Idis DV-2232 User manual

AI BOX
DV-2232
Quick Guide

2
Before reading this manual
This manual contains basic instructions on installing and using AI BOX, an IDIS product.
Users who are using this product for the rst time, as well as users with experience using comparable products,
must read this manual carefully before use and heed to the warnings and precautions contained herein while using
the product. Safety warnings and precautions contained in this manual are intended to promote proper use of the
product and thereby prevent accidents and property damage and must be followed at all times.
Once you have read this manual, keep it at an easily accessible location for future reference.
•The manufacturer will not be held responsible for any product damage resulting from the use of unauthorized parts and
accessories or from the user's failure to comply with the instructions contained in this manual.
•It is recommended that rst-time users of AI BOX and individuals who are not familiar with its use seek technical
assistance from their retailer regarding product installation and use.
•If you need to disassemble the product for functionality expansion or repair purposes, you must contact your retailer and
seek professional assistance.
•Both retailers and users should be aware that this product has been certied as being electromagnetically compatible for
commercial use. If you have sold or purchased this product unintentionally, please replace with a consumer version.
•This equipment has the PFC (Power Factor Correction) circuit. For stable operation, use a sign-wave output UPS with an
AVR(Automatic Voltage Regulator).
Safety Precautions
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the product’s enclosure that may be of sucient magnitude to
constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.
Symbol Publication Description
IEC60417, No.5032 Alternating current
WARNING
Hazardous moving parts
Keep away from moving fan blades
AVERTISSEMENT
Pièces mobiles dangereuses
Se tenir éloigné des pales de ventilateurs mobiles

Before reading this manual
3
Important Safeguards
1. Read Instructions
All the safety and operating instructions should be read before the appliance
is operated.
2. Retain Instructions
The safety and operating instructions should be retained for future reference.
3. Cleaning
Unplug this equipment from the wall outlet before cleaning it. Do not use
liquid aerosol cleaners. Use a damp soft cloth for cleaning.
4. Attachments
Never add any attachments and/or equipment without the approval of the
manufacturer as such additions may result in the risk of re, electric shock or
other personal injury.
5. Water and/or Moisture
Do not use this equipment near water or in contact with water.
6. Ventilation
Place this equipment only in an upright position. This equipment has an
open-frame Switching Mode Power Supply (SMPS), which can cause a re or
electric shock if anything is inserted through the ventilation holes on the side
of the equipment.
7. Accessories
Do not place this equipment on an unstable cart, stand or table. The
equipment may fall, causing serious injury to a child or adult, and serious
damage to the equipment. Wall or shelf mounting should follow the
manufacturer's instructions, and should use a mounting kit approved by the
manufacturer.
This equipment and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the equipment and cart
combination to overturn.
8. Power Sources
This equipment should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power, please
consult your equipment dealer or local power company. You may want to
install a UPS (Uninterruptible Power Supply) system for safe operation in order
to prevent damage caused by an unexpected power stoppage. Any questions
concerning UPS, consult your UPS retailer.
This equipment should be remain readily operable.
9. Power Cords
Operator or installer must remove power and TNT connections before
handling the equipment.
10. Lightning
For added protection for this equipment during a lightning storm, or when it
is left unattended and unused for long periods of time, unplug it from the wall
outlet and disconnect the antenna or cable system. This will prevent damage
to the equipment due to lightning and power-line surges.
11. Overloading
Do not overload wall outlets and extension cords as this can result in the risk
of re or electric shock.
12. Objects and Liquids
Never push objects of any kind through openings of this equipment as they
may touch dangerous voltage points or short out parts that could result in a
re or electric shock. Never spill liquid of any kind on the equipment.
13. Servicing
Do not attempt to service this equipment yourself. Refer all servicing to
qualied service personnel.
14. Damage requiring Service
Unplug this equipment from the wall outlet and refer servicing to qualied
service personnel under the following conditions:
A. When the power-supply cord or the plug has been damaged.
B. If liquid is spilled, or objects have fallen into the equipment.
C. If the equipment has been exposed to rain or water.
D. If the equipment does not operate normally by following the operating
instructions, adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualied technician to
restore the equipment to its normal operation.
E. If the equipment has been dropped, or the cabinet damaged.
F. When the equipment exhibits a distinct change in performance ─this
indicates a need for service.
15. Replacement Parts
When replacement parts are required, be sure the service technician has
used replacement parts specied by the manufacturer or that have the same
characteristics as the original part. Unauthorized substitutions may result in
re, electric shock or other hazards.
16. Safety Check
Upon completion of any service or repairs to this equipment, ask the service
technician to perform safety checks to determine that the equipment is in
proper operating condition.
17. Field Installation
This installation should be made by a qualied service person and should
conform to all local codes.
18. Correct Batteries
Warning: Risk of explosion if battery is replaced by an incorrect type. Replace
only with the same or equivalent type. Dispose of used batteries according to
the instructions. The battery shall not be exposed to excessive heat such as
sunshine, re or the like.
Avertissement: risque d'explosion en cas d'utilisation d'une batterie de type
incorrect. Le remplacer uniquement par un type identique ou équivalent.
Mettre les batteries usées au rebut conformément aux instructions. La batterie
ne doit pas être exposée à une source de chaleur excessive, telle que le soleil,
le feu, ou analogue.
19. Tmra
A manufacturer’s maximum recommended ambient temperature (Tmra)
for the equipment must be specied so that the customer and installer may
determine a suitable maximum operating environment for the equipment.
20. Elevated Operating Ambient Temperature
If installed in a closed or multi-unit rack assembly, the operating ambient
temperature of the rack environment may be greater than room ambient.
Therefore, consideration should be given to installing the equipment in an
environment compatible with the manufacturer’s maximum rated ambient
temperature (Tmra).
21. Reduced Air Flow
Installation of the equipment in the rack should be such that the amount of
airow required for safe operation of the equipment is not compromised.
22. Mechanical Loading
Mounting of the equipment in the rack should be such that a hazardous
condition is not caused by uneven mechanical loading.
23. Circuit Overloading
Consideration should be given to connection of the equipment to supply
circuit and the eect that overloading of circuits might have on over current
protection and supply wiring. Appropriate consideration of equipment
nameplate ratings should be used when addressing this concern.
24. Reliable Earthing (Grounding)
Reliable grounding of rack mounted equipment should be maintained.
Particular attention should be given to supply connections other than direct
connections to the branch circuit (e.g., use of power strips).
HDMI Port Precautions
•Use a certied cable marked with an HDMI logo when using HDMI.
The screen may not display or a connection error may occur if you do
not use a certied HDMI cable.
•It is recommended that you use the following HDMI cable type.
–High-speed HDMI Cable
–High-speed HDMI Cable with Ethernet

Before reading this manual
4
In-Text
Symbol Type Description
Caution Important information concerning a specic function.
Note Useful information concerning a specic function.
User’s Caution Statement
Caution: Any changes or modications to the equipment not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
FCC Compliance Statement
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART
15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE
WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE
RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO
CAUSE HARMFUL INTERFERENCE, IN WHICH CASE USERS WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT THEIR OWN EXPENSE.
WARNING: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID
THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT.
THIS CLASS OF DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE CAUSING EQUIPMENT
REGULATIONS.
WEEE (Waste Electrical & Electronic Equipment)
Correct Disposal of This Product
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household
wastes at the end of its working life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote
the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
oce, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal.

Before reading this manual
5
Copyright
© 2020 IDIS Co., Ltd.
IDIS Co., Ltd. reserves all rights concerning this manual.
Use or duplication of this manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited.
Contents of this manual are subject to change without prior notice.
Registered Trademarks
IDIS is a registered trademark of IDIS Co., Ltd.
Other company and product names are registered trademarks of their respective owners.
The information in this manual is believed to be accurate as of the date of publication even though explanations of some
functions may not be included. We are not responsible for any problems resulting from the use thereof. The information
contained herein is subject to change without notice. Revisions or new editions to this publication may be issued to incorporate
such changes.
The software included in this product contains some Open Sources. You may obtain the corresponding source code which we
have to distribute according to the license policy. Go to Client Menu - About page for more information. This product includes
software developed by the University of California, Berkeley and its contributors, and software developed by the OpenSSL Project
for use in the OpenSSL Toolkit (http://www.openssl.org/). Also, this product includes cryptographic software written by Eric
Young ([email protected]), and software written by Tim Hudson ([email protected]).

6
Table of Contents
1
2
3
Part 1 – Product Information .................................8
Product Features ................................................................8
Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Overview ......................................................................11
Front Panel...............................................................................11
Rear Panel ...............................................................................12
Part 2 - Installation .........................................14
System Installation .............................................................14
Installation...............................................................................14
Upgrade .................................................................................16
Camera Installation.............................................................18
General Guidline for VA Box Camera ......................................................18
People Counting .........................................................................19
Crowd Detection .........................................................................19
Social Distancing Violation ...............................................................20
Mask Rule Violation ......................................................................20
Part 3 - VA in the Box Setting via NVR ........................21
Camera Protocol .........................................................................21
Firmware Upgrade .......................................................................21
VA Box Setup...................................................................21
VA Box ..................................................................................22
VA BOX_Registration .....................................................................22
VA BOX_Setup ...........................................................................23
VA Box_Event Set up .....................................................................28

Table of Contents
7
4
5
Part 4 -View Analysis in Remote Client .......................31
VA Box .........................................................................31
VA Box View..............................................................................31
Personnel Adjustment....................................................................31
VA Dashboard ..................................................................32
VA Dashboard Screen ....................................................................32
Registration and Search ..................................................................33
Site Panel Setup..........................................................................34
Violation .................................................................................35
Event ....................................................................................37
Part 5 - Appendix ...........................................38
Troubleshooting ...............................................................38
Specications ..................................................................38

8
Product Features
This VA in the Box (VA Box) analyzes the live video from DirectIPTM cameras and transmits the video over Ethernet
connections. This product oers the following features:
●32-channel H.264 and H.265 IP camera supported
●DirectIPTM protocol supported
●Various image analysis function such as People Counting, Crowd Detection, Social Distancing Violation, Mask Rule
Violation.
–People Counting : Counts the number of people passing through the line on the video.
–Crowd Detection : Alarm occurs according to the analysis of the number of people detected in the video.
–Social Distancing Violation : Alarm occurs according to the estimating and analyzing the distance between
people detected in the video.
–Mask Rule Violation : Selected camera detects a face and an event occurs according to the mask wearing rule set
on the face.
●Conguration of device settings and integrated management of multiple VA Boxes on the NVR (Network Video
Recorder)
Part 1 – Product Information

Part 1 – Product Information
9
Example2 : VA Box Connection Diagram Using PoE Switch
PWR
CONSOLE
/ PoE
RESET DIAG
PoE
21 43 65 87 1091211
1 3 5 7 9 11 13 15
10 12 14 16
2 864
NVR (Network Video Recorder)
Network Camera
VA Box (DV-2232)
PoE Switch
Example 1 : VA Box Connection Diagram Using PoE Switch
PWR
CONSOLE
/ PoE
RESET DIAG
PoE
21 43 65 87 1091211
1 3 5 7 9 11 13 15
10 12 14 16
2 864
Network Camera
VA Box (DV-2232)
NVR (Network Video Recorder)
PoE Switch

Part 1 – Product Information
10
Example 3 : VA Box Connection Diagram Using PoE Switch
PWR
CONSOLE
/ PoE
RESET DIAG
PoE
21 43 65 87 1091211
1 3 5 7 9 11 13 15
10 12 14 16
2 864
NVR (Network Video Recorder)
Network Camera
VA Box (DV-2232)
PoE Switch
Example 4 : VA Box Connection Diagram without PoE Switch
1 3 5 7 9 11 13 15
10 12 14 16
2 864
Network Camera
VA Box (DV-2232)
NVR (Network Video Recorder)
Types of Cables
AUDIO IN
AUDIO OUT VGA OUT HDMI
eSATA
NETWORK
CLIENT
VIDEO IN / PoE
NC C NO ARI G RS -485
- +
A/1 A/2 A/3 A/4 G Tx Rx
RS -232
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DONOT REMOVE COVER (OR BACK).
NOUSER-SERVICEABLE PARTS INSIDE.
REFERSERVICING TO QUALIFIED
SERVICEPERSONNEL.
1 3 2 4
CAUTION
RISKOF ELECTRIC SHOCK
DONOT OPEN
A C E G
VIDEO IN
Ext.
B D F H
100-240V~
AUDIO IN
AUDIO OUT VGA OUT HDMI
eSATA
NETWORK
CLIENT
VIDEO IN / PoE
NC C NO ARI G RS -485
- +
A/1 A/2 A/3 A/4 G Tx Rx
RS -232
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DONOT REMOVE COVER (OR BACK).
NOUSER-SERVICEABLE PARTS INSIDE.
REFERSERVICING TO QUALIFIED
SERVICEPERSONNEL.
1 3 2 4
CAUTION
RISKOF ELECTRIC SHOCK
DONOT OPEN
A C E G
VIDEO IN
Ext.
B D F H
100-240V~
Video Encoder
NVR (Network Video Recorder)
Analog Camera
LAN Cable (Data + PoE Power)

Part 1 – Product Information
11
Accessories
Upon unpacking the product, check the contents inside to ensure that all the following contents are included.
●VA in the Box
●Instruction Manual (This document)
●Keyboard
●Mouse
●L wrench
●Screw
Overview
Front Panel
1 2 3
4
1Power Button 2Power LED 3HDD LED 4USB Port
1Power Button
Turn the system on or o.
2Power LED
Is lit when the unit is turned on.
3HDD LED
Flickers when the unit accesses to the hard disk drive.
4USB Port
Connect USB devices such as a mouse, keyboard, USB storage device or printer.

Part 1 – Product Information
12
Rear Panel
1
234567890
1
Power In
2
Audio Out
3
RS232
4
VGA (D-Sub)
5
E-SATA
6
USB 3.0
7
DP
8
HDMI
9
USB 2.0
0
Network (LAN1)
1Power In
Connect a power cord.
2Audio Out
Connect an amplier (Line-out). The NVR does not have amplied audio output, so you will need a speaker with an
amplier.
3RS232
Connect a remote control device for RS232 communication.

Part 1 – Product Information
13
4VGA (D-Sub)
Connect an HD (High-Denition) PC monitor which supports a D-Sub interface. Connect a monitor before turning
on the system. Video might not be displayed on the monitor when connecting a monitor after turning on the
system.
5E-SATA
Connect an external hard disk drive which supports an eSATA interface.
6USB 3.0
Connect USB devices such as a mouse, keyboard, USB storage device or printer.
7DP
Connect an HD (High-Denition) PC monitor which supports a DP interface.
8HDMI
Connect an HD (High-Denition) PC monitor which supports an HDMI interface.
0Network (LAN1)
Connect a CAT 5e or higher cable with an RJ-45 connector.
•The location of ports in slots can be dierent from the image above.
•If the LAN 1 and LAN 2 is connected to the same network, the system may malfunction.

14
Part 2 - Installation
System Installation
Installation
1 Download DV-2232 software from IDIS website
(www.idisglobal.com).
2 Execute InstStarterVABox.exe in the version
information folder of the downloaded le.
• Installing for the rst time after purchase, install
DV-2232 S/W using the installation le on the
desktop.
- C:\Users\admin\Desktop\Version\Setup
3 Select the language.
4 Select the Next after reading the instructions.
5 After reading the DV-2232 license terms, choose
whether to accept it, and then select Next.
If you do not agree, it cannot proceed with the
installation.

Part 2 - Installation
15
6 Read the full CUDA End User License Agreement,
choose whether to accept it, and then select Next.
If you do not agree, it cannot proceed with the
installation.
7 After specifying the installation path, select Next..
8 Check the Conrm Installation then select Next.
9 Wait for the installation to complete.
10
Check the installation completion message and click
Close to complete the installation.

Part 2 - Installation
16
Upgrade
1 Execute InstStarterVABox.exe in the version
information folder of the downloaded le.
• Installing for the rst time after purchase, install
DV-2232 S/W using the installation le on the
desktop.
- C:\Users\admin\Desktop\Version\Setup
2 Select the language.
3 After reading the instructions, Select the Upgrade
ans then Next.
4 After reading the DV-2232 license terms, choose
whether to accept it, and then select Next..
If you do not agree, it cannot proceed with the
installation.
5 Read the full CUDA End User License Agreement,
choose whether to accept it, and then select Next..
If you do not agree, it cannot proceed with the
installation.

Part 2 - Installation
17
6 Check the Conrm Installation then select Next.
7 Wait for the installation to complete.
8 Check the installation completion message and click
Close to complete the installation.

Part 2 - Installation
18
Camera Installation
General Guidline for VA Box Camera
In order to properly operate and manage VA Box such as cameras, especially people counting, Crowd Detection,
Social distance violations, and mask rule violations, the following must be applied.
Make sure that the lighting is sucient.
60°60°
30°
30°
[Make sure there is enough light]
The Exceeding the limit, Crowd Detection, Social Distancing Violation and Mask Rule Violation of the VA in
the Box may cause errors in actual measurements. So there may be errors in the actual measurement. In the
following conditions, the analytical performance may suer due to faulty detections.
• If there is not enough light.
• If it is dicult to obtain a sucient view.
• If only part of the object is visible at the edge of the eld of view.
• When several extremely fast moving objects appear randomly in the image.
• When a person is lying down or sitting without standing upright.
• When a moving object is too close to the camera.
• When several people move as a group and their motions block one another.
• When an object moves quickly.
• If an object is reected on the oor, wall, glass, metal or water or makes a shadow from a light source.
• If the position of the camera diers from the direction of a light source and it makes a shadow.
• Fisheye analysis not supported.
• Corridor Format analysis not recommended.
• When it can be recognized as a person such as a mannequin or video screen.

Part 2 - Installation
19
People Counting
Camera Installation
The whole body appears at the place to be counted, and it is installed diagonally so that the front and rear people passing by do not block each other.
- It is installed so that the movement of a person passing through the boundary line can be easily captured.
-The image should be installed so that the person does not tilt more than 30 degrees, and the size of the person on the image should
be larger than 1/16th of the image size.
60°60°
30°
30°
In the case of VA in the Box people counting, the recognition rate may decrease in the following cases.
• If there is a narrow gap between people passing through the counter line.
• A congested environment in which both incoming and outgoing are made at the same time based on the
counting line.
Crowd Detection
In the case of VA in the Box Crowd Detection, the recognition rate may decrease in the following cases.
• Place with a large oating population
• People who near the camera cover the body of the person behind.

Part 2 - Installation
20
Social Distancing Violation
In the case of VA in the Box Social Distancing Violation, the recognition rate may decrease in the following
cases.
• Only part of the human body is visible
• The perspective of distant and close people is lost due to a horizontal or low-angle camera.
• People close to the camera occupy too much area of the image to obscure nearby people
• People who near the camera cover the person in around.
Mask Rule Violation
Camera Installation
The conditions must be satisfied to determine whether the subject violates the mask rules. It is recommended that the camera be installed at the
average height of a person.
- When the resolution is 1920x1080, it can be detected when the size of the face is over 50x50 pixels.
- Based on the front of a person's face, it is detected only within 30°C up and down and 60°C left and right.
60°60°
30°
30°
