IDEAL Viceroy GT Series Guide

Viceroy G.T.
Installation, Assembly and Servicing
Oil or Dual Gas Fired Boilers
CAUTION.
To avoid the possibility of injury during the installation, servicing or cleaning of this
appliance care should be taken when handling edges of sheet steel components.
Assembly and Installation Instructions for Ideal Viceroy Oil, Gas or Dual Fired heating boilers should be read in
conjunction with the general technical data tables enclosed and any other technical publication supplied with the
burner.
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

GENERAL
CONTENTS
Boiler Models..................................................................4
Packing ...........................................................................5
Installation ......................................................................6
Assembly/Hydraulic Connection ..................................7
Filling the Installation.....................................................8
Desludging/Chimney Connection.................................9
Dimensions/Connection ..............................................10
Oil or Gas Connection .................................................11
Control Panels ..............................................................12
Start Up .........................................................................16
Maintenance .................................................................19
Precautions...................................................................20
Data Table .....................................................................21
Main Dimensions..........................................................22
2
INTRODUCTION
DUTY
The range of boilers is suitable for: combined indirect pumped
domestic hot water and central heating systems; independent
indirect pumped domestic hot water or central heating
systems.
Fully pumped systems may be open vented or sealed.
The range of boilers is NOT suitable for:
1. Gravity DHW systems.
2. Gravity heating systems.
3. Direct domestic hot water supply.
GAS SAFETY (INSTALLATION AND USE)
REGULATIONS, 1994
It is law that all gas appliances are installed and serviced by a
CORGI registered installer in accordance with the above
regulations. Failure to install appliances correctly could lead to
prosecution. It is in your own interest, and that of safety, to
ensure the law is complied with.
The installation of the boiler MUST also be in accordance with
the latest l.E.E Wiring Regulations, local building regulations,
bye-laws of the local water authority, the building regulations
and the Building Standards (Scotland) and any relevant
requirements of the local authority.
Detailed recommendations are contained in the following
British Standard Codes of Practice:
BS. 6891 Low pressure installation pipes.
BS. 6798 Installation of gas fired hot water boilers of rated
input not exceeding 60 kW.
BS. 5449 Forced circulation hot water systems.
BS. 5546 Installation of gas hot water supplies for
domestic purposes (2nd Family Gases)
BS. 6644 Ventilation (for gas appliances of rated input
exceeding 60 kW)
BS. 5440:2 Ventilation (for gas appliances of rated input not
exceeding 60 kW)
Viceroy GT Range - Installation
FOUNDATION
The boiler must stand on a non-combustible floor
(i.e. concrete or brick) which must be flat, level and of a
suitable load bearing capacity to support the weight of the
boiler (when filled with water) and any ancillary equipment.
If the boiler is mounted on a plinth then the dimensions must
exceed the plan area of the boiler by at least 75mm on each
side
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

Viceroy GT Range - Installation 3
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

The technical instructions for boiler installation given in the
document must be scrupulously followed, otherwise the
guarantee will be invalidated.
GENERAL
4Viceroy GT Range - Installation
1 THE BOILERS COVERED BY THIS DOCUMENT
The Viceroy GT range of boilers is an automatic range of
pressurised hot water boilers, connected to a chimney, to be
fitted with an independent burner using domestic fuel oil or
gas, with a working power rating from 175 to 780kW.
Boiler models:
VICEROY GT “DELUXE”: boiler with “DIEMATIC-m” integral
electronic control panel. Used as the «master» boiler for
installations of 2 or 3 boilers in cascade where the other
boilers are fitted with an «E» control panel.
VICEROY GT “STANDARD”: boiler with “E” control panel: on
option can be fitted a SV-matic weather compensator or a
SVR module for domestic hot water priority. Used as a
«slave» boiler for installations of two or three boilers in
cascade where one is fitted with a “DIEMATIC-m” control
panel.
VICEROY GT: boiler with standard control panel to be
connected, if needed, to main control cabinet.
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

Viceroy GT Range - Installation 5
Before installing your boiler, you can check with the chart
below if you have all the component packages
For optional equipment you may use with this boiler, see the current price list.
GENERAL
PACKING
Item Box nr. Viceroy Viceroy Viceroy Viceroy Viceroy Viceroy Viceroy
8 9 10 11 12 13 14
Underframe 1 1 1 1 1 1 1
(dimensions according to model)
Front section 1 1 1 1 1 1 1
Normal intermediate section 5 6 7 8 9 10 11
Special intermediate section 1 1 1 1 1 1 1
Rear Section 1 1 1 1 1 1 1
Common accessories IE 20 1 1 1 1 1 1 1
Accessories boiler in bulk 1 1 1 1 1 1 1
(composition according to model)
Baffles IE 30 1
IE 31 1 1
IE 32 1 1
IE 33 11
Inner body insulation * IE 51 1
IE 53 1 1
IE 55 1 1
IE 57 11
Casing: common parts IE 10 1 1 1 1 1 1 1
Casing: varying parts IE 11 1 1
IE 12 1 1 1
IE 13 1 1 1 2 2 2
IE 14 1 1
Wiring ducts IE 41 1
IE 42 1
IE 43 1
IE 44 1
IE 45 1
IE 46 1
IE 47 1
Control panel -E ID 22 or 1 1 1 1 1 1 1
-Standard ID 24
Technical documents IE 408 1
IE 409 1
IE 410 1
IE 411 1
IE 412 1
IE 413 1
IE 414 1
Table 1 - Viceroy GT in bulk
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

GENERAL
6Viceroy GT Range - Installation
2 INSTALLATION OF THE BOILER
The minimum dimensions indicated on the following drawing
must be respected to ensure good access around the boiler
Remark: To allow the inlet of the combustion air, the boiler
room must be adequately ventilated, the section and the
location must comply with local recommendations.
* Caution: Pay particular care to the space required for the boiler when the door is open. For an installation of several
boilers side by side, these dimensions need to be modified.
Sections 8 9 10 11 12 13 14
Dimensions A mm 1505 1665 1825 1985 2145 2305 2465
Dimensions B mm 130 -40 120 -40 120 -40 120
Dimensions C m 1.5 2 2 2 2.5 2.5 2.5
Section cm2 S 840 960 1090 1240 1390 1550 1710
Burner door open
8229-EN-05 A
8229-EN-54
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

Ventilation General
Detailed recommendations for air supply are quoted in BS.
6644. The ventilation requirements in this gas fired boiler
standard are also valid for oil fired boilers of the same heat
input.
INSTALLATION
Viceroy GT Range - Installation 7
4 HYDRAULIC CONNECTION
Dimensional information required
Remark: We draw your attention to the risks of corrosion of
boilers which are installed in or near rooms in which the
atmosphere can be polluted by chloride or fluoride
substances.
E.g. : industrial buildings (solvents), refrigerating machines,
etc...
In these cases, we cannot provide a warranty.
Installation Recommendations
The installation of the boiler MUST be in accordance with the
following British Standards and Codes of Practice:
BS. 799 Pts. 4,5,6 & 7 Oil Burning Equipment
BS. 5410 Pts. 2 & 3 Installations for Space Heating and
Hot water Systems
BS. 5449 Pt.1 Hot Water Systems
BS. 5854 Flues and Flue Structures in Buildings
BS. 5885 Pt.1 Gas Burners - with outputs of
60kW upwards
BS.6644 Installation of Gas Fired Boilers
BS.6880 Low Temperature Hot Water Heating
Systems
BS.6891 Low Pressure Gas Pipework
British Gas Industrial Gas Fired Boilers and
Publication No. IM.11 Air Heaters
The following must be confirmed with:
Current Building Regulations and Clean Air Act
Water Authority Regulations
Local Authority Regulations and Regional bylaws
Gas Safety Regulations
Any Special regional requirements of local Electricity and Gas
undertaking.
Fire Service and Insurance Company requirements.
All electrical wiring MUST comply with the current I.E.E.
regulations for the electrical equipment of buildings. In the
interests of safety, a competent installer should be employed
to effect the installation of the appliance. Manufacturer’s
notes must NOT, in any way, be taken as over riding
statutory obligations.
3 ASSEMBLY
For the assembly of the boiler, refer to the removable leaflet
in the middle of the instruction book.
Water flow/return tapping
GT 8 to 10: Ø2”1/2
GT 11 to 14: Ø3”
Threaded drain 2”
Viceroy Viceroy
GT 8 to 10 GT 11 to 14
D mm 235 254
E mm 1427 1447
8229-EN-06
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

INSTALLATION
8Viceroy GT Range - Installation
Example of installation of a Viceroy GT boiler with production
of domestic hot water through independent calorifier(s)
1. Water flow flange
2. Water return flange
3. 4 bars safety valve + manometer*
4. Flow control device
5. Air separator
6. Air vent
7. Valve
8. Recycling pump
9. Expansion tank
10. Drain valve
11. Desludging valve
12. Mixing valve
13. Check valve
14. Circulating pump
15. Pressure gauge
16. Sludge decantation pot
(particularly recommendation for older installations)
17. Independent calorifier
18. Safety unit, set and sealed at 7 bars with over flow
19. Pressure reducer (if system pressure >5.5bars)
20. Domestic cold water inlet
21. Domestic hot water flow
22. Calorifier heating pump
23. Domestic water circulating pump (optional)
24. DHW circuit return
25. Water meter (eventually)
26. Water treatment when TH > 25°
27. Heating system filler
(with circuit breaker in accordance with regulations).
* 6 bars maxi
Heating
Circuit
FILLING THE INSTALLATION
The boiler may be filled by the drain tap. Filling should be
done at a slow flow rate in order to purge all the air
contained in the boiler by the upper point of the installation.
Filling is always done with circulating pumps stopped.
General
Recommendations relating to the water system are contained
in BS.5449 Pt.1, BS5401 Pt.2. and BS.6880.
MOST IMPORTANT: start up after partial or
total drain of the installation:
If all air does not purge naturally via an opened expansion
system, then in addition to automatic airvents able to ensure
continuous automatic elimination of air from the system while
it is running, the installation must also include manual
airvents so that all upper points of the installation can be
vented and so that when the installation is full of water it can
be verified that all air is eliminated before the boiler are fired.
8219-EN-12
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

INSTALLATION
Viceroy GT Range - Installation 9
DESLUDGING
Desludging hole
threaded 2”1/2
A desludging hole of Ø1”1/2 supplied with a plug is
provided in the lower part of the boiler to enable sludge to be
drained out. The installer can fit 1/4 turn valve.
Draining sludge involves the loss of significant quantities of
water from the system, which must be refilled after the
procedure.
Comment: Any replacement of boilers in an old system must
include a careful washing out of the full installation. Fit a
sludge trap on the return and close to the boiler.
5 CHIMNEY CONNECTION
As the Viceroy GT is a high performance boiler, the
temperature of the flue gases may be less than 160°C. The
installer ought to take all precautions (padding out, casing, T
for draining condensation) in order to avoid deterioration of
the chimney.
If necessary, the baffles of the 4 upper smoke chambers may
be partially removed with a resulting increase in temperature
of the flue gases.
8229-EN-07
8219-EN-21
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

INSTALLATION
10 Viceroy GT Range - Installation
DETERMINING THE FLUE
DIMENSIONAL INFORMATION NEEDED FOR CONNECTION
To size the height and cross section of the chimney, refer to
the regulations currently in force. GT boilers are boilers with
pressurised combustion chambers and the pressure of the
outlet must not exceed 0 mbar unless special precautions
are taken to seal carefully between the outlet and the flue.
The installer should provide a measuring point (Ø10mm hole)
on the flue for burner adjustment and control of the
combustion.
Detailed recommendations, relating to the design of flues for
GAS fired appliances are quoted in BS.6644 and British Gas
Publication No. IM 11., whilst BS.5410 Pt.3 similarly applies
OIL fired burners.
Chimney connection (outer Ø)
VICEROY GT 8 to 10: Ø250
VICEROY GT 11 to 14: Ø300
CONNECTION
Connection should be made according to regulation and
practice by using a sealed pipe in a material able to
withstand hot combustion gases and possible acidic
condensation. The connection should be removable and
present minimal loss of load, it means it should be as short
as possible and without sudden change of cross section.
Its diameter should always be at least equal to that of the
boiler outlet, 250mm for the 8, 9 and 10 section boilers and
300mm for the 11, 12, 13 and 14 section boilers.
8229-EN-08
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

INSTALLATION
Viceroy GT Range - Installation 11
6 OIL OR GAS CONNECTION
See specific technical information supplied with the burner.
Caution: The baffle at the head of the burner must be in line
with the burner door insulation level.
Drilling Ø for burner door (on request).
Gas Supply
The gas supply MUST be sized in accordance with British
Gas recommendations and be fabricated in compliance with
CP.331 Pt.3 any Local Gas Board installation standards.
The Local Gas Board should be contacted, at a stage prior to
actual installation, for any advice or information required.
Details and advice, relating to the use of L.P.G. for firing the
IDEAL VICEROY GT range of heating boilers, are available on
request to Caradon Ideal Ltd.
Oil Storage Tank
The oil storage tank, oil supply pipe and connections to the
burner unit MUST comply with the requirements of BS.779
and CP.5410.
The installation should conform to the recognised standards
of good practice in the trade and comply with the relevant
Codes of Practice, Building Regulations and Local Authority,
Fire and insurance requirements.
** maxi diameter for fixing:
ØB maxi = 290 mm
or ØB maxi = 330 with 4 fixings at 15°or at 45°
ØA 135 175 190 240 250 290
ØB** 170 200 220 270 325 330
ØM 8 8 10101412
8229-EN-10
Burner door
insulation
Baffle
8229-EN-09
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

INSTALLATION
12 Viceroy GT Range - Installation
7 ELECTRICAL CONNECTIONS TO THE CONTROL PANEL
CAUTION: The connection must be carried out by a
qualified professional.
As the electrical wiring has been carefully checked in the
factory, the internal connections of the control panel must
not be modified under any circumstances.
The electrical connections of the boiler must conform with
the IEE wiring regulations in force and with the specifications
shown on the electrical drawings provided with the
equipment, and the instructions given below.
The equipment should be supplied by a circuit using an
omnipolar circuit breaker with an opening gap greater than
3mm.
DELUXE - control panel
All the connections are made to the 2 terminal blocks
provided for this purpose in the control panel.
The connection cables are routed towards the front via the 2
cut outs in the panel behind the boiler, and run in the wiring
duct towards the panel via the two rectangular cut outs of
the front top panel. The senor cables run on one side, the
cables carrying the 230 V supply on the other and are
supported on both sides by plastic clips.
Caution: The sensor wiring must be kept separate from
the other circuits. Inside the boiler, use the cable runs.
Outside the boiler, 2 wiring ducts at least 10cm apart
should be used.
Wiring is secured in the control panel using cable clips (6
cable clips are supplied in a separate packet); these are to
be fitted into the control panel base - see diagram below.
Caution: The maximum current which may be switched
by the outlet is 2 A, cos ϕ= 0.7 (= 450 W at he motor of
0.5 Méch., hp signal current less than 16 A), if the charge
exceeds one of these values, the control must be relayed
by means of a contractor. The outlet group is protected
by a 5 A fuse.
8229-EN-44
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

INSTALLATION
Viceroy GT Range - Installation 13
Fitting the SVR option
The SVR option box is to be fitted in the front part of the
control panel. To do this:
1-2. Remove the blank by cutting the surface with a
stanley knife following the black line and by breaking
the perforations in the steel plate behind with a pair of snips.
3. Connect the two connections, situated behind the
blank, to the back of the SVR unit: blue connector to
the blue plug, red connector to the red plug.
4. Locate the unit by its front and fix it using the two
screws sited in the front part of the equipment
(1/4 turn clockwise)
The limit thermostat supplied with the SVR option is to be
fitted in the control panel in the place provided for this
purpose, using the two self tapping screws supplied. The 3
pin thermostat male terminal is to be connected in the
position provided on the 25 pin terminal block after having
taken out the bridge; the thermostat bulb is to be located in
the small pocket in the body of the boiler.
12
34
8219-EN-13
8219-EN-9
8229-EN-45
8219-EN-11
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

INSTALLATION
14 Viceroy GT Range - Installation
The SV-matic weather compensator is fitted in the front part
of the control panel. To do this:
1-2. Remove the blank by cutting the surface with a
stanley knife following the black line and by breaking
the perforations in the steel plate behind with a pair of snips.
3. Connect the two connections, situated behind the
blank, to the back of the SVR unit: blue connector to
the blue plug, red connector to the red plug.
4. Locate the unit by its front and fix it using the two
screws sited in the front part of the equipment
(1/4 turn clockwise)
Caution: When a two stage SV-matic weather compensator type
322 DB is fitted, the resistor and the bridge respectively fitted
between terminals 34 and 37, and 34 and 35 must be removed.
1 2
3
Fitting an SV-matic weather compensator
8219-EN-9
8219-EN-14
8219-EN-11
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

INSTALLATION
Viceroy GT Range - Installation 15
STANDARD CONTROL PANEL
The connections are made on the terminal strip in the control
panel, accessible by opening the panel
(3 screws at the back - see diagram).
The connection cables are directed towards the front via the
two cut outs in the rear panel of the boiler, and routed in the
cable run to the control panel via the 2 rectangular cut outs
in the front top panel.
The burner control circuit generally a 2-stage burner, is fitted
with 2 European 7 and 4 pin plugs supplied with the boiler,
which simply need to be fitted into the female plugs supplied
with the burners. In the case of a burner not fitted with
female plugs, remove the plugs on the burner cable from the
boiler and connect the leads to the terminal bar on the
burner.
Burner connection
REAR FRONT
8259N2
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

ASSEMBLY
16 Viceroy GT Range - Installation
8STARTUP
1. Double STB-STW switch: To test the safety thermostat,
press simultaneously on the two switches STB and STW
(put the summer/winter switch 2 ( ) in
«Summer position»“”)
2. Burner/Heating pump double switch: Switch controlling
the burner and heating pump.
-In«Winter»position : the heating and the domestic
hot water are on.
-In«Summer»position , only the domestic hot
water is on (if a calorifier is connected).
Where an SV-matic weather compensator is fitted or
for a series installation, the two switches must be in
«Winter»position .
3. Auto/Manual switch:
- AUTO: Automatic position, the position to be used in
normal operation for boilers fitted with an SV-matic
weather compensator or with an SVR module. The
temperature of the boiler is adjusted by the control.
- Manual : Manual position, the position to be
used for boilers not fitted with an SVR module. The
temperature of the boiler is adjusted by the first and
second stage boiler thermostats 5. This position can
be used to test the burner on an installation fitted with
an SV-matic weather compensator.
4. Location for a hourrun meter if required for first or second
stage
5. Boiler thermostat for first or second stage:
Graduated from 30°C to 90°C.
However, a pre-set integral temperature stop limits the
temperature to 80°C. This stop can be changed if necessary.
To alter it, remove the thermostat button by pulling below
and with pliers relocate the stop in the hole according to the
temperature limit required.
Important:Boiler thermostats must always be at maximum
stop in the case where an SV-matic weather compensator is
fitted or a boiler fitted with a «DIEMATIC-m»electronic
control panel.
6. Indicator lamps for 1st and 2nd stage: these only light if
the thermostat concerned or the control are calling for
heat and the safety contact is closed.
7. Boiler thermometer
8. Location for possible smoke thermometer
9. Safety thermostat with manual reset
(cut temperature: 100°C)
10. Fuse 5 AT.
11. Location for SV-matic weather compensator or the
possible SVR option (here SV-matic 232 DB shown in place)
For boilers connected to a domestic hot water calorifier
12. Control rheostat for the temperature for the DHW sited on
the SVR box or the type B SV-matic weather
compensator (graduated from 20°to 80°C - adjustment
advised: 50°C)
DELUXE (option) - control panel
Presentation of the control panel
8219-EN-5 B
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

ASSEMBLY
Viceroy GT Range - Installation 17
Operating instructions of the Deluxe control panel
Regulation of the boiler:
The boiler is controlled either by the boiler thermostats or by
the SV-matic weather compensator (in option).
For boilers fitted with an SV-matic weather compensator the
temperature of the boiler is controlled by the action of the
regulator on the burner according to the external
temperature. The boiler thermostats will be then set to maxi.
Operating safety is ensured by the safety thermostat with
manual reset.
For boilers fitted with an SV-matic weather compensator
acting on a valve, heating temperature is adjusted by the
regulator on a motorised mixer valve according to the
outside temperature.
Regulation of domestic hot water
With SVR option or SV-matic type B:
The temperature of the domestic hot water is adjusted by a
rheostat 12 located on the SVR or SV-matic weather
compensator. When the domestic hot water is heated, the
burner and load pump start while the heating accelerator
stops; the temperature of the boiler is then regulated by the
limit thermostat incorporated in the SV-matic weather
compensator or mounted on the SVR option (this thermostat
is pre-set from factory at 80°C)
Once the hot water demand is satisfied, the burner stops
and the load pump continues to operate for 4 minutes (timing
adjustable from 30 seconds to 15 minutes). This enables the
residual calories within the body of the heater to be used,
and to complete the heating of the calorifier particularly in
summer.
Start up
Before starting the boiler, check that the installation is
properly filled with water.
Make the start up adjustments in the following chronological
order:
Put the boiler thermostats 5 to the desired position
(altering the position of the stop if necessary).
Important: For boilers fitted with an SV-matic weather
compensator adjust the boiler thermostats to max.
Put the domestic hot water thermostat 12 to the desired
temperature (SVR or SV-matic options). The temperature
of the hot water thermostat must always be lower than
the setting on the first stage boiler thermostat (or the limit
thermostat in the unique case of the SVR option).
Put switch 3:
Either on manual position : Boilers not fitted with an
SV-matic weather compensator.
Or on automatic position “AUTO”: Boilers fitted with an
SV-matic weather compensator.
Check that the safety thermostat 9 is not tripped. To do
this, unscrew the hexagonal cap and using a suitable
screwdriver, press on the reset button.
Put the burner/accelerator switch 2 on winter position
IMPORTANT: In the absence of other settings. it is advised
never to set the boiler thermostat under mark 4 (40°C) so as
to avoid all risk of condensation inside the boiler.
“”.
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

18 Viceroy GT Range - Installation
ASSEMBLYASSEMBLY
1. Stop/Start switch for the burner
2. STB test switch: momentary action to test the safety
thermostat
3. Boiler thermostat first and second stage: Graduated from
30°to 90°C. Integral pre-set stop limits the maximum
temperature to 80°C. This stop can be adjusted if
necessary. To adjust it, remove the thermostat button by
pulling and use pliers to move the stop to the hole
according to the temperature desired.
The second stage thermostat must always be set to a lower
value than the first stage thermostat.
4. Boiler thermometer
5. Location for possible smoke thermometer
6. 5 AT fuse
7. Safety thermostat with manual reset
(factory set at 100°C)
Standard control panel presentation
Operating principle of the control panel
Adjustment and regulation of the boiler is done by boiler
thermostats or by adjustments on the external control unit, if
there is one. Operating safety is ensured by the manual reset
safety thermostat.
Start up
Put the boiler thermostat 3 on the desired position (alter the
stop position if necessary). Where a control unit is fitted, see
informations supplied with this control unit.
Check that the safety thermostat 7 is not tripped. To do this,
unscrew the hexagonal cap and using a suitable screwdriver,
press on the reset button.
Put the burner switch 1 on run
Important: in the absence of other settings, it is advised
never to set the boiler thermostat lower than mark 4 (40°C)
so as to avoid all risk of condensation inside the boiler.
8219-EN-5
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

Viceroy GT Range - Installation 19
ASSEMBLY
Boiler
It is not advisable to drain an installation, except in case of
absolute necessity. Check regularly the water level of the
installation and top it up if necessary, avoiding a sudden inlet
of cold water into the hot boiler.
This operation can only be done a few times a year;
otherwise, look for the leakage and remedy it without delay.
Cleaning of the flue gas circuit:
For this purpose:
- unhook the front cover,
- open the sweeping doors (upper doors)
by unscrewing the 3 lock nuts (19mm spanner)
- remove the baffles
- using the brush supplied, carefully sweep
the 8 flue ways
- also brush the baffles and the front face
- if possible use a vacuum cleaner
- put the baffles back in place
(pay attention to their direction)
- shut the door
The good performance of the boiler depends on its
degree of cleanliness.
Cleaning of the boiler must be carried out as often as
required and at least, as the chimney once a year or more,
according to the regulations in force. The following
operations are always carried out with the boiler and the
power supply shut off.
9 MAINTENANCE
Hints for maintenance
Identification plate
Baffles (per flue way) GT 8 GT 9-10 GT 11-12 GT 13-14
Upper 8229-0010 2x8229-0010
then 2x then 3x
8229-0022 8229-0010 1x8229-0022 8229-0010
Middle 8229-0011 2x8229-0011
then 2x then 3x
8229-0023 8229-0011 1x8229-0023 8229-0011
Lower 8229-0012 2x8229-0012
then 2x then 3x
8229-0024 8229-0012 1x8229-0024 8229-0012
8229-EN-46 A
8229-EN-28
1
2
43or
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]

20 Viceroy GT Range - Installation
ASSEMBLY
Maintenance of the combustion chamber
- open the burner door (lower door) by unscrewing 4 lock
nuts (19mm spanner)
- brush the inside of the combustion chamber
- using a vacuum cleaner, vacuum up the soot deposits
accumulated in the combustion chamber
- close the door and replace the front cover
Cleaning the smoke box (flue hood)
For this purpose:
- remove the left and right hand sweeping covers of the
smoke box (2 H12 nuts + washers - 19mm spanner) and
remove the soot using a vacuum cleaner
- replace the sweeping covers
Precautions to be observed in case of very long stop of the boiler
- The boiler and the chimney must be carefully swept
- Shut the boiler doors to avoid any air flow inside
- If the boiler is going to be stopped for several months, we
also advise removing the flue connection off the nozzle and
to close it with a cover
- In case of stop of the heating in winter leading to risks of
freezing, we advise the use of a concentrated antifreeze
agent to prevent the heating water from freezing.
Otherwise, completely drain the installation
Vacuum
Cleaner
For latest prices and delivery to your door visit MyTub Ltd - 0845 303 8383 - www.mytub.co.uk - [email protected]
