IDK NJR-TW01UHD Operating manual

4K@60/HDCP 2.2 AV HDMI Network Extender, Rugged Chassis
NJR-TW01UHD/NJR-RW01UHD
<Command Reference Guide>
Ver.1.0.0
Thank you for choosing our product.
To ensure the best performance of this product, please read this user guide fully and carefully before
using it and keep this manual together with the product for future reference as needed.
IDK Corporation

NJR-TW01UHD/NJR-RW01UHD Command Guide
2
Trademarks
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
Connection Reset and IP NINJAR are registered trademarks of IDK Corporation in Japan.
All other company and product names mentioned in this manual are either registered trademarks or
trademarks of their respective owners. In this manual, the “®” or “™” marks may not be specified.

NJR-TW01UHD/NJR-RW01UHD Command Guide
3
Before reading this manual
All rights reserved.
Some information contained in this Command guide such as exact product appearance, diagrams, menu
operations, communication commands, and so on may differ depending on the product version.
This Command guide is subject to change without notice. You can download the latest version from IDK’s
website at: http://www.idkav.com
The reference manual consists of the following two volumes:
■User guide: Please download the User guide from the website above.
Provides explanations and procedures for operations, installation, connections among devices,
I/O adjustment and settings.
■Command guide (this document):
Provides explanations and procedures for external control using RS-232C and LAN communications.

NJR-TW01UHD/NJR-RW01UHD Command Guide
4
Table of Contents
1How to read this Guide .............................................................................................................................. 5
2About this Guide ........................................................................................................................................ 7
3Communication configuration and Specifications...................................................................................... 8
3.1 RS-232C communication...................................................................................................................... 8
3.1.1 RS-232C connector specification.................................................................................................. 8
3.1.2 RS-232C communication specification ......................................................................................... 8
3.2 LAN communication.............................................................................................................................. 9
3.2.1 LAN connector specification........................................................................................................ 10
3.2.2 LAN communication specification............................................................................................... 11
3.3 Controlled by IP-NINJAR Configurator............................................................................................... 11
3.3.1 Setting LAN communication........................................................................................................ 11
3.4 External control from NJR-CTB.......................................................................................................... 13
4Command................................................................................................................................................. 14
4.1 Summary............................................................................................................................................. 14
4.2 Command list...................................................................................................................................... 15
4.3 Setting items....................................................................................................................................... 17
4.4 Parameter input format....................................................................................................................... 18
4.5 Details of commands .......................................................................................................................... 20
4.5.1 Error status.................................................................................................................................. 20
4.5.2 Basic setting................................................................................................................................ 21
4.5.2.1 Setting input........................................................................................................................ 21
4.5.2.2 Setting output...................................................................................................................... 23
4.5.2.3 Audio setting....................................................................................................................... 26
4.5.2.4 Setting EDID....................................................................................................................... 28
4.5.2.5 Setting RS-232C................................................................................................................. 34
4.5.2.6 Setting LAN......................................................................................................................... 35
4.5.2.7 Advanced setting................................................................................................................ 37
4.5.2.8 Information.......................................................................................................................... 38

NJR-TW01UHD/NJR-RW01UHD Command Guide
5
1 How to read this Guide
This guide explains commands for the NJR-W01UHD.
■LAN model and RS-232C model
Cable
NJR-TW01UHD
NJR-RW01UHD
Control
Model
Model
Multimode fiber
RS-232C
NJR-TW01UHD-MM-232
NJR-RW01UHD-MM
LAN
NJR-TW01UHD-MM-LAN
Singlemode fiber
RS-232C
NJR-TW01UHD-SM-232
NJR-RW01UHD-SM
LAN
NJR-TW01UHD-SM-LAN
The NJR-TW01UHD LAN models and NJR-RW01UHD control commands from IP-NINJAR Configurator or
NJR-CTB via LAN.
The both NJR-TW01UHD and NJR-RW01UHD do not support command control of RS-232C communication.
The RS-232C communication is for command transmission (pass through).
Perform command control of NJR-TW01UHD (RS-232C model) from NJR-RW01UHD or IP-NINJAR device
connected to 10 GbE switch.
For other products of IP-NINJAR series, see “[Table 1.1] Document for IP-NINJAR products”.
IP network
Fiber optic cables
Source device
HDMI
NJR-TW01UHD
Source device
HDMI
NJR-T01UHD
NJR-RW01UHD
HDMI
NJR-R01UHD
HDMI
4K monitor
Monitor
PC for control
(For NJR-CTB)
LAN
LAN
IP-NINJAR
Management &
Control Platform
(NJR-CTB)
PC for control
(For IP-NINJAR Configurator)
LAN
4K@60
1080p
4K@60
1080p
Chapter 2 to 4
Chapter 2 to 4
(NJR-CTB Command Guide)
10 GbE switch
[Fig. 1.1] Document structure

NJR-TW01UHD/NJR-RW01UHD Command Guide
6
[Table 1.1] Document for IP-NINJAR products
Model User Guide Command Guide
NJR-T01UHD/NJR-R01UHD NJR-T01UHD/NJR-R01UHD
User Guide
NJR-T01UHD/NJR-R01UHD
Command Guide
NJR-TW01UHD/NJR-RW01UHD
NJR-TW01UHD/NJR-RW01UHD
User Guide
NJR-TW01UHD/NJR-RW01UHD
Command Guide
NJR-T01SDI NJR-T01SDI
User Guide
NJR-T01SDI
Command Guide
NJR-T04HD/NJR-R04HD
NJR-T04HD/NJR-R04HD
User Guide
NJR-T04HD/NJR-R04HD
Command Guide
NJR-AB08DAN
NJR-AB08DAN User Guide/Command Guide
NJR-CTB
NJR- CTB
User Guide
NJR- CTB
Command Guide
IP-NINJAR Configurator IP-NINJAR Configurator User Guide

NJR-TW01UHD/NJR-RW01UHD Command Guide
7
2 About this Guide
Communication commands enable the following main operations:
・Setting input, output
・Setting audio
・Setting EDID
・Displaying information

NJR-TW01UHD/NJR-RW01UHD Command Guide
8
3 Communication configuration and Specifications
3.1 RS-232C communication
The NJR-TW01UHD (RS-232C model) and NJR-RW01UHD support command transmission (pass through)
via RS-232C communication.
【4.5.2.5 Setting RS-232C】
3.1.1 RS-232C connector specification
RS-232C pin assignments:
5
1
9
6
Male D-Sub (9 pin)
RD
TD
N.C.
N.C.
N.C.
N.C.
GND
RTS
CTS
Pin No.
1
3
2
4
6
5
7
9
8
Signal name
RD
TD
N.C.
N.C.
N.C.
N.C.
GND
RTS
CTS
Signal name
(Receive Data)
(Transmit Data)
(Ground)
(Request to Send)
(Clear to Send)
NJR-W01UHD
Cross cable
Control device
(Not Connected)*
(Not Connected)*
(Not Connected)*
(Not Connected)*
*Not used
[Fig. 3.1] RS-232C connector
3.1.2 RS-232C communication specification
[Table 3.1] RS-232C specification
Compliant standard
RS-232C
Baud rate
9600 [bps]
Data bit length
8 [bit]
Parity check
None
Stop bit
1 [bit]
X parameter
Invalid
Flow control None
Communication method Full duplex

NJR-TW01UHD/NJR-RW01UHD Command Guide
9
3.2 LAN communication
The NJR-TW01UHD (LAN model) and NJR-RW01UHD can be controlled from IP-NINJAR Configurator or
NJR-CTB via LAN.
Make sure not to form a loop by the NJR-TW01UHD (LAN model)/NJR-RW01UHD when connecting a LAN
cable to the NJR-TW01UHD (LAN model)/NJR-RW01UHD.
The NJR-TW01UHD (LAN model)/NJR-RW01UHD constantly send broadcast packet in order to notify status.
Broadcast storm: This problem occurs when a network system is overwhelmed by continuous broadcast
traffic or the like.
Note:
The terminal software cannot be used.

NJR-TW01UHD/NJR-RW01UHD Command Guide
10
3.2.1 LAN connector specification
Pin assignment of the LAN connector is as follows.
Since Auto MDI/MDI-X that distinguishes and switches straight/cross cables automatically is supported, extra
care is not necessary to connect the NJR-TW01UHD (LAN model)/NJR-RW01UHD to PC, HUB or the like.
1 8
*Not used
[Fig. 3.2] LAN connector
Pin No.
Signal name
MDI MDI-X
1000BASE-T 100BASE-TX/10BASE-T 1000BASE-T 100BASE-TX/10BASE-T
1 TRX+ (Transmitted &
Received data +)
TX+ (Transmitted data +) TRX+ (Transmitted &
Received data +)
RX+ (Received data +)
2 TRX- (Transmitted &
Received data -)
TX- (Transmitted data -) TRX- (Transmitted &
Received data -)
RX- (Received data -)
3 TRX+ (Transmitted &
Received data +)
RX+ (Received data +) TRX+ (Transmitted &
Received data +)
TX+ (Transmitted data +)
4 TRX+ (Transmitted &
Received data +)
N.C. (Not connected)* TRX+ (Transmitted &
Received data +)
N.C. (Not connected)*
5 TRX- (Transmitted &
Received data -)
N.C. (Not connected)* TRX- (Transmitted &
Received data -)
N.C. (Not connected)*
6 TRX- (Transmitted &
Received data -)
RX- (Received data -) TRX- (Transmitted &
Received data -)
TX- (Transmitted data -)
7 TRX+ (Transmitted &
Received data +)
N.C. (Not connected)* TRX+ (Transmitted &
Received data +)
N.C. (Not connected)*
8 TRX- (Transmitted &
Received data -)
N.C. (Not connected)* TRX- (Transmitted &
Received data -)
N.C. (Not connected)*

NJR-TW01UHD/NJR-RW01UHD Command Guide
11
3.2.2 LAN communication specification
[Table 3.2] Specification of LAN communication
Physical layer 10Base-T (IEEE802.3i)/100Base-TX (IEEE802.3u)/
1000Base-T (IEEE802.3ab)
Network layer ARP, IP, ICMP
Transport layer UDP
3.3 Controlled by IP-NINJAR Configurator
The NJR-W01UHD can be controlled from IP-NINJAR Configurator by connecting a control device to the
NJR-TW01UHD (LAN model) or NJR-RW01UHD via a LAN cable.
Control the NJR-TW01UHD (RS-232C model) using the IP-NINJAR Configurator from NJR-RW01UHD or
IP-NINJAR device connected to 10 GbE switch.
For operations from the IP-NINJAR Configurator, refer to the User Guide of IP-NINJAR Configurator.
The IP-NINJAR Configurator can be downloaded from
http://www.idkav.com
3.3.1 Setting LAN communication
Follow the procedure below to control the NJR-TW01UHD (LAN model) or NJR-RW01UHD:
(1)Connect the control device to the LAN connector of the NJR-TW01UHD (LAN model) or NJR-RW01UHD
through a LAN cable
(2)Start the IP-NINJAR Configurator in the control device
(3)Send communication command from the Maintenance page of the IP-NINJAR Configurator
You can control the NJR-TW01UHD (LAN model) or NJR-RW01UHD and get the status information using
communication command

NJR-TW01UHD/NJR-RW01UHD Command Guide
12
EDID emulator
NJR-TW01UHD (LAN model)
D/A conversion
Audio D
*1
PC for control
HDMI INPUT
HDMI OUTPUTAUDIO OUTPUT
TX
LAN
NJR-RW01UHD
Step (1)
LAN cable
Video/Audio D
*1
Video/Audio D
*1
HDMI OUTPUT AUDIO OUTPUTRS-232CLAN
Step (2)
Step (3)
Communication
command * PCs can control both NJR-TW01UHD (LAN model) and NJR-RW01UHD by connecting to
either NJR-TW01UHD or NJR-RW01UHD.
LAN connector
Audio A
*2
Audio D
*1
Video/Audio D
*1
D/A conversion
Audio A
*2
or D
*1
Fiber optic
cables
NJR-TW01UHD (LAN model) or NJR-RW01UHD
RX
HDMI receiver HDMI transmitter
HDMI transmitter
*1 Audio D
: Digital audio
*2 Audio A : Analog audio
[Fig. 3.3] LAN communication setup
①For entering the desired command
②For sending the command to NJR-TW01UHD or NJR-RW01UHD
④For deleting the log
③For displaying the log
①
②
④
③
[Fig. 3.4] Command input from Maintenance page

NJR-TW01UHD/NJR-RW01UHD Command Guide
13
3.4 External control from NJR-CTB
Connect a control device to the NJR-CTB via a LAN cable to control the NJR-W01UHD using communication
commands.
Control the NJR-TW01UHD (RS-232C model) using the NJR-CTB from NJR-RW01UHD or IP-NINJAR device
connected to 10 GbE switch.
Control the NJR-TW01UHD (RS-232C model) using the IP-NINJAR Configurator from NJR-RW01UHD or
IP-NINJAR device connected to 10 GbE switch.
For operations from the NJR-CTB, refer to the Command Guide of NJR-CTB.
MAINTENANC connector
Tablet
MAINTENANCE
NJR-CTB
PC for control
LAN cable
*2
Communication
command
TCP: 1100
Command
server
WEB server
Browser
HTTP: 80
LAN
LAN connector
HUB
LAN cable
*1
10 GbE switch
Fiber optic
cables
LAN connector
NJR-TW01UHD or NJR-RW01UHD
NJR-CTB
NJR-TW01UHD
NJR-TW01UHD NJR-RW01UHD
NJR-RW01UHD
Fiber optic
cables
*1
The LAN connector of NJR-CTB should be connected to the LAN connector of NJR-TW01UHD (LAN model)/NJR-RW01UHD or the 10 GbE switch
*2
PC for control should be connected to the MAINTENANCE connector of NJR-CTB or the LAN connector of NJR-TW01UHD (LAN supported model)/NJR-RW01UHD
[Fig. 3.5] Connecting to NJR-CTB

NJR-TW01UHD/NJR-RW01UHD Command Guide
14
4 Command
4.1 Summary
A command consists of “@” (“40” in hexadecimal), 3 or 4 one-byte alphabetical characters (upper and lower
cases) followed by parameters (one-byte numbers). For some commands, multiple parameter values can be
specified. Processing is executed by sending a delimiter at the end of the command.
Example:@SDT,1,1,1,10000
“,” (a comma, “2C” in hex) is indicated between a command and parameter and between two parameters.
“ ” is indicated as a delimiter CR LF (return+line feed, “0D” and “0A” in hex).
■If an error occurs:
An error response is returned if an undefined command or inappropriate parameter is included.
Example:@SDT,1
@ERR,1
■Using as HELP
If only delimiter is sent, command list as the help command is returned.
Example:
---------------- HELP (1/2) ---------------
(INPUT SETTING Command)
@GDT / @SDT : Getting/Setting No-signal input monitoring
Signal Detect Time
@GHE / @SHE : Getting/Setting HDCP input enabled/disabled
(OUTPUT SETTING Command)
@GDM / @SDM : Getting/Setting Output mode
(AUDIO Command)
@GAM / @SAM : Getting mute status of digital audio output
Muting/unmuting digital audio output
-------------------------------------------

NJR-TW01UHD/NJR-RW01UHD Command Guide
15
4.2 Command list
■Error status
Command Function Page
@ERR
Error status
20
■Setting input
Command Function Page
@GDT / @SDT No-signal input monitoring 21
@GHE / @SHE HDCP input enabled/disabled 22
■Setting output
Command
Function
Page
@GDM / @SDM
Output mode
23
@GEN / @SEN HDCP output 24
@GHM / @SHM Hot plug ignoring duration 25
■Setting Audio
Command
Function
Page
@GAM / @SAM
Muting/unmuting digital audio output
26
@GAAS / @SAAS
Output audio
27
■Setting EDID
Command Function Page
@GVF / @SVF
EDID resolution
28
@RME
Copying EDID
29
@GWX / @SWX
Selecting WXGA mode
29
@GDI / @SDI
Deep Color input
30
@GAF / @SAF
Audio format
31
@GSP / @SSP
Speaker configuration
32
■Setting RS-232C
Command Function Page
@GCTB / @SCTB RS-232C communication 34
■Setting LAN
Command Function Page
@GIP / @SIP LAN 35
@GMC MAC address 36
■Advanced setting
Command
Function
Page
@CLRC
Initialization
37
@RBTC
Reboot
37

NJR-TW01UHD/NJR-RW01UHD Command Guide
16
■Information
Command
Function
Page
@GSS
I/O status
38
@GES
Monitor EDID
41
@GIV Version 43

NJR-TW01UHD/NJR-RW01UHD Command Guide
17
4.3 Setting items
Some setting items can be controlled via commands/GUI operation; the others cannot be controlled.
[Table 4.1] Available setting method
Command: Command input, GUI: GUI operation, WEB&C: WEB browser and command input, No: Not supported, -: N/A
Command
Setting method
NJR-TW01UHD
NJR-RW01UHD
NJR-CTB
LAN
(IP-NINJAR Configurator) LAN
Setting input
@GDT / @SDT Command WEB&C
@GHE / @SHE Command WEB&C
Setting output
@GDM / @SDM
Command
WEB&C
@GEN / @SEN
Command
WEB&C
@GHM / @SHM
Command
WEB&C
Setting Audio
@GAM / @SAM
Command
WEB&C
@GAAS / @SAAS
GUI
WEB&C
Setting EDID
@GVF / @SVF
Command
WEB&C
@RME
Command
WEB&C
@GWX / @SWX
Command
WEB&C
@GDI / @SDI
Command
WEB&C
@GAF / @SAF
Command
WEB&C
@GSP / @SSP Command WEB&C
Setting RS-232C
@GCTB / @SCTB GUI WEB&C
Setting LAN
@GIP / @SIP GUI WEB&C
@GMC GUI WEB&C
Advanced setting
@CLRC
GUI
WEB&C
@RBTC
GUI
WEB&C
Information
@GSS
Command
WEB&C
@GES
Command
WEB&C
@GIV
Command
WEB&C

NJR-TW01UHD/NJR-RW01UHD Command Guide
18
4.4 Parameter input format
Parameter input formats are common for each setting.
If a command is input from the LAN connector of the NJR-TW01UHD (LAN model) or NJR-RW01UHD using
the IP-NINJAR Configurator, “1” (fixed) is specified to “ch” (channel) because only one NJR-TW01UHD (LAN
model) or NJR-RW01UHD can be controlled.
If a command is input from the NJR-CTB, any channel can be specified because multiple NJR-W01UHD
devices that are connected over a network switch can be controlled.
Example:
Format
@SAM, device, ch, port, mute
Parameter
device: Model
1 = NJR-TW01UHD, 2 = NJR-RW01UHD
ch: Channel
1 to 512 = Channel 1 to Channel 512
If a command is input from the IP-NINJAR Configurator, “1” is set (fixed).
port: Connector
“1” fixed
mute: Audio mute
0 = Mute OFF [Default], 1 = Mute ON
PC for control
LAN cable
NJR-TW01UHD (LAN model)NJR-RW01UHD
Fiber optic cables
@SAM,1,1,1,1
@SAM,2,1,1,1
[Fig. 4.1] Command input from IP-NINJAR Configurator

NJR-TW01UHD/NJR-RW01UHD Command Guide
19
10 GbE switch LAN cable
Fiber optic cables
@SAM,1,64,1,1
PC for control
NJR-TW01UHD NJR-RW01UHD
Input channel 1
LAN cable
NJR-TW01UHD NJR-RW01UHD
Input channel 64
Output channel 1
Output channel 64
@SAM,2,1,1,1
NJR-CTB
[Fig. 4.2] Command input from NJR-CTB

NJR-TW01UHD/NJR-RW01UHD Command Guide
20
4.5 Details of commands
4.5.1 Error status
@ERR
Error status
Description Response in case the command is not executed
Response
@ERR, error
Parameter error: Error status
1 = Erroneous parameter format or value
2 = Undefined command or wrong format
3 = Currently cannot be used
99 =Error other than errors above
Getting
example
Command
Response
@GAM
@ERR,1
Description Sending @GAM command
Parameter error
Remarks
－
