Icy Box IB-TH100-DK User manual

Manual IB-TH100-DK
Swivel stand for tablet and smartphone with
USB Type-C®DockingStation
Handbuch IB-TH100-DK
Drehbarer Ständer für Tablet und Smartphone
mit USB Type-C®DockingStation

Manual IB-TH100-DK
Please read carefully the following information to prevent injuries, da-
mage to material and device as well as data loss:
Warning levels
Signal words and safety codes indicate the warning level and provide immediate
information in terms of the probability of occurrence as well as the type and severity
of the consequences if the measures to prevent hazards are not complied with.
Warns of a directly hazardous situation causing
death or serious injury.
Warns of a potentially hazardous situation that may
cause death or serious injury.
Warns of a potentially hazardous situation that may
cause minor injury.
Warns of a potential situation that may cause ma-
terial or environmental damage and disrupt operative
processes.
1. Risk of electrical shock
Contact with parts conducting electricity
Risk of death by electrical shock
• Read the operating instructions prior to use
• Make sure the device has been de-energised prior to working on it
• Do not remove contact protection panels
• Avoid contact with conducting parts
• Do not bring plug contacts in contact with pointed and metal objects
• Use in intended environments only
• Operate the device using a power unit meeting the specifications of the type plate
only!
• Keep the device/power unit away from humidity, liquid, vapour and dust
• Do not modify the device
• Do not connect the device during thunderstorms
• Approach specialist retailers if you require repairs
2. Hazards during assembly (if intended)
Sharp components
Potential injuries to fingers or hands during assembly (if
intended)
• Read the operating instructions prior to assembly
• Avoid coming into contact with sharp edges or pointed components
• Do not force components together
• Use suitable tools
• Use potentially enclosed accessories and tools only
3. Hazards caused by a development of heat
Insufficient device/power unit ventilation
Overheating and failure of the device/power unit
• Prevent externally heating up components and ensure an exchange of air
• Do not cover the fan outlet and passive cooling elements
DANGER
WARNING
CAUTION
IMPORTANT
WARNING
CAUTION
IMPORTANT

Manual IB-TH100-DK
• Avoid direct sunlight on the device/power unit
• Guarantee sufficient ambient air for the device/power unit
• Do not place objects on the device/power unit
4. Hazards caused by very small parts and packaging
Risk of suffocation
Risk of death by suffocation or swallowing
• Keep small parts and accessories away from children
• Store/dispose of plastic bags and packaging in an area that is inaccessible to
children
• Do not hand over small parts and packaging to children
5. Potential data loss
Data lost during commissioning
Potentially irreversible data loss
• Always comply with the information in the operating instructions/quick installation
guide
• Exclusively use the product once the specifications have been met
• Back up data prior to commissioning
• Back up data prior to connecting new hardware
• Use accessories enclosed with the product
6. Cleaning the device
Harmful cleaning agents
Scratches, discolouration, damage caused by moisture
or short circuit in the device
• Disconnect the device prior to cleaning
• Aggressive or intense cleaning agents and solvents are unsuitable
• Make sure there is no residual moisture after cleaning
• We recommend cleaning devices using a dry, anti-static cloth
7. Disposing of the device
Environmental pollution, unsuitable for recycling
Potential environmental pollution caused by
components, recycling circle interrupted
This icon on product and packaging indicates that this product must
not be disposed of as part of domestic waste. In compliance with the
Waste Electrical and Electronic Equipment Directive (WEEE) this elec-
trical device and potentially included batteries must not be disposed
of in conventional, domestic waste or recycling waste. If you would
like to dispose of this product and potentially included batteries, please
return it to the retailer or your local waste disposal and recycling point.
If you have any questions, please do not hesitate to contact our support at
[email protected] or visit our website at www.icybox.de.
WARNING
IMPORTANT
IMPORTANT
IMPORTANT

Handbuch IB-TH100-DK
Zur Vermeidung körperlicher Schäden, sowie von Sach-, Geräteschäden
und Datenverlust beachten Sie bitte folgende Hinweise:
Warnstufen
Signalwort und Sicherheitszeichen kennzeichnen die Warnstufe und geben einen
sofortigen Hinweis auf Wahrscheinlichkeit, Art und Schwere der Folgen, wenn die
Maßnahmen zur Vermeidung der Gefahr nicht befolgt werden.
warnt vor einer unmittelbar gefährlichen Situation, die
zum Tod oder zu schweren Verletzungen führen wird.
warnt vor einer möglicherweise gefährlichen
Situation, die zum Tod oder zu schweren Verletzungen
führen kann.
warnt vor einer möglicherweise gefährlichen Situati-
on, die zu leichten Verletzungen führen kann.
warnt vor einer möglichen Situation, die zu Sach- und
Umweltschäden führen und den Betriebsablauf stören
kann.
1. Gefahren durch elektrische Spannung
Kontakt mit elektrisch leitenden Teilen
Lebensgefahr durch Stromschlag
• vor Benutzung Betriebsanleitung lesen
• vor Arbeiten am Gerät, Spannungsfreiheit sicherstellen
• Kontaktschutzblenden nicht entfernen
• Kontakt mit Spannungsführenden Komponenten vermeiden.
• Steckkontakte nicht mit spitzen und metallischen Gegenständen berühren
• Verwendung nur in dafür vorgesehenen Umgebungen
• Gerät ausschließlich mit Typenschildkonformen Netzteil betreiben!
• Gerät/Netzteil fern von Feuchtigkeit, Flüssigkeit, Dampf und Staub halten
• Eigenständige Modifikationen sind unzulässig
• Gerät nicht während eines Gewitters anschließen
• Geben Sie Ihr Gerät im Reparaturfall in den Fachhandel
2. Gefahren während Montage (wenn vorgesehen)
Scharfkantige Bauteile
Finger- oder Handverletzungen bei Zusammenbau
(wenn vorgesehen) möglich
• vor Montage, Betriebsanleitung lesen
• Kontakt mit scharfen Kanten oder spitzen Bauteilen vermeiden
• Bauteile nicht mit Gewalt zusammensetzen
• geeignetes Werkzeug verwenden
• nur gegebenenfalls mitgeliefertes Zubehör und Werkzeug verwenden
3. Gefahren durch Wärmeentwicklung
Mangelhafte Belüftung des Geräts/Netzteils
Überhitzung und Ausfall des Geräts/Netzteils
• externe Erwärmung vermeiden und Luftaustausch zulassen
• Lüfter-Auslass und passive Kühlkörper freihalten
GEFAHR
WARNUNG
VORSICHT
ACHTUNG
WARNUNG
VORSICHT
ACHTUNG

Handbuch IB-TH100-DK
• direkte Sonneneinstrahlung auf Gerät/Netzteil vermeiden
• ausreichend Umgebungsluft für Gerät/Netzteil sicherstellen
• keine Gegenstände auf dem Gerät/Netzteil abstellen
4. Gefahren durch Kleinstteile und Verpackung
Erstickungsgefahr
Lebensgefahr durch Ersticken oder Verschlucken
• Kleinteile, Zubehör für Kinder unzugänglich verwahren
• Plastiktüten und Verpackung für Kinder unzugänglich verwahren/entsorgen
• Kleinteile und Verpackungen nicht in Kinderhände geben
5. Möglicher Datenverlust
Datenverlust bei Inbetriebnahme
Unwiederbringlicher Datenverlust möglich
• Unbedingt Hinweise in der Bedienungsanleitung/Schnellinstallationsanleitung
beachten
• Produkt nur verwenden, wenn Spezifikationen erfüllt sind
• Datensicherung vor Inbetriebnahme durchführen
• Datensicherung vor Anschluss neuer Hardware durchführen
• dem Produkt beiliegendes Zubehör verwenden
6. Reinigung des Gerätes
Schädigende Reinigungsmittel
Kratzer, Farbveränderungen, Feuchteschäden oder
Kurzschluss am Gerät
• vor Reinigung, das Gerät außer Betrieb nehmen
• aggressive bzw. scharfe Reinigungs- und Lösungsmittel sind ungeeignet
• nach der Reinigung sicherstellen, dass keine Restfeuchtigkeit vorhanden ist
• Reinigung der Geräte am besten mit trockenem Antistatiktuch durchführen
7. Entsorgung des Gerätes
Umweltverschmutzung, Wiederverwertung nicht möglich
Mögliche Umweltbelastung durch Bestandteile,
Recyclingkreislauf unterbrochen
Dieses auf dem Produkt und der Verpackung angebrachte Symbol
zeigt an, dass dieses Produkt nicht mit dem Hausmüll entsorgt werden
darf. In Übereinstimmung mit der Richtlinie über Elektro- und Elekt-
ronik-Altgeräte (WEEE) darf dieses Elektrogerät und ggf. enthaltene
Batterien nicht im normalen Hausmüll oder dem Gelben Sack ent-
sorgt werden. Wenn Sie dieses Produkt und ggf. enthaltene Batterien
entsorgen möchten, bringen Sie diese bitte zur Verkaufsstelle zurück
oder zum Recycling-Sammelpunkt Ihrer Gemeinde.
Bei Fragen kontaktieren Sie gerne unseren Support unter [email protected]
oder besuchen Sie unsere Internetseite www.icybox.de.
WARNUNG
ACHTUNG
ACHTUNG
ACHTUNG

Manual IB-TH100-DK
Package content
1x IB-TH100-DK, 1x manual
View
1. USB Type- C®PD 3.0 interface with Power Delivery support up to 100 watts
(no data transfer)
2. HDMI®2.0 interface with up to 3840x2160@60 Hz
3. USB 3.2 Gen 1 Type-C®interface, data transfer rates of up to 5 Gbit/s and
5 V/0.9 A charging support
4. USB 3.2 Gen 1 Type-C®host computer interface
5. Tablet/smartphone support
1 2 3
4
5

Manual IB-TH100-DK
6. 2x USB 3.2 Gen 1 Type-A interface, data transfer rates of up to 5 Gbit/s
and 5 V/0.9 A charging support
7. 3.5 mm headset combo jack
8. SD 3.0 card reader, data transfer rates of up to 100 MB/s
microSD 3.0 card reader, data transfer rates of up to 100 MB/s
6 7
8

Manual IB-TH100-DK
Requirements
Stand:
• Smartphone or tablet with max 11“
Dock:
• Android, iOS®, Windows®, macOS®, Chrome OS™
• USB Type-C®enabled host device
• DisplayPort™Alt Mode and Power Delivery support required!
• No power supply included (only necessary for Power Delivery)
USB Type-C®
Not all USB Type-C®host ports support the full functionality of the USB Type-C®
standard. Some ports might only provide data transfer without supporting Power
Delivery over USB.
To use this dock to its full potential, ensure that the USB Type-C®host port of your
computer supports DP Alt Mode, USB Power Delivery, Thunderbolt™3 / 4 or
USB4®.
USB Type-C™≠USB Type-C™
Important!
This ICY BOX product requires the usage of DisplayPort™ Alt Mode
technology over the USB Type-C™ connector. Not all computers,
notebooks or tablets with a USB Type-C™ interface support the
DisplayPort™ Alt Mode.
Please check the specifications of your computer system as
well as its USB Type-C™ interface or use the ICY BOX product with a
Thunderbolt™ 3 connector.
Computer
manual
DisplayPort™
Alt Mode
USB version information
Legacy USB standards Current USB standards Data transfer rate
USB 3.0 = USB 3.1 (Gen 1) = USB 3.2 Gen 1 = 5 Gbit/s
USB 3.1 = USB 3.1 (Gen 2) = USB 3.2 Gen 2 = 10 Gbit/s
USB 3.2 (Gen 2x2) = USB 3.2 Gen 2x2 = 20 Gbit/s
-= USB4 Gen 3x2 = 40 Gbit/s

Manual IB-TH100-DK
Starting up
Stand function:
• Unfold the holder to place a smartphone or tablet on it
Caution: When opening or closing the stand, there is a risk of trapping hands.
Adjust the parts to the desired position carefully.
• Do not move the upper pivot further than the pivot point of the centre axis at
the base so that the tablet holder does not tip over backwards.
Attention!
Pay attention to the distribution of the centre of gravity!!!
• The support should not be tilted too far back or forward so that the placed
unit does not fall down.

Manual IB-TH100-DK
The support should not be tilted too far back or forward so that the placed unit does
not fall down.
Place your smartphone or tablet vertically or horizontally on the support surface.
Note: If larger tablets (10" - 11") are used, lower the angle and height settings if
necessary (to prevent the risk of tipping over).
Tilt: back and forth
Height adjustment:
up and down

Manual IB-TH100-DK
When the docking station cable is not connected, you can now rotate support and
device 360°, clockwise or counterclockwise.
When the docking station cable is connected (see next step), you can perform a
rotation of up to 180°, depending on the device used.

Manual IB-TH100-DK
DockingStation Function
1. Remove the integrated USB Type-C®connection cable located at the bottom
of the stand and pass it through the cut-out in the base to the outside.
2. Connect the USB Type-C®cable to the supported USB Type-C®interface of
your smartphone, tablet or computer.

Manual IB-TH100-DK
3. Connect your peripheral devices to the corresponding interfaces of the dock.
Use of memory card slots
SD card
Insert the SD card into the SD card slot with the bevelled corner first. The golden PINs
of the card must show downwards.
microSD card
Insert the microSD card into the microSD card slot with the bevelled corner first. The
golden PINs of the card must show upwards.
Note: Single-LUN – the card readers can only work with one memory card at a time
Configure a display device
Please set up your display settings according to your operating system and
requirements.
For detailed information refer to the corresponding operation manual and descripti-
on of your operating system.
Note: Video output capabilities are dependent on the video graphics card and
hardware specifications of your connected host computer. Certain video graphics
cards and operating systems have limited MST and DisplayPort™support, while
some monitors will also limit the available resolution.

Manual IB-TH100-DK
Supported video resolutions
Output
Number of displays HDMI®Display 1
Video matrix design (Host PC = Windows Alternate mode systems (HBR2), maximum resoluons
Single video output ✓3840x2160@30 Hz
Video matrix design (Host PC = Windows Alternate mode systems (HBR3), maximum resoluons
Single video output ✓3840x2160@60 Hz Video matrix design (Host PC = Mac* TB4 | USB4®systems (>M1 chip), maximum resoluons Single video output ✓3840x2160@60 Hz
Video matrix design (Host Android™/ iOS® systems, maximum resoluons
Single video output ✓Product related to its maximum resoluon via USB DP Alt Mode
* macOS®based computers only support SST (Single Stream Protocol),
so the video output on the displays are the same. ** DSC (Display Stream Compression) support necessary
Supported video resolutions
The IB-TH100-DK supports 4K resolutions if the connected display and the graphics
unit support it.

Manual IB-TH100-DK
Samsung DeX (Android™) Konfiguration
Note: Screenshots may vary slightly depending on the operating system.
Other smart device manufacturers often offer similar functions (e.g. PIXEL/Google,
Easy Projection/Huawei, etc.).
If this is not the case, the content of the smart device display is usually mirrored to the
connected monitor.
• As soon as a Samsung DeX-enabled smartphone or tablet is connected to
the DockingStation connected to an HDMI®monitor, the Samsung DeX desk-
top opens on the connected monitor (permissions may need to be granted
on the smart device).
• If you have connected a keyboard/mouse to the docking station, you can
now use and operate the contents of the connected smart device as you
would with a desktop computer.

Manual IB-TH100-DK
• It is also possible to use and operate the desktop monitor via an integrated
Samsung DEX touchpad on the smart device display.

Manual IB-TH100-DK
• Now, if necessary, make adjustments in the settings of design, resolution
and other functions according to your needs. Detailed instructions for use
can be found under the menu item - Settings - Samsung DeX --- „How to use
Samsung DeX

Manual IB-TH100-DK
Windows®display configuration
Note: The screenshots might vary slightly with the operating system.
Extended monitor application under MST technology (MultiStreamTrans-
port protocol)
Arrange your displays
Once the extra monitors are connected, they can be configured to either mirror
mode, extended mode or to the setting of the primary display.
e.g: extending your monitors
- Position the mouse anywhere on the Windows®desktop
- Right-click and select Display settings to bring up the configuration window.
- Refer to the Display configuration section
- Identify your monitors by clicking the Identify button.
- Select the relevant monitor for the following settings by clicking the identified
monitor symbol

Manual IB-TH100-DK
- Select Multiple displays > Extend desktop
to this display if you wish to extend a monitor.
- Click Keep changes to confirm and exit.
- Once the setting is completed, simply drag and drop the application icons to
arrange your monitors.
(However, some applications may not support the display on the extended desktop).
1.
2.
3.

Manual IB-TH100-DK
Setting the right resolution and frequency of your displays
There are two possibilities to choose the resolution of the selected monitor:
1. Standard
- Identify your monitors by clicking the Identify button.
- Select the relevant monitor by clicking the identified monitor symbol.
- Click on Display resolution
- Choose the right resolution from the drop-down menu. Refer to the
video matrix table!
- Click Keep changes to confirm and exit.
1.
2.
