Idea BASSO Series User manual

1
QS_BASSO21t_EN_v3.3
BASSO21t
21˝ High Performance Band-Pass Touring Subwoofer QuickStart Guide
Many key factors are to be considered when conguring the subwoofer section
of a loudspeaker system to perfectly match each application: size/weight,
logistic and operational setups, SPL needs, LF extension, cost limitations, as well
as sound engineer preferences (depending on dierent the type and size of the
event) or audio program characteristics and regional style taste for subwoofer
mixes.
BASSO Series models allow the user to choose the most adequate subwoofer
for any given situation from within a family of products with common nish,
design solutions and performance philosophy as well as shared rigging and
transport accessories.
BASSO21t is a 21˝ subwoofer that has been designed to deliver high SPL levels
and eciency out of a medium format enclosure delivering serious power
density.
The 5th Order Band-Pass design together with the premium-quality European
21˝ woofer deliver serious SPL with maximum impact in the 50 to 100 Hz octave
and the extended sub range of 30 Hz allows for Infra extension application into
any system.
BASSO21t features four integrated handles and two 35 mm pole mount sockets
for vertical and horizontal set-ups. BASSO21t is compatible with optional BASSO
rigging frames for ground-stacked congurations. Optional wheels kit is also
available.
+/- 1 Subwoofer Signal
+/- 2 Parallel Signal
NL-4 PINOUT:
SYSTEM CONFIGURATION AND SETTINGS
RECOMMENDED SETTINGS
BASSO21t back panel is tted with a pair of Neutrik NL-4 connectors in
parallel for straightforward, exible installation setup.
Type Freq Q Gain
Bell 54 Hz 7.0 -2.10
Bell 132 Hz 3.0 -3.30
Low Pass 87 Hz 0.8 --
Bell 42 Hz 3.0 -0.30
HPF: 20 Hz Butterworth 24dB
LPF: 65 Hz Butterworth 24dB
LPF@ 80 Hz
Type Freq Q Gain
Bell 65 Hz 5.3 -4.30
Bell 132 Hz 3.0 -2.00
Low Pass 101 Hz 0.8 --
Bell 50 Hz 3.0 -0.40
HPF: 20 Hz Butterworth 24dB
LPF: 77 Hz Butterworth 24dB
LPF@ 100 Hz
Type Freq Q Gain
Bell 73 Hz 3.4 -4.70
HPF: 20 Hz Butterworth 24dB
LPF: 82 Hz Butterworth 24dB
LPF@ 120 Hz
BASSO21t
INPUT LINK
PRODUCT OF EUROPE
Made in Spain
Designed, engineered
and manufactured by
IDEA in Cedeira (Galicia)
8 Ω
81 kg / 178.5 lbs
1400W RMS
The installation of this product
should be implemented by
qualified professionals
following safe practices and
local regulations.
Refer to the owner's manuals
for rigging instructions,
system components and
suspension hardware intended
for this product.
NL-4 PINOUT
Subwoofer Signal
Parallel Signal

2
QS_BASSO21t_EN_v3.3
Enclosure design Band-Pass
Transducers 1 x 21’’
Power Handling (RMS) 1400 W
Nominal Impedance 8 Ohm
SPL (Continuous/Peak) 132/138 dB SPL
Frequency Range (-10 dB) 25 - 100/120/150 Hz
Frequency Range (-3 dB) 30 - 80/100/120 Hz
Dimensions (WxHxD) 900 x 600 x 950 mm
(35.4 x 23.6 x 37.4 inch)
Weight 81 kg (178,5 lbs)
Connectors
+/-1
+/-2
2 x Neutrik speakOn NL-4 in parallel
Input
Link
Cabinet Construction 18 mm Plywood
Grille 2 mm perforated weatherised steel with protective foam
Finish Durable IDEA proprietary Aquaforce paint coating process
Handles 4 integrated handles
Feet/Skates 2 skates (H)
Installation Two 36 mm Pole mount sockets (top and side)
Accessories Riggin Frame (RF-900)
Riggin Frame adaptor (RF-9060)
Riggin System (RS-BASSO-L)
Wheels (WH-04)
35 mm Pole (K&M-21336)
TECHNICAL DATA
TECHNICAL DRAWINGS
950 mm 900 mm
600 mm
BASSO21t
INPUT
INPUT
LINK
LINK
PRODUCTOFEUROPE
PRODUCTOFEUROPE
MadeinSpain
MadeinSpain
Designed,engineered
Designed,engineered
andmanufacturedby
andmanufacturedby
IDEAinCedeira (Galicia)
IDEAinCedeira (Galicia)
8Ω
81kg/ 178 lbs
1500WRMS
Theinstallationof this product
Theinstallationof this product
shouldbeimplemented by
shouldbeimplemented by
qualifiedprofessionals
qualifiedprofessionals
followingsafepractices and
followingsafepractices and
localregulations.
localregulations.
Refertothe owner's manuals
Refertothe owner's manuals
forrigginginstructions, system
forrigginginstructions, system
componentsandsuspension
componentsandsuspension
hardwareintendedfor this
hardwareintendedfor this
product.
product.
NL
NL
-
-
4PINOUT
4PINOUT
SubwooferSignal
ParallelSignal

3
QS_BASSO21t_EN_v3.3
I MAS D ELECTROACÚSTICA SL
POL. A TRABE 19-20 15350 CEDEIRA (GALICIA - SPAIN)
DECLARES THAT: BASSO21T
COMPLIES WITH THE FOLLOWING EU DIRECTIVES:
ROHS (2002/95/CE) RESTRICTION OF HAZARDOUS SUBSTANCES
LVD (2006/95/CE) LOW VOLTAGE DIRECTIVE
EMC (2004/108/CE) ELECTRO-MAGNETIC COMPATIBILITY
WEEE (2002/96/CE) WASTE OF ELECTRIC AND ELECTRONIC EQUIPMENT
EN 60065: 2002 AUDIO, VIDEO AND SIMILAR ELECTRONIC APPARATUS. SAFETY REQUIRE-
MENTS.
EN 55103-1: 1996 ELECTROMAGNETIC COMPATIBILITY: EMISSION
EN 55103-2: 1996 ELECTROMAGNETIC COMPATIBILITY: IMMUNITY
DECLARATION OF CONFORMITY
WARNINGS AND SAFETY GUIDELINES
WARRANTY
QS_BASSO21t_EN_v3.3
!
• All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical
parts and 2 years from date of purchase for electronic devices.
• The guarantee excludes damage from incorrect use of the product.
• Any guarantee repair, replacement and servicing must be exclusively done by the factory or any of authorized service centres.
• Do not open or intend to repair the product; otherwise servicing and replacement will not be applicable for guarantee repair.
• Return the damaged unit, at shipper’s risk and freight prepaid, to the nearest service centre with a copy of the purchase invoice in
order to claim guarantee service or replacement.
• Read this document thoroughly, follow all safety warnings and keep it for future reference.
• The exclamation mark inside a triangle indicates that whatever repairing and component replacement operations must be done by
qualied and authorized personnel.
• No user serviceable parts inside.
• Only use accessories tested and approved by IDEA and supplied by the manufacturer or an authorized dealer.
• Installations, rigging and suspension operations must be done by qualied personnel.
• Only use accessories specied by IDEA, complying with maximum loads specications and following local safety regulations.
• Read the specications and connection instructions before proceeding to connect the system and use only cabling supplied or rec-
ommended by IDEA. Connection of the system should be done by qualied personnel.
• Professional sound reinforcement systems can deliver high SPL levels that may result in hearing damage. Do not stand close to the
system while in use.
• Loudspeaker produce magnetic eld even while they are not in use or even when disconnected. Do not place or expose loudspeakers
to any device that is sensitive to magnetic elds such as television monitors or data storage magnetic material.
• Disconnect the equipment during lightning storms and when it is not to be used for a long time.
• Do not expose this device to rain or moisture.
• Do not place any objects containing liquids, such as bottles or glasses, on the top of the unit. Do not splash liquids on the unit.
• Clean with a wet cloth. Do not use solvent-based cleaners.
• Regularly check the loudspeaker housings and accessories for visible signs of wear and tear, and replace them when necessary.
• Refer all servicing to qualied service personnel.
• This symbol on the product indicates that this product should not be treated as household waste. Follow local regulation for recy-
cling of electronic devices.
• IDEA declines any responsibility from misuse that may result in malfunction or damage of the equipment.

4
QS_BASSO21t_EN_v3.3
For further information scan the QR Code
or refer to the following web address: www.ideaproaudio.com/product-detail/basso21t
www.ideaproaudio.com
IDEA is always in pursuit of better performance, greater reliability and design features.
Technical specications and minor nish details may vary without notice in order to improve our products.
©2020 - I MAS D Electroacústica SL
