ICON MP14-Argon2 User manual

1
ICON Tablet
Model: MP14-Argon2
Directions
Meanings of icons:

2
Forbidding: forbid improper operations to avoid damaging
the tablet.
Caution: cautions for operators to avoid potential damages.
Please note and remember.
Importance: important information, common notes,
definitions, general knowledge and references, etc.
Other trademarks and trade name may be used in this manual to refer
to either the entities claiming the marks and names or their products.
The manufacture disclaims any proprietary interest in trademarks and
trade names other than its own.
Information in this manual is subject to change without notice.
Reproduction in any manner whatsoever without the written
permission from the manufacture is strictly forbidden.
Product images in this manual are for your reference only.
Contents

3
Directions.........................................................................1
Safety Precautions..........................................................4
1 Know Your Tablet......................................................... 7
2 Get to Know Your System...........................................7
2-1 Add screen shortcuts ............................................... 8
2-2 Delete screen shortcuts/widgets ........................... 10
2-3 On-screen Keyboard .............................................. 11
3 System Settings ......................................................... 12
3-1 Wireless & networks............................................... 12
3-2 Device...................................................................... 15
3-3 Personal .................................................................. 16
3-4 System..................................................................... 16
4 Browser....................................................................... 17
5 Camera ........................................................................ 18

4
6 Specifications............................................................. 20
7 CE Mark....................................................................... 21
8 Shell .........................................................................24
Safety Precautions
1. DO NOT expose the tablet to dirty or dusty environment. Keep the
environment clean and dry.

5
2. DO NOT place or drop objects on the top of the tablet. DO NOT
shove any foreign objects into the tablet. DO NOT cover the LCD
Screen strongly.
3. DO NOT expose the tablet to strong magnetic or electrical fields;
DO NOT place the floppy disk near or on the tablet, which may loss
the data of the floppy disk.
4. DO NOT leave the tablet facing the sun as it can damage the LCD
Screen, especially in the car.
5. DO NOT expose the tablet to or use near liquids, rain, or moisture.
6. DO NOT throw the tablet in municipal waste.
Check local regulations for disposal of electronic products.
8. DO NOT insert anything into the tablet that may result in short
circuit or damage the circuit.
9. Power off the tablet, if you want to install or remove some external
devices which are not support hot-plug.
10. DO NOT disassemble the tablet, only a certified service
technician should perform repairs on your computer. Otherwise,
problems may result and the manufacturer should not hold
responsibility for the damage.
11.
Direct current
To indicate on the rating plate that the equipment is
suitable for direct current only; to identify relevant terminals.

6
12. Meaning of crossed –out wheeled dustbin。Do not dispose
of electrical appliances as unsorted municipal waste, use separate
collection facilities. Contact you local government for information
regarding the collection systems available. If electrical appliances are
disposed of in landfills or dumps, hazardous substances can leak into
the groundwater and get into the food chain, damaging your health
and well-being. When replacing old appliances with new ones, the
retailer is legally obligated to take back your old appliance for
disposals at least free of charge.
13．the product complies with the essential requirements of
the relevant European health,
safety and environmental protection legislation.
14. For AC/DC Adapter, the socket-outlet shall be installed near the
equipment and shall be easily accessible.
15. Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.

7
1 Know Your Tablet
KEYS:connect to the console through a cable, so that the host can
control the volume or reset
AUDIO JACK: connect to the console through a cable to provide
audio signal output.
Picture1-1

8
2 Get to Know Your System
Connect to the power supply and then it will display the home screen
as below picture
.
Click on the screen for ten times, pause for 5 seconds and then do it
again for ten times’clicks to enter the Setting priviledged mode as
below.
Picture 2-1

9
Quick settings

10
: tap to return to the previous page.
: tap to enter Home screen.
: tap to open recent APPs list menu.
: tap to enter APPs Menu.
If it’s your first time to use the tablet, the system will enter the guide
menu. Please finish the initial setting following the instructions.
2-1 Add screen shortcuts
On the home page, touch and hold the blank area to popup menu to
change wallpaper;
Touch to access APPS menu as shown in picture 2-3; touch and
hold an APPS icon to add it to the home screen.
Notification
Bar
Picture 2-2

11
2-2 Delete screen shortcuts/widgets
On the home screen, touch and hold the shortcut or widget to be
deleted until the icon “×” appears at the top middle of the home screen.
Drag the shortcuts to the remove icon to delete.
2-3 On-screen Keyboard
Just touch a text field to open the on-screen keyboard;
Touch on the tool bar to close it.
Toggle letters & numbers
Space
Caps lock
button
Backspace
Go
Picture 2-3
Picture 2-4
Expression

12
3 System Settings
3-1 Wireless & networks
3-1-1 Wi-Fi
Touch the Wi-Fi swtich behind of the Wi-Fi item to turn on the Wi-Fi
function and then the system will auto-scan the available networks to
display as shown in picture 3-2.
Select one network and input its password if necessary to connect.
Touch to perform advanced Wi-Fi settings.

13
3-1-2 Bluetooth
The Bluetooth function enables you to exchange files between the
tablet and other Bluetooth devices.
Before this step, please activate the Bluetooth function of
other device (mobile phone, Bluetooth earphone etc.)
and make sure the device is in range.
Touch the Bluetooth swtich behind of the Bluetooth item to turn on the
Bluetooth function and then the system will auto-scan the visible
Bluetooth device nearby and display after finding as shown in picture
3-3:
Picture 3-2

14
Touch the desired Bluetooth device to start pairing. Then according to
the indications on both sides, users can complete the connection
successfully in seconds.
After pairing, you can share files between the unit and the Bluetooth
device.
Touch to perform advanced Bluetooth settings.
3-1-3 Data usage
Touch to see the data usage information.
3-1-4 More
Picture 3-3

15
The system supplies users more networks settings, such as Airplane
mode, Tethering and VPN.
3-2 Device
3-2-1 Display
Touch to open display settings, including Brightness level, Wallpaper,
Sleep, Press power button twice for camera, Screen saver, Font
size ,Display size and Cast.
3-2-2 Notification
All apps will be displayed here for you to choose whether to open the
notification or not.
3-2-3 Sound
Touch to do the Sound general settings.
3-2-4 Apps
Picture 3-5

16
Touch to check the Apps’information.
3-2-5 Storage
Touch to check the usage of internal shared storage.
3-2-6 Memory
Set memory in 3 hours, 6 hours,12 hours or 1 day and check the
memory in the time period.
3-2-7 Users
Touch to set the owner’s information, or add a new user.
3-3 Personal
3-3-1 Location
To open or close location services.
3-3-2 Security
Security information of system settings.
3-3-3 Accounts
To add email accounts or google accounts.
3-3-4 Language & input
To choose the system language and open/close the Spell checker.
You can also set the keyboard & input methods.
3-3-5 Backup & reset
Reset the system to the factory states.
3-4 System
3-4-1 Date & time

17
Option is about the current system date & time setting. You can set
the date and time, and their format of the tablet.
3-4-2 Accessibility
Look at what other accessibilities in the system or add some.
3-4-3 Printing
Search connected printer to print some files.
3-4-4 Developer options
To turn on/off the development settings. These settings are intended
for development use only. They can cause your device and the
applications on it to break or misbehave.
3-4-5 Schedule power on & off
Choose the time and set the schedule power on or off as you need.
3-4-6 About tablet
The detailed information about the unit, including Status, Legal
information, Model number, Android version, Android security patch
level,Kernel version, Build number and Custom build version.
4 Browser
Open:
After the network connection completed, touch the browser icon to
access the network browsing.
Designing wed may slow the speed to browse the web.

18
5 Camera
Open:
Take Pictures: 1. Aim the object.
2. Press to take a picture.
Notice:
1. Select video mode if you want to record videos.
2. All photos or videos taken are both stored in the photos and gallery.
Picture5-1

19
6 Specifications
ICON part No.
415321
ICON model
MP14-Argon2
Description
14 inch display tablet, with touch,
and core board
OS
Android 9.0
CPU Manufacturer
MTK
CPU Model
MT8163 V/A
CPU Core Model
Cortex A53 / Quad core
CPU Frequency
1.5 GHz
LPDDR3
2G
Mass Memory
8GB iNAND
Resolution
1920RGB (W) x1080(H)
Aspect Ratio
16：09
Contrast
800:1
WiFi
802.11a/b/g/n
Bluetooth Version
BT5.0
Front Camera
2M pixels
Adapter
12V 2A (not included)

20
7 For CE
Compliance with the RE Directive
We, ICON Health & Fitness Inc.
Hereby, ICON Health & Fitness Inc. declares that the radio equipment
MP14-Argon2 is In compliance with Directive 2014/53/EU
SW and HW Version
Product SW Version: Model number Argon
Product HW Version: A492C V2.0
Operating Temperature: 0℃~40℃
RF EXPOSURE
A minimum separation distance of 20 cm must be maintained between the
user's body and the device, including the antenna during body-worn
operation to comply with the RF exposure requirements in Europe.
Operations in the 5.15-5.35GHz band are restricted to indoor usage only in
following Countries：
