OZO DS-01 User manual

DOCKING STATION DS-01
OZO_Docking_Station_125x125_Final.indd 1 03/06/16 13:01

Index
WARNINGS
Operating and Storage Temperature 4
General Warnings 5 - 6
BASICS
Charging Battery 8
Extracting Data 9
WARRANTY AND LEGAL
Warranty 11 - 13
Regulatory and Safety Notices 14
Recycling 15
Box Content
1. Docking Station DS-01, for battery charging and data transfer
2. Docking Station AC power supply and AC cables
3. Media Cable MC-01, for USB3 data transfer to computer directly
from Media Module or cartridge in Docking Station
OZO_Docking_Station_125x125_Final.indd 2 03/06/16 13:01

WARNINGS
OZO_Docking_Station_125x125_Final.indd 3 03/06/16 13:01

Operating and Storage Temperature
Operating Temperature
The device should only be used
between +32°F and +86°F (0°C and
+30°C). Do not use outside this
range.
Storage Temperature
The device should be stored
between -4°F and +122°F (-20°C and
+50°C). Do not store outside this
range.
4
+32°F / +86°F 0°C / +30°C
-4°F / +122°F -20°C / +50°C
OZO_Docking_Station_125x125_Final.indd 4 03/06/16 13:01

General Warnings
HANDLE WITH CARE
Do not drop the device
If the device is dropped, it may be
damaged or modied externally or
internally and become unusable for
the intended purpose.
After dropping, in case of damage or
incorrect operation, please contact
the manufacturer for (non-warranty)
repair.
Battery
Do not insert a fully charged battery
into the charger repeatedly. Due to
the high initial charge, the battery
could be overcharged which could
lead to damage to the battery and to
the battery charger.
Water / humidity
Do not use in or near water. The
device is not waterproof, and may
be damaged if used underwater, in
rain, or in environments with high
moisture or humidity.
Repairs / opening the device
Repairs should be performed only by
qualied service personnel.
Do not attempt to open the device,
as this may cause damage which will
void the warranty.
Power source
Use only the supplied power sources.
Take precautions when handling
power plugs.
5
OZO_Docking_Station_125x125_Final.indd 5 03/06/16 13:01

General Warnings
Do not use with power outlets
or extension cords if they are
overloaded, dusty, wet or physically
damaged.
The socket-outlet shall be installed
near the equipment and shall be
easily accessible.
Cables
Do not use the supplied USB cable to
directly connect two computers, as
this may cause damage.
Do not walk or step on cables.
Do not place heavy objects on
cables.
Do not twist cables.
6
OZO_Docking_Station_125x125_Final.indd 6 03/06/16 13:01

BASICS
OZO_Docking_Station_125x125_Final.indd 7 03/06/16 13:01

Charging Battery
Insert an OZO Digital Cartridge
(A - supplied separately) into the
Docking Station (B).
Ensure a power cable is connected to
the Docking Station.
The LED on the Docking Station
(C) should ash white to indicate
charging is in progress, and show
solid white to indicate when the
Digital Cartridge battery is fully
charged. Charging an empty battery
can take up to 3 hrs.
A Digital Cartridge must be inserted
at least once to the powered Docking
Station before it can be used in the
device.
A red light indicates a problem.
Slow ashing red indicates “No
Battery found”. Solid red indicates
C
B
A
8
“Cannot charge” (broken or
misplaced battery). Fast ashing red
indicates a malfunction.
OZO_Docking_Station_125x125_Final.indd 8 03/06/16 13:01

Extracting Data
Connect the supplied USB cable
from the Docking Station (A) to a
computer with the OZO Creator
application installed. Insert an
OZO Digital Cartridge (B - supplied
separately) with an OZO Media
Module (supplied separately) inside.
Alternatively, connect the supplied
USB cable directly between an
OZO Media Module (C - supplied
separately) and the computer.
9
A
B
C
OZO_Docking_Station_125x125_Final.indd 9 03/06/16 13:01
