Idis DA-AP3000 User manual

This manual is intended for users of the DA-AP3000 mounting bracket. It
includes instructions for mounting the DA-AP3000 mounting bracket to another
bracket.
• This bracket is intended to be used with a specic model of camera.
Do not use it with other models of cameras.
• This installation should be performed by a qualied service
personnel in conformance to all local codes.
• You may need to reinforce the ceiling. If the ceiling is not strong
enough to support the camera, the camera may fall.
• Do not use this product for other purposes.
Mounting
Mount the bracket to the ceiling as follows:
1 Mount bracket onto another bracket(DA-MA2000) and
x it by using the screws. Bracket
(DA-MA2000)
Connect your camera to the bracket as follows:
2 Screw the bottom cover onto bracket.
Bracket
Camera
DA-AP3000 INSTALLATION MANUAL

IDIS Co., Ltd.
For more information, please visit www.idisglobal.com Ver.1.0
3 Attach the dome cover to the bottom cover. Turn the
dome cover clockwise to fasten the dome cover.
4 Turn on power.
Bottom
Cover
Camera
Dome
Cover
Dimensions
Unit: mm (inch)
3 (0.11)
Ø 100 (3.93)
3 - Ø 4.2 (0.16) Hole
2 - M4 TAP
Ø 138 (5.43)
P.C.D. Ø 120 (4.72)
