ICP Electronics LCD-Kit03 User manual

LCD-Kit03
640x480 – 18bits
LTM10C209A LCD Display
©Copyright 1999 by ICP Electronics Inc. All Rights Reserved.
Manual first edition May01, 1999.
The information in this document is subject to change without prior
notice in order to improve reliability, design and function and does not
represent a commitment on the part of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special,
incidental, or consequential damages arising out of the use or
inability to use the product or documentation, even if advised of the
possibility of such damages.
This document contains proprietary information protected by
copyright. All rights are reserved. No part of this manual may be
reproduced by any mechanical, electronic, or other means in any
form without prior written permission of the manufacturer.

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 1
Contents
1. Introduction.................................................................................2
1.1 Specifications...........................................................................................3
1.2 What You Have.........................................................................................4
2. Installation..................................................................................5
2.1 LCD-03 Connection Board Layout.......................................................5
2.2 LCD-Kit03 Connection Layout...............................................................6
2.3 Unpacking Precautions………………………………………………..7
2.4 Backlight Inverter Control.......................................................................8
3. LCD-Kit03 Connectors.............................................................9
3.1 LCD Connector........................................................................................9
3.2 Backlight Connector..............................................................................10
3.3 Touch Panel Power Connector...........................................................11
3.4 Brightness Setting Connector… .........................................................11
4. Voltage and BIOS Setting......................................................12
4.1 BIOS Setting for SBCs with C&T 65555 Chipset.............................13
4.2 BIOS Setting for SBCs with HM86508 Chipset................................14

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 2
1
Introduction
Welcome to the LCD-Kit03 – LTM10C209A. The LCD-Kit03 is high
brightness and long life TFT LCD panel with 640 x 480 resolution
and 18-bits display colors. It is made for the system
manufacturers, integrators, or VARs that want to provide all the
performance, reliability, and quality at a reasonable price.
The LCD-Kit03 is designed with High Luminance, clear 256k-colors
and Low Reflection to present a High Image Quality. With its thin
and light weight plus compact size (10.4”), LCD-Kit03 is also the
most suitable solution for FA/OA Equipment, Display Terminals,
Measuring Instrument and Industrial portable Workstation .
The LCD-Kit03 comes with specifically designed mounting kit for
fast installation. It is also Plug and Play, can be directly and easily
connected to JUKI, NOVA, POS,… series main boards and also
PLC-655, PLC-508 LCD control card without any additional parts
needed.

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 3
1.1 Specifications :
Supply Voltage : +5V
Panel Size : 10.4” Diagonal
Display Active Area Size: 211.2mm x 158.4mm
Viewing Area : 215.2mm x 162.4mm
Display Colors : 256k Colors by the combinations of 18 bits data
Number of Pixels : 640 (W) x 480 (H)
Brightness : 250 cd/m2
Pixel Format : 1 pixel = R + G + B dots
Pixel Arrangement : R, G, B Vertical Strip
Pixel Pitch : 0.33mm (H) x 0.33mm (V)
Viewing Direction : 6 o’clock (in direction of max. contrast)
Viewing Angle : +/- 50o(H), -10o~ +30o(V)
Contrast Ratio : > 100 : 1
Outline Dimensions : 265.0mm (W) x 188.8mm (H) x 12.0mm (D)
Surface Treatment : Anti-glare and Hard Coat 3H
Backlight: Twin cold-cathode fluorescent lamps for sidelighting
Operating Temperature : 0~50oC
LCD MTBF : 50,000 hours
Backlight MTBF : 20,000 hours (min)

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 4
1.2 What You Have
In addition to this User's Manual, the LCD-Kit03 package includes
the following items:
•one LTM10C209A 10.4” LCD Panel with its mounting kit
•one 70cm 44-pin LCD connection cable
•one BIOS Utility Diskette
If any of these items is missing or damaged, contact the dealer from
whom you purchased the product. Save the shipping materials and
carton in case you want to ship or store the product in the future.

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 5
2
Installation
This chapter describes how to install the LCD-Kit03. The layout of
LCD-03 Connection Board is shown on the next pages and the
Unpacking Precautions that you should be careful with are
described on the following page. Also included is the jumpers and
connectors description for this LCD-Kit03.
2.1 LCD-03 Connection Board Layout

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 6
2.2 LCD-Kit03 Connection Layout
Note :
¬LCD-03 Connection Board
-31-pin connection cable, connecting CN5 and LCD Display
®Brightness VR, connected to CN6
¯Backlight Inverter cable, connecting CN2 and Backlight Inv.
°70cm 44-pin LCD connection cable
±Backlight Inverter
²Backlight Inverter ON/OFF Switch, connected to CN4
To CPU Display Card
<Display Signal>
To LCD Panel Backlight
To LCD Display
LCD-03 1
2
3
5
6
4
LCD-03
7

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 7
2.3 Unpacking Precautions
üSome components on LCD-Kit03 are very sensitive to static electric
charges and can be damaged by a sudden rush of power. Ground
yourself to remove any static charge before touching your LCD-
Kit03 . You can do it by using a grounded wrist strap at all times or
by frequently touching any conducting materials that is connected
to the ground.
üDo not touch the inner side of LCD panel and the connector/cable of
fluorescent lamp/backlight when the power is on. The inverter
supplies HIGH VOLTAGE to these parts (~ 550Vrms).
üDisconnect power supply before handling and doing connection on
LCD-Kit03. Do not plug any connector or jumper while the power is
on. It will cause fatal damage to your LCD panel.
üMake sure that every connector is connected in correct direction.
Any incorrect connection may cause smoke or burn of electrical
parts or fatal damage of your LCD panel.
üBe careful with the liquid crystal material. Do not swallow, inhale or
have skin contact with this material in case that the LCD panel is
broken and the liquid flow out. If you inhale the liquid material, rinse
your mouth immediately with water then go to see a doctor. If you
have skin contact with the liquid, wash it immediately with alcohol.
Be careful, too, with the chips of glass if the panel is broken.
üFor outdoor usage, an ultra-violet ray protect-lens is recommended
to apply onto LCD display. It will prevent your LCD from strong sun-
light, scratches, dust and water invasion etc. which can cause
damage to the LCD display.

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 8
2.4 Backlight Inverter Control
•JP1: Backlight Inverter ON/OFF control - jumper
PIN NO. FUNCTION
1-2 USE FPVEE
2-3 USE ENBKL

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 9
3
LCD-Kit03 Connectors
3.1 LCD Connector
•CN1: 22x2 Header/2.0mm LCD Connector
(connect to LCD Control Card)
PIN NO FUNCTION PIN NO FUNCTION
1+12V 2+12V
3GND 4GND
5+5V 6+5V
7FPVEE 8GND
9P0 10 P1
11 P2 12 P3
13 P4 14 P5
15 P6 16 P7
17 P8 18 P9
19 P10 20 P11
21 P12 22 P13
23 P14 24 P15
25 P16 26 P17
27 P18 28 P19
29 P20 30 P21
31 P22 32 P23
33 GND 34 GND
35 SHFCLK 36 FLM
37 M38 LP
39 GND 40 ENBKL
41 GND 42 NC
43 +5V 44 +5V

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 10
•CN5: LCD OUTPUT (Hirose DF9-31P-1V) Connector
(connect to Panel Display)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1GND 2SHFCLK
3GND 4P18
5P19 6P20
7GND 8P21
9P22 10 P23
11 GND 12 P10
13 P11 14 P12
15 GND 16 P13
17 P14 18 P15
19 GND 20 M
21 GND 22 P2
23 P3 24 P4
25 GND 26 P5
27 P6 28 P7
29 GND 30 +5V
31 +5V
3.2 Backlight Connector
•CN2: Backlight Inverter Connector
PIN NO. DESCRIPTION
1Vin
2ON/OFF
3GND
4VR
•CN4: JST-2Pin/2.5mm Backlight Inverter ON/OFF Switch
PIN NO. DESCRIPTION
1+12V

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 11
2To CN2 pin1
1-2 ON : Backlight Inverter ON
1-2 OFF : Backlight Inverter OFF
3.3 Touch Panel Power Connector
•CN3: Touch Panel Power Connector
PIN NO. DESCRIPTION
1+12V
2GND
3GND
4+5V
3.4Brightness Setting Connector
•CN6: Brightness VR Connector
PIN NO. DESCRIPTION
1Series Resistor to VCC
2VR
3GND
Note: Pin1 is reserved for potentiometer

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 12
4
Voltage and BIOS Setting
After all jumpers and connectors have been set and connected
correctly, the next step is to set the Voltage and BIOS of the LCD-
Kit03. These settings are done on your SBC.
Voltage Setting
The Supply Voltage for LCD-Kit03 is +5V. You must set the LCD
Voltage Setting Jumper on your SBC to +5V. Please, refer to SBC
User Manual of your SBC or refer to the following tables.
BIOS Setting
For SBCs with C&T 65555 LCD/CRT Interface Chipset, the setting
can be done simply in CMOS Setup. For SBCs with HM86508
LCD/CRT Interface Chipset, the BIOS setting must be done by
upgrading the VGA BIOS using the BIOS file in the attached disk.
Please, refer to the following tables for more detail information.
Note: To do the above settings, you must have one VGA monitor
connected to your SBC because your LCD-Kit03 may not work
correctly or even does not show anything before the Voltage and
BIOS settings are correct.

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 13
4.1 BIOS Setting for SBCs with C&T 65555 Chipset
BIOSSetup LCD Volt. Setting
JUKI-710 Standard CMOS Setup: JP9: 2-3 > ON
LCD&CRT: Auto or Both 5-6 > ON
Panel & P.M.U. Setup:
Panel Type:
6 :640x480 18Bit TFT Color
JUKI-740E Peripheral Setup: JP39: 2-3 > ON
LCD&CRT Selection : Auto or Both
LCD Type :
#6 640x480 18bit
JUKI-745E Peripheral Setup: JP39: 2-3 > ON
LCD CRT Selection: Auto or Both
LCD Type :
#6 640x480 18bit
NOVA-600 Peripheral Setup: JP10: 2-3 > ON
LCD CRT Selection: Auto or Both
LCD Type :
#6 640x480 18bit
POS-566 Peripheral Setup: JP23: 2-3 > ON
LCD CRT Selection: Auto or Both
LCD Type :
#6 640x480 18bit
LCD-Kit03

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 14
4.2 BIOS Setting for SBCs with HM86508 Chipset
BIOS Setup LCD Volt. Setting
JUKI-730
use
flash634 j730lcd3.rom
to upgrade bios
No volt. Setting
(ALi6117) (5V only)
JUKI-732E
use
flash634 j732lcd3.rom
to upgrade bios
No volt. Setting
(ALi6117) (5V only)
JUKI-750E
use
flash631j750lcd3.rom
to upgrade to bios
No volt. Setting
(ACC Maple) (5V only)
JUKI-752
use
flash631j752lcd3.rom
to upgrade bios
No volt. Setting
(ACC Maple) (5V only)
PM-1021
use
flash634 1021lcd3.rom
to upgrade bios
No volt. Setting
(ALi6117) (5V only)
NOVA-300
use
flash634 n300lcd3.rom
to upgrade bios
No volt. Setting
(ALi6117) (5V only)
WAFER-4823
use
flash631 4823lcd3.rom
to upgrade bios
No volt. Setting
(ACC Maple) (5V only)
LCD-Kit03

LCD-Kit03 640 x 480 / 18 bits
LTM10C209A 15
Note : to upgrade the BIOS, under DOS prompt insert the attached
disk then type the bold letter command of the middle column then
follow the instruction on your monitor.
Example: for NOVA-300 SBC, under DOS prompt type:
A:\ flash634 n300lcd3.rom or
C:\ flash634 n300lcd3.rom if you have copied the files
flash634.com and n300lcd3.rom to your hard-disk.
