IDEM SAFETY SWITCHES SCR-31-i User manual

SCR
-
Viper Safety Relays
SCR
-
31
-
i / SCR
-
21
-
i / SCR
-
31P
-
i
The new generation of safety relays from IDE
Single or Dual channel operation
The Viper
Safety Relays range from IDEM are designed to meet the latest safety standards and
offer enhanced LED diagnostics and simplified wiring. Applications include safety interloc
switches, emergency e-stop devices door guard monitoring. The SCR-31P-i is design to be
compatible with OSSD devices.(e.g. Light Curtains)
The Viper Safety Relays range includes output expansion units that can be directly wired to SCR-
21-i / SCR-31-i / SCR-31P-i safety relays to increase the number of safety output contacts. The
expansion modules are available with either immediate or time-delayed output contacts.
The SCR-21-i / SCR-31-i / SCR-31P-i internal logic uses force guided relays to achieve cross
monitoring, this ensures that a single fault does not lead to the loss of the safety function and that
all faults are detected at or before the next safety demand.
Monitored Manual or Auto Start/Reset
Up to 3 Safety output contacts
1 Auxiliary output contact
(Depending on model No.)
Contactor feedbac chec
Easy diagnosis of status via 6 LEDs
Up to PLe, SILCL 3, Category 4
22.5mm DIN rail mounting
24Vac/dc operation
Emergency stop and guard interloc
monitoring
Output expansion units available to
increase number of outputs.
Functional Description
When the control line inputs are closed and the start/reset condition
has been met the safety output contacts close.
The safety relay outputs open when the inputs are de-activated or if
there is a power failure. When dual channel inputs are used it is not
necessary to synchronise switching of the input channels.
When operating in the monitored manual reset configuration the
reset button must perform a ma e-then-brea action before the
safety relay will activate.
External device feedbac contacts can be monitored via the reset
loop.
Block Diagram and Connections
Terminal Description
A1 Power Supply
A2 Power Supply
S11 24Vd.c. Control voltage
S12 Control Line
S13 Control Line (SCR-21-i / SCR-31-i only)
S14 Control Line (SCR-31P-i only)
S10 Control Line
S21 Auto Start
S22 Monitored Manual Start
13-14 Safety Output Contact 1
23-24 Safety Output Contact 2
33-34 Safety Output Contact 3 (SCR-31-i / SCR-31P-i)
41
-
42
31-32
Auxiliary Output Contact 1
(SCR
-
31
-
i / SCR
-
31P
-
i)
Auxiliary Output Contact 1 (SCR-21-i)
SCR
-
21
-
i / SCR
-
31
-
i
SCR
-
31
P
-
i

To request this datasheet in other languages please contact i[email protected]
Um dieses Datenblatt in Deutscher Sprache wenden Sie sich bitte anfordem [e-mail]
Variants
Part No.
Description
280001 SCR-21-i, AC/DC 24 V, (50-60Hz), Fixed screw terminals
280002 SCR-31-i, AC/DC 24 V, (50-60Hz), Fixed screw terminals
280003 SCR-31P-i, AC/DC 24 V, (50-60Hz), Fixed screw terminals
280001-P SCR-21-i, AC/DC 24 V, (50-60Hz), Pluggable Terminals
280002-P SCR-31-i, AC/DC 24 V, (50-60Hz), Pluggable Terminals
280003-P SCR-31P-i, AC/DC 24 V, (50-60Hz), Pluggable Terminals
Application Circuits
Fig.1 SCR-21-i, Single Channel, E-Stop, Auto Reset Fig.2 SCR-21-i, Dual Channel, Guard Interlock, anual Reset
Fig.3
SCR
-
31
-
i, Dual Channel, E
-
stop, anual Reset
Fig.4
SCR
-
31P
-
i, Dual Channel, OSSD Inputs, Auto Reset
Fig.5
Auto Reset
Fig.6
anual Reset
Fig.7
Contactor Feedback Check ( anual Reset)
Electrical Connection
•A power supply unit with electrical isolation from the mains supply must be connected.
•External fusing of each safety output contact is necessary, a 4A. slow-blow or 6A. quic action) must be provided.
•The maximum cabling and connecting resistance of control lines must not be exceed 300 ohms.

Pour obtenir cette fiche en Francais, euillez contacter [e-mail]
Para solicitor esta hoja de datos en Espanol, por fa our contacto con [email protected]om
IDE Safety Switches
Viper Safety Relays
SCR
-
21
-
i / SCR
-
31
-
i
/ SCR
-
31P
-
i
Dimensions Diagnostic LEDs
POWER Power to the safety relay.
RESET Reset loop S11-S21 or S11-S22 is closed.
CH1 Channel 1 control loop S11-S21 is closed.
CH2 Channel 2 control loop S13-S10 is closed.
K1 Power to Internal relay K1.
K2 Power to Internal relay K2.
Safety Characteristics
Characteristic Data according to
IEC
62061
Safety Integrity Level
SIL3
PFH
4.1 E
-
10 (
1/h
)
(0.4% of SIL3 (1
E
-
07
(1/h))
PFD
av
3.6 E
-
05
(
1/h
) (3.6% of SIL3 (1
E
-
03)
Characteristic Data according to
EN ISO
13849
-
1
Performance Level
e
Category
4
MTTF
d
142a
(High)
Diagnostic Coverage
99%
(High)
Specification
Standards
EN/ISO13849
-
1; EN /
SO
13849
-
2; EN62061; EN
60204
-
1; EN/
ISO
12100
;UL508
Power supply Circuit
Rated o
perating
v
oltage
24V AC/DC
Operating
v
oltage
t
olerance
-
15%
-
+10%
Rated
s
upply
f
requency
50Hz
–
60Hz
Rated supply current
75mA
Power consumption
24V
AC/
DC
2
.5
W
Control Circuits
Rated output voltage
S11
24V DC
Input current
S11..S14
100mA
Response
t
ime
100ms
Release t
ime
25ms
Recovery
t
ime
Approx. 1s
Output Circuits
Rated o
utput
v
oltage
250VAC
Max.
c
urrent per output
6A
Max. t
otal
current all outputs
6
A
Safety contact brea ing Capacity
AC
230V, 4A for AC
-
15
DC
24V, 30W, 2A, DC
-
13
Minimum contact load
10V 10mA
Min.
c
ontact fuses
4A S
low blow, 6A
F
ast blow
Contact material
AgSnO
2
Contact service life
10 x 10
6
General Data
Rated impulse withstand voltage
4 V
Rated insulation voltage
250V
Degree of protection
IP
Temperature range
-
20C + 55C
Degree of contamination
2
Overvoltage
c
ategory
III
Weight
0.15
g
Mounting
Any p
osition

IDE SAFETY SWITCHES Ltd, 2 Ormside
Close, Hindley Industrial Estate, Hindley Green, Wigan, WN2 4HR UK. Tel: [phone] Fax.: [phone]
IDE (USA
)
-
4416 Technology Way
, Fremont, CA 94538
Tel: [phone]
Email:
[e-mail]
Web:
www.idemsafety.com
Do
c.
10258
0
Jun
18
SAFETY WARNINGS
•Installation should only be carried out by
competent and authorised personnel and in
accordance with the instructions in this manual.
•Only make electrical connections when the
device is isolated from the main supply.
•If “Automatic Start” is selected be aware that
safety output contacts will switch immediately
after the power supply is connected.
•Opening the device will void the warranty. Never
attempt to repair any device.
•Adhere to Safety Checks.
•DO NOT DEFEAT, TA PER, OR BYPASS THE
SAFETY FUNCTION. FAILURE TO DO SO CAN
RESULT IN DEATH OR SERIOUS INJURY.
•L'installation doit être effectuée par un personnel
compétent et autorisé et en conformité avec les
instructions de ce manuel.
•faites uniquement des connexions électriques lorsque
l'appareil est isolé de l'alimentation principale.
•Si "Démarrage automatique" est sélectionné être
conscient que les contacts de sortie de sécurité passeront
immédiatement après l'alimentation est connectée.
•Ouverture de l'appareil annule la garantie. Ne jamais
tenter de réparer tout appareil.
•Adhérer à des contrôles de sécurité.
•NE DÉFAITE PAS, SABOTAGE, OU DE CONTOURNER LA
FONCTION DE SÉCURITÉ. ANQUE ENT À S'Y PEUT
ENTRAÎNER LA ORT OU DES BLESSURES GRAVES
Installation and aintenance Information Regarding UL 508
Installation should as per EN 60204-1 in addition to any local
regulations. The safety relay should be mounted inside a
cabinet enclosure and on a 35mm DIN rail according to DIN
EN 60715. No maintenance is required, there are no
serviceable parts. (Refer to Safety Chec s). The product is
designed to be a component of a customised safety
orientated control system. It is the responsibility of the user
to ensure the correct overall functionality of its systems and
machines. IDEM, its subsidiaries and affiliates, are not in a
position to guarantee all of the characteristics of a given
system or product not designed by IDEM.
Pilot Duty R300, B300
Single contact must be used
250V AC/DC / 6,0A
Resistive
Single contact must be used
250V AC/DC / 6,0A
General Purpose
All contacts at once can be used.
USE COPPER OR COPPER-CLAD ALUMINUM CONDUCTORS
Maximum surround air temperature 40°C
Safety Checks.
1. Ensure the appropriate safety level is achieved for the application function.
2. The safety functions must be tested regularly. For applications were infrequent use is foreseeable, the system must have a manual
function test. At least once per month for PLe Cat3/4 or once per year for PLd Cat3 (ISO13849-1 / ISO14119).
EC Declaration of Conformity
Manufacturer: IDEM SAFETY SWITCHES Ltd.
2 Ormside Close, Hindley Industrial Estate, Hindley Green, Wigan, WN2 4HR, UK
Product: Safety Emergency Stop De ices
Model types: SCR-21-i
SCR-31-i
SCR-31P-i
The abo e products conform to the safety requirements of the following directi es and standards:
Machinery Directi e 2006/42/EC
EMC Directi e 2014/30/EC
Low Voltage Directi e 2006/95/EC
EN 13849-1:2015
EN 13849-2:2012
EN 62061:2005+A2:2015
EN 61508 (Parts 1-7): 2011-02
EN 60204-1:2006+A1:2009+AC:2010
EN 50178:1997
Third Party Certification: NB 0035 TUV Rheinland Industrie Ser ice GmbH
M. Mohtasham
Managing Director
