BASSO18
18˝ High Performance Direct Radiation Professional Subwoofer QuickStart Guide
Many key factors are to be considered when conguring the subwoofer
section of a loudspeaker system to perfectly match each application:
size/weight, logistic and operational setups, SPL needs, LF extension, cost
limitations, as well as sound engineer preferences (depending on dierent
the type and size of the event) or audio program characteristics and
regional style taste for subwoofer mixes.
BASSO Series models allow the user to choose the most adequate
subwoofer for any given situation from within a family of products with
common nish, design solutions and performance philosophy as well as
shared rigging and transport accessories.
BASSO18 is a high-density single 18” direct radiation subwoofer that
delivers a very natural, linear response in the VLF range from 28 Hz up
to 180 Hz. Built with 18” Premium birch plywood and tted with a 2 mm
steel grille, this medium format medium format cabinet is nished with
IDEA Aquaforce weatherized coating to endure life on the road or stylishly
integrate in any installation.
BASSO18 seamlessly matches with 2-way loudspeakers in LUA and
EXO Series maximizing the high-density performance of these systems
for a wide range of portable, mobile and install professional sound
reinforcement applications, from high power club sound systems and
medium size live music events to rental and touring companies.
+/- 1 Subwoofer Signal
+/- 2 Parallel Signal
NL-4 PINOUT:
SYSTEM CONFIGURATION AND SETTINGS
RECOMMENDED SETTINGS
BASSO18 back panel is tted with a pair of Neutrik NL-4 connectors in
parallel for straightforward, exible installation setup.
BASSO18
Setup of this product shouldbe
implemented by qualified
professionalsfollowing safe
practices and localregulations.
Refer to the owner'smanuals for
instructions, systemcomponents
and setup operations for this
product.
PARALLEL I/O A
B
PARALLEL I/O
PRODUCT OF EUROPE
Made in Spain
Designed, engineered
and manufactured by
IDEA in Cedeira (Galicia)
Nominal Impedance: 8 Ohm
Recommended amplifier power:
1000/2000 W
SubwooferSignal
Parallel Signal
NL-4 PINOUT
Type Freq Q Gain
Bell 75 Hz 5.0 0.80
Low Pass 120 Hz 0.8 --
Bell 35 Hz 2.5 0.20
Bell 75 Hz 6.0 0.70
HPF: 20 Hz Butterworth 12dB
LPF: 72 Hz Butterworth 24dB
LPF@ 85 Hz
Type Freq Q Gain
Bell 55 Hz 3.0 0.40
Low Pass 130 Hz 0.8 --
Bell 35 Hz 2.5 0.20
Bell 75 Hz 8.0 -1.00
HPF: 20 Hz Butterworth 12dB
LPF: 88 Hz Butterworth 24dB
LPF@ 100 Hz
Type Freq Q Gain
Bell 90 Hz 7.5 -3.80
Low Pass 160 Hz 0.8 --
Bell 35 Hz 2.5 0.20
Bell 103 Hz 8.0 0.70
HPF: 20 Hz Butterworth 12dB
LPF: 107 Hz Butterworth 24dB
LPF@ 120 Hz
Type Freq Q Gain
Bell 95 Hz 4.3 -4.50
Low Pass 190 Hz 0.6 --
Bell 35 Hz 2.5 0.20
Bell 140 Hz 1.0 1.50
HPF: 20 Hz Butterworth 12dB
LPF: 130 Hz Butterworth 24dB
LPF@ 150 Hz

2
QS_BASSO18_EN_v3.3
Enclosure design Bass Reex
Transducers 1 x 18’’
Power Handling (RMS) 1.2 kW
Nominal Impedance 8 Ohm
SPL (Continuous/Peak) 131/137 dB SPL
Frequency Range (-10 dB) 28 - 100/120/150/180 Hz
Frequency Range (-3 dB) 34 - 85/100/120/150 Hz
Dimensions (WxHxD) 600 x 600 x 740 mm (23.6 x 23.6 x 29.1 in)
Weight 54 kg (119 lbs)
Connectors
+/-1
+/-2
2 x Neutrik speakOn NL-4 in parallel
Input
Link
Cabinet Construction 18 mm Plywood
Grille 2 mm perforated weatherised steel with protective foam
Finish Durable IDEA proprietary Aquaforce paint coating process
Handles 4 integrated handles
Feet/Skates 4 rubber feet
Installation 36 mm Pole mount socket
Accessories Riggin Frame (RF-600)
Riggin System (RS-BASSO-L)
Wheels (WH-04)
35 mm Pole (K&M-21336)
TECHNICAL DATA
TECHNICAL DRAWINGS
740 mm 600 mm
600 mm
PARALLELI/O
BASSO18
NominalImpedance:8 Ohm
This product must be installed
and/or operated by qualified
professionals following safe
practicesandlocal regulations.
Refer to the owner’s manual
for instructions and optional
accessories.
Recommendedamppower:
1500/3000Watt
A
B
PARALLELI/O
SubwooferSignal
ParallelSignal
NL-4PINOUT
PRODUCTOF EUROPE
Madein Spain
Designed, engineered
and manufactured by
IDEAin Cedeira (Galicia)

3
QS_BASSO18_EN_v3.3
I MAS D ELECTROACÚSTICA SL
POL. A TRABE 19-20 15350 CEDEIRA (GALICIA - SPAIN)
DECLARES THAT: BASSO18
COMPLIES WITH THE FOLLOWING EU DIRECTIVES:
ROHS (2002/95/CE) RESTRICTION OF HAZARDOUS SUBSTANCES
LVD (2006/95/CE) LOW VOLTAGE DIRECTIVE
EMC (2004/108/CE) ELECTRO-MAGNETIC COMPATIBILITY
WEEE (2002/96/CE) WASTE OF ELECTRIC AND ELECTRONIC EQUIPMENT
EN 60065: 2002 AUDIO, VIDEO AND SIMILAR ELECTRONIC APPARATUS. SAFETY REQUIRE-
MENTS.
EN 55103-1: 1996 ELECTROMAGNETIC COMPATIBILITY: EMISSION
EN 55103-2: 1996 ELECTROMAGNETIC COMPATIBILITY: IMMUNITY
DECLARATION OF CONFORMITY
WARNINGS AND SAFETY GUIDELINES
WARRANTY
QS_BASSO18_EN_v3.3
!
• All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical
parts and 2 years from date of purchase for electronic devices.
• The guarantee excludes damage from incorrect use of the product.
• Any guarantee repair, replacement and servicing must be exclusively done by the factory or any of authorized service centres.
• Do not open or intend to repair the product; otherwise servicing and replacement will not be applicable for guarantee repair.
• Return the damaged unit, at shipper’s risk and freight prepaid, to the nearest service centre with a copy of the purchase invoice in
order to claim guarantee service or replacement.
• Read this document thoroughly, follow all safety warnings and keep it for future reference.
• The exclamation mark inside a triangle indicates that whatever repairing and component replacement operations must be done by
qualied and authorized personnel.
• No user serviceable parts inside.
• Only use accessories tested and approved by IDEA and supplied by the manufacturer or an authorized dealer.
• Installations, rigging and suspension operations must be done by qualied personnel.
• Only use accessories specied by IDEA, complying with maximum loads specications and following local safety regulations.
• Read the specications and connection instructions before proceeding to connect the system and use only cabling supplied or rec-
ommended by IDEA. Connection of the system should be done by qualied personnel.
• Professional sound reinforcement systems can deliver high SPL levels that may result in hearing damage. Do not stand close to the
system while in use.
• Loudspeaker produce magnetic eld even while they are not in use or even when disconnected. Do not place or expose loudspeakers
to any device that is sensitive to magnetic elds such as television monitors or data storage magnetic material.
• Disconnect the equipment during lightning storms and when it is not to be used for a long time.
• Do not expose this device to rain or moisture.
• Do not place any objects containing liquids, such as bottles or glasses, on the top of the unit. Do not splash liquids on the unit.
• Clean with a wet cloth. Do not use solvent-based cleaners.
• Regularly check the loudspeaker housings and accessories for visible signs of wear and tear, and replace them when necessary.
• Refer all servicing to qualied service personnel.
• This symbol on the product indicates that this product should not be treated as household waste. Follow local regulation for recy-
cling of electronic devices.
