Idea-fly F210 User manual

Shenzhen Idea-Fly Technology Co., Ltd
F210 Racing Quadcopter User manual www.idea-y.com
F210 Racing RC Quadcopter
User Manual

Warnings and Safety Notes
Thanks for purchasing F210 quadcopter.Please regularly visit F210 web
page at www.ide-y.com which is updated regularly. product information,
technical updates and manual corrections will be available on this web page.
Due to unforeseen changes or product upgrades, the informationcontained
in the manual is subject to change without notice.
Read this disclaimer carefully before using this product. By using this
product ,you here by agree to this disclaimer and signify that you have ready
them fully. please strictly follow the manual to assemble and use the product.
The manufacturer and seller assume no liability for any resulting damage or
injury arising from the operation or use of this product.
F210 Racing Quadcopter User manual www.idea-y.com
This product is a multi-rotor aircraft which will provide a very good ight
experiencewith the good condition of the power system and all the parts in
good condition. Please contact customer service for the latest instructions
and warnings. Idea-Fly will reserve the rights to update this disclaimer.
General Safety
The quadcopter can be extremely dangerous and cause bodily injury.
Exercise the utmost caution when ying and operating it. It can be dangerous
if you do not y it in a safe manner or do not pay close attention while ying it.
You alone are responsible for its actions during ight.
Before flight, always do a quick motor test to verify that all four
propellers are spinning the correct directions. If you’re not careful,
it’s possible to accidently install the outrigger arms and/or propellers
incorrectly, which can result in the quadcopter not flying correctly and
possibly crashing.
The propellers must be removed from the motors whenever you update the autopilot’s
firmware or whenever there’s any question about safely operating the quadcopter.
• Do not attempt to fly the quadcopter if one or more of the propellers are damaged. Flying with
damaged propellers is not safe and can make the quadcopter fly uncontrollably.
• Always make sure the propellers are installed correctly and that the propeller hub washers
and mounting screws are secured tightly. Never install the propellers without also installing
the propeller hub washers!
01

Tableof Contents
Get to know your aircraft
Get to know your remote controller
Attention before ight
Charging the battery
F210 Racing Quadcopter User manual www.idea-y.com
02
03
04
05
05
Prepare Your Quadcopter 06
Ready for ight
Motor Unlock/Lock
07
07
End of ight 08
Operation Instruction 09
Specications 10

Get to know your aircraft
Premium carbon ber frame： Made of sturdy and durable carbon ber,
the upper board is 1.5mm thick, while the thickness of the arms and the
board beneath them is 3.5mm
F3 10DOF ight controller with barometer and compass, which delivers
you fantastic ight experience
Brilliant 2205 2300KV motors. With imported bearings processed through
CNC and 100% dynamic balance
ABCDE
F
G
H
I
J
K
L
ABattery Cover
BLiPo Battery
CESC
DPropeller(CW)
EScrew For propeller
FPower Connector
GRear Indicator LED
HPropeller(CCW)
IF3 Flight Controller
JPropeller(CW)
KReceiver
LThrottle Value LED
F210 Racing Quadcopter User manual www.idea-y.com
03

Get to know your remote controller
The F210 build-in 3 different ight modes, you can use the
SWB ofthe remote controller to change the ight mode.
SWA
SWB
Stick 1
Up Button
Down Button
Blind Button LCD Screen On/Off
Cancel Button
OK Button
Stick 2
Trim
Trim
Handle bar
Antentan
Stick Mode explain: Flight Mode Switch explain:
SWB
* Select the appropriate stick mode according your ight skills
F210 Racing Quadcopter User manual www.idea-y.com
04
AngleMode
BaroMode
ManualMode

Attention before ight
The F210 mini-quad is recommended for pilots,14 years or
older, with RC hobby experience.
Only y the F210 in dry weather, with low wind, please do
not y in rain or heavy foggy conditions.
Always choose large open elds for ying. Check local LAW
and ordinances for legal ying areas.
Always keep at least 10 feet distance to the aircraft when
armed ,to avoid injury from high-speed propellers on the
ground or while ying. Always disarm before handling the
aircraft.
Charge The Battery
1. Connect the power-cable to the wall-outlet, the E4charger
accept voltage from 110Vto 240V.
2.Select the battery type LiPo by toggle
the battery type switch.
3. Select the suitable charge current by
toggle the current switch, max support 3A.
4. Insert the balance port and power
port to the charger, then the charge
process will start automatic.
5. When the battery is fully charged, the charge
status LED glows constant green.
Explanation of charger led status
LED green blinking
LED glows constant red
LED glows constant orange
LED glows constant green
LED glows constant red
LED flashes red
Charge Status LED
Cell Status LED
The charges is ready to charge.
The charger is charging in CC mode.
The charger is charging in CV mode.
The charging process finishes.
The cell is charging.
The cell is discharging
F210 Racing Quadcopter User manual www.idea-y.com
05

Prepare Your Quadcopter
Heading
ccw
cw
ccw cw
1. Install the propeller
Fix the clockwise propellers
onto the clockwise motors
based on the rotation direction
marked on the motors, then x
the counterclockwise propellers
as the same way. Tighten the
propellers manually and make
sure the propeller is installed
in proper way and fastened.
Install prop by hand and
tighten by holding the motor
with the included wrench.
You can also use the wrench to help remove broken props
in case of crash.
2. Install the battery
First open the battery cover, then
put the battery into the top of the
body and move it forward-
backwards as required for perfect
balance, then rmly secure the
battery with the velcro strap.
Put the battery into
the suitable place
secure the battery with
the velcro strap
1. Make sure the battery installed in a suitable place so
that the quadcopter has a best balance.
2. Please secure the battery with the velcro strap rmly to
prevent battery moving during the ight.
F210 Racing Quadcopter User manual www.idea-y.com
06

Ready for ight
1. Place the aircraft in a wide open space, with the rear facing you.
2. Put all the switch in the remote controller to the UP position,
release all the trim buttons and function buttons, move the throttle
to the lowest position, then turn on the remote controller.
3. If you have a video receive equipment(such as a 7 inch screen,
glass, etc) please turn on the equipment and set the receive channel
to the correct channel, then turn it on.
Motor Unlock/Lock
Motor Unlock
After power on the remote controller and aircraft, the rear
indicator LED will be constant green, that means the ight
controller initialization nished.
Gently push the throttle stick down and move the rudder(YAW)
stick to the right side and hold for more than 2 seconds(On
the mode 2 the throttle and YAW stick is the same stick), you
will see the rear LED becomes constant blue, means the
motors are unlocked. Be very careful at this point, as pushing
the throttle stick will start the motors.
The unlock method shown as below
F210 Racing Quadcopter User manual www.idea-y.com
07

Motor Unlock/Lock
Motor Lock
Lock the motors by moving the throttle stick all the
way down and the rudder(YAW) stick all the way to
the left side and hold for about 2 seconds, the rear
LED will become constant green means that the
motors are locked.
TEST: Push the throttle up a little, the motors will not start.
End of ight
1. Land the aircraft, disarm(lock) the aircraft.
2. First power off the aircraft by unplugging the battery, then
turn off the remote controller.
3. Finally, remove the battery from the aircraft.
F210 Racing Quadcopter User manual www.idea-y.com
08

Operation Instruction
F210 Racing Quadcopter User manual www.idea-y.com
09

Specications
General
Type:Racing Quadcopter
Brand: Ideay
Model: Grasshopper F210
Features: 5.8G FPV,Radio Control
Motor Type: Brushless Motor
Functions: 3D Inverted Flight,3D rollover,Forward/backward,
FPV,Left / Right Hand Throttle Switch,Turn left/right,
Up/down
Max Speed: more than 230km/h
Built-in Gyro: Yes
Material: Carbon Fiber
Connectivity
Remote Control: 2.4GHz Wireless Remote Control
Channel: 10-Channels
Mode: Mode 2 (Left Hand Throttle)
Control Distance: Above 800m
Battery
Battery: 14.8V 1300mAh 45C 4S
Flying Time: 10-13mins
Charging Time (h): about 2.5 hours
Battery Weight: 148g
Camera Video Resolution: 700TVL (horizontal resolution)
Video Standards: PAL
Dimension
and Weight
Product weight: 0.328 kg
Package weight: 0.865 kg
Product size (L x W x H): 20.50 x 20.00 x 8.50 cm / 8.07 x 7.87
x 3.35 inches
Package size (L x W x H): 41.00 x 27.00 x 11.00 cm / 16.14
x10.63 x 4.33 inches
F210 Racing Quadcopter User manual www.idea-y.com
10

Tel:[phone]
User manual is subject to change
without prior notice
Please go to Idea-Fly ofcial website
to get the latest information
