IDEAL Vogue Combi c26 User manual

When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and
performance specification that we require.
Do not use reconditioned or copy parts that have not been clearly authorised by Ideal.
TIMER, ELECTRONIC, 7 DAY - USER GUIDE
Vogue Combi c26, c32, c40

2

3
Vogue Combination boiler
Timer, Electronic, 7 Day
Contents Page
Timer ....................................................................... 3
Timed/On/Off ........................................................... 4
+ Hours.................................................................... 5
Time/Date ................................................................ 6
Time Program.......................................................... 7
Holiday Mode........................................................... 8
Display Backlight Intensity..................................... 9
Reset to Factory Settings .......................................11
The national regulations and respective safety instructions are to be observed.
Interferences and changes to the device will lead to cancellation of the warranty.
Summer/Winter Time (GMT/BST) - automatically updated

4
Timer, Electronic, 7 Day
Note: if the Low Battery symbol is visible or the display is blank then replace the batteries
2
4
1
8
1
2
6
0
Day of the week
Time
Program
Operating
Mode
Time
Hot Keys

5
Timed, Continuously On and Continuously Off operation
To set Central Heating to be Continuously On
press MODE until “CONT ON” is shown.
To set Central Heating to be Continuously Off
press MODE until “CONT OFF” is shown.
2
4
1
8
1
2
6
0
2
4
1
8
1
2
6
0
To set the Central Heating for Timed operation
press MODE until “TIMED ON” or “TIMED OFF” is shown.
2
4
1
8
1
2
6
0
2
4
1
8
1
2
6
0

6
+ Hours
To set + Hours press “+HOURS” and this screen will be shown.
If + Hours is used during an on period, the Central Heating on period will be extended by up to 5 hours.
Press “+” until the required setting is shown and then press OK

7
Time/Date
Summer/Winter time is automatically updated
At installation the “SET TIME/DATE” menu option activates automatically (starts at step 2)
1. Press MENU and this
screen will be displayed
2. Press NEXT until this
screen is displayed
3. Press OK and this
screen will be displayed.
Press “+” and “-” until the
correct HOURS is shown.
4. Press OK and this
screen will be displayed.
Press “+” and “-” until the
correct MINUTES is
shown.
5. Press OK and this
screen will be displayed.
Press “+” and “-” until the
current YEAR is shown.
6. Press OKand this
screen will be displayed.
Press “+” and “-” until the
current MONTH is shown.
7. Press OK and this
screen will be displayed.
Press “+” and “-” until the
current DAY is
shown.
8. Press OK and this
screen will be displayed.
When it disappears press
EXIT to return to normal
operation

8
Time Program
1Press MENU and this
screen will be displayed,
then press OK.
2 Press “+” and “-” until
the desired Hours figure is
shown and then press OK
Press “+” and “-” until the
desired Minutes figure is
shown and then press OK
3 Press “+” and “-” until
the desired Hours figure is
shown and then press OK
Press “+” and “-” until the
desired Minutes figure is
shown and then press OK
4Press “+” and “-” until
the desired Hours figure is
shown and then press OK
Press “+” and “-” until the
desired Minutes figure is
shown and then press OK
5 Press “+” and “-” until
the desired Hours figure is
shown and then press OK
Press “+” and “-” until the
desired Minutes figure is
shown. If you would like
to set a 3rd On period
continue programming in
the same manner,
otherwise press DAY.
6 Press YES to Copy
Monday’s On/Off times to
Tuesday, otherwise press
NO.
7 Program the remainder of the times in the same
manner before pressing EXIT to return to the
Menu and then EXIT again to return to normal
operation

9
Holiday Mode
1 Press MENU and this
screen will be shown.
2 Press NEXT until this
screen is shown.
3 This screen will be
shown briefly before
automatically moving to
the next screen
4 Press “+” and “-” until
the desired Holiday Year is
shown.
5. Press “OK” and this
screen will be shown.
Press “+” and “-” until the
desired Holiday Month is
shown.
6. Press “OK” and this
screen will be shown.
Press “+” and “-” until the
desired Holiday Day is
shown.
7. Press “OK” and this
screen will be shown.
Press “+” and “-” until the
required Holiday Duration
is shown.
8 Press “OK” and this
screen will be briefly
shown before moving to
the Menu, press EXIT to
return to normal operation

10
To change the LCD backlight intensity proceed as follows.
Display Backlight Intensity
1 Press MENU and this screen
will be shown.
2 Press NEXT until this screen is
shown.
3 Press OK and this screen will be
shown, then press “+” or “-” until
the required setting is shown.
Press OK to return to the Menu
and then EXIT to return to normal
operation.

11
The Timer can be returned to Factory Settings as follows.
Reset To Factory Settings
1 Press MENU and this screen will be shown.
2 Press NEXT until this screen is shown.
3 Press OK and this screen will be shown.
4 Press OK to Reset and this screen will be briefly
shown before returning to the Menu.
Press EXIT to return to normal operation.

Ideal, P.O. Box 103, National Ave, Kingston Upon Hull, HU5 4JN. Tel. 01482
492251 Fax. [phone]. Registration No. London 322 137.
Ideal Stelrad Group pursues a policy of continuing improvement in the design and performance
of its products. The right is therefore reserved to vary specication without notice.
August 2012 UIN 208904 A01
