Logik S105BR14 User manual

Black Glass TV Stand
with Bracket
S105BR14
Instruction Manual

3
CUSTOMER HELPLINE (UK Customers Only)
0844 561 1234
MAX
50”
MAX TV LOAD
50 kg
KG
• Suitable for at screen TVs with screen sizes up to 50”
• Stand Dimensions: Height 122 x Length 105 x Depth 45 cm
• TV Bracket VESA Compliant: Up to 800 x 400mm
• Maximum TV Load: 50 kg
• 3 Shelves
2 people are required to lift the unit during assembly.
ATTENTION - Please note before assembling your TV stand
• Check that you have all the parts and familarise yourself with this installation
guide.
• Make sure you have enough space to layout all the parts. Keep children and
pets away from the work area, small parts could choke them if swallowed.
• Assemble the TV stand on a soft level surface as close to its nal position as
possible.
WARNING
• We do not recommend the use of power drills. Only use hand screwdrivers
and do not over-tighten the components unnecessarily.
• Do not stand or sit on the TV stand, this could cause damage.
• Only use this product when fully assembled.
• Do not place very hot or cold items on any part of the TV stand unless thick
table mats are used.
• When cleaning the TV stand use a damp cloth with washingup liquid or soap.
Do not use washing powder or any other substances containing abrasives.
• Do not place TV near to the front of the TV stand.
• Always sit the TV stand on rm level ground and ensure that the base is fully
in contact with the ground.

4
If items are missing, or damaged contact Partmaster on 0344 800 3456
