Idis TC-D Series User manual

TC-D
Series
Installation Manual
TC-D5511RX

2
This is a basic installation manual for use of an IDIS camera. Users who are using this product for the rst time, as
well as users with experience using comparable products, must read this operation manual carefully before use and
heed to the warnings and precautions contained herein while using the product. Safety warnings and precautions
contained in this operation manual are intended to promote proper use of the product and thereby prevent accidents
and property damage and must be followed at all times. Once you have read this operation manual, keep it at an easily
accessible location for future reference.
•The manufacturer will not be held responsible for any product damage resulting from the use of unauthorized parts and
accessories or from the user's failure to comply with the instructions contained in this manual.
•The information in this document is believed to be accurate as of the date of publication even though explanation
about some functions may not be incorporated. The manufacturer is not responsible for any problems resulting from
the use thereof. The information contained herein is subject to change without notice. Revisions or new editions to this
publication may be issued to incorporate such changes.
•It is recommended that rst-time users of this camera and individuals who are not familiar with its use seek technical
assistance from their retailer regarding product installation and use.
•If you need to disassemble the product for functionality expansion or repair purposes, you must contact your retailer and
seek professional assistance.
•Both retailers and users should be aware that this product has been certied as being electromagnetically compatible for
commercial use. If you have sold or purchased this product unintentionally, please replace with a consumer version.
Safety Symbols
Symbol Publication Description
IEC60417, No.5031 Direct current
In-Text
Symbol Type Description
Caution Important information concerning a specic function.
Note Useful information concerning a specic function.
Before reading this manual

Before reading this manual
3
Safety Precautions
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Important Safeguards
1. Read Instructions
All the safety and operating instructions should be read before the
appliance is operated.
2. Retain Instructions
The safety and operating instructions should be retained for future
reference.
3. Cleaning
Unplug this equipment from the wall outlet before cleaning it. Do not
use liquid aerosol cleaners. Use a damp soft cloth for cleaning.
4. Attachments
Never add any attachments and/or equipment without the approval
of the manufacturer as such additions may result in the risk of re,
electric shock or other personal injury.
5. Water and/or Moisture
Do not use this equipment near water or in contact with water.
6. Placing and Accessories
Do not place this equipment on an wall or ceiling that is not strong
enough to sustain the camera. The equipment may fall, causing
serious injury to a child or adult, and serious damage to the
equipment. Wall or shelf mounting should follow the manufacturer's
instructions, and should use a mounting kit approved by the
manufacturer.
This equipment and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause the
equipment and cart combination to overturn.
Do not place this equipment in an enclosed space. Sucient
ventilation is required to prevent an increase in ambient temperature
which can cause malfunction or the risk of re.
7. Power Sources
This equipment should be operated only from the type of power
source indicated on the marking label. If you are not sure of the
type of power, please consult your equipment dealer or local power
company. You may want to install a UPS (Uninterruptible Power
Supply) system for safe operation in order to prevent damage caused
by an unexpected power stoppage. Any questions concerning UPS,
consult your UPS retailer.
This equipment should be remain readily operable.
8. Power Cord
Operator or installer must remove power and TNT connections before
handling the equipment.
9. Lightning
For added protection for this equipment during a lightning storm,
or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable
system. This will prevent damage to the equipment due to lightning
and power-line surges. If thunder or lightning is common where the
equipment is installed, use a surge protection device.
10. Overloading
Do not overload wall outlets and extension cords as this can result in
the risk of re or electric shock.
11. Objects and Liquids
Never push objects of any kind through openings of this equipment
as they may touch dangerous voltage points or short out parts that
could result in a re or electric shock. Never spill liquid of any kind on
the equipment.
12. Servicing
Do not attempt to service this equipment yourself. Refer all servicing
to qualied service personnel.
13. Damage requiring Service
Unplug this equipment from the wall outlet and refer servicing to
qualied service personnel under the following conditions:
A. When the power-supply cord or the plug has been damaged.
B. If liquid is spilled, or objects have hit the equipment.
C. If the equipment has been exposed to rain or water.
D. If the equipment does not operate normally by following the
operating instructions, adjust only those controls that are covered
by the operating instructions as an improper adjustment of other
controls may result in damage and will often require extensive work
by a qualied technician to restore the equipment to its normal
operation.
E. If the equipment has been dropped, or the cabinet damaged.
F. When the equipment exhibits a distinct change in performance —
this indicates a need for service.
14. Replacement Parts
When replacement parts are required, be sure the service technician
has used replacement parts specied by the manufacturer or that
have the same characteristics as the original part. Unauthorized
substitutions may result in re, electric shock or other hazards.
15. Safety Check
Upon completion of any service or repairs to this equipment, ask the
service technician to perform safety checks to determine that the
equipment is in proper operating condition.
16. Field Installation
This installation should be made by a qualied service person and
should conform to all local codes.
17. Tmra
A manufacturer’s maximum recommended ambient temperature
(Tmra) for the equipment must be specied so that the customer and
installer may determine a suitable maximum operating environment
for the equipment.

Before reading this manual
4
FCC Compliance Statement
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART
15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE
WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE
RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE
HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO
CAUSE HARMFUL INTERFERENCE, IN WHICH CASE USERS WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT THEIR OWN EXPENSE.
WARNING: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID
THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. THIS CLASS OF DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE
CANADIAN INTERFERENCE CAUSING EQUIPMENT REGULATIONS.
WEEE (Waste Electrical & Electronic Equipment)
Correct Disposal of This Product
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household
wastes at the end of its working life. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote
the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
oce, for details of where and how they can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal.
Copyright
© 2020 IDIS Co., Ltd.
IDIS Co., Ltd. reserves all rights concerning this operation manual.
Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited.
Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements.
Registered Trademarks
IDIS is a registered trademark of IDIS Co., Ltd.
Other company and product names are registered trademarks of their respective owners.
Warning: This product emits infrared light. Do not look into the IR
LED.

5
Table of Contents
1
2
3
Part 1 – Introduction.........................................6
Product Features ................................................................6
Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Overview .......................................................................8
Dome Cover ..............................................................................8
Body .....................................................................................8
I/O Device Port ...........................................................................9
Installation ......................................................................9
Removing the Dome Cover ................................................................9
Installation...............................................................................10
Closing the Dome Cover..................................................................10
Angle Adjustment........................................................................11
Dimension ...............................................................................11
Part 2 - Camera Connection .................................12
DirectCX DVR Layout ...........................................................12
Part 3- Appendix ...........................................13
Troubleshooting ...............................................................13
Specications ..................................................................14

6
Product Features
TC-D5511RX is an analog camera that transmits video
over coaxial.
•DC 12V support
•Smart IR support
•TVI/AHD/SD video output support
•Defog function support
•Wide dynamic range compensation (True WDR) for
improved video quality in high-contrast situations
•Sense-Up support for improved low-lighting video
capture performance
•Day & Night feature (built-in IR cut lter changer)
•Multiple event detection modes: Motion Detection
•Features a xed focus lens(mega pixel lens)
Part 1 – Introduction

7
Accessories
Upon purchasing the product, check inside the box to make sure all the following accessories are included. External
appearances and colors of the accessories may vary depending on the model.
Camera Guide Pattern
Screws (2 ea.) Quick Guide

Part 1 – Introduction
8
Overview
Product color and design may vary depending on the
model.
Dome Cover
Body
12
3
4
5
1Lens
2Rubber Bushing
3Bottom Cover
4IR LED
5Wall/Ceiling Installation Hole
•Lens
Equipped with a xed-focus lens.
•Rubber Bushing
Blocks LED infrared rays.
•Bottom Cover
Allows you to install the camera on a wall or a ceiling.
•IR LED
A sensor inside the camera detects the level of
illumination and activates the IR LED in low-lighting
conditions.
•Wall/Ceiling Installation Hole
Used to screw the camera on a wall or a ceiling.

Part 1 – Introduction
9
I/O Device Port
1
2
3
1Power In (DC 12V)
2BNC Video Out (Yellow Cable)
3OSD Button
•Power In (DC 12V)
Connect it to the power adapter (DC 12V).
•BNC Video Out
Connect it to the DVR.
•OSD Button
Use the button to set the OSD menu.
You can change the video output format by using the
OSD button.
•CVBS: Press the UP button three times, and then
press the center of the OSD button.
•TVI: Press the LEFT button three times, and then
press the center of the OSD button.
•AHD: Press the RIGHT button three times, and then
press the center of the OSD button.
The following table describes the coaxial cable
specications.
<The coaxial cable specications>
Item Content Note
Connector BNC
Cable 3C-2V 5C-2V
Maximum
length
300m 500m
Installation
Installation of this product does not require the use of
special tools.
For more information on other devices comprising the
overall system, refer to their respective installation
manuals.
Product color and design may vary depending on the
model.
Removing the Dome Cover
Turn the dome cover to remove it from the body.

Part 1 – Introduction
10
Installation
•Check the wall or ceiling to see if it needs to be
reinforced. The camera may fall o if the wall or
ceiling is not strong enough to support its weight.
•Install the camera in a shaded area. If the camera
is installed in direct sunlight, it may be aected
adversely.
Use the provided guide pattern to check the distance
between the screw holes if necessary.
Use the screws and anchors provided with the camera
to secure the body on a wall or a ceiling.
Closing the Dome Cover
Remove the protective lm inside of the dome cover.
Attach the dome cover to the bottom cover. Turn the
dome cover clockwise to fasten.

Part 1 – Introduction
11
Angle Adjustment
The lens can be rotated along three axes.
3
1
2
1
Lens Rotation
2
Vertical Rotation
3
Horizontal Rotation
•Lens Rotation
Used to adjust the lens' rotation angle. Turn the
rotator in clockwise or counterclockwise direction.
•Vertical Rotation
Used to adjust the lens' vertical angle. Turn the rotator
in clockwise or counterclockwise direction.
•Horizontal Rotation
Used to adjust the lens' horizontal angle.
Turn the horizontal rotator in the clockwise or
counterclockwise direction.
Dimension
110mm
31mm
78mm

12
DirectCX DVR Layout
DirectCX DVR
TVI Camera
Network
Power
Remote Monitoring
VGA Monitor Out
HDMI Monitor Out
Part 2 - Camera Connection

13
Troubleshooting
Problem Check
The main unit won't turn
on.
•Check the power cable connection.
•Check the power outlet.
I can't see Live videos. •Check the camera's power status.
•Check the connection status of the camera with DVR.
Images are blurry. •Make sure the lens is clean. If not, clean it using a soft piece of cloth or a brush.
•Make sure the lens is in focus. Adjust the focus during daytime.
•If there is too much light coming into the camera or the camera is picking up an
overly bright light source, adjust the camera's position/angle accordingly.
Video color appears
incorrect.
Check the white balance settings. If using the Auto option, it may take some time
for the white balance to be adjusted.
Images are blinking. If the camera is pointed at the sun or a uorescent lamp, adjust the camera's angle
away.
Part 3- Appendix

Part 3- Appendix
14
Specications
These product specications may change without prior notice.
Camera
Image Sensor 1/2.8” CMOS
Max. Resolution 2592 x 1944
Scanning Mode Progressive Scan
Lens type Fixed-focal
Focal Length f=2.8mm
Aperture F2.0
Angular Field of View H: 104.8° / V: 76.9° / D: 130° (f=2.8mm)
Min. Illumination COLOR : 0.15 lux F2.0
B/W : 0 lux (IR LED ON)
Dynamic Range True WDR
Electronic Shutter Speed Auto, Manual (1/30 ~ 1/30,000), Anti-Flicker , Sense-Up (OFF, X2, X4, X8, X16, X32)
Day & Night IR cut lter with auto switch
IR Distance (LEDs) 20m (4ea)
Pan/Tilt/Lens Range Pan: ~175 ~ 175˚, Tilt: 0~64˚, Lens: -90 ~ 90˚
Video
Video Output TVI / AHD / SD
Max. Frame Rate 20fps : 2592 x 1944
12.5fps : 2592 x 1944
30fps : 2560 x 1440
30fps : 1920 x 1080
30fps : 720 X 480
Supported Resolution 2592 x 1944, 2560x1440 ,1920x1080 , 720 X 480

Part 3- Appendix
15
General
Operating Temperature -10˚C ~ 50˚C (14˚F ~ 122˚F)
Boot Up Temperature 0˚C ~ 50˚C (32˚F ~ 122˚F)
Operating Humidity 0% ~ 90%
Power Source DC 12V
Power Consumption Max. 3.4W
Approval FCC, CE
External Dimensions (Ø x H) 110mm x 78mm (4.33" x 3.07")
Weight (Main Unit) 0.177kg (0.39lb)
V1.0

IDIS Co., Ltd.
For more information, please visit at
www.idisglobal.com
