Idis FM4100 User manual

This manual is intended for the users of the FM4100 ceiling mounting bracket.
It includes the instructions for mounting the FM4100 ceiling mounting bracket
to the ceiling.
• This bracket is intended to be used with DC-D4213RX. Ask your
retailer for details on a specic model and do not use it with other
models of cameras.
• This installation should be performed by a qualied service
personnel in conformance to all local codes.
• You may need to reinforce the ceiling. If the ceiling is not strong
enough to support the camera, the camera may fall.
• Do not use this product for other purposes.
Mounting
1 Make a hole in the ceiling to install the
bracket using the provided guide pattern.
2 Place the foot of the product as shown in the
gure and push it into the ceiling.
< O > < X >
3 Mount the bracket to the ceiling, then x it
by turning the screws clockwise.
Be careful not to tighten the screws with too much
force.
4 Assemble the camera body(DC-D4213RX) to
the bracket until it clicks.
When disassembling the product, you can remove the
product by pressing the hook with a at screwdriver.
Hook
FM4100 INSTALLATION MANUAL

IDIS Co., Ltd.
For more information, please visit www.idisglobal.com
Ver.1.0
5 Use the screws (M4 2ea) provided with the
camera to secure on the bracket while it is
temporarily xed with the hook.
6
Adjust the angle.
• Make sure that Eva Cushion is assembled
and rmly pressed against the camera dome
cover, otherwise it will create IR reection.
• Adjust the tilt angle not to cause IR
reection.
7 Assemble the dome cover to the camera
body.
Dimensions
Unit: mm (inch)
96.5 (3.79)
Ø 140.6 (5.53)
Ø 82 (3.22)
57.5 (2.26)
154 (6.06)
Ø 109.8 (4.32)
Ø 136.4 (5.37)
Ø 116.4 (4.58)
Ø 30(1.18)
