86.3/16.7

R70 7030005530 S.RES ERJ2GEJ 100 X (10) B 80.2/25.8

R71 7030005220 S.RES ERJ2GEJ 223 X (22K) B 79.2/26.7

R72 7030005120 S.RES ERJ2GEJ 102 X (1K) B 49.0/26.4

R75 7030008010 S.RES ERJ2GEJ 123 X (12K) B 78.7/29.5

R76 7030005530 S.RES ERJ2GEJ 100 X (10) B 79.6/27.9

R77 7030004980 S.RES ERJ2GEJ 101 X (100) B 80.5/27.9

R78 7030005090 S.RES ERJ2GEJ 104 X (100K) B 76.0/28.2

R79 7030008340 S.RES RR0510P-182-D (1.8K) B 72.3/31.8

R80 7030005060 S.RES ERJ2GEJ 333 X (33K) T 76.6/29.7

R82 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) B 73.5/25.1

R83 7030008340 S.RES RR0510P-182-D (1.8K) B 73.5/27.8

R84 7030011000 S.RES RR0510P-392-D (3.9K) B 73.7/24.2

R85 7030011000 S.RES RR0510P-392-D (3.9K) B 76.5/32.5

R86 7030005090 S.RES ERJ2GEJ 104 X (100K) T 74.5/23.6

R87 7030005000 S.RES ERJ2GEJ 471 X (470) T 75.7/30.3

R88 7030008370 S.RES ERJ2GEJ 561 X (560) T 74.5/26.5

R89 7030005050 S.RES ERJ2GEJ 103 X (10K) T 77.6/29.7

R91 7030005090 S.RES ERJ2GEJ 104 X (100K) T 72.7/20.7

R92 7030005230 S.RES ERJ2GEJ 334 X (330K) T 74.5/25.4

R94 7030004990 S.RES ERJ2GEJ 221 X (220) T 77.0/32.8

R95 7030005120 S.RES ERJ2GEJ 102 X (1K) T 75.7/32.0

R96 7030007570 S.RES ERJ2GEJ 122 X (1.2K) T 77.0/31.9

R97 7030007340 S.RES ERJ2GEJ 153 X (15K) T 84.8/34.9

R98 7030007290 S.RES ERJ2GEJ 222 X (2.2K) B 99.0/22.2

R99 7030007340 S.RES ERJ2GEJ 153 X (15K) B 79.6/34.7

R100 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 74.4/21.6

R101 7030004990 S.RES ERJ2GEJ 221 X (220) T 77.6/28.0

R103 7030005230 S.RES ERJ2GEJ 334 X (330K) B 46.2/38.1

R104 7030005700 S.RES ERJ2GEJ 274 X (270K) B 47.2/38.1

R105 7030005230 S.RES ERJ2GEJ 334 X (330K) B 46.2/39.7

R106 7030005050 S.RES ERJ2GEJ 103 X (10K) B 47.2/39.7

R108 7030010040 S.RES ERJ2GEJ-JPW B 65.2/37.6

R109 7030005050 S.RES ERJ2GEJ 103 X (10K) B 63.1/35.3

R110 7030005070 S.RES ERJ2GEJ 683 X (68K) T 69.3/20.7

R111 7030005310 S.RES ERJ2GEJ 124 X (120K) T 66.5/34.8

R115 7030005040 S.RES ERJ2GEJ 472 X (4.7K) T 83.4/25.9

R116 7030007060 S.RES ERJ2GEJ 684X (680K) T 80.7/25.6

R120 7030010040 S.RES ERJ2GEJ-JPW [#01] B 66.5/41.6

7030010040 S.RES ERJ2GEJ-JPW [#02]

7030010040 S.RES ERJ2GEJ-JPW [#03]

7030010040 S.RES ERJ2GEJ-JPW [#04]

7030010040 S.RES ERJ2GEJ-JPW [#05]

7030010040 S.RES ERJ2GEJ-JPW [#07]

7030010040 S.RES ERJ2GEJ-JPW [#09]

7030010040 S.RES ERJ2GEJ-JPW [#21]

7030010040 S.RES ERJ2GEJ-JPW [#22]

7030010040 S.RES ERJ2GEJ-JPW [#23]

7030010040 S.RES ERJ2GEJ-JPW [#41]

7030010040 S.RES ERJ2GEJ-JPW [#42]

7030010040 S.RES ERJ2GEJ-JPW [#43]

7030010040 S.RES ERJ2GEJ-JPW [#44]

7030010040 S.RES ERJ2GEJ-JPW [#45]

7030010040 S.RES ERJ2GEJ-JPW [#46]

7030010040 S.RES ERJ2GEJ-JPW [#47]

7030010040 S.RES ERJ2GEJ-JPW [#49]

7030010040 S.RES ERJ2GEJ-JPW [#50]

7030010040 S.RES ERJ2GEJ-JPW [#53]

7030010040 S.RES ERJ2GEJ-JPW [#61]

7030010040 S.RES ERJ2GEJ-JPW [#62]

7030010040 S.RES ERJ2GEJ-JPW [#63]

7030010040 S.RES ERJ2GEJ-JPW [#81]

7030010040 S.RES ERJ2GEJ-JPW [#82]

7030010040 S.RES ERJ2GEJ-JPW [#83]

7030010040 S.RES ERJ2GEJ-JPW [#85]

7030010040 S.RES ERJ2GEJ-JPW [#86]

7030010040 S.RES ERJ2GEJ-JPW [#89]

7030010040 S.RES ERJ2GEJ-JPW [#90]

7030010040 S.RES ERJ2GEJ-JPW [#93]

7030010040 S.RES ERJ2GEJ-JPW [#95]

7030010040 S.RES ERJ2GEJ-JPW [#96]

7030010040 S.RES ERJ2GEJ-JPW [#99]

R121 7030005060 S.RES ERJ2GEJ 333 X (33K) B 68.6/41.2

R122 7030005050 S.RES ERJ2GEJ 103 X (10K) T 98.3/39.1

R123 7030005050 S.RES ERJ2GEJ 103 X (10K) B 99.8/42.1

R124 7030005700 S.RES ERJ2GEJ 274 X (270K) T 73.8/24.5

R125 7030005090 S.RES ERJ2GEJ 104 X (100K) [#21] B 39.9/6.2

7030005090 S.RES ERJ2GEJ 104 X (100K) [#22]

7030005090 S.RES ERJ2GEJ 104 X (100K) [#23]

7030005090 S.RES ERJ2GEJ 104 X (100K) [#61]

7030005090 S.RES ERJ2GEJ 104 X (100K) [#62]

7030005090 S.RES ERJ2GEJ 104 X (100K) [#63]

R126 7030004980 S.RES ERJ2GEJ 101 X (100) B 23.2/4.5

R127 7030005240 S.RES ERJ2GEJ 473 X (47K) B 33.7/10.9

R128 7030008290 S.RES ERJ2GEJ 183 X (18K) B 33.7/9.2

R129 7030007060 S.RES ERJ2GEJ 684X (680K) B 35.7/9.2

R133 7030005090 S.RES ERJ2GEJ 104 X (100K) B 35.4/5.3

R134 7030005050 S.RES ERJ2GEJ 103 X (10K) B 43.9/8.5

R135 7030008410 S.RES ERJ2GEJ 392 X (3.9K) B 43.9/9.5

R136 7030005240 S.RES ERJ2GEJ 473 X (47K) B 40.7/9.5

R137 7030005080 S.RES ERJ2GEJ 823 X (82K) B 45.0/12.7

R138 7030005000 S.RES ERJ2GEJ 471 X (470) B 45.0/14.3

R139 7030008310 S.RES ERJ2GEJ 564 X (560K) B 43.6/16.6

R140 7030005700 S.RES ERJ2GEJ 274 X (270K) B 41.9/17.5

R141 7030010040 S.RES ERJ2GEJ-JPW B 37.4/18.6

R142 7030008410 S.RES ERJ2GEJ 392 X (3.9K) B 36.7/9.2

R143 7030005100 S.RES ERJ2GEJ 154 X (150K) B 33.7/16.0

R144 7030005700 S.RES ERJ2GEJ 274 X (270K) B 37.4/17.5

R145 7030005100 S.RES ERJ2GEJ 154 X (150K) B 34.7/17.7

R146 7030005060 S.RES ERJ2GEJ 333 X (33K) B 34.7/16.0

R147 7030005100 S.RES ERJ2GEJ 154 X (150K) B 35.7/17.7

R148 7030005000 S.RES ERJ2GEJ 471 X (470) B 37.4/16.3

R149 7030005110 S.RES ERJ2GEJ 224 X (220K) B 33.7/17.7

R150 7030008310 S.RES ERJ2GEJ 564 X (560K) B 43.6/17.5

R151 7030005080 S.RES ERJ2GEJ 823 X (82K) B 33.9/38.4

April 2013

Eqv.= This component is equivalent to the REF No. component listed above, and

may be substituted on parts orders and repairs.

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

R152 7030008300 S.RES ERJ2GEJ 184 X (180K) B 34.1/42.9

R153 7030005310 S.RES ERJ2GEJ 124 X (120K) B 35.9/42.9

R154 7030005080 S.RES ERJ2GEJ 823 X (82K) B 35.9/41.3

R155 7030005720 S.RES ERJ2GEJ 563 X (56K) B 35.9/37.1

R156 7030005050 S.RES ERJ2GEJ 103 X (10K) B 48.1/16.4

R157 7030004980 S.RES ERJ2GEJ 101 X (100) [#21] B 30.1/8.0

7030004980 S.RES ERJ2GEJ 101 X (100) [#22]

7030004980 S.RES ERJ2GEJ 101 X (100) [#23]

7030004980 S.RES ERJ2GEJ 101 X (100) [#61]

7030004980 S.RES ERJ2GEJ 101 X (100) [#62]

7030004980 S.RES ERJ2GEJ 101 X (100) [#63]

R158 7030005160 S.RES ERJ2GEJ 105 X (1M) B 37.9/37.1

R159 7030005120 S.RES ERJ2GEJ 102 X (1K) B 35.9/39.7

R160 7030005050 S.RES ERJ2GEJ 103 X (10K) B 35.0/39.7

R161 7030005050 S.RES ERJ2GEJ 103 X (10K) B 48.0/19.7

R162 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 48.0/18.8

R163 7030005050 S.RES ERJ2GEJ 103 X (10K) B 87.6/12.1

R164 7030005050 S.RES ERJ2GEJ 103 X (10K) B 85.7/10.5

R165 7030005050 S.RES ERJ2GEJ 103 X (10K) B 102.6/14.7

R166 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 101.2/24.6

R167 7030005050 S.RES ERJ2GEJ 103 X (10K) B 48.2/6.3

R168 7030005050 S.RES ERJ2GEJ 103 X (10K) B 49.1/6.3

R169 7030004980 S.RES ERJ2GEJ 101 X (100) B 101.2/25.6

R172 7030005220 S.RES ERJ2GEJ 223 X (22K) T 92.1/33.7

R181 7030005220 S.RES ERJ2GEJ 223 X (22K) B 57.0/6.3

R182 7030005220 S.RES ERJ2GEJ 223 X (22K) B 57.0/8.0

R183 7030005220 S.RES ERJ2GEJ 223 X (22K) B 55.2/8.0

R184 7030005050 S.RES ERJ2GEJ 103 X (10K) B 53.4/10.0

R185 7030007300 S.RES ERJ2GEJ 332 X (3.3K) B 52.5/10.0

R186 7030005090 S.RES ERJ2GEJ 104 X (100K) B 57.0/10.0

R187 7030005070 S.RES ERJ2GEJ 683 X (68K) B 55.2/12.8

R188 7030005050 S.RES ERJ2GEJ 103 X (10K) B 53.4/8.0

R190 7030007570 S.RES ERJ2GEJ 122 X (1.2K) B 54.3/12.8

R194 7030005090 S.RES ERJ2GEJ 104 X (100K) B 57.9/22.2

R195 7030005090 S.RES ERJ2GEJ 104 X (100K) B 60.2/23.5

R196 7030007350 S.RES ERJ2GEJ 393 X (39K) B 60.2/24.4

R197 7030005080 S.RES ERJ2GEJ 823 X (82K) B 60.2/26.7

R198 7030008300 S.RES ERJ2GEJ 184 X (180K) B 57.0/24.4

R199 7030006610 S.RES ERJ2GEJ 394 X (390K) [#01] B 58.6/24.4

7030006610 S.RES ERJ2GEJ 394 X (390K) [#02]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#03]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#04]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#05]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#07]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#09]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#21]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#22]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#23]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#41]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#42]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#43]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#44]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#45]

7030010040 S.RES ERJ2GEJ-JPW [#46]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#47]

7030010040 S.RES ERJ2GEJ-JPW [#48]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#49]

7030010040 S.RES ERJ2GEJ-JPW [#50]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#53]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#61]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#62]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#63]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#81]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#82]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#83]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#85]

7030010040 S.RES ERJ2GEJ-JPW [#86]

7030010040 S.RES ERJ2GEJ-JPW [#88]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#89]

7030010040 S.RES ERJ2GEJ-JPW [#90]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#93]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#95]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#96]

7030006610 S.RES ERJ2GEJ 394 X (390K) [#99]

R200 7030005030 S.RES ERJ2GEJ 152 X (1.5K) B 58.6/25.4

R201 7030005050 S.RES ERJ2GEJ 103 X (10K) T 96.6/39.1

R202 7030005000 S.RES ERJ2GEJ 471 X (470) T 96.6/38.1

R209 7030005070 S.RES ERJ2GEJ 683 X (68K) B 47.2/41.3

R210 7030005240 S.RES ERJ2GEJ 473 X (47K) B 46.2/42.9

R211 7030005240 S.RES ERJ2GEJ 473 X (47K) B 46.2/41.3

R213 7030005040 S.RES ERJ2GEJ 472 X (4.7K) B 42.2/37.0

R214 7030005240 S.RES ERJ2GEJ 473 X (47K) B 44.2/37.0

R215 7030005070 S.RES ERJ2GEJ 683 X (68K) B 55.0/32.0

R216 7030005070 S.RES ERJ2GEJ 683 X (68K) B 56.7/32.0

R217 7030005070 S.RES ERJ2GEJ 683 X (68K) B 60.2/30.0

R218 7030005070 S.RES ERJ2GEJ 683 X (68K) B 60.2/32.0

R219 7030005240 S.RES ERJ2GEJ 473 X (47K) B 58.4/33.0

M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)

S.=Surface mount

REF PARTS DESCRIPTION M. H/V

NO. NO.

LOCATION

[MAIN UNIT]

R220 7030005220 S.RES ERJ2GEJ 223 X (22K) [#01] B 60.2/34.0

7030005220 S.RES ERJ2GEJ 223 X (22K) [#02]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#03]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#04]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#05]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#07]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#09]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#21]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#22]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#23]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#41]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#42]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#43]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#44]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#45]

7030010040 S.RES ERJ2GEJ-JPW [#46]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#47]

7030010040 S.RES ERJ2GEJ-JPW [#48]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#49]

7030010040 S.RES ERJ2GEJ-JPW [#50]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#53]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#61]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#62]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#63]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#81]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#82]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#83]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#85]

7030010040 S.RES ERJ2GEJ-JPW [#86]

7030010040 S.RES ERJ2GEJ-JPW [#88]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#89]

7030010040 S.RES ERJ2GEJ-JPW [#90]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#93]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#95]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#96]

7030005220 S.RES ERJ2GEJ 223 X (22K) [#99]

R221 7030005220 S.RES ERJ2GEJ 223 X (22K) B 48.2/39.7

R222 7030008300 S.RES ERJ2GEJ 184 X (180K) B 7.0/19.3

R223 7030005720 S.RES ERJ2GEJ 563 X (56K) B 7.0/20.3

R224 7030005220 S.RES ERJ2GEJ 223 X (22K) B 7.0/21.3

R225 7030007260 S.RES ERJ2GEJ 330 X (33) T 94.4/20.7

R226 7030005300 S.RES ERJ2GEJ 150 X (15) T 94.5/16.0

R227 7030009140 S.RES ERJ2GEJ 272 X (2.7K) T 97.4/22.5

R228 7030007300 S.RES ERJ2GEJ 332 X (3.3K) T 95.5/22.5

R229 7030005120 S.RES ERJ2GEJ 102 X (1K) T 95.4/26.7

R230 7030005230 S.RES ERJ2GEJ 334 X (330K) B 34.1/22.6

R231 7030005100 S.RES ERJ2GEJ 154 X (150K) B 34.1/21.6

R233 7030004980 S.RES ERJ2GEJ 101 X (100) T 98.7/12.1

R234 7030005120 S.RES ERJ2GEJ 102 X (1K) T 103.3/16.8

R235 7030005000 S.RES ERJ2GEJ 471 X (470) T 80.5/8.0

R236 7030005090 S.RES ERJ2GEJ 104 X (100K) T 77.2/8.5

R237 7030005030 S.RES ERJ2GEJ 152 X (1.5K) T 78.8/5.5

R238 7030005000 S.RES ERJ2GEJ 471 X (470) B 85.7/5.4

R239 7030007340 S.RES ERJ2GEJ 153 X (15K) B 26.3/19.5

R240 7030005720 S.RES ERJ2GEJ 563 X (56K) B 50.6/24.4

R241 7030009150 S.RES ERJ2GEJ 824 X (820K) B 50.6/28.5

R242 7030006610 S.RES ERJ2GEJ 394 X (390K) B 50.6/27.4

R243 7030007340 S.RES ERJ2GEJ 153 X (15K) B 52.2/24.4

R244 7030005240 S.RES ERJ2GEJ 473 X (47K) B 53.8/24.4

R245 7030008290 S.RES ERJ2GEJ 183 X (18K) B 50.6/25.4

R246 7030005090 S.RES ERJ2GEJ 104 X (100K) B 45.8/32.1

R247 7030005000 S.RES ERJ2GEJ 471 X (470) B 45.8/35.1

R248 7030005050 S.RES ERJ2GEJ 103 X (10K) B 43.9/5.3

R249 7030005120 S.RES ERJ2GEJ 102 X (1K) B 45.2/20.6

R254 7030005090 S.RES ERJ2GEJ 104 X (100K) B 58.4/34.0

R255 7030008290 S.RES ERJ2GEJ 183 X (18K) [#01] B 56.7/33.0

7030008290 S.RES ERJ2GEJ 183 X (18K) [#02]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#03]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#04]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#05]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#07]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#09]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#21]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#22]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#23]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#41]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#42]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#43]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#44]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#45]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#47]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#49]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#53]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#61]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#62]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#63]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#81]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#82]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#83]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#85]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#89]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#93]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#95]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#96]

7030008290 S.RES ERJ2GEJ 183 X (18K) [#99]

R256 7510001730 S.THE ERTJOEP 473J B 18.7/39.4

R257 7030005090 S.RES ERJ2GEJ 104 X (100K) B 18.7/37.4

R258 7030005530 S.RES ERJ2GEJ 100 X (10) B 26.3/31.4

R259 7030005160 S.RES ERJ2GEJ 105 X (1M) B 26.3/32.4

R260 7030008010 S.RES ERJ2GEJ 123 X (12K) B 27.7/31.3

R261 7030008010 S.RES ERJ2GEJ 123 X (12K) B 26.3/29.4

R262 7030008010 S.RES ERJ2GEJ 123 X (12K) B 26.3/28.4

R263 7030005090 S.RES ERJ2GEJ 104 X (100K) B 16.8/41.4

R264 7030005820 S.RES RR0510P-103-D (10K) B 10.7/4.7

R265 7030005820 S.RES RR0510P-103-D (10K) B 8.8/4.7

This manual suits for next models

Table of contents

Other Icom Portable Radio manuals

Icom

Icom IC-F9011 User manual

Icom

Icom IC-A25N User manual

Icom

Icom IC-F4GT User manual

Icom

Icom IC-435 User manual

Popular Portable Radio manuals by other brands

Philips

Philips AE6775 Specifications

Motorola

Motorola Mag One D8 user guide

Wouxun

Wouxun KG-824B manual

Yaesu

Yaesu FT-23R MKII Technical supplement

Uniden

Uniden 810e owner's manual

Motorola

Motorola APX 3000 user guide

Blaupunkt

Blaupunkt PP6BR owner's manual

Sangean

Sangean U-3 user manual

Vivax

Vivax APM-1030 user manual

Roberts

Roberts R9927 manual

Radio Shack

Radio Shack Radio owner's manual

Roberts

Roberts Clasic 997 manual

TerraTec

TerraTec NOXONiRadio Detailed manual

Wouxun

Wouxun KG-S86B manual

Philips

Philips DA9011 brochure

Philips

Philips AE2110/04 user manual

Eton

Eton E5 owner's manual

Blaupunkt

Blaupunkt PR3BK owner's manual

Icom IC-F3020 Installation and operating instructions

Popular Portable Radio manuals by other brands
