ICOP Technology VDX3-6724-1G User manual

ICOP Technology Inc.
User Manual
VDX3-6724
with
DM&P Vortex86DX3 1GHz processor
Half-Size CPU Module with
4S/4USB/VGA/LCD/LVDS/
AUDIO/2LAN/GPIO/
1/2GB DDR3 Onboard
Version 2.0

VDX3-6724 User Manual
ICOP Technology Inc. 1
Copyright
The information in this manual is subject to change without notice for
continues improvement in the product. All rights are reserved. The
manufacturer assumers no reasonability for any inaccuracies that may be
contained in this document and makes no commitment to update or to keep
current the information contained in this manual.
No part of this manual may be reproduced, copied, translated or transmitted,
in whole or in part, in any form or by any means without the prior to written
permission of ICOP Technology Inc.
ⓒCopyright 2016 ICOP Technology Inc
Trademarks Acknowledgement
Vortex86DX3TM is the registered trademark of DM&P Electronics Inc.
Other brand names and product names that appear in this document are the
properties and registered trademarks of their respective owners. All names
mentioned herewith are served for identification purpose only.

VDX3-6724 User Manual
ICOP Technology Inc. 2
Revision History
Revision
Date
Remark
1.0
June 13, 2016
First release
2.0
June 8, 2016
New Add:
(1) Working temperature for Dual Core version
(2) Cable set for VDX3-6724 with Compact
Flash

VDX3-6724 User Manual
ICOP Technology Inc. 3
Table of Contents
1General Information ........................................................................................................................ 5
1.1 Overview ........................................................................................................................5
1.2 Block diagram .................................................................................................................5
1.3 Specifications ..................................................................................................................6
1.4 Ordering Information .....................................................................................................8
2Hardware Information................................................................................................................... 10
2.1 Board Dimension..........................................................................................................10
2.2 Board Outline ...............................................................................................................11
2.3 Connector and Jumper Location and Summary.............................................................12
2.4 Pin Assignments & Jumper Settings ..............................................................................14
J1: LCD .............................................................................................................................14
J2: VGA.............................................................................................................................15
J3: LVDS (24-bit Support Only) ........................................................................................15
J4: SATA DOM.................................................................................................................15
J5: Power Connector (Terminal Block 5.0mm) ..................................................................16
J6: SATA DOM POWER..................................................................................................16
J8: PS/2 KEYBOARD/MOUSE ......................................................................................16
J9: LAN1 (RJ45) ................................................................................................................16
J10: LAN2 .........................................................................................................................16
J11: USB0&1 .....................................................................................................................17
J12: USB2&3 .....................................................................................................................17
J13: GPIO (Port 6/7) ........................................................................................................17
J15: RESET .......................................................................................................................18

VDX3-6724 User Manual
ICOP Technology Inc. 4
J17: COM1 RS232/485 D-Sub 9 pin (Optional: TTL/ GPIO-P4) .....................................18
J18: COM2 RS232/485 (Optional: TTL/ GPIO-P5) .........................................................18
J20: COM5 RS232 (Optional: TTL/ GPIO-P0).................................................................18
J22: COM6 RS232 (Optional: TTL/ GPIO-P1).................................................................19
J24A: PC/104 Connector –64 pin.....................................................................................20
J24B: PC/104 Connector –40 pin .....................................................................................20
J28: Line-Out.....................................................................................................................21
J29: MIN-In.......................................................................................................................21
J30: Touch screen (Optional) .............................................................................................21
J31: Print............................................................................................................................22
3Software Resources......................................................................................................................... 22
3.1 ICOP Technical Resource Website ...............................................................................22
4Basic BIOS Setting ......................................................................................................................... 23
4.1 Introduction..................................................................................................................23
4.2 CPU Clock Adjusting....................................................................................................23
4.3 Console Redirection......................................................................................................23
4.4 Serial Ports Switching....................................................................................................24
4.5 IDE Configuration........................................................................................................25
4.6 Advanced PCI-PnP Setting ...........................................................................................26
4.7 ACPI Enable.................................................................................................................27
5Basic LCD Panel Setting ...............................................................................................28
5.1 Introduction................................................................................................................28
5.2 Pin Assignment of LVDS............................................................................................28
5.3 Basic BIOS Setting for LCD .......................................................................................29
Technical Support Directly from ICOP................................................................................................ 31
User Manual Feedback............................................................................................................................. 31
Appendix TFT Panel Data Output ........................................................................................................ 32

VDX3-6724 User Manual
ICOP Technology Inc. 5
Warranty..................................................................................................................................................... 34
1 General Information
1.1 Overview
The VDX3-6724 is a low-power CPU module which compliant with ETX standard. It takes the
advantage of Vortex86DX3 1GHz x86 CPU which integrate the SATA, I2C, VGA, LVDS, PS/2,
USB, HD Audio and even with 16-bit ISA bus support.
The VDX3-6724 is designed as a plug in replacement, with backward compatibility to support
legacy software to help extend existing product life cycle without heavy re-engineering.
1.2 Block diagram
Board Block Diagram

VDX3-6724 User Manual
ICOP Technology Inc. 6
1.3 Specifications
Processor
DM&P SoC CPU Vortex86DX3 1GHz
L1:32K I-Cache, 32K D-Cache, L2 Cache:512KB
RAM
1GB/2GB DDR3 Onboard
Bus
PC/104 Standard Compliant
Watchdog Timer
Software programmable from 30.5 us to 512 seconds x2sets
Display
Integrated 2D VGA chip with dual display support
(VGA + TTL / VGA + LVDS)
VGA: Maximum resolution up to 1920x1080 @ 60Hz
LVDS: Maximum resolution up to 1024x768 @ 60Hz
Single channel 24-bit LVDS
LAN
Integrated 10/100Mbps Ethernet x1
Realtek 81111F 10/100/1000Mbps Ethernet x1
Audio
HD Audio
Optional
Interface
PS/2 touch controller x1
USB hot SWAP x1
I/O Interface
SATA 7P Connector x1
RS232 port x2
RS232/485 port x2
Parallel port x1
USB port (Ver. 2.0) x4
16-bit GPIO port x1
10/100Mbps Ethernet port x1
10/100/10000Mbps Ethernet port x1

VDX3-6724 User Manual
ICOP Technology Inc. 7
Connectors
SATA 7P for SATA x1, 2P for SATA Power x1
2.54mm 26-pin box header for Printer x1
2.54mm 20-pin box header for GPIO x1
2.54mm 10-pin box header for USB x2
2.54mm 10-pin box header for RS232 x3
2.54mm 2-pin header for Reset x1
2.0mm 44-pin box header for LCD x1
2.0mm 20-pin header for LVDS x1
2.0mm 8-pin header for Ethernet x1
1.25mm 4-pin wafer for Line-out/MIC-in x2
External RJ-45 connector for Ethernet x1
External Mini DIN connector for KBD/Mouse x1
External D-Sub 15 pins female connector for VGA x1
External D-Sub 9 pins male connector for RS232 x1
Flash Disk
Support
Compact Flash Type I/II (Optional)
Onboard eMMC 512MB/4GB (Optional)
Power
Requirement
Single Voltage +5V @1000mA (Typical)
Dimensions
184mm x 122mm (7.24 x 4.80 inches)
Weight
180g
Operating
Temp.
-20℃~ +70℃(Single Core)
-10℃~ +60℃(Dual Core)
-40℃~ +85℃(Optional for Single Core)
-20℃~ +70℃(Optional for Dual Core)
Operating
System Support
Free DOS, DOS 6.22, PCDOS 7.1, DR-DOS, x-DOS, OS/2, Windows 7,
Windows Embedded Standard 7, Windows Embedded Compact 7,
Windows Embedded Compact 6, Windows XP Professional, Windows
Embedded Standard(XPE), POS Ready(WePOS), Embedded Linux, QNX,
Vxworks and FreeBSD.

VDX3-6724 User Manual
ICOP Technology Inc. 8
1.4 Ordering Information
Part Number
Product Description
VDX3-6724-1G
Vortex86DX3 Half-Size CPU Module with 1GB DDR3
VDX3-6724-2G
Vortex86DX3 Half-Size CPU Module with 2GB DDR3
VDX3-6724-2C-1G
Vortex86DX3 Half-Size Dual Core CPU Module with 1GB DDR3
VDX3-6724-2C-2G
Vortex86DX3 Half-Size Dual Core CPU Module with 2GB DDR3
VDX3-6724-CF-1G
Vortex86DX3 Half-Size CPU Module with 1GB DDR3
with CF card slot
VDX3-6724-2C-CF-1G
Vortex86DX3 Half-Size Dual Core CPU Module with 1GB DDR3
with CF card slot
VDX3-6724-CF-2G
Vortex86DX3 Half-Size CPU Module with 2GB DDR3
with CF card slot
VDX3-6724-2C-CF-2G
Vortex86DX3 Half-Size Dual Core CPU Module with 1GB DDR3
with CF card slot
CABLE-6724-SET
GPIO (2.54) x1
RS-232 (2.54) x3
Audio Line x2
YKB x1
Printer (2.54) x1
USB (2.54) x2
NET 4x2 (2.0) x1
CABLE-6724-CF
RS-232 (2.54) x3
Audio Line x2
YKB x1
USB (2.54) x2
NET 4x2 (2.0) x1
ICOP-0096
Vortex86 LVDS 18-bit Converter Kit for LCD Panel Display
CABLE-LVDS-30
18-Bit LVDS Cable
*Default setting for processor on VDX3-6724 is Single-core. If Dual-core processor is required,
please contact ICOP ([e-mail]).

VDX3-6724 User Manual
ICOP Technology Inc. 9
Storages:
Product Name
MLC
SLC
0℃~ +70℃
-40℃~ +85℃
SDM-SST-2G-H-M
V
V
SDM-SST-4G-H-M
V
V
ISATA-8G-H-M
V
V
ISATA-16G-H-M
V
V
ISATA-32G-H-M
V
V
ISATA-4G-H-M-X
V
V
ISATA-8G-H-M-X
V
V
ISATA-16G-H-M-X
V
V
ISATA-32G-H-M-X
V
V
ISATA-1G-H-S
V
V
ISATA-2G-H-S
V
V
ISATA-4G-H-S
V
V
ISATA-8G-H-S
V
V
ISATA-16G-H-S
V
V
SDM-SST-2G-H-S-X
V
V
SDM-SST-4G-H-S-X
V
V
SDM-SST-8G-H-S-X
V
V
ISATA-16G-H-S-X
V
V

VDX3-6724 User Manual
ICOP Technology Inc. 10
2 Hardware Information
2.1 Board Dimension

VDX3-6724 User Manual
ICOP Technology Inc. 11
2.2 Board Outline
VDX3-6724
Note:
1. COM RS232/485 is selected by BIOS.
2. Touch screen is optional. If touch screen function is selected, onboard SPI ROM and PS/2
function will be disabled.
3. GPIO will be occupied when eMMC is selected on VDX3-6754.
4. LPT, eMMC, and GPIO are not available on VDX3-6754-CF.
5. CF card slot is only available on VDX3-6754-CF. (See the image below)

VDX3-6724 User Manual
ICOP Technology Inc. 12
2.3 Connector and Jumper Location and Summary
Jumper Location:

VDX3-6724 User Manual
ICOP Technology Inc. 13
Jumper Summary:
Nbr.
Name
Type of Connections
Pin Nbr
J1
LCD
Box Header, 2.0mm, 2x22
44
J2
VGA
15-pin D-Sub Female
15
J3
24-bit LVDS
Pin Header, 2.0mm, 10x2
20
J4
SATA DOM
SATA 7P Connector, 7x1
7
J5
Power Connector
Terminal Block, 5.0mm, 2x1
2
J6
SATA DOM Power
Box Header, 2.0mm, 1x2
2
J8
PS/2 Keyboard/Mouse
Mini-DIN Female
6
J9
LAN1
RJ45 Connector
8
J10
LAN2
Pin Header, 2.0mm, 4x2
8
J11
USB0&1
Box Header, 2.54mm, 5x2
10
J12
USB2&3
Box Header, 2.54mm, 5x2
10
J13
GPIO (Port6/7)
Box Header, 2.54mm, 10x2
20
J15
Reset
Pin Header, 2.54mm, 1x2
2
J17
COM1(RS232/485 or optional TTL/P4)
D-Sub Male
9
J18
COM2(RS232/485 or optional TTL/P5)
Box Header, 2.54mm, 5x2
10
J20
COM5(RS232/485 or optional TTL/P0)
Box Header, 2.54mm, 5x2
10
J22
COM6(RS232/485 or optional TTL/P1)
Box Header, 2.54mm, 5x2
10
J24A
PC104 Connector –64 pins
Box Header, 2.54mm, 32x2
64
J24B
PC104 Connector –40 pins
Box Header, 2.54mm, 20x2
40
J28
Line-Out
Wafer, 1.25mm, 4x1
4
J29
MIC-In
Wafer, 1.25mm, 4x1
4
J30
Touch screen Controller
(Optional)
Wafer, 1.25mm, 4x1
4
J31
Print
Box Header, 2.0mm, 13x2
26
J34
Master/Slave for CF Card
Slide switch
3
CF1
CF card slot
SP1
Buzzer

VDX3-6724 User Manual
ICOP Technology Inc. 14
2.4 Pin Assignments & Jumper Settings
J1: LCD
Pin#
Single Name
Pin #
Single Name
1
+3.3V
2
+3.3V
3
LG2
4
LG3
5
LG4
6
LG5
7
NC
8
NC
9
LR0
10
LR1
11
LR2
12
LR3
13
LR4
14
LR5
15
GND
16
NC
17
NC
18
NC
19
NC
20
GND
21
NC
22
NC
23
LB0
24
LB1
25
LB2
26
LB3
27
LB4
28
LB5
29
NC
30
NC
31
LG0
32
LG1
33
GND
34
GND
35
NC
36
LCLK
37
NC
38
LDE
39
NC
40
LHSYNC
41
NC
42
LVSYNC
43
LBACKL
44
LVDDEN
(Please refer to Appendix for TFT Flat Panel Data Output)

VDX3-6724 User Manual
ICOP Technology Inc. 15
J2: VGA
Pin#
Single Name
Pin #
Single Name
1.
R OUT
2
G OUT
3
B OUT
4
NC
5
GND
6
GND
7
GND
8
GND
9
NC
10
GND
11
NC
12
DDCDAT
13
HSYNC
14
VSYNC
15
DDCCLK
J3: LVDS (24-bit Support Only)
J4: SATA DOM
Pin#
Single Name
Pin #
Single Name
1
VCC3 (+3.3V)
2
VCC3 (+3.3V)
3
GND
4
GND
5
RxIN0+
6
RxIN0-
7
RxIN1-
8
GND
9
GND
10
RxIN1+
11
RxIN2+
12
RxIN2-
13
CKIN-
14
GND
15
GND
16
CKIN+
17
RxIN3-
18
GND
19
GND
20
GxIN3+
Pin#
Single Name
Pin #
Single Name
1
GND
2
TX+
3
TX-
4
GND
5
RX-
6
RX+
7
GND

VDX3-6724 User Manual
ICOP Technology Inc. 16
J5: Power Connector (Terminal Block 5.0mm)
J6: SATA DOM POWER
J8: PS/2 KEYBOARD/MOUSE
J9: LAN1 (RJ45)
J10: LAN2
Pin#
Single Name
1
+5V
2
GND
Pin#
Single Name
Pin #
Single Name
1
VCC
2
GND
Pin#
Single Name
Pin #
Single Name
1
KBCLK
2
MSCLK
3
GND
4
KBDAT
5
MSDAT
6
VCC
7
GGND
8
GGND
9
GGND
Pin#
Single Name
Pin #
Single Name
1
ATX+
2
ATX-
3
ARX+
4
LED0
5
LED0+
6
ARX-
7
LED1+
8
LED1
Pin#
Single Name
Pin #
Single Name
1
ATX+
2
ATX-
3
ARX+
4
LED0
5
LED0+
6
ARX-
7
LED1+
8
LED1

VDX3-6724 User Manual
ICOP Technology Inc. 17
J11: USB0&1
Pin#
Single Name
Pin #
Single Name
1.
VCC
2
VCC
3
LUSBD0-
4
LUSBD0-
5
LUSBD0+
6
LUSBD1+
7
GND
8
GND
9
GGND
10
GGND
J12: USB2&3
Pin#
Single Name
Pin #
Single Name
1.
VCC
2
VCC
3
LUSBD2-
4
LUSBD3-/LUSBD4-
5
LUSBD2+
6
LUSBD3+/LUSBD4+
7
GND
8
GND
9
GGND
10
GGND
*USB3 will be replaced by USB4 when DOS USB Hot Swap function is enabled
(Optional)
J13: GPIO (Port 6/7)
Pin#
Single Name
Pin #
Single Name
1.
GND
2
VCC
3
GP60/SDA_D2
4
GP70
5
GP61/SDA_D3
6
GP71
7
GP62/SDA_CMD
8
GP72
9
GP63/SDA_CLK
10
GP73
11
GP64/SDA_D0
12
GP74
13
GP65/SDA_D1
14
GP75
15
GP66/SDA_CD
16
GP76
17
GP67/SDA_WP
18
GP77
19
VCC
20
GND
*When onboard eMMC is enabled, GPIO will be disabled.
**Not available on VDX3-6724-CF

VDX3-6724 User Manual
ICOP Technology Inc. 18
J15: RESET
Pin#
Single Name
Pin #
Single Name
1.
RST_SW
2
GND
J17: COM1 RS232/485 D-Sub 9 pin (Optional: TTL/ GPIO-P4)
Pin#
Single Name
Pin #
Single Name
1.
DCD1/1RS485-
2
RXD1/1RS485+
3
TXD1
4
DTR1
5
GND
6
DSR1
7
RTS1
8
CTS1
9
RI1
10
NC
J18: COM2 RS232/485 (Optional: TTL/ GPIO-P5)
Pin#
Single Name
Pin #
Single Name
1.
DCD2/2RS485-
2
RXD2/2RS485+
3
TXD2
4
DTR2
5
GND
6
DSR2
7
RTS2
8
CTS2
9
RI2
10
NC
J20: COM5 RS232 (Optional: TTL/ GPIO-P0)
Pin#
Single Name
Pin #
Single Name
1.
DCD5
2
RXD5
3
TXD5
4
DTR5
5
GND
6
DSR5
7
RTS5
8
CTS5
9
RI5
10
NC

VDX3-6724 User Manual
ICOP Technology Inc. 19
J22: COM6 RS232 (Optional: TTL/ GPIO-P1)
Pin#
Single Name
Pin #
Single Name
1.
DCD6
2
RXD6
3
TXD6
4
DTR6
5
GND
6
DSR6
7
RTS6
8
CTS6
9
RI6
10
NC
