Idea BASSO24t User manual

1
QS_BASSO24t_EN_v3.3
BASSO24t
Dual-12˝ Compact Band-Pass Multipurpose Subwoofer QuickStart Guide
Many key factors are to be considered when conguring the subwoofer
section of a loudspeaker system to perfectly match each application:
size/weight, logistic and operational setups, SPL needs, LF extension,
cost limitations, as well as sound engineer preferences (depending
on dierent the type and size of the event) or audio program
characteristics and regional style taste for subwoofer mixes.
BASSO Series models allow the user to choose the most adequate
subwoofer for any given situation from within a family of products with
common nish, design solutions and performance philosophy as well as
shared rigging and transport accessories.
BASSO24t F400 is a dual 12” band-pass subwoofer with a very shallow-
form factor and excellent power-density that make this loudspeaker a
versatile tool for any small, unobtrusive installed sound reinforcement
and portable FOH applications to more powerful, medium-sized
congurations for Touring and Rental companies and theatre and club
installations.
+/- 1 Subwoofer Signal
+/- 2 Parallel Signal
NL-4 PINOUT:
SYSTEM CONFIGURATION AND SETTINGS
RECOMMENDED SETTINGS
BASSO24t back panel is tted with a pair of Neutrik NL-4 connectors in
parallel for straightforward, exible installation setup.
Type Freq Q Gain
Bell 166 Hz 7.0 -6.00
Bell 74 Hz 5.0 1.70
Bell 169 Hz 5.0 -4.30
Bell 63 Hz 14.0 -1.00
HPF: 26 Hz Butterworth 18dB
LPF: 76 Hz Butterworth 24dB
LPF@ 80 Hz
Type Freq Q Gain
Bell 166 Hz 7.0 -6.00
Bell 93 Hz 7.0 2.00
Bell 169 Hz 5.0 -4.30
Bell 63 Hz 13.0 -0.80
HPF: 26 Hz Butterworth 18dB
LPF: 93 Hz Butterworth 24dB
LPF@ 100 Hz
Type Freq Q Gain
Bell 166 Hz 7.0 -6.00
Bell 105 Hz 7.0 0.50
Bell 169 Hz 5.0 -4.30
Bell 63 Hz 13.0 -0.80
Bell 240 Hz 8.0 -8.00
HPF: 26 Hz Butterworth 18dB
LPF: 117 Hz Butterworth 24dB
LPF@ 120 Hz
Type Freq Q Gain
Bell 166 Hz 6.0 -5.00
Bell 250 Hz 6.0 -11.00
Bell 124 Hz 6.0 -1.60
Bell 137 Hz 5.7 1.40
Bell 63 Hz 13.0 -0.80
Bell 250 Hz 4.0 -1.80
HPF: 26 Hz Butterworth 18dB
LPF: 165 Hz Butterworth 24dB
LPF@ 160 Hz

2
QS_BASSO24t_EN_v3.3
Enclosure design Symmetrical Air mass Loading 5th order Band-Pass
Transducers 2 x 12˝
RMS Power Handling * 1 500 W
Nominal Impedance 4 Ohm
SPL (Continuous/Peak) 129/135 dB SPL
Frequency Range (-10 dB) 44 - 100/120/150/180 Hz
Frequency Range (-3 dB) 52 - 80/100/120/160 Hz
Dimensions (WxHxD) 600 x 365 x 850 mm (23,6 x 14,4 x 33,5 inch)
Weight 49 kg (108 lbs)
Connectors
+/-1
+/-2
2 x Neutrik speakON® NL-4 in Parallel
Input
Link
Cabinet Construction 15 mm Plywood
Grille 1.5 mm perforated weatherised steel with protective foam
Finish Durable IDEA proprietary Aquaforce paint coating process
Handles 4 integrated handles
Feet/Skates 4 rubber feet
Installation 4 threaded M8 inserts. 2 x 36-mm Pole mount sockets (H/V)
Accessories 35 mm Pole (K&M-21338)
TECHNICAL DATA
IEC ltered pink noise with a 6dB crest factor, 2 hours.
*
Frequency range values for recommended factory presets.
**
TECHNICAL DRAWINGS
850 mm 600 mm
365 mm
BASSO24t
NominalImpedance:8Ohm
Thisproductmustbe installed
DQGRURSHUDWHGE\TXDOLƋHG
professionalsfollowingsafe
practicesandlocalregulations.
Refertotheowner’s manual
forinstructionsandoptional
accessories.

3
QS_BASSO24t_EN_v3.3
I MAS D Electroacústica SL
Pol. A Trabe 19-20 15350 CEDEIRA (Galicia - Spain)
Declares that: BASSO24t
Complies with the following EU Directives:
RoHS (2002/95/CE) Restriction of Hazardous Substances
LVD (2006/95/CE) Low Voltage Directive
EMC (2004/108/CE) Electro-Magnetic Compatibility
WEEE (2002/96/CE) Waste of Electric and Electronic Equipment
EN 60065: 2002 Audio, video and similar electronic apparatus. Safety requirements.
EN 55103-1: 1996 Electromagnetic compatibility: Emission
EN 55103-2: 1996 Electromagnetic compatibility: Immunity
DECLARATION OF CONFORMITY
WARNINGS AND SAFETY GUIDELINES
WARRANTY
QS_BASSO24t_EN_v3.3
!
• All IDEA products are guaranteed against any manufacturing defect for a period of 5 years from date of purchase for acoustical
parts and 2 years from date of purchase for electronic devices.
• The guarantee excludes damage from incorrect use of the product.
• Any guarantee repair, replacement and servicing must be exclusively done by the factory or any of authorized service centres.
• Do not open or intend to repair the product; otherwise servicing and replacement will not be applicable for guarantee repair.
• Return the damaged unit, at shipper’s risk and freight prepaid, to the nearest service centre with a copy of the purchase invoice in
order to claim guarantee service or replacement.
• Read this document thoroughly, follow all safety warnings and keep it for future reference.
• The exclamation mark inside a triangle indicates that whatever repairing and component replacement operations must be done by
qualied and authorized personnel.
• No user serviceable parts inside.
• Only use accessories tested and approved by IDEA and supplied by the manufacturer or an authorized dealer.
• Installations, rigging and suspension operations must be done by qualied personnel.
• Only use accessories specied by IDEA, complying with maximum loads specications and following local safety regulations.
• Read the specications and connection instructions before proceeding to connect the system and use only cabling supplied or rec-
ommended by IDEA. Connection of the system should be done by qualied personnel.
• Professional sound reinforcement systems can deliver high SPL levels that may result in hearing damage. Do not stand close to the
system while in use.
• Loudspeaker produce magnetic eld even while they are not in use or even when disconnected. Do not place or expose loudspeakers
to any device that is sensitive to magnetic elds such as television monitors or data storage magnetic material.
• Disconnect the equipment during lightning storms and when it is not to be used for a long time.
• Do not expose this device to rain or moisture.
• Do not place any objects containing liquids, such as bottles or glasses, on the top of the unit. Do not splash liquids on the unit.
• Clean with a wet cloth. Do not use solvent-based cleaners.
• Regularly check the loudspeaker housings and accessories for visible signs of wear and tear, and replace them when necessary.
• Refer all servicing to qualied service personnel.
• This symbol on the product indicates that this product should not be treated as household waste. Follow local regulation for recy-
cling of electronic devices.
• IDEA declines any responsibility from misuse that may result in malfunction or damage of the equipment.

4
QS_BASSO24t_EN_v3.3
For further information scan the QR Code
or refer to the following web address: www.ideaproaudio.com/basso24t
QS_BASSO24t_EN_v3.3
www.ideaproaudio.com
IDEA is always in pursuit of better performance, greater reliability and design features.
Technical specications and minor nish details may vary without notice in order to improve our products.
©2020 - I MAS D Electroacústica SL
Pol. A Trabe 19-20 15350 Cedeira (Galicia – Spain)
