ICS LT 80 User manual

I.C.S
INDUSTRIA COSTRUZIONI STAMPI S.P.A.
VIA MAURA PONTI (PROL. X LODI)
27010 COPIANO (PAVIA)
ITALIA
EDITION OF del 13/04/2015
ASSEMBLY MANUAL, USE
AND MAINTENANCE
USO E MANUTENZIONE
BIN WITH WHEELS FOR
RECYCLING LT 80 -120 -240

Assembly manual,use and maintenance Page 2
INDEX : 0 INTRODUCTION
0.1 Generality
0.2 Purpose
0.3 Normative References
1TECHINCAL DATA
1.1 Part list
1.2 Table of Components and weights
1.3 Dimensions
2 ASSEMBLY DIAGRAM
2.1 Prescription for assembly
2.2 Assembly instruction
3 CLEANING
3.1 Precautions Cleaning
4 ORDINARY MAINTENANCE
4.1 Accidental Event
4.2 Operation of extraordinary maintenance
5 PACKAGING AND DELIVERY BINS
5.1 Packaging Components
5.2 Precautions Packaging
6 DECLARATION OF CONFORMITY
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE AND
MAINTENANCE
EDITION N° 1 OF 13.04.2015
CONTAINER RECYCLING

Assembly manual,use and maintenance Page 3
0.1 GENERALITY
This manual is designed to provide SPECIFICATIONS, THE INSTRUCTIONS ASSEMBLY necessary for
operations of USE, MAINTENANCE, CLEANING and finally DELIVERY to Article produced by ICS SPA
called BIN CABINET WITH WHEELS FOR RECYCLING.
0.2 PURPOUSE
The purpose of the Handbook is primarily to provide the correct information on how to do the Assembly,
maintenance, cleaning and shipping of BIN in full SAFETY. Respecting conformity EU directives applicable
to it.
0.3 NORMATIVE REFERENCES
The normative references applicable to the bin with wheels for recycling are
STANDARD :
UNI EN 840/1 UNI EN 840/5 UNI EN 840/6
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE AND
MAINTENANCE
EDITION N° 1 OF 13.04.2015
CONTAINER RECYCLING
-0 -
INTRODUCTION

Assembly manual,use and maintenance Page 4
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 1 OF 13.04.2015
CONTAINER RECYCLING
- 1 -
TECHNICAL DATA
1GENERAL FEATURES
The article, BIN CABINET WITH WHEELS FOR RECYCLING produced by ICS SPA factory in Copiano
(Pavia), is a mobile container with plastic wheels, for the separate collection of materials recovered for
recycling, and waste disposal . The different colors (RED, YELLOW, GREEN, BLUE, BROWN, GREY)
help the differentiation of waste and proper disposal. Featuring Special rubbers cushioning on the lid,
allowing it to absorb the impact of the closure reducing noise after disposal of the waste. (patented) for the
rejection. (patented) Not only in sealing, the container is equipped with cushioning system of opening of
the cover, to eliminate noise in the early stages of recovery of municipal, but also during the complete
manual openings of the lid, avoiding that the same, slam violently against the body of the bin. (patented)
Easy to use and can be moved as Strong wheels with solid rubber tires, secured by axle made of
galvanized steel corrosion. The coupling seat, then the system of attachment of the wheels to the shaft
galvanized, has been studied also to minimize the spaces between the wheels and the bin, avoiding that
during transport of the bin, the rolling of the wheels cause excessive noise.
1.1 PART LIST
The article, BIN WITH WHEELS FOR RECYCLING consists of the following components
·1 BIN BODY •2 LID WITH HANDLES
·3 PINS FIXING THE COVER OF THE BIN
·4 CUSHIONING OF RUBBER CLOSING THE LID
·5 CUSHIONING OF RUBBER OPENING THE LID
·6 GALVANIZED STEEL SHAFT, FOR ATTACHING THE WHEELS
·7 WHEELS

Assembly manual,use and maintenance Page 5
1.2 TABLE OF COMPONENTS AND WEIGHTS
BIN LT 80
COMPONENTE Q.TA’MATERIALE PESO
BIN BODY 1
POLIETILENE ALTA’DENSITA
STABILIZZATO UV
4.600 KG.
LID
1
POLIETILENE ALTA’DENSITA
STABILIZZATO UV
0.500KG.
PINS FIXING THE COVER OF THE BIN
2
POLIETILENE ALTA’DENSITA
STABILIZZATO UV
0.028 KG.
GALVANIZED STEEL SHAFT, FOR
ATTACHING THE WHEELS
1 ACCIAO ZINCATO
0.450 KG.
WHEELS 2
CERCHIO IN POLIPROPILENE
ESTERNO IN GOMMA
2.070 KG.

Assembly manual,use and maintenance Page 6
BIN LT 120
COMPONENT PCS MATERIAL WEIGHT
BIN BODY 1
POLYETILENE HIGH DENSITY
UV STABILIZED
5.200 KG.
LID WITH HANDLES
1
POLYETILENE HIGH DENSITY
UV STABILIZED
0.700 KG.
PINS FIXING THE COVER OF THE BIN
2
POLYETILENE HIGH DENSITY
UV STABILIZED
0.028 KG.
CUSCHIONING OF RUBBER CLOSING
THE LID
4
RUBBER
0.005 KG.
CUSCHIONING OF RUBBER OPENING
THE LID
2
RUBBER 0.005 KG.
GALVANIZED STEEL SHAFT, FOR
ATTACHING THE WHEELS
1 GAVANIZED STEEL
0.540 KG.
WHEELS 2
RING IN POLIPROPILENE
EXTERNAL IN RUBBER
2.070 KG.
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 1 OF 13.04.2015
CONTAINER RECYCLING
- 1 -
TECHNICAL DATA

Assembly manual,use and maintenance Page 7
BIN LT 240
COMPONENT PCS MATERIAL WEIGHT
BIN BODY 1
POLYETILENE HIGH DENSITY
UV STABILIZED
8.750 KG.
LID WITH HANDLES
1
POLYETILENE HIGH DENSITY
UV STABILIZED
1.200 KG.
PINS FIXING THE COVER OF THE BIN
2
POLYETILENE HIGH DENSITY
UV STABILIZED
0.028 KG.
CUSCHIONING OF RUBBER CLOSING
THE LID
4
RUBBER
0.005 KG.
CUSCHIONING OF RUBBER OPENING
THE LID
2
RUBBER 0.005 KG.
GALVANIZED STEEL SHAFT, FOR
ATTACHING THE WHEELS
1 GAVANIZED STEEL
0.620 KG.
WHEELS 2
RING IN POLIPROPILENE
EXTERNAL IN RUBBER
2.070 KG.
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 2 OF 13.04.2015
CONTAINER RECYCLING
- 1 -
TECHNICAL DATA

Assembly manual,use and maintenance Page 8
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 2 OF 13.04.2015
CONTAINER RECYCLING
- 1 -
TECHNICAL DATA
1.3 DIMENSION
BIN LT 80
RIF. PICTURE DIM MODEL LT. 80
Dim A mm 920
Dim B mm 860
Dim C mm 430
Dim D mm 500
Dim E mm 445
Dim F mm 295
Dim G mm 450
Dim H mm 200
Empy Mass: kg 5,2 + ( Axles and 2 wheels)
Capacity : LT 80

Assembly manual,use and maintenance Page 9
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE AND
MAINTENANCE
EDITION N° 2 OF 13.04.2015
CONTAINER RECYCLING
- 1 -
TECHNICAL DATA
BIN 120
RIF. PICTURE DIM MODEL LT. 120
Dim A mm 935
Dim B mm 875
Dim C mm 492
Dim D mm 563
Dim E mm 481
Dim F mm 352
Dim G mm 481
Dim H mm 200
Empy Mass: kg 6.7 + ( Axles and 2 wheels)
Capacity : LT 120

Assembly manual,use and maintenance Page 10
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 2 OF 13.04.2015
CONTAINER RECYCLING
- 1 -
TECHNICAL DATA
BIN LT 240
RIF. PICTURE DIM MODEL LT. 240
Dim A mm 1063
Dim B mm 1000
Dim C mm 647
Dim D mm 720
Dim E mm 580
Dim F mm 422
Dim G mm 580
Dim H mm 200
Empty Mass: kg 10 + ( Axles and 2 wheels)
Capacity : LT 240

Assembly manual,use and maintenance Page 11
2 ASSEMBLY DIAGRAM
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 2 OF 13.04.2015
CONTAINER RECYCLING
- 2 -
ASSEMBLY
Cushioning Opening
Cushioning
Closure
6
7

Assembly manual,use and maintenance Page 12
2.1 PRESCRICTIONS FOR ASSEMBLY
2.2 ASSEMBLY ISTRUCTIONS
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 2 OF 13.04.2015
CONTAINER RECYCLING
- 2 -
ASSEMBLY
PRESCRICTIONS FOR ASSEMBLING THE BIN
For the assembly the bin, there is not need to use any tool that may create dangerous
situations, and does not require any type of special training for the assembly.
NB: Make sure that all components are in perfect condition and state of preservation,
so that cracks or deformation affecting the perfect operation of the product. In case
you have abnormal contact your dealer.
FASI ASSEMBLY INSTRUCTION FOR THE BIN
1° Insert the Rubber (Comp. 6) in 4 locations round of the lid
2° Insert the Ring (Comp. 7) in the 2 oval sites of the Bin Body
3° Place the lid (Comp. 2) on the bin, so that the holes [I] and [III] are aligned
on the same wheelbase.
4° Take 2 pins fixing for the lid (Comp. 4), with the steel attachment facing
down, insert them into the holes [I] and [III] previously aligned, and push
them up to perfect coupling on the handle of the bin.
5° Insert the shaft (Comp. 3) into the holes [II] of the bin
6° Take the wheels (Comp. 5) and hook them until at the click of fixing on the
shaft

Assembly manual,use and maintenance Page 13
3 CLEANING
The bin with wheels produced by ICS SPA, has been specially designed with rounded to facilitate
cleaning and prevent build up of dirt. The cleaning of the bin, in each component, can be performed
with water or industrial detergents or common little aggressive.
It 'not recommended to use aggressive solvents that could compromise the stability of the material and
consequently the resistance.
3.1 PRECAUTIONS FOR CLEANING
In case of use of industrial cleaners, wear protective gloves, and if the cleaner so requires, wear a face
mask, especially for cleaning the inside of the bin preventing inhaling the fumes created in the bin. In
the case of completely filling with liquid for cleaning, be careful during movement, as they can be
dangerous and cause a full load during the transport with danger in case of tipping, for the limbs, feet,
hands, etc..
.
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 2 OF 13.04.2015
CONTAINER RECYCLING
- 3 -
CLEANING

Assembly manual,use and maintenance Page 14
4 ORDINARY MAINTENANCE
The BIN FOR RECYCLING, does not require any scheduled maintenance except cleaning.
4.1 ACCIDENTAL EVENT
In case of a fall, shock or incorrect use, it is recommended to check the perfect anchor pin fixing lid to
the bin and wheels to the axle.
4.2 OPERATION OF EXTRAORDINARY MAINTENANCE
In case of accidental release even partial, is invited to reassemble if not damaged, according to the assembly
sequence described in Chapter 2 of this instruction manual.
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 2 OF 13.04.2015
CONTAINER RECYCLING
- 4 -
MAINTENANCE

Assembly manual,use and maintenance Page 15
5 PACKAGING AND DELIVERY
The bins have been designed to optimize the transport during expeditions and promote the storage
warehouse. The model LT 120, has been patented for what concerns the stacking of a bin inside the other. A
system to meet the needs of the market and storage because, by inserting the bins in row one after the other
by turning them 90 °, are obtained files to be placed on pallets common measurement, thus allowing to protect
them in shipping and storage, reducing the breakage of the covers during transport, because they remain
protected in the perimeter of the pallet and packaging. (See table below)
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 2 OF 13.04.2015
CONTAINER RECYCLING
- 5 -
PACKAGING AND
DELIVERY
Lt
240
11
PS FO
R ROW
Lt 120
10 PCS
4 ROWS FOR A TOTAL OF 40 PCS
Lt 120
12
PS FOR ROW
PALLET DIMENSION 100 X 120
WITHOUT PALLET
FIRST BIN WITH AXLE AND WHEELS

Assembly manual,use and maintenance Page 16
5.1 Packaging Components
COMPONENT TYPE OF PACKAGING QUANTITY
LID FOR BIN 120 LT PALBOX 100 PCS
LID FOR BIN 240 LT PALBOX 60 PCS
AXLES BIN LT 120 SINGLE PACK 10 PCS 1.520 PCS
ASSALI BIDONI LT 240 SINGLE PACK 10 PCS 1.000 PCS
WHEELS FOR BIN PALLET 850 PCS
5.2 Precautions Packaging
The bins are designed to be resistant to extreme use, provided that you respect certain parameters specified
in the data sheet of the bin (available from the Manufacturer).
With regard to shipping operations, the only precaution is to check that the lids during loading, they are not
compressed or deformed. If it is dispatched on a pallet, it is important to verify that the pallets are to lean and
not the file bins avoiding possible distortion of the lids.
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 1 OF 01.010.2010
CONTAINER RECYCLING
- 5 -
PACKAGING AND
DELIVERY

Assembly manual,use and maintenance Page 17
I.C.S. INDUSTRIA COSTRUZIONI STAMPI SPA
Via Maura Ponti (Prol. X Lodi)
27010 Copiano Pavia
ASSEMBLY MANUAL, USE
AND MAINTENANCE
EDITION N° 1 OF 01.010.2010
CONTAINER RECYCLING
- 6 -
DECLARATION OF
CONFORMITY

Assembly manual,use and maintenance Page 18
